Condition: excellent (used), Year of construction: 2018, MAZAK QUICK TURN 200MSY Max. machining diameter: 380 mm Max. milling speed: 5,000 rpm Max. spindle speed, main spindle: 5,000 rpm Max. bar diameter: 65 mm The machine is equipped with: - CNC control: Mazatrol SmoothG Iijdoy Tbz Nspfx Aizob - Tool Eye - C-axis - C-axis - Y-axis - Automatic parts catcher - Interface for loader magazine - Reinforced coolant pump, 70 bar - Chip conveyor - Standard MAZAK tool package

Condition: excellent (used), Year of construction: 1999, 1. CNC turning center with dual spindle and dual turret, WT 250 NAKAMURA, manufactured in 1999, including: Iiodpsy Ta Iujfx Aizeb * 4 axes * 1 parts loader

Condition: excellent (used), Year of construction: 1998, 1. CNC turning center with twin spindle and twin turret, WT 250 NAKAMURA, manufactured in 1998, including: Iodpfjy Ta Ihox Aizoib * 4 axes * 1 MASTER 880 IEMCA bar feeder

Condition: good (used), Year of construction: 2005, 1. 5-axis CNC turning center, TOME NTJ NAKAMURA model, year 2005. Iisdpjy Ta Hqsfx Aizsb 2. LNS bar feeder.

Condition: used, Year of construction: 2011, Technical details: standard turning dia.: 200 turning length: max. 810 mm control: MSX-701 MAPPS IV greates pass round over bed: 800 mm Max. distance between centres: 1130 mm max. turning diameter: 320 mm max. workpiecediameter: 300 mm bar material dia.: 65 mm Traverse X-Axis 1: 210 Traverse X-Axis 2: 210 mm Traverse X-Axis 3: 210 mm Traverse Y-Axis 1: 110 (+65/-45) mm Traverse Y-Axis 2: 110 (+45,/-65) mm Traverse Z-Axis 1: 300 mm Traverse Z-Axis 3: 300 mm Traverse Z-Axis 2: 810 mm Traverse B-Axis: 870 mm turning speed range - spindle: 5.000 1/min Number of spindle speed ranges: 2 . spindle nose: JIS A2-6 spindle bore: 73 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° turning speed range - spindle: 5.000 1/min spindle nose: JIS A2-6 spindle bore: 73 mm bar material dia. max: 65/52 mm spindle bearing diameter: 120 mm Ijdjy S Tm Uopfx Aizsib C-Axis: 0,001 ° Number of Turrets: 3 . Number of tool stations: 16 x 3=48 pos Schank height for square tool: 20 mm Diameter of boring bar: 32 mm turret changing time (4-stations): 0,18 sec Number of driven tools: 16 x 3=48 pos max. spindle speed driven tools: 6.000 U/min. Rotary tool machining ability: M16 / Ø16 . rapid traverse X-axis: 30 m/min rapid traverse Y-axis: 20 m/min rapid traverse Z-axis: 50 m/min drive capacity - spindle motor: 25 / 22 kW power capacity - driven tools: 7,5 / 5,5 kW total power requirement: 92,7 kVA weight of the machine ca.: 9,4 t dimensions of the machine ca.: 4,0 x 2,8 x 2,4 m Accerories Chip conveyor Coolantsystem C-axis in main and sub spindle Y-axis 2 x part counter total counter tool setting Overhead partsgripper with conveyor belt. Spindle 1 Chuck SMW KNCS-N 210 / 52 mm Spindle 2 Collet Chuck Hainbuch Spanntop nova Kombi Axfix 65 Robot interface Lehmann Robot with parts belt for feeding and disposal CNC Turning- and Milling Center MORI SEIKI NZ 2000 T3Y2 The NZ2000 T3Y has 2 spindles and 3 turrets, and 2 turrets have the Y-axis function and built-in milling motors. This not only allows synchronized machining using 3 turrets, but also achieves heavy-duty cutting and high-speed machining using rotary tools thanks to the built-in motor turrets. For shaft parts loading and unloading there is a Lehmann Robot conveyor belts for loading and unloading. The machine can also be sold without robot. *

Condition: used, Year of construction: 1998, functionality: unexamined, Control system: FANUC Series 0i-T Swing over bed: 610 mm Swing over cross slide: 430 mm Max. turning diameter: 500 mm Max. turning length: 1500 mm Spindle bore: D102 mm Speed range: 50 – 2800 rpm Feed range: 1 – 10,000 mm/min Rapid traverse (X / Z axes): X: 10 m/min, Z: 15 m/min Spindle nose: A2-11Turret: 12 stations Tool holder: VDI50 Tailstock sleeve: MT6 Drive power: 26 kW Power requirement: 36 kW Weight: 11,500 kg Dimensions LxWxH: 4200 x 2200 x 2100 mm Accessories, Equipment - Chip conveyor - Coolant system - Tailstock - Transformer - Electronic handwheel (MPG) - Tool setter (tool measuring arm) The machine is ready for operation. Iedpey S Tbfjfx Aizeib

Condition: excellent (used), Year of construction: 2012, HAAS ST-10Y cnc lathe with C-axis, Y-axis Year: 2012 Technical details: Chuck Size 165 mm Max Part Swing max 419 mm Max Cutting Diameter 279 mm Max Cutting Length (varies with workholding) 406 mm Bar Capacity 44 mm Travels X Axis 200 mm Y Axis ± 51 mm Z Axis 406 mm Feedrates Rapids on X,Y 12.0 m/min Rapids on Z 30.5 m/min Spindle Nose A2-5 Max Rating 15.0 hp 11.2 kW Max Speed 6000 rpm Max Torque 102.0 Nm on 1300 rpm Draw Tube Bore ø 46 mm Spindle Bore ø 58.7 mm Main Spindle C Axis Positioning (±) 0.02 ° 0.02 ° Brake Holding Torque 190 Nm Control Type Interpolated Motion and Positioning Tailstock Taper MT3 Hydraulic Quill Travel 95 mm Manual Body Positioning 508 mm Turret 12 positions Live Tooling Max Speed 4000 rpm Tooling BMT45 Coolant Capacity 114 L Weight 3600 kg Ijdpfx Aey S S I Rjizeib Accessories/options: - complete with C-axis and Y-axis - driven tool holders, 2 axial and 2 radial - swarf conveyor - hydraulic chuck - collet type chuck - static tool holders, 10 pieces - parts catcher - tool measuring arm - foot pedals for chuck and tailstock operating Under power in our warehouse, possible to test it anytime!

Condition: ready for operation (used), Year of construction: 1999, operating hours: 12,500 h, functionality: fully functional, controller model: OSP 7000M, Equipment: chip conveyor, TECHNICAL DETAILS Tool changer: 24 BT40 MACHINE DETAILS Control system: OSP 7000M HS: Big Bore Ijdpfxsy S Sw Eo Aizoib GS: Standard Bore Coolant pump: 8 bar Spindle hours: 12,500 h EQUIPMENT Chip conveyor

Condition: ready for operation (used), Year of construction: 2008, operating hours: 13,900 h, functionality: fully functional, turning diameter: 630 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 935 mm, controller model: Okuma OSP P200L, TECHNICAL DETAILS Swinging diameter over slide: 630 mm Machining diameter: 630 mm Distance between centers: 900 mm Travel range X-axis: 580 mm Travel range Y-axis: 160 mm Travel range Z-axis: 935 mm Travel range W-axis: 1,000 mm Travel range C-axis: 360° Travel range B-axis: -30° to 195° Main spindle: 3,800 rpm Counter spindle: 5,000 rpm Milling spindle: 6,000 rpm Rapid traverse X-axis: 40,000 mm/min Rapid traverse Z-axis: 40,000 mm/min Rapid traverse Y-axis: 26,000 mm/min Rapid traverse W-axis: 20,000 mm/min Rapid traverse C-axis: 200 rpm Rapid traverse B-axis: 30 rpm Tool diameter max.: 90 mm Tool diameter without neighboring tools max.: 130 mm Tool length max.: 300 mm Tool weight max.: 10 kg MACHINE DETAILS Number of axes: 6 Control: Okuma OSP P200L Dimensions & Weight Footprint: 4,340 × 2,050 mm Iiedey S Swxopfx Aizeb Height: 2,600 mm Weight: 10,300 kg Spindle hours: 13,900 h EQUIPMENT Documentation/Manual Speed infinitely adjustable Marpos tool sensor Chip conveyor & coolant system with small band filter system ATC 60 system HSKA-63 (60 tools)

Condition: as good as new (ex-display), Year of construction: 2021, operating hours: 10 h, functionality: fully functional, Swing diameter over bed: 550 mm Max. machining length: 428 mm Max. machining diameter: 300 mm Spindle bore: 62 mm Bar machining: 51 mm Spindle nose: A2-6 Motor spindle speed range: 35 - 5000 rpm X-axis travel: 210 mm Z-axis travel: 561 mm Tool changer for powered tools: 12 Tool changer locking: hydraulic Tool changer drive: servo Tool change time: 0.2 seconds Tool holder: cross-section 25 mm Max. speed of powered tools: 5000 rpm Max. power of powered tools: 5 kW Max. milling capacity, shank cutter: 16 mm Max. milling capacity, cutter head: 50 mm Max. drilling capacity: 16 mm Max. threading capacity: M16x2 Rapid traverse rate, Z-axis: 30 m/min Rapid traverse rate, X-axis: 30 m/min Positioning accuracy: 0.008 mm Repeatability: 0.003 mm Tailstock: programmable Arbor mount: Morse taper 4 Tailstock travel including quill travel: 565 mm Hydraulic unit tank capacity: 20 L Ijdpey S R Tlefx Aizeib Hydraulic unit pump output: 1.5 kW Hydraulic unit nominal pressure: 3.5 - 6 MPa Central lubrication tank capacity: 2 L Central lubrication output: 25 W Coolant tank capacity: 130 L Coolant pump output: 25 W Continuous motor power: 11 kW 400 V 50 Hz Short-term motor power (30 min): 15 kW 400 V 50 Hz Weight: 4,000.00 kg Dimensions: 2600 x 1685 x 1768 mm Machine scope of delivery: Coolant system, extraction system with filter, tool changer for 12 powered tools, 200 mm hydraulic chuck, Siemens 828D control, 17" touchscreen, programmable tailstock, Renishaw measuring arm, chip conveyor, German operating manuals, CE declaration of conformity.

Condition: ready for operation (used), Year of construction: 2005, operating hours: 10,223 h, functionality: fully functional, machine/vehicle number: 1278R18TBF, turning length: 720 mm, turning diameter over cross slide: 530 mm, turning diameter: 320 mm, spindle speed (max.): 4,000 rpm, spindle bore: 65 mm, travel distance X-axis: 270 mm, travel distance Y-axis: 120 mm, travel distance Z-axis: 720 mm, bar passage: 65 mm, total height: 2,100 mm, total length: 4,300 mm, total width: 2,000 mm, overall weight: 4,200 kg, number of tool stations in tool turret 3: 12, Due to business closure, an AMV Angelini Oscar turning machine with a Y-axis and counter-spindle is being sold. The machine is very well-equipped – with chucks for the main and counter-spindle, collet chucks (Hainbuch) for the main and counter-spindle, a parts catcher, and prepared for a bar feeder; it also includes a chip conveyor. High-pressure pump, 12 driven tool stations VDI30. Control system: Fanuc 21 I-TB series. Isdpfx Aiey S R Atjzeib A large number of accessories are included, such as turning tool holders and driven tools. The machine is still powered and can be inspected by appointment.

Condition: ready for operation (used), Year of construction: 2018, operating hours: 4,178 h, travel distance X-axis: 230 mm, travel distance Z-axis: 605 mm, overall weight: 5,600 kg, controller manufacturer: MAZATROL, controller model: Smooth Control, number of axes: 5, This 5-axis Mazak QuickTurn Smooth 200MSY was manufactured in 2018. It features a robust main spindle and sub spindle, along with live tooling capabilities. The machine has a weight of 5600 kg, ensuring stability during operation. If you are looking to get high-quality turning and milling capabilities, consider the Mazak QuickTurn Smooth 200MSY turn-mill centre we have for sale. Contact us for further details. • Control: Mazatrol Smooth Control • Machine Weight: 5600 kg Iiodpfx Aijy S A U Uozsb • Main Power Supply: 3AC 400V 50/60Hz • Control Circuit Voltage: AC 100V / DC 24V • Rated Capacity: 47.4 kVA • Main Motor Current: Max. 65 A • Pure Cutting Hours: 4178 h • Main Spindle: Yes • Sub Spindle: Yes • Y-Axis: Yes • Live Tooling: Yes • Machine Type: Turn-Mill Centre • including tools • The machine was serviced by the manufacturer on February 17, 2026, and has not been in operation since. Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: used, NAKAMURA-TOME NTRX 300 is a machining and turning center from bar, engineered for precision, high accuracy and reliable production. Main capacities: 6 axes (5 simultaneous), Z travel 1125 mm, X 700 mm, Y ±125 mm, B tilt 225°, C 360° resolution 0.001; workpieces up to 1100 mm length and Ø 640 mm; tool magazine 40 stations, tool Ø max 90 mm, tool length 300 mm. Technical specs: spindle nose Capto C6, main spindle up to 4500 rpm, milling spindle up to 8000 rpm, spindle motor 15/11 kW, rapid traverse 36 m/min, air 5–7 bar, 3x400 V 50 Hz, total power 65.1 kVA, weight ~18000 kg, footprint 4530×2670×2615 mm. Accessories: coolant system, paper filtration, toolholder set, milling cutters, drills, lamp, oil‑mist extractor, bar loader. Achieves tight tolerances; suited for automotive, aerospace, medical, watchmaking and machine‑tool sectors. Iodpfjy S A Rpex Aizjib

Condition: refurbished (used), Year of construction: 2000, functionality: fully functional, turning diameter over cross slide: 590 mm, turning diameter: 270 mm, spindle speed (max.): 3,500 rpm, travel distance X-axis: 215 mm, travel distance Y-axis: 180 mm, travel distance Z-axis: 950 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 7 m/min, rapid traverse Z-axis: 20 m/min, rotational speed (max.): 6,000 rpm, type of input current: three-phase, bar diameter (max.): 90 mm, overall weight: 9,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, We are offering this INDEX G300Y/B CNC turning and milling center, manufactured in 2000 and completely overhauled in 2020, for sale. Machine type: INDEX G300Y/B Machine number: 500087 Overhauled: 04/2020 Power supply: 3~ Voltage: 400 V Frequency: 50 Hz Control voltage: 24 V Rated current: 120 A Please refer to the attached PDF for detailed technical data. The machine includes a parts handling system with a conveyor belt on the counter-spindle side. The electrical system has been completely renewed, and the machine is running on Sinumerik one. We acquired this machine to gain initial experience in the field of turning/milling centers. We are now acquiring a new machine, and once it is installed and in production (Q4/2026), the G300 will be available for sale. Iiedoy Sz Akjpfx Aizeb If you have any questions or require further information, please feel free to send us a message or call us.

Condition: excellent (used), Year of construction: 2012, operating hours: 10,168 h, functionality: fully functional, machine/vehicle number: NL254120635, CNC turning machine Manufacturer: DMG MORI Type: NLX 2500 SY 700 with WH10 automation Year of manufacture: 2012 Turning diameter: 460 mm Turning length: 795 mm Control system: MORI SEIKI M730 BM Diameter over cross slide: 590/360 mm Spindle bore: 80 mm Travel distances X/Z: 260/795 mm Total power consumption: 40 kVA Machine weight: approx. 6.4 t Space requirement: approx. 3.994 x 3.056 x 2.187 m Iedsy Szwhopfx Aizeib

Condition: excellent (used), Year of construction: 2015, operating hours: 6,147 h, functionality: fully functional, machine/vehicle number: 7023000088B, Machine type: CNC turning and milling center Manufacturer: DMG MORI Type: NLX2500SY/700 Year of manufacture: 2015 Control system: M730 UM Mapps CELOS Country of origin: Japan Delivery time: upon agreement Incoterms: EXW Additional information: CNC turning and milling center DMG MORI NLX2500SY/700 Maximum turning diameter: 356 mm Turning length: 705 mm Control system: M730 UM Mapps CELOS Swinging diameter over bed: 920 mm Swinging diameter over cross slide: 742 mm Spindle speed range - main spindle: 4,000 min/-1 Drive power - main spindle: 18.5 / 15 kW Spindle nose: JIS A2-8 Spindle bore: 80 (91) mm C-axis: 0.001° Spindle speed range - counter spindle: 6,000 min/-1 Drive power - counter spindle: 11 / 7.5 kW Spindle bore: 43 mm C-axis: 0.001° X-axis travel: 260 mm Z-axis travel: 795 mm Y-axis travel: +/- 50 mm Rapid traverse (X / Y / Z): 30 / 10 / 30 m/min Number of tool positions: 12 Shank height for square tools: 25 mm Shank diameter of drills: 50 mm Turret indexing time: 0.27 sec. Spindle speed range - driven tools max.: 10,000 min -1 Drive power - driven tools: 5.5 / 4.2 kW Total power consumption: 41 kVA Machine weight: approx. 6.4 t Space requirement: approx. 5.0 x 3.0 x 2.3 m CNC turning and milling center DMG MORI - NLX 2500 SY / 700 - Counter spindle Iisdey Sxukepfx Aizeb - Driven tool - C, Y-axis

Condition: used, Year of construction: 2006, Control system: Mazatrol 640 T Nexus Working area: - Max. swing diameter: 675 mm - Max. swing diameter over slide: 276 mm - Max. turning diameter: 380 mm - Max. turning length: 538 mm - Max. bar capacity: Ø 65 mm Main spindle: - Max. speed: 35–5,000 rpm - Main drive power, integrated spindle motor: 26 kW / 22 kW - Max. torque: 350 Nm - Spindle nose: A2-6" - Spindle bore: Ø 76 mm - Chuck diameter: Ø 210 mm - Indexing, C-axis: 0.001° Tool turret: - Number of tool stations: 12 Travel: - X-axis: 230 mm Iiodoy Sxkljpfx Aizob - Y-axis: 100 mm - Z-axis: 575 mm Coolant: - Tank capacity: 160 l Travel speeds: - Rapid traverse X-axis: 30 m/min - Rapid traverse Y-axis: 21 m/min - Rapid traverse Z-axis: 33 m/min Tailstock: - Mounting: MK 5 - Tailstock travel: 550 mm Scope of delivery: - Existing manuals as shown in the pictures - 8 driven tool holders - 13 static tool holders - LNS Quickload Servo III bar feeder - Coolant system - Chip conveyor Dimensions & Weight - Approx. footprint L x W x H: 6015 x 2000 x 1900 mm - Approx. weight: 5600 kg Control system: Mazatrol 640 T Nexus * Max. swing diameter: 675 mm * Max. turning diameter: 380 mm * Spindle nose: A2-6" * Max. turning length: 538 mm * Max. bar capacity: Ø 65 mm * Max. speed: 35–5,000 rpm * Max. torque: 350 Nm * Spindle bore: Ø 76 mm * Indexing, C-axis: 0.001° * X-axis: 230 mm * Y-axis: 100 mm * Z-axis: 575 mm * Tank capacity: 160 l * Rapid traverse X-axis: 30 m/min * Rapid traverse Y-axis: 21 m/min * Rapid traverse Z-axis: 33 m/min * Mounting: MK 5 * Tailstock travel: 550 mm * Approx. weight: 5600 kg

Condition: excellent (used), Year of construction: 2007, operating hours: 7,690 h, functionality: fully functional, machine/vehicle number: NL301GJ1021, Technical data - MORI SEIKI NL3000Y/1250 Operating hours: 7,690 h Year of manufacture: 11/2007 Number of axes: 5 X-axis travel: 280 mm Y-axis travel: 120 mm Z-axis travel: 1,300 mm Spindle bore: 105 mm Number of tools: 12 Spindle power: 22 kW Spindle speed: 3,000 RPM Iisdpfoy Sxh Dsx Aizsb Swing over bed: 995 mm Swing over cross slide: 825 mm Maximum turning diameter: 420 mm Bar capacity: 90 mm Maximum turning length: 1,260 mm Milling motor power: 5.5 / 3.7 kW, speed 6,000 RPM Rapid traverse rates (XZ): 30 m/min Tailstock body travel: 1,284 mm Tool setter, 3-jaw chuck, coolant system, interlocked safety guards, low-voltage lamp Dimensions (approx.): L x W x H: 5,200 x 3,400 x 2,270 mm Weight approx. 8,100 kg

Condition: good (used), Year of construction: 2007, SPINNER TC110L-MCY Powerful, used CNC turning and milling center with C/Y-axis for complex machining operations with driven tools. Year of manufacture: 2007 Control: SIEMENS 840DE sl ShopTurn X – 350 mm Y – 230 mm (-115/+115 mm) Z – 1,840 mm C-axis Swing diameter up to 690 mm Spindle 26 kW with 2-speed gearbox Speeds up to 3,200 rpm Spindle bore 110 mm Equipment: Turret make BARUFFALDI type TBMR250-12 with 12 stations, completely overhauled in 2024 Driven tools up to 4,000 rpm VDI 50 tool holders Hydraulic steady rest by SMW Hydraulic three-jaw chuck by SMW with 315 mm diameter Oil mist extraction system by IFS model M1600, year 2012 Hinged belt chip conveyor by KNOLL, model S-1/50 Paper belt filter system by KNOLL, model KF150/700 High-pressure coolant pump Electronic handwheel Foot switch Including: Operating manual/documentation Technical Data & Transport – see PDF. All technical data, images, and contents are non-binding and without guarantee. Subject to change and error. All other accessories visible in the photos and videos are not included in the scope of delivery, and are therefore not part of this sale. The scope of delivery only includes accessories explicitly stated here, in the order confirmation, or invoice. FCA (Free Carrier, loaded on truck) D-Traunstein Packaging only Delivery time: immediately Iiodpey Sxbwefx Aizsb Subject to prior sale / Payment due upon conclusion of purchase

Condition: excellent (used), Year of construction: 2008, HYPERTURN 665 MCplus - Y Multi-axis CNC turning center for complete machining of turning and milling parts, equipped with integrated spindle motors (ISM) on both main and sub-spindle, featuring a thermal compensation system (liquid-cooled). Drive power: Main spindle: 29 kW Sub-spindle: 22 kW Speed range: Main spindle: 0-5,000 rpm Sub-spindle: 0-7,000 rpm Spindle interface (DIN 55026): Main spindle: KK6 (max. bar capacity 65 mm) Sub-spindle: KK6 Y-axis: Travel range +/- 50 mm The Y-axis is engineered to distribute resultant cutting forces over two axes, providing exceptional rigidity for all machining operations. All linear axes feature preloaded roller guides, a digital drive system, integrated spindle encoder, and state-of-the-art SINUMERIK 840D control. Includes: * Hollow clamping cylinder with draw tube * Parts ejector and flushing system through the sub-spindle * 2 x 12-position VDI 30 tool turrets, radial mounting with direction logic, accommodating up to 2 x 12 driven tooling stations * Swivel speed adjustable via feed selector Performance data: Max. 6.7 kW at 2,650 rpm Constant torque: 25 Nm Speed range: 0-5,000 rpm - C-axis for main and sub-spindle - TRANSMIT software for simple C-axis programming * Finished parts unloading device * Sinumerik 840D * Chip conveyor with programmable discharge height of 1,200 mm (hinged belt type) * Integrated coolant system in the chip conveyor: 2 high-pressure pumps at 14 bar 2 rinsing pumps at 3.7 bar * Electrical cabinet cooling unit * Electrostatic oil mist separator * Hydraulic unit * Machine light * Documentation IMPORTANT: Export/re-export from the EU requires an export license R7AW2001 – Year of manufacture: 2008 Including: S6Z170 PC keyboard Siemens R7Z460 Machine installation and mounting hardware X1Z100 EMCO standard bar feeder interface R7Z030 Alarm lamp Iedpfx Aey Svz Ieizjib R7Y750 Finished part transfer conveyor, crosswise S6Z900 EMCO TOPLOAD 10-65/3300 R7Z620 Automatic tool setter – HT665 S6Z110 Setting gauge VDI 30 + Various static and driven tool holders + Clamping devices for main spindle and sub-spindle

Condition: good (used), Year of construction: 2005, operating hours: 9,999 h, functionality: fully functional, SPINNER Werkzeugmaschinenfabrik GmbH Used CNC Lathe Model: SPINNER UP65 Year of manufacture: 2005 Control: Siemens Sinumerik 840 Main spindle + counter spindle Sauter turret with driven tools Operating hours: 80,412 h Accessories: 3 driven tools, 10 standard tools with holders, 8 empty holders CE certified Buffer battery last changed in March No chip conveyor Typical technical specifications of the SPINNER UP65: • Max. turning diameter: approx. 300–400 mm • Max. turning length: approx. 600–1,000 mm • Swing over bed: approx. 500–600 mm • Spindle bore: 65 mm main spindle • Main spindle speed: approx. 4,000–5,000 rpm • Counter spindle speed: up to approx. 6,000–7,000 rpm • Main spindle drive power: approx. 15–22 kW • Turret: Sauter tool turret with driven tools • Tool holder: typically VDI30 • Travel paths: X approx. 200–250 mm, Z approx. 600–1,000 mm • Rapid traverse: X approx. 20 m/min, Z approx. 24 m/min Iodsy Sr Iqspfx Aizsib • Control: Siemens Sinumerik 840 • Machine weight: approx. 4,500–6,500 kg Chucks: • Main spindle: Ø160 with Ø81, through bore Ø60 • Counter spindle: Ø160 with Ø43

Condition: used, Year of construction: 2011, controller manufacturer: Siemens, controller model: C200-4D SL, _____ Description: Year of manuf. : 2011 Control : Siemens C200-4D SL In General: Year of construction:2011 Control system:Siemens 840 Dsl (C200-4D SL) Bar capacity:65 mm Milling spindles:18,000 rpm Main spindle: Technology:Motorised spindle Speed:5,000 rpm Max. power:35.5 kW Torque max.:170 Nm C-axis:0.001° Z-axis:390 mm Bar capacity:65 mm Clamping cylinder:Hollow clamping cylinder Chuck:3-jaw chuck Sub spindle: Technology:Motorised spindle Speed:5,000 rpm Max. power:35.5 kW Torque max.:170 Nm C-axis:0.001° X-axis:600 mm Z-axis:390 mm Bar capacity:65 mm Chuck:3-jaw chuck Tool carrier I: Technology:Milling spindle on cross slide Speed:18,000 rpm Tool holder:HSK 40 X-axis:350 mm Y-axis:160 mm (+/- 80 mm) B-axis:230° Tool carrier II: Technology:Milling spindle on cross slide Speed:18,000 rpm Tool holder:HSK 40 Y-axis:160 mm(+/- 80 mm) B-axis:230° Tool magazin: Technology:Chain magazine Number of stations:80 pieces Tool changer:Double gripper Tool length max.:180 mm Equipment: Chip disposal:Chip conveyor Iedpfx Aijy Sq T Sszoib Coolant supply:IKZ system with filter Parts removal:Gantry-type pick-up

Condition: used, Year of construction: 2005, machine/vehicle number: ZT151AEG0163, CNC control MORI SEIKI MSX-501, 2 turrets each with 16 tool stations, driven tools, 2 spindles, bar capacity 52 mm, max. speed 6,000 rpm, max. turning diameter 190 mm, max. turning length 450 mm, Y-axis +/- 40 mm, machine weight 5,100 kg, chip conveyor Isdpjy Sqhpjfx Aizjib

Condition: excellent (used), Year of construction: 2006, x-travel 750 mm y-travel 210 mm z-travel 1150 + 100 mm control Fanuc MSX-701III Maximum turning diameter 660 mm Max. turning length 1498 mm Diameter over cross slide max. 400 mm number of spindle speeds 3000 U/min tool piece magazine with 40 Plätzen turret 10 Fach Iodpfxsy Spuus Aizeib total power requirement 90 kVA weight of the machine ca. 26,6 t dimensions of the machine ca. 5301 x 2997 x 2788 mm

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot Iiodpfxsy Snkue Aizsb CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler
