Condition: used, Punching Machine MUHR & BENDER - MUBEA Type KL 350 / 203 Machine No. Year of manufacture 19 Punching force 35 tons Throat depth 203 mm Ram stroke 22 mm Capacity Ø 28 mm in 10 mm sheet (at 450 N/mm²) Ø 23 mm in 12 mm sheet (at 450 N/mm²) Ram plate 117 x 70 mm Table plate 175 x 100 mm, thickness 100 mm Drop-through opening in table cutout Ø 56 mm Stroke release Single stroke via foot switch Itsdpfxsyvvkws Abcsd Motor power 1.5 kW Power supply 400 Volt, 50 Hz - Electric foot switch for stroke release - Manual lever positioning device for punch movement - Equipped with a Ø 8 mm punching tool - Support tables approx. 270 x 230 mm each on left and right of punching unit - Metal base frame Space requirement L x W x H 750 x 720 x 1500 mm Weight 430 kg In very good condition

Condition: used, functionality: unexamined, Year of construction: 1986, machine/vehicle number: 1233, control type: manual, degree of automation: semi-automatic, actuation type: hydraulic, punching force: 20 t, type of input current: three-phase, Equipment: foot remote control, Used punching machine with a selection of diameters for round and square holes. Both the large and small punching machines, as well as the cabinet, are included. Each punching machine can be operated independently via foot pedal. Itsdpfx Abeyu Hqqjced

Condition: excellent (used), functionality: fully functional, Boschert EL 300 Itedpfsylmgajx Abcjd Throat depth 300 mm Trumpf tool system compatible up to size III 28 t punching force Large worktable with stops in X and Y

Condition: good (used), Year of construction: 1990, machine/vehicle number: X0006, Offer 25364 Itodpfox I Nc Rox Abced Technical Data: - Punching force: 200 kN - Max. sheet thickness: 6 mm - Max. punching diameter: 90 mm - Stroke: 42 mm - Throat depth: 400 mm - Maximum strokes per minute: 200 spm - Installation height: mm - Drive: 400 V / 3 kW - Required space approx.: W 1000 x H 1650 x D 1200 mm - Weight approx.: 1400 kg - Including: positioning table, quick-change punch device, foot switch, emergency stop switch, various punches and dies The machine can be inspected by appointment at the 63322 Rödermark site. Company Erich Mieth: Tel. 06074-90877 Monday - Friday: 9:00 am - 12:00 pm and 2:00 pm - 5:00 pm The price includes 19% VAT. You will receive an invoice with VAT shown separately. Sale to commercial customers only. Payment by bank transfer before collection of the machine.

Condition: good (used), Profile steel knife, shearing tool, cutting tool, separating tool, punching tool, punch, punch die, punch stamp -Manufacturer: WMW Smalcalda, shearing tool for square/round steel -Item No.: 5450 9/83 -Shearing tool for round steel: 25/40/55 mm Isdpjx I A Rzsfx Abcetd -Type: 4412151064 -Square steel: 34 x 34 mm -Round steel: Ø 19/29/37 mm -Number: 3x shearing tools available -Price: per piece -Dimensions: 200/160/H18 mm -Weight: 3.9 kg

Condition: good (used), Punch holder, die holder, notching tool, punching tool, punch, punch die, punching die, for eccentric press, hydraulic press -Stamp holder: with slotted punch tool, without die -Socket: Ø 51 mm / Bolt circle Ø 110x18 mm see photos -Punch tool: Slotted hole 22.5x50 -Dimensions: Ø 135 x 180 mm -Weight: 6.7 kg Itodpfx Abox Idm Recsd

Condition: good (used), Year of construction: 2010, machine/vehicle number: 792-128, Offer 25368 Technical data: - Pressing force at 10 bar 70 kN - Ram stroke 20 mm - Air consumption per stroke 10 l - Air supply 6 - 10 bar - Barcode scanner - Drive 220 V / 1 kW Itjdpfx Abjx E S Eiocsd - Space requirement approx. W 1000 x H 2100 x D 1200 mm - Weight approx. 450 kg - Feed station with decoiler 4000 mm - Discharge conveyor 1900 mm - Software manual PRS - AWS

Condition: used, functionality: fully functional, For sale is a MABI 8Z dished end punch which we used as a multi-hole punch. Itodpfex Dbunox Abcsd

Condition: good (used), Year of construction: 1998, Neat used punching machine from Euromac Itjdpfx Absxld R Ijced Type CX 1000 30 Capacity 30 ton Unloading 1000mm Overwrap up to 10000mm Including drawer cabinet with lots of tooling and multitool

Condition: used, Punching Machine MUHR & BENDER - MUBEA Model KL 350 / 203 Machine No. KL3509864 Year of manufacture: 1998 Punching force: 35 tons Throat depth: 200 mm Ram stroke: 22 mm Capacity: Ø 28 mm in 10 mm sheet (at 450 N/mm²) Ø 23 mm in 12 mm sheet (at 450 N/mm²) Ram plate: 265 x 70 mm Ram plate thickness: 25 mm outside / 50 mm in the center Table plate: 285 x 250 mm, thickness 40 mm Table cutout: 115 x 85 mm Drop-through opening in table cutout: 115 x 25 mm Installation height: 125 mm (with table and ram plate) Number of strokes: single stroke via foot switch Motor power: 1.5 kW Isdpfxoxf Utae Abcotd Power supply: 400 Volt, 50 Hz - Electric foot switch for stroke activation - Manual lever search device for punch movement - Special tool as punching tool Space required (L x W x H): 800 x 800 x 400 mm Weight without tool: 340 kg Weight with tool: 370 kg Good condition

Condition: used, Pneumatic punching unit TÜNKERS or DE-STA-CO, pneumatic power cylinder Pneumatic punching frame, punching frame, punching unit, punching frame Isdjxf Uqxspfx Abcetd Year of manufacture: 2019 Model No. 141-1040F Punching frame No. B-13-26/100 Punching force: 4 tons (40 kN at 8 bar) Air connection max. 8 bar Throat depth: 100 mm Frame width: 60 mm Hole diameter: Ø 2-13 mm Hole diameter (installed punch): Ø 4 mm Die diameter (outside): Ø 22 mm - Stripper with Vulkollan polyurethane elastomer Dimensions (L x W x H): 280 x 110 x 480 mm Weight: 36 kg very good condition

Condition: used, Punching force: 300 kN Itsdpfx Asxcndyjbcsd For example, punch a 20 mm hole in 12 mm steel Stroke triggering via foot switch Assortment of tools is included in the price

Condition: used, Punching force: 350 kN For example, punch a 23 mm hole in 12 mm steel Stroke triggering via foot switch Itodpjxcnccefx Abcjd Support table with folding cams Assortment of tools is included in the price

Condition: used, Punching Bracket, Punching Unit SUPRA-CLAP Type C12.300 Throat Depth: 300 mm Punching Capacity: 0.3 to 2 mm material thickness, depending on cutting clearance Hole Diameter: Ø 2 to Ø 12 mm Iedexbh Rdspfx Abcotd Distance between lower die and punch holder: 8.5 mm Distance between upper and lower bracket: 13 mm Punch Shank Diameter: Ø 12 mm Cutting Plate Outer Diameter: Ø 30 mm Cutting Plate Thickness: 12 mm Drop-through Opening in Punching Bracket: 14.5 mm Installation Height: approx. 145 mm - Standard punch length 70 mm with 60° head (Punch per DIN 9861 Form C) - Punch holder with spring stripper and return spring - Mounting slot 50 x 13.5 mm and 8 mm locating pin Punching Bracket Dimensions (L x W x H): 390 x 36 x 145 mm Weight: 4 kg Good condition 9 units available, price per unit 3 units with tool inserts (punch + die) 6 units without tool inserts (without punch + without die)

Condition: used, Punching bracket, punching unit SUPRA-CLAP / CEWE Type PAE 50 - 400 3GN 3P1 Throat depth: 400 mm Punching capacity: max. 10 mm material thickness Hole diameter: max. Ø 50 mm Distance between upper and lower bracket: 19 mm Punch holder: Ø 78 mm Cutting plate outer diameter: Ø 78 mm Cutting plate thickness: 20 mm Drop-out opening in punching bracket: 52 mm Installation height: approx. 220 mm - Punch holder as a punch unit with punch mount and material stripper with disc springs - Punch holder rotation-proof guided and spring-loaded - Punch length 97 mm, shank Ø 35 / 50 mm - Round hole tool: punch Ø 41 mm and die Ø 41.5 mm - Long fixing hole: 270 x 13.5 mm Dimensions of punching bracket (L x W x H): 550 x 95 x 220 mm Weight: 27.5 kg Good condition 4 units available, price per unit Iedpfxsxbh N Ts Abcstd 3 units with Ø 41 mm punch tool 1 unit with Ø 43 mm punch tool

Condition: used, Punching bracket, punching unit SUPRA-CLAP type C7 300 Throat depth: 300 mm Punching capacity: max. 2 mm material thickness Hole diameter: Ø 2 to Ø 7 mm Distance between lower die and punch holder: 7 mm Distance between upper and lower bracket: 12 mm Punch shank: Ø 7 mm Iodjxbh N Hspfx Abcotd Die outer diameter: Ø 20 mm Die thickness: 12 mm Pass-through opening in punching bracket: 11 mm Installation height: 142 mm - Standard punch length 70 mm with 60° head - Equipped with a round hole punch approx. Ø3 to 4 mm - Punch holder with stripping spring and return spring - Mounting slot 50 x 14 mm and 8 mm locating pin Dimensions punching bracket L x W x H: 390 x 26 x 145 mm Weight: 3.7 kg Good condition 13 pieces available, price per piece

Condition: ready for operation (used), pressure 30.0 t punching cross-cut in cmm 30.0 in 9.0 mm stroke ca. 35 Hub/min throat 610 mm stroke - stepless adjustable 0 - 28.0 mm oil volume 35.0 l work height max. 1010 mm total power requirement 4.0 kW weight of the machine ca. 1200 kg. range L-W-H 1400 x 700 x 1600 mm good condition (!!) with a lot of application tools (stamps/dies) Iedpsxaaipsfx Abcetd Furnishing: - electro-hydraulic hole punch, with large throat - Material/sheet metal scrapers including scraper plates - Large material support table, with adjustable depth stops - continuous stroke adjustment - freely movable foot switch including protective cover - Forklift pockets for easy transport - side storage area - lots of accessories + tools - including tool cabinet - Matrix base (for special size matrices) - Stamp holders (for special size stamps) - original user manuel

Condition: new, punching pressure 28.0 t punching cross-cut in cmm 31 in 7.0 mm ST throat 250 mm dayligth 223 mm no. of strokes 10 - 30 Hub/min oil volume 32.0 ltr. work height max. 1033 mm total power requirement 3.0 kW weight of the machine ca. 553 kg dimensions of the machine ca. 730 x 540 x 1530 m Furnishing: - Punch quick-change device up to Ø 31 mm - green series - installed: round punch no. 5 Ø 25.0 mm and round die no. 3 Ø 25.7 mm - Free: LED lighting in the punching area - Swiveling scraper (plates exchangeable) - Various material support tables are available separately - Brace - 2-step foot switch, with double press for grain search function - electrical controls - Stroke length and stroke position continuously adjustable - integrated hydraulic unit with oil filling - Performance specifications apply to a material strength of 450 N/mm² - Main connection cable and plug for 16 amps are not included in the scope Itedpfx Ajw U U S Nsbcsd of delivery

Condition: used, Year of construction: 2000, pressure 16 t throat 350 mm stroke 25 mm no. of strokes 200 - 1000 /min distance table/ram, max. stroke up, adjustment up 230 mm table surface area 480 x 280 mm Table height above floor 1050 mm ram surface 200 x 110 mm ram adjustment 25 mm diameter of blanks - 1800 mm no. of flutes 16 - 460 material thickness 2,0 mm distance between mid parts spindle and mid ram 160 - 680 mm power requirement 6,0 kW Weight 5,60 t Itedpfx Aow U Ekvobcsd dimensions of the machine (WxDxH) 1,4 x 2,9 x 2,4 m year of manufacture 1971 - new control 2000 with infinitely variable AC-drive, pneumatic clutch (Ortlinghaus), manual ram adjustment, electro-pneumatic blank clamping, automatic stripping device, intermittent control (ram lifting for idle stroke), fully automated centralized oil lubrication, two-hand operation, electrical control Siemens S 7 (yom 2000) various change wheels

Condition: good (used), We are offering several dies, punches, reducing sleeves, and a quick-release clamping set for Peddinghaus here. Exact details can be found in the PDF. Isdpfxew Trkge Abcotd

Condition: good (used), We are offering several dies, punches, reducing sleeves, and a quick-release clamping set for Peddinghaus here. Exact details can be found in the PDF. Itsdpfx Aow Tri Nebcjd

Condition: used, total length: 1,800 mm, total width: 1,000 mm, total height: 2,000 mm, Empty weight: 2.000 kg Price: On request Thickness 45 mm Maximum pressure 70 tons Punch cutting machine Model: Hydraulic Manufacturer: GEKA Type: Hydracrop 70S Power: 70 tons Cutting round: 45mm Cutting beam: 45mm Cutting plate: 450x15mm Iodpjw Ryxmjfx Abcstd Cutting corners: 250x6mm Incl. multiple punches Machine-afmetingen: 1800x1000x2000mm Machine weight: 2000kg - Documentation available: No - CE certificate present: No - Drive: Hydraulic - Punching force [ton]: 70 - Notching width [mm]: 250 - Max. plate thickness notching [mm]: 6 - Round bar cutting capacity [mm]: 45 - Shearing width [mm]: 450 - Max. plate thickness shearing [mm]: 15 - Transport dimensions: 1800mm x 1000mm x 2000mm (l x w x h) - Transport weight [kg]: 2000kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: new, functionality: unexamined, Year of construction: 2024, machine/vehicle number: 16.41-PS0382, control type: CNC control, degree of automation: automatic, actuation type: electric, sheet thickness (max.): 8 mm, input voltage: 400 V, input current: 20 A, type of input current: three-phase, 2024 Pima Power PS 1225 Brand new Complete machine. Machine was tipped on its side during transit and was damaged. Machine is stored in Our warehouse in California USA. Contact to set up in person inspection. Iedpfxsw Nbh Ho Abcetd

Condition: used, Year of construction: 2001, Combined punching machine with shear and automatic loading/unloading system – FINN-POWER SG + TRS6FB _____ Brand: FINN-POWER Model: SG + TRS6FB Year of manufacture: 2001 Machine weight: 22,000 kg Punching force: 300 kN Shearing force: 250 kN Max. working pressure: 300 bar Description: CNC combination punching machine + corner shear, complete with: • automatic loading system with sheet metal storage • CNC rotary turret • integrated corner shear • conveyor belts for unloading Itsdpfow Iflmox Abcod • soundproof cabin and safety guards • dedicated Finn-Power CNC The machine is currently installed and can be inspected by appointment. Condition: • Immediately available 📍 Location: Italy _____

Condition: not inspected (used), functionality: unexamined, machine/vehicle number: 4203773681008, table length: 1,400 mm, table width: 600 mm, No reserve price – guaranteed sale to the highest bidder! Placing a bid obligates the buyer to collect the machine within the specified period from 28/07/2025 to 31/07/2025. TECHNICAL DETAILS Table dimensions: 1,400 x 600 mm Motor: 11.4 kW MACHINE SPECIFICATIONS Overall width: 2,500 mm Overall length: 2,200 mm Overall height: 2,000 mm Total weight: 1,500 kg Operating voltage: 380 V Frequency: 50 Hz Rated current: 25 A Control voltage: 220 V with transformer Auxiliary voltage: 24 V Breaker rated short-circuit current: 0.165 kA Documents and Numbers Control number: 42037.301.01.00 Wiring diagram: 42037.301.01.01 Serial number: 42037.736.81.008 Iedpewvi N Tofx Abcstd
