Condition: used, Year of construction: 2008, Equipment: documentation/manual, Control: Syntec-Mitsubishi Main spindle bore: 36 mm Spindle power: 7 kW Speed: 1–6'000 rpm X-axis: 185 mm Tedpfxjz Hdb Hj Af Asc Z-axis: 165 mm Y-axis: 490 mm Sub-spindle bore: 34 mm X-axis: 293 mm Z-axis: 295 mm Chip conveyor: Yes Parts conveyor belt: Yes Number of driven tools: 8 Number of axes: 5 Number of C-axes: 2 Bar feeder: 3-meter LNS Siemens fire suppression system Condition: Used Length: about 2'420 mm Width: about 1'500 mm Height: about 1'935 mm Machine weight: about 3'800 kg

Condition: used, overall weight: 45,000 kg, Maus MTV4LSL500 Turning Machine/Drill. Weight 45,000 kg. Delayed removal unit will be ready for removal by the end of September. Buyer responsible for removal, contractor must be licensed and insured. Tsdpjz Hc Npofx Af Ajc

Condition: good (used), Year of construction: 1997, functionality: fully functional, 1 x CNC long-turn lathe Star SA 12/16 Year of manufacture: 1997 Tsdpfx Aoz Hccisf Ajc Control system: Fanuc 18 i-T with loading magazine Iemca CH 220/32 Year of manufacture: 1998 Technical data: Spindle bore: 16 mm Spindle travel: 140 mm Main spindle speed: 500 - 12,000 rpm Counter spindle speed: 500 - 8,000 rpm Speed: driven tools: 0 - 4,000 rpm (remaining data see photos) Approximately 6 months ago, the counter spindle was fitted with new bearings. The machine can be inspected while in operation and under power.

Condition: good (used), Year of construction: 2006, functionality: fully functional, Fanuc control, 5 axes, powered tools, tool changer spindle, tool magazine. Tjdpfxez E Ayxj Af Aoc

Condition: good (used), Year of construction: 2006, functionality: fully functional, Fanuc control system, 11 axes, Todpfx Afjz E Ayfs Ajc powered tools, tool changer spindle, Iemca tool magazine.

Condition: like new (used), Year of construction: 2019, operating hours: 7,300 h, machine/vehicle number: IntNr231648, For sale is a very well-maintained TORNOS Swiss GT 13-8 CNC Swiss-type automatic lathe, manufactured in 2019, with only approximately 7,300 operating hours. Technical data – TORNOS Swiss GT 13-8 Manufacturer: TORNOS Model: Swiss GT 13-8 Machine type: CNC Swiss-type automatic lathe Year of manufacture: 2019 Control system: FANUC 31i-B Number of CNC axes: 8 Number of spindles: 2 Todpfx Afsz Er Tnj Asc Operating hours: approx. 7,300 h Condition: very good Main spindle Max. bar diameter: 13 mm Max. machining length: approx. 190 mm Max. spindle speed: 15,000 min⁻¹ Spindle drive power: approx. 4 kW C-axis Counter spindle Max. machining/clamping diameter: 13 mm Max. speed: 15,000 min⁻¹ Drive power: approx. 4 kW C-axis resolution: 0.001° Tool turret 1 8 tool positions Speed of driven tools: up to 6,000 min⁻¹ Drive power: approx. 1 kW Tool turret 2 8 tool positions Speed of driven tools: up to 6,000 min⁻¹ Drive power: approx. 1 kW Front machining up to 4 tool positions Rear/opposite-side machining Up to 8 tool positions Of which up to 4 are driven positions Speed of driven tools: up to 6,000 min⁻¹ Drive power: approx. 0.75 kW Tool holder package is charged separately! TORNOS Robobar SBF 213 bar feeder High-pressure coolant system, type: HP-20-140 Kraft & Bauer fire extinguishing system ELBARON oil mist separator Supply voltage: 400 V The machine can be inspected while powered on by prior arrangement. Subject to changes, errors and prior sale!

Condition: like new (used), Year of construction: 2016, operating hours: 9,300 h, machine/vehicle number: IntNr231649, For sale is a very well-maintained TORNOS Swiss GT 13-8 CNC Swiss-type automatic lathe, manufactured in 2016, with only approximately 9,300 operating hours. Technical Data – TORNOS Swiss GT 13-8 Manufacturer: TORNOS Model: Swiss GT 13-8 Machine Type: CNC Swiss-type automatic lathe Year of Manufacture: 2016 Control System: FANUC 31i-B Number of CNC Axes: 8 Number of Spindles: 2 Operating Hours: approx. 9,300 h Condition: very good Main Spindle Max. bar diameter: 13 mm Max. machining length: approx. 190 mm Max. spindle speed: 15,000 rpm Spindle drive power: approx. 4 kW C-axis Counter-Spindle Max. machining/clamping diameter: 13 mm Max. speed: 15,000 rpm Drive power: approx. 4 kW C-axis resolution: 0.001° Tsdpsz Er A Nofx Af Aoc Tool Carrier 1 8 tool positions Speed of driven tools: up to 6,000 rpm Drive power: approx. 1 kW Tool Carrier 2 8 tool positions Speed of driven tools: up to 6,000 rpm Drive power: approx. 1 kW Front machining Up to 4 tool positions Rear/Opposite-side machining Up to 8 tool positions Of which, up to 4 are driven positions Speed of driven tools: up to 6,000 rpm Drive power: approx. 0.75 kW Tool holder package is charged separately! TORNOS Robobar SBF 213 bar feeder High-pressure coolant system, type: HP-20-140 Kraft & Bauer fire extinguishing system ELBARON oil mist separator Supply voltage: 400 V The machine can be inspected under power by prior appointment. Subject to changes and errors in technical data and specifications, as well as prior sale!

Condition: good (used), Year of construction: 2002, functionality: fully functional, Control system: Traub TX 8i Main spindle Max. bar diameter: 26 mm Max. speed: 8,000 rpm Counter spindle Max. bar diameter: 26 mm Max. speed: 8,000 rpm Tooling system Number of turrets: 2 (upper and lower turret) Tsdpfx Afsz Erdte Aec Tool positions per turret: 12 stations, without drive Front tool holder, 5-position, with Z3 slide, without drive Rear machining station (5 tools), without drive Bar loader: IEMCA BOSS 432/44

Condition: like new (used), Year of construction: 2023, operating hours: 12,147 h, functionality: fully functional, spindle motor power: 3,700 W, spindle speed (max.): 10,000 rpm, type of input current: three-phase, input voltage: 380 V, Equipment: documentation/manual, Citizen A20-3F7 + FMB Minimag 20 bar FEEDER Year: 2023 7 axes: X1, X2, Y1, Z1, Z2, C1, C2 Tedpoz D Tx Nofx Af Aoc Removable guide bushing: can be used in both Swiss-type (sliding headstock) and fixed-headstock configurations. Maximum main spindle speed: 10,000 rpm Machining length: 200 mm X2 axis with linear guides Simultaneous C-axis control on both the main and sub-spindle, with back-working driven tools Short cycle times thanks to the advanced CNC control (Fanuc FS32i) Maximum machining diameter: 20 mm (standard) Machining length per chucking: 200 mm, or 2.5 × D in fixed-headstock mode Main spindle: 10,000 rpm, 3.7 kW Sub-spindle: 8,000 rpm, 1.5 kW Gang-type driven tools: 6,000 rpm, 0.75 kW Back-working driven tools: 6,000 rpm, 0.75 kW Compact footprint: approx. 2.5 m² Polygon turning function Equipped with an FMB Minimag 20 bar feeder.

Condition: used, Year of construction: 2011, STAR ECAS-20 — CNC SWISS-TYPE AUTOMATIC LATHE MACHINE IDENTIFICATION — VERIFIED FROM NAMEPLATE Manufacturer: Star Micronics Co., Ltd., Japan Model: ECAS-20 Type: 570 Manufacturing date: March 2011 Serial number: 0509 Lot number: 047 Supply voltage: AC 200 V, three-phase Frequency: 50/60 Hz Rated apparent power: 8.0 kVA Machine weight: 3,500 kg CE marking: Present Tedpfxsz D Ezve Af Aoc MODEL SPECIFICATIONS — MANUFACTURER DATA Configuration: 10 axes; independent front/back machining; simultaneous two-tool turning Control system: Star Motion Control System Maximum machining diameter: 20 mm Headstock stroke: 205 mm MAIN AND SUB-SPINDLES Maximum speed: 10,000 rpm each Motor output each: 2.2 kW continuous / 3.7 kW for 30 minutes C-axis indexing: 0.01° each Sub-spindle chucking diameter: 20 mm Front-ejection length: 80 mm Workpiece projection: 30 mm TOOLING Turning positions: 4 front, 2 rear Tool shank: 12 mm; optional 16 mm Sleeve-holder positions: 4; optional 2 rear-end stationary tools Stationary drilling: Ø10 mm Tapping/die-cutting: M8 × 1.25 Optional driven positions: 3 front, 3 rear Driven-tool speed: 8,000 rpm Driven-tool motor: 0.75 kW Driven drilling: Ø8 mm Driven tapping: M6 × 1.0 Milling: Ø10 mm Slotting: 1.5 mm wide × 4 mm deep BACKWORKING Tool positions: 4 Drilling, stationary/driven: Ø10/Ø8 mm Tapping, stationary/driven: M8 × 1.25 / M6 × 1.0 CAPACITY AND DIMENSIONS Coolant tank: 120 litres Machine dimensions (W × D × H): 2,588 × 1,150 × 1,765 mm Overall installation dimensions with peripherals: Unconfirmed EQUIPMENT VISIBLE IN PHOTOGRAPHS Bar-feeding equipment with pendant control Fire-suppression cylinder and automatic CO₂ warning label CNC operator panel

Condition: like new (used), Year of construction: 2015, operating hours: 18,000 h, machine/vehicle number: IntNr231671, CNC Swiss-type lathe STAR SR32JN, new, manufactured in 2015 Control system, manufacturer: Fanuc, series 32i-B, 7 axes (X/Z/Y/C1/X1/Z1/C2), Tsdpfxsz Dwube Af Ajc Bar diameter max. 32 mm, Turning length max. 80 mm, Main spindle, speed max. 7,000 rpm, C-axis 0.001 degrees, Counter spindle diameter max. 32 mm, Counter spindle speed max. 7,000 rpm, C-axis, Tool holder for a total of 23 tools (linear tool holder, front tool holder, rear machining), Coolant pump with increased flow rate Parts conveyor belt, Mayfran chip conveyor, Bar feeder magazine FMB turbo 3-36/3200 / A / accessories for short-turning The machine can be inspected under power by appointment. Subject to changes, errors in technical data and specifications, and prior sale!

Condition: used, TSUGAMI HS 207-5AX is a CNC automatic lathe / Swiss-type lathe with high precision, excellent accuracy and reliability. 5 axes, 2 spindles; turning diameter 3–20 mm; max turning length 250 mm; internal spindle diameter 20 mm. Spindle speeds 200–10,000 t/min; spindle power 3.7 kW; back spindle 2.2 kW; 35 tools; rapid traverse 32 m/min; power 50 Hz 3x400 V; total installed 14.6 kVA; weight ~3300 kg; footprint 2110×1200×1885 mm. Bar feeder LNS EXPRESS 320. Built to achieve tight tolerances on precision components. Todpfez Dv Efsx Af Ajc

Condition: used, STAR SR-16 R is a CNC automatic lathe / CNC Swiss type lathe offering high precision, accuracy and reliable performance. Capacities: 7 axes, 2 spindles, max turning length 205 mm, spindle bore 16 mm, max drilling Ø10 mm; travels X1 16 mm, X2 40 mm, Y1 89 mm, Z1 205 mm, Z2 80 mm, C‑axis spindle resolution 0.01°. Specs: main spindle up to 12,000 rpm, back spindle up to 8,000 rpm, driven tool speeds 8,000 rpm, rapid traverse 20 m/min; supply 3x400 V 50 Hz, total power 6 kVA; weight ~2200 kg, footprint 2207×1080×1700 mm. Accessories: LNS SUPER HYDROBAR bar feeder, ELBARON oil‑mist extractor, transformer. Achieves tight tolerances; suited for automotive, watchmaking, machine tools, aerospace and medical sectors Tsdpfx Afez Dvz Tj Aoc

Condition: used, TORNOS DECO 2000/13 is a CNC automatic lathe engineered for precision machining, high accuracy and dependable reliability. Key capacities: 10 axes; max workpiece length 180 mm; internal spindle diameter 13 mm; spindle speeds 100-12000 t/min; back spindle 100-8000 t/min. Main specs: 50 Hz 3x400 V supply; spindle motor 2.2 kW; total power 11 kVA; weight approx. 2550 kg; footprint L2000×W1260×H1950 mm. Equipment: bar feeder IEMCA GENIUS 226/32, chip conveyor, coolant system, oil mist extractor. Achieves tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace, medical. Tedez Dvztepfx Af Ajc

Condition: used, Year of construction: 2016, turning speeds 0 - 8.000 U/min hollow 20 mm Tsdpfx Afez Dbyne Asc control FANUC - 31i B Turning Automatic Lathe - swiss lathe | ML20C5 - 2016 equipped with bar feeder and chip conveyor. The machine is in a well-maintained condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: ML20C5 | ML-20C5 | ML-20 C5 | ML 20 C5

Condition: used, Year of construction: 2020, Star SB-20R Type G CNC Sliding Head Lathe with Fanuc Series Oi-TF CNC Control, 5 Axis Machine, Twin Spindle Collet Chucks, 16 Tool Positions, up to 7 Turning Tool Positions, 4 Sleeve Tool Positions, 5 Driven Tool Positions, (5 Spindle Cross Drilling Unit ER11/16 0M151), 20mm Max Work Piece Diameter, Main Spindle Speed 10,000rpm, Sub Spindle Speed 9000rpm, Fire Trace Automatic Fire Suppressant System, Parts Catcher & Conveyor. S/No. 7009 (0374) (2020), 1750kg with FMB Micromag 20 6 meter Barfeed. Country of Origin: Japan Todpsz Armxefx Af Aec Location: These lots are located in Biggleswade, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser.

Condition: used, Year of construction: 2004, Citizen R04 turning machine with Tryton LNS. Todpfx Afozz Nmto Ajc

Condition: used, TECHNICAL DETAILS Tedjzzfk Ijpfx Af Asc - Maximum workpiece diameter : 4 [mm] - Travel : 24 [mm] WEIGHT & DIMENSIONS - Machine floor space : 1580 x 1100 [mm] - Machine height : 1505 [mm] - Machine weight : 800 [kg]

Condition: used, Year of construction: 2012, operating hours: 31,800 h, functionality: fully functional, CNC long-turn lathe Manufacturer: STAR Type: SR-32J Year of manufacture: 2012 with: FANUC 32i control system Back-end machining Synchronous spindle Powered tools C-axis Tjdpfx Aezzdbrjf Aoc Chip conveyor Parts conveyor belt Oil mist extraction system Fire extinguishing system Bar loader magazine FMB TURBO 3-36

Condition: used, Year of construction: 2018, Citizen Cincom L20E - 2M10 CNC Sliding Head Lathe with Cincom System M70LPC - VU CNC Control, Twin Spindle, Collet Chucks, 20mm Max Workpiece Diameter, 26 Tool Mounting Positions, 5 Lathe Tools, 7 Gang Tool Drilling, 6 Front Drilling, 8 Back Drilling, Driven Tool Capability, Spindle 1 - 200 - 10,000rpm, Spindle 2 - 200 - 8000rpm, Fire Track Automatic Fire Suppression System, Filtermist 5400, Parts Catcher & Conveyor, Serial No. QF6822 (2018) Imeca Boss 338-HD SM Barfeed, Serial No. 021941NA01 (2019), 2350kg. Country of Origin: Thailand Location: These lots are located in Biggleswade, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. Tedpfxszzb Ays Af Aoc

Condition: ready for operation (used), Year of construction: 2000, spindle speed (max.): 10,000 rpm, bar diameter (max.): 24 mm, travel distance X-axis: 46 mm, travel distance Y-axis: 294 mm, controller manufacturer: MITSUBISHI, controller model: Meldas, number of axes: 7, This 7-axis Citizen Cincom L20 VII was manufactured in 2000. It features a maximum machining diameter of 20 mm and a maximum machining length of 200 mm per chucking. The machine is equipped with a Mitsubishi Meldas CNC control and includes a bar feeder, enhancing its productivity. If you are looking to get high-quality turning capabilities, consider the Citizen Cincom L20 VII Swiss-type turning machine we have for sale. Contact us for further details. • Maximum machining diameter: 20 mm • Recommended machining diameter: 6–20 mm • Maximum machining length: 200 mm per chucking • Main spindle speed control: Stepless, S5-digit • Main spindle indexing: 1 degree • Maximum front drilling diameter: 10 mm • Maximum front tapping capacity: M8 with tap / M6 with die • Back spindle: Included • Back spindle maximum chucking diameter: 20 mm • Back spindle speed: 200–8000 rpm • Back spindle speed control: Stepless, S4-digit • Back spindle indexing: 1 degree • Maximum back drilling diameter: 8 mm • Maximum back tapping capacity: M6 • Maximum back machining length: 80 mm Todpfozza Nfsx Af Asc • Maximum workpiece projection from back spindle: 30 mm • Cross live tool drilling capacity: 7 mm • Cross live tool tapping capacity: M6 • Cross live tool speed: 200–5000 rpm • Front live tool drilling capacity: 5 mm • Front live tool tapping capacity: M5 • Front live tool speed: 200–5000 rpm • Back live tool drilling capacity: 4 mm • Back live tool speed: 200–5000 rpm • Maximum number of tools: 16 • Turning tool stations: 7 • Cross drilling tool stations: 3 • Front drilling tool stations: 3 • Back drilling/machining tool stations: 3 • Turning tool shank size: 12 x 12 x 130 mm • Rotary tool shank diameter: 7 mm with ER11 / AR11, 10 mm with ER16 / AR16 • Tool holder sleeve diameter: 19.05 mm • Guide bushing: L20, 20.01 mm • X1-axis stroke: 45.5 mm • Y1-axis stroke: 294 mm • Z1-axis stroke: 205 mm • X2-axis stroke: 316 mm • Z2-axis stroke: 180 mm • Rapid traverse X1 / Y1 / Z1: 20 m/min • Rapid traverse X2 / Z2: 20 m/min • Minimum input increment X1 / Y1 / Z1: 0.001 mm • Minimum input increment X2 / Z2: 0.001 mm • Maximum bar length: 2500 mm • Centre height: 1050 mm Additional equipment • Bar feeder: LNS Hydrobar Mini-Sprint S2 Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: good (used), Year of construction: 2013, TX8i-s / WinFlexIPS Bar diameter up to Ø 32 mm Design allows for conversion between long and short turning Controlled axes: 9 Tool holder WRV on top, X/Y/Z dual drive Counter spindle with WRV on the bottom, separate drive Rear unit with drive Rated voltage 400 V, 3~, N, PE · 50 Hz Connection power 28 kVA, pre-fuse 63 A Recommended supply line: 16 mm² up to 30 m, otherwise 25 mm² Total drive power 46 kW · 73 A Compressed air requirement approx. 300 Nl/min Machine weight 6,850 kg Dimensions L × W × H 3,870 × 1,670 × 2,500 mm Safety standard EN ISO 23125, design type 3 small - Coolant lubrication with cutting oil — internal feed 30 bar, medium pressure 20 bar, high-pressure internal cooling 80–120 bar with its own pump - Coolant treatment system with strip filter (ELBARON) - Mist extraction and fume separator - Fire protection and extinguishing system — prerequisite for unmanned shifts with oil - Workpiece removal with linear unit (part gripper) - Incl. various clamping jaws - Linear measuring system in the X-axes - TRAUB tool monitoring and WinFlexIPS programming - Bar loader FMB turbo 3-36 for bars up to 3,200 mm, with synchronous and displacement device - Chip conveyor, hinged belt - Color: Dust gray RAL 7037 Machine operating time approx. 30,600 hours Machine price without the shown accessories (extensive accessories can be purchased separately) Errors and prior sale excepted. Todpfezzahzjx Af Asc The machine can be inspected under power with short notice.

Condition: excellent (used), Year of construction: 2018, operating hours: 16,500 h, CNC long-turn lathe Manufacturer: STAR Type: SR-20R IV type A Year of manufacture: 2018 Equipped with: FANUC 31i control system Rear-end machining Synchronous spindle Powered tools Y2 axis Manual B-axis C-axis Fire extinguishing system Chip conveyor Oil mist extraction system Todpezyf R Sefx Af Asc Parts conveyor belt Bar feeder magazine FMB TURBO 2-20

Condition: good (used), Year of construction: 2005, operating hours: 15,938 h, functionality: fully functional, Escomatic New Mac 646 + Year 2005 6 axes 15938 run time hours 4x chuck tools 1 x Cross drill station 3 x Frontal drill stations 1 x Pick up spindle for back burring 3 x Frontal driven back burring stations 2 x radial driven back burring stations 1 x Support of steel bobin 1 x Oil tank 1 x Arm support for coollant on main spindle Todpfezx Hucsx Af Asc Machine in good running condition

Condition: used, TECHNICAL DETAILS - Number of turret positions : 4 - Max. stroke of drilling, tapping, and threading spindles : 32 [mm] - Max. stroke of the counter-grip spindle : 36 [mm] - Max. diameter for brass threading/tapping : 5 [mm] - Max. diameter for steel threading/tapping : 4 [mm] - Max. threaded length : l [mm] - Max. clamping diameter of drilling spindles : 6 [mm] - Maximum Ø of the counter-gripper : 6.35 [mm] - Maximum workpiece diameter : 6.35 [mm] - Feed ratio 1:2 with counter-gripper or revolver : 31 [mm] - 1:1 feed ratio with counter-gripper or revolver : 62 [mm] - Dual feed, 1:1 ratio, counter-clamp only : 124 - Number of speeds/cam cycles : 37 - Production : 0.8 - 35 [parts/min] Tsdpfx Afjzx Hlbj Ajc - Number of tools : 3 - Maximum tool travel : 4 [mm] - Toolholder Spindle Speed : 2400 / 3800 / 6000 [rpm] - Tool Dimensions : Ø 6 x 34 [mm] WEIGHT & DIMENSIONS - Machine floor space : 1800 x 900 [mm] - Machine weight : 1090 [kg]
