Condition: used, Year of construction: 2000, x-travel 880 mm Kdodpfx Aezfaxhjfuen y-travel 630 mm z-travel 630 mm weight of the machine ca. 8800 kg

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, Manufacturer: HERMLE Model: C 800 V Machine Type: CNC Vertical Machining Center Year of Manufacture: 2002 Control System: Siemens SINUMERIK Configuration: 3-Axis Machining Center Location: France Condition: excellent, can be demonstrated while powered on Origin: technical university / training and research environment Technical Data: Travel Ranges: X-axis: 800 mm Y-axis: 600 mm Z-axis: 500 mm Spindle: Tool Interface: HSK-A 63 Max. Spindle Speed: 16,000 rpm Max. Spindle Power: 15 kW Max. Torque: 130 Nm Internal Cooling / Coolant Through Spindle: 40 bar Axes / Feed Rates: Max. Axis Speed: 35 m/min Acceleration: 5 m/s² Tool Changer: Tool Magazine: 30 positions Tool System: HSK-A 63 Equipment: Siemens SINUMERIK CNC control system HERMLE control panel 3-axis configuration Vertical milling spindle HSK-A63 spindle 16,000 rpm spindle speed Internal cooling / High-pressure cooling through the spindle, 40 bar 30-position tool magazine Enclosed work area Fixed machine table with T-slots Machine light Coolant system / Pump unit available External high-pressure pump visible Renishaw system / Measuring probe system visible Electronic hand-held device / Handwheel Control cabinet integrated Extraction / Exhaust connection visible Machine vise visible in photos, scope of delivery to be agreed Manuals / technical documentation available Description: For sale is a HERMLE C 800 V CNC vertical machining center, manufactured in 2002, with a Siemens SINUMERIK control system. The machine comes from a technical university or training and research environment in France. It is therefore not a conventional production machine from heavy series production, but a machine from a technically well-maintained environment. The HERMLE C 800 V is a very stable and high-quality 3-axis milling machine with a large working area, HSK-A63 spindle, 16,000 rpm, 30-position tool magazine, and internal cooling / high-pressure cooling through the spindle at 40 bar. The following combination is particularly noteworthy: * HERMLE machine construction quality * Siemens SINUMERIK control system Kdsdpfxjzd Sr Rj Afuon * HSK-A63 tool interface * 16,000 rpm spindle * Internal cooling / High-pressure cooling 40 bar * 30-position tool magazine * Renishaw measuring system visible * Origin from a technical university environment The machine is very well suited for toolmaking, mold making, prototype construction, training, research, single-part production, and precise general CNC milling operations. The machine is currently set up and can be inspected or demonstrated while powered on, by arrangement. Note on peripherals: According to the current photographic documentation, a coolant / pump unit and an external high-pressure pump are available. A large separate KNOLL chip conveyor, KNOLL paper band filter, or a large central KSS filter system is not available. The exact scope of delivery of peripherals, accessories, clamping devices, tool holders, measuring probes, and documentation will be finalized before the sale. Sold as a used machine, as is, without warranty. Technical specifications are subject to change without notice. Subject to prior sale.

Condition: ready for operation (used), Year of construction: 1997, operating hours: 99,99,999 h, functionality: fully functional, machine/vehicle number: 11898, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, nominal power (apparent): 32 kVA, controller manufacturer: Heidenhain, controller model: TNC 430, total height: 2,930 mm, total length: 2,700 mm, total width: 2,210 mm, table width: 560 mm, table length: 1,000 mm, table load: 1,500 kg, overall weight: 7,200 kg, spindle speed (min.): 20 rpm, spindle speed (max.): 15,000 rpm, operating hours of spindle: 9,99,999 h, coolant supply: 3 bar, spindle motor power: 10,500 W, number of spindles: 1, number of slots in tool magazine: 30, input voltage: 400 V, type of input current: three-phase, Equipment: documentation/manual, rotational speed infinitely variable, Hermle C800V X=800 Y=600 Z=500 Table size 1000x560 Table load 1500kg Machine is fully functional. Sold without clamping devices. 15,000 1/min, SK40. HDH TNC430, (without coolant through spindle, without chip conveyor). The machine can be inspected in production until June 24th, or by arrangement. Kdedozd Aimepfx Afusn Delivery is included within a 300km radius of Bonn, to the curb, without unloading, between June 30th and July 9th. For greater distances, the difference must be covered by the buyer. This offer is only valid for buyers from Germany. Machine location near Bonn.

Condition: good (used), Year of construction: 2004, operating hours: 90,000 h, functionality: fully functional, machine/vehicle number: 6010.0176, Technical Data Manufacturer: MIKRON Model: UCP 800 Duro Year of construction: 2004 Control system: Heidenhain iTNC 530 Travel in X-axis: 800 mm Travel in Y-axis: 650 mm Travel in Z-axis: 500 mm Rotary table 600 x 600 mm Max. table load: 500 kg Rotation range C-axis: 360° Tilting range A-axis: +120° / -100° Rapid traverse X/Y/Z: 30 m/min Spindle manufacturer: Step-Tec AG Spindle type: HVCS212-S-12-1.7/20-2F-HSK-A63 Max. spindle speed: 20,000 rpm Tool interface: HSK-A63 Spindle power: 12 kW (S1) Machine weight: approx. 9,900 kg Connection power: 18 kW Operating voltage: 3x 400V + PE / 50Hz Description For sale is a high-precision 5-axis vertical machining center from the Swiss quality manufacturer MIKRON, model UCP 800 Duro. The machine is in good, well-maintained condition and is equipped with a powerful Step-Tec motor spindle up to 20,000 rpm and a reliable Heidenhain iTNC 530 control system. An integrated BLUM LaserControl system ensures precise tool measurement and breakage monitoring. Special advantage for buyers: The machine is currently still installed and operational. An inspection and a function test can be carried out after prior appointment. Equipment / Highlights ( )5-axis simultaneous machining for complex components Heidenhain iTNC 530 CNC control system with hand-held device Step-Tec high-speed spindle (max. 20,000 rpm) BLUM LaserControl (laser tool monitoring) Chip conveyor including chip cart CE marking available Delivery conditions Kdedpfx Afjzc Hqaouon Condition: Used, fully functional, can be tested while powered on. Location: Sinn, Germany Availability: By arrangement. Dismantling & Transport: The buyer bears the costs for dismantling, loading and transport (ex works / EXW).

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 15744, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain iTNC 530, table load: 1,500 kg, TECHNICAL DETAILS Travel range, X-axis: 800 mm Travel range, Y-axis: 600 mm Kjdpszcymzofx Afujdn Travel range, Z-axis: 600 mm Table length: 1,000 mm Table width: 560 mm Table load: max. 1,500 kg Spindle connection: HSK63 Tool changer: 30 positions Rapid traverse rate: 35 m/min Acceleration: 5 m/s² MACHINE DETAILS Control system: Heidenhain iTNC 530 Dimensions & Weight Dimensions (L x W x H): 4,200 x 2,500 x 2,800 mm Weight: 7,200 kg Total connected load (including cooling unit): 42 kVA

Condition: ready for operation (used), Year of construction: 2002, operating hours: 35,816 h, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller manufacturer: HEIDENHAIN, overall weight: 7,000 kg, spindle speed (max.): 10,000 rpm, spindle motor power: 16,800 W, number of axes: 3, This 3-axis HERMLE C 800 V was manufactured in 2002. It features a spindle speed range of 20 to 10,000 rpm and a spindle power of 25 kW. The machine has a net weight of 7,000 kg and includes additional equipment such as a cooling unit and a jib crane. If you are looking to get high-quality machining capabilities, consider the HERMLE C 800 V vertical machining centre we have for sale. Contact us for further details. - Control Unit: Heidenhain (Control On: 114,325 hours)- Machine On Time: 111,736 hours- Program Run Time: 40,346 hours- Spindle On Time: 35,816 hours- Drive On Time: 76,783 hours- Axes In Motion: 37,963 hours- Operation Voltage: 400 V / 3 ~- Frequency: 50 Hz- Control Voltage: 24 V =- Total Nominal Current: 63 A- Total Rating: 43 KVA- Spindle Speed Range: 20 to 10,000 rpm- Spindle Diameter at Front Bearing: 70 mm- Tool Taper/Spindle Interface Options: HSK A63 (DIN 69063)- Tool Clamping Retention Force (HSK A63): 18 kN- Spindle Power (40% / 100% ED): 25 / 16.8 kW- Spindle Torque (40% / 100% ED): 159 / 107 Nm- Maximum Spindle Speed with Open Guard Doors: 3,000 rpm- Additional Equipment Included:* Cooling Unit / Chiller (FLKS 170)* Line Filter (LF BN/HC 110 G 5 B 1.0)* Ventzki Chip Hopper / Dumpster (Model LC-805-500 L, Max Capacity 1500 kg, Tare 156 kg)* ABUS Jib Crane (Load capacity 500 kg) mounted near or to the machine site* Floor cooling fan Kedpfx Afjzcylqsusdn

Condition: used, Year of construction: 1999, controller manufacturer: Heidenhain, controller model: MillPlus, _____ Description: Year of manuf. : 1999 Control : Heidenhain MillPlus Speed : 12000 rpm Movement X/Y/Z : 800/650/550 mm Spindle: Technology:Motorspindle Speed:12.000 rpm Power (max.):15 kW Torque (max.):130 Nm Taper:SK40 Workingtable: Clamping surface:1.100 x 650 mm Tableloading (max.):600 kg In general: Toolmagazine:25 stations Rapid travers in X/Y/Z:18/18/15 m/min Equipment/Accessory: Chipmanagement:Chip tray Coolingmanagement:Coolant pump Oilmistseparation:Electrostatic extraction, W+W EL-FI 1000 Kodpfx Aezbzcbefuodn Further Equipment:Rinsing pistol Further Accessory:Misc. used Toolholder SK 40

Condition: ready for operation (used), Year of construction: 1999, travel distance X-axis: 900 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 410M, spindle speed (max.): 5,000 rpm, number of axes: 3, This 3-axis KUNZMANN WF9 CNC was manufactured in 1999. It features a reliable Heidenhain TNC 410M control system, ensuring precision and efficiency in operations. If you are looking to get high-quality machining capabilities, consider the KUNZMANN WF9 CNC vertical machining centre we have for sale. Contact us for further details. Kdjdpfx Aszbu Nzefusn • Condition: Good / Fully operational • Control System: Heidenhain TNC 410M

Condition: ready for operation (used), Year of construction: 2014, travel distance X-axis: 860 mm, controller manufacturer: HEIDENHAIN, controller model: TNC530 i, spindle speed (max.): 10,000 rpm, number of axes: 3, This 3-axis WEMAS VZ 860 was manufactured in 2014. It features an internal coolant supply and is equipped with a Heidenhain TNC 530 i control system, ensuring efficient operation. If you are looking to get high-quality machining capabilities, consider the WEMAS VZ 860 vertical machining centre we have for sale. Contact us for further details. • With internal coolant supply • Condition: Very good / Fully operational • Control System: Heidenhain TNC 530 i Kdjdpfx Aozbu Iwjfuon Technical Specification Through-spindle Coolant Yes

Condition: ready for operation (used), Year of construction: 1999, spindle speed (max.): 6,000 rpm, travel distance X-axis: 850 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 430, number of axes: 3, This 3-axis RECKERMANN VMC 850 was manufactured in 1999. It features an internal coolant supply and is equipped with a Heidenhain TNC 430 control system, ensuring efficient operation. If you are looking to get high-quality machining capabilities, consider the RECKERMANN VMC 850 vertical machining centre we have for sale. Contact us for further details. • With internal coolant supply • Condition: Very good / Fully operational • Control System: Heidenhain TNC 430 Kdsdpfx Afozbu Aboujn Technical Specification Through-spindle Coolant Yes

Condition: excellent (used), Working travels 860 x 560 x 600 mm Table size 1000 x 560 mm Ksdpfxszbrrto Afujdn Spindle taper SK40 Spindle speeds -10'000 rpm Tool changer 24 Pos. Control HEIDENHAIN iTNC-530 Coolant through spindle 3D measuring tracer Tool lenght measuring device Misc. accessories MARCELS MASCHINEN CH

Condition: excellent (used), Year of construction: 2006, travel distance X-axis: 800 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 500 mm, feed rate X-axis: 30,000 m/min, feed rate Y-axis: 30,000 m/min, feed rate Z-axis: 30,000 m/min, controller manufacturer: HeidenHain iTNC530, total height: 3,200 mm, total length: 3,200 mm, total width: 2,400 mm, table width: 600 mm, table length: 600 mm, table load: 500 kg, rotational speed (max.): 20,000 rpm, spindle motor power: 18,000 W, number of slots in tool magazine: 30, 5-axis CNC machine (VMC) MIKRON - UCP 800 MACH-ID 9640 Make: MIKRON Type: UCP 800 Control: HeidenHain iTNC530 X - Travel: 800mm Y - Travel: 650mm Z - Travel: 500mm A - Axis: +120 to -100° B - Axis: 360.000° Table Length: 600mm Table Width: 600mm Table load: 500 Feed rate X-Axis: 30000mm/min. Feed rate Y-Axis: 30000mm/min. Feed rate Z-Axis: 30000mm/min. Spindle Taper: HSK63ISO/Bt/Mk Kodpfx Aezbqy Nofujdn Power on spindle: 18kW Speeds / ranges: 20000Rpm ATC / revolver: 30 Coolant through spindle / Bar:20 Number of controlled axis: 5 Chip conveyor: yes Coolantsystem: yes Length: 3200mm Width: 2400mm Height: 3200mm Weight: 10000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Year of construction: 2001, travel distance X-axis: 800 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 600 mm, controller manufacturer: Heidenhain TNC 426, total height: 2,750 mm, total length: 4,050 mm, total width: 2,250 mm, table width: 490 mm, table length: 1,000 mm, table load: 750 kg, overall weight: 4,200 kg, spindle speed (min.): 5 rpm, spindle speed (max.): 12,000 rpm, coolant supply: 20 bar, distance table center to spindle nose: 665 mm, spindle motor power: 13,000 W, spindle nose: SK40, Equipment: chip conveyor, rotational speed infinitely variable, Travel X/Y/Z 800/510/600 mm, Control HEIDENHAIN TNC 426, spindle power 13 KW, spindle speed 5-12'000 rpm, ISO40, table size 490x1000 mm, max. table load 750 kg, tool changer 30 places, dimension 40500x2250x2750 mm, weight ca. 4200 kgs, accessoires Renishaw OMP60 tool prove, coolant through spindle 20 bar, chip conveyor, tool holders, manuals Kodpfszblfgox Afuodn

Condition: excellent (used), Year of construction: 2018, Traverses X Y Z 800 x 450 x 510mm, table size 1000 x 450 mm, table load 600KGS, spindle taper BT40, spindle speed 12,000rpm, 30 station ATC, spindle power 18.5/11Kw, Ksdpfxjzbhv Ie Afujdn Through spindle coolant, Siemens 828D control

Condition: ready for operation (used), Year of construction: 2010, travel distance X-axis: 850 mm, travel distance Z-axis: 650 mm, spindle speed (max.): 24,000 rpm, spindle motor power: 11,000 W, number of axes: 4, This 4-axis Elumatec SBZ-140 was manufactured in 2010. It features a maximum profile length of 7600 mm and a Y-axis travel of 850 mm, making it suitable for machining aluminum and thin-walled steel profiles. The machine includes an air-cooled spindle with a maximum speed of 24,000 rpm and a tool magazine capacity of 8 positions for efficient operation. If you are looking to get high-quality machining capabilities, consider the Elumatec SBZ-140 vertical machining centre we have for sale. Contact us for further details. • Application: Machining of aluminum and thin-walled steel profiles • Operating system: Windows • Machining capabilities: Milling, drilling, tapping, end machining • Continuous machining range: 0°–180° Kdedpfx Aozaq Eijfusn • Working area: • Max. profile length with end machining: 7480 mm • Max. profile length without end machining: 7600 mm • Axis travels: • A-axis rotation: 0°–180° • A-axis programming increment: 0.1° • Axis speeds: • Y-axis: up to 60 m/min • Z-axis: up to 60 m/min • Spindle: Air-cooled • Tool magazine: 8 positions, co-moving for fast tool changes, expandable system • Machine features: Stationary profile machining, fast automatic tool changes, suitable for aluminum and thin-walled steel profiles, two machining zones (optional) • Pneumatic system: 7 bar required, approx. 180 l/min air consumption (with spray system) • Electrical data: 400 V / 3-phase / 50 Hz, main connection 63 A • Control panel: 15” color display, USB interface, LAN connection Additional equipment • Angle head set (0°, 90°, 180°, 270°) for end machining and double profiles • Pendulum mode / 2 working zones (optional configuration)

Condition: reconditioned (used), CNC Vertical Machining Center HERMLE B 300 V With Heidenhain iTNC 530 path control Year of manufacture: 2014 Travel ranges: X 800, Y 600, Z 500 Speed range: 20 – 18,000 rpm, stepless With the following accessories: Fixed angular table, 1000 mm x 560 mm clamping surface Vertical tool changer with 30 magazine slots (HSK 63) Air blow through the spindle center IKZ 40 bar Chip conveyor Tool measurement in the work area (BLUM laser) Coolant system Manual cabinet door, manual cabinet roof Polycarbonate safety panels Electronic thermal compensation iTNC 530 Electric hand control module HR 410 3D measuring probe Control cabinet cooler (RITTAL) Spindle oil cooler Kdjdpfx Aoy U H Iqjfuon Chip flushing gun 4 adjustable machine feet Operating manuals

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: AB0704, travel distance X-axis: 810 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 610 mm, rapid traverse X-axis: 810 m/min, rapid traverse Y-axis: 610 m/min, rapid traverse Z-axis: 610 m/min, controller manufacturer: Siemens, controller model: Sinumerik 810D, workpiece weight (max.): 1,000 kg, table load: 1,000 kg, rotational speed (min.): 8,000 rpm, rotational speed (max.): 8,000 rpm, overall weight: 5,000 kg, number of slots in tool magazine: 32, input voltage: 400 V, type of input current: three-phase, Equipment: CE marking, chip conveyor, rotational speed infinitely variable, The Spinner VC810 is a high-precision, German-made 3-axis CNC vertical machining center. Its rigid cast iron construction ensures stable and vibration-free machining. This reliable, European-made machine is specifically designed for complex milling and drilling operations in tool and machine manufacturing. It is used in custom manufacturing. Regularly maintained. The tool changer has one faulty spindle. Currently in production until the end of June 2026 (can be viewed in operation by prior arrangement). Net price. Kedpfx Ajy Uvr Ssfujdn

Condition: used, Year of construction: 1999, functionality: fully functional, Technical data: Manufacturer: Spinner Type: VC 810 Year of manufacture: 1999 Control system: Siemens 840D ShopMill Kedpfx Aoy Uhiisfuodn Travel distances: X 810 mm, Y 600 mm, Z 510 mm Spindle Speed: 8,000 rpm Torque: 105/70 Nm Work table Dimensions L/W: 1,000 x 600 mm Table load: 1,000 kg Tooling Tool holder: SK40 Tool changer: 24-position Dimensions and weight Dimensions L/W/H: 2,900 mm x 2,300 mm x 2,600 mm Weight: 6,500 kg Spindle newly fitted with bearings. Coolant through spindle (IKZ) Handwheel

Condition: used, Year of construction: 2007, x-travel 800 mm y-travel 650 mm z-travel 500 mm Control Heidenhain iTNC 560 spindle tunring speed 12.000 U/min In our estimation, the machine is in good used condition and can be inspected under power by appointment. Kdjdjy T Scwspfx Afujn Accessories, as well as the tools and clamping devices shown in the images, are included in the scope of delivery only if explicitly noted in the additional information. Subject to changes, errors in technical data and specifications, and prior sale!

Condition: used, TECHNICAL DETAILS - Number of axes : 5 MILLING SPINDLE - Tool holder type : BT40 - Spindle speeds : 12000 [rpm] - Spindle power : 18 [kW] LINEAR AXES - Travels on X/Y/Z axes : 800 / 700 / 510 [mm] - Rapid traverses rates (X/Y/Z) : 35 / 35 / 35 [mm/min] Ksdey Tzcgjpfx Afuodn A ROTARY AXIS - Travel : -110 / +30 [°] - C ROTARY AXIS - Travel : 360 [°] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 32 TABLE - Table dimensions : 610 x 530 [mm] - Maximum weight upon table : 350 [kg] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 4.000 x 2.700 [mm] - Machine height : 2.600 [mm] EQUIPMENT - CNC : Hurco Ultimax - Interactive programming - Electronic handwheel - Coolant tank

Condition: used, Year of construction: 2009, x-travel 835 mm y-travel 510 mm z-travel 510 mm CNC-control iTNC530 HEIDENHAIN table-size 1000 x 560 mm max. table load 800 kg spindle taper SK 40 spindle turning speed range 20 - 14.000 U/min feed stepless 1 - 20.000 mm/min rapid traverse 20 m/min drive capacity - spindle motor 13 / 9 kW tool change unit 32 Pos coolant IKZ 25 bar voltage 400 V total power requirement 30 kVA weight of the machine ca. 4,5 t dimensions of the machine ca. 2,25 x 3,20 x 2,30 m chip conveyor 3,50 x 0,85 x 1,55 m coolant equipment 1,40 x 1,60 x 1,80 m spindle oil cooler 0,40 x 0,50 x 1,00 m - Serial-No.: 15415041384 - Machine ON: 72,882 h - Program Run: 25.267 h - control: HEIDENHAIN iTNC 530 - Linear scales in all 3 axis - electr. handwheel - Tool changer 30 pos. with double gripper - Chip conveyor - TSC with belt filter system Kedpjy Ty A Sefx Afuodn - Coolant unit - new ball screw incl. bearings (X-Axis)

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 850 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 450 mm, controller model: Fagor 8055/FL, spindle speed (max.): 1,200 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 850 mm Travel range, Y-axis: 500 mm Travel range, Z-axis: 450 mm Spindle speed (max.): 1,200 rpm Spindle speed (min.): 30 rpm Table width: 530 mm Table length: 900 mm T-slots: 14 mm wide, spaced at 60 mm Table load capacity: max. 400 kg MACHINE DETAILS Control system: Fagor 8055/FL Input voltage: 380 V Input current: Three-phase Connected power: 56 kW EQUIPMENT Documentation/Manual Various tool holders and tools Kedpfx Afjy Tv Aujuodn

Condition: good (used), Year of construction: 2010, Posmill B 800, year of manufacture 2010, Fanuc Oi 100 control, travel X/Y/Z 800/510/630 mm, 24-position tool changer, BT 40 spindle taper, spindle speed up to 10,000 rpm, table size 950 x 510 mm, max. table load 500 kg, Hexagon infrared probe, through-spindle coolant 20 bar, Hexagon infrared tool measuring system. Kdsdpfjy Thvmjx Afusn

Condition: used, Year of construction: 1990, Technical details: x-travel: 800 mm y-travel: 410 mm z-travel: 510 mm control: Fanuc 10 MA rapid travel x/y/z: 20/20/15 mm/min table surface area: 1100 x 450 mm tool taper: BT 40 tool magazin:: 30 BT 40 max. tool length: 250 mm max. tool weight: 8 kg power requirement: 7,5/5,5 kW turning speed range: 6000 1/min weight of the machine ca.: 6,3 t Under offer is a complete CNC tool shop, whioch will be given up due to old age of owner. The Mori Seiki is still highly accurate. All existing tool holders, tools, drills, etc. come with the machine. All measuring devices also come with the machine. Upon request orders for parts to be made can be passed on to new owner. This is a low cost all inclusive opportunity for a "Startup" * Kdjdpsy S T T Ujfx Afuen

Condition: as good as new (ex-display), Year of construction: 2020, machine/vehicle number: VT0341, functionality: fully functional, High-performance machining center SPINNER VC850-5A Travel distances X850, Y510, Z510 mm High-performance milling spindle up to 18,000 rpm Power Pmax 20 kW / Nmax 66 Nm as a built-in hybrid spindle with direct drive, without belt Tool holder on the spindle HSK63 TOOL MAGAZINE with 32 tool stations DIRECT MEASURING SYSTEMS in the X/Y/Z axes In the latest generation of SIEMENS "SINUMERIK ONE" control system - SPINNER - SPIOS 24" touch operating panel for I4.0 applications - Operating panel height-adjustable, rotatable and tiltable for best ergonomics - incl. engraving cycles - 24" liquid crystal flat color screen with multi-touch functionality - User memory 2 GByte - 15 zero-point shifts - 1 free USB interface - Ethernet interface standard SPINNER MULTI-CONTROL WHEEL on the operating panel, integrating the following functions into a single control element: - Handwheel function in jog mode - Feed override in automatic mode Kdodpfoy S Ttzjx Afujn - Start button and feed influence in single-block setup mode, automatically resetting to 0% at the end of the sequence -> all important functions of the setup mode integrated into one control element Electrical preparation for HOWIMAT 2-axis rotary tilting table on VC850/VC1150 2-axis ROTARY TILTING TABLE mounted on the right in the working area particularly rigid and space-saving, suitable for holding chucks or collets TILTING AXIS: - Dividing accuracy +- 0.005 degrees - Swivel range 105 degrees - Maximum tangential moment 1,200 Nm ROTARY AXIS with direct drive via coaxial motor: - Dividing accuracy +- 0.005 degrees - Bore 80mm, spindle nose D=160 mm - Maximum tangential moment 500 Nm UNIVERSAL CHIP CONVEYOR VC850 PREPARATION of the spindle FOR HIGH PRESSURE for using the additional tank up to 70/80 bar HIGH-PRESSURE TANK 70bar with paper band filter for flushing centrally through the spindle Additional compressed air supply at the spindle head Compressed air centrally through the milling spindle Flushing gun in the working area PREPARATION FOR SPINNER STANDARD PROBING SYSTEM Wireless SPINDLE PROBE ADDITIONAL HOOD on top for a closed working area STANDARD DOCUMENTATION in German consisting of machine manual and CNC manuals is delivered in digital form on the control system. Paper manuals available at an additional cost. RING EYES for crane unloading, set consisting of 4 pieces absolutely necessary for crane transport STANDARD PAINTING two-color in light gray RAL7035 and blue-gray RAL5008 Electrical design EUROPEAN STANDARD as follows: Operating voltage 3x400V +/-10% Mains frequency 50Hz (+/-2%) TN network (5-conductor) Notes: The price includes warranty services only within Germany. In the case of new and demonstration machines, the images are not necessarily of the individual machine, but of comparable machines. Accessories shown, such as clamping devices or tool holders, are included in the scope of supply only to the extent listed in the technical description. Please request a detailed offer ex works. Visit our factory near Munich or one of our showrooms. We may have other offers for comparable machines. Subject to prior sale.
