Matkowski

Condition: used, Hydroptic 7A, No 267, Temp 23deg, Made In Switzerland, 40" Under Rail, Right Angled Head, Boring Head s x(2) and Related Tooling, Itodsx I R N Sspfx Aanjr

Condition: new, Year of construction: 2024, functionality: fully functional, RÖDER Profile Drilling Machine PBA 3000 NC with 2-axis positioning control Heidenhain Positip 8016 active Iodpjx E Sytefx Aanotr for x- and y-axis and drilling unit Optimum MH35V Year of manufacture: 2024 For rational and efficient drilling of beams, profiles, tubes, and other long workpieces Technical Data: Max. travel distance x-axis: 3000 mm Max. travel distance y-axis: 250 mm Max. travel distance z-axis: 350 mm Max. support length: 5700 mm (by means of extendable support rollers) Max. support weight: 500 kg Standard Equipment: 3 pcs. mechanical vices Röhm BOF 4 Max. clamping width: 220 mm Clamping width: 160 mm Jaw height: 50 mm Drilling unit Optimum MH35V Technical Data: Motor: 1.5 kW, 400 V Drilling capacity in S235JR: ø 32 mm Continuous drilling capacity in S235JR: ø 28 mm Tapping mode: Yes Spindle taper: BT 30 Spindle stroke: 90 mm Gearbox: Two-stage industrial motor and additionally 6 gearbox speeds Speed range: 220 – 3100 rpm Gear head: swivels +/- 30° Minimum quantity lubrication equipped with micro-dosing pump, pneumatic frequency generator, 6 mm push-in fitting for pressure supply/device control; 75-litre PE fluid tank, nozzle feed line D8 mm, length 2000 mm, plastic link nozzle G1/8" with holder D12 x 30 mm, nozzle tip made from aluminium Optional, available at extra cost: Pneumatic tapping unit M3 – M12; integrated on PBA 3000/6000, pneumatic, with flexible arm, Speed 400 rpm Working area: Radius 100–950 mm, 6 pcs. quick-change inserts M4, 5, 6, 8, 10, 12; including linear guide, adapter, pneumatic connection and maintenance unit Subject to prior sale. No liability for typographical errors and mistakes.

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, travel distance X-axis: 1,200 mm, travel distance Y-axis: 150 mm, The KT1200 coordinate table with TSB 35 (drilling machine by Knuth) allows for high efficiency – maximum time savings, as the time-consuming measuring, marking with high tolerances, center punching, and manual positioning are no longer necessary. Functionality – precise positioning capability and absolute repeat accuracy thanks to adjustable stops. Coordinate Table Technical Data: - Max. travel distance x-axis: 1,200 mm - Max. travel distance y-axis: 150 mm - Max. workpiece weight: 60 kg - Vices: 2 pcs. - Max. clamping width of vice: 158 mm - Max. clamp opening of vice: 140 mm - Required space (L x W x H): 1850 x 560 x 2000 mm - Repeatability: +/- 0.2 mm - Electronic position indicators - Position stops: 8x (x-axis) Iodpfx Aasx E Sl Nsnstr - Travel movements x and y: 2x handwheel with clamping Knuth TSB 35 Drilling Machine Technical Data: - Drilling capacity in S235JR: Ø 35 mm - Continuous drilling capacity in S235JR: Ø 25 mm - Thread cutting in S235JR: M22 - Spindle taper: MK 4 - Speed range: 125 – 3030 rpm Subject to prior sale. No warranty for typographical errors or mistakes.

Condition: used, Year of construction: 1990, table: 900-1500 mm digital ja weight 5 t Iodjx E Dt Espfx Aanotr

Condition: used, Hello, For sale: Coordinate drilling machine BKOZ 800x1200. Iodpfjxyi N Eex Aanetr The machine is operational and in continuous use; inspection and testing are possible on site. The price listed in the advertisement is net; VAT is to be added. The machine can be viewed in Starachowice, Kwiatkowskiego 13. Phone contact available from 7:00 to 16:00 668495897

Condition: used, spindle diameter 90 mm x-travel 700 mm y-travel 500 mm Control Heidenhain bore capacity in steel 40 mm spindle taper MK 4 bore spindle stroke 170 mm Itsdpfsxwzg Rex Aansr spindle turning speed - stepless 10-2.000 U/min ll diameter 230 mm table dimensions 900 x 770 mm vertical travel of crossrail-slide 630 mm boring spindle 6 Stück/ 0.02-0.20 U/min distance between columns 900 mm Passage between spindle and table 815 mm spindle drive 4 PS total power requirement 380 V weight of the machine ca. 3,9 t In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: used, Jig Boring Machine WMW BKoE 450 x 800 Travel X: 560 mm Travel Y: 400 mm Iodpsxuf Utjfx Aanotr Travel Z: 470 mm Spindle: Ø 90 mm Cone: CM4 Spindle exit: 150 mm Spindle speed: from 50 to 1600 RPM Table size: 450 x 800 mm Maxi loading capacity on table: 400 kg Scale3 axes HEIDENHAIN Automatic descent Voltage: 380 V Width with ends table: 2900 mm / without ends table: 1500 mm Depth: 2500 mm Total height: 2600 mm Weight: 4,5 T

Condition: used, Drilling / Jig Boring Machine CONSTANT SUPEMEC type P65 Travel X: 500 mm Travel Y: 300 mm Travel Z: 550 mm Cone: SA40 Spindle speed: from 77 to 1520 RPM Table size: Length 1200 mm x Width 420 mm Maxi distance spindle nose/table: 670 mm Mini distance spindle nose/table: 120 mm Throat depth: 300 mm Variable speed drive for X - Y Voltage: 380 V Width: 1600 mm Depth: 1800 mm Height: 2400 mm Itsdpfx Aajxuf Uasnjr Total width with control panel: 2700 mm Weight: 3 T

Condition: excellent (used), Year of construction: 2009, Year 2009 VOORTMAN V600 CNC SINGLE SPINDLE DRILLING MACHINE with 5 station automatic tool changer. 18 metres length, drilling capability 16.3 metres. Isdpfx Ajw D Uqfoanjtr Profile Capacity 35mm -1050mm. Drill capacity 8mm-40mm.

Condition: excellent (used), Year of construction: 2012, · V200 Plate drilling machine (executed with a VD40 drilling unit and an X-Y coordinate table). · VTC 8/40 tool changer (8 places). · Hydraulic numbering unit VN 1/16 · Deburring unit VDB 2 (each hole is automatically deburred). Itsdewphgdspfx Aanor Max. length 1.400 mm* Max. width : 1.000 mm Min/max. thickness : 3 - 60 mm Capacity : : 600 kg * Longer lengths (max. 2 400mm) possible by automatic repositioning.

Condition: used, Price: On request - Documentation available: No - CE certificate present: No - Control: Conventional - Drilling depth: 150mm - Model: ördinatenboor - Digital readout: Yes - Table width: 1500mm - Table length: 2200mm - Travel X: 2500mm - Travel Y: 1400mm - Spindle diameter: 100mm - Travel Z: 1000mm - Number of axes: 3 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Ijdpfx Aaswfpbbonstr Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Technical details: z-travel: 400 mm range of revolution per miute: max. 3.000 / steples U/min feed continuous: keine Angaben quill stroke vertical: 100 mm spindle taper: MK2 table surface area: 445 x 315 mm distance table - lower edge spindle: max. 520 mm table travel: längs: 250 mm table travel: quer: 330 mm table height over floor: 920 mm total power requirement: 1,6 kW weight of the machine ca.: 1500 kg machine dimensions LxWxH: 1,3 x 1,1 x 2,0 m Application: Milling and drilling slotted holes There is a precision dial gauge for depth display on the drill spindle head. 5x T-slots to DIN 650: a=10; h=18; b=18; c=8mm Itjdpfx Aaev A S Efsnor Features: Two-way digital ACU-RIDE display *

Condition: used, functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 3,000 rpm, spindle speed (min.): 120 rpm, table length: 550 mm, table width: 320 mm, spindle mount: MK 2, total height: 1,500 mm, total length: 1,400 mm, total width: 2,100 mm, rotational speed (min.): 120 rpm, rotational speed (max.): 3,000 rpm, drilling capacity: 75 mm, distance between stands: 600 mm, spindle motor power: 551 W, For sale is a Hauser brand coordinate drilling machine of type OP3 The machine is ready for use and fully functional Technical data: HAUSER OP3 coordinate drilling machine Table: 550 x 320 mm Longitudinal travel: X-axis 400 mm Cross travel: Y-axis 250 mm Vertical travel: Z-axis 400 mm Cone in the spindle: MK 2 Drilling capacity in steel: 20 mm Stroke of the drilling spindle Z-axis: 130 mm Itodpfx Aaevzrx Noner Bore diameter: max. 75 mm Distance from table to spindle: 600 mm Spindle speeds: infinitely variable: 120- 3000 rpm Feed rates: Drill spindle slide: Number (steps) 2, 0.03 mm/rev 0.06 mm/rev Spindle motor: 0.75 HP Machine weight: approx. 1500 kg Dimensions: 1400x1500x2100 Transport and loading can be organized throughout Europe on request for an additional charge. Prices plus VAT Viewings possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machine purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For more information or contact options, visit us on our website

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 780 mm, 1 used, very well-maintained high-precision CNC jig boring machine SIP MP 600 Machine built 1995 - 2007, converted to HEIDENHAIN iTNC 530 and completely overhauled. Table 1100 x 700 - free passage between the columns 750 mm Spindle diameter of the hydrostatic spindle 130 mm - 1 micron concentricity! Conversion to HEIDENHAIN CNC 3-axis interpolation. Reading accuracy of the boring spindle less than 1 micron - hydraulic weight and load compensation in the crossbeam. This machine is in fantastic condition - we would be happy to demonstrate it to you in our warehouse under power. Price Isdpfxsu Titze Aanjtr (domestic plus 19% VAT) ex warehouse Delivery time: immediately - subject to prior sale and errors. Payment: As usual, net before collection. Technical data is non-binding - errors excepted.

Condition: good (used), Year of construction: 2006, machine/vehicle number: 860027, Offer 24331 Ijdpou Aqz Ajfx Aanetr Technical data: - Table surface 1700 x 550 mm - manual travel X / Y 1300 x 500 mm - MAXION drilling machine, type: BT 18 STP - Drilling capacity up to 18 mm - Tapping device up to M 16 - Drill spindle holder MK 2 - Drill spindle stroke with fine drilling depth adjustment 76 mm - Pneumatic feed unit PV 12 - throat depth 670 mm - Spindle speeds 100 - 1800 rpm - 200 - 3600 rpm - mot. Stroke of the drilling unit - mot. Table clamping x + y - Minimum quantities Lubrication - Pneumatic connection 6 bar - Connection 400 V - Space requirement approx. W 1750 x H 1600 x D 1000 mm - Weight approx. 1200 kg

Condition: new, Year of construction: 2024, functionality: fully functional, travel distance X-axis: 1,200 mm, travel distance Y-axis: 160 mm, table width: 1,850 mm, table load: 75 kg, 2-axis coordinate table KT1200 for professional use with pillar drilling machines - can be used with all common makes of pillar drilling machines using the adapter plates included in the scope of delivery. Travels: x-axis 1200 mm y-axis 160 mm With the KT1200, you achieve maximum time savings because the time-consuming measuring, scribing, center punching and manual positioning with high tolerances is no longer necessary. Precise positioning and repeat accuracy is made possible. including 2 vices can be freely positioned over the entire travel range, the coordinate table can be moved in x and y directions using the handwheels; a clamp guarantees that the coordinates approached are fixed, 8 pcs. Position stops for the x-axis, one position indicator each for x- and y-axis Clamping width max. 158 mm, Clamping width 140 mm Space requirement LxWxH 1850 x 560 x 285 mm; Electronic position indicators for x- and y-axis; Repeat accuracy +/- 0.2 mm Weight: 75 kg Max. Workpiece dimensions 120 x 120 x 1200 mm Max. Workpiece weight: 60 kg Mounting support for drilling machine at least 520 x 225 mm Drilling unit optionally available. Iedpfxjuzkdno Aanetr Now at a special price for stock clearance!

Condition: good (used), Year of construction: 2006, machine/vehicle number: 185078, Offer 24435 Technical data: - Table surface 1700 x 550 mm - manual travel X / Y 1300 x 500 mm - MAXION drilling machine, type: BT 15 GL - Drilling capacity up to 18 mm - Tapping device up to M 10 - Drill spindle holder MK 2 - Drill spindle stroke with drilling depth fine adjustment 90 mm - Pneumatic feed unit PV 12 - throat depth 670 mm - 4 spindle speeds 320 + 560 + 1000 + 1600 rpm - mot. Stroke of the drilling unit Itedpfx Aajur H Ehonsr - Table clamping x + y - Minimum quantities Lubrication - Pneumatic connection 6 bar - 400 V connection - Space requirement approx. W 1750 x H 1600 x D 1000 mm - Weight approx. 1200 kg - various guide cartridges

Condition: good (used), spindle diameter 105 mm x 600 mm-TRAVEL y-travel 400 mm spindle throat 475 mm Ijdpfeuldt Nex Aanetr Spindle speed - infinitely variable 70-2000 U / min table surface 800 x 400 mm Automatic spindle movement weight of the machine approximately 2.5 t

Year of construction: 2018, condition: excellent (used), Drilling machine with coordinate deduction system, little use, fully programmable. Isdpfjpcgybox Aanetr Specification: Model: APOLLO TRAP + SPEEDY Serial no: T6104130618 Year: 2018 Force: 3.4 KN Weight: 620 kg Made in: Italy If you have more questions, we will be happy to answer them.

Condition: used, machine/vehicle number: 52 / 519, spindle diameter:90 mm x-travel:700 mm distance between columns:900 mm size of table:770 x 900 mm x-Travel:700 mm y-travel:500 mm z-travel:1100 mm feed range - table:15 - 280 mm/min rapid traverse Z-axis:530 m/min spindle bore diameter / taper:MT4 (Morse) mm spindle bore diameter:max. 230 mm spindle stroke - max.:170 mm spindle speeds low range:10 U/min spindle speed high range:2000 U/min vertical feeds of spindle head::0.02 - 0,2 mm/r feed steps:6 Main spindle capacity:3 kW total power requirement:4,2 kW weight of the machine ca.:4 t dimensions of the machine ca.:1,9 x 2,2 x 2,4 m Hauser (SIP) High Precision Co-ordinated Jig Boring Machine, Model - M5 Itodpoh Ra Stjfx Aaner Douple Column Design Boring machine Large table (900 x 770 mm) for bulky Objects. All Axis are equipped with Fine Dial for High Presion Boring. A Complete Accesseries and tools are Avilable with the machine ( Drill Bits, Drill Chucks, Multiple Boring heads, Boring Inserts and Bits, Small and large rotary index table for small and big loads).

Condition: excellent (used), Henri Hauser M5 DR jig boring machine spindle diameter 90 mm x-travel 700 mm y-travel 500 mm Drilling capacity in steel 40 mm spindle mounting MK 4 drilling spindle stroke 170 mm number of spindle revolutions 2 infinitely variable 10-2000 rpm Boring diameter max. 230 mm Table dimension - longitudinal 900 mm Table dimension - crosswise 770 mm Vertical travel of cross beam 630 mm Drilling spindle 6 pieces Iedpfxjg Ibuxj Aanstr from/to 0.02-0..20 rpm Clearance between uprights 900 mm Passage between spindle and table 815 Spindle motor 4.0 HP Total power requirement 380 V Machine weight approx. 3.9 t Complete factory closure, large selection of storage platforms, pallet racks, shelf racks, paternosters. High-quality industrial machines, lathes, grinding machines, hand machines Further articles - new and used - you will find in our shop! International shipping costs on request!

Condition: like new (used), CNC vertical jig boring machine WMW MIKROMAT Travel X: 1120 mm Travel Y: 710 mm Spindle travel Z: 315 mm Travel W: 630 mm Numerical Command: CNC NUM 1060 Spindle: Ø 125 mm Cone: SA40 Ijdpfsgy E Dpex Aanetr Rotation: from 36 to 2240 RPM Table size: 1400 x 900 mm Distance between colums: 1080 mm Maxi distance spindle nose/table: from 0 to 900 mm max Maxi eligible load on table: 1000 kg max Separate electrical panel Machine renewed in 2000 with CN NUM1060 Voltage: 380 V Dimensions (L x W x H): 4000 x 2460 x 3030 mm Weight: approx. 9 T

Condition: used, Year of construction: 1996, spindle diameter 60 mm x-travel max. 1000 - min. 100 mm y-travel max. 1000 - min. 100 mm bore capacity in steel max. 40 mm thread capacity max. M24 Thickness max. 60 - min. 5 mm spindle turning speed - stepless einstellbar 1 - 1.000 U/min feed stepless einstellbar, Eilgang 1 - mm/min feed stepless einstellbar, Arbeitsgang mm/min feed power 16 KN tool taper SK 40 spindle stroke 600 mm Iodpfxegvkkzs Aanstr positioning speed in allen Achsen 1 - 10.00 mm/min positioning accuracy auf 300 mm = +/- 0,01 mm table load max. 500 kg work height max. 1000 mm weight of the machine ca. 4,8 t dimensions of the machine ca. 3,5 x 3,3 x 3,1 m Control Bosch CNC plate drilling system HMB PBM1000/60 - W12 for drilling head plates and Base plates in steel construction with tool changer (12x) Number of drilling spindles: 1 pc. Operating Voltage: 220/380V Frequency: 50 Hz Total connection value: 22 kVA

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 7/61, Manufacturing origin Swiss Voltage 380/50/3 Netweight abt. 760 kg Dimensions abt. 1250x1000x1700 mm TECHNICAL DATA WORK CAPACITY Travel X and Y 200x200 mm Vertical slide travel 250 mm Travel of drilling spindle 70 mm Max free passage between table and spindle nose 330 mm Free passage between column and centre of spindle 260 mm Max drilling capacity (steel) 10 mm Max reaming capacity 50 mm TABLE Usable surface 400x300 mm Admitted load 100 kg Itjdpfxed Amgko Aanor Travels X and Y through motors Number of T-slots 6 (longitudinal) DRILLING HEAD Spindel morse taper 0 Speed of spindle 150-3000 rpm Feed of drilling spindle 0,015 mm/t PRECISION Direct reading on divided drums 0,01 mm Direct reading on verniers 0,001 mm Guaranteed precision on displacement of slide-way 0,002 mm MEASURE Measuring system direct, optical Elements of measure graduated rule, div.1mm Read-out projection screens Shifting of zero-point yes Direct read-out 0,001 mm Guaranteed positioning precision 0,002 mm Installed power 1,2 kW errors and omissions excepted data given without obligation Inventory Nr.2160006, machine equipped with : 1 turning table Ø 220 with optical measure 1 centering microscope with 3-points suspension, zoom 40x, lightening 1 centering device with dial comparator cap. 3 mm. MT0 1 centering point MT0 1 tracing tool with spring-mounted point MT0 1 center punch MT0 1 chuck for centering drills MT0 1 self clamping drill-chuck 0-5 mm., MT0 1 boring head type 0, cap. 0.5-30 mm., MT0 1 levelling foot with 2 round levelling supports

Condition: used, >> Condition very good! >> Speed: 45 - 4000 rpm. >> Fehlmann cross table: 380 x 750 mm Iedpfxsb Ecm Ts Aanjtr >> XYZ: 420/300/500 mm >> Motorized height adjustment of the drilling head
