Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW Dkjdpfxjz N E Ars Ap Dsu bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 02260002571, The Gildemeister CTX 420 Linear is a powerful and highly precise CNC universal lathe (or turning-milling center) designed for demanding series and mass production. It is primarily characterized by its linear motor technology in the X-axis, which, compared to conventional ball screws, ensures extremely high dynamics, rapid positioning, and wear-free operation. Equipment: -Single spindle, three-jaw chuck, 11-position tool turret, automatic tailstock, chip conveyor Control system: -Heidenhain Dkodsz N Etkopfx Ap Dsu Accessories: -Workbench, under-mounted telescopic drawer unit (7 drawers) Contents: Hand tools, analog and digital measuring instruments, indexable cutting inserts.

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: NL301GL1022, travel distance X-axis: 280 mm, travel distance Z-axis: 1,370 mm, overall weight: 11,500 kg, The Mori Seiki NL3000MC/2000 is a high-precision, robust CNC turning and milling center designed for heavy-duty machining and the processing of long workpieces. The model designation indicates the NL series (class 3000), and the MC version signifies that the machine is equipped with driven tools (milling) and a C-axis for milling operations. Equipment: -Single spindle, three-jaw chuck, 10-station tool turret, chip conveyor Control: -MSX-850 III (NL301GL1082) Dodpfx Aoz N Emwep Dsku Special features: -BMT technology (Built-in Motor Turret): The tool motor integrated directly into the turret minimizes vibrations and heat generation, resulting in significantly improved milling performance. -High stability: The massive flat-bed design provides excellent damping properties for hard materials and deep cuts. Accessories: -Work bench (1-door, 4 drawers), telescopic drawer cabinet (7 drawers), standing table, shelf Contents: various hand tools, various tool holders, machine accessories

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 615, overall weight: 8,700 kg, The Mori Seiki SL-303 BMC/1500 is a robust, high-precision 3-axis CNC inclined-bed turning and milling center. The model designation indicates a system with driven tools (BMC), C-axis, milling function (MC), and an extended distance between centers of 1500 mm for machining long workpieces (e.g., shafts). Equipment: -Single spindle, three-jaw chuck, automatic tailstock SMW Autoblock, 12-tool turret, automatic steady rest, chip conveyor Control: -MSG-501 (SL303-615) Key Features & Advantages: -Complete machining (Multi-Process): By using driven tools and C-axis control, milling, drilling, and threading operations can be performed directly after turning without re-clamping. -High rigidity: The massive cast iron inclined bed effectively dampens vibrations, which contributes to excellent surface finishes and a long tool life. Dkjdpfjz N Dkbsx Ap Dou -Thermal stability: Comprehensive cooling and oil circuits around the spindle minimize thermal expansion during long and heavy roughing operations. Accessories: -Workbench with partition (1 door, 3 drawers), containing: hand tools -Telescopic drawer cabinet (7 drawers), side shelf, containing: various turning tools and tool holders

Condition: used, Year of construction: 2007, functionality: fully functional, HWACHEON HI TECH 200 B FANUC CONTROL MAX TURNING DIA 350 MM MAX TURNING LENGHT 400 250 MM HYD 3 JAW CHUCK TAILSTOCK SLOTTED TURRET YEAR 2007 TOOL SETTER Dkedpfx Apjz N Dfls Deu

Condition: good (used), Hwacheon HI Eco 31A CNC Lathe, C Axis & Live Tools, Serial Number 1053444L45, Year 1998, Swarf Conveyor, Foot Pedal, Fanuc CNC Control, 2 Jaw & 3 Jaw Power Chucks, Tool Arm, Dkjdpfxsz N A Avj Ap Dou Tailstock, 10 Station Turret, Manuals, Toolholders, Transformer

Condition: good (used), Year of construction: 2013, operating hours: 1,561 h, functionality: fully functional, General Information Description Specification Manufacturer MAZAK Model Quick Turn Smart 200 CNC Control Mazatrol Smart Year of Manufacture 2013 Serial Number 249187 Total Operating Hours 11,755 hours Cutting Hours 1,561 hours Network Connection LAN Condition Very good technical condition, clean, accurate and exceptionally well maintained 2. Machining Capacity & Working Area Description Specification Maximum Swing Diameter 530 mm Maximum Swing Over Cross Slide 343 mm Bar Capacity 65 mm Spindle Bore 76 mm X-Axis Travel 195 mm Z-Axis Travel 560 mm X-Axis Rapid Traverse 30,000 mm/min Z-Axis Rapid Traverse 33,000 mm/min 3. Spindle & Tooling Description Specification Maximum Spindle Speed 5,000 rpm Spindle Motor Power 15 kW Selectable Thread Start Position Yes Through-Tool Coolant Yes Tool Turret 12 stations Turret Indexing Time 0.17 seconds per station Tailstock Automatic, MT5 Tool Measuring Arm Included Parts Catcher Included Robot Interface Additional M-function (1 pair) Smartshift BASE Quick-Change System Included Chuck SMW AUTOBLOK Collet Chuck 4. Integrated Automation – Universal Robots UR5e Collaborative Industrial Robot (Cobot) Description Specification Dksdpfx Apoz Nyn No Dou Manufacturer Universal Robots Model UR5e Year of Manufacture January 2021 Robot Type Collaborative Robot (Cobot) Usage Demonstration use only Payload 5 kg Reach 850 mm Repeatability ±0.03 mm Working Envelope 2.6 m³ Maximum TCP Speed 1,000 mm/s Joint Speed 180°/s Robot Weight 21 kg Mounting Options Floor, ceiling, wall or angled mounting Power Supply 100–240 V AC Power Consumption Approx. 200 W Controller UR e-Series Control Box Programming URScript and graphical block programming Safety Standards ISO 10218-1, ISO/TS 15066, PLd Category 3 Fieldbus Communication PROFINET, EtherNet/IP, Modbus TCP Digital I/O 16 inputs / 16 outputs Analog I/O 2 inputs / 2 outputs Tool Flange ISO 9409-1-50-4-M6 5. Robot Integration with Mazak Smart 200 The UR5e robot is fully integrated with the Mazak Quick Turn Smart 200, providing a complete automated machining solution. - Smartshift BASE quick-change coupling system - Additional M-function for robot interface - Pre-programmed automation sequences - Quick switching between manual and robotic operation - Video available showing the robot and machine operating together - Fully tested and used in production - Complete robot and machine integration 6. Machine Condition The machine is reported to be in excellent technical and operational condition. - Fully operational and functioning correctly - No active alarms or critical faults - Smooth movement on all axes - Spindle runs smoothly without abnormal vibrations - Linear guides and ball screws in good condition - Hydraulic and pneumatic systems functioning normally - Regular in-house maintenance performed - Lubrication system operating correctly - Primarily used for light machining of aluminium and plastic components - Robot and CNC machine fully integrated and tested 7. Documentation Available - Machine photographs - Video of machine operation - Complete machine manuals - Electrical diagrams

Condition: ready for operation (used), functionality: fully functional, Biglia 510 2T lathe with hydraulic spindle and automatic tool changer turret, designed for fitting production. Dsdpjz Nwmcjfx Ap Djku Included with the machine is a second chip conveyor and spare drive components for the numerical control, previously removed from an identical machine.

Condition: used, Year of construction: 2007, Gildemeister CTX 520 linear CNC turning machine Gildemeister Type/Model: CTX 520 linear Condition: Used Year of manufacture: 2007 Technical data Working area max. turning diameter: 680 mm Turning diameter over X-axis guide: 565 mm Chuck diameter: 250/315 mm Spindle bore: 107 mm Spindle speed C-axis (main spindle): 400 rpm Travel in X-axis: 315 mm Travel in Z-axis: 1350 mm Number of tools: 12 Power max. 100% duty cycle: 4.9 kW Torque 100% duty cycle: 10.5 kW Spindle speed range: 4500 rpm Tailstock Tailstock stroke: 1200 mm Tailstock force: 14 kN Taper: 5 MK Quill stroke: 120 mm Coolant system Capacity: 250 l Pump power: 1.7 kW Dkjdpfx Apsz Ng R De Dju Flow rate at 6 bar: 20 l/min Connected load: 65 kVA / 100 A Operating voltage: 400 V Dimensions and weight Weight approx.: 10 t + 0.65 t Dimensions approx.: 6000 x 3050 x 2270 Equipment - Chip conveyor Inquiry item: Transport costs will be provided in an individual offer.

Condition: good (used), Year of construction: 2000, functionality: fully functional, Mori Seiki SL 250, Dedpfjz Nglbex Ap Djku Year of manufacture: 2000, Control system: Mori Seiki, Travel range X/Z: 235/495 mm, Travel range of counter-spindle: 505 mm, Spindle speed up to 3,500 rpm, Spindle bore: 86 mm, Turret: 10-station, Driven tools up to 4,000 rpm, Machine weight: approx. 5,600 kg.

Condition: good (used), Year of construction: 2010, functionality: fully functional, turning length: 995 mm, turning diameter: 660 mm, spindle speed (min.): 35 rpm, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,045 mm, rotational speed (max.): 12,000 rpm, bar passage: 65 mm, total height: 2,597 mm, total length: 3,820 mm, total width: 2,348 mm, spindle nose: A2-6, overall weight: 9,570 kg, We are pleased to offer this well-maintained CNC turning and milling machine. It is a Mazak Integrex 200-IV S, manufactured in 2010, fitted with the Mazatrol Matrix control system. Technical specifications: Turning diameter: 660 mm Max. turning length: 995 mm Bar capacity: 65 mm Travel on X-axis: 580 mm Travel on Y-axis: 150 mm Travel on Z-axis: 1,045 mm Travel on W-axis: 1,490 mm B-axis travel: –30 to 210° Main and counter spindles: 5,000 rpm C-axis indexing of both spindles: 0.001° Dodpjz Ndu Eefx Ap Doku Milling spindle: 12,000 rpm (Capto C6) Tool magazine: 40 tool positions We realise that you may wish to receive further information or view the machine. In that case, please contact us, providing your company details so that we can get in touch with you. About Mamach Machinehandel: With over 40 years’ experience in the CNC machinery sector, we are now one of Europe’s leading suppliers of metalworking machinery. Our success is based on high quality, customer-focused service and a strong international network. Discover our wide range of used CNC lathes and machining centres – we’d be happy to advise you personally!

Condition: used, Year of construction: 1999, Technical details: turning diameter over bed: 665 mm turning dia. over face-slide: 530 mm turning length: 750 mm max. turning diameter: 395 mm longitudinal traverse (z-axis): 500 mm facing movement (x-axis): 600 mm control: TX8H spindle passage: 80 mm revolution per minute: 60 -12.000 U/min tool turret - number of stations: 24+1 operating hours - idle run: 26466 h operating pressure: 6 bar diameter of quill: 85 mm quill stroke: 140 mm Dkjdpsz Ndq Tefx Ap Deu tool taper: ISO 40 total power requirement: 36 kW Weight approx.: 6,6 t dimension machine approx.LxWxH: 4,8 x 3,5 x 2,8 m The TRAUB TNA 400 is a high-performance CNC turning machine designed for the precise complete machining of turned parts. Equipped with the proven TRAUB TX8H control system, the machine is suitable for both single-part and series production. It features a hydraulic chuck, tailstock, and a fully enclosed working area with a coolant system. Its robust design ensures high precision and reliable process stability in continuous industrial operation. Equipment: ·TX8H CNC control ·Swivel table ·Central lubrication system ·Coolant system ·Spindle cooling ·Spindle air blow function ·Working area lighting ·Chip flushing nozzles ·Electronic handwheel ·Leveling elements ·Signal tower light ·Manual wash gun ·Macro programming ·NAVI-MILL workshop programming ·Programming cycles ·Program runtime calculation ·Parts counter ·Intelligent handwheel ·Tool magazine with 24 + 1 tool positions *

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, * Mori Seiki NL 2500 SY. * Year 2009. * 5-axis machine. * Sub-spindle. * Y-axis. * C-axis. * 1.5-meter LNS bar loader. * 12-station turret, all stations motorized. * Y-axis travel: ±60 mm. * C-axis on both spindles. * Integrated main spindle motor: 18 kW. * Integrated sub-spindle motor: 15 kW. * Direct-drive motor for powered tools: 5.5 kW. * Motor starting torque: 640 N·m. * Motors without belts or gearboxes. * Main spindle size: A2-8. * Sub-spindle size: A2-6. * Bar capacity: 80 mm. * 250 mm Kitagawa B-210 main spindle chuck with metric system. Dkodpfx Apsz Nc Sve Deu * 210 mm Kitagawa B-208 sub-spindle chuck with metric system. * Prismatic guides on all axes. * Main spindle speed: 4,000 rpm. * Motorized tool speed: 6,000 rpm. * Daikin oil cooler for both spindles. * Mapps 4 conversational automatic programming system. * Automatic force control and tool wear monitoring. * Rapid traverse speed: 30 m/min on the X and Z axes. * Turret indexing time: 0.2 seconds. * Two Renishaw arms for automatic tool measurement. * Communication ports via USB, PCMCIA card, and RS-232. * Installation interface for bar feeder. * Automatic workpiece collector. * Dual foot pedal for independent opening and closing of the main spindle and sub-spindle. * Side-mounted hinged chip extractor with integrated particle filters. * Extensive selection of static and motorized tool holders. * Electrical transformer. * Documentation, parts list, electrical schematics, programming guide, and operating manual. * Weight: 6,200 kg. * Machine currently in operation. * Immediate delivery, unless sold immediately.

Condition: used, Year of construction: 2002, functionality: fully functional, CNC turning machine Gildemeister Type: CTX 420 V6 Linear Year of construction: 2002 Technical data: Working area: Max. swing diameter over X-axis 680 mm Swing diameter over X-axis 565 mm Chuck diameter 200/250 mm Z-axis travel 260 mm X-axis travel 635 mm Spindle head: Spindle head (flat flange) 170 main spindle, 140 counter spindle Spindle diameter at front bearing 120/90 mm Spindle bore 79/57 mm Main drive: Power of the AC main drive (100% duty cycle) 25 kW Torque max. 270 Speed range 25-5000 rpm Counter spindle Drive power AC 25 kW Torque max. 7000 Nm Speed range 35-7000 rpm Tool turret Number of tool stations 12 Tool holder according to DIN 69880 Cylindrical shank diameter 40 mm Indexing time 30°, 0.15 sec. Number of driven tools 5 Drive power 13.2 kW Torque 28 Nm Speed max. 4500 rpm C-axis, main spindle/counter spindle Speed range 0-250 rpm Torque 200/120 Nm Speed for point positioning 0.025 degrees Y-axis, vertical travel +/- 40 mm Dkodpfxez I T Avj Ap Deu Hydraulics Capacity, total approx. 25 l Pressure max. 80 bar Pressure for clamping device max. 70 bar

Condition: like new (used), Year of construction: 2021, operating hours: 1,400 h, CNC turning machine MT RENT T25FSY Year of manufacture: 2021 Control: SIEMENS 828 D Operating hours: 1400 h Djdpfx Apsz I R Sbs Deku Technical data: * Year of manufacture: 2021 * Control: Siemens Sinumerik 828D * Operating hours: approx. 1,400 h * Max. swing diameter over bed: 600 mm * Max. turning diameter: 460 mm * Max. turning length: 558 mm * X-axis travel: 310 mm * Z-axis travel: 620 mm * Y-axis travel: 110 mm / ±55 mm * B-axis travel / counter spindle: 650 mm * Spindle bore: 77 mm * Max. bar diameter: 65 mm * Main spindle speed: max. 4,500 rpm * Counter spindle speed: max. 4,500 rpm * Main spindle motor: 23 kW * 12-station BMT-60 tool turret * 12 driven tool stations * Tool shank: 25 × 25 mm * Max. drilling bar diameter: 40 mm * Hydraulic working pressure: 40 bar Equipment: * Y-axis * C-axis * Counter spindle * Driven tools * BMT-60 turret * WTO / QuickFlex tool holder * Bar loader * Chip conveyor * Hydraulic 3-jaw chuck * Coolant system * Workpiece/part catcher * Foot pedals * Flat guides

Condition: good (used), Year of construction: 2007, functionality: fully functional, spindle diameter: 60 mm, We are selling our INDEX G200. The machine is in excellent condition and can be inspected while powered on. It is being sold including a bar feeder, chip conveyor, and various tools. The machine has only been operated with oil. Dodpfx Apsz I Rxnj Djku The machine has X/Y/B axes!

Condition: ready for operation (used), Year of construction: 2012, operating hours: 41,280 h, travel distance X-axis: 165 mm, travel distance Z-axis: 700 mm, total height: 2,200 mm, total width: 1,630 mm, overall weight: 9,000 kg, controller manufacturer: FANUC, controller model: Series 31i-MODEL A, product length (max.): 2,800 mm, number of axes: 8, This 8-axis DOOSAN PUMA TT 1800 SY was manufactured in 2012. It features a maximum turning diameter of 230 mm and a maximum workpiece length of 700 mm. The machine is equipped with two spindles and two turrets, providing enhanced machining capabilities. If you are looking to get high-quality turning and milling capabilities, consider the DOOSAN PUMA TT 1800 SY turn-mill centre we have for sale. Contact us for further details. - Operating Hours: 41,280 h (as of Spindle Hours: 24,632 h (as of Total Machined Parts (TEIL GESMT): 14,162 pcs- Number of Spindles: 2 (Main Spindle & Counter/Sub Spindle)- Main Spindle Speed Range: 50 - 5,000 rpm- Counter Spindle Speed Range: 50 - 6,000 rpm- Number of Turrets: 2 (Tool holders)- Powered/Driven Tools: Yes- C-Axes: 2- Y-Axes: 1 (Upper turret)- Max. Turning Diameter: 230 mm- Max. Workpiece Length: 700 mm- Power Supply Voltage: AC 200/220V, 3-Phase (PE, 50/60 Hz) / 400 V, 50 Hz- Rated Power (Nennleistung): 75.21 kVA- Full Load Current (Volllaststrom): 197.37 A- Interrupting Capacity (Unterbrechungsstrom): 13 kA- Short-Circuit Current (Kurzschluss-Strom): 25 kA- Schematic Output (Schaltplan-Ausgabe): PT1H31AA02- Additional Equipment & Accessories: * FMB turbo 8-80/3200 bar feeder * Chip conveyor * Coolant system with belt filter * Internal coolant supply (IKZ) & supply via turret head * Hydraulic power unit * Large selection of tool holders, collet chucks (REGO-FIX / ER), and turning inserts Technical Specification Dodpjz I Rbvefx Ap Djku Counter Spindle Yes Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2010, Make: SPINNER Type of machine: TC 400-52 MC Year of manufacture: 2010 Control system: Siemens SINUMERIK 840D SolutionLine Machine's weight: 4.000 kg Tool holder: VDI 30 / DIN 69880 x-travel: 200 mm y-travel: nicht vorhanden z-travel: 515 mm Speed range: bis 5.000 U/min Dodpjz I Nawefx Ap Dsku Spindle lock: A6 Cutting diameter: 280 mm Driven tool: Ja Turning length: 500 mm Chip removal device: Ja Tailstock: Ja, hydraulisch / MK4 Overall dimensions: 2.100 × 1.350 × 1.800 mm (ohne Stangenlader) Chuck size: 210 mm Chuck size: 210 mm Traverse Z-axis: 515 mm Tool turret - slots: 12 Counter spindle: Nein C-axis: Ja Spindle opening: 52 mm

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, turning length: 1,073 mm, turning diameter: 380 mm, spindle speed (max.): 3,500 rpm, travel distance X-axis: 255 mm, travel distance Y-axis: 110 mm, travel distance Z-axis: 1,100 mm, bar passage: 81 mm, total height: 1,960 mm, total length: 3,805 mm, total width: 2,100 mm, overall weight: 5,800 kg, Equipment: documentation/manual, Hyundai WIA SE2600LSY is a high-performance CNC turning centre equipped with a Y-axis and sub-spindle for complete machining of complex components in a single setup. The machine features a FANUC i-Series control, BMT55 live tooling with speeds up to 6,000 rpm, and a maximum turning diameter of 380 mm. It is equipped with a 10" main spindle and 6" sub-spindle, providing excellent flexibility for both turning and milling operations. Optional equipment included: Automatic tool setter 15 bar high-pressure coolant pump Chip conveyor with chip container Bar feeder interface Parts catcher Dedpoz Izngefx Ap Deku Standard set of tool holders, including 2 + 2 live tool holders

Condition: used, Year of construction: 2015, functionality: fully functional, NAKAMURA NTJ-100, CNC turning and milling center with FANUC 31i-B control Dkjdsz Iy Uropfx Ap Dju • C-axis on the left spindle • C-axis on the right spindle • Milling drive on the upper turret • Milling drive on the lower turret • B-axis on the upper turret +/-91° • Y-axis +/- 40 mm on the upper turret • Y-axis +/- 32.5 mm on the lower turret • Bar capacity left 42mm A2-5, 6000 rpm • Bar capacity right 42 mm A2-5, 6000 rpm • 12/24 + 6 stations under 45° turret, top • 12/24 stations turret, bottom • 90° inclined bed • Interface for bar loader magazine, Hommel • Air blow-out, right spindle • Drive power left, FANUC AC11/7.5kW • Drive power right, FANUC AC 11/7.5KW • Chuck pressure monitoring, right and left • 19" touch monitor • Door lock • Clamping force control • Helical interpolation • NT-Nurse 2 • NT-Work navigator • Feed rate and rapid traverse adjustment switch • Transformer • CE marking • Memory capacity 2560 meters • Tool offset memory 99 items • Program management 2000 programs • Extended editor function • Background editor • Macro B • Direct input of drawing dimensions • G52-G59 • Polar coordinate interpolation • Cylindrical interpolation • Current documentation • Machine color RAL 9002, light gray • Door color RAL 7011, iron gray • Chip conveyor RAL 7024, graphite gray Machine options NTJ-100 Air and coolant blow-out through the right spindle Ø 65mm NTJ-100 Chuck blow-out, left spindle NTJ-100 Intelligent handwheel NTJ-100 Polygon turning function Manual tool probe, removable for left and right Workpiece unloading NTJ-100 Unloading with gripper hand on the upper turret for parts up to Ø 65 mm x length 150 mm / 3.0 kg NTJ-100 Material collection tray type A with enclosed collection box, left, for material remnants and finished part ejection, part size up to spindle bore 65 mm NTJ-100 enlarged main spindle, left, Ø 65 mm, spindle nose A6 NTJ-100 enlarged counter spindle, right, Ø 65 mm, spindle nose A6 Chip disposal Hinged belt chip conveyor for NTJ-100, discharge right. Manufacturer: AME. Color: RAL 7024. Motor right, in the direction of travel.

Condition: used, Year of construction: 2019, operating hours: 9,000 h, machine/vehicle number: IntNr231662, A high-performance and versatile Doosan LYNX 2100 LSYB CNC turning/milling center, manufactured in 2019, with approximately 9,000 operating hours, is for sale. Technical data Manufacturer: Doosan Machine Tools Model: LYNX 2100 LSYB Control: Doosan-FANUC i Machine type: CNC turning/milling center Year of manufacture: 2019 Operating hours: approx. 9,000 h Working area Max. turning diameter: approx. 300 mm Max. turning length: approx. 510 mm Swinging diameter over bed: approx. 600 mm Swinging diameter over cross slide: approx. 400 mm Bar capacity: approx. 65 mm Travel distances X-axis: approx. 205 mm Y-axis: approx. 105 mm / ±52.5 mm Z-axis: approx. 560 mm Travel distance of counter-spindle / B-axis: approx. 560 mm Main spindle Spindle speed: up to approx. 4,500 rpm Spindle power: approx. 15 kW Spindle taper: ASA A2-6 Spindle bore: approx. 76 mm Bar capacity: approx. 65 mm C-axis: included Counter-spindle Max. speed: approx. 6,000 rpm Power: approx. 5.5 kW C-axis: included Automatic workpiece transfer between main and counter-spindle Tool turret Turret: BMT45P Dkjdpsz Itiiefx Ap Deu Tool stations: 12 Powered tools: available Max. speed of powered tools: approx. 6,000 rpm Rapid traverse rate X-axis: approx. 30 m/min Z-axis: approx. 36 m/min Dimensions and weight Machine weight: approx. 4,200 kg Dimensions L × W × H: approx. 2,880 × 1,710 × 1,920 mm The machine can be inspected by appointment. Subject to changes, errors and prior sale!

Condition: excellent (used), Year of construction: 2019, Vertical CNC lathe – 3 axes Brand: HYUNDAI WIA Type: LV 800 RM Year: 2019 (575 cutting hours) CNC: FANUC 32iB + manual guide Specifications: Turning capabilities: Maximum swing diameter: 890 mm Maximum turning diameter: 800 mm Maximum turning height: 800 mm Dkjdsz Iqlnjpfx Ap Dsu Horizontal travel: 440 mm Vertical travel: 800 mm C-axis: 360,000 positions 3-jaw hydraulic chuck: Diameter: 530 mm Rotation speed: 2000 rpm Main motor power: 37/30 kW Dimensions (width x depth x height): 2000 x 2877 x 3300 mm Weight: 11 tons Equipped with: 12-tool turret C-axis 0.001° Rotating tool spindles 7.5 kW, 3000 rpm Through-tool coolant supply 20 bar Renishaw Quickset Rotating tool holders: 3 x axial, 3 x radial Turning tool holders Set of chuck jaws Manual 3-jaw chuck, dia. 630 mm Chip conveyor

Condition: used, Year of construction: 2012, functionality: fully functional, Spinner TC 600 65 SMCY with C-Y axis and sub-spindle Technical data: max. swing diameter ~600 mm max. turning diameter ~400 mm max. turning length ~650 mm Travel X/Y/Z: X 275 / +50/-40 / Z 700 max. rapid traverse X/Z 15/24 max. speed 4500 rpm spindle power 22 kW torque 250 Nm max. speed sub-spindle: 6000 rpm chuck 165 mm spindle power sub-spindle: 10 kW tailstock 8 taper socket MK4 Dksdez Iqf Ujpfx Ap Dju Number of tools: 16 tool holder: VDI 30 max. speed rotating tools: 5000 rpm power (60%): 6 kW torque (60%) ~30 Nm Weight: 5,000 kg Dimensions: 2.5 m × 1.6 m × 2 m Accessories: chip conveyor tool holders extraction system

Condition: good (used), Year of construction: 2003, functionality: fully functional, turning length: 600 mm, turning diameter: 324 mm, travel distance X-axis: 260 mm, travel distance Z-axis: 635 mm, rotational speed (max.): 5,000 rpm, bar passage: 65 mm, GILDEMEISTER CTX 420 linear V3 Year of manufacture: 2003 Control system: Heidenhain Plus IT / DataPilot Machine type: CNC turning machine Design: C-axis and driven tools Working area: Swinging diameter over bed: 680 mm Swinging diameter over cross slide: 565 mm Max. turning diameter: 324 mm Max. turning length: approx. 600–635 mm Travel in X-axis: 260 mm Travel in Z-axis: 635 mm Main spindle: Speed range: 20–5,000 rpm Drive power: 37 / 25 kW Max. torque: approx. 390 / 270 Nm Bar diameter: approx. 65 mm Spindle bore: approx. 79 mm Tool turret: 12-position Sauter tool turret Tool holder: VDI 30 Driven tool stations: up to 12 Speed of driven tools: up to approx. 4,500 rpm Power of tool drive: approx. 12.2 kW C-axis: C-axis available Rapid traverse rates: Rapid traverse rate X-axis: up to 60 m/min Rapid traverse rate Z-axis: up to 45 m/min Tailstock: Tailstock available Arbor mounting: MK 5 Tailstock travel: approx. 580 mm Machine data: Machine weight: approx. 6,000–6,500 kg Dimensions L x W x H: approx. 3,500 x 2,460 x 2,100 mm Typical equipment: Driven tools C-axis Dsdpfxsz Iqc He Ap Djku 12-position turret Tailstock Chip conveyor Coolant system

Condition: refurbished (used), functionality: fully functional, turning diameter: 200 mm, rotational speed (max.): 6,000 rpm, Control system: Siemens 840 Dsl General Bar diameter (HS): 60 mm Bar diameter (GS): 60 mm Milling spindle Milling spindle: HSK D-50 Tool holder I (X/Y/Z/B) Technology: Tool turret with 14 stations Tool holder: HSK D-50 Tool drive: 6,000 rpm X-axis: 155 mm Y-axis: +/- 60 mm Z-axis: 590 mm B-axis: 360° swiveling Tool holder II (X/Z) Technology: Tool turret with 14 stations Tool holder: VDI 25 W-shank Tool drive: 6,000 rpm X-axis: 105 mm Z-axis: 400 mm Dkodpfxez Ip Iue Ap Deu Equipment Chip management: Hinged belt chip conveyor Coolant management: Switchable coolant pump, 8/80 bar Bar loader: UNIMAG interface Control function: “Guide unit” for cross slide 2 Warranty: 12 months
