Condition: good (used), Year of construction: 2012, Technical data – SD22P • Table dimensions: 410 x 210 • Maximum workpiece dimensions: 650 x 420 x 240 • Table travel: 300 x 200 • Electrode stroke: 370 • Guide travel: 100 • Column travel: 100 • Spindle speed: 200 RPM Kodpsx Tquxofx Adwjll • Electrode diameter: 0.1 to 3.0 • Electrode length: up to 400 Distance between guide and table • Standard: 50 to 240 • Maximum: 300 Installation / mechanics • Required floor space: 120 x 130 x 210 cm • Weight: 750 • Dielectric tank: 20 L • Filter: cotton / paper Electrical • Voltage: 200 V, 220 V, 346 V, 380 V, 420 V, 440 V (575 V Canada new) • Power (standard): 4 kVA • Switching device: Power FET Settings • T-ON: 0 to 99 • T-OFF: 0 to 99 • IP: 0 to 15 • STAB: 0 to 9 • GAP: 0 to 9 • SERVO: 0 to 9 Current • Amperage: 25 A • Option: 50 A Disclaimer • Technical data are provided for information only, may contain errors, and are subject to change at any time without prior notice.

Condition: not inspected (used), Year of construction: 2003, functionality: unexamined, total height: 2,000 mm, total length: 1,500 mm, table width: 220 mm, overall weight: 700 kg, table length: 460 mm, No reserve price – guaranteed sale to the highest bidder! The machine is being sold at auction due to closure of operations. Bidding requires timely collection between 26.01.2026 and 29.01.2026! TECHNICAL DETAILS Table dimensions: 460 x 220 mm Hole size: 0.2 - 3.0 mm MACHINE DETAILS Electrical data Operating voltage: 380 V Frequency: 50 Hz Connection: 3.8 kVA Kodpexqn Hksfx Adwsll Dimensions & weight Dimensions (L x W x H): 1,500 x 1,100 x 2,000 mm Weight: 700 kg

Condition: good (used), Year of construction: 2016, X-Axis Travel (mm): X-Axis Travel (mm): X-Axis Travel (mm): Worktank length: Worktank width: Worktank height: Kodpfew Tc Hfox Adwoll Max. workpiece length: Max. workpiece width: Max. workpiece height: Max. workpiece weight: Taper angle/height: Automatic Wire Feeding: Length x width x height: Weight (kg): Worked power hours: The technical data and illustrations are not binding. They are not warranted characteristics and are subject to change.

Condition: used, Year of construction: 2012, functionality: fully functional, machine/vehicle number: 709863, overall weight: 828 kg, Specifications (Hot and Cold Side) PS max: 10bar TS min: 0°C TS max: 110°C V: 39L PT: 13bar Klsdpfxjwrh I Hj Adwsl Fluid group:2 The Funke plate heat exchanger FP405-61-1-N-0 is a high-quality device that efficiently transfers heat between two media. Its innovative design allows effective and reliable heat transfer in various industrial applications. The heat exchanger is characterized by its robust construction and easy handling, ensuring a long service life and low-maintenance operation. It is ideal for use in heating, cooling, or process systems where efficient energy use and precise temperature control are required.

Condition: good (used), Year of construction: 1997, High-speed EDM drilling machine, KOTON Type: EDM-KTH-202A.. In good condition with cooling and filter unit. Machine documentation available. Klsdpfxjwmn Sze Adwsl See data sheet for specifications.

Condition: like new (used), Year of construction: 2022, functionality: fully functional, travel distance X-axis: 1,460 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 700 mm, total height: 2,850 mm, total length: 2,500 mm, total width: 2,400 mm, workpiece weight (max.): 6,000 kg, table width: 800 mm, overall weight: 6,000 kg, type of input current: three-phase, table length: 1,800 mm, drilling depth: 500 mm, Technical equipment -Automatic swivel head +-45 degrees -Preparation for rotary swivel axis -High quality of drive axes and guides -Integrated compressor cooling units for electronics and external Kjdpfx Asvppxpodwell connection option for dielectric cooling -High erosion performance thanks to MOSET generator -Fine filter for working with small pipe diameters EROSIX CONTROL -Fast probing -Simple programming for complex 5-axis machining -Extensive measuring cycles -Program transfer and storage via TCP/IP interface -High operating comfort

Condition: like new (used), Year of construction: 2022, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 700 mm, total height: 2,800 mm, total length: 1,350 mm, total width: 1,260 mm, workpiece weight (max.): 300 kg, table width: 450 mm, overall weight: 2,300 kg, type of input current: three-phase, table length: 888 mm, drilling depth: 500 mm, Technical equipment -4-way guide changer -32-way electrode changer -Preparation for rotary swivel axis -High quality of drive axes and guides -Integrated compressor cooling units for electronics and external connection option for dielectric cooling Klodpjvppw Sofx Adwjl -High erosion performance thanks to MOSET generator -Fine filter for working with small pipe diameters EROSIX CONTROL -Fast probing -Simple programming for complex 5-axis machining -Extensive measuring cycles -Program transfer and storage via TCP/IP interface -High operating comfort

Condition: used, Year of construction: 1975, Technical details: Ksdpeu Nu Elofx Adwoll table length: 430 mm table width: 270 mm x-axis: 300 mm y-axis: 240 mm z-axis: 250 mm total power requirement: 2 kVA weight of the machine ca.: 0,72 t weight: Schaltschrank: ca. 200 kg space requirements of the machine approx.: L:0,9 x B:1,0 x H:2,1 m START HOLE EROSION MACHINE - size of cooling pond: 1000 x 510 x 900mm - incl. electric cabinet: 600 x 550 x 1400mm Machine is on sale as is, without been checked and will be sold as is! i.D. *

Condition: ready for operation (used), Year of construction: 2008, An Agie start hole drilling machine for the EDM industry is available. Travel X/Y/Z: 300mm/200mm/300mm, electrode diameter: 0.3mm-3mm, max. drilling depth: 200mm, table dimensions X/Y: 400mm/300mm, max. workpiece weight: 300kg. Machine dimensions X/Y/Z: approx. 1400mm/900mm/2000mm, weight: approx. 950kg. Documentation available. On-site inspection is possible. Klsdou Ilbuspfx Adwsl

Condition: good (used), Year of construction: 2019, functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 300 mm, Toolmaking dissolved through company takeover Klodpfst Stwwox Adwsl

Condition: used, Year of construction: 2018, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 640 mm, total height: 2,200 mm, total length: 1,780 mm, total width: 1,580 mm, table width: 450 mm, table length: 940 mm, Clamping table with M8 clamping holes Monitor 19" Kjdpfx Aotpa Adedwsll Electrode changer 18-fold Guide changer 3-fold Plastic protection at the front of the table NSD PC control unit Z-axis programming with switch-off Automatic zeroing of the Z-axis during drilling Automatic approach cycles Crash monitoring during positioning Latest generator technology with multi-pulse function Filter with filter pump Automatic intermediate guide Z-axis for 700 mm electrodes W-axis force compensation Ionizing unit Filter & high pressure pump Work light Remote control unit Ionization control Various tools in toolbox

Year of construction: 1990, condition: used, Weigl ER - 1500 Brief description: Start hole eroding machines Waldmann & Description: Immediately available from site : Start hole eroding machines Waldmann & Weigl Klsdsnzh Ivopfx Adwsl Type ER - 1500 Year of manufacture 1990 table size 500 x 500 mm installation height 400 mm twist drill 0,1 - 20 mm taps M 2 - M 20 electrodes 1 - 12 mm drilling machine Interkrenn Economy 280 S height adjustment 700 mm throat 180 mm quill stroke 80 mm speed range 120 - 2580 rpm Tool holder MK 2

Condition: as good as new (ex-display), Year of construction: 2022, travel distance X-axis: 300 mm, travel distance Y-axis: 200 mm, For sale is a start hole eroding machine bes S 32-3 Properties High drilling speed low electrode wear Kjdpfx Adeir Eahowjll table size (width x depth) 450 x 210 mm travel X/Y/Z 290 x 190 x 350 mm Motorized coarse adjustment Z 150 mm Max. Workpiece height 245 mm Max. Workpiece weight 200 kg Electrode guide adjustment 150 mm Electrode diameter 0.3 - 10 mm External dimensions of the machine 1030 x 800 x 2100 mm Net weight of the machine 600 kg Filtration canister 20 l (standard), Programmable Z-axis standard Several machines available immediately.

Year of construction: 1989, condition: good (used), Sell 2 sinker EDM machines Ksdpfx Adjhgrnhswell Complete with filter, divider, tools, smoke evacuation

Year of construction: 2020, condition: as good as new (ex-display), electrode diameter 0,5 to 3mm travels 300x400x350mm ) CE-cretification verifies the best possible safty all Machines in over-floor construction Elektrode Ø 0,5-3mm Kodpfof Hmn Aox Adwsll Travel X-Axis 300mm Travel Y-Axis 400mm Travel Z-Axis 350mm Travel W-Axis 300mm Speed W Axis 30-60mm/min Rapid feed Z-Axis 120mm/min removal rate (max.) 300:1 Table dimension 320x440mm max.generator capacity 30A
