UNIMEC Srl

Condition: like new (used), Year of construction: 2016, operating hours: 9,018 h, functionality: fully functional, turning length: 500 mm, turning diameter over cross slide: 290 mm, turning diameter: 240 mm, spindle speed (max.): 6,000 rpm, spindle bore: 73 mm, travel distance X-axis: 210 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 525 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 23 m/min, rapid traverse Z-axis: 30 m/min, spindle nose: 140h5, overall weight: 4,300 kg, Equipment: documentation/manual, rotational speed infinitely variable, This DMG MORI CTX alpha 500 V6 is in excellent condition and shows 9,018 spindle hours. The machine is very comprehensively equipped and was recently professionally cleaned. This CTX alpha 500 is fitted with: - Main spindle with HAINBUCH TOPlus mini Axzug 65 chuck. Itsdpsxpwyqsfx Aabjn - Sub-spindle with HAINBUCH TOPlus Kombi Axfix 65 chuck. - LNS Quick Load Servo III bar feeder. - DMG CELOS software. - Chip conveyor. - Workpiece catcher/discharge unit. - Tool measuring arm. - Double foot pedal for clamping/unclamping both main and sub spindle. - Various tooling (driven & static). - Various HAINBUCH collets and clamping jaws. - Rinsing gun. - All original documentation (NL+DE).

Condition: used, Year of construction: 2015, Technical details: turning diameter: 340 mm turning length: 1000 mm control: OSP P200 L swing diameter over cross slide guide: 470 mm swing diameter max. over bed cover: 580 mm travel -x axis: 260 mm travel -z axis: 1065 mm Iodpoxpwclsfx Aabjtn rapid travel - longitudinal/face: 30 / 25 m/min bar material dia.: 52 mm spindle diameter: 80 mm Spindle RPM: 5000 1/min spindle drive: 22 / 15 kW turret stations / rotary tool stations: 12/12 VDI 40 : 7 kW speed of driven tools: 6000 1/min Tailstock Travel: 1015 mm tailstock quill taper MT: 5 total power requirement: 38,7 kVA weight of the machine ca.: 6500 kg dimensions of the machine ca.: 4 x 2,5 x 2 m memory: 2 GB Accerories Power Chuck Kitagawa B 206 150 mm Chip conveyor Signal lamp 2 colors manual tool eye High precision Turning and Milling Centre with turret for milling tools and main spindle with C- axis. - Easy programming by MAPPS III Control. - programmable tail stock - Chip conveyor - Chuck set KITAGAWA with chuck B 212 - High pressure coolant system 20 l / 5bar - *

Condition: good (used), Year of construction: 2011, Müga TT - 42, year of manufacture 2011, Mitsubishi M 700 control, bar machining up to 42 mm, sub-spindle, 2 turrets, driven tools, workpiece catcher, workpiece conveyor belt, chip conveyor, intelligent handwheel, short bar loader 1m, reduction tubes. Ijdpfoxpulkox Aabetn

Condition: excellent (used), With sub-spindle With C-axis, with Y-axis MAZAK Mazatrol Nexus control Turning length -538 mm Swing Diameter -675 mm Turning diametre 380 mm Spindle speeds 35- 5'000 + 35- 6'000 rpm Tool changer with 16 driven positions Bar loader Tool presetter device Piece catcher attachment Misc. accessories Itsdoxpugbopfx Aabsn MARCELS MASCHINEN CH

Condition: used, Electric spare parts Operational panel Full electric cabinet All parts, see pictures Machine was in full working condition. Fixed price, loaded on transport Iodexpn Rgepfx Aabjtn Parts can be seen upon appointment.

Condition: good (used), Year of construction: 2018, CNC lathe DOOSAN Puma 4100XLMC with Fanuc control; Iedpfx Asxph U Esabjtn Only 2,000 spindle hours!!! 3m turning length with programmable hydraulic steady rest SLU 4; Spindle bore 165 mm; All axes are flat-guideways – suitable for heavy-duty machining; Spindle with gearbox – over 2,400 Nm; Chip conveyor, tool setter, extraction system; 380 mm chuck installed, plus an additional 530 mm chuck; Various fixed and driven tool holders;

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Isdpfxsxphk Te Aabstn Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, Turning length: 3,000 mm Swing diameter over cross slide: 520 mm X-axis travel: 600 mm Y-axis travel: 150 mm Z-axis travel: 3,150 mm Swing diameter: 520 mm Turning length: 3,000 mm Control: SIN 840 D Siemens Z-axis: 3,150 mm Z-axis feed rate: 1 – 40,000 mm/min Rapid traverse Z-axis: 40.00 m/min X-axis: 600 mm X-axis feed rate: 1 – 30,000 mm/min Rapid traverse X-axis: 30.00 m/min Main spindle S1 Spindle speed range: 1 – 3,300 rpm Drive power at 100% load: 29.00 kW Spindle nose DIN 55026 – size A11 Spindle diameter at front bearing: 160 mm Spindle bore: 115 mm C-axis: 360 x 0.001° Milling spindle S2 Tool holder: Capto C6 Infinitely variable speed range: 1 – 6,000 rpm Ijdpfx Aasxpfd Debetn Y-axis: -100 / +150 mm B-axis: -110 / +110° Tool magazine with 100 stations Total power requirement: 145 kW Machine weight approx.: 24 t

Condition: used, Year of construction: 2001, turning length: 400 mm, turning diameter: 420 mm, spindle speed (max.): 5,000 rpm, bar passage: 60 mm, total height: 1,850 mm, bar diameter (max.): 60 mm, overall weight: 5,500 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK, power: 44 kW (59.82 HP), number of spindles: 2, space requirement length: 2,450 mm, space requirement width: 1,400 mm, CONTROLS .. CNC controls SIEMENS SINUMERIK BASIC FUNCTIONS .. design principle: inclined bed .. number of spindles: 2 .. - counter spindle: yes .. number of turrets: 2 .. number of c-axes: 2 .. number of y-axes: 1 WORKING RANGE TURNING .. swing diameter (max): 420 mm .. turning diameter (max): 200 mm .. bar diameter (max): 60 mm .. worpiece length max.: 400 mm MAIN SPINDLE .. spindle revolutions (max): 5000 /min .. spindle bore diameter: 60 mm .. c-axis: yes COUNTER SPINDLE .. spindle revolutions (max): 5000 /min X/Z SLIDE .. number of tool positions (total): 14 .. - rotation speeds (max): 6000 /min .. - drive power: 5.5 kW TOOL MAGAZINE .. number of positions: 14 ELECTRICAL SPECIFICATIONS .. total power consumption: 44 kW .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 2450 mm Itodsxpdt Rspfx Aabjn .. space requirements -front/back-: 1400 mm .. total height: 1850 mm .. total weight approx.: 5500 kg ATTACHMENTS (TURNING) .. chip conveyor: yes Accessories - Chip conveyor - Iemca Master 880R bar feeder

Condition: ready for operation (used), Year of construction: 2021, operating hours: 13,392 h, Control Unit Brand SIEMENS Iodpoxn U Dkofx Aabotn Model 840D with ShopTurn 3G Main Drive Spindle speed range 6000 Spindle motor power 13/14 kW Tool taper ISM 52 Synchro Number of axis 5 Media Chip conveyor Yes Additional Equipment CELOS Products DMG MORI Service Agent DMG MORI NetService DMG MORI IoT Connector DMG MORI Messenger V2 SERVICE Camera Tail Stock the 2 SMW-Autoblok BBD17/52 which can also be seen on the machine chuck. and the addition of the software (tccentric turning and milling cycle, as well as a deburring toothing cycle). This 5-axis DMG MORI CTX Alpha 500 V6 was manufactured in 2021. A versatile turn-mill centre featuring a Siemens 840D controller, ERGOline interface, and CELOS manufacturing support. It offers a 470 mm machining length, 6000 rpm max speed, and a 12-position Sauter turret with live tooling. Ideal for complex machining tasks. Contact us for more information about this machine. Application Types Turning

Condition: used, Year of construction: 1999, operating hours: 56,000 h, functionality: fully functional, machine/vehicle number: 01780000621, turning length: 1,097 mm, turning diameter over cross slide: 320 mm, turning diameter: 455 mm, spindle motor power: 30,000 W, spindle speed (min.): 18 rpm, spindle speed (max.): 3,600 rpm, spindle bore: 107 mm, travel distance X-axis: 320 mm, travel distance Z-axis: 1,097 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 30 m/min, chuck outer diameter: 315 mm, The price includes various tool holders and 4 driven tools. Itedpfexn Sfxjx Aabjn

Condition: new, Year of construction: 2022, operating hours: 173 h, functionality: fully functional, machine/vehicle number: TJPM1003, turning length: 640 mm, turning diameter over cross slide: 215 mm, turning diameter: 215 mm, spindle motor power: 15,000 W, spindle speed (max.): 5,000 rpm, spindle bore: 51 mm, travel distance X-axis: 190 mm, travel distance Y-axis: 90 mm, travel distance Z-axis: 660 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 12 m/min, rotational speed (max.): 6,000 rpm, type of input current: three-phase, bar diameter (max.): 51 mm, Equipment: documentation/manual, rotational speed infinitely variable, Japanese Takisawa TM-2000 Y2 turning center with two turret, and Y axis (both), sub spindle and Fanuc 0iTF Plus controller. Demo machine with 173 h running time. Options: Kitagawa BB206 3 jaw chuck for main spindle Kitagawa B206 3 jaw chuck for sub spindle SMW (Mario Pinto) PPBE-42 collet chuck for main spindle SMW (Mario Pinto) collet chuck for sub spindle Itedpfx Asxn Sapjaben Raku-Raku monitor controller option Abnormal load detection function 9 bar high pressure coolant Bar feeder interface Remaining bar discharge device Tool setter (manual) Workpiece unloader with conveyor Chip conveyor Static toolholders 2 pcs axial rotary toolholder

Condition: ready for operation (used), Year of construction: 2013, operating hours: 15,000 h, Main Drive Spindle speed range 12000 Tool taper Capto C6 Number of axis 5 Movement Y-Axis Movement 230 mm A-Axis Movement 1550 mm Workpiece Workpiece drm over bed 1000 mm Itsdpoxn Dl Djfx Aabon This 5-axis DOOSAN Puma MX2600ST turn-mill centre was manufactured in 2013. It features a maximum turning diameter of Ø 760 mm, part length up to 1540 mm, and bar capacity of Ø 76 mm. Equipped with a Fanuc 31i-A control, dual spindles with speeds up to 4000 rpm, and a milling spindle at 12,000 rpm. Includes a tool magazine with 80 positions and a swarf conveyor. Consider the opportunity to buy this DOOSAN Puma MX2600ST turn-mill centre. Contact us for more information. Application Types Turning

Condition: good (used), Year of construction: 2007, Brand: Mori Seiki Type: NT3200 Year of build: 2007 Serial number: NT320GA0030 Additional information: Run time: 7976H Maximum turning diameter (milling head): 600mm Maximum turning diameter (turret): 210mm Maximum turning length: 1045mm Spindel bore: 67mm Number of tool spaces: 40 Spindel: Kitagawa SS1666 Spindel speed: 5000 RPM Control system: Fanuc Series 31i Equipped with: tool presetter,Absolent AB oil mist filter, Enomoto chip conveyor, Ercoatius coolant filter, documentation Milling head Maximum speed: 12000 RPM Tool shaft size: C5 X-axis travel: 685mm Y-axis travel: ±125mm Z-axis travel: 1075mm B-axis travel: ±120° X/Z-axis rapid traverse: 50 m/min Y-axis rapid traverse: 30 m/min Turret Number of tool places: 12 Driven tool speed: 6000 RPM X-axis travel: 130mm Z-axis travel: 970mm X/Z-axis rapid traverse: 30 m/min Machine dimensions LxWxH: 5200x3100x3000mm Own weight: 14400 kg Including bar feder Brand: Iemca Type: VIP 80E II Year 2007 S/N: 020710QA07 Own weight: 605 KG Bar capacity: 6-80mm Isdpfx Aaexn Ddtobetn

Condition: used, Year of construction: 2007, turning diameter 300 mm turning length 600 mm control FANUC, 18i-TB turning diameter over bed slide 230 mm travel x1 165 mm travel z1 700 mm travel x2 190 mm travel z2 720 mm travel -y axis +/- 50 mm main spindle bore 76 mm main spindle speed 5.000 U/min main spindle drive 22 kW max. torque on the spindle 208 Nm sub spindle bore 76 mm sub spindle speed 5.000 U/min sub spindle drive 22 kW max. torque on the spindle 208 Nm tool turret 2 x 12 Stat. number of driven tool stations 2 x 12 speed of driven tools 5.000 U/min max. torque 47 Nm work piece power 5,5 kW C-axis resolution 0,001 ° rapid traverse x + z axis 20 / 40 m/min rapid traverse y-axis 7,5 m/min Isdpfx Aexn Amteabjtn total power requirement 68,4 kVA weight of the machine ca. 7,8 t Accessories: collet fixture on main spindle, hydr. 3-jaw chuck make KITAGAWA, BB 208, 210 mmø, on sub spindle, various tool holders for turret, bar loader make HYDRAFEED, model MULTIFEED MX-1B for bar dia. 3 - 80 mm and bar length up to 1650 mm, chip conveyor, coolant with belt filter device

Condition: good (used), Year of construction: 2003, Travel - x: 140 mm Travel - y: 710 mm Turning diameter: 250 mm Iodpfxjxnyu Uo Aabetn Main spindle speed: 5,000 rpm Turning length: 710 mm Tool speed: 6,000 rpm Bar capacity: 65 mm Machine weight approx.: 6,550 kg

Condition: used, Daewoo Puma 230 M C Axis CNC Lathe Year: 2000 Technical specifications - Control Unit: Fanuc 18i-T - Turning Diameter: Approx. 290–400 mm - Turning Length: 500–560 mm - C Axis - Turret: 12-station, (live tools) - Spindle Speed: 4500 rpm - Spindle Power: 15 kW - Bar Capacity: 65 mm - X-Axis Travel: 205 mm - Z-Axis Travel: 580 mm - Tailstock: Programmable counter-spindle - Chip Conveyor: Available - Bar Feeder: CK LOAD - Chuck: KITAGAWA B210, 3-jaw - Somme brand live tools will be provided. Iedpexnw Avofx Aabjtn

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, Z 1,065mm, Y 140mm, X 530mm, ATC 40 pos, HSK63, Mazatrol PC Fusion 640. weight 7.000kg Itedpfexnwp Aex Aabon

Condition: used, Year of construction: 2007, turning length: 400 mm, turning diameter: 420 mm, spindle speed (max.): 5,000 rpm, bar passage: 60 mm, total height: 1,850 mm, bar diameter (max.): 60 mm, overall weight: 5,500 kg, controller manufacturer: SIEMENS, controller model: SINUMERIK, power: 44 kW (59.82 HP), number of spindles: 2, space requirement length: 2,450 mm, space requirement width: 1,400 mm, CONTROLS .. CNC controls SIEMENS SINUMERIK BASIC FUNCTIONS .. design principle: inclined bed .. number of spindles: 2 .. - counter spindle: yes .. live positions: yes .. number of c-axes: 2 .. number of y-axes: 1 WORKING RANGE TURNING Itjdoxnv Tyopfx Aabon .. swing diameter (max): 420 mm .. turning diameter (max): 200 mm .. bar diameter (max): 60 mm .. worpiece length max.: 400 mm MAIN SPINDLE .. spindle revolutions (max): 5000 /min .. spindle bore diameter: 60 mm .. c-axis: yes COUNTER SPINDLE .. spindle revolutions (max): 5000 /min .. c-axis: yes X/Z SLIDE .. number of tool positions (total): 14 .. - rotation speeds (max): 6000 /min .. - drive power: 5.5 kW TOOL MAGAZINE .. number of positions: 14 ELECTRICAL SPECIFICATIONS .. total power consumption: 44 kW .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 2450 mm .. space requirements -front/back-: 1400 mm .. total height: 1850 mm .. total weight approx.: 5500 kg ATTACHMENTS (TURNING) .. chip conveyor: yes Accessories - Chip conveyor - Iemca Master 880MP bar feeder

Condition: ready for operation (used), Year of construction: 2007, Control Unit Brand FANUC Model 18i MB5 Movement X-Axis Movement 800 Y-Axis Movement 500 Z-Axis Movement 550 Itjdpfxoxnr Efs Aabjn Additional Equipment Approx. 20 tool holders included Bar loader short Knoll paper belt chip conveyor HL450/900 This 5-axis CHIRON Mill 800 was manufactured in 2007, featuring a swivel head, bar loader, internal cooling, and a Knoll paper belt chip conveyor. Equipped with a Fanuc 310i-model A5 and HSK-a-63, it includes about 20 tool holders. Consider the opportunity to buy this CHIRON Mill 800 turn-mill centre. Contact us for more information about this machine. Application Types Milling

Condition: used, Year of construction: 2019, max. swing dia. 695 mm max. working diameter 340 mm Max. Turning length 500 mm spindle bore 76 mm control MAZAK SmoothC max. Spindle speed 5.000 U/min. turret stations 12 driven tools turning speeds 4.500 U/min CNC Turning- and Milling Center | MAZAK - QT-Compact 200MY L equipped with C- and Y-axes, a 12-station turret set up for driven tools, a tailstock, a chip conveyor, an automation package, and an LTA air filtration system The machine is in good condition and can be inspected under power. Iedpsxnqzljfx Aabotn For further technical details, please refer to the attached offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: QTC200MYL | QTC 200MY L | QT-200MYL

Condition: used, Year of construction: 2011, DMF360 Base Machine Gantry Milling Machine X3600 Y1100 Z900mm Siemens 840D solutionline Fixed Table 4200 x 1100 mm Equipment / Accessories Built-in rotary table ø1050mm Swivel head as B-axis 20-18000 rpm Dynamic package X-Axis 80m/min Work area partition Measuring probe, laser tool measurement, tool breakage detection Electronic handwheel Blow air through spindle center Coolant supply 40/80 bar with band filter system, 1000 L tank Chip flushing and rinse gun Chip conveyor, discharge height 1250mm Air conditioning unit for drive and control cabinet Automatic doors A-Axis Lehmann EA420, right-side preparation Hydraulic clamping for fixed and rotary table Robot interface with contact pressure monitoring Interpolated turning Iodpfx Aaoxnqf Rsbstn High-speed settings Compcad – compressor function 3D machining, 3D tool correction Shutdown and automatic machine start Oil and emulsion mist extraction system

Condition: used, Year of construction: 2001, travel distance X-axis: 220 mm, travel distance Z-axis: 635 mm, This Gildemeister CTX-400 S2 horizontal lathe with CNC control is being auctioned online in our industrial auction / machinery auction for mechanical engineering companies – clearing out machinery inventory and restructuring. Itedpfxsxnqbfs Aabsn

Condition: used, Year of construction: 1996, MAZAK SUPER QUICK TURN 10 MS CNC LATHE MAKE MAZAK, MADE IN JAPAN MODEL SUPER QUICK TURM 10 MS YEAR 1996 CONTROL MAZATROL T PLUS MAX SWING 435mm SWING OVER CARRIAGE 370mm MAX. MACHINING DIA 230mm MAX. BAR WORK DIA 42mm MAX DISTANCE BETWEEN SPINDLES 705mm SPINDLE MOTOR AC11kw (15HP) SPINDLE SPEED 6000rpm 2ND SPINDLE MOTOR AC5.5kw (7.5HP) 2ND SPINDLE SPEED 6000 rpm ROTARY TOOL MOTOR AC2.2kw (3HP) ROTARY TOOL SPEED 3000 rpm TURRET TOOL CAPACITY 12 TOOLS STATIONS RAPID TRAVERSE RATE X,Z:30m/min (1180IPM),C: 400rpm MACHINE DIMENSION L x W x H, 2705mm x 1465mm x 1835mm MACHINE WEIGHT 3850kg PLUS C-AXIS SUB SPINDLE Iedpsxnpp Iofx Aabetn DRIVEN TOOLS (3 NO.S) PARTS CATCHER SWARF CONVEYOR TOOL SETTING PROBE COLLET CHUCK BUILT IN TRANSFORMER FULL SET OF MANUALS GOOD WORKING ORDER

Condition: excellent (used), Year of construction: 2022, operating hours: 5,500 h, functionality: fully functional, Fanuc control, commissioned in 2023, two turrets, all stations driven, Y-axis on upper turret, sub-spindle, parts catcher, Hainbuch chuck, chip conveyor, short bar loader, accessories. Itjdpfsxnpcujx Aabon
