Condition: excellent (used), Year of construction: 2006, functionality: fully functional, travel distance X-axis: 300 mm, feed length Z-axis: 500 mm, FOR SALE CNC LATHE Twin-spindle lathe Brand: CMZ Model: TL20 S Year of manufacture: 2006 Bodpfx Adox Au R Hsdjdk CNC GE Fanuc Series 21i-TB Tool turret capacity: 12 stations Number of axes: 3 axes Working area: X: 280 mm, Z: 500 mm, B Working speed: 4,000 rpm and on sub-spindle: 5,000 rpm Spindles: 2 spindles

Condition: used, Year of construction: 2021, 2-axis CNC lathe Haas ST20, year 2021 Turret VDI40 210mm chuck NC tailstock Chip conveyor included with the machine Bedpfjx Auybex Addodk

Condition: good (used), Year of construction: 2008, turning diameter: 320 mm, Romi G30M CNC Turn/Mill Slant Bed Lathe With Fanuc 21i-TB Control & LNS Quick Load Servo III Barfeeder Hainbuch Ø210mm Collet Chuck. Maximum Swing Ø620mm. Maximum Turning Ø320mm. Maximum Turning Length Between Centres 1,010mm. Axis Travel 'X'=255mm, 'Z'=1,010mm, 'C'=0.001° (Increment). Bar Capacity Ø65mm. Rapid Traverse 'X'=18m/min, 'Z'=24m/min, 'C'=300rpm. Spindle Speed Range 3-3,000rpm (22kW Motor). 12 Station Duplomatic Turret. Tooling Type VDI40. Turning Shank 25 x 25mm, Boring Bar Section Ø40mm, Axial/Radial Toolholder ER32. Automatic Tailstock Travel 835mm, Quill Travel 130mm, Quill Ø100mm. S/No. 016.007882.408. Bdodsx Agtgjpfx Addek With Coolant System, Kabel Schlepp Chip Conveyor, Reven Mist Extraction Unit, Signal Tower & Manuals. Floor Space Required 4,280 x 1,900mm. Weight 6,700kg.

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, turning length: 1,000 mm, turning diameter: 340 mm, Machine type: CNC lathe Manufacturer: Okuma Type: LU15-M Year of manufacture: 2000 Control: OSP-U100L Country of origin: Japan Delivery time: from stock Long turning length - 1000 mm Towable tailstock - automatic G152 Partial hollow clamping device The lathe is in very good condition. The basic and additional equipment enables this used machine to process long turning lengths of up to 1000 mm. Effective production is also possible thanks to the towable tailstock - automatic, the tool breakage / wear control, the partial hollow clamping device, the K pump and the dialog programming (IGF). An optimal machine for economical and reliable production. The machine is user-friendly and can be integrated into production immediately. Machine equipment Spindle motor VAC built 22/15 kW Long turning length – 1000 mm Towable tailstock – automatic G152 3-jaw chuck Forkardt, diameter 250 mm Steady preparation B-turret Partial hollow clamping device Dialog-IGF K-pump Bdjdpfx Aex Afz Aeddsk Tool breakage/wear control Chip conveyor Technical data Max. turning diameter: 340 mm Max. turning length: 1000 mm Travel X-axis: upper 260 mm (170+90); lower 140 mm (90+50) Travel Z-axis: upper 1,040 mm; lower 1.015 mm C-axis travel: 360° Spindle – number of travel steps: 2 – automatic Bore diameter: 62 mm A-turret (upper): 12 tools, all M-tool compatible, VDI 40 B-turret (lower): 8 tools, VDI 40 Rotating tool speed: 45~4500 min -1 Rapid feed: m/min X:15, Z:20, C:200 min -1 Tailstock quill diameter: 90 mm Tailstock quill stroke: approx. 100-120 mm Machine dimensions without accessories LxW: approx. 4800 x 2200 mm Machine height: approx. 2030 mm Weight: approx. 6900 kg Optional Transport organization and implementation Machine delivery and installation Machine commissioning and production-ready handover

Condition: like new (used), Year of construction: 2020, operating hours: 170 h, functionality: fully functional, turning diameter over cross slide: 390 mm, turning length: 510 mm, turning diameter: 390 mm, spindle bore: 65 mm, spindle speed (max.): 4,500 rpm, travel distance X-axis: 250 mm, travel distance Z-axis: 590 mm, spindle motor power: 15 W, Year of manufacture: 2020 CNC: Fanuc 0i-T Plus Bdedpfx Asxz Rlqsddsk X-AXIS TRAVEL: 250 mm Z-AXIS TRAVEL: 590 mm SPINDLE AND SUB-SPINDLE POWER: 15/11 kW Spindle/counterspindle MOTOR TORQUE: 224 / 58.5 Nm SELF-CENTERING CHUCK M/CM: 8″/6″ SPINDLE/COUNTERSPINDLE SPEED: 4500/5000 RPM SPINDLE/SUB-SPINDLE NOSE: A2-6 / A2-5 X-AXIS RAPID TRAVERSE: 30 m/min Z-AXIS RAPID TRAVERSE: 36 m/min B-AXIS TRAVEL: 570 mm TURRET: 12 MOTORIZED POSITIONS MAX TURNING DIAMETER: Ø 390 mm MAX TURNING LENGTH: 510.5 mm MAX BAR CAPACITY: Ø 65 mm MAX SWING DIAMETER: Ø 800 mm MACHINE WEIGHT: 4,200 kg OVERALL DIMENSIONS: 3847 x 1987 x 1700 mm

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, turning length: 600 mm, turning diameter: 370 mm, Machine Type: CNC Turning Machine Manufacturer: Okuma Model: LU300-2ST Year of Manufacture: 2005 Control: OSP-E100L Availability: In stock Machine Equipment: - Parts conveyor belt and collection tray – workpiece chute with removal conveyor, including electrical kit - 2 turret disks with VDI40 (12 + 8 stations) - Power chuck cylinder for hollow spindle – pull tube bore 52 mm - Expansion kit “D” – Kit one-touch IGF-D - Chuck open/close while spindle is running via M-code - Reinforced coolant pump 8 bar - Coolant can be switched on/off at turret A and B via M-function - Interface for bar feeder connection - Chip conveyor Technical Details: - Swing over bed: 530 mm - Swing over cross slide: 380 mm - Distance between centers: 600 mm - Max. turning diameter: 370 mm - Max. turning length: 600 mm - X-Axis travel: upper 260 mm / lower 140 mm - Z-Axis travel: upper 640 mm / lower 615 mm - Rapid traverse X-Axis: 20,000 mm/min - Rapid traverse Z-Axis: 25,000 mm/min - Spindle speed: 45 ~5,000 rpm - Spindle bore: 62 mm - 2 tool turrets: upper 12 stations, lower 8 stations Bdedpfxsxz Eqbe Addsk - Spindle power: 22/15 kW - Machine dimensions (L x W): approx. 2950 x 2050 mm - Machine height: approx. 2010 mm - Weight: approx. 6,500 kg Options: - Organization and execution of transport - Machine installation and placement - Machine commissioning

Condition: excellent (used), Year of construction: 2018, Maximum cutting diameter 356mm, maximum machining length 406mm, bar capacity 63.5 mm, spindle speed 4,000 rpm, 20 hp spindle motor, Bdjdpfsxz Ekuox Addok 12 station turret, coolant and tool setter.

Condition: reconditioned (used), Year of construction: 2006, CNC Lathe GILDEMEISTER CTX 420 linear Equipped with Siemens 840 D powerline control Year of manufacture: 2006 Max. turning diameter: 324 mm Max. turning length: 600 mm Max. swing diameter: 680 mm Spindle bore: 79 mm Max. spindle speed: 4,500 rpm Including the following accessories: Bedpfx Adexzt Dcededk Sliding guard with interior lighting 12-position turret with 12 driven stations Y-axis, C-axis Tool measuring device Parts catcher 3-jaw hydraulic chuck 210 mm with foot switch Hainbuch hydraulic collet chuck IRCO Breuning RBK 10012 bar feeder Signal lamp Tailstock with quill Chip conveyor Oil mist extraction Coolant system with high-pressure coolant (IKZ) and belt filter unit Operating manuals

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, MAZAK QT COMPACT 200MYL 500 U Year of manufacture: 2019 MAZATROL SmoothC Max. turning diameter: 340 mm Max. turning length: 535 mm Max. spindle speed: 5,000 rpm C-axis: 0.0001° Spindle: A2-6 Spindle bore: 65 mm Tool turret 12 tool stations 12 powered tool stations Milling spindle power: 5.5 kW Max. milling speed: 4,500 rpm Travel distances: X-axis: 215 mm Z-axis: 605 mm Y-axis: 100 mm Tailstock: 565 mm Rapid traverse X/Y/Z: 30/10/30 m/min Measuring probe Bdsdpfsxzd Sqox Addjk Bar feeder interface NC tailstock 3-jaw chuck Kitagawa BB208, diameter 210 mm Toolholder package: 8 fixed + 4 driven toolholders (2/2) Swarf conveyor – ConSep

Condition: good (used), Year of construction: 2008, functionality: fully functional, The machine is in good technical condition; inspection during operation is possible by arrangement. Bar feeder length: 1,500 mm. Equipped with Fanuc control system, new linear guides and covers installed in 2024. Runs without issues, accuracy within 0.02 mm. Bedpfx Aexy N Ihjddsdk

Condition: used, Year of construction: 2006, functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, CMZ lathe Axes X, Z, C, B Type TL 20 MS Year 2006 CNC GE Fanuc Series 31i-Model A Twin spindle With documentation With some tool holders With chip conveyor Bsdpoxy Adisfx Addjdk Can be inspected under power Video available

Condition: excellent (used), Year of construction: 2017, operating hours: 901 h, functionality: fully functional, Controller HAAS (15 inch LCD screen, USB, 1 Mb Programspeichern, Ethernet, IQS, VPC) Chuck dia D210 mm Swing dia over bed 419 mm Max. turning dia D279 mm Max. turning length 406 mm X travel 305 mm Y travel +/-51 mm Z travel 406 mm Spindle bore D88,9 mm Max. bar diameter D64 mm C axis 0,01 degree Spindle speed 4000 rpm Spindle nose A2-6 Max. driven tool speed 6000 rpm Rapid speed X/Y/Z = 12 / 12 / 30,5 m/min. Spindle power 14,9 kW Turret Hybrid 6 x BOT / 6 x VDI40 - 12-fold Tailstock sleeve MT3 Bdsdpfoxylx Nex Addsk Tailstock sleeve D95 mm Tailstock travel 508 mm Power required 400V, 40A Weight 3600 kgs Dimensions LxWxH = 3200 x 1540 x 1803 mm Accessories, features - C axis programmable - Y axis - Driven tool turret (all positions) - Integrated tool presetter - Chip conveyor - 3 jaws chuck D210 mm - Tailstock - Makros and software options - Tailstock The machine can be fine in very good condition (only 900 feedrate hours).

Condition: like new (used), Year of construction: 2022, MAZAK QUICK TURN 350MY 1500U Max. turning diameter: 830 mm Max. turning length: 1,539 mm Max. milling speed: 4,500 rpm Max. spindle speed: 3,300 rpm Max. bar diameter: 102 mm The machine is equipped with: - Mazatrol SmoothG CNC control - KITAGAWA three-jaw chuck BR-12, diameter 304 mm - Tool Eye - C-axis - Y-axis - SMW steady rest - NC tailstock Bdsdexyk Hrjpfx Addsk - Reinforced coolant pump - Chip conveyor - 8 pcs. fixed tool holders - 2 pcs. driven tool holders

Condition: good (used), Year of construction: 2007, functionality: fully functional, Description: The machine is in good technical condition, with the possibility of testing upon prior agreement. FANUC 18i-TB control system. Spindle speed: 42-4200 rpm. Main motor power: 11 kW. Turret with 12 positions (6 positions for driven tools). KITAGAWA hydraulic cylinder. Collet chuck. C-axis / Y-axis. Parts catcher. Chip conveyor. Grundfos cooling unit. Maximum spindle bore: 51 mm. Maximum machined diameter in chuck: 320 mm. Interface for bar feeder. Machine and accessory dimensions (W x L x H): Machine: 1800 x 2350 x 2200 mm Coolant tank: 2150 x 1100 x 700 mm Chip conveyor: 2100 x 500 x 1400 mm Machine weight: 3500 kg Bedpjxyix Hofx Addedk

Condition: ready for operation (used), Year of construction: 1998, Mazatrol T plus Spindle bore 40 mm Spindle speed 5000 rpm 8-position turret Bjdpfx Adjxyh Efododk No tailstock Weight 3500 kg

Condition: used, NZX 1500/800SY is a CNC Turning-Milling-Drilling Center with high precision, accuracy and reliability. Capacities: 2 turning spindles, 2 revolvers, swing diameter over bed 800 mm, max. turning Ø 320 mm, max. bar Ø 52 mm; travels Z 810 mm, X 210 mm, Y 110 mm (both carriages). Specs: spindle speeds 0–6000 t/min, spindle power 22/18.5 kW, driven tools power 7.5/5.5 kW, spindle nose JIS A2-5, spindle hole 61 mm; rapid traverse X 30 m/min, Z 50 m/min, Y 20 m/min; weight ~8100 kg; overall dims L4396×W2835×H2320 mm. Accessories: direct measuring system X axis, lamp, coolant system, coolant through counter spindle, loader interface, parts catcher, workpiece conveyor, chip conveyor. Delivers tight tolerances; typical applications: automotive, aerospace, medical, watchmaking and machine tools. Bdsdpfx Adoxx U Tmjdsk

Condition: good (used), Year of construction: 1986, controller manufacturer: TRAUB, controller model: TX 8, number of spindles: 1, CONTROLS .. CNC controls TRAUB TX 8 BASIC FUNCTIONS .. number of spindles: 1 .. number of x/z slides: 1 .. number of turrets: 1 .. live positions: yes .. number of c-axes: 1 WORKING RANGE TURNING .. swing diameter (max): 450 mm .. turning diameter (max): 350 mm .. bar diameter (max): 60 mm .. worpiece length max.: 490 mm MAIN SPINDLE .. spindle revolutions (max): 4000 /min .. c-axis: yes TOOL MAGAZINE .. number of positions: 12 ELECTRICAL SPECIFICATIONS .. total power consumption: 39 kW .. mains voltage: 400 V .. mains frequency: 50 Hz Bedjxxqbyjpfx Addedk DIMENSIONS / WEIGHTS .. space requirements -left/right-: 3150 mm .. space requirements -front/back-: 2100 mm .. total height: 2100 mm .. total weight approx.: 4000 kg ATTACHMENTS (TURNING) .. tailstock: yes - Machine in good condition Features: - Complete tool holders (very comprehensive) - Includes driven tool holders - Documentation

Condition: ready for operation (used), Year of construction: 2013, operating hours: 24,412 h, functionality: fully functional, turning length: 1,000 mm, turning diameter: 300 mm, travel distance X-axis: 235 mm, travel distance Z-axis: 1,144 mm, controller model: OSP P300L-R, TECHNICAL DETAILS X-axis travel: 235 mm Z-axis travel: 1,144 mm Turning length: 1,000 mm Turning diameter: 300 mm Swing over bed: 450 mm Turret: 12 positions – all driven Spindle speed: 45 – 4,500 rpm Spindle bore: 68 mm Tool holder: VDI 40 MACHINE DETAILS Control: OSP P300L-R Weight: 6,600 kg Bodexxi Uljpfx Addedk Operating hours: 24,412 h EQUIPMENT Chip conveyor Chuck diameter 250 mm Touch setter Tailstock

Condition: used, Year of construction: 1998, controller manufacturer: Okuma, controller model: OSP7000L, _____ Description: Year of manuf. : 1998 Control : Okuma OSP7000L Turning diam. : 340 mm Turning length : 250 mm Mainspindle: Technology:Motorspindle Speed:4.500 rpm Power (max.):22 kW Barcapacity:65 mm Workpiecemeasurement:3-Jaw chuck, Kitagawa B-210 Toolcarrier I (X/Z): Technology:Turret with 12 Stations Taper:VDI40 Movement in X/Z:260/640 mm Rapid travers in X/Z:15/20 m/min Toolcarrier II (X/Z): Technology:Turret with 12 Stations Taper:VDI40 Movement in X/Z:140/615 mm Rapid travers in X/Z:15/20 m/min Equipment/Accessory: Chipmanagement:Chip conveyor :Coolingmanagement:; Coolant pump Toolmeasurement:Automatic Measuringarm Bodpfsxxftwex Addsdk Further Equipment:Trafo

Condition: excellent (used), Year of construction: 2015, 2-axis Mazak QT200 Smart Year of manufacture: 2015 Z-axis travel: 560 mm Maximum turning diameter: 350 mm Spindle bore: 65 mm Kitagawa BB208 chuck Programmable tailstock Tool probe Parts catcher Bar feeder interface Only 3,500 operating hours Bedpfxoxxb T Ho Addedk With the machine: -documentation -chip conveyor, coolant tank and pump

Condition: used, Year of construction: 1995, LATHE DAEWOO PUMA 12 L CNC FANUC: O – T MAX. SWING DIAMETER: 570 mm MAX. TURNING LENGTH: 1,020 mm MAX. TURNING DIAMETER: 480 mm BAR CAPACITY: 90 mm SPINDLE SPEED: 12 – 2,500 RPM ASA – 8 Bjdpfxsxwvxne Addedk POWER CHUCK: 315 mm TRAVELS: X: 260 mm Z: 1,050 mm TOOL TURRET: 12 POSITIONS WEIGHT: 6,000 kg CHIP CONVEYOR

Condition: good (used), Haas ST-10 CNC lathe, year 2017. Bjdpfexwncxex Addodk

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: E2A010, MACHINE SPECIFICATION Maximum swing over bed 440mm Maximum turned diameter 215mm X axis travel 187mm Z axis travel (max. turned length) 420mm Carriage inclination 60° (slant bed) Spindle centre height (from floor) 950mm Spindle nose A2-5 Hole through spindle 64mm Maximum spindle speed 4000 rpm Spindle motor 7.5kW X axis Ballscrew (diameter and pitch) 32mm x 10mm X axis rapid traverse rate 30 m/min Z axis Ballscrew (diameter and pitch) 32mm x 10mm Z axis rapid traverse rate 30 m/min Turret tooling type VDI 30 Turret stations 12 Approximate Weight 4000 Kg Machine Equipped with Fanuc 0i-TD CNC Control System Hydraulic 3 jaw chuck 170mm diameter 5 off toolholders Coolant system Lighting Interlocked guarding Bjdpsxwk Spsfx Addsdk Manual

Condition: used, Year of construction: 2001, turning diameter 340 mm turning length 750 mm control SYSTEM TX 8H spindle passage 80 mm swing over plan sled 530 mm greates pass round over bed 665 mm turning speed range - main spindle 3.150 min/-1 drive capacity - main spindle 22 kW number of tool places 12 Pos. In our assessment, the machine is in good used condition and can be inspected under power by appointment. Two machines are available. Price per unit. Machine 1: - Images 1-5 Bdsdpfx Adexwdw Eodek - Operating hours approx. 55,790 h Machine 2: - Images 6-10 - Operating hours approx. 54,347 h Technical Features & Accessories: - Y-axis - Accessory package with rigid and driven tool holders - Chip conveyor Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Subject to changes and errors in the technical data and specifications, as well as prior sale!

Condition: good (used), Year of construction: 2005, functionality: fully functional, turning diameter over cross slide: 310 mm, turning length: 520 mm, turning diameter: 310 mm, travel distance X-axis: 210 mm, travel distance Z-axis: 610 mm, Sinumerik 810D Powerline with Shopturn CNC control 3-jaw chuck Schunk (diameter 210mm) 12-fold turret head (VDI 30 taper) C-axis driven tools tailstock coolant device chip conveyor Technische Daten / technical details: Bdodoxvy Ahepfx Addsk max. Umlaufdurchmesser über Bett / max rotary diameter over bed 600 mm max. Umlaufdurchmesser über Schlitten / max. rotary diameter over sledge 360 mm max. Drehdurchmesser / max. turning diameter 310 mm max. Drehlänge / max. turning length 520 mm Abstand zwischen den Spitzen / distance between centers 680 mm Planweg (x) / cross way (x) 210 mm Längsweg (z) / longitudinal way (z) 610 mm max. Stangendurchmesser / max bar diameter 65 mm Drehzahlbereich / spindle speed 0-4200 UpM /rpm Drehzahl angetriebene Werkzeuge / speed of driven tools 5000 UpM /rpm Werkzeugrevolver / turret head 12 fach /holes Eilgang x,z / rapid feed x,z 24,24 m/min Antriebsleistung Spindel / drive capacity spindle 18 kW Gewicht der Maschine ca. / weight 3900 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.
