Vertical machining center

HAAS UMC-750

Condition: excellent (used), Year of construction: 2015, Machine type: 5-Axis Machining Centre (Simultaneous) Year of manufacture: 2015 Control: HAAS CNC control to DIN 66025 X-axis travel: 762 mm Y-axis travel: 508 mm Z-axis travel: 508 mm Max. spindle speed: 15,000 rpm Spindle motor power: 22.4 kW (vector drive) Spindle taper: SK 40 (DIN 69871) Max. torque: 122 Nm (at 2,000 rpm) Table dimensions: ∅ 630 x 500 mm Max. workpiece weight: 300 kg Lhjdpfxsycuiqe Adwob Number of simultaneously controlled axes: 5 C-axis rotation range: 360° continuous B-axis swivel range: -35° / +110° Rapid traverse rates (X, Y, Z): 30.5 m/min Tool magazine (positions): 40+1 (side-mounted) Coolant system capacity: 284 litres Machine weight: approx. 8.2 t Cooling systems: - Through-Spindle Coolant (TSC), 21 bar - Programmable coolant nozzle (P-COOL) - Additional coolant filtration system (25 μm) - Hand rinsing gun with coolant Measuring and probing systems: - RENISHAW probing system (WIPS-R) - Work probe - Tool measurement system Chip management: - Hinged belt chip conveyor Software & Control: - High-Speed Machining (HSM) - Ethernet interface - Macros - Coordinate rotation and scaling

Condition: excellent (used), Year of construction: 2018, Tool holder VDI 30 Tool turret with 12 stations Main spindle speed: 5,000 rpm Lhodpjx Nnbhefx Adweb Drive power: 16.5 kW Including bar feeder Including documentation

Condition: ready for operation (used), Year of construction: 2015, travel distance X-axis: 762 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 508 mm, spindle speed (max.): 15,000 rpm, number of axes: 5, This 5-axis HAAS UMC 750SS vertical machining center was manufactured in 2015. It features a spindle speed of 15,000 rpm, a CT 40 cone type, and a tool magazine with 40 + 1 places. Additional features include internal cooling and a chip conveyor. A great opportunity to buy this HAAS UMC 750SS vertical machining center. Contact us for further details regarding this vertical machining center. Extra Information Lsdpfx Aeyalkmodwohb Machine still under power Technical Specification Through-spindle Coolant Yes

Condition: ready for operation (used), Year of construction: 2021, travel distance X-axis: 762 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 508 mm, controller manufacturer: HAAS, spindle speed (max.): 12,000 rpm, spindle motor power: 22,400 W, number of axes: 5, This 5-axis HAAS UMC-750SS vertical machining center was manufactured in 2021. Consider the opportunity to buy this HAAS UMC-750SS vertical machining center. Contact us for more information. Additional equipment • Coolant tank – 208 liters with mobile cart • Programmable coolant pump (M-code controlled) // Programmable Coolant Nozzle (P-COOL) • Safe Run – crash and overload detection system • Control cabinet surge protection Lhsdpfex U Tizex Adwsb • Voltage fault detection module (EPFDM) • Second Home Position button • Remote Jog Handle with 2m cable (RJH-XL) • Memory lock key-switch • Rotary axis scales • Top cover Machine Benefits Technical Machine Benefits • 30+1 tool side-mount tool changer • Wireless intuitive probing system (wips) • Broken tool detection (btd) Extra Information Media display via M130 (images, videos, PDF on screen) Standard machine memory: 1 GB Control Unit 15" color LCD monitor with USB port Touchscreen control interface Ethernet interface HaasConnect remote monitoring HaasDrop wireless file transfer WiFi connectivity Controller High-speed machining (HSM) Rigid tapping Dynamic Work Offsets / Tool Center Point Control (DWO/TCPC) Macro programming, coordinate rotation & scaling

Condition: like new (used), Year of construction: 2017, operating hours: 59 h, functionality: fully functional, grinding length: 400 mm, grinding width: 200 mm, feed length X-axis: 510 mm, feed length Z-axis: 220 mm, feed rate X-axis: 20 m/min, grinding wheel diameter: 205 mm, distance table to spindle center: 357 mm, table load: 120 kg, type of input current: three-phase, grinding wheel width: 16 mm, spindle speed (max.): 3,600 rpm, spindle speed (min.): 1,000 rpm, overall weight: 2,100 kg, grinding spindle motor power: 2,200 W, grinding wheel speed: 3,600 rpm, input voltage: 400 V, Equipment: documentation/manual, TECHNICAL CHARACTERISTICS: Year of manufacturing: 2017 Colour touchscreen: Yes Maximum grinding lenght x width: 400 x 200 [mm] Stroke X axis (table movement): 510 [mm] Min. Stroke speed X axis: 100 [mm/min] Max. Stroke speed X axis: 20000 [mm/min] Z axis travel (transverse movement): 220 [mm] Min. distance spindle nose / table: 22.5 [mm] Max. distance spindle nose / table: 357.5 [mm] Max. load on table: 120 [Kg] Grinding wheel min. speed: 1000 [rpm] Grinding wheel max. speed: 3600 [rpm] Grinding spindle motor power: 2.2 [kW] Max. diameter grinding wheel: 205 [mm] Max. grinding wheel width: 16 [mm] Min. grinding wheel width: 6 [mm] Grinding wheel bore: 31.75 [mm] Number of running hours: 59 [h] Supply voltage: 400 [V] Total power required: 11 [kVA] Weight : 2100 [Kg] INCLUDED EQUIPMENT: x1 150 [L] coolant tank FB1/R with papertape filtration unit FB1 x1 BRAILLON electro-permanent magnetic chuck type EPEFINE 2 x1 BRAILLON magnetic chuck remote control, microprocessor-based, type T10 x5 grinding wheel flanges x1 oil chiller x1 transformer x2 service keys x1 balancing shaft x1 set of axis-brackets for transport STANDARD CONVERSATIONAL PROGRAMMING MODE: Straight and angular dressing (standard) Surface grinding, multiple plunge grinding, and face grinding (standard) INCLUDED ISO PROFILING: Wheel profiling Contour machining of workpiece Full functionality for V-shape and freeform programming on the grinding wheel, and ISO contouring on the workpiece. Ledpfxew Hf Hij Adwehb Precise positioning integrated: +/- 1 [μm] Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Similar machine to brands like Jones & Shipman, Jung, Favretto, Blohm, Studer. Also see cylindrical grinder, lathe, machining center, milling machine.

Condition: excellent (used), Year of construction: 2016, With B + C axis Working travels 762 x 508 x 508 mm Table diameter 500 mm Lhjdpfxjlhqyde Adwjb Spindle taper 40 Spindle speeds -12'000 rpm Tool changer 40 Pos. Control HAAS Coolant through spindle Misc.accessories MARCELS MASCHINEN CH

Condition: excellent (used), Year of construction: 2015, operating hours: 2,153 h, functionality: fully functional, machine/vehicle number: 1125367, Equipment: chip conveyor, rotational speed infinitely variable, Haas UMC-750 5 Axis Vertical Machining Centre with Haas CNC Control, 630mm x 500mm Table, Travels X Axis 762mm, Y Axis 508mm, Z Axis 508mm, C Axis 360deg Rotation, B Axis -35deg to + 100deg, Spindle Speed 12,000rpm, 40 Tool ATC , BT40 Spindle Taper, Swarf Conveyor, Coolant System. S/No. 1125367 (2015). Lhodex Uznfopfx Adwob Wireless probing.

Year of construction: 2024, condition: used, Grinding wheel holder:: HSK 50 E Diamond grinding wheel diameter: 50 - 250 mm max. width of grinding wheel: 70 mm Grinding wheel bore diameter: 20 mm Speed of the diamond / CBN disc spindle: infinitely variable 100 - 1000 rpm., Radius of the grinding wheel: 0-30 mm Dimensions of the dressing wheel: 180 x 25 x 31.75mm, Speed of rotation of the dressing wheel: 200 - 2000 rpm., Oscillation stroke of the dressing wheel: 0-70 mm Connected load of the motor of the dressing wheel: 2,2 kW Weight approx: 1400 kg Dimensions L x W x H: 1850x2300x2100mm, Description: Suitable for dressing and profiling diamond and CBN grinding wheels. ccesories: Total enclosure. Motor Upgrade (stronger motors for the wheel being dressed and the dressing wheel), Wheel motor strengthened to 4 kW, Dressing wheel motor strengthened to 2,2 kW, 2 Machine lights 12 V, Optical linear scale with digital display counter (0,001 mm) X, Z Axes, 2/3” TV Camera with 15” LCD monitor (microscope with zoom 15‐120X included), Lhodpfxjlfil Sj Adwob High performance swivelling angle reader (0,05°), Diamond / CBN wheel spindle speed stepless adjustable 100 - 1000 rpm, Turning speed of dressing wheel stepless adjustable 200 - 2000 rpm, Stepless oscillation speed, Automatic central lubrication, SIC Wheel dresser manual,

Condition: good (used), Year of construction: 2016, 1 used 5-axis machining centre Manufacturer: Haas Model: UMC-750 Year of manufacture: 01/2016 Recorded power-on hours: 4,960; Feed hours: 10,247 Travel X/Y/Z = 762x508x508 mm 10,000/5,000 hours Lhjdpfsxyinnex Adwjb Tool holder: SK40 40-position tool changer NC SRT table size: 630x500 mm Maximum table load: 300 kg Maximum swing diameter: 686 mm

Condition: excellent (used), Year of construction: 2019, operating hours: 5,277 h, functionality: fully functional, travel distance X-axis: 762 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 508 mm, workpiece weight (max.): 300 kg, table width: 500 mm, table length: 630 mm, overall weight: 8,500 kg, spindle speed (max.): 15,000 rpm, spindle motor power: 22,400 W, spindle nose: CT 40, number of slots in tool magazine: 40, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, CNC Machining Centre HAAS UMC 750 SS TECHNICAL CHARACTERISTICS: Lhjdpex Nf Tbefx Adweb Year of manufacturing: 2019 Number of simultaneous axes: 5 Stroke X axis: 762 [mm] Stroke Y axis: 508 [mm] Stroke Z axis: 508 [mm] Angular C axis stroke: 360 [°] Table dimensions : Ø630 x 500 [mm] Max. load on table: 300 [Kg] B axis swivelling stroke: +110 [°] / 350 [°] Spindle type: CT 40 Max. spindle speed: 15000 [rpm] Spindle power: 22.4 [kW] Tool changer magazin number of stations: 40 Lubrication tank capacity: 284 [l] Number of running hours: 5277 [h] Weight: 8500 [Kg] EQUIPMENT INCLUDED: x1 spindle 15000 [rpm] x1 through-spindle coolant x1 high-pressure coolant pump 21 bar x1 auxiliary coolant filter x1 RENISHAW wireless workpiece probe x1 calibration sphere x1 RENISHAW tool probe x1 HAAS oil mist extractor x1 HAAS remote handwheel x1 HENNIG chip conveyor, type 101435 Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. machine similar to Mikron, Hermle, DMG Mori, Mazak, Hedelius, AXA, Chiron, Matec, Reiden, Lagun, Haas, Alzmetall, as well as milling, drilling and tapping machines, and CNC grinding machines

Condition: excellent (used), Year of construction: 2023, CNC Milling and Turning Center Machine type: DMG Mori CLX 450 TC Control: Siemens 840 D sl Operate Slimline Year of manufacture: 2023 TECHNICAL DATA: Max. turning length: 1,100 mm Turning diameter: 400 mm Main spindle: ISM 65 Speed range: 5,000 rpm Drive power: 14 / 17 kW Torque: 275 / 345 Nm Spindle nose: A2-8 Bar capacity: 67 mm C-axis CNC spindle swiveling for milling and turning operations Max. speed: 12,000 rpm Drive power: 8.8 / 10.5 kW Torque: 73 / 90 Nm Tool holder: HSK 63 Tool positions: 60 Counter spindle: ISM 65 Spindle nose: A2-8 Max. speed: 5,000 rpm Drive power: 14 / 17 kW Torque: 275 / 345 Nm C-axis X-axis: 750 mm Y-axis: +/- 100 mm Z-axis: 1,100 mm B-axis: +/- 120 mm Features: Chip conveyor Direct position measuring system Chip flushing gun 3-jaw chuck: SMW-Autoblok BBD 250/78 mm 3-jaw chuck: SMW BBD 250/78 mm Ljdpfxsx Ryw Rj Adwohb Tailstock function on counter spindle High-pressure pumps: 8 bar / 20 bar Coolant tank: 600 l Oil mist extraction Probe: Renishaw RMP 40

Condition: excellent (used), Year of construction: 2016, Used 5-axis universal machining center Year of manufacture: 2016 Working area: X travel: 762 mm Y travel: 508 mm Z travel: 508 mm Spindle nose to table (max): 610 mm Spindle nose to table (min): 102 mm Table / Load capacity: Platter diameter: 500 mm Max. table load: 300 kg 7 T-slots, 63 mm spacing Spindle: Taper: CT40 Max. speed: 12,000 rpm Max. rated power: 22.4 kW (30 hp) Inline direct-drive, liquid cooled 5-axis function: B-axis (tilt): +120° to -35° C-axis (rotation): 360° Tool changer: SMTC, 40+1 positions Tool change time: approx. 1.8 s (tool-to-tool) Through-spindle coolant 21 bar Chip conveyor Renishaw measuring system Lhjdpfx Aex Rpbxedwjb Feeds: Rapid traverse: up to 30.5 m/min on all axes Max. cutting feed rate: approx. 21.2 m/min General: Coolant tank: 208 l Air requirement: approx. 113 l/min at 6.9 bar Weight approx. 6,460 kg Machine can be inspected near Heilbronn by appointment. Loading available. Buyer is responsible for transport. Technical data, accessories, and machine description are non-binding.

Condition: ready for operation (used), Year of construction: 2019, General Data Measurements width 2387 mm Measurements depth 3978 mm Measurements height 2565 mm Machine weight 8200 kg Control Unit Brand HAAS Main Drive Spindle speed range 12000 Tool taper ISO 40 Number of axis 5 Movement X-Axis Movement 762 mm Y-Axis Movement 508 mm Lodpex I S Ntefx Adwshb Z-Axis Movement 508 mm Table Table load 300 kg This 5-axis HAAS UMC-750 was manufactured in 2019, featuring a robust universal machining center with a 500 mm table diameter and a maximum table load of 300 kg. It includes a high-speed spindle up to 12,000 rpm, ISO 40 taper, and a 40-position tool changer. Ideal for complex geometries and diverse machining tasks. Contact us for more information about this machine. Application Types Milling

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, machine/vehicle number: GS1000/5-T, rotational speed (max.): 30,000 rpm, overall weight: 15,500 kg, Year of manufacture: 2014 Condition: very good Magazine: 66 x HSK63 Control: Heidenhain 530 Spindle: n=30,000 Erowa zero-point clamping system integrated into the table Erowa Robot Easy 250 automation with 6 pallets 3D probing system Oil-air lubrication of high-frequency spindle Laser measurement Spindle hours: Lhsdpfow Awmtex Adwob

Condition: ready for operation (used), Year of construction: 2014, operating hours: 60,000 h, Control Unit Brand HAAS Main Drive Number of axis 3 Spindle Speed 12000 RPM Tool taper BT 40 This 5-axis HAAS UMC-750 was manufactured in 2014. It features a vertical machining center with a 12000 rpm spindle, BT40 tooling, and a 70-tool holder capacity. Additional highlights include coolant through spindle, a probe, toolsetter, and high-speed machining capabilities. Consider the opportunity to buy this HAAS UMC-750 vertical machining center. Contact us for more information about this machine. Application Types Lsdpfx Asx Ixh Nsdwehb Milling
