Parts washer

ITS Cleaner

Condition: as good as new (ex-display), Year of construction: 2022, 1.0 ft. Ultrasonic Cleaning Device Manufacturer: AIR FRESH SERVICE INDUSTRIEFILTER Type: 1-Chamber Cleaning System Rodsv Nztxspfx Agujcb Inner Tank: 750 x 600 x 770 mm Year of Manufacture: 2022 THIS DEVICE HAS NEVER BEEN USED.

Condition: like new (used), Year of construction: 2023, operating hours: 800 h, functionality: fully functional, total length: 1,400 mm, total height: 2,300 mm, total width: 250 mm, workpiece weight (max.): 72 kg, For sale: Nearly new automatic powder coating line, installed in 2023, with approximately 800 operating hours. Current layout footprint: approx. 12 x 28 m, H 5 m. Price and dismantling timeline subject to individual agreements. Redpox H Tadefx Aguecb Layout modifications available: pre-treatment tunnels can be added, and the curing oven can be reconfigured as a straight-through tunnel suitable for parts exceeding 6 meters in length. We can provide a complete quotation including dismantling and international relocation upon separate arrangement. Excellent opportunity to acquire an almost-new line at a lower price and with much shorter lead times compared to a new installation. Monorail conveyor: - Speed: 0.9 – 3.3 m/min - Automatic lubrication - Automatic chain tensioning unit - Chain pitch: 270 mm - Total length: 131 m - Total load capacity: 9500 kg - Steel supports between the floor and conveyor Automatic powder coating booth Gema: - PVC booth: MagicCompact EquiFlow BA04 - MagicControl 4.0 control panel - Photo-cell frame for automatic gun control - 16 x OptiGun GA03-P automatic guns - 1 x OptiSelect GM04 manual gun - 17 x OptiSpray AP01.1 powder feed pumps - OptiCenter OC07 powder feeding system - Ultrasonic sieve US07 for OptiCenter - 2 x ZA07-23 reciprocators with X-axis automatic control - MonoCyclone EZ05-16, 16,000 m³/h - Powder filter: 16,000 m³/h, 30 kW - Big-Bag system for waste powder collection - CO₂ explosion protection system - Manual spray wall / trolley unit shown in pictures NOT INCLUDED Powder curing oven: - Hybrid heating (electricity or gas) — offers unique flexibility to choose the most economical energy source - Installed capacity: 300 kW - Max. temperature: 220°C - Siemens PLC control panel

Year of construction: 2025, condition: new, Ultrasonic bath UEC 300 is industrial solution for cleaning large and heavy parts that are very dirty. The machines contain a pneumatic elevator capacity of 200 kg. Working frequency is 28kHz with sweep technology. The machine consists of a main ultrasonic bath with three side ultrasonic piezo transducers and second, overhead bath with oil separator. Control is with high quality touch screen HMI with 3D display notifications. Complete bath is made from acid resistance stainless steel AISI304 thickness 2mm. ----- Characteristics : Platform size : 900x570mm Maximum load : 200 kg. Useful height : 400mm Rjdpfxsgd Uifo Aguscb Ultrasonic power : 3kW(6kWp-p) Ultrasonic frequency 28 kHz with sweep mode Heater power : 9kW FEATURES : Touch screen 7 " with 3D notification Automatic water filling system. Automatic elevator mode work Level sensor Elevator position sensors Cover sensor Warranty : 2 years. WE HAVE AND OTHER MODELS ON STACK

Condition: used, HIGH SPEED DOWEL CROSS-CUT AND CHAMFERING MACHINE LOSER MOD. AA220 - Range of working diameter: 6 - 18 mm - Capacity: about 7,500 - 15,000 dowels/hour Rcjdpfx Agjqpdkcsusb

Year of construction: 1988, condition: good (used), machine/vehicle number: D 05103, Lg.No. 13439 Technical data: - Polishing wheel- grinding wheel dimension approx. 300 x 40 x 76 mm - grinding belt dimension approx. 3500 x 50 mm - contact wheel dimension 400 x 50 mm - drive speed 1450 rpm Rodpfok D Ewgjx Aguscb - drive 400 V / 1,8 kW - space requirement approx. W 1100 x H 2450 x D 800 mm - Weight approx. 300 kg

Condition: excellent (used), Year of construction: 2011, *The video is just an example of how this cell can be set up Cell with Kuka KR 180 grinding robot Grinding cell Berger 2012 (external grinding A1) - Total weight approx. 6,300 kg - Cell dimensions: approx. 4,650 x 2,400 x 3,100 mm 6-axis robot Kuka KR 180 R2500 Extra - Year of manufacture: 2011 - KRC 4 controller - Additional axis (7th axis) Belt grinding station BSS10 - Max. belt dimensions: 3,500 x 30 mm - Max. contact wheel diameter: 200 mm - Motor power: 4 kW 2 x polishing stations, - Polishing wheel diameter: 350 - 600 mm - Power: 5.5 kW Gripper change cabinet Belt conveyor Interoll Automation GmbH - Total length approx. 2,000 mm - Belt width approx. 440 mm The price includes a complete concept as shown in the video. We have 4 such cells available. Rjdpfx Agog Saqvjuocb It is possible to customize every detail as shown in the video.

Condition: as good as new (ex-display), Year of construction: 2025, These parts washers are designed for spray washing, using aqueous detergents at a temperature of 60°C maximum. All machines are made of AISI 304 stainless steel and they are models for one wash treatments. These machines function thanks to the basket’s motorized rotation around its vertical axis and they are suitable for washing small and medium-sized parts, with moderate weights. Rcedpfx Agjuxuv Aeusb

Condition: new, Year of construction: 2023, total length: 6,700 mm, total width: 1,500 mm, total height: 2,950 mm, warranty duration: 12 months, overall weight: 2,200 kg, power: 12 kW (16.32 HP), Machine height : ~2.950 mm Machine width : ~1.500 mm Machine width with open doors : ~2.950mm Machine length : ~2.950 mm Rcjdsvr Tbaopfx Agueb Table diameter : 1.200 mm Maximum work piece height : 500 mm Maximum table capacity : 500 kg Number of blast wheels : 1 x 7.5kW E-Eco Frequency inverter for turbine : 1 pcs Blasting time : Adjustable PLC : Siemens S7 1200 + TP 4'' Filter : PC2 (1.500m3/h) Total installed power : ~10,5 kW Application for sandblasting truck rims: YES Application for sandblasting pipes from 1’’(24mm) to 8’’(203mm) :YES This type of machine can be assembled before delivery, it takes just a day to prepare it for work. The machine is in stock. A test of the machine in our premises is possible with prior notice

Condition: good (used), Year of construction: 1969, 1 x Centrifuge Steimel S 3 Year of manufacture: 1969 with conical basket and lockable lid. Rcodpfx Aju Ttrvsgujb The machine is in technically flawless condition. Technical data: Max. load: 50 kg / 20 l Speed: 1,000 rpm The machine can be inspected under power.

Condition: new, Year of construction: 2021, Table polishing machine / flat polishing machine for parts up to 3000mm length. With one or two polishing units. Basic machine and control cabinet new, polishing units used but completely overhauled with new polishing motor. Redpsg D Rfmsfx Aguscb
