Used Heroal Drilling Jigs for sale (4,883)

Condition: like new (used), Heroal drilling jigs Dusdpfx Asuizl Njgmjw

Condition: used, Drill stand, drill stop, drill press stand, drill jig, drill bushing jig -Quick release device Dedpfed Rh Rcsx Agmjuw -Max. Height: 100mm -Dimensions: 400/240/H220 mm -Weight: 22 kg

Condition: used, Drilling / Jig Boring Machine CONSTANT SUPEMEC type P65 Travel X: 500 mm Travel Y: 300 mm Dsdpfx Aszg Hy Isgmouw Travel Z: 550 mm Cone: SA40 Spindle speed: from 77 to 1520 RPM Table size: Length 1200 mm x Width 420 mm Maxi distance spindle nose/table: 670 mm Mini distance spindle nose/table: 120 mm Throat depth: 300 mm Variable speed drive for X - Y Voltage: 380 V Width: 1600 mm Depth: 1800 mm Height: 2400 mm Total width with control panel: 2700 mm Weight: 3 T

Year of construction: 2014, condition: used, Max. Stanzkraft: 50 kN Stroke activation via foot switch Good condition Djdpewb Eucsfx Agmeuw

Condition: used, Year of construction: 2012, power: 20 kW (27.19 HP), working width: 1,300 mm, number of spindles: 82, plate height: 90 mm, working length: 3,000 mm, The pick-up deadlines specified in the General Terms and Conditions apply. The absolute latest pick-up date is August 31, 2026! TECHNICAL DETAILS Working area, X-axis: 3,000 mm Working area, Y-axis: 1,300 mm Maximum panel thickness: 90 mm Total number of drilling spindles: 82 Drilling units, Unit 1 (top) Spindles for vertical drilling: 31 Spindles for horizontal drilling in the X direction: 8 Spindles for horizontal drilling in the Y direction: 2 Drilling units, Unit 2 (bottom) Spindles for vertical drilling: 31 Spindles for horizontal drilling in the X direction: 8 Spindles for horizontal drilling in the Y direction: 2 Milling spindles Number of milling spindles: 2 Milling spindles, Unit 1 (top) Number of controlled axes: 3 Motor power: 4.5 kW Milling spindles, Unit 2 (bottom) Number of controlled axes: 3 Motor power: 4.5 kW Grooving units Number of grooving units: 2 Grooving units, Unit 1 (top) Unit: Fixed for creating channels in the X direction Max. tool diameter: 160 mm Motor power: 3.5 kW Grooving units, Unit 2 (bottom) Unit: Fixed for creating channels in the X direction Max. tool diameter: 160 mm Djdpfezf Ibdjx Agmsuw Motor power: 3.5 kW MACHINE DETAILS Total installed power: 20 kW Machine programming software: BIESSEWORKS EQUIPMENT Automatic panel stacking system with motorized transfer Barcode scanner (manufacturer: SICK) CE marking Protective grating Safety mats The machine is sold and delivered in its actual and legal condition (“as is, where is”) based on photographic documentation and technical/commercial documents with a descriptive nature. The buyer has the right to inspect the goods before pick-up and assumes responsibility for the installation, securing, and use of the machine at the destination. External reference: 8565

Condition: ready for operation (used), Year of construction: 2026, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 755 mm, travel distance W-axis: 500 mm, number of slots in tool magazine: 54, TECHNICAL DETAILS Type: CNC EDM drilling machine Travel in X-axis: 600 mm Travel in Y-axis: 500 mm Travel in Z-axis: 755 mm Travel in W-axis: 500 mm W-axis type: Servomotor Electrode length: 800 mm Dusdpfxozhnigo Agmsw Drilling diameter: from 0.10 mm MACHINE DETAILS Width: 1,975 mm Depth: 1,445 mm Height: 2,280 mm Height: max. 2,785 mm EQUIPMENT Electric changer with 18 stations Electric changer with 36 stations Automatic electrode and guide changer Breakthrough detection CAD import with intuitive touch operation Detection of holes by color code Automatic wear compensation Blind hole machining with depth control 3-stage discharge control Thread erosion for hardened materials M3 - M16 Generator power booster for large diameters Indexing axes, 1- and 2-axis available Large water tank with 175 l and filter system Drilling depth measurement Automatic electrode control

Condition: good (used), functionality: fully functional, machine/vehicle number: 901, travel distance X-axis: 370 mm, travel distance Y-axis: 470 mm, travel distance Z-axis: 405 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 75 rpm, table length: 500 mm, table width: 380 mm, spindle mount: MK 2, total height: 2,000 mm, total length: 1,590 mm, total width: 1,290 mm, quill stroke: 155 mm, Jig boring mill, fine boring mill, plate boring mill, table boring mill, boring mill. Duedpfsy Af Thjx Agmew -Jig boring machine: including tool cabinet with various tools -Table dimensions 380 x 500 mm -Travel: Z 405 mm/Y 470 mm/X 370 mm -Quill stroke: 155 mm -Take: MK2 (plus outer cone for spindle tool) -Speeds: 75 - 2000 rpm -Machine dimensions: 1590/1290/H2000 mm -Machine weight: 1774 kg -Cabinet dimensions: 720/460/H1000 mm -Cabinet weight: 158 kg Price negotiable Rotary table shown in one of the pictures not included Worldwide shipping can be arranged at additional charges

Condition: good (used), Stago PB 2015 Paper Drill This is the latest drill from Stago, originally from the office of a large company. The machine is 100% functional. The drill table is adjustable in all directions (sides, front/back). It has stops for setting the drilling spacing. The installed table is an enlarged version. Additionally, the drill has an automatic table lock. Dsdpfxsziyqxj Agmouw Sturdy construction – weighs approximately 70 kg. 230V power supply Two drilling heads. Drill diameter: 2-10 mm. Stack height: 60 mm. The machine has an adjustable spacing between the heads. The drill has been serviced. Drills and tools are included.

Condition: new, Year of construction: 2026, functionality: fully functional, power: 4 kW (5.44 HP), input voltage: 400 V, input current: 16 A, input frequency: 50 Hz, actuation type: electric, rotational speed (max.): 3,100 rpm, rotational speed (min.): 700 rpm, total width: 1,487 mm, total length: 4,440 mm, total height: 2,793 mm, throat depth: 1,490 mm, overall weight: 1,900 kg, Equipment: CE marking, documentation/manual, NEW | YEAR 2026 | CE CERTIFIED | MADE IN POLAND | EXW €38,000 + VAT WHY THE PRIAM The Priam is a vertical, electronically controlled glass drilling machine that does most of the work for the operator. The entire feed is electronically controlled — drilling is smooth and repeatable. The operator's role is minimal. After mounting the hole saws, they press the "Calibration" button — the machine measures the length of both drills (front and rear) and their diameter, then automatically assigns the correct spindle speed. After every drill change, the machine will not start drilling until calibration is done — setup errors are impossible. The hole position on the vertical axis is entered on the monitor and the support bar travels there automatically (up to 1,060 mm below the spindle axis); horizontally, the glass is positioned against 6 stops. The machine does the rest: the pneumatic clamp measures the glass thickness, the rear spindle pre-drills to a depth calculated by the controller, and the front spindle completes the hole from the other side — chip-free, clean edges at the first attempt. Optional: double-sided chamfering (hole saw with chamfering ring), tapered holes, and pulse drilling mode for laminated (VSG) glass. BUILT FOR SERIAL PRODUCTION Up to 20 holes on the vertical axis can be programmed — the operator enters the dimensions once and the machine drills them automatically. In serial production (shower enclosures, balustrades) the following panes are drilled without re-entering positions. Drilling at position 0 on the support bar allows holes on the glass edge (half-moon cut-outs). Performance: a Ø 75 mm hole in 4 mm glass in approx. 25–30 s (feed in glass approx. 1 mm/s, speed set by the operator). Recommended: thin-wall, self-sharpening hole saws (e.g. Champion, L=75 mm). TECHNICAL DATA Drilling diameter range: Ø 5–80 mm (both drills same diameter) Glass thickness: 2–20 mm Max. pane size: 2,000 × 4,000 mm, up to 200 kg Support bar travel: up to 1,060 mm below spindle axis Holes on the glass edge (half-moon): yes, position 0 Drilling program: up to 20 holes on the vertical axis Spindle speed: adjustable 700–2,800 RPM, assigned automatically after calibration Feed: automatic, electronically controlled Cooling: closed water circuit, approx. 30 l Compressed air: 6 bar (pneumatic clamping) Power supply: 400 V / 16 A / 4 kW Machine dimensions (L × W × H): 4,440 × 1,487 × 2,793 mm Weight: 1,900 kg Dedpfx Agsh Ek H Somsuw Scope of delivery: CE marking, documentation, operating manual MANUFACTURER, SERVICE, TERMS EXPOGLASS is a Polish manufacturer of glass processing machinery — built at our own factory in Nysa (in-house welding shop and powder coating). Service with online support; spare and wear parts available from stock. Delivery and commissioning across the EU, operator training on site. Delivery time: approx. 8 weeks. Warranty: 12 months. Visit our factory and see the Priam drill your own glass samples before you buy — video of the machine in operation in this listing. Glasstec 2026, Düsseldorf, 20–23 October, Hall 12, Stand 12A72.

Condition: excellent (used), functionality: fully functional, Detel M-35 multi-spindle drilling machine Number of spindles: 35 Spindle spacing: 32 mm Distance between extreme spindles: 1088 mm Dodpfxozh U Hle Agmeuw Drilling depth: up to 90 mm Vertical and horizontal drilling capability 4 pneumatic material clamps Drilling speed adjustment Motor power: 2 x 1.4 kW

Condition: new, Year of construction: 2026, functionality: fully functional, /// DESCRIPTION Multi-functional CNC drilling machine is able to drill from 6 sides. Independent top grooving, 5.5kw main spindle of 4-slot tool changing magzine, and 1 drilling block on top, one drilling block and one main spindle on bottom meet different process requests and gives batch-size-one production max flexibility; Software is open port, support most formats in market. Compact design, save space /// TECHINICAL SPECS Total power - 21.07 KW Machine dimensions - 3962× 3010× 2320mm Power supply - 380 V/50 Hz Air supply 0.6-0.7 MPa SYNTEC control system Panel size Length 200-2,800 mm Width 30-1,220 mm Thickness 10-60 mm Maximum travel speed X-axis/U-axis - 135 m/min Y axis - 75 m/min Z axis - 30 m/min V axis (push) - 30 m/min Drilling blocks Top 1; Bottom 1 Number of vertical drills (top) 1 Number of horizontal holes (top) X: 2*2+ Y: 2*2 Number of vertical drills (lower) 9 Maximum drill diameter Φ35 mm Distance between holes 3 Rotation speed 5000 rpm Shaft diameter Φ10 mm Drill length 7 Main shaft Dsdpfjyi Avfex Agmjuw Upper - 1*5.5 kW ER32 ATC4 18000 rpm Lower - 1*3.5 kW er25 18000 rpm Saw blade Power 1.7 kW Dimensions Ф 100* Ф 22* δ 4Center distance 6500 mm Conveying capacity approx. 0.2 t/hour Conveying speed approx. 0.5 m/sec Width of belt 500 mm Motor power 1.5 kW Operation voltage 400 V Frequency 50 Hz

Condition: new, Year of construction: 2026, functionality: fully functional, ### High-Flexibility Processing for Custom Furniture Production The NANXING ND612DCT is an upgraded industrial CNC center engineered for high-precision six-sided drilling and multi-directional routing. This model is specifically designed to provide maximum flexibility for "Batch Size One" production, allowing manufacturers to handle individual custom orders with the same efficiency as mass production. ### Key Advantages & Technologies Versatile 6-Sided Processing: Capable of full six-sided drilling, front/back and side grooving, plus front/side routing in a single seamless cycle. Specialized Hardware Support: Pre-configured to process complex joinery and fittings, including Lamello joints, LogiClip connectors, wiring channels, and sky/floor door hinge mortises. Advanced C-Axis & ATC System: Features a 5.5 kW top ATC8 spindle paired with a 5.5 kW C-axis. This configuration includes a 2-slot interchangeable cross-head for 360° rotation and multi-directional side routing. Co-Linear Drilling Efficiency: The top and bottom drilling blocks are aligned co-linearly, significantly increasing processing speeds for through-holes. Industrial-Grade Build: The monolithic frame is stress-relief tempered and processed using precision Japanese SNK equipment to ensure lifetime structural integrity. ### Technical Specifications Panel Dimensions Length: 200 – 2,800 mm; Width: 50 – 1,220 mm; Thickness: 10 – 60 mm | | Max Travel Speed | X/U Axes: 135 m/min; Y Axis: 75 m/min; Z Axis: 30 m/min | | Drilling Configuration | Top: 19 vertical, 32 X-horizontal, 22 Y-horizontal; Bottom: 9 vertical | | Main Spindles | Top: 5.5 kW ATC8 + 5.5 kW C-axis; Bottom: 3.5 kW ER25 | | Control System | SYNTEC CNC on Windows 10 platform | | Total Power / Weight | 29.2 kW / 4,900 kg | ### Standard Features & Smart Functionalities Intelligent Detection System: Equipped with high-precision sensors for automatic detection of panel length, width, and thickness to eliminate operator errors. Surface Protection: Features an automatic feeding and outfeed system with a brush device and conveyor belt to protect delicate or finished surfaces. Smart Tool Management: The user-friendly interface allows for easy tool setup and includes a life-cycle tracking function that alerts operators when tools need replacement. Open-Port Compatibility: Supports all major industry software formats, including MPR, DXF, BAN, BPP, PDX, XML, and XXL. Comprehensive Inclusions: The standard package comes with an overhead barcode scanner, mobile control console, and an air-conditioned electrical cabinet for consistent performance in any environment. ### About the Manufacturer NANXING Machinery (est. 1996) is a world-class leader in intelligent woodworking machinery. With professional assembly lines and rigorous quality control certified by CE specialists, Nanxing equipment delivers standardized performance and extreme durability for modern furniture factories. Dujdpfx Aeygtidjgmew

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, Equipment: documentation/manual, The automatic drilling machine Jet Smart is the ideal solution for craftsmen and small and medium enterprises. Flexibility, speed and ease of use are the main features of the machine which ensures high productivity and a perfect drilling in any working condition. Fast and precise drilling! Boring from the top: a choice without compromises! Perfectly aligned joints aligned and no error thanks to automatic reading of piece dimension, that allows to correct any difference between real panel length and the one set. Djdpey Rl Arsfx Agmeuw ///Technical details Max. piece dimension - 3050x900x60 mm Min. piece dimension - 200x70x10 mm Max. speed axis X-Y - 40-40 m/min Boring head: vertical / horizontal spindle, blade X - 12 / 6, 125 mm Electrospindle (S6) - 5,5 kW (7,5 HP) - 18.000

Condition: new, bore capacity in steel St 60 32 mm bore capacity in cast iron GG 20 38 mm Drilling capacity in St 60 40 mm threading in St 60 M 24 threading in GG 20 M 30 Short spindle MK 3 spindle stroke 120 mm throat 293 mm column diameter 115 mm Machine table - usable table surface 515 x 360 mm T-Slots Amount - Width - Distance 2 x 14 x 224 mm Distance spindle-table min. 117 / 701 mm feed von Hand spindle turning speed - stepless 160 - 2250 U/min Djdpfjyvvptsx Agmsuw total power requirement 1,45/1,9 kW weight of the machine ca. 260 kg

Condition: ready for operation (used), Year of construction: 2022, machine/vehicle number: 179-000-000000-000, functionality: unexamined, Machine data Designation: IMI Djdpfxozim R Eo Agmjuw Installation dimensions: approx. 2000 × 1200 × 2300 mm Weight: approx. 1500 kg

Condition: new, Year of construction: 2026, functionality: fully functional, Nanxing ND712D is a state-of-the-art 6-sided CNC drilling machine, equipped with two independent workstations, allowing for simultaneous processing of two panels and doubling productivity. This machine is designed for furniture manufacturers seeking speed, precision, and reliability within a compact footprint. Key Features - 2 independent workstations (1200 + 650 mm), each with a dedicated computer and processing units. - Optimized drilling blocks: up to 19 vertical drills + horizontal drills on the X and Y axes. - 4 main spindles (2 upper, 2 lower) with power up to 5.5 kW and 18,000 rpm. - Air-cushion tables for scratch-free panel handling. - Automatic dimension detector with alarm and panel compensation feature. - Servo-driven clamps and automatic side alignment system for maximum accuracy. - Advanced software + SYNTEC CNC control with user-friendly interface, supporting MPR, DXF, BPP, PDX, and XML file formats. - Barcode scanner for integration into automated production workflows. - Enhanced safety: side sensors, emergency stop, cable protection. Technical Specifications - Panel dimensions: Length 200–3000 mm / Width 30–650 mm / Thickness 10–60 mm - Max. traverse speed: X/U – 135 m/min, Y – 75 m/min, Z – 30 m/min - Total installed power: 43.8 kW Duodpfx Aexcwmqogmow - Weight: 6,300 kg - Machine dimensions: 6,620 × 4,620 × 2,378 mm - Power supply: 380V / 50Hz / 3 phase Application Areas - Medium and large-scale furniture manufacturing - Panel processing for kitchen cabinets, wardrobes, bathroom and office furniture - Complete 6-sided drilling + light milling in a single setup User Benefits - High productivity: processes two panels simultaneously - Error reduction: automatic dimension detection and precise positioning - Smart line integration: barcode scanner, compatible with ERP/CAD-CAM software - Optimal cost / maximum efficiency: one machine equals two drilling solutions

Condition: new, bore capacity in steel St 60 30 mm bore capacity in cast iron GG 20 30 mm Drilling capacity in St 60 30 mm threading in St 60 M 16 threading in GG 20 M 20 Short spindle MK 3 spindle stroke 140 mm throat 293 mm column diameter 115 mm Machine table - usable table surface 514 x 360 mm T-Slots Amount - Width - Distance 2 x 14 x 224 mm Dusdpfjyvvn Nsx Agmjw Distance spindle-table min. 132 / 724 mm feed von Hand spindle turning speed - stepless 100 - 1.800 U/min total power requirement 1,0/1,6 kW weight of the machine ca. 260 kg

Condition: new, bore capacity in steel St 60 30 mm bore capacity in cast iron GG 20 30 mm Drilling capacity in St 60 30 mm threading in St 60 M 16 threading in GG 20 M 20 Short spindle MK 3 spindle stroke 140 mm Djdpfxsyvvmxo Agmjuw throat 293 mm column diameter 115 mm Machine table - usable table surface 514 x 360 mm T-Slots Amount - Width - Distance 2 x 14 x 224 mm Distance spindle-table min. 132 / 724 mm feed von Hand spindle turning speed - stepless 225 - 4300 U/min total power requirement 1,0/1,6 kW weight of the machine ca. 260 kg

Condition: new, 40 mm threading in St 60 M24 threading in GG 20 M30 Short spindle MK 3 spindle turning speed - stepless 160 - 2250 U/min Dujdpfx Agjyvvmremew Center of spindle to wall or column 293 mm Column diameter 115 mm spindle stroke 120 mm Machine table - usable table surface 514 x 360 mm T-Slots Amount - Width - Distance 2 x 14 x 224 mm Distance spindle-table min. 117/701 mm feed 0,10 + 0,20 mm/U Motor output 1,45 / 1,9 kW height of the machine ca. 1840 mm weight of the machine ca. 285 kg

Condition: new, CATALOG NUMBER: M0261 TECHNICAL DATA Number of spindles: 21 Distance between first and last drill: 640 mm Distance between spindle centers: 32 mm Max. workpiece size: 50 x 915 x 3000 mm Max. drilling depth: 65 mm Number of pneumatic clamps: 2 Working table height: 860 mm Max. clamp height above table: 70 mm Working pressure: 6-7 bar Air consumption: 10 l/cycle Motor power: 1.5 kW Noise level: 76.1 dB Spindle speed: 2800 rpm Djdpfxjzh Ikkj Agmouw Dimensions (L/W/H): 1030/1030/1285 mm Weight: 275 kg PRODUCT FEATURES Main machine features: - Single-head boring machine, drilling range 0 - 90 ° - Pneumatically adjustable head inclination angle - Cast iron fences - Spindles adapted for quick-connect couplings - Patented pneumatic workpiece clamps - Cast iron work table - Fast and precise adjustment - Accurate drilling - Made in Italy Standard equipment: - 2 aluminum rulers, 1.5 m each (right and left) with two stops - 5 quick couplings - Wooden box for secure transport of the machine ADVANTAGES - Drilling vertically, horizontally, or at an angle - Multi-spindle - Brand new machine - CE certified - Robust and professional Net price: 13,800 PLN Net price: 3,330 EUR Net price calculated at an exchange rate of 4.15 PLN/EUR (prices may vary in case of significant exchange rate fluctuations) - We ship machines to every part of the country - Possibility to trade in another machine as part payment The prices provided are net prices. Net price applies to international transactions and EU customers with a valid EU VAT number. Before placing an order for a new product, please confirm availability and current price.

Condition: excellent (used), CATALOG NUMBER 6059 TECHNICAL DATA - Number of horizontal spindles: 2×20 pcs - Number of vertical spindles: 1×20 pcs - Distance between the outermost spindles: 610 mm Dodpfx Agozh H Dijmsuw - Distance between spindles: 32 mm - Feed cylinder stroke: 60 mm - Max length of workpiece: 3400 mm - Horizontal spindle adjustment: up/down, front/back - Vertical spindle adjustment: right/left - Each drilling unit can operate independently - Right/left drill bits, threaded mounting (screw-in) - 3 pneumatic clamps - Motor power: 4×1.85 kW - Air requirement: 6-8 bar - Dimensions (L/W/H): 4600x1180x2200 mm - Weight: approx. 1500 kg Net price: PLN 12,900 Net price: EUR 3,070 depending on exchange rate, reference 4.2 EUR (Prices may vary depending on exchange rate fluctuations)

Condition: good (used), Code: 0439 Brand: RIGES Djdpfx Aezk Eiiogmjuw Model: RT 25 - CE Standard Professional pillar drill for wood and metals, mounted on a steel column – CE Standard Three-phase motor Hp 2 N° 9 speeds Drilling diameter 25 mm Height adjustable and tiltable work table Work table dimensions 350 x 350 mm Overall dimensions mm 400 x 730 x 1800 h Weight kg 110

Condition: used, Year of construction: 1981, x-travel 650 mm y-travel 450 mm workpiece height 585 mm Control ADCOS CNC 400 total power requirement 15 kW weight of the machine ca. 5000 kg dimensions of the machine ca. m H A U S E R (Switzerland) CNC Controlled Hi Precision Double Column Jig Grinder Model S 40 – CNC 311 / ADCOS 400 CNC Year 1981 / CNC modernized in 2008 # 0126 _____ Table size approx. 630 x 770 mm Table load capacity approx. 500 kg Table travel longitudinal max. (X) 650 mm Grinding head slide cross max. (Y) 450 mm Vertical adjustment of cross rail max. (W) 500 mm Grinding spindle stroke max. (Z) 140 mm Stroke number of grinding head (4cycles) 0,5-12 m/min. Dedpot Hw S Uofx Agmjuw Vertical distance between Table/grinding spindle 0-585 mm Distance between columns 750 mm Conical grinding max. 16 ° Grinding-Ø bore approx. 230/360 mm 18 spindle speeds depending on spindle motor infinitely variable 4.500-80.000 rpm Fine feeds in X and Y-axis and W-axis 0,5-1.500/3.000/800 mm/min. Planetary speed (C) 5-250 rpm U-axis, radial feed 6 mm Total electrical load approx. 15 kW - 400 V – 50 cycles Weight approx. 4.500 kg Accessories/ Special Features: • CNC Pathcontrol replaced and modernized into a ADCOS Control Model CNC 400, (German Manufacturer) including large monitor and relevant software, electronic handwheel, for following axis: X=Table length, Y= spindlehead carriage cross, Z= Quill vertical/stroke, C=Quill-Rotation,U=Circular Infeed, w=Vertical adjustment of cross rail. • Z-axis as rapid stroke for shorter processing times, plunge-cut grinding, face grinding, Pre-selection of reversing stops (start movement + teach-in) and of stroke speed (infinitely variable), • U-axis as manual and controlled feed-axis radial, mounted on grinding head, with electr.display of feeding size 1 Grinding motor mounted on spindle, maybe up to a spindle speed of 30.000 rpm, • Mounted accustic grinding contact-display device KSV 5 • Separate standing coolant facility, switching- and control cabinet, separate hydraulic system, central lubrication system, dust suction, etc Condition : very good / can be inspected under power Delivery : ex stock – as inspected Payment : net – after completion of contract

Condition: used, Year of construction: 1987, x-travel 400 mm y-travel 250 mm workpiece height 485 mm Control ELESTA CNC 314 total power requirement 10 kW weight of the machine ca. 4000 kg dimensions of the machine ca. m H A U S E R CNC - Controlled Vertical Precision Coordinate Grinding Machine Model S 3 – CNC 314 Year 1987 / 1998 partially reconditioned by Swiss-HTT # 0463 _____ Table size, approx. 600 x 380 mm Max. load on table, approx. 300 kg Table travel, longitudinal, max. (X Axis) 400 mm Table travel, cross, max. (Y Axis) 250 mm Vertical adjustment of grinding head max. (W Axis) 450 mm Stroke of grinding spindle, max. (Z Axis) 120 mm Table Longitudinal and cross feeds (X/Y-Axis) 0 – 1.500 mm/min Speed of grinding head stroke 15 – 7.500 mm/min Vertical distance between table and grinding spindle, max. 0 – 485 mm Distance between grinding spindle and column 350 mm Conical grinding, up to max. 16 ° Grinding Ø bore approx. 230 mm 18 Spindle speeds, depending on spindle motor 4,500 – 80,000 rpm Planetary speeds (C-Axis) 5 – 250 rpm U Axis, radial infeed 6 mm Total electrical load, approx. 10 kW - 380 V - 50 Hz Weight, approx. 4.000 kg Accessories / Special Features: * CNC Continuous Path Control, Model CNC 314, (ELESTA-POLESTA II) with monitor,for 4 axes (XYC+U) in 2 1/2 dimension (XYC) Interpolation with a free programming,the U-Axis is not interpolating it is just an infeed axis. There is also a handwheel controldevice for setting – up purposes. Digital Read-out for the Z-Axis W Axis for vertical positioning of grinding head, Z Axis as high speed stroke axis, also for blind-hole grinding and surface grinding. U Axis for the infeed cycles during bore grinding. C Axis Feed for the of the Planetary Head. * Alltogether 2 grinding turbines 22.500 to 80.000 rpm, with some collets * Built-on Acoustic Grinding Contact Display Device Model KSV 5. * Separate coolant unit with band filter. * Built-on fire extinguishing system. Separate switch and control cabinet. Covered working area. Djdpst Hw Txjfx Agmeuw Separate hydraulic unit * Central lubrication, service tools. Condition : Very good - Machine can be inspected under power. Delivery : Ex stock - as inspected under power. Payment : Net, after conclusion of contract

Condition: used, Year of construction: 1970, bore capacity in steel (diameter) 32 mm arm length 1000 mm workpiece height max. 1400 mm total power requirement 6 kW Djdpfxot H Smyo Agmsuw weight of the machine ca. 3.700 kg dimensions of the machine ca. m
