Metal Gringing & Edge Rounding Machine

NS Maquinas OD120 + OD160

Condition: new, Model Name Rsdogvqzcjpfx Ag Njp Airtower FT 20.000

Condition: used, Year of construction: 2007, turning diameter 300 mm swing over bed 430 mm swing diameter over slide rest 300 mm control SIEMENS, SINUMERIK 840 D travel -x axis 160 mm travel -z axis 510 mm Part length max. 480 mm main spindle bore 53 mm main spindle speed 0 - 7000 U/min spindle head DIN 55026 A2-5 max. torque on the spindle 100 Nm main spindle drive 15 kW sub spindle bore 53 mm sub spindle speed 0 - 7000 U/min spindle head DIN 55026 A2-5 max. torque on the spindle 100 Nm Rodpfjwx R Rksx Ag Njp sub spindle drive 15 kW C-axis resolution 0,001 ° C-axis rapid feed 1000 U/min tool turret 1 x 12 Stat. number of driven tool stations 12 tool shaft (cylinder shaft DIN 69880) VDI 25 speed of driven tools 0 - 8000 U/min max. torque 16 Nm output 4 kW feed power X/Z axis 4000 / 6000 N rapid traverse X-axis 24 m/min rapid traverse Z-axis 30 m/min total power requirement 38 kVA weight of the machine ca. 4 t dimensions of machine L x W x H 2,65 x 1,84 x 2,32 m Accessories: collet fixture 173 E on main spindle, collet fixture 163 E on sub spindle, bar loading magazine make FMB, model turbo 3-36/3200 A, YOM 2018, for bar dia. up to 36 mm and bar length up to 3200 mm, various toolholders for turret (no driven toolholders), coolant

Condition: new, Metal Deburring and Edge Rounding Machine (Double Side). DM1100 2C, edge rounds top and bottom sides of metal parts in one single pass. This double sided operation machine deburrs metal sheets rounding its internal and external contours. Featuring 2 sets of double cross belts this machine removes sharp edges on stainless steel, steel and aluminum parts cut by laser, punching or shearing. This metal deburring machine can easily edge round parts with small dimensions, being capable of deburring different shapes and parts sizes from 50mm up to 1100mm. Processes simultaneously both sides of metal sheet parts cut by laser or punching machine, saving time and reducing operation costs. Additional conveyor belt and support table enables single side edge rounding of metal parts down to 50x50mm. Rodpfx Aod Ev Upsg Nop DM1100 2C can edge round metal parts with plastic foil, keeping the original finishing and assuring the work purely on the edges. Easy and tool free cross belt replacement. Program for automatic positioning of upper and lower cross belts in order to improve the access, reducing replacement procedure time. High performance on all edges and also on internal holes. Easy to use with an integrated touch screen for monitoring the working settings and the machine alarms. Technical Details: Working capacity (mm) 1100x50 No. Cross belt stations 2 Cross belt speed (m/s) 2-8 Feeding speed (m/m) 0.6-3.2 Cross Belt Motor (kW) (4x) 3 Feeding motor (kW) (3x) 0.18 Total power (kw) 13.1 Consumption (A) 30 Dust extraction connection (Ø mm) 150 Dimensions (mm) 2560x1980x2150 Weight (kg) 2210

Condition: used, abrasive belt measures: 50 x 100 Ø mm Rjdpfx Aeb Tcv Hsg Nsp engine: 380 V, 0,7 kW space needed: 650 x 550 x 1050 mm

Condition: good (used), The debarker is great for debarking hardwood as well as softwood. Carriage made of heavy steel construction 5 pairs of drive wheels Milling arm made of heavy steel construction Hydraulic milling head 22 kW motor Rsdpfx Ajtuyr Isg Njp Log feeder shown in the picture is not part of the ad and is available for an extra charge of 25,000 PLN / 5,500 EUR

Condition: new, Year of construction: 2023, pipe drilling machine, inclined drilling machine, automatic drilling machine TDM100, manual, with one drilling head IMMEDIATELY AVAILABLE FROM STOCK + TO BE INSPECTED UNDER POWER Rsdjlgvkispfx Ag Njp - minimum quantity lubrication - manual material clamping - manual feed - max. tube length 3.000mm (option 6.000mm) - positioning accuracy +/- 0,2mm - 10 stops (can be extended as required) - manual insertion and removal of material - drill head swivels +/- 50 - manual 360 degree tube swiveling device - power drilling unit 1 x 2,2 kW - motor speed 295 - 2950 rpm - display speed on touch panel - illumination drilling unit - integrated tool cabinet - round tube up to 114mm - square up to 100 x 100mm - flat material up to 100 x 15mm - T-profile up to 100 x 100 x 12mm - L-profile up to 100 x 100 x 8mm - Double post up to 100 x 15mm - Flow drilling up to M12 - Drilling up to Ø 50mm

Year of construction: 2003, condition: used, pressure 100 t stroke 10-130 mm Rsdpfx Aera Rr Ejg Nop no. of strokes 30-90 Hub/min throat 330 mm ram - range of adjustment 100 mm table surface area 950x660 mm ram surface 540x440 mm hole in the table Ø 230 mm table height 1000 mm tool hole in ram Ø 50 mm total power requirement 7,5 kW weight of the machine ca. 7 t

Condition: refurbished (used), Year of construction: 2013, Electrostatic air filter Indusa elstar EL4001 NVAS R/O Rjdpfx Agefyiqbo Nep There are 3 units still available. Air intake is on the lower right, air outlet is on the upper left. The air filters are from 2010–2013 and have seen very little use, as operations switched to a central extraction system in 2014. All filters have been fully overhauled, cleaned, disinfected, and fitted with new internals. The units are in excellent optical and technical condition. Each unit undergoes a 24-hour test run prior to delivery. The elstar series’ thoughtful design, high-quality workmanship, and flexible modular system form the basis of its success among electrostatic air filters. The electrostatic air filter purifies contaminated machine exhaust precisely where it is generated—making the air breathable again! The elstar electrofilter is designed for the separation of oil mist, coolant mist, oil smoke, welding fume, vapors, airborne particulates, oxidized smoke, and aerosols, making it suitable for almost any industrial application.

Condition: new, saw blade diameter 350 mm capacity 90 degrees: round 115 mm Rsdjfg Rlcjpfx Ag Njp capacity 90 degrees: square 95 mm 180 x 95 mm Working height 925 mm saw blade turning speeds 15 - 90 U/min total power requirement 3,0 kW weight of the machine ca. 0,68 t dimensions of the machine ca. 0,8 x 1,0 x 1,85 m Electro-pneumatic, vertical, linear-guided automatic saw for use of HSS saw blades to make series cuts from 60° left to 45° right steel. The machine also works in semi-automatic cycle. CNC machine with multiprocessor and two with MEP control, latest generation controlled axes that make it possible to achieve 1000 with the same material thickness different cutting programs, each with a different cutting length and number of pieces program.

Condition: new, Step By Step Wet Painting Systems Elboy Industrial Solutions designs and manufactures full range of paint shops for your product. With ELBOY, you can navigate through your facility with virtual reality in the design phase, enabling you to make the desired changes in the design phase and not to encounter the surprise results. It provides designing and manufacturing services for your application by paying special attention to environmental pollution and work safety issues for the processes of Sandblasting, Putty, Washing, Undercoat and Finishing Coat for all sizes of products. Step by Step are systems with overhead conveyor or floor conveyors which can be designed for all sizes of product. Booths of Sandblasting, Chemical Washing, Pre-coat, Drying, Putty , Top Coat and Baking can be integrated into the system. In order to respectively carry out the processes determined by the system step by step, the automatic doors are opened at the end of the time period and the product automatically proceeds to the next process line. These fully automated systems are controlled via a 15” touch screen and provide various reporting methods such as main computer monitoring, product reporting and score reporting upon the demand and provide remote control. These are the paint shops where your product is designed and manufactured by our engineers in line with your capacity, use area and other demands. Maximum efficiency is aimed to be provided with minimum staff and the least space usage at electrostatic powder coating or wet paint, sandblasting, varnishing, coating, washing and similar system requirements. Rjdpsdy Dw Asfx Ag Njp
