Condition: used, STÄHLI DLM 700 is a 2-wheels flat honing machine, designed for precision, high accuracy and reliability. Capacities: 4–8 rotor discs, max wheel Ø 650 mm, max workpiece height 100 mm, continuous load 600 daN, wheel and work drive speeds 0–100 t/min. Specs: main motor 4 kW, pin‑ring and disc drives 2 kW, total installed power 18 kW, 3×400 V 50 Hz, air 7–8 bar, weight ~3000 kg, footprint 2100×1750×2100 mm. Accessories: set of rotor discs, tool cabinet, oil mist extractor, lamp, loading/unloading table, rinsing gun. Enables tight tolerances; typical sectors: automotive, watchmaking, machine tools, aerospace, medical. Nsdpex S N Hqjfx Adwekt

Condition: excellent (used), Year of construction: 2012, machine/vehicle number: 1000-4.15.12, Lapping Machine ELP 1000/4 Serial No.: 1000-4.15.12 Year of Manufacture: 2012 Outer Diameter of Work Disc: 1,020 mm Outer Diameter of Leveling Ring: 368 mm Number of Working Stations: 4 units Lapping Plate Rotational Speed: 80 rpm Infinitely Variable Speed Control: 0–80 rpm Drive Power: 4 kW Voltage: 400 V Njdox Eznyopfx Adwskt Control Voltage: 24 V DC Control System: Simatic S7 Dimensions (L x W x H): 1,925 mm x 1,400 mm x 2,011 mm Noise Emission Level: 70 dBA Continuously Adjustable Lapping Pump: CA4, SB-3V Immersion Pump: TB25/220, 2,700 rpm Tank for Grinding and Polishing Media: 15 l Coolant Consumption: Closed circuit

Condition: good (used), LAPPING MACHINE Hahn & Kolb LHD 0 -Machine from a government institution / Original condition -Lapping plate diameter 400 mm -Max. workpiece height 120 mm -Max. distance between the cast lapping plates 80 mm -Speed range 40-80-160 rpm -Drive motor speed 700/1400/2800 rpm -Total power 1.8-2.7 kW -Facing device – manually operated -Various lapping cages Nksdpfex Dy S Ejx Adwjt -Documentation Dimensions: LxWxH 1.4x1.3x1.9 meters / Weight: 1600 kg Errors and input mistakes excepted.

Condition: used, Year of construction: 2000, honing diameter 80 / 152 mm stroke 210 mm throat 210 mm total power requirement 4,1 kVA weight of the machine ca. 1,1 t dimensions of the machine ca. 1,22 x 0,87 x 2,44 m Kennametal Extrude Hone Machine , Model 77C, Year 2000 Abrasive Flow Machining for pressure flow lapping, or flow grinding of mech. parts. Polishing and deburring or surface modifications of complex components are carried out by means of a viscous abrasive (pressure flow lapping medium) and pressure. Nsdpfx Ajx Dxxdedwjkt

Condition: excellent (used), Year of construction: 2013, operating hours: 250 h, Lapping Machine Stähli FLM 750 Manufacturer: Stähli Läpp Technik AG Model: FLM 750 Year of manufacture: 2013 Voltage/Frequency: 3x400V + N + PE / 50Hz Power consumption: 11.5 kW Max. current: 25 A Weight: 2500 kg Rotary table diameter: 750 mm Inner diameter of conditioning ring: 300 mm Nkjdpfx Adoxpnnxswst Rotational speed: 6–75 rpm Drive power: 4.0 kW Number of pneumatic cylinders: 3 pcs Compressed air supply: 6–10 bar Dimensions: 1700 x 1250 x 2200 mm Noise level:

Condition: like new (used), Year of construction: 2018, functionality: fully functional, Used CNC lapping machine Nkodpfsxg Ncxex Adwet Make: MELCHIORRE S.r.l. Model: ELC Type: 1500 Year of manufacture: 2018 Serial No: 2780/08 Weight: 14,000 kg

Condition: used, TECHNICAL DETAILS - Plate - External diameter : 750 [mm] - Internal diameter : 150 - Main motor rotation speed : 4 [kW] - Supply voltage : 380 [V] - Total installed power : 3.6 [kW] WEIGHT & DIMENSIONS - Machine floor space : 1100 x 1700 [mm] - Machine height : 2000 [mm] Njdpfxsxb Em Ns Adwokt - Machine weight : 1100 [kg] - Number of hours : 5160 [h]

Condition: excellent (used), Year of construction: 2005, operating hours: 23,900 h, functionality: fully functional, machine/vehicle number: 503982, STAEHLI DLM-705 FLAT LAPPING MACHINE Country of origin: CH Dimensions: 3300x1970x2600 mm Net machine weight: 8000 kg TECHNICAL SPECIFICATIONS Outer diameter of lapping plates: 705 mm Number of satellites: 4-8 Distance between lapping plates: < 390 mm Nkjdew Uc Hnopfx Adwot Programmable working pressure for parts to be machined: 0-200 daN Stop precision: 0.1 µm Programmable rotational speed for the lapping plates Flat honing and micro-finishing: 0-250, 300, 400, 600 min⁻¹ Central drive: 0-125, 220 min⁻¹ Machining accuracy: 0.1 µm Subject to errors or omissions; technical data is provided without guarantee.

Condition: good (used), Year of construction: 2006, functionality: unexamined, machine/vehicle number: 06 03 1000, Country of manufacture: CH Voltage: 400V Dimensions: 1200 x 1650 x 2050 mm Net machine weight: 1900 kg TECHNICAL SPECIFICATIONS Machine: Disc rotation speed: 0–110 rpm Maximum drive power for discs: 2 kW Maximum upper disc load: 20 daN Disc diameter: Ø 450 mm Internal drive rotation speed: 0–115 rpm Maximum internal drive power: 0.5 kW Disc drive motors (continuous motor): Type: DC motor Armature voltage Ua: 260 V Field voltage Ue: 340 V Rotation speed: 3110 rpm Power: 2 kW External ventilation: 220V, 50/60 Hz Internal drive motor: Motor type: smooth operating mid-position control motor Armature voltage Ua: 260 V Field voltage Ue: 340 V Rotation speed: 3110 rpm Power: 0.5 kW Separate ventilation: 220V, 50/60 Hz Vertical drive motor: Type: stepper motor Steps per second: 50 Torque: 1100 Nm Crown gear adjustment: Type: AC brake motor 2 positions Voltage: 380V / 50 Hz Rotation speed: 700–1400 rpm Power: 0.25/0.37 kW DC brake: 24V Braking torque: 16 Nm Power converters: Input voltage: 380V / 50 Hz Induced voltage: 270 V Field voltage: 340 V Worm gear reduction ratio (internal drive): Ratio: i = 1 : 30 Worm gear reduction ratio (lower system): Ratio: i = 1 : 15.5 Worm gear reduction ratio (upper system): Ratio: i = 1 : 15.5 Operating pressure: Air circuit: 6–7 bar Lapping fluid pump: Connection voltage: 380V 50Hz Nkedpfx Adew T Tpdjwot Rotation speed: 2600 rpm Flow rate: 57 L/min Protection: IP 44 Control and measurement device: Measurement range: 6 (±3 to ±11000 mm) See details in Millitron user manual Inductive probe: Measurement range: ±2 mm Setpoint adjustment device: Display: 4 digits Unless stated otherwise, all technical data are provided without guarantee and subject to change or error.

Condition: good (used), Year of construction: 2018, functionality: fully functional, disc diameter: 1,600 mm, Single-disc fine grinding or polishing machine For large components Workpiece holder Ø 1600 mm Tool Ø 500 mm to 525 mm, can be fitted with various fine grinding or polishing pads Nksdpfx Aowrpclsdwjt Control S7 with HDMI KSM tank 50 liters Polishing agent circulation system 50 liters Main drive 11 KW

Condition: not inspected (used), Year of construction: 1996, empty load weight: 800 kg, Diameter 1.5 - 160 mm Stroke 400 mm Weight 800 kg Tools Njdswgm Sajpfx Adwekt

Condition: used, Honing machine DELAPENA SPEEDHONE EA Nedpfev R Hv Ujx Adwjkt

Condition: used, Year of construction: 2015, functionality: fully functional, grinding wheel diameter: 914 mm, - Weight approx. 1600 kg - Dimensions (LxWxH) 1,820x1,820x2550 mm - Tool diameter 914 mm - Working disk diameter 36 inches - 4 stations with 304 mm inner diameter each - PLC control Siemens S7 - Separate control cabinet - Tool cooling - Protective cover over linear guides - Station forced drives for conditioning rings - KSS circulation system - 7.5 KW spindle operation - Machine table diameter 1,800 mm - Control cabinet 800x550x2,200 - CE conformity available - Bosch safety concept - Use until decommissioning for honing flat surfaces for injection systems - Machine is ready for operation Nksdevu Agdjpfx Adwet - Machine is in good condition, constant preventive maintenance - 2 CBN tools (new price of a tool approx. 30,000.00 €)

Condition: used, TECHNICAL DETAILS Nkedpfjug U D Hsx Adwot - Honing range : Ø 0,6 – 2,5 [mm] - Spindle speed : 2000 – 7000 [RPM] - Motor power : 100 [kw] - Table dimensions : 100 x 100 [mm] - Honing oil container with pump : 12 [l] - Weight : 160 [kg] - Dimensions : 650 x 500 x 700 [mm] EQUIPMENT - Plate 2 positions - Fittings with floating frame

Condition: used, TECHNICAL DETAILS - Spindle number : 1 - Honing range : Ø 1,5 - 50 [mm] - Honing stroke : 0 - 100 [mm] Nsdjug U Dyepfx Adwjkt - Spindle speed : 150 - 2500 [Rpm] - Dimensions : 1550 x 800 x 1450 [mm]

Condition: used, TECHNICAL DETAILS Nksdpfx Adeug U Dtowjt - honing diameter : 1 - 12 [mm] - honing length : 40 [mm] - 2 honing heads - 1 control head - 1 deburring unit with multispindle head

Condition: used, TECHNICAL DETAILS - Plate diameter : 348 [mm] - Part dimensions (rings) : approx. 70 [mm] - Part dimensions (full) : approx. 40 [mm] - Remaining work thickness : approx. 5 [mm] Nodpfx Aoug U Dmsdwokt EQUIPMENT - Same as on photos

Condition: used, TECHNICAL DETAILS - Plate diameter : 348 [mm] Nedpfx Asug U Dgjdwjkt - Part dimensions (rings) : approx. 70 [mm] - Part dimensions (full) : approx. 40 [mm] - Remaining work thickness : approx. 5 [mm] EQUIPMENT - same as on photos

Condition: used, Year of construction: 1975, table diameter mm workpiece height mm number of wheels 2 total power requirement 11 kW weight of the machine ca. 4,2 t dimensions of the machine ca. m Nedjub Al Ijpfx Adwokt

Condition: used, Year of construction: 1974, table diameter mm workpiece height mm number of wheels 2 total power requirement 8 kW Nedpfxeub Alzj Adwjkt weight of the machine ca. 4,2 t dimensions of the machine ca. m

Condition: used, Year of construction: 1983, table diameter 1000 mm workpiece height 25 mm number of wheels 1 total power requirement kW Nsdpfxst Hw H So Adwjkt weight of the machine ca. t dimensions of the machine ca. m

Condition: good (used), Peter Wolters AC500 lapping machine TECHNICAL DATA AND SCOPE OF SUPPLY TECHNICAL DATA Rolling device size: 42 TS 7/14 Working disk diameter: 415 mm Ring width: 54 mm Working disk thickness: 50 mm Possible wear of the disks to approx.: 20 mm Number of rotor disks: 14 Drive data: 380 V / 50 Hz Upper disk drive: 1.0 / 1.4 kW Worm gear motor: 56 / 112 rpm Nedpfx Astxitvjdwjkt Lower disk drive: 1.0 / 1.4 kW Worm gear motor: 500 / 100 rpm Workpiece drive: 0.5 / 0.7 / 0.9 kW 3-pole worm gear motor: 6 / 18 / 36 rpm Tilt arm drive: 0.25 kW Digital load adjustment of the upper work disk: 0-250 daN Connection data Electrical connection: 5.0 kW Compressed air connection: 5-7 bar Compressed air consumption: Approx. 8 Nl/min OFFER SCOPE U.A: (list not exhaustive): Peter Wolters AC 500 lapping machine / fine grinding machine 1 inverter per motor documentation Exact scope of offer according to photo gallery No responsibility is taken for the correctness, completeness and up-to-dateness of the information.

Condition: used, Perfectly working grinding machine "станка 3Л722" Basic parameters Accuracy class A Maximum workpiece dimensions (length x width x height) 1250 x 400 x 400 Maximum dimensions on electromagnet 1250 x 400 x 280 Minimum dimensions on electromagnet 50 x 40 x 3 Distance from the spindle axis to the table mirror mm 210..625 Maximum product weight kg 600 Maximum weight on electromagnet 400 Machine work table Dimensions of table work surface (length x width) 1000 x 400 Table feed speed 3..35 Grinding head Dimensions of grinding wheel ПП450х80х203 Grinding wheel speed/min 1460 Maximum grinding speed m/s 34.4 Maximum diametrical feed, mm 430 Accelerated transverse disc feed m/min 1,2 Automatic cross feed for each table feed mm/rev 1..60 Maximum vertical disc feed, mm 415 ?? 0,002 ?? 0,2 Automatic vertical disc advance, mm 0,002..0,128 Vertical accelerated advance speed, m/min 0,2 Electrical equipment Number of motors 13 Disc spindle motor power, kW 11 Hydrostatic pump motor power 4 Hydrostation air heat exchanger motor power 0,09 Lubrication system pump power 0,25 If you have any further questions, we will be happy to answer them. Nsdpoqwzt Nofx Adwokt

Condition: used, Year of construction: 2008, Technical details: max. workpiece diameter: 29 mm min. workpiece diameter: 26 mm workpiece length: 66 mm the system was originally delivered for the following workpiece sizes: diameter 26mm - 29mm length 65mm - 66mm Nedpfjlqac Sjx Adwjkt Changing parts in the clamping device, handling, etc. would probably result in diameters of up to approx. Ø50mm Total length will probably be almost 400 mm possible with a few conversions. Also dependent on tool lengths, machining lengths on the component, etc. *

Condition: ready for operation (used), functionality: limited functionality, disc diameter: 525 mm, Weight approx. 1,900 kg Nsdpfx Ajh Invrodwokt Dimensions (LxWxH) approx. 1,800x1,500x2,200 mm Working disc diameter 525 mm Largest disc ring width 175 mm Largest workpiece dimension 170 mm Speed of the working disc 45/70/90/140 rpm Main drive performance 4.0 kW Connection 400V/50Hz Emergency stop switch Conventional control with control panel Full-fledged lapping machine, conventional control
