Year of construction: 2014, condition: used, Number of sanding units 6 St. sanding width 180 mm Sanding height max. 150 mm STAEHLE Grinding Machine Type Gloria/Saturn E 180 RF ----- Stähle Hess Finish Grinding Machine Type Saturn E 180 RF (formerly Gloria) Kjdpfx Aajx Dng Donenf with 2 grinding units, plus top and bottom Roto Finish grinding attachments. 1 upper grinding belt 1 lower grinding belt 2 upper Roto Finish grinding attachments 2 lower Roto Finish grinding attachments For a detailed description, please see the accompanying PDF from the manufacturer. Sold on behalf of a customer. The images are from our archive and were taken before the machine was delivered to the customer. (Technical specifications according to the manufacturer - without guarantee!)

Year of construction: 2011, condition: used, functionality: fully functional, MACHINING CAPACITIES: - Height (thickness): 30 to 390 mm - Maximum workpiece width: 400 mm - Abrasive belt speed: 1300 m/min - Conveyor feed speed: 10 m/min - Belt dimensions: 420x1800 mm (consult us for supply) MACHINE CONFIGURATION: - Roller table, belt operates from below Table height from floor: 90 cm - Automatic workpiece detection by sensor - Sanding pad with pneumatic pressure - Automatic belt rotation direction change MACHINE FEATURES: - Main power supply: 400V, 3-phase, 50Hz, IN 22A (35A protection) - Automatic star-delta starter Kjdpfx Ajx A Unxeanenf - Ammeter(s) for power consumption monitoring Feed motor: 0.5 kW Belt motor: 7.5 kW - Pneumatic tensioning, oscillation, and disengagement of rollers - Pneumatic supply: 6 to 8 bar - Extraction: 2 lower ports Ø150 mm Recommended airflow: 2200 m³/h Speed: 20 m/sec - CE marking, emergency stops front and rear, lockable isolator switch Note: For your satisfaction, we remind you that belts should be released when the machine is not in use and that all humidity, including dew point inside your workshop in winter, must be avoided. Dimensions: 1500x1300x2050 mm (H) Weight: 1200 kg

Year of construction: 2022, condition: used, Number of sanding units 6 st. sanding width 45-165 mm Sanding height max. 45-92 mm weight 2200 kg Ecoline Q-SAND 6 For sale on behalf of a customer ----- Long text as PDF attachment! Brief description: The machine has automatic height detection for the pass-through. It has 2 sanding discs at the top and 2 sanding discs at the bottom, each connected to a brush unit. Technical manufacturer's description: Ecoline Q-Sand: the ideal sander for scantlings and more. Designed to work on both sides of the workpiece with three-dimensional Kedexyafkopfx Aansnf adjustment, Q-Sand guarantees maximum precision and uniformity. It is equipped with sanding discs, lamellar brushes, and a double disc for more effective material removal, which improves adhesion for subsequent treatments. Q-Sand can be installed in a line or, thanks to its complete operational autonomy, can also be used independently. It is also ideal for window frames, beams, and custom-made products, and optimizes processing times with automated systems and advanced production control. ----- Price of the above machine on request! ----- (Technical data according to manufacturer - without guarantee!) All prices quoted are net. Plus statutory VAT.

Condition: used, functionality: fully functional, grinding belt length: 2,500 mm, grinding belt width: 300 mm, grinding height: 150 mm, double-belt wood sanding machine, for sanding window frames Ksdpjxvtlpsfx Aansnf

Year of construction: 2007, condition: used, control Siemens 840D grinding wheel diameter 900 mm Workpiece - grinding width 144 - 152 mm Knsdpfxjxq Hkuj Aansf Workpiece - grinding dimension 22 - 25 mm turning speeds 24 m/s: 1.425 U/min peripheral speed max. 25 m/sec capacity 37 kW total power requirement 75 kW weight ca. 18,0 t dimensions of the machine ca. L 4,9 x B 4,9 x H 2,6 m In our opinion, the machine is in good condition used condition. Double face side grinders The machine was used for the production of connecting rods. Accessories, tools and clamping devices shown are only part of the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well as Subject to prior sale!

Year of construction: 2008, condition: used, Number of sanding units 8 st. sanding width 150 mm Machine can be inspected during production! Leistomat - Finisch and intermediate leveling machine Löwer LZ 8 ----- ----- for finish sanding (smoothing, defibering and edge breaking) or intermediate sanding profiled window latch - Finish and intermediate sanding machine with eight sanding blade aggregates, 2 surface units at the top (synchronism / counter-rotation) 2 surface units below (synchronism / counter-rotation) 4 profile units with angled arrangement top right, bottom right, top left, bottom left, all mating - linear guidance of all grinding units over Linear ball bearing sets on hardened shafts - Timed immersion of all in the opposite direction rotating grinding units directly above the incoming Workpiece edges to avoid looping through the Primer in the front edge area. By the It is possible to immerse the aggregates deeper in the Be able to deliver profiles. - Timed replacement of the rotating in synchronism Aggregate - motor workpiece thickness adjustment of the machine by means of motorized height adjustment via push button - Display of workpiece thickness via digital display with modern magnetic tape system Kodpfoxpi D Ujx Aanenf - Variable grinding disc speed via frequency converter to adapt the grinding intensity to different Primers by means of frequency converters 200-1000 rpm - Workpiece width recognition at the machine infeed with automatic adjustment of the left grinding units to the current workpiece width - Profile preselection via selector switch on the machine inlet side as well as automatic adjustment of the Abrasive blade aggregates on the selected profile - modern PLC control for easy operation of the machine - Suction connection 5 x 100mm diameter - Length (body) x width x height (mm): 2600 x 1500 x 1600 Length complete: 3600mm (including roller conveyor with integrated workpiece width recognition) - Operating voltage 400V, 50Hz, 3P, air connection 6 bar - CE version Technical specifications: Number of sanding units: 8 pcs. Surface brush width: max. 150 mm Working height: max. 100 mm Surface Brush Motor: 0.75 kW Side brush motor: 0.37 kW Brush speed: 1380 rpm Feed motor: 1.1 kW Feed rate: 4-20 M / min Feed stepless Speed ??controller grinding units Automatic width detection Digital magnetic tape gauge Extraction nozzle: 5 x 100 mm Air requirement: 5 x 565 m3 / h Minimum air velocity at the connection of the machine: 20 m / s Dimensions: Length: 2600 mm Width: 1480 mm Height: 1700 mm Weight: 950 kg WITH inlet roller conveyor ----- Price of the Löwer amchine on request! he return conveyor device that can be seen in the pictures is no longer available and is NOT included in the scope of delivery (Technical data according to manufacturer - without guarantee!)

Condition: new, Number of sanding units 1 st. sanding width 150 mm Sanding height max. 150 mm Kjdpfexmk Ayex Aanonf Loewer edge finishing machine MiniSpin N ----- Machines for finishing and fine sanding of Edges and profiles with a grinding spindle horizontal or vertical. Motor 0,75 KW Spindle in vertical position for machining edges Pivoted spindle in horizontal position, laterally etc. for processing longer profile bars or Conjunction with a combined grinding head for grinding of edges with a grinding disc blades Grinding head swiveling + / - 20 ° for editing oblique lines Working height / width 150 mm max. Diameter roller / brush

Condition: good (used), Year of construction: 1996, double-sided top and bottom sanding with sanding shoe and dust brush Knsdpsxfl Eaefx Aanef max. sanding width 300 mm max. sanding height 200 mm year of manufacture 1994 with CE mark

Condition: used, Number of sanding units 2 st. sanding width 190 mm Sanding height max. 4-180 mm HESS - GLORIA 2 BELT SINGLE WOOD SANDING MACHINE ----- Manufacturer's description: ----- Compact design designed according to modern principles. Quiet and vibration-free operation thanks to rigid, stable machine housing and special insulation. Work safety device in accordance with the EC Machinery Directive with the "dust-tested" certificate. Offset grinding units with large-dimensioned tension rollers for good heat dissipation and stable sanding belt guidance. Sanding units with forced sanding belt oscillation. 2-point sanding dust extraction directly on the sanding roller. Airborne dust extraction on the large tension rollers. Integrated sanding belt blower for longer service life of the sanding belts. Integrated brushing and finishing device, adjustable via threaded spindle, with large dust extraction. Motorized grinding thickness adjustment of the entire upper unit via precision threaded spindles and linear ball sets on hardened and ground precision shafts with dust and dirt protection. Electronic digital display for workpiece thickness (resolution 0.1 mm). Contact roller and grinding shoe in a balanced ratio to the grinding belt grain load. Hardened and ground grinding rollers. Maintenance-free and wear-free oxide ceramic grinding shoes (DBGM) with excellent sliding properties, good heat dissipation and high dimensional accuracy. Grinding belt tension via pneumatic cylinder. Grinding belt change via pneumatically controlled belt relaxation. Ability to adjust the grinding belt run when changing the belt. Electro-pneumatic pressure monitoring of the compressed air supply with visual fault display. Automatic machine stop triggered when sanding belt breaks and by run-in protection with integrated wood thickness control. Optical display on the control panel. Feed device and proven, calibrated non-slip and non-adhesive transport belts on precisely ground tables and spring-loaded pressure rollers. Cardan shaft drive for even wood transport. Feed speed continuously adjustable. Chip removal adjustment bottom via precision threaded spindle with dimension display via scale ring (resolution 0.1 mm) Ergonomic arrangement of the operating and setting elements on the machine front: sanding unit and brush device at the top, sanding unit and brush device at the bottom, workpiece transport device, sanding thickness setting, operating display, fault display. Control and operating unit with lockable main switch built into the machine housing. All motors electrically protected against overload. Technical data: ----- Grinding belt speed: 24 m/sec. Kjdev D Rg Dopfx Aanonf Grinding width: 190 mm Grinding thickness: 4 - 180 mm Shortest workpiece length: 300 mm Feed speed: Continuously adjustable 5 - 25 m/min. Sanding belt dimensions: 200 mm wide 1600 mm long Electrical connection: 400 V, 3/N PE, 50 HZ Grinding units: 2 x 4 kW Feed: 0.75 kW Height adjustment: 0.18 kW Pneumatic connection: R 3/8", 80 NL, 8 bar Extraction air volume: 2 x 2000 - 2500 m3/h 20 - 25 m/sec. Extraction connection nozzle: 2 x 160 mm diameter at the top of the machine housing External dimensions: Length: 1600 mm Width: 1030 mm Height: 1820 mm Height with extraction nozzle: 1930 mm Working...

Condition: used, Number of sanding units 4 St. sanding width 190 mm Sanding height max. 180 mm Control ja weight 3300 kg Dimensions (L/W/H) 2600x920x1890 mm Dust suction hood 2x180, 2x120 mm Löwer DSM 2004 Double-Sided Sanding Machine ----- 4-Belt Sander + Disc Unit (Top/Bottom) Manufacturer's Description: ----- Double-sided, four-belt, single-wood sander for sanding solid wood such as window frames, etc. Highly stable, top-quality design with innovative details. Suitable for high continuous loads, even with high material removal rates. - Sequentially arranged grinding units for roughing, fine grinding, and finishing, each from above and below 1. Belt grinding unit with heavy steel roller 2. Belt grinding unit with rubberized roller and shoe 3. Finishing unit with fiber brush (see optional equipment below) - Direct-drive grinding rollers for slip-free power transmission - Maintenance-free and wear-free CERMET-coated grinding shoes with very good thermal conductivity and absolute dimensional accuracy - External cooling of the grinding zones for cooler grinding and longer belt life - Forced pneumatically controlled grinding belt oscillation - Effective grinding dust extraction directly at the grinding rollers - Airborne dust extraction at the tension rollers - Integrated brushing and finishing unit with large grinding dust extraction - Motorized grinding thickness adjustment via precision threaded spindles and large linear ball bearing sets on hardened and ground precision shafts with dust and Dirt protection - Chip removal adjustment at the bottom via precision threaded spindle with dimension display via scale ring (0.1 mm resolution) - Sanding belt tension via pneumatic cylinder with constant tension pressure - Sanding belt change with pneumatic belt release in seconds - Sanding belt tracking adjustment during belt change - Electropneumatic compressed air monitoring - Infeed protection via contact roller for workpieces that are too thick - Workpiece transport via calibrated, non-slip and adhesive conveyor belts over heavy-duty cast iron tables with a finely planed surface and spring-loaded pressure rollers with fine adjustment - Cardan shaft drive for smooth and consistent workpiece transport - Geared feed motor with infinitely variable speed 4-20 m/min - All motors electrically protected - Ergonomically arranged operating elements - Digital thickness display (0.1 mm resolution) with modern magnetic tape system Technical data: ----- - Sanding belt speed 22 m/s - Sanding belt length 1800 mm - Sanding belt width 200 mm - Working width 190 mm - Sanding thickness 2-180 mm - Four brake motors for drive 5.5 kW - Feed motor 1.5 kW - Feed speed 4-20 m/min - Automatic height adjustment 0.37 kW - Two brush units with fiber brushes D 120 x 200 mm at 0.37 kW each - Extraction ports 2 x 180 mm, 2 x 120 mm Kjdpfovu Hgbex Aanenf - Extraction air velocity 20 m/s - Pneumatic connection 6 bar - Working height 870 mm - Length (with soft disc 2740 mm) 2600 mm - Length with control unit (with soft disc 3035 mm) 2985 mm - Width 880 mm - Height 1910 mm - Weight approx. 3300 kg - Operating voltage 400 volts, 50 Hz, 3P - CE compliant Equipped with the following special options: -----...

Condition: new, Number of sanding units 2 St. sanding width 190 mm Sanding height max. 2-180 mm LÖWER double-sided grinding machine DSM 2000 ----- Double-sided single wood sander for sanding Solid wood such as window wood etc. Stable top quality Guide with long casting tables, brushing and finishing equipment and conveyor belt feed. Suitable for high continuous loads even with higher chip removals. - Staggered sanding and finishing units at the top and bottom - Directly driven rubberized grinding rollers for slip-free power transmission - Combined grinding via roller and shoe for high chip removal at the same time flat intervention zone - Maintenance and wear-free CERMET-coated sanding shoes with very good thermal conductivity and absolute Dimensional accuracy - External cooling of the grinding zones for cooler grinding and higher grinding Grinding belt service life - Forced pneumatically controlled sanding belt oscillation - effective sanding dust extraction directly on the sanding rollers Airborne dust extraction on the tension rollers - Integrated brushing and finishing device with large sanding dust extraction - Motorized grinding thickness adjustment via precision threaded spindles and large-sized linear ball bearing sets on hardened and ground precision shafts with dust and dirt protection - Adjustment of the chip removal at the bottom using a precision threaded spindle Dimension display via scale ring (resolution 0.1mm) - Sanding belt tension via pneumatic cylinders with constant clamping pressure - Sanding belt change with pneumatic belt relaxation in seconds - Adjustment of the sanding belt run when changing the belt - electro-pneumatic compressed air monitoring - Run-in protection via contact roller for workpieces that are too thick - Workpiece transport via calibrated non-slip and non-stick conveyor belts over heavy, 1000mm long cast tables with a finely planed surface and Spring-loaded pressure rollers with fine adjustment - Cardan shaft drive for smooth and even workpiece transport - Feed gear motor with three different feed speeds for quick adaptation to different types of wood - all motors electrically protected - Ergonomically arranged controls on the workpiece inlet side - automatic workpiece thickness scanning (no previous measurement necessary) - Digital thickness display (resolution 0.1mm) with modern magnetic tape system Technical data: - Sanding belt speed: 22 m/s - Sanding belt length: 1800mm - Sanding belt width: 200mm - Working width: 190mm - Grinding thickness: 2-180mm - two brake motors for drive: 5.5 kW - Feed motor: 1.0 kW - Feed speed: 6, 11 and 16 m/min. - automatic height adjustment: 0.37 kW - two brush units with fiber brushes D 120 x 200mm at 0.37 kW - Suction nozzle: 2 x 120mm and 2 x 150mm - Pneumatic connection 6 bar - Working height: 850mm - Length: 2105mm - Length with control panel 2490mm - Width: 880mm - Height: 1910mm - Weight: approx. 1500 kg - Operating voltage: 400 volts, 50 Hz, 3P - CE version ----- ----- Knedpsvu Hdtjfx Aanof Basic price of the machine on request! ----- ----- Special accessories with surcharge: continuous feed 4-20 m/min. for speed adjustment to the previous machine Price on request Workpiece blow-off - using nozzles from above and below at the machine ...

Condition: new, Number of sanding units 8 st. sanding width 180 (260) mm Sanding height max. 160 mm Dimensions (L/W/H) 3065x1600x1900 mm weight of the machine ca. 1500 kg LÖWER Leistomat SD ----- Automatic fine grinding machine for wood grinding (smoothing, defibering and Edge breaking) or intermediate sanding of profiled window bars. With soft disc Technology for the visible surfaces as well as automatically safe profile and Width adjustment. Knsdpfx Aevnv Uheanof - 2 lamella roller units on the side, each 0.75kW, L=120mm, D=200mm 1 softisc unit Ø=200mm above 0.75kW, 1 slat roller unit L=200mm top 0.75kW, 1 soft disc unit Ø=200mm bottom 0.75kW, 1 slat roller unit L=200mm bottom 0.75kW, 2 lamella roller units on the side, each 0.75kW, L=120mm, D=200mm - Linear guidance of all grinding units Linear ball bearing sets on hardened shafts - time-controlled immersion of all lamella roller units directly above the incoming workpiece edges. By the It is possible to immerse the aggregates deeper into the profiles to be able to deliver. - Motorized workpiece thickness adjustment of the machine - variable grinding flap speed via frequency converter for adjusting the grinding intensity using frequency converters (separate for discs, surface rollers and side rollers) - Disc aggregates as soft discs with Velcro fastener for Grinding wheels (wood pulp) - Feed via three lower and one upper conveyor belts and Spring-loaded pressure rollers with infinitely variable speed 4-15m/min - Parameters that can be set using the touch panel are workpiece thickness, Workpiece width (left side units individually), immersion depth Side units, spindle speed, feed speed - Saving the parameters as machine programs in program mode - Working in automatic mode with non-contact Workpiece width detection and profile detection as well as automatic Adjustment of the sanding units to the workpiece width and the Profile shape (workpiece height is set in advance) - pneumatically clocked driven feed roller, automatic Clamping of the workpiece and feeding in after unit adjustment - Red/green indicator lights to indicate operational readiness - shortest workpiece length 380mm - Transport belt width 200mm - max. workpiece width 180mm (260mm in the envelope process) - Workpiece height 12-160mm - Suction connection 4 x 100mm and 2x80mm diameter - Sensor-controlled tool blow-off directly on the discs - Length (case) x width x height (mm): 3065x 1600 x 1900 Complete length: 4365mm (including roller conveyor with integrated workpiece width detection) - Weight: 1500kg - Operating voltage 400V, 50Hz, 3P, air connection 6 bar - CE version ----- Price of the above machine on request! ----- Special accessories with additional costs: Set of replacement slats for Leistomat SD-200 consisting of Area aggregates: 30 strips EH45 / 200 - 7 (rolls) 30 strips EH45 / 200 - 20 (rolls) Folding units: 96 strips M55 / 120 - 4 SmartFlex slat disc Ø200 solid with 30 grooves 50mm long Set of replacement slats for SmartFlex slat disc consisting of 60 strip M35 / 50 K 180-7 p Sandpaper disc VB for soft disc D=200mm grit 220 with velor backing (Velcro), pack of 100. Sandpaper disc VB for soft disc D=200mm grit 280 with velor backing (Velcro), pack of 100. ----- Price of the above-mentioned special accessories on request! -----...

Condition: new, Number of sanding units 4 St. sanding width 190 mm Sanding height max. 180 mm LÖWER-DoubleSander Solid DSM 2004 ----- Double-sided four-belt single wood sander for Sanding solid wood such as window frames etc. Highly stable top design with innovative details. Suitable for high continuous loads even with higher chip removals. - sanding units arranged one after the other for pre-grinding, Fine sanding and finishing sanding, each from above and below 1. Belt sanding unit with heavy steel roller 2. Belt sanding unit with rubberized roller and shoe 3. Finishing unit with fiber brush - Directly driven grinding rollers for slip-free Power transmission - maintenance and wear-free CERMET-coated grinding wheels shoes with very good thermal conductivity and absolute Dimensional accuracy - External cooling of the grinding zones for cooler grinding and longer sanding belt service life - force-guided pneumatically controlled sanding belt oscillation - effective sanding dust extraction directly on the Grinding rollers - Airborne dust extraction on the tension rollers - Integrated brushing and finishing device with large Grinding dust extraction - motorized grinding thickness adjustment via precision threaded spindles and large-sized linear ball screws bearing sets on hardened and ground precision shafts with dust and dirt protection - Adjustment of the chip removal at the bottom via precision Threaded spindle with dimension display via scale ring (Resolution 0.1mm) - Sanding belt tension via pneumatic cylinder constant clamping pressure Knodpfx Aajvnv Tqjnjf - Sanding belt change with pneumatic belt relaxation Within seconds - Adjustment option for the sanding belt run Band change - electro-pneumatic compressed air monitoring - Anti-running protection via contact roller if it is too thick workpieces - Workpiece transport via calibrated non-slip and non-stick fixed conveyor belts over heavy, cast tables Finely planed surface and spring-loaded pressure rollers with fine adjustment - Cardan shaft drive for smooth and consistent Workpiece transport - Feed gear motor with stepless speed 4-20 m/min - all motors electrically protected - ergonomically arranged controls - digital thickness display (resolution 0.1mm) with modern Magnetic tape system Technical data: - Sanding belt speed 22 m/s - Sanding belt length 1800mm - Sanding belt width 200mm - Working width 190mm - Grinding thickness 2-180mm - four brake motors for 5.5 kW drive - Feed motor 1.5 kW - Feed speed 4-20 m/min. - automatic height adjustment 0.37 kW - two brush units with fiber brushes D 120 x 200mm at 0.37 kW - Suction nozzle 2 x 180mm 2 x 120mm - Extraction air speed 20 m/s - Pneumatic connection 6 bar - Working height 870mm - Length (with soft disc 2740mm) 2600mm - Length with control panel (with soft disc 3035mm) 2985mm - Width 880mm - Height 1910mm - Weight approx. 3300 kg - Operating voltage 400 volts, 50 Hz, 3P - CE version ----- Price of the above machine on request! ----- Special accessories with additional charge: Workpiece blow-off - using nozzles from above and below at the machine outlet arranged, pneumatically controlled 4-belt sanding belt blowout via nozzles directly on the radii of the tension rollers inside the suction arranged, timer controlled on/off 5 seconds each, can be switched on separately Di...

Year of construction: 1986, condition: excellent (used), I sell Profile Grinding Machine Reckmann LM 161. Grinder in very good condition, little used. Kodjuyg Rnjpfx Aanjnf

Condition: used, Number of sanding units 4 St sanding width 190 mm Sanding height max. 4-180 mm weight 4200 kg Hess Expert 4-belt single wood sanding machine machine will be checked by our technicians ----- Ø Grinding at the bottom/top Ø With 2 offset grinding units each (bottom and top) Ø Grinding units (bottom and top) connected in series according to the Dressing principle Ø Pre-sanding with coarse grit (calibrate) Ø Regrinding with fine grit (finish) Ø Central motorized height adjustment of the lower grinding units Ø Central motorized and synchronous height adjustment of the entire upper Grinding and brushing units including the upper transport units Ø Oscillating sanding belt utilization (during the sanding process) Ksdpfxet Tqy Ee Aanjnf Ø Absolute power connection thanks to 5.5 KW motors and large dimensions drive drums Ø Oxide ceramic grinding shoe for - exact surface geometry - no adjustment work - permanent dimensional accuracy - completely maintenance and wear-free Basic structure: Stable, heavy welded construction made of strong-walled rectangular profiles additional, statically calculated reinforcements for optimal Vibration dampening. Staggered grinding units with large dimensions Belt drive drums for slip-free belt running. Two-point suction for direct and flying dust with sealing brushes and integrated sanding belt blow-off Device to increase the service life of the sanding belts. Grinding units in heavy steel plate construction as the basis for vibration-damped, quiet tape running. Absolutely backlash-free guides as ball linear sets hardened and ground shafts. Height adjustment of the grinding units via hardened and ground special linear guides as well as pre-tensioned ones Guide carriage. Permanent precision thanks to dust and dirt protection Ball linear sets and guide carriages. Large-sized pre-grinding rollers as contact rollers. Contact rollers and Sanding shoes in a balanced ratio to the sanding belt grain load. The large drive drums guarantee full transmission the 5.5 kW drive power of the grinding motors on the sanding belt. Therefore Slip-free, stable running and optimal heat dissipation. This makes it the strongest Chip removal possible. Automatic machine stop activation in the event of a belt break. Visual display on the control panel and via flashing lights on the machine. Sanding shoes for finish completely maintenance-free and wear-free made of oxide ceramic with optimal heat dissipation. Grinding belt tension via appropriately sized compression springs. Sanding belt relaxation for belt changing using a pneumatic device sensitive, distortion-free placement of new tapes. Upper grinding unit and brush device centrally motorized Height adjustable with digital display in the control panel for the motorized Grinding thickness adjustment. Brushing and finishing device, for better surface finish, integrated into the basic machine. Two special brush rollers 150 mm Æ arranged one above the other in synchronous function for advance thrust. Separate height adjustment of the brush rollers on precise Carriage guides for post-correction of wear. Additional transport roller for Removal or further transport of the workpiece from the automatic grinding machine with the conveyor belt. Wooden guide in the inlet area for hard guide and bearings mounted on both sides pressure rollers. Safe transport of profiled workpieces on ca...

Year of construction: 2001, condition: good (used), table diameter 200 mm workpiece height 100 mm number of wheels 1 Control Robot CNC total power requirement 6 kW weight of the machine ca. 1,8 t dimensions of the machine ca. 1,83 x 2,04 x 2,1 m Technical data - Grinding capacity : Ø 0.025 –12.7 [mm] - Bar diameter : Ø 1.0 –12.7 [mm] - Grinding length : W15 (option W20) - Z-axis : 35[mm] Resolution : 0.5 [µm] – X- axis : 25 [ mm] Resolution : 0.1µm – Y-axis : 286[mm] Resolution : 0.5µm – U- Knodpfx Ajtt Tb Djanjf axis : 15 [mm] Resolution : 0.1µm Head Motor: 0.70 [kW] Rotation: 300 – 3000 [rpm] Grinding - Raw grinding : 1.5 [kW] Spindle : Ø 60 [mm] Grinding wheel diameter : Ø 200 [mm] Cutting speed : 30 m/sec. - Completion: 0.75 [kW] Spindle: Ø100 [mm] Grinding wheel diameter: Ø150 [mm] Cutting speed: adjustable - Dimensions (L x W x H): 1830 x 2040 x 2100 mm - Weight: approx. 1800 [kg] Accessories - Loading and unloading robots - Fire protection device CONTROL axes; 4 axes + 2 programmable robots - simultaneously linear interpolation of the 4 axes + cylindrical interpolation of 2 robot axes
