Condition: used, functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, Haas lathe Hedpfoydpw Eex Aamsh Type SL-10 With bar feeder With tooling

Condition: excellent (used), Year of construction: 2022, operating hours: 6,600 h, functionality: fully functional, machine/vehicle number: ML0118-000493, turning diameter over cross slide: 670 mm, turning length: 1,285 mm, turning diameter: 420 mm, spindle speed (max.): 2,800 rpm, travel distance X-axis: 293 mm, travel distance Y-axis: 130 mm, travel distance Z-axis: 1,350 mm, spindle motor power: 30,000 W, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 30 m/min, total height: 2,315 mm, total length: 4,530 mm, total width: 2,249 mm, quill travel distance: 100 mm, quill diameter: 100 mm, quill stroke: 1,350 mm, swing diameter over cross slide: 670 mm, turning diameter over bed slide: 720 mm, workpiece weight (max.): 1,000 kg, torque: 1,240 Nm, overall weight: 8,000 kg, bar passage: 102 mm, spindle nose: A2-11, Equipment: documentation/manual, rotational speed infinitely variable, CNC turning machine with driven tools and Y-axis, programmable tailstock (servo-driven), driven tool turret with BMT 65P interface, programmable steady rest holder with steady rest SLUB 3.1, automatic tool measurement arm, coolant gun, SMW power chuck 325 mm and SMW power chuck 400 mm, chip conveyor, Liqui band filter system, various tool holders including driven holders, filter for coolant extraction, programming system for external computer. Hedpfx Aaeydcd Somoh

Condition: ready for operation (used), Year of construction: 1998, operating hours: 17,000 h, functionality: fully functional, turning length: 305 mm, spindle speed (max.): 5,000 rpm, swing diameter over bed slide: 440 mm, bar passage: 42 mm, controller model: Heidenhain Elektro Pilot 3190, TECHNICAL DETAILS Swing diameter over bed: 440 mm Swing diameter over carriage: 210 mm Turning length: 305 mm Bar capacity: 42 mm Hedpoycu A Rsfx Aamsh Spindle speed: 5,000 rpm Turret: 12 stations Driven stations: 6 stations Tool holder: VDI 20 MACHINE DETAILS Control: Heidenhain Elektro Pilot 3190 Dimensions & Weight Machine dimensions (L x W x H): 2,800 x 1,651 x 1,771 mm Machine weight: approx. 3,000 kg Power-on hours: approx. 17,000 h EQUIPMENT Chip conveyor C-axis Driven tools Parts catcher Tailstock Documentation

Condition: good (used), Year of construction: 2009, functionality: fully functional, Manufacturer: Gildemeister Model: CTX 410 V4 Hedpfx Aoyax Swsamsh Year of manufacture: 2009 Control: Heidenhain plus IT Travel: X 170 mm, Z 635 mm, Y +/-40 mm Program run time: 11,400 h Spindle Spindle speed: 5,000 rpm Spindle bore: 65 mm Turning diameter over cross slide: 375 mm Turning length: 635 mm Turret Tool holder: VDI30 Number of stations: 12 with AGW Dimensions and weight Dimensions: 5,000 mm x 2,500 mm x 2,800 mm Weight: approx. 5,800 kg

Condition: excellent (used), Year of construction: 2012, Haas ST 30 Year of manufacture: 2012 Tailstock Hsdpfx Aasyaatcomsh Part catcher Tooling

Condition: used, Year of construction: 1986, serial number 7175455 3 Backenfutter Durchm. 30 tool taper ja Hedpsx U A Tcofx Aameh turret head für 6-fach-Belegung centre distance ca. 700 mm turning diameter max. ca. 450 mm Control FANUC dimensions of the machine ca. 3.000 x 2.000 x 2.200 mm

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD3100M FANUC 0IT PLUS CNC HIGH POWER TURNING CENTRE WITH HARDENED & GROUND BOX GUIDEWAYS, HIGH SPEED SERVO TURRET, C-AXIS & DRIVEN TOOLS & 12" STD CHUCK Swing Over the Bed Ø 750 MM Swing Over the Carriage Ø 500 MM Maximum Turning Diameter Ø 420 MM Maximum Turning Length 740 MM Bar Capacity - Main Ø 102 MM MAIN SPINDLE Chuck Size Ø 12” – 305 MM Spindle Bore Ø 115 MM Spindle Speed (Rpm) 2,800 RPM Motor (Max. / Cont.) 26.0 / 18.5 KW Torque (Max. / Cont.) 1,123 / 657 NM Spindle Type BELT [GEARLESS] Spindle Nose A2-11 C-Axis Indexing 360° (0.001°) Travel X 265 MM Travel Z 830 MM Rapid Speed X 24 M / MIN Rapid Speed Z 30 M / MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 12 Tool Size - OD 25 MM² Tool Size - ID Ø 40 MM Indexing Time 0.15 SEC / STEP LIVE TOOLS Motor (Max / Cont.) 5.5 / 3.7 KW Milling Tool Speed 5,000 RPM Torque (Max. / Cont.) 70.0 / 35.4 NM Collet Size ER32 - Ø 25 Type BMT65P QUILL TYPE TAILSTOCK [PROGRAMMABLE BUILT IN TAILSTOCK] Taper MT5 [MT4] Quill Diameter Ø 100 MM Quill Travel 120 MM Tailstock Travel 830 MM TANK CAPACITY Coolant Tank200 L Lubricating Tank 1.8 L POWER SUPPLY Electrical Power Supply 27 [30 GEARLESS] KVA Voltage 415V / 50HZ / 3PH MACHINE Floor Space (L x W) 3,885 x 1,800 MM Height 1,850 MM Weight 6,050 KGS STANDARD FEATURES SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 12 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" TOUCH SCREEN MONITOR FOR FANUC (SMART GUIDE i) HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) PART PROGRAM STORAGE - 2MB (1,000 REGISTERABLE PROGRAMS) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR Hedpfox Thzvjx Aameh FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) TOOLBOX MAIN SPINDLE - 2,800 RPM, 26.0 / 18.5 KW, 1123 NM BELT DRIVEN TOOLING PACKAGE QUILL TYPE TAILSTOCK WITH STD LIVE CENTER 12 STATION BMT65P SERVO TURRET, LIVE TOOLS 5,000 RPM, 5.5 KW, 47.0 NM FACTORY FITTED MACHINE OPTIONS CHIP BUCKET STANDARD CHIP CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD (RATED AT 60HZ SUPPLY) BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE 30 KVA TRANSFORMER AND CABLE QUICK TOOL SETTER - MANUAL PROGRAMMABLE TAILSTOCK IN LIEU OF STDMACHINE CONSTRUCTION & FEATURES 12” STANDARD CHUCK SIZE. 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. 12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET – BMT65P. 2,800 RPM 26.0 / 18.5 [35.0 / 25.0 GEARLESS] KW HIGH POWER MAIN SPINDLE. 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. C-AXIS MAIN SPINDLE. ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET.

Condition: used, Year of construction: 1999, turning diameter 450 mm turning length 380 mm control Seicos 40L Multi max. machining diameter 340 mm Bar feed 51 mm Hodpjx S Rxuofx Aamsh turning speed range - spindle 30 ~ 5.000 U/min drive capacity - spindle motor 11 / 7,5 kW spindle nose A2-6 spindle bore 59 mm bearing diameter 100 mm travel -x axis 215 mm travel -z axis 400 mm turret (x-stations) 16 feed 0,001 ~ 500 mm/min rapid traverse X/Z: 30 m/min Shank diameter 25 x 25 mm Drill shank diameter 40 mm taper of center MK 5 tailstock adjustment 300 mm total power requirement 23 kVA weight of the machine ca. 4,6 t dimensions of the machine ca. 5,5 x 2,8 x 2,2 m CNC Lathe HITACHI SEIKI - HiTec-Turn HT 20 RIII

Condition: defective spare-parts repository (used), Year of construction: 2002, functionality: not functional, type of input current: three-phase, overall weight: 17,000 kg, We offer this defective INDEX G400 CNC lathe, year of construction 2002. Machine type: G400 Machine number: 650036 Year of manufacture: 2002 Supply voltage/frequency: 3 Ph / 50 Hz Supply voltage: 400 V Control voltage: 24 V Nominal current: 204 A Nominal power: 120 kW Bed weight: 700 kg Machine weight: 17000 kg Hodpox S Ir Esfx Aamsh If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: used, Year of construction: 2011, turning diameter 0700 mm turning length 800 mm control 840D Siemens turret head 12 swing over bed 380 mm spindle turning speed - stepless 10- 5000 rpm spindle bore 67 mm Hjdpfxex Sy U Eo Aamjh feed - longitudinal/cross 20000 mm/min rapid travel - longitudinal/face 30 m/min dimensions 5000 x 2800 x 2000 mm total power requirement 65 KVA weight of the machine ca. 7,5 t Machine has C-axe and 6 live tooling positions

Condition: used, Year of construction: 1987, turning diameter max. 400 mm turning length 1.000 mm control EPL 2 greates pass round over bed 400 mm Swing dia. over traverse guideway 225 mm travel -x axis 260 mm travel -z axis 1.040 mm turning speed range - main spindle 20 - 4.000 min/-1 power capacity - main spindel 11 kW max. Torque 75 Nm spindle bore 72 mm chucking diameter 185 mm spindle head 140H5 spindle diameter in front bearing 100 mm number of toolpositions 12 pos. diameter of quill 80 mm quill stroke 100 mm taper of center MK 4 pressure max. 800 daN rapid power traverse in X-and Z direction 10 m/min Feed speed x: 5 m/min. Feed speed z: 5 m/min. Feed force x: 500 daN Feed force z: 800 daN total power requirement 29 kW weight of the machine ca. 4,0 t dimensions of the machine ca. 4,6 x 2,1 x 2,0 m Hsdpfx Aasx Sy Urjmoh CNC - Lathe GILDEMEISTER - NEF CT 40

Condition: good (used), Year of construction: 2001, Ref. -No.: 10551 Manufacturer: TRAUB Type: TNC 42/65 Year of construction: 2001 Type of control: CNC Control: TRAUB TX Storage location: Halberstadt Country of origin: Germany Machine-No.: 93XXXXX Turning Speeds: 8000 RPM X stroke: 450 mm Turning Length: 450 mm Spindle Speeds: 4000 RPM Hedex Sw Icepfx Aameh Clamping Diameter: 42 / 65 mm Spindle Diameter In Front Bearing: 110 mm Tool Taper: 14 Max. Torque: 170 / 230 Nm Rapid Travel Speed X-Axis: 15 m / min Rapid Travel Speed Y-Axis: 6 m / min Rapid Travel Speed Z-Axis: 30 m / min Dimensions Of The Machine (Lxwxh): 4354 x 2076 x 1917 m Chisel slide cross section turning and milling support: 16 x16 ( 20 x20 ) mm Pressure: 70 bar hydraulic tank: 70 L. Total Power Requirement: 39 kVA Weight Of The Machine Ca.: 5,2 t Feed force X-axis at 100% duty cycle: 5000 N Feed path X-axis: 140 mm Z-axis feed path: 450 mm Y-axis feed path: 35 mm Ball screw Z-axis (Ø x pitch): 32 x 10 mm Ball screw X-axis (Ø x pitch): 32 x 5 mm Ball screw Y-axis (Ø x pitch): 25 x 5 mm Further information: - Revolver 1 Number of branches 10 - Revolver 2 Number of branches 14 - Hecowpkfie Htlx Tfefh - Powered tools Yes

Condition: good (used), Year of construction: 2002, Ref. -No.: 10434 Manufacturer: OKUMA Type: LC 40 Year of construction: 2002 Type of control: CNC Control: FANUC 18-i TB Storage location: Halberstadt Country of origin: Germany Turning Speeds: 10 - 2.800 RPM Bar passage: 91 mm Chuck diameter: 450 mm Hodsx Sw Euopfx Aamjh Tailstock - diameter: 120 mm Turning Diameter: 550 mm Turning Length: 800 mm Swing Diameter: 800 mm Spindle passage: 90 mm Spindle nose: A2-8 Tailstock Quill Stroke: 150 mm Total Power Requirement: 44 kW Weight Of The Machine Ca.: 8 t Number of tool stations: 12 pc

Condition: excellent (used), Year of construction: 2008, Control system MSX-850 IV. Axes C and Y, live tools, NC tailstock - fully programming. Hjdpfsx Sw Aasx Aameh Including chip conveyor. Chuck 300mm hole 90mm Diameter ... 420 - 500 mm Swing over bed ... 995 mm Swing over cross slide ... 825 mm Max. working length ... 1260 mm Max. bar diameter ... 90 mm Axe X ... 280 mm Axe Z ... 1370 mm Max. spindle revolutions ... 3000 rpm Spindle boring ... 105 mm Number of toos ... 10 Machine dimensions ... 4532 x 2291 x 2390 mm Machine weight ... 7600 kg

Condition: good (used), Year of construction: 2014, spindle speed (min.): 2,000 rpm, travel distance Z-axis: 500 mm, Year of manufacture: 2014 Hodpjx Nwphofx Aamjh Chuck diameter: 15'' Number of axes: 3 Length: 500 mm Swing diameter: 450 mm Spindle speed (RPM): 2000 Machinable material types: Steel, aluminium, titanium, graphite, copper, Invar, composite, Delrin, Peek

Condition: used, Year of construction: 2006, Turning length 1500 mm Max. turning dia. 420 mm Spindle bore 105 mm Spindle speeds 3300 rpm Spindle speeds on live tools 3000 rpm Turret w/12 stations Hjdpfjx Nfwgjx Aamoh Hydraulic tail stock Control: Mazatrol 640 T Nexus Equipped with: Magazine bar feeder FMB SL 80 3 pcs. live tools Various tool holders

Condition: ready for operation (used), Year of construction: 2022, operating hours: 113 h, functionality: fully functional, machine/vehicle number: AL150210302, turning length: 336 mm, turning diameter: 440 mm, spindle bore: 61 mm, spindle speed (max.): 6,000 rpm, controller model: DMG MORI COMPACT LINE, No minimum price – guaranteed sale to the highest bidder! Only 113 operating hours! The payment deadline for the machine is 04/12/2025! Placing a bid obligates you to collect the machine on time, between 12/10/2025 and 12/12/2025! The machine can be inspected on 11/25/2025! TECHNICAL DETAILS Turning length: 336 mm Turning diameter: 440 mm Bar capacity (max.): 52 mm Swing over bed: 620 mm Swing over cross slide: 465 mm Spindle speed (max.): 6,000 rpm Number of spindle speed ranges: 1 step Spindle bore diameter: 61 mm Spindle bearing inner diameter: 100 mm Shank diameter for square tools: 20 mm Shank diameter for boring bars: 32 mm X-axis travel: 260 mm Z-axis travel: 375 mm Rapid traverse in X-axis: 30,000 mm/min Rapid traverse in Z-axis: 30,000 mm/min Number of tool magazine positions: 12 MACHINE DETAILS Hedpfxjx Itdxe Aamoh Control model: DMG MORI COMPACT LINE Frequency: 50 Hz Operating hours: 113 h EQUIPMENT • Coolant system • Chip conveyor

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, TECHNICAL SPECIFICATIONS: CNC: Siemens 840D Powerline _ Working Area Swing over bed: 400 mm Swing over cross slide: 270 mm Turning length: 650 mm Transversal travel (X): 220 mm Longitudinal travel (Z): 700 mm _ Main Spindle Spindle nose according to DIN 55026 A (outer bolt circle): A6 Spindle diameter at front bearing: 90 mm Spindle bore: 65 mm Spindle nose taper: metric 72 (MK5) Motor power 40/100% duty cycle: 15 / 12 kW Max torque 100% duty cycle: 400 / 320 Nm Spindle speed: 4,000 rpm _ Cross Slide X/Z Transversal travel X: 220 mm Longitudinal travel Z: 700 mm Ball screw X/Z (Ø × pitch): 32 × 5 mm Hsdpfx Aex Ihn Ejamsh Rapid traverse X/Z: 15 m/min Feed force X/Z: 3 / 6 kN _ Tool Holder Number of tool stations (direct mounting): 8 Tool shank cross-section: 20 × 20 mm Tool disc wrench opening: 220 mm Boring bar shank diameter: 25 mm _ Tailstock Max quill force: 680 daN Taper: MK 4 Quill diameter: 65 mm Quill stroke (hydraulically movable): 40 mm _ Coolant System Capacity: 500 l Pump power: 1.20 kW Flow rate: 37 l/min Pressure: 1.9 bar Tank capacity: 25 l _ Electrical Requirements Connected load: 22 kVA Operating voltage: 400 V Frequency: 50 Hz Protection (slow-blow / VDE 0100): 35 A Voltage variation at 400 V: +6% / −10% _ Dimensions and Weight Overall dimensions (L × W × H, incl. chip conveyor): 2,100 × 1,750 × 1,710 mm Machine weight (without chip conveyor): approx. 2,800 kg _ Year of Manufacture 2008

Condition: ready for operation (used), Max. swing over bed: 460 mm Max. swing over cross slide: 230 mm Max. turning length: 810 mm Hjdpfox Hx Aqox Aamsh Spindle bore: 56 mm Main spindle speed range: 20 – 3,100 rpm Tool turret: 8-position VDI30 Control: FANUC Oi-TC Year of construction: 2007 Machine weight approx.: 6,200 kg

Condition: ready for operation (used), Year of construction: 2001, turning length: 1,000 mm, turning diameter: 400 mm, spindle bore: 80 mm, spindle speed (max.): 3,200 rpm, overall weight: 6,400 kg, Fanuc 18T, 4500 machining hours 12-position turret Capacity: 1000 x 400 mm Chuck: 315 mm Hsdsx Hhl Uspfx Aamoh Spindle bore: 80 mm Chip conveyor

Condition: refurbished (used), Year of construction: 2014, turning diameter over cross slide: 480 mm, turning length: 680 mm, turning diameter: 410 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 290 mm, travel distance Z-axis: 750 mm, spindle motor power: 22 W, Brand: Hyundai-Wia Model: L-300/MSA Category: CNC Lathes Hsdpfx Aaox Elzkemoh Year of manufacture: 2014 CNC Control: FANUC Series 32i-Model A Machine weight: 7,000 kg Machine dimensions: Length: 4,780 mm Width: 2,055 mm Height: 2,000 mm Capacity: Maximum swing over bed: 750 mm Maximum swing over carriage: 480 mm Maximum turning diameter: 410 mm Maximum turning length: 680 mm Bar capacity (spindle/sub-spindle): 76 mm / 65 mm Travel: X-axis: 290 mm Z-axis: 750 mm ZB-axis: 700 mm C-axis: 360° (minimum indexing angle: 0.001°) Spindle: Spindle diameter: 254 mm Spindle speed: 3,500 rpm Spindle nose: ASA A2-8 Spindle motor power (max./cont.): 22/18.5 kW Minimum C-axis control angle: 0.001° Sub-spindle: Sub-spindle diameter: 210 mm Sub-spindle speed: 4,000 rpm Spindle nose: ASA A2-6 Sub-spindle motor power (max./cont.): 11/7.5 kW Minimum C-axis control angle: 0.001° Turret: Turret stations (live tool capable): 12 Live tool speed: 4,000 rpm Live tool motor power (max./cont.): 5.5/3.7 kW Turning/boring tool dimensions: 25x25 mm or 50 mm Rapid traverse: X / Z axis: 20,000 mm/min Z axis: 24,000 mm/min Accessories and additional features: Chip conveyor Coolant tank with 20 bar high-pressure wash pump Automatic tool setter with push button and M code (down/up) Various live and static tool holders included Comprehensive documentation: manuals, electrical diagrams, CE declaration

Condition: used, Year of construction: 2017, functionality: fully functional, CHIP CONVEYOR 1200MM Hinged belt conveyor with discharge height approx. 1200mm, Hodpfxex A Dn Ue Aamoh suitable for: • Long steel chips • Chip nests • Wool chips For dry and wet machining Free loading Available immediately

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, turning length: 1,337 mm, turning diameter: 420 mm, General Control: Siemens 828 D Turning diameter: 420 mm Turning length: 1,337 mm Swing diameter: 700 mm Bar capacity: 89 mm Rapid traverse speed: 20 / 10 / 24 m/min Main spindle Bar capacity: 89 mm Chuck size: 305 mm Speed: 2,500 rpm Spindle power: 22 kW Spindle torque: 1,050 Nm Sub spindle Speed: 4,000 rpm Spindle power: 12 kW Spindle torque: 122 Nm Tool turret Technology: 12 stations Tool drive: 5,000 rpm Power: 9.4 kW Torque: 90 Nm Tool holder: BMT-65 / BH Travel X: 280 mm Travel Y: 120 mm Travel Z: 1,390 mm Equipment Chip disposal: chip conveyor Coolant capacity: 240 liters Tool measurement: measuring arm in the working area Part discharge: parts catcher Bar feeder: prepared Hsdpfxsx Ag Hme Aamsh

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, turning diameter: 400 mm, General Control: Fanuc 0i-TF PLUS Turning diameter: 400 mm Turning length: 560 mm Swing diameter: 690 mm Chuck diameter: 254 mm Main spindle Speed: 3,500 rpm Spindle power: 18.5 kW Torque: 410 Nm Bar capacity: 81 mm Sub-spindle Speed: 5,000 rpm Spindle power: 7.5 kW Torque: 86 Nm Turret Hjdpfx Ajx Ag E Noameh Technology: Turret with 12/24 stations (double indexing) Tool drive: 5,000 rpm Travel X: 240 mm Travel Y: 120 mm Travel Z: 700 mm Equipment Chip disposal: Chip conveyor Tool measurement: Probe arm in the working area Part removal: Parts catcher Automation: Prepared

Condition: used, Year of construction: 2000, DAEWOO PUMA 350 A CNC Lathe CNC FANUC 18 – T AUTOBLOCK Steady Rest Hjdpfxjxztzbj Aamjh Presetting Max. swing diameter over bed: 700 mm Max. swing diameter over carriage: 480 mm Max. turning diameter: 400 mm Max. turning length: 1,050 mm Max. bar capacity: 90 mm Chuck diameter: 305 mm Spindle nose: ASA – 8 Spindle speed: 30 – 3,000 rpm Travel: X: 362 mm Z: 1,105 mm Tool turret: 12 positions Spindle power: 22/26 kW Weight: 9,000 kg Year of first installation: 2000 Complete with all documentation
