CTB Machine LTD.

Condition: used, Year of construction: 2008, functionality: fully functional, Control: MAZATROL 640 workpiece diameter, max.: 1.050 mm workpiece length, max.: 1.000 mm Codpfx Afsyhp A Aepjpu Max. Spindle speed: 10.000 rpm table speeds: 500 rpm table drive: 37 kW number of tools: 80 number of paletts: 2 chucking diameter: 800 mm

Condition: used, Year of construction: 2019, Mazak Quick Turn 200MB Control: Mazatrol Smooth G Year of manufacture: 2019 Turning length: 500 mm Maximum swing: 695 mm Maximum machining diameter: 380 mm Maximum machining length: 541 mm Chuck size: 8" X-axis: 234 mm Z-axis: 625 mm Main spindle: - Power: 26 kW - Max spindle speed: 5,000 rpm - Spindle nose: A2-6 - Spindle bore: 76 mm - Max bar diameter through spindle: 65 mm Turret: - 12 tool positions (VDI type) - 12 driven positions - Milling drive power: 5.5 kW - Max speed: 5,000 rpm - Interface for bar feeder - Through-spindle coolant pressure up to 15 bar - Automatic part catcher Cjdeyhph Sepfx Afpopu The machine is in very good condition, includes standard tools and driven tools. Serviced 2026-01-12. Year of manufacture: 2019 * Max spindle speed: 5,000 rpm * Spindle nose: A2-6 * Spindle bore: 76 mm * Milling drive power: 5.5 kW * Max speed: 5,000 rpm Turning length: 500 mm X-axis: 234 mm Chuck size: 8" * Power: 26 kW Z-axis: 625 mm

Condition: used, Year of construction: 2019, Control: MITSUBISHI M730UM with CELOS Main spindle with integrated motor spindle ISM 80: 15/18.5 kW Speed range: 10–4000 rpm 10" hollow chuck 254mm KITAGAWA BB210A821 Counter spindle with integrated motor spindle ISM 65 Speed range: 10–5000 rpm 10" hollow chuck 254mm KITAGAWA BB208A621 20-position BMT star turret KNOLL high-pressure coolant system 70 bar Y-axis with 100mm travel Cpedpfx Aeyhpfqefpou Gantry loading system LG-10AI

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Cjdpsyhpd Tsfx Afpepu Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: used, Year of construction: 2006, functionality: fully functional, Control: MAZATROL 640 workpiece diameter, max.: 1.050 mm workpiece length, max.: 1.000 mm Max. Spindle speed: 10.000 rpm table speeds: 500 rpm table drive: 37 kW Cpodpfxjyhm Rwe Afpsu number of tools: 80 number of paletts: 2 chucking diameter: 800 mm

Condition: good (used), Year of construction: 2001, functionality: fully functional, Fanuc control, turret with 6 driven tool stations, tailstock, C-axis, bar feeder. Cpodpfxoyhm A Ho Afpju

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, CNC Control: F31iA X axis travel mm: 560 Y axis travel mm: 560 Z axis travel mm: 630 B axis travel: 360.000° Table load capacity: 400 kg Cutting feed rate X/Y/Z mm/min: 50,000 Maximum rapid traverse X/Y/Z m/min: 50 Spindle speed rpm: 14,000 Spindle power kW: 18.5 Taper type: BT-40 Torque Nm: 120 Magazine type Magazine positions: 60 Maximum tool diameter mm: 70 Maximum tool diameter with adjacent positions empty mm: 140 Maximum tool length mm: 400 Maximum tool weight kg: 8 Coolant tank capacity l: 500 Through spindle coolant pressure bar: 70 Cedpfx Ajyhlqpjfpspu EQUIPMENT Chip conveyor Through spindle coolant with high-pressure pump, 70 bar Tool breakage detection probe Renishaw spindle measuring system Extended tool offsets: up to 400 offsets Additional coordinate systems: 48 Workpiece coordinate systems Tool life management Extended program memory: Total length 1,280 m (512KB) Up to 1,000 storable programs Preparation for NH4000 8CPP + 8 Pallets

Condition: used, Year of construction: 2014, Mazak Quick Turn Smart 250 CNC Turning Centre with Mazatrol Smart CNC Control, Kitagawa BB 210 Powered 3 Jaw Chuck, 12 Position Tool Turret, Tailstock, Max Spindle Speed 4000rpm, Filtermist FX 4002 Oil Mist Extractor. Machine Weight 4610kg. S/No. 240540 (2014) Includes Various Tool Holders, Sleeves and Centre in Turret and Boxes. Country of Origin: United Kingdom Cpjdpfx Aoyhd Exsfpju Location: These lots are located in Dundee, Scotland, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the Purchaser. All/Any tooling is being offered as specifically described.

Condition: used, Year of construction: 2006, Mazak Quick Turn Nexus 350m CNC Turning Centre with Mazatrol 640T Nexus CNC Control, Max Swing 750mm Diameter, Standard Machining Diameter 336mm, Max Machining Diameter 420mm, Bar Work Capacity 102mm, Spindle Speeds Max 4000rpm, 12 Tool Turret, Kitagawa Powered 3 Jaw Chuck, Tailstock, Filtermist FX4002 Oil Mist Extractor, Machine Weight 7500kg. S/No. 184642 (2006) Includes Various Tool Holders in Turret, Driven Tool Holders and Sleeves. Country of Origin: United Kingdom Location: These lots are located in Dundee, Scotland, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the Purchaser. All/Any tooling is being offered as specifically described. Cpjdpfx Aoyhdycefpsu

Condition: used, Year of construction: 2006, Doosan Puma 700L Turning Centre with Fanuc Series 21i-TB CNC Control, 600mm Diameter Powered 3 Jaw Chuck, Approx. 3000mm Between Centres, 10 Position Tool Turret, Tailstock, Machine Weight 21500kg. S/No. P60L0377 (2006) Includes Various Tool Holders and Sleeves in Tool Turret and Boxes. Country of Origin: Korea Cjdpfxeyhdw Ie Afpspu Location: These lots are located in Dundee, Scotland, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the Purchaser. All/Any tooling is being offered as specifically described.

Condition: excellent (used), Year of construction: 2019, operating hours: 9,100 h, functionality: fully functional, We offer: CNC Bed Milling Machine Manufacturer: DMG MORI Model: DMF 260-11 linear Year of manufacture: 2017 Control: Celos with Siemens 840D sl Operate Technical Data: Max. turning diameter: 670 mm Turning length: 1,538 mm Bar capacity: max. 65 mm Travel axes: x1 axis: 675 mm y axis: +/- 150 mm z1 axis: 1,562 + 164 mm b axis: +/- 120° a axis: 1,542 mm Main spindle: Max. speed: 5,000 rpm Drive power: 15/15/11 kW Spindle bore: Ø 73 mm Torque: 421/302/256 Nm Counter spindle: Max. speed: 5,000 rpm Drive power: 15/15/11 kW Spindle bore: Ø 73 mm Torque: 421/302/256 Nm Milling spindle: Speed range: 0 – 20,000 rpm Tool holder: Capto C6 Number of tool stations: 114 positions Feed rates: x axis: 50 m/min y axis: 40 m/min Cjdeyhdqnjpfx Afpopu z axis: 50 m/min a axis: 36 m/min b axis: 100 rpm Hollow clamping device: Ø 67 mm Operating hours: approx. 9,100 h Spindle hours: approx. 4,600 h Technical features and accessories: - High/low pressure chucking system for main and counter spindle; programmable hydraulic 2-stage clamping pressure regulation - 8" hollow chuck Ø210 mm, hydraulic 3-jaw chuck by Kitagawa BB208A621 on main and counter spindle, incl. hollow clamping cylinder - Double foot switch with protective cover - B axis with 0.0001° positioning - Tailstock function for the counter spindle - Self-centering hydraulic steady rest, centering diameter 20 – 165 mm, by SMW SLU-X3.1 - Machine designed for coolant emulsions - Hinged belt chip conveyor - Coolant gun - Coolant shower at the chuck of main and counter spindle - Compressed air blow-off system for chuck on main and counter spindle - Coolant supply through the counter spindle - Oil separator as belt skimmer - ICS, compact filter system / paper band filter Knoll KF110/700, 70 bar, 700 l tank - Direct measuring systems - Spindle probe system with wireless transmission, Renishaw RMP 60 - Automatic tool setter for the turning-milling spindle - EtherNet I/P interface - Electrical I/F for multi-channel bar feeder/loader wired to terminal strip - Air filter unit for drying and oil separation - 10 additional M functions - 95 kVA three-phase autotransformer - 3D quickSET - Pocket and island milling function - Fast fixed cycles - Program restart - Optional skipping of a program block - Workpiece unloader with conveyor belt and collection tray Accessories, depicted tools, and clamping devices are only included if specified in the additional information. Subject to technical changes, errors, and prior sale!

Condition: used, Year of construction: 1995, functionality: fully functional, We offer this used CNC lathe MAZAK MULTIPLEX 620 MARK 2, year of manufacture 1995, currently located in Spain. Immediately available. Control: MAZATROL T PLUS – Turning diameter: 200 mm – Number of spindles: 2 Codpfjyhdf Ejx Afpspu

Condition: excellent (used), Manufacturer: Yamazaki Mazak Corporation Model: Nexus VCN-510C Machine type: Vertical CNC machining center Control: MAZATROL 640M Cpodpfx Afjyha Ivspou X-axis travel: 1,050 mm Y-axis travel: 510 mm Z-axis travel: 510 mm Worktable: T-slot table, moving table Tool magazine: Automatic tool changer (ATC) Control cabinet: Yes Additional equipment: Lubrication system Weight: 7,100 kg

Condition: good (used), Year of construction: 2018, functionality: fully functional, The machine is in good technical condition, testing can be arranged by prior agreement. Cedpfxoyg Sh So Afpepu

Condition: good (used), Year of construction: 1998, Mazatrol T-Plus control Max. turning diameter: 470 mm Max. swing diameter: 575 mm Csdpfjyg Ru Dex Afpopu Turning length: 1,500 mm Spindle speed: 3,000 rpm Magazine for 40 tools (KM 63/SK 40) B-axis Y-axis Steady rest Tailstock Chip conveyor

Condition: good (used), Year of construction: 2008, functionality: fully functional, Okuma Multus B300-W Cpsdsyg Rf Nepfx Afpju 6-axis turning and milling center - Okuma OSP P200L - Year 2008 - Cutting time: 10,500 h - H1 milling spindle: 6,000 rpm - Main spindle: 3,800 rpm, Rota NC 315-86 - Counter spindle: 5,000 rpm - ATC 60 system HSKA-63 (60 tools) - Geometry: very good - Marpos tool sensor

Condition: used, Year of construction: 2008, functionality: fully functional, We offer this used DOOSAN Puma 300C CNC lathe, year 2008, currently located in Spain. Immediately available. Travel distances: X-axis: 282 mm Z-axis: 681 mm Rapid traverse speed: X-axis: 16 m/min Z-axis: 24 m/min Swing diameter over bed: 590 mm Max. turning diameter: 400 mm Max. turning length: 630 mm Centre distance: 690 mm Bar capacity: 102 mm Spindle bore: 115 mm Spindle power: 26 kW Cpedoyg Ndwepfx Afpou Spindle speed range: 10–2800 rpm Tool turret stations: 12 Bar feeder: SpaceSaver SS

Condition: excellent (used), Year of construction: 2015, Maximum turning diameter: approx. 380 mm Maximum swing over bed: approx. 675 mm Maximum turning length: approx. 500–540 mm Bar capacity (main spindle): approx. 76 mm (3″) MAIN SPINDLE Maximum spindle speed: 4,000 rpm Spindle motor power: 26 kW Spindle bore: approx. 77–88 mm Chuck: 8″ power chuck SUB SPINDLE Maximum spindle speed: 6,000 rpm Spindle motor power: approx. 11 kW Chuck: 6″ or 8″ power chuck Part transfer function Cpsdpeyg It Defx Afpju AXES X-axis travel: approx. 230 mm Z-axis travel: approx. 575 mm C-axis on main spindle (full contouring and interpolation) TURRET / TOOLING Number of tool stations: 12 positions Live tooling capability (drilling and milling) Tool measurement system (Tool Eye) CNC control: Mazatrol Matrix Nexus EIA/ISO programming Conversational Mazatrol programming 19″ color LCD screen (touch screen) COOLING & CHIP HANDLING High pressure coolant through spindle: 15 bar External flood coolant via spindle nozzles Hinged belt chip conveyor with side discharge Complete coolant system with pumps and filters AUTOMATION Automatic bar feeder included Automatic chuck open/close Chuck status feedback via sensors Automatic part transfer between spindles OTHER FEATURES Pitch error compensation (X, Z) 3D tool compensation Helical interpolation Polar coordinate programming Thread cutting (G33) Workpiece coordinate rotation User macro functions Tool breakage detection MACHINE DIMENSIONS & WEIGHT (approx.) Machine weight: 5,000 – 5,500 kg Machine footprint: approx. 2,600 × 2,000 × 1,900 mm

Condition: excellent (used), Year of construction: 2021, operating hours: 1,100 h, functionality: fully functional, 2021 yom 1100 cutting hours turning diameter 500 mm turning length 1016 mm control Mazatrol Smooth G axis stroke (X,Y,Z) 450/200/1066 mm 1436 mm rapid travel x/y/z 40000 mm/min rapid travel W 30 m/min Main spindle: spindle turning speed range 35 – 5000 U/min Motor output (40%ED) 15 KW capacity at 100% 11 KW spindle bore 76 mm bar material dia. 51 (max 65) mm spindle nose JIS A-6» Cjdpfxeyg Irgs Afpopu 3-jaw chuck Kitagawa B208 milling spindle turning speed range 12000 U/min power capacity 7,5 kW tool taper Capto C6 tool change unit numbers of positions in the tool changer 36 max. tool diameter 90 mm max. tool length 210 mm max. tool weight 5 kg dimensions of the machine ca. 3,8 x 2,42 x 2,5 m total power requirement 35 kW weight of the machine ca. 9,1 t dimensions of the machine ca. 3,8 x 2,5 x 2,5 m

Condition: ready for operation (used), Year of construction: 2007, spindle motor power: 45,000 W, spindle speed (max.): 3,500 rpm, total height: 2,110 mm, overall weight: 7,600 kg, controller manufacturer: OKUMA, controller model: OSP -P200L, product length (max.): 5,330 mm, number of axes: 2, This Okuma LB400-M was manufactured in 2007. A robust turn-mill centre featuring a swing diameter over bed of 620 mm and over saddle of 420 mm. It offers a bar capacity of 80 mm and a chuck size of 400 mm. The spindle operates at speeds up to 3,500 rpm, powered by a 45 Kw motor. Includes a 12-position motorized turret. Contact us for more information about this machine. • Number of axes: 2 + C Codpjygxccofx Afpepu • Swing diameter over bed: 620 mm • Swing diameter over saddle: 420 mm • Distance between centers: 1,270 mm • Chuck size: 400 mm • Bar capacity: 80 mm • Turret type: Motorized • Tool stations: 12 positions • X rapid traverse: 20 m/min • Z rapid traverse: 25 m/min • Tailstock spindle taper: MT #5

Condition: used, Year of construction: 2008, turning diameter: 275 mm, spindle bore: 80 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 260 mm, travel distance Z-axis: 1,345 mm, total height: 2,232 mm, total length: 4,339 mm, total width: 2,232 mm, overall weight: 7,600 kg, Equipment: documentation/manual, CNC Lathe with Y-axis, driven tools an 2nd spindle CNC Control MSX-850-lll (mitsubishi 720 BM) Turning diameter 275 / 366 mm Spindle bore diameter 80 mm Spindle speed 4000 R/min Cpodpfx Ajygw Hmofpou Spindle motor 18.5/15 Kw Movement X-axis 260 mm Movement Y-axis +50 / -50 mm Movement Z-axis 1345 mm Movement W-axis (subspindle to mainspindle) 1275 mm Min indexing C-axis main spindle 0,001 ° Number of tools on turret 12x Number of driven tools 12 x Tool Taper BMT Bar feeder LNS Quick Load Servo lll Spindle motor driven tools 6000 R/min If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: like new (used), Year of construction: 2015, operating hours: 3,886 h, functionality: fully functional, turning length: 685 mm, turning diameter over cross slide: 650 mm, spindle speed (max.): 4,000 rpm, spindle bore: 91 mm, travel distance X-axis: 267 mm, travel distance Z-axis: 600 mm, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, chuck outer diameter: 250 mm, swing diameter over cross slide: 650 mm, spindle nose: A2-8, overall weight: 5,200 kg, Equipment: documentation/manual, rotational speed infinitely variable, This DMG MORI CLX 450 V3 is standard equipped with: - PROGRESSLine (display of remaining production time and piece count for a complete machining process). - Interface for barfeeder. - Chip conveyor. - High-pressure pump (12 bar). Cjdpfx Ajyguqiefpepu - New 3-jaw chuck (SMW AUTOBLOK type BB-D Ø250) incl. sets of jaws. - Workpiece catcher/dispenser. - Original DMG mist extraction system. - Foot pedal for clamping/unclamping main spindle. - Rinsing gun (5 bar). - Original DMG documentation.

Condition: new, Year of construction: 2019, operating hours: 10 h, functionality: fully functional, turning length: 750 mm, turning diameter over cross slide: 630 mm, turning diameter: 400 mm, spindle motor power: 18,500 W, spindle speed (max.): 4,800 rpm, spindle bore: 65 mm, travel distance X-axis: 300 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 780 mm, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (max.): 4,000 rpm, type of input current: three-phase, feed length X-axis: 300 mm, feed length Y-axis: 100 mm, feed length Z-axis: 780 mm, torque: 384 Nm, bar passage: 51 mm, feed rate Y-axis: 15 m/min, total height: 1,800 mm, total length: 4,750 mm, chuck outer diameter: 208 mm, total width: 2,200 mm, bar diameter (max.): 51 mm, overall weight: 6,500 kg, Equipment: documentation/manual, rotational speed infinitely variable, We offer this new Woodway GS-2000SY CNC turning and milling center, year of manufacture: 2019. Cpjdpfxoygnhhe Afpeu Manufacturer: Woodway Model: GS-2000SY Year: 2019 Condition: new Category ID: 1128 Type ID: 2239 Type: CNC turning and milling center Accessories: 3 radial and 3 axial driven tool holders, in addition to 12 static holders. Also equipped with a Renishaw HPRA manual tool setting arm. The machine has only been commissioned; no machining has taken place! Demonstration in powered-on condition is possible, but no machining, as then it would no longer be considered new! If you have any questions or require further information, please send us a message.

Condition: used, Year of construction: 2003, centre distance 2.500 mm greates pass round over bed 900 mm swing diameter over bed slide 800 mm turning diameter over bed slide 670 control SIEMENS - 840D travel -x axis 500 mm travel -y axis min: 260 | max: 2.595 mm spindle diameter in front bearing 165 mm driven tools turning speeds 2.000 U/min Cedpfsygm Tvox Afpepu CNC Turning- and Milling Center | HEYLIGENSTAEDT - HEYNUMAT 24U / 2500 equipped with c- and y-axis. Additional equipment: - Extraction system - Steady rest (20 - 230 mm) - tailstock with its own drive - Power: Main drive 60 kW The machine is in a well-maintained condition and can be inspected at any time under power. A machine video from the production plant will be shared on request. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: HEYNUMAT 24 | HEYNUMAT24 | HEYNUMAT 24U 2500

Condition: used, Year of construction: 2008, turning diameter 12,7 mm turning length 50 mm control Traub System TX 8i turning speeds 12000 U/min c-axis 0,001° gripping station 12,7 mm c-axis 0,001 ° speeds 12000 U/min rapid traverse 15 m/min turret (x-stations) 6 worktool system 5+3 worktool system 3 Werkzeugsysteme total power requirement 2,5/4 kW weight of the machine ca. 2 t dimensions of the machine ca. 2,4 x 1,1 x 1,7 m CNC turning machine Traub TNL 12K with barloader LNS Tryton 112 Motor drive S8 (rear working with driven tools possible) Motor drive S7 (front working with driven tools possible) Cedpfxeygm R Ie Afpjpu
