Tool grinding machine

Chuet Nevers Schleifscheiben Ø max. 200 mm

Condition: used, mileage: 6,35,000 km, power: 405 kW (550.65 HP), first registration: 05/2011, fuel type: diesel, overall weight: 18,000 kg, brakes: retarder, gearing type: semi-automatic, emission class: euro5, loading space length: 4,500 mm, loading space width: 2,360 mm, loading space height: 600 mm, Equipment: soot filter, - Retarder - Air conditioning - Tow bar - 3-way tipper Suspension: Leaf springs Nlodpfx Aleyaml Sshsc

Condition: new, Center length ----- 750 mm Center height ----- 125 mm Turning diameter ----- 250 mm Passage of main spindle ----- 26 mm Bed width ----- 135 mm Spindle speed ----- variable 30-2200 rpm Frequency motor ----- 1.1 kW INCLUDING Nlodpfoq E I Avsx Alhec * Delta frequency switch * Automatic longitudinal and transverse feed * Thread cutting clock * 3 chuck 125 mm * 4 chuck 125 mm * Clamping plate * Fixed spectacles * Guiding glasses * Back plate * Back plate * Box with various tools Option * Base cabinet

Condition: ready for operation (used), Number of axis: 6, nominal load: 90kg, controls: Engel, weight: 1.13t. Nsdpfsk N Dnhex Alholc

Condition: new, carrying capacity 500 kg number of suction cups 6 suction cup dia. 215 mm Vacuum lifter VH 6-500 for the horizontal transport of smooth, dry and airtight panels. Robust supporting structure made of steel, painted in RAL 2000 with low Own weight. Nledpfx Aljq Sc Aushsc consisting of: - 1x galvanized longitudinal beam with a length of 2,400 mm - 3x galvanized crossbeams with a length of 1,000 mm - 6x Springy, articulating and adjustable suction cup holders - 6x suction cups Ø 215 mm, the seal can be separated in case of wear whose metal supports can be changed inexpensively and without tools - 6x ball valves to switch off individual suction cups, thus also smaller formats can be lifted without having to move suction cups or traverses. - 1x spiral connection cable small helix: * with an extension length of 3,500 mm, designed as an extension cable with CEE plug and coupling. * is routed to the lifting device next to the load chain. - Low-maintenance, very high-quality, dry-running rotary vane vacuum pump a suction capacity of 8 m³/h and a final vacuum of 85% (150 mbar) - Electrical connection: 3 phases 230/400 V + PE, 50 Hz, with cable (approx. 0.5 m long) and CEE plug (16 A). Integrated into the control with isolating transformer (necessary if the vacuum lifter is connected via the crane trolley and this has no neutral conductor) - Operating handle can be extended to 1,000 mm from the center of the traverse. Sturdy sheet metal bag for your crane control incl. at no extra charge. - Operation "suction / release" using manual slide valve: The wear-free and very robust manual slide valve ensures safe Suction and release after pressing the release button. (twice loosening according to EN 13155) - Control and safety device for vacuum lifters: * Robust control box. * Contactor circuit for the vacuum pump. * Safety warning device with audible alarm. * Vacuum gauge with danger zone indicator. * Large vacuum storage tank with safety check valve * Double actuation when releasing the load. - Fine dust filter to protect the vacuum pump - Detailed and easy to understand documentation. One year warranty against material and manufacturing defects One-shift operation (without wearing parts). Initial test UVV 18, VBG 9a with CE declaration of conformity - according to EN 13155 - Packing for truck transport.

Year of construction: 2010, condition: used, METAL SHEET PROFILING LINE FOR TILE ROOF PANELS Reduced price due to urgent sale Scope of supply 1 Uncoiler 2 Front shear + coil guide table 3 Film applicator 4 Base parts of cassette type forming machine 5 Roll forming machine for roof tile for "COPPO" 6 Roll forming machine for rooftile for "ATIIKA" 7 Roll forming machine for rooftile for "T177.5" 8 Shearing (Cut-off) machine: Flying type 9 Drawing part 10 Auto stacker 11 Electric control panel Technical specifications - Manufacturer: IL Kwang (Korea) - Manufacturing: Year 2010 - Material: Pre-painted, galvanized steel sheet (ASTM A 526/ JIS G 3302 SGCC) - Tensile strength: 250 ~ 320 MPA - Max. coil width: 1250 mm - Coil thickness: 0.35 – 0.8 mm - Max. coil weight: 15 ton - Outer coil diameter: Max. 1300 mm - Inner coil diameter: 508 mm - Line speed (length > 5 m): Max. 8 m/min - Speed control: Frequency control by inverter - Commercial voltage: 380 / 50 V/Hz 3 Phases - Surface (LxWxH): Approx. 30 x 8 x 5 m Brand of components - Motor: Siemens (ICE. type) - PLC + Inverter: Siemens 7 - Servo: Mitsubishi (with C.E ) - Touch screen: Pro-face (with C.E.) - Electric components: L.G (with C.E.) Commercial voltage: 380 / 50 V/Hz 3 Phases Line speed (length > 5 m): Max. 8 m/min Material: Pre-painted, galvanized steel sheet (ASTM A 526/ JIS G 3302 SGCC) Tensile strength: 250 ~ 320 MPA Max. coil width: 1250 mm Coil thickness: 0.35 – 0.8 mm Max. coil weight: 15 ton Nodpfxsymbfyo Alhjlc Outer coil diameter: Max. 1300 mm Motor: Siemens (ICE. type) PLC + Inverter: Siemens 7 Servo: Mitsubishi (with C.E ) Touch screen: Pro-face (with C.E.) Electric components: L.G (with C.E.) Speed control: Frequency control by inverter Inner coil diameter: 508 mm Surface (LxWxH): Approx. 30 x 8 x 5 m

Condition: refurbished (used), overall weight: 7,800 kg, Jaw width: 650 x 450 mm Capacity: 12 - 60 cbm/h Gap width: 35 - 150 mm Weight: 7,800 kg Nsdpoq Tth Tsfx Alhjlc Power requirement: 45 kW Completely overhauled in the workshop and newly stored

Condition: refurbished (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 119/020.0895, Manufacturing origin CH Voltage 400 V Netweight 4500 kg Custom position 8460.2320 Dimensions 2700x2350x2100 mm TECHNICAL DATA Control Fanuc 16i-T Center height 175 mm Distance between centers 1000 mm LINEAR AXES Grinding length 500 mm Strokes X : 267 mm Z : 650 mm WHEEL HEADSTOCK Continuous orientation +/- 8.5°. External grinding wheel size 500x80x203 mm Power 7.5 kW Speed 44 m/sec. WORKPIECE HEADSTOCK Taper type MT5 C-axis +/- 5 Power 1 kW Speed 30-1000 min-1 TAILSTOCK Taper type MT3 Sleeve stroke 35 mm Sleeve diameter Ø 50 mm Max. workpiece weight 130 kg POWER SUPPLY Voltage 400V 50 Hz errors and omissions excepted-data given without obligation Fully overhauled: Mechanics, geometry, hydraulics and electrical parts checked and/or replaced. Grinding headstock Disassembly, cleaning of parts, replacement of worn and defective parts, overhaul of motor, replacement of bearings, replacement of belts, disassembly of spindle, replacement of seals and O-Rings + adjustment. New paintwork. Headstock Dismantle, clean parts, replace worn and faulty parts, overhaul motor, replace belts. New spindle bearings. New paintwork. Tailstock Dismantled, checked and overhauled. Hydraulics Dismantle, check motor, replace hoses, defective and worn parts. Check hydraulic block X-axis Dismantle, replace worn parts such as O-Rings, seals, rings etc., overhaul hydraulic piston, grind tables. Z axis Dismantle, grind tables, replace worn and defective parts, overhaul hydraulic piston, new paintwork. Electrical cabinet Complete check, change various relays. Painting Colors: White RAL 9003 and gray RAL 7011 Geometry according to manufacturer's protocol. Nedpfx Alolbgfceholc Inspection and cleaning of various accessories

Condition: good (used), Year of construction: 1962, High speed radial drilling machine, radial drilling machine, drilling machine, boom drilling machine, high speed radial drilling machine Nlodpfx Aoirax Uelhjc -Clamping table: 400 x 1100 mm -Projection: 930 mm -Taper mount: MK4 -Engine power: 1.35/1.8 kW -Speed: 41-1700 rpm -Columns: Ø 200 mm -Spindle stroke: 125 mm -Thread cutting device: YES -Feed: 0.075 - 0.3 mm/rev -Dimensions: 1800/1235/H2240 mm -Weight: 1500kg

Condition: new, Year of construction: 2024, Bending force: 320 t Year of manufacture: New (delivery time 6-8 weeks) Control system: DT 15 Bending length: 3050 mm Distance between columns: 2600 mm Y rapid traverse speed: 160 mm / s Y working speed: 10 mm / s Y return speed: 140 mm / s Motorized crowning Table length: 630 mm Table width: 154 mm Table height: 900 mm Stroke: 365 mm Overhang: 410 mm 2 support arms 2 rear stop fingers Travel speed X-axis: 250 mm / s R-axis working speed: (max.) 140 mm / s R-axis travel: 250 mm Standard equipment: Nedpofifg Hofx Alhelc Y1, Y2, X (3-axis) Y1, Y2, X = 650 mm (double guide, aluminum) D-BEND software for 3D bending simulation and alignment Manual crowning R-axis, manual Motorized rear stop with linear guide and ball screw Rear stop finger with height adjustment (R-axis, manual) CE upper tool holder system (upper tools) Front support arms for sheet metal, sliding (with T-slot and stops) Hydraulic blocks and valves in special design, in accordance with worldwide applicable standards Electrical equipment, in accordance with worldwide applicable standards Option: CE standard with manual Fiessler AKAS II M -FPSC-B-C (SAFETY PLC) CNC motorized crowning Y1, Y2, X, R (4-axis) CNC motorized crowning Motor power 37 kW Oil tank capacity 250 liters Length 4300 mm Width 1820 mm Height 3230 mm Weight approx. 17250 kg

Condition: excellent (used), Year of construction: 1997, pressure 170 t chamfer lenght 4080 mm distance between columns 3680 mm column arm 410 mm dayligth 385 mm stroke 215 mm ajustment speed 200 mm/sec working feed 1-10 mm/sec return speed 135 mm/sec table width 200 mm table height 1050 mm Number of working hours 25.430 h oil volume 350 l total power requirement 29 KVA weight of the machine ca. 16.450 kg. range L-W-H 4620 x 2210 x 2885 mm Machine in good condition Regularly serviced by the manufacturer CNC backgauge with 8 axes (!!) - in checked conditions - machinevideo - ?v=yEaRj0XJAC4 Equipment: Nljdpexcp Rbofx Alhoc - CNC electro-hydraulic press brake/die bending press - DELEM CNC control - swiveling front left * High-resolution graphic screen * Clear, concise menus in the operator's language * Large tool and product library * Graphic 2D programming * Automatic bend sequence calculation and collision detection * Emergency stop button at front - CNC axis adjustment: * Y1 - Y2 - X1 - X2 - R1 - R2 - Z1 - Z2 axis + CNC crowning - X axis - adjustment speed: 500 mm/sec. * Max. stop range: 860 mm - R axis - Adjustment speed: 300 mm/sec. * Max. travel: 250 mm - Z axis - Adjustment speed: 1000 mm/sec. * Max. travel: 3260 mm - CNC electric motor table crowning - CNC electro-pneumatic die shift (I axis) - WILA / TRUMPF upper tool clamping - hydraulic - WILA / TRUMPF lower tool clamping - hydraulic - 2x front, robust support arms - movable - 1x freely movable 2-hand/foot control - 1x freely movable foot switch - Side safety device (swivel doors) - Rear safety device (sliding doors) - Original operating instructions
