Used Klingelnberg - Oerlikon Measuring Machine for sale (67,454)

Condition: used, Year of construction: 2007, max. wheel diameter 400 mm workpiece dia. 36-300/400 mm axis distance 135-290 mm spindle turning speed - stepless 3000 1/min dist. between centers 100-550 mm Control Siemens 840D weight of the machine ca. 4000 kg dimensions of the machine ca. 2000x3055x2788 mm Test method: - Single flank rolling test - Double flank rolling test Gbsdpfx Aaey D T Suoyop - Structure-borne noise test - Heli testing in two-flank contact. Features: - Use of up to 6 test slides - Highest testing accuracy and repeatability - Machine table with workpiece drive - Swiveling pneumatic unit - Spray oil lubrication (type: Vogel) - Oil mist extraction (type: Elbaron)

Year of construction: 2002, condition: used, z-travel 200 mm Clamping diameter of the cutter heads max. 550 mm Max. permissible cutter head weight 150 kg Mounting plate diameter for cutter heads 360 mm Mounting cone for cutter heads Nominal diameter 500 mm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m Cutter Head Set-Up- and -Measuring Machine In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in dry milling, high gear cutting quality and a long service life can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) Gjdpfxjy A S U So Aayobp - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: used, Year of construction: 2006, voltage 110 - 230 V frequency range 50 - 60 Hz Power connection 0,5 kVA Dimensions (HxWxD) 1000 x 800 x 1750 mm weight 150 kg Measuring machine for bar knives. Equipment/accessories: -Measuring tools -Clamping devices Godpfeyhq T Aox Aaysbp -Computer -Monitor -Printer -Cabin -Technical documentation

Condition: used, Year of construction: 2007, max. wheel diameter 500 mm Hypoid adjustment ±70 mm axial cross angle 90 ° Distance Y- 150 - 350 mm Distance Z-axis 120 - 340 mm turning speed range - stepless 0 - 5000 U/min Gsdpfx Aajukitxoyebp max. torque on the spindle 57 Nm Cone 99,2 mm Pull-in force Tool clamping 23000 N Braking torque max. 93 Nm total connected load 20 kVA total power requirement 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 2,35 x 2,24 x 2,5 m

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, wheel diameter: 400 mm, overall weight: 4,000 kg, distance between centers: 550 mm, spindle speed (max.): 3,000 rpm, controller model: Siemens 840 D, TECHNICAL DETAILS Max. wheel diameter: 400 mm Workpiece diameter: 36–400 mm Centre distance: 135–290 mm Max. spindle speeds (infinitely variable): 3,000 rpm Centre width: 100–550 mm MACHINE DETAILS Control: CNC Siemens 840 D Dimensions & Weight Space requirement: approx. 2,000 x 3,055 x 2,788 mm Machine weight: approx. 4,000 kg EQUIPMENT Single-flank rolling test Double-flank rolling test Structure-borne noise testing Helical contact testing (double-flank contact) Use of up to 6 test carriages Gbsdpfx Aeywg Hxeayep Highest test accuracy and repeatability Machine table with workpiece drive Swivelling pneumatic unit Spray lubrication (Type: Vogel) Oil mist extraction (Type: Elbaron)

Condition: good (used), Year of construction: 2006, voltage 110 - 230 V frequency 50 - 60 Hz Power connection 0,5 kVA weight 150 kg dimensions of the machine ca. 1,0 x 0,8 x 1,75 m Stick blade profile control unit - Control via PC control with Windows XP operating system - Digital drive amplifiers, linear motors and measuring systems - Fully automatic position determination of the cutting edges and axis position of the stick blade - Measurement of almost all single-part and continuous processes required for spiral bevel gears and hypoid gears - Machine concept designed for the shortest set-up and changeover lines and maximum measuring accuracy - Combination probe for measuring tip and surface measurement - Integrated drawer for accessories Gbsdjymfz Sjpfx Aaysp - Keyboard integrated in flat drawer - Operating elements and PC protected against unauthorized access with lockable cabinet element

Condition: good (used), Year of construction: 2002, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Gbodpfsw N S E Aox Aayep Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, grinding wheel diameter: 200 mm, workpiece length (max.): 200 mm, TECHNICAL DETAILS Grinding wheel diameter: 100–200 mm Maximum workpiece length: 200 mm MACHINE DETAILS Control: Siemens 840D or equivalent CNC axes: 3–5 axes Drive power: 5–10 kW Coolant tank: 100–200 litres EQUIPMENT Coolant filtration system Universal applicability for different tool types and geometries High flexibility through CNC programming and adaptable clamping devices Process reliability thanks to integrated cooling and filtration system Gbsdpfjya Dy Hjx Aaysp Easy maintenance due to modular design and central supply units

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 06010056, total height: 1,620 mm, total width: 910 mm, total length: 980 mm, A coordinate measuring machine manufactured by Tesa, model: Micro-hite 3D, will be auctioned. MACHINE DETAILS Overall length: 980 mm Gjdpfx Aaezhmq Noyobp Overall width: 910 mm Overall height: 1,620 mm Installation date: March 24, 2006

Condition: used, Year of construction: 2017, functionality: fully functional, machine/vehicle number: PZ131117, type of input current: AC, input voltage: 230 V, overall weight: 105 kg, input frequency: 50 Hz, Metrios MT11080 Optical Measuring Machine (2017) Gsdezhumropfx Aayebp

Condition: good (used), Year of construction: 2010, 2010 Mitutoyo Crysta-Apex C574 High-Accuracy, 3D CNC Coordinate Measuring Machine Gbodjzk Dpzspfx Aayjp Serial number: 80461121; Measuring range (X x Y x Z): 500 mm x 700 mm x 400 mm; Table size: 1160 mm L x 638 mm W; Maximum Workpiece Height: 180 kg; Maximum Workpiece Height: 545 mm; Drive Speed: Up to 520 mm/s; Acceleration: 0.17 G (1,667 mm/s²); Linear Encoder Resolution: 0.1 μm (0.0001 mm); Accuracy: MPE (Maximum Permissible Error) typically ranges from E₀ = (1.7 + 3L/1000) μm; Equipped Reinshaw TP 200 compact module-changing probe; Principal application: DCC CMM where high accuracy is required; Sense directions: 6-axis (±X, ±Y, ±Z); Unidirectional repeatability (2σ µm): Trigger level 1: 0.40 μm (0.000016 in), Trigger level 2: 0.50 μm (0.00002 in); XY (2D) form measurement deviation: Trigger level 1: ±0.80 μm (0.000032 in), Trigger level 2: ±0.90 μm (0.000036 in); XYZ (3D) form measurement deviation: Trigger level 1: ±1.00 μm (0.00004 in), Trigger level 2: ±1.40 μm (0.000056 in); Repeatability of stylus change: With SCR200: ±0.50 μm (0.00002 in) maximum, Manual: ±1.00 μm (0.00004 in) maximum; Trigger force (at stylus tip): XY plane (all modules): 0.02 N, Z-axis (all modules): 0.07 N; Overtravel force (at 0.50 mm displacement): XY plane (SF/EO module): 0.2 to 0.4 N, XY plane (LF module): 0.1 to 0.15 N, Z-axis (SF/EO module): 4.90 N, Z-axis (LF module): 1.60 N; Weight (probe sensor and module): 22 g (0.78 oz); Maximum extension (when mounted on a PH10 PLUS series head): 300 mm (11.81 in); Maximum recommended stylus length (M2 styli range): SF/EO module: 50 mm steel to 100 mm GF, LF module: 20 mm steel to 50 mm GF; Mounting method: M8 thread; Suitable interface: PI 200-3, UCC; Stylus module changing rack: SCR200; Stylus range: M2; Equipped with Reinshaw SCR200 stylus change rack; Weight: 0.75 kg; Mounting orientation: Vertical or horizontal; Mounting fixture: Single stud (M8, M10); Number of ports: 6; Repeatability of stylus change (2σ) at 50 mm: Automatic ≤ 1 μm, Manual ≤ 2 μm; Entry speed: Unrestricted; Module pull-off force: 800 g maximum; Overtravel protection: Electromechanical (minimum deflection: 5); LED indicators: Power: Green, Status: Red (flashing during probe inhibit); Change cycle detection: Optoelectronic beam system with Hall effect proximity sensor; Multi-rack usage: Up to two SCR200 units (12 ports) may be connected with a special cable; all needed documents will be provided in order to restart the machine Machine Weight: 625 kg; Maxine Dimensions: 2200 mm L x 1500 mm W; Inv. Nr: 2077; Due to the dual-use classification of these instruments, all transactions involving them must be approved by Mitutoyo Japan; Mitutoyo can also provide transportation preparation, installation, and commissioning at the new location as a paid service. Optional loading services are available on site. Indicative price: 70 EUR, VAT not included;

Condition: good (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 200008301032, measuring range X-axis: 400 mm, measuring range Y-axis: 500 mm, measuring range Z-axis: 350 mm, workpiece weight (max.): 280 kg, total height: 2,000 mm, total width: 1,100 mm, total length: 1,100 mm, overall weight: 500 kg, table width: 680 mm, table length: 855 mm,

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, measuring range X-axis: 1,000 mm, measuring range Y-axis: 3,000 mm, measuring range Z-axis: 800 mm, Measuring range X-axis: 1,000 mm Y-axis: 2,000 mm Z-axis: 800 mm Granite guideways Air-bearing axes Measuring accuracy Length measurement deviation: approx. 1.3 µm plus L/400 depending on the design and calibration status Probing systems Renishaw probing heads are possible Touch trigger and scanning PH10, TP20, SP25, SP80, depending on the configuration Workpiece weight Permissible table load up to approx. 2,000 kg depending on the design Control CNC control with hand-held operator unit Software Metrosoft CM Version 3.112 WENZEL Quartis R16 Electrical supply 230 V, 50/60 Hz Power consumption: approx. 1 kVA Gsdpfoy Ewgxsx Aayobp Pneumatic supply Compressed air, 6 to 10 bar filtered and dry

Condition: used, Year of construction: 2014, x-axis 1.200 mm y-axis 3.000 mm z-axis 1.000 mm solution 0.0001 mm max. workpiece height 1.200 mm max. workpiece weight 3.000 kg In our assessment, the machine is in good used condition and can be inspected under power by appointment. Gbjdpfozbc Hhsx Aayop Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice. Prior sale is reserved.

Condition: good (used), Year of construction: 2017, Machine is in good working conditions. Parts shown by hand not come. Technical data are on pictures. Gjdpjzlalhefx Aayjbp

Year of construction: 1987, condition: used, x-travel 2800 mm y-travel 800 mm Gbodpfst Hw I Njx Aayop z-travel 1300 mm weight of the machine ca. 3 t

Year of construction: 1990, condition: used, x-travel 4070 mm y-travel 1185 mm z-travel 1985 mm total power requirement kW weight of the machine ca. 15 t dimensions of the machine ca. 6000 x 4500 x 4000 m Gbjdpfx Aet Hwt Esaysp Consisting of: Working Range: Measuring column, longitudinal movement, X Axis 4,070 mm Measuring slide, cross, as Y Axis (measuring head) 1,185 mm Measuring slide, vertical, as Z Axis (vertical) 1,985 mm Adjustment of measuring head, roll axis 360 ° pitch axis 220 ° Measuring table 5,000 x 2,000 mm Weight, approx. 15,000 kg Space required 6,000 x 4,500 x 4,000 mm Accessories / Special Features : o 3D tracer head, with turning/swivelling device. o Universal 3D Measuring Software, KOROS CAD 5.2.0 from November 2001 (with lots of enhancements), as well as HOLOS UX for manual or automatic measuring of all geometric elements and free-form surfaces, ideally on passenger car bodies, engineering parts and large forming tools. o Separate switch cabinet (Master F1) with programming possibility and a mobile manual control console. o Steel clamping table, which can be levelled, 2,000 x 5,000 mm. o Machine was maintained annually by DEA Company, and the software was updated regularly. This unit is ideal for measuring complete car bodies. Condition : Very good. Machine is assembled and can be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. Thank you for your interest. We have a selection of measuring machines on stock.

Year of construction: 1986, condition: used, x-travel 2400 mm y-travel 1600 mm Gedpfjt Hwxnjx Aayjbp z-travel 1800 mm total power requirement kW weight of the machine ca. 3300 kg dimensions of the machine ca. m

Year of construction: 1998, condition: used, x-travel 0 mm y-travel 0 mm z-travel 0 mm Gbsdpfx Aaet Hwx Ujyjp total power requirement kW weight of the machine ca. 3500 kg dimensions of the machine ca. m

Year of construction: 2000, condition: used, x-travel 1000 mm y-travel 1600 mm z-travel 800 mm Control WENZEL WPC 2040/FW31.351 total power requirement kW weight of the machine ca. 5500 kg dimensions of the machine ca. m Godpfot Hw Nyjx Aaysbp Coordinate measuring m/c, software QUARTIS R12/16, Renishaw PH10Mplus

Condition: used, Year of construction: 2000, table length 1160 mm table width 710 mm daylight 650 mm Gbedpfxjt Hw S Ij Aayjp Control WENZEL ME 5007 total power requirement kW weight of the machine ca. 800 kg dimensions of the machine ca. m 3-D-coordinate measuring machine with METROLOG II-Software

Year of construction: 1995, condition: used, x-travel 9200 mm y-travel 1600 mm z-travel 2400 mm Gedpfxjt Hwwkj Aayjbp dia. of test piece mm working area mm dist. between centers mm control ZEISS C 99 total power requirement kW weight of the machine ca. 30 t dimensions of the machine ca. 10 x 3,6 m

Year of construction: 1995, condition: used, x-travel 5500 mm y-travel 2750 mm z-travel 1500 mm total power requirement kW weight of the machine ca. 20 t dimensions of the machine ca. 8x4,5x4,2 m Measuring column, longitudinal movement, X Axis 5,500 mm Measuring slide, cross, as Y Axis (measuring head) 2,750 mm Measuring slide, vertical, as Z Axis (vertical) 1,000 mm Adjustment of measuring head, roll axis 360 ° Measuring table 5,000 x 2,500 x 350 mm Weight, approx. 20,000 kg Gbodpfst Hwp Hjx Aayep Space required 8,000 x 4,500 x 4,200 mm Accessories / Special Features : o RENISHAW 3D probe head with rotating-tilting device, operating depending on orientation. o Universal 3D Measuring Software, CHOROS Version 5.2 with DEC Software, OPEN VMS Alpha ADL, Version 6.1 with various additional SEC Software, OVMS Base, NAS 150, Cluster, OPEN 3 D, Version 2.5, etc. for manual or automatic measuring of ruled geometry and freeform surfaces, ideally on auto bodies, machine tool parts and forming tools. o ALPHA Programming Station with hard drive, disk drive, printer and a mobile manual control panel. o Steel clamping table, which can be levelled, 2,500 x 5,000 mm. o Machine was maintained annually by DEA Company. Condition : Very good. Machine is on stock but not yet assembled. Stable, heavy duty design for high precision measurements. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. Thank you for your interest. We have a selection of measuring machines on stock.

Year of construction: 1990, condition: used, x-travel 850 mm y-travel 1200 mm z-travel 600 mm total power requirement kW weight of the machine ca. t Gsdot Hwqkspfx Aayjbp dimensions of the machine ca. m Universal 3D measuring center, double-column, modern software, many accessories

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: 400181806, measuring range X-axis: 100 mm, travel distance Z-axis: 3,500 mm, TECHNICAL DETAILS Measuring range, X-axis: 100 mm Measuring range, Z2-axis (column), travel: 3,500 mm Measuring range, Z2-axis (horizontal): 360 mm Resolution: 0.04 µm Resolution, X-axis: 0.05 µm Resolution, Z2-axis: 1 µm Measuring force: 30 mN (adjustable via weight setting) Drive speed, X-axis: 80 mm/s Drive speed, Z2-axis: 30 mm/s Measuring speed, X-axis: 0.0220 mm/s Straightness, X-axis: 0.8 µm/100 mm Tilt angle, X-axis: 45° Accuracy (20°C), X-axis: (0.8 + 0.01L) µm Accuracy (20°C), Z1-axis: (1.4 + |2H|/100) µm MACHINE DETAILS Operating temperature range: 15 to 25 °C Operating humidity range: 20 to 80 % RH (condensation-free) Storage temperature range: -10 to 50 °C Storage humidity range: 5 to 90 % RH (condensation-free) Gbjdpfszkvqdex Aaysp Dimensions & Weight External dimensions, main unit (W x D x H): 756 x 482 x 1,166 mm External dimensions, control unit (W x D x H): 221 x 344 x 490 mm External dimensions, remote control box (W x D x H): 248 x 102 x 262.2 mm Weight, main unit: 150 kg Weight, control unit: 14 kg Weight, remote control box: 0.9 kg EQUIPMENT Single-sided tapered probe (standard accessory)
