Used Wenzel Horizontal Alarm Coordinate Measuring Machine for sale (69,159)

Year of construction: 2002, condition: excellent (used), 3D coordinate measuring machine in a stand-alone design *Floor installation on steel legs *Height from floor to measuring plate: 650 mm Measuring range X 2,100, Y 1,600, Z 2,100 [mm] Measuring uncertainty 25 + L/70, max. 50 [µm] at L = 3,000 mm Dynamics 3D traversing speed 220 mm/sec 3D acceleration 1000 mm/sec² Probing system Renishaw PH10M Renishaw TP20 + 2 modules Control system Pantec Eagle Pro / WPC2040 Joystick Dcjdpfx Ashlqapjnqei HT400 Software POLYWORKS Inspector (alternative available) Optional technologies Probe changing rack MCR20 Supplier's services Transport, commissioning, calibration, final acceptance Warranty 12 months, from the date of acceptance

Year of construction: 2004, condition: excellent (used), 3D coordinate measuring machine in a stand-alone design *Floor-mounted installation on steel feet *Height from floor to measuring plate: 600 mm Measuring range *X 3,200, Y 1,600, Z 1,800 [mm] Measurement uncertainty *30 + L/40, max. 60 [µm] at L = 3,000 mm Dynamics *3D traversing speed: 220 mm/sec *3D acceleration: 1000 mm/sec² Probing system Dcedpohlqknefx Anqsi *Renishaw PHS / alternatively PH10M *Renishaw TP20+2 modules Control system *Pantec Eagle Pro Wireless control unit *Handheld control unit HT400 Software POLYWORKS Inspector Optional technologies Probe changer MCR20 Probe changer ACR3 Optical scanner KREON or NIKON Supplier’s services Transport, commissioning, calibration, final acceptance Warranty 12 months, from the date of acceptance

Condition: used, Year of construction: 2003, Coordinate Measuring Machine Wenzel LH 54 (Year of Manufacture 2003) in well-maintained and fully functional condition. The machine is built on a stable granite structure combined with air-bearing guides. This allows the portal and axes to move almost frictionlessly and smoothly over the granite—a proven foundation for high measurement accuracy and repeatability. The LH 54 is designed for reliable use in quality assurance as well as in series production and delivers consistent measurement results even during continuous operation. Before delivery, the machine is inspected and test-run by our service technicians in Remscheid, ensuring full functionality. The system is currently powered on and can be viewed and demonstrated at any time. PC System (modernized): After purchase, a completely new PC system will be installed, meeting WENZEL’s current requirements. This system is fully up to date and thoroughly tested before the machine is finally handed over to the buyer. Optional Services (upon agreement): - Installation and commissioning of the measuring machine within NRW - Issuance of a factory calibration certificate - Determination of length measurement uncertainty - Determination of probing uncertainty - Determination of repeatability range - Execution in accordance with DIN EN ISO 10360-2:2010-06 - Maximum measuring volume diagonal: 4,660 mm - Determination of probing uncertainty according to DIN EN ISO 10360-5:2020-11 - Including full documentation - DAkkS calibration by the accredited Klostermann calibration laboratory - Accreditation number: D-K-17518-01-00 - Accredited according to DIN EN ISO/IEC 17025:2018 - Training for the WM | Quartis measuring software - Custom programming for your components Additional Information: On request, the machine can be retrofitted with the proven Renishaw SP25M probe. The retrofit includes additional service work and complementary hardware components, which will adjust the purchase price accordingly. Additional software modules, custom adaptations, as well as individual accessories and clamping systems are available on request—optimally tailored to your specific measurement requirements. Measuring range X: 500 mm Measuring range Y: 1.000 mm Measuring range Z: 400 mm Measurement uncertainty: Eo = 2,5 + L/300 [μm] Installed software: WM | Quartis R2026-1 Controller: WPC2040 Basic PC System: Windows 11 (current configuration) Dcsdpfjy Dcivsx Anqoi Probing system: TP20 Probe head: PH10T Probe module: 1 × TP20 Standard Force Module head interface: PHC10-3 PLUS Probe interface: PI200 (Combi) Joystick: HT400 Exchange bridge: MCR20 (empty) Accessories: Stylus kit M2 | Mouse & keyboard | 2 × 24" TFT monitors | Printer Included services: Final inspection upon purchase | Disassembly and transport preparation | Packing | Loading onto customer-provided truck Included transport frame: On loan

Condition: excellent (used), Year of construction: 1988, functionality: fully functional, total height: 2,600 mm, total width: 1,230 mm, total length: 2,030 mm, input voltage: 230 V, table width: 1,230 mm, table height: 940 mm, table length: 2,030 mm, year of last overhaul: 2017, Manual coordinate measuring machine: Wenzel LS1588 – fully operational and in good condition, including rotary table. In 2018, the original electronics were upgraded to duwe3D electronics. Table without PC is included in the offer. Most recently used with Polyworks (not included). Dsdpfxew R N S Ne Anqeci

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 06010056, total height: 1,620 mm, total width: 910 mm, total length: 980 mm, A coordinate measuring machine manufactured by Tesa, model: Micro-hite 3D, will be auctioned. Djdozhmq Nspfx Anqoci MACHINE DETAILS Overall length: 980 mm Overall width: 910 mm Overall height: 1,620 mm Installation date: March 24, 2006

Condition: used, Year of construction: 2004, functionality: fully functional, machine/vehicle number: 0007306, measuring range X-axis: 700 mm, measuring range Y-axis: 1,000 mm, measuring range Z-axis: 600 mm, CRYSTA PLUS M 7106 Manual Coordinate Measuring Machine Dsdpfx Aezkakbenqjci 1. 1 piece 8,500.00 8,500.00 Measuring range: X=700 Y=1000 Z=600 Length deviation of measurement: E=(4.5+0.45L/100) * High accuracy * Unlimited micro-feed capability for traversing (point acquisition) * Self-adjusting air bearings * Quiet operation with minimum air consumption * Granite measuring table * Precision glass scales * Software for MS-Windows NT/2000/XP/WIN 7 * Upgrade from MCOSMOS Manual V2 to V4 * Computer - personal computer * LED monitor DELL 24" * Ceramic calibration sphere for SMS - diameter 20mm

Condition: good (used), Year of construction: 2007, Machine is in good condition. Parts shown by hand not come. X 500 mm x Y 700 mm x Z 500 mm. Dcsdpfx Aszi D Egonqji

Condition: used, Nikon Model: VMZ-R3020 XYZ travel distances: 300 x 200 x 200 mm *Type TZ with low magnification objective: 250 x 200 x 200 mm Display resolution 0.01 μm Maximum permissible deviation (MPE) EUX, MPE EUY, MPE 1.2 + 4L / 1000 µm EUXY, MPE 2.0 + 4L / 1000 µm EUZ, MPE 1.2 + 5L / 1000 µm Djdpfx Ansyiy Hbjqsci Maximum sample weight 20 kg (Guaranteed accuracy: 5 kg) Camera Monochrome / Color 1/3 CMOS camera Working distance Type 1, 2, and 3: 50 mm Type 4: 30 mm Type TZ: (High magnification) 11 mm / (Low magnification) 32 mm Type A: 73.5 mm (63 mm with laser AF) Laser AF repeatability range 1),3) 2σ ≦ 0.5 µm Illumination Type 1, 2, 3, and 4: Episcopic, transmitted and 8-segment ring illumination with 3 incidence angles *white LED / Type 4 has only 1 angle Type TZ: Left objective: Episcopic, darkfield; right objective lens: episcopic, transmitted light, darkfield Type A: Episcopic, transmitted and 8-segment ring illumination with 1 incidence angle *white LED Power supply, power consumption AC100V-240V, 50/60 Hz / 4A – 2A Dimensions & weight Main unit with table (W x D x H): 700 x 730 x 1793 mm / approx. 265 kg Controller: 190 x 450 x 450 mm / approx. 12 kg Installation footprint (W x D)4): 2700 x 2400 mm Condition: used Scope of delivery: (see picture) (Subject to technical modifications and errors. All information is non-binding!) We are happy to answer further questions for you by phone.

Condition: excellent (used), Year of construction: 2021, Renishaw Type: Equator 500 Year of manufacture: 2021 Item description: For sale is a Renishaw Equator™ 500, a high-precision industrial 3D measuring and inspection system designed for series production and process control on the shop floor. The Equator 500 is not a traditional coordinate measuring machine (CMM), but a comparative measurement system developed specifically for fast, repeatable measurements directly in the production environment. It is ideal for mass production, in-process measurements, and automated inspection routines. The unit is perfectly suited for checking dimensional accuracy, geometric tolerances, and position tolerances of workpieces, and can provide feedback to CNC machines. The software loads correctly, system status as per display: "Started OK" (see photos). Features & Application Areas: - 3D measurement of workpieces - Comparative measurement principle (very fast inspection cycles) - High repeatability in the micrometer range - Real-time temperature compensation - Suitable for shopfloor use - Automation ready (e.g. robot loading) - Ideal for series production, spot-checks, and process control Dcodpfxezix Nmo Anqoi Typical Industries: - CNC manufacturing - Metalworking - Automotive / supplier industry - Mechanical and tool engineering Technical Data (manufacturer information / approximate values) Manufacturer: Renishaw Model: Equator™ 500 (H+150) Device type: Comparative 3D measuring system / CMM Measuring range: X / Y: approx. Ø 500 mm Z: approx. 150 mm Measurement principle: Comparative coordinate measurement technology Temperature-compensated measurement Accuracy: Very high repeat accuracy Measurement accuracy in the micrometer range (depending on application and strategy) Control & Software Controller type: Equator 500 Software version: 2.5.21.1 RRTLOS version: 5.1.12 Operation via PC-based Renishaw software Electrical Data: Supply voltage: 230 V AC Frequency: 50 / 60 Hz Power requirement: approx. 1 kW Dimensions (approx.) Total height: approx. 1,900 mm Footprint / diameter: approx. 1,200 mm Weight (approx.): 130 kg Condition: used Scope of delivery: (see photos) - Renishaw Equator™ 500 measuring system - Controller / industrial PC - Monitor - Keyboard and mouse - Base frame - Accessories as shown in the photos (Subject to technical modifications and errors. All data provided without liability!) For further questions, we are happy to assist you over the phone.

Condition: used, For sale is a high-quality 3D CNC coordinate measuring machine from the renowned manufacturer Werth Messtechnik – model Scope-Check 650×750×500/MB/Z. This device stands out for its precision, reliability, and versatility in industrial metrology. Features & Equipment: - CNC-controlled 3D coordinate measuring machine - Multi-sensor capable (optical and tactile measurements possible) - Moving-bridge design (MB/Z) for high stability and flexibility - High precision measurement of complex workpieces - Robust construction, designed for continuous industrial use - Suitable for quality control, production monitoring, and R&D applications Additional Equipment – Renishaw TP200 Probe System: The high-precision, touch-trigger Renishaw TP200 probe is ideal for workpieces with tight tolerances and complex geometries. It allows for quick probe change-outs and precise measurements even with long probe styli. Key Features: - Strain gauge technology: Minimizes deflections are registered with high accuracy; typical errors such as “lobing” are avoided - High precision: Repeatability up to 0.4 μm, 2D probing uncertainty ±0.8 μm - Fast changeover: Automatic probe change with SCR200 rack, no recalibration required - Durability: Probe module lifetime exceeds 10 million triggerings - Flexibility: Standard- (SF) and low-force (LF) modules for sensitive materials - Compatibility: Usable with Renishaw PH10 probe heads and extensions up to 300 mm Technical Specifications (excerpt): - Connection: M8 connector, PI200 interface - Probing directions: 6-way (+X, -X, +Y, -Y, +Z, -Z) - Probing force XY: 0.02 N, Z: 0.07 N - Overtravel force XY: up to 0.4 N, Z: up to 4.9 N - Weight (sensor + module): 22 g - Stylus threads: M2 Technical Data: - Manufacturer: Werth Messtechnik - Model: Scope-Check 650×750×500/MB/Z - Measuring range: X = 650 mm, Y = 750 mm, Z = 500 mm - Supply voltage: 115–230 V AC - Power consumption: max. 10 A Scope of Supply: - Werth Scope-Check 650×750×500/MB/Z - Renishaw TP200 probe system including probe modules - Accessories as shown in the attached images Important note: "The table shown in the photos is not included in the sale." (Specifications and technical details subject to change and errors!) We are happy to answer further questions by phone. Dcsdpfjzii Dzex Anqji

Condition: excellent (used), Year of construction: 2020, Keyence KEYENCE XM-2000 with XM-H1000 – 3D Coordinate Measuring System (CMM) Professional handheld measurement system for precise 3D measurements directly in production environments. Item description: For sale is a used KEYENCE XM-2000 coordinate measuring system including the XM-H1000 handheld probe. This innovative system enables precise 3D measurements directly at the workplace – without a dedicated measuring room, complex setup, or special CMM expertise. The device is ideally suited for manufacturing operations, quality assurance, initial sample inspection reports (ISIR/PPAP), in-process controls, as well as for reverse engineering. Technical Data – KEYENCE XM-C1000 / XM-H1000 (XM Series) Measuring System (General) Specification: Measurement range (XYZ): approx. 600 × 300 × 200 mm (depending on setup) Measurement accuracy: ±(8 + L/80) µm (L = measured length in mm) Repeatability: ±3 µm (typical) Resolution: 1 µm Measuring principle: Optical tracking with camera-based detection Calibration: User calibration with calibration sphere possible CAD Comparison: Directly on the device (STEP, IGES, etc.) Export formats: PDF, Excel, CSV, DXF Tolerance analysis: Automatic with color mapping XM-C1000 – Control and Evaluation Unit (Controller) Component: Display: 15” touchscreen Connections: USB, LAN, HDMI, power Storage options: Internal + USB export Software functions: Measurement, CAD comparison, report generation Operation: Touchscreen + pushbutton operation Languages: Multilingual (including German) XM-H1000 – Handheld Probe Specification: Probe type: Handheld with pressure button Feedback: LED status indicator, vibration signal Probe tip: Interchangeable, various tips available Tracking: Detected via controller’s camera system System Characteristics Specification: Operating temperature: 10 – 35 °C Power supply: 100–240 V AC, 50/60 Hz System dimensions (complete): approx. 800 × 600 × 800 mm (depending on setup) Total system weight: approx. 25–40 kg (depending on configuration) Mounting: On table or optional measuring table Scope of delivery: KEYENCE XM-2000 control and evaluation unit KEYENCE XM-H1000 handheld probe XM-C1000 (Controller) Camera unit / tracking module Connection cables and power supplies Dcodpfxezii Dnj Anqji Condition: Used, fully functional, in very good condition. Shipping & Delivery: Shipping via freight forwarding Collection by appointment possible. International shipping available on request. If you have any questions, need further information or wish to arrange a viewing appointment, please feel free to contact us. (Subject to changes and errors in the technical data and information!) We are also happy to answer any further questions by phone.

Condition: excellent (used), Zeiss Coordinate Measuring Machine Model: O-INSPECT 442 Machine Designation: Coordinate Measuring Machine Machine Type: O-INSPECT 442 The multisensor measuring machine O-INSPECT ZEISS enables optimal optical or contact measurement of all features. The CALYPSO software simultaneously displays the actual state, nominal profile, and deviations, making measurement results easy to identify and interpret. General Data: Dimensions: Width 1055 mm, Length 1351 mm, Height 1770 mm Measuring range: X 400 mm, Y 400 mm, Z 200 mm Weight: CMM 800 kg Workpiece, max. 20 kg CMM noise level < 70 dBA Electrical Data: Supply voltage: 100, 110, 120, 125, 230, 240 V~ (± 10 %) Current type: 1 / N / PE Frequency: 50 to 60 Hz (± 3.5 %) Power consumption: max. 1500 VA Fuses: At 230 V or 240 V: 16 A At 100 V or 125 V: 15 A Travel Speeds: Creep speed, SLOW function: 0 to 5 mm/s Setup mode: 0 to 70 mm/s Automatic measurement: Axis (X, Y) max. 200 mm/s Axis (Z) max. 50 mm/s Axis (3D) max. 287 mm/s Ambient Conditions: The following conditions must be met for proper operation of the measuring machine. Operating ambient temperature: +17°C to +35°C Relative humidity: 40% to 70% (non-condensing) Room temperature for measurement: 20°C ±1 K Altitude above sea level: 100–125 V: max. 3000 m 230–240 V: max. 2000 m Probe System: Probe System: CFS Probe Types Data: Probe Type: CFS 2 mm Measuring range: 2 mm, Working distance: 61 mm, Spot diameter: 12.5 µm Measurable surface angle to beam direction: 90 ± 15° Measuring range: 3 mm, Working distance: 22.5 mm, Spot diameter: 12 µm Measurable surface angle to beam direction: 90 ± 30° Measuring range: 10 mm, Working distance: 70 mm, Spot diameter: 24 µm Measurable surface angle to beam direction: 90 ± 20° The values for surface angles are limit values and depend on the reflectivity of the workpiece surface. Rotary Table: Dcodpfx Aszii Dhjnqoi Mass and resolution Table weight: 7 kg Resolution: 0.15’’ Dynamics: Angular speed max: 50°/s Rotational speed: 8.3 min⁻¹ Scope of Delivery: In the standard version, the O-INSPECT coordinate measuring machine is supplied with the following components: - Coordinate measuring machine (CMM) - Controller (integrated) - Control panel - PC with peripherals - Software - CALYPSO 5.2 - Documentation - Probe system - Reference stylus - Calibration artifact - Calibration template Scope of delivery: (Zeiss coordinate measuring machine as shown) Condition: used (Specifications subject to change and errors excepted!) Please inquire about transport options prior to purchase. If you have further questions, we are happy to assist you by phone.

Condition: as good as new (ex-display), Year of construction: 2017, Measuring Range Dedpfxjr Elmpo Anqeci XY – axis Ø350mm Z – axis 200 mm Accuracy acc. ISO 10360 E = [2,9 + 4L/1000]µm incl.: - Renishaw TP20 - Renishaw MCR20 probe changer (+1 additional module) - Aberlink 3D software On Demand: Aberlink CAD offline programming/ CAD compare Installation and training (2 days) fee € 5.000,-- excl. travel costs Machine is only for rent € 1.000,-- incl yearly service excl. travel costs

Condition: used, Werth Type: Werth SCOPE-CHECK 400 3D coordinate measuring machine Technical data: Measuring capacity (X x Y x Z): 400 x 200 x 200 [mm] Work table with integrated electrical cabinet: 1600 x 950 x 780 [mm] Max. weight on table: 20 [kg] Operating conditions: * Relative humidity: 40 - 70 [%] * Temperature: 10 - 40 [°C] Measuring accuracy (20°C, 8 kg, magnification 5X, resolution 0.5 microns) On table: E1 = 1.8 + L/120; E2 = 2.0 + L/150 Dcsdszh Dq Hopfx Anqei All positions: E1 = 2.5 + L/120; E2 = 2.9 + L/100; E3 = 4.5 + L/75 Incremental scales Ball screw drive with servo motor Optical magnification (video): 0.5X to 5X Optical field (video): 13 x 10 [mm] to 1.3 x 1 [mm] Movement on linear guide with ball bearing Combinable lighting: diascopic, episcopic, ring-shaped LED/axial Voltage: 230 [V] Frequency: 50 [Hz] Power: 2 [kW] Weight: 300 [kg] Accessories CN Lighting control via software Video sensor IP for detection of measuring contour (screen display) Electronic control for table movement Manual control for table via joystick Predisposition for mechanical probe Calibration, 3D measurement, probe communication software Scope of delivery: (Werth coordinate measuring machine with accessories as shown) Condition: used (Changes and errors in the technical data and specifications are reserved!) Please inquire about transport options before purchasing. We will gladly answer any further questions you may have by telephone.

Condition: refurbished (used), Year of construction: 2004, Complete refurbished Sheffield D12 with very new controller; probe, software etc. (2017) - 3D measuring machine with liner guideways (no air necessary) - Machine is moveable (wheels) - Measuring range X / Y / Z = 500 x 900 x 400mm - Accuracy acc. to ISO 10.360 MPE = 4,9 + 4L/1000µm - Pantec Eagle Controller - Temperature control on demand (new) - Renishaw PH1, on demand PH10T (used or new) - Renishaw TP20 (used or new) - Renishaw MCR200 probe change rack (on demand) - Software Inspect3D Inca Professional (new + options) - Computer HP Workstation W10 (like new) Dcjdofmkxiopfx Anqji Machine is ready for demonstration

Condition: excellent (used), Year of construction: 2008, machine/vehicle number: 196-477 NL, measuring range X-axis: 500 mm, measuring range Y-axis: 700 mm, measuring range Z-axis: 400 mm, Machine in excellent condition from a measuring room Djdjyxxphspfx Anqeci

Condition: like new (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: 201502530269, measuring range X-axis: 700 mm, measuring range Y-axis: 700 mm, measuring range Z-axis: 600 mm, table load: 560 kg, Equipment: documentation/manual, type plate available, ZEISS CONTURA G2 7/7/6 – VAST XXT TL1 Year of Manufacture: 2015 | Commissioned: 2016 | Immaculate Condition | Extremely Low Operating Hours We are offering for sale a ZEISS Contura G2 coordinate measuring machine (CMM) with a measuring range of 700 × 700 × 600 mm, equipped with a VAST XXT TL1 scanning probe head. The device comes from a controlled laboratory environment and was used exclusively on-demand, single-shift operation, never on a production line – resulting in exceptionally low actual usage and outstanding technical condition. 🔹 Basic Information Manufacturer: ZEISS Model: Contura G2 Measuring Range (X/Y/Z): 700 / 700 / 600 mm Dcedoyzmbdspfx Anqei Year of Manufacture: 2015 Commissioned: 2016 Technical and Visual Condition: Perfect Measurement Error MPE (E0) = 1.7+L / 350 μm 🔹 Configuration and Accessories ✅ ZEISS VAST XXT TL1 active scanning probe head ✅ Stylus rack / magazine ✅ Set of measuring styli (mainly diameters ⌀ 0.6 mm and ⌀ 1.5 mm) ✅ Reference sphere ✅ BP26_SE control console 🔹 Usage History Device used exclusively in laboratory conditions Occasional, project-based (on-demand) use Single-shift operation, no serial or production work As a result, the machine exhibits extremely minimal mechanical wear 🔹 Service and Calibration ✅ Service and calibration exclusively by official ZEISS technicians ✅ Regular maintenance according to manufacturer guidelines ✅ No third-party interventions ✅ Device fully operational 🔹 Status 📍 Machine available immediately 🔍 Viewing possible 📄 Full documentation included ✅ Buyer arranges transport

Condition: not inspected (used), functionality: fully functional, Súradnicový merací prístroj SIP 30 M Presnosť merania +/- 0,001 Dedpfxezh A Uds Anqeci Coordinate measuring machine SIP 30 M Measurement accuracy +/- 0.001

Condition: used, Year of construction: 2016, functionality: fully functional, machine/vehicle number: 60766, API Radian R20 Laser Tracker – a professional 3D measurement system For sale is a professional 3D laser tracking and measurement system, the API Radian R20, used in industry, quality control, automation, robotics, and industrial metrology. Dodpfx Anozila Seqoci The device is fully functional, ready for use, and comes from the equipment of a research and development company. The tracker was used in industrial conditions as intended. Technical data: Manufacturer: API – Automated Precision Inc. Model: Radian R20 Serial number: 60766 Year of manufacture: 2016 Measurement range: 20 m Technology: Laser Tracker 3D The set includes: API Radian R20 Laser Tracker controller / control unit SMR reflector tripod tracker transport case accessory transport cases cables and accessories as shown in the photos Technical condition: The device comes from the equipment of a research and development laboratory. The technical and visual condition corresponds to the product photos. Before sale, the equipment undergoes technical verification. Commercial information: The product is covered by a start-up warranty. If you have any questions or need additional information, please send a message or contact us by phone.

Condition: good (used), Hexagon Type: Hexagon Optiv Performance 442 Product description: The 3D multi-sensor coordinate measuring machine Optiv Performance 442 combines optical and tactile measurements in a single system. The system supports multi-sensor measurements with a vision sensor, tactile sensor, TTL laser (Through-The-Lens), and the innovative Chromatic White Light Sensor (cws). The base unit with a vision sensor can be modularly expanded with all available sensors. Application areas: • Use on a level surface • Versatile geometric measurements and GD&T analyses with standard construction accuracy • Design principle: » Low-vibration granite construction with a fixed bridge and movable table » Integrated substructure with optional vibration dampers • Guides: » Precise mechanical linear guides in all axes • Drives: » DC servo motors, power transmission via backlash-free ball screws at the center of gravity • Length measuring system: » Incremental length measuring system • Resolution: 0.1 pm Dcsdozgr R Eopfx Anqji Hexagon Optiv 442 multi-sensor measuring machine equipped with a camera, laser, and Renishaw probe system. • Measuring range per sensor: 410x410x200mm • Dimensions: 1232x910x1663mm • Weight: approx. 940kg • Max. load capacity: Glass plate 30kg • Accuracy: U1=1.9 + L/200; U2=2.4 + L/150; U3=2.9 + L/100 (L = measuring length in mm) • Max. travel speed per axis: 200mm/s • Camera with 2-stage zoom • Laser • LED ring light • Renishaw 6-position probe changer • Renishaw TP200 probe system • Monitor operation • Windows 7 Ultimate evaluation station • Measuring machine HEXAGON Optiv 442 Electrical connection values: Voltage 115/230 V ± 10% Mains frequency 50/60 Hz ± 5% Power consumption 1000 VA Weight: approx. 1100 kg Condition: used Scope of supply: (See image) (Changes and errors in the technical data are subject to change!) We will be happy to answer any further questions you may have by telephone.

Year of construction: 2012, condition: excellent (used), Coord3 Hera coordinate measuring machine in top condition Measuring Ranges X – axis 900 mm Y – axis 2000 mm Z – axis 800 mm Accuracy acc. ISO 10360 E = [2,5 + 4L/1000]µm Pantec Eagle Pro Probe system Renishaw PH10MQ+SP25M Probe changer Renishaw FCR25 Dcedslmlhwepfx Anqoi Inspect3D Inca V7 (latest Version) Computer Hewlett Packard (Windows 11 Pro) Dual Monitor On demand with old PC (W7) and old Arco CAD license (minus € 5.000,--)

Condition: used, Year of construction: 2000, table length 1160 mm table width 710 mm daylight 650 mm Control WENZEL ME 5007 total power requirement kW Dedpfx Anjt Hw S Ieqoci weight of the machine ca. 800 kg dimensions of the machine ca. m 3-D-coordinate measuring machine with METROLOG II-Software

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, measuring range X-axis: 505 mm, measuring range Y-axis: 405 mm, measuring range Z-axis: 405 mm, Mitutoyo Crysta Apex C544 year of manufacture: 2006 x, y, z: 505 x 405 x 405 mm manual storage for measuring probes clamping plate calibration sphere 5 x measuring probes Renishaw TP 200 PH 6M probe incl. computer, software, dongle, and documentation Dcodpsy R A Apsfx Anqsi machine is powered up for inspection

Condition: used, Year of construction: 2019, functionality: fully functional, machine/vehicle number: 199102, WENZEL LH 108 CNC Coordinate Measuring Machine Manufacturer: WENZEL Type: LH 108 Dodpfx Aney Tnyfjqjci Design: CNC 3D coordinate measuring machine (bridge design) For sale is a precise and powerful WENZEL LH 108 coordinate measuring machine. This machine is ideally suited for quality assurance, production metrology, and demanding measuring tasks in tool and mold making. The LH 108 impresses with its stable granite construction, air-bearing axes, and high measuring accuracy. Thanks to CNC control, both single and series measurements can be carried out efficiently. Technical Data Measuring range: approx. X 1000 / Y 1600 / Z 800 mm Max. workpiece weight: up to approx. 2000 kg High measuring accuracy in the µm range Equipment Air bearings in all axes Granite guides for maximum stability Modern CNC control with joystick operation Various probe systems (depending on the model) Temperature compensation (model-dependent) Application areas Quality assurance and incoming goods inspection Series and single-part measurement Freeform surfaces and complex components Reverse engineering Other Machine in used condition. Inspection possible by arrangement.

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, 3D Coordinate Measuring Machine | Brand: MAUSER/ZEISS | Type: KMZ-G 602520 | Year of manufacture: 1988/2003 Optionally available with an air-conditioned hall. The machine has been calibrated regularly by ZEISS. The last calibration was performed on August 7, 2025, the next calibration (recommended) is scheduled for August 2026. TECHNICAL SPECIFICATIONS:: Measuring ranges (Length x Width x Height): 6.000 x 2.500 x 2.000 mm Travels: - X-axis: 6.000 mm - Y-axis: 2.500 mm - Z-axis: 2.000 mm - Length measurement uncertainty according to VDI/VDE 2617: U3 = (5,0 + L/250)µm, V2 = 3,5 µm - Length measurement uncertainty according to ISO 10360-2: MPE_E = (5,0 + L/250)µm - Environmental conditions for maintaining the specified accuracy: * Temperature range: 21°C +/- 3°K * Temperature fluctuation: 0,5°K/h, 1,0°K/d, 0,5°K/m - Environmental conditions for operation: * Temperature range: + 15°C up to 35°C * Humidity: 30 up to 70% General features, Equipment: - Portal measuring machine with ultra-precision guides Dcjdpsy Iub Sjfx Anqsi and ball-screw drives - Second Y-axis with granite guideway and air bearing - High-resolution Zeiss scales - Positive-drive mechanisms in all three axes - Collision protection for the quill and probe head (for VAST-TK) for manual and setup modes - Safety position for crane interlock - Reference temperature compensation - Microcomputer control - Practice piece: cube, star-shaped stylus - Reference probe D = 8 mm, length: 115 mm - Reference standard D = 30 mm - includes basic software package - Load-bearing capacity: Limited only by the foundation design - Measuring system: VAST - Software: Zeiss CALYPSO - Documentation Without guarantee of completeness and correctness of the technical information and the equipment. - Subject to prior sale -
