Used Boring Head for sale (13,573)

Condition: used, Vertical milling head, milling head with motor drive THIEL Tool holder: MK 5 (Morse taper size 5) Quill stroke, spindle travel: 80 mm Spindle speed at motor speed 1410 rpm = 490 / 780 / 1200 rpm. Spindle speed at motor speed 2950 rpm = 970 / 1530 / 2380 rpm. Spindle bore: 37 mm Motor power: 1.4 / 1.8 kW Nsdpfx Asxddwrjdwecl Motor speed: 1410 / 2850 rpm Power connection: 400 Volt, 50 Hz - Spindle speed via 2 motor speeds and 3 belt stages - Mounting flange milling head Ø 215 mm with 2 bores Ø 15 mm, hole spacing 180 mm - suitable for tools with drawbar thread (ejector tang interferes with clamping) Required space L x W x H: 450 x 400 x 350 mm Net weight: 61 kg Good condition

Condition: used, inner taper of milling spindel / collet diameter / turning speed range / U/min Nodpol Ichvjfx Adwocl

Condition: used, inner taper of milling spindel / collet diameter / Ncsdpfx Ajhprk Hjdwel turning speed range / U/min

Condition: used, inner taper of milling spindel / Ncodpfx Ashwt Eljdwsl collet diameter / turning speed range 1500 U/min

Condition: used, Year of construction: 1993, Control Sinumerik 805 turning speeds 45 - 6000 U/min Solid drill diameter / 0 weight of the machine ca. 20 t Type of machine: deep hole drilling machine Model / Type: TB 2 15 30001KT Year of construction: 1993 Manufacturer: hole Machine number: 221-3000-2093 Machine weight: approx. 20,000 kg Machine footprint: Width = approx. 3800mm Length = approx. 13500mm Height = approx. 3100mm Drilling length: approx. 3500mm Drilling capacity: drill 45mm / drill out 80mm Spindle speed range: 45 - 6000 rpm Control: Siemens Sinumerik 805 Hamül – coordinate table Type: KT 8.5 – 10.10 Clamping surface: approx. 1100 mm x 980 mm Travel: Y - axis: approx. 800mm Traverse path X - axis: approx. 500mm 7 pieces clamping - T - grooves: 18 mm Special equipment: 1 piece Fibroplan NC - rotary indexing table Type: NC 1.05 Permissible transport load in horizontal use 2500 kg With manual chuck Forkardt F 630 The NC rotary indexing table can be adjusted manually in the longitudinal and transverse directions relative to the clamping table and is clamped hydraulically. 1 piece chips - centrifuge Type: VZ5A from CEPA Drum capacity: 80 liters Loading weight max. 100 kg Drum - Ø: 600 mm Speed: 1000 rpm Nedpfxjvvx Hij Adwecl 1 additional pump for large drill Ø 1 piece Bosch radial piston pump no.: Suitable for lip drills (internal cooling, chips run outwards) Suitable for BTA drills with screw-on heads (internal cooling, chips run inwards)

Condition: used, Year of construction: 2006, Solid drill diameter / mm bore depth / mm number of spindles / Froriep CNC deep hole drilling machine – the prefabrication specialist Year of manufacture: 2006 Control system: Siemens Sinumerik 840D Max. drilling depth: 8,850 mm Workpiece diameter: 150 – 900 mm Speed range: 1 – 300 rpm Feed rate: 0.5 – 4,500 mm/min Drive power: 129 kW Swing diameter over bed: 1,000 mm Nodpfxjxgu R Io Adwscl Clamping diameter faceplate: 900 mm Weight: approx. 47,000 kg Ideal for precise pre-drilling of deep holes – including faceplate, steering ring

Condition: used, Year of construction: 2006, Solid drill diameter / mm bore depth / mm number of spindles / 2-machine package: Froriep deep hole drilling machine & Irle finishing machine Perfectly matched duo for deep hole drilling and precise finishing of large workpieces A specialised machine package is available for sale – two perfectly matched systems for the complete machining of long, heavy workpieces with the highest demands on precision and efficiency. MACHINE 1 Froriep CNC deep hole drilling machine – the prefabrication specialist Year of manufacture: 2006 Control system: Siemens Sinumerik 840D Max. drilling depth: 8,850 mm Workpiece diameter: 150 – 900 mm Speed range: 1 – 300 rpm Feed rate: 0.5 – 4,500 mm/min Drive power: 129 kW Swing diameter over bed: 1,000 mm Clamping diameter faceplate: 900 mm Njdpfjuddimsx Adwecl Weight: approx. 47,000 kg Ideal for precise pre-drilling of deep holes – including faceplate, steering ring MACHINE 2 Irle machine – high-precision finishing Power: 129 kW Control: Siemens NC control Speed range: 2 – 300 rpm (stepless) Feed: 3 – 4,500 mm/min (in steps) Centre distance: 11,000 mm Swing diameter over bed: 1,250 mm Clamping range of steady rests: 150 – 1,100 mm Workpiece length: up to 11,000 mm Workpiece weight: up to 10 tonnes Max. outer diameter: 850 mm With up to 50,000 Nm torque, perfect for smooth drilling, honing and demanding finishing processes. Your advantages at a glance - Complete solution from a single source – from pre-drilling to finishing - Large workpieces up to 11 metres and 10 tonnes in weight - High process reliability thanks to perfect machine synchronisation - Ready for immediate use, well maintained and from ongoing operation - Ideal for mechanical engineering, energy, oil & gas, hydraulics and large parts manufacturing

Year of construction: 1999, condition: used, table length mm table width mm table load t plate width 2980 mm plate depth 3000 mm plate height 1400 mm Ncodpfxjgxqvzj Adwjl total power requirement 11 kW weight of the machine ca. t required space m

Condition: used, Year of construction: 2004, Solid drill diameter 200 mm bore depth / mm number of spindles / Technical data Power: 129 kW Control: Siemens NC control Speed range (stepless): 2 - 300 rpm Feed range (in steps): 3 - 4500 mm/min Oil system capacity: 20,000 litres Maximum delivery rate: 1500 l/min Circular diameter in steady rest: 1100 mm Circular diameter over bed: 1250 mm Centre distance: 11000 mm Clamping diameter face plate: up to 1100 mm Max. workpiece weight with one tailstock: 10 t Clamping range of the two steady rests: 150 - 1100 mm Clamping range BOZA: 1 = 200 - 400 mm 2 = 400 - 800 mm Dimensions Min. outer diameter: 406 mm Max. outer diameter: 850 mm Wall thickness: 10–150 mm Max. workpiece length: 11,000 mm Max. workpiece weight: 10 t Max. strength: 800 N/mm² Specific cutting resistance (Ks): 2000–2100 N/mm² Machine data Machine length: 28,800 mm Centre height: 560 mm Swing diameter over bed: 1120 mm Full drilling diameter: 200 mm Core drilling diameter: 350 mm Ncjdpfx Adexgic Eewol Reaming diameter without drilling: 350 mm Reaming diameter with drilling: 350 mm Headstock: Main drive motor: Siemens Type: 1 PH 7228 Performance data at 1,000 min: 113 kW / 1,079 Nm Performance data at 1,150 min: 129 kW / 1,017 Nm Main gearbox: Z-F manual gearbox Type: 2 K210 Switchable gear ratios: i = 1:1 i = 1:4 Fixed gear ratio for spindle: i = 11.68 Max. torque: 50,000 Nm Speed range I: 2...300 min Speed range II: 2 ...75 min

Condition: used, x-axis / mm y-axis / mm z-axis / mm The boring mill is sold without clamping plates – the price refers exclusively to the boring mill. Technical data Horizontal milling and drilling machine with support sleeve Working range Vertical adjustment of the headstock from the clamping surface: 0 - 3000 mm Horizontal adjustment of the column: 7000 mm Maximum drilling depth with drill spindle alone: 1200 mm Maximum drilling depth with drill spindle and support sleeve together: 1300 mm Drill spindle diameter: 150 mm Milling spindle diameter: 240 mm Ncsdexdnrajpfx Adwsl Support sleeve diameter: 390 mm Support sleeve extension: 700 mm Drill spindle tool holder: ISO 50 Maximum workpiece weight: 70,000 kg When placed in 4 prisms: 95,000 kg Main drive Total speed range, adjustable from 2 - 795 rpm Series 1 2 - 50.4 rpm Series 2 50.4 - 126 rpm Series 3 126 - 314 rpm Series 4 314 - 795 rpm Maximum drive power at rated speed 17.5 80 kW Quick adjustment speed of spindle box and column 1800 mm/min Rapid adjustment speed of drill spindle and support sleeve 1400 mm/min Fine adjustment speed of spindle box and column medium 75 mm/min Fine 3 mm/min Fine adjustment speed of drill spindle and support sleeve Medium 57.7 mm/min Fine 2.5 mm/min Feed of headstock and column for milling Row 1 3 - 75 mm/min Row 2 72 - 1800 mm/min Feed of drill spindle for drilling Row 1 0.19 - 4.7 mm/min Row 2 2.2 - 56 mm/min Row 3 56 - 1400 mm/min Special equipment Numerical length measuring device in horizontal and vertical directions Accuracy 0.01 mm Rotatable and movable clamping table, Collet & Engelhard, Offenbach Model Tdvmf 1.6 (for technical data, see ‘Clamping table’) Rotatable and movable clamping table from Scharmann, Rheydt Model DAV 1600 Rotatable and movable clamping table from Froriep, Rheydt Swivel crane for tool change, maximum load capacity 500 kg Special tools Carbide core drill bits for extracting core samples Universal facing and boring head from Wohlhaupter, Frickenhausen Model UPA7, with the following specifications: 1 division of the fine adjustment 0.01 mm in diameter 1 revolution of the fine adjustment 0.5 mm in diameter Facing and boring range 0 - 1250 mm Maximum slide adjustment 210 mm Automatic slide feed in mm/rev during facing 0.05 - 0.10 - 0.15 - 0.20 - 0.25 - 0.30 - 0.35 - 0.40 - 0.45 - 0.50 - 0.55 - Quick adjustment per revolution of the quick adjustment spindle 6 mm in diameter Largest diameter of the slide at zero position corresponds to the smallest drilling diameter of 323 mm Head height without shaft 260 mm

Condition: as good as new (ex-display), Year of construction: 2026, TOS Varnsdorf WH 10 CNC Heidenhain TNC620 / Sinumerik ONE, CE-certification Work spindle diameter 100 / 105 mm Clamping taper ISO 50 Tool shank 69871 DIN Clamping adapter - screw TOS 4100793 Main motor power (S1/S6-40%) 22/34 kW Max. spindle speed 2500 / 3000 rev/min Max. torque of the spindle (S1/S6-40%) 2173/3250 Nm Table transverse travel X 1250 / 1800 mm Headstock vertical travel Y 1100 / 1250 mm Table longitudinal travel Z 1000 mm / 1250 mm Spindle stroke W 630 mm Table clamping surface 1000x1100 / 1200x1400 mm Workpiece weight max. 3,000 / 4000 kg Feed range 4 – 6000 mm/min Total power consumption 50 kVA Machine weight 13 000 kg Features mechanical side - hardened guide surfaces on all axes - Biplast-V lining for the guide ways counter surfaces - Geometric accuracy according to the accuracy protocol TOS Varnsdorf WH 10 - Sliding working spindle with diameter of 100 mm, spindle bearings - FAG, SKF - hydraulic tool clamping set 22kN - Ott-Jakob - Headstock with cooling circuit - Ball screws on the X, Y, Z and W axes - KSK Kurim - Rim and pinion for precise rotary table positioning - Hydraulic system (unit, pumps, hoses, fittings) - Rotary table reinforcement controlled by CNC system - Central lubrication system controlled by CNC system - Tribotec - Telescopic covers (X and Z axes) Nedpjpdrzzsfx Adwscl Features electrical side - CNC control system iTNC 620 Heidenhain Gen3 + Heidenhain Options nr. 8, 19 and 20 - Servo-motors Siemens 1FKZ 100…(5 pcs.) - Spindle motor 1PH8135... - 22kW - Converter Heidenhain UM114D - Linear scales Heidenhain for X, Y and Z axes - Encoder Heidenhain ROD 480 for rotary table - Encoder Heidenhain TTR ERM for spindle - Oriental stop - Control cabinet from Ritall with cooling unit - Wiring and modern electrical components - End-limit switches Balluff - Rotational control panel - Workplace lighting Other - Electrical inspection report, technical documentation - Certificate of geometric accuracy WH 10 Tos Varnsdorf - spindle ball-bar test protocol, linear scales accuracy protocol - cooling of work space placed on spindle forehead (tank, pump, hoses) - working spindle support with brass bushings SP200 Tos Varnsdorf - Heidenhain HR510 handwheel - Heidenhain Linear scales upgrade to LC115 series for X, Y and Z axis Options - Through spindle coolant - CE certificate for the machine - Safety fence and operator cabin with sliding door, - Automatic tool changer TOS Varnsdorf AVN 40 - Heidenhain TS 460 radio touch probe + receiver - Dismantling of the machine, packaging and loading - Machine installation - Extension of the 12-month warranty by a further of 12 months

Condition: used, We have different type of Pump-Heads as well. Operating Temperature: 0° to 40°C (32° to 104°F) Storage Temperature: −45° to 65°C (−49° to 149°F) Chemical Resistance: ABS plastic case with polyester label; gold, iridite-coated aluminum chassis; zinc-plated screws. All materials withstand standard cleaning solvents Line Voltage Limits: 230 V, 50–60 Hz Power Output: 0.075 kW (0.1 hp) Maximum Current (230 V units): 1.1 A, shorted output conditions Start/Stop – Local Control Input Voltage: Nsdpfx Adsycgpvowocl Disable 15 V DC (typ) Enable 0.8 V DC max Start/Stop – Local Control Input Current: Disable 100 µA max leakage Enable 15 mA max Maximum Torque (300, 600 rpm units): 13 kg·cm (180 oz-in) Maximum Torque (1100 rpm units): 26 kg·cm (360 oz-in) Speed Regulation – Line: ±1% Speed Regulation – Load: ±2% Speed Drift: ±10% Enclosure Rating: IP23 per IEC529 Humidity (non-condensing): 10% to 90% Altitude: Less than 2000 m Display: Green LED Dimensions (L × W × H): 292 mm × 203 mm × 184 mm (11-1/2 in × 8 in × 7-1/4 in) Weight: 25 kg (55 lb)

Condition: used, No. 3254 Hinge-hole boring machine / hinge-hole drilling machine Hettich Blue Max Mini Used Hinge-hole boring machine / hinge-hole drilling machine Hettich Blue Max Mini together with a hole-line drilling machine Technical data Hettich Blue Max Mini: Drill motor 400 V, 1.1 kW, 2800 rpm Pneumatic feed Technical data hole-line drilling machine: 1.1 kW, 2800 rpm With foot pedal Transport dimensions approx. 1200 x 800 x 900 mm LWH Weight approx. 100 kg Ncedsx T Rzfspfx Adwel Sale on behalf of customer, ex location near 73430 Aalen, without dismantling, without transport and assembly Dismantling, loading and transport by us optionally possible Subject to errors in the description and price To avoid possible misunderstandings, an on-site inspection is possible and recommended by appointment Sold as is Technical specifications, condition description, year of construction and scope of delivery according to manufacturer's brochure or previous owner, without guarantee Subject to prior sale For used machines, any warranty is excluded, the following applies: “sold as seen” Pictures and videos serve as examples and do not represent the actual scope of delivery Terms of payment: Prices plus VAT, payment before collection or shipment Terms of delivery: ex location

Condition: new, Technical data: Number of spindles: 42 (21 + 21) Spindle pitch: 32 mm Total spindle width in head: 640 mm Working table height: 860 mm Working table dimensions: 885 x 349.5 mm Motor: 2 x 1.5 kW/2 HP Motor speed: 2800 rpm Operating pressure: 6/8 bar Air consumption: 10 liters per cycle Extraction nozzle diameter: 80 mm Power supply: 380 V Ncjdpfxsya Dfve Adwel Overall dimensions: Width: 1070 mm Depth: 1035 mm Height: 1505 mm Net weight: 366 kg

Condition: used, Year of construction: 1998, functionality: fully functional, Tabulka 1800 x 1800 mm Průměr vřetena 130 mm Osy X x Y x Z ... 2000 x 2000 x 800 mm Vřeteno 800 ot/min Max. zatížení stolu 12 t Ncedpfx Adswhpv Rewol Strojní dimesniony 6700 x 6000 x 4420 mm Hmotnost stroje 32 000 kg Řídicí systém MEFI 872 Series. Přestavěn v roce 1998.

Condition: reconditioned (used), Year of construction: 2005, NC indexing head Hofmann RWNC 160 Center height: 160 mm With tailstock Nedpfx Adewtfpdjwecl

Condition: used, offer consists of: 1x Hohner 52/8 stitching head suitable for any kind of booklet maker / saddle stitcher Ncedpjxwly Uofx Adwel - weight: 8,7kg We can also organize the following for you: packaging, loading, transport ( by ship or plane) including customs

Condition: used, 2 Hohner Stitching Heads 43/6, used The Hohner stitching heads 43/6 are high-quality stitching heads designed for professional wire saddle stitching of brochures and other printed products. These used stitching heads offer reliable performance and precision in stitching. Special features: - Versatility: Suitable for the production of brochures, booklets, and other printed products requiring stable stitching - Compatibility: Can be used in saddle stitchers from various manufacturers such as Horizon, Duplo, or Bourg - Flexible application: Ideal for processing different paper formats and weights - Easy handling: Quick adaptation to various stitching requirements - Precise stitching: Ensures clean and uniform stitching with high quality - Wire thickness: Compatible with round wire - Robust construction: Designed for industrial use Njdpoxwlxqjfx Adwocl Technical specifications: - Wire: 26-28 - Maximum stitching thickness: Up to 6 mm - Minimum staple distance: 43 - 52 mm - Length of staple crown: 12 mm - Net weight: Approx. 1.5 kg per stitching head

Condition: new, Year of construction: 2026, Vertical Turning center SCR 50 2S Turning Center’s Specifications Nominal Turning Envelope Faceplate Diameter 4.500 mm Machining Diameter Optional 4.700 mm – with the CE Enclosure - 5.300 mm ( without ) Machining Heights 2.100 mm /3500 mm Work Piece Weight 30.000 kg / 50T Nominal Turning Travels X & U - Axis Ram Carriage From -100 mm To 2.600 mm Z and W - Axis Ram 1.250 mm / 1700 mm Faceplate Diameter 4.500 mm/Normal face plate with T-slots Jaw chucks height 200 mm Nedpehh Dnxofx Adwocl Work Table Speed: 0-50rpm Power Continuous S1 96 kW / 2X75kW Torque Continuous S1 130,000 Nm / 320,000Nm Turning main drive mechanism Gear box reducer ZF and belt transmission Z & W - Axis Ram Turning Ram - Left and Right side Ram Size 250 by 250 mm or bigger Tool holder type KM 63 Tool Storage (ATC) No. of Tool storage 2 Tool Storage, left and right sides Stations qty 12 stations per each tool storage Stations type Turning toolholder ATC turning capabilities: Maximum Singular Tool Weight – turning toolholder Maximum tool weight 50 kg Maximum tool size 250 x 150 mm X 700 mm Axes Drives X and U - Axes Ram Carriage Power Continuous S1 6.5 kW Thrust Continuous S1 45,000 N Z-Axis Ram Power Continuous S1 6.5 kW Thrust Continuous S1 45,000 N Axes Rates X, U And Z, W-Axes Feed Rates 0.02 to 6,000 mm/min X, U And Z, W-Axes Rapid Rates 6,000 mm/min Coolant System Coolant Tank Capacity 2,000 L Coolant Pressure / Flow Rate: -external coolant (turning) -internal Filtration unit: -type -accuracy 6 bar at 100 LPM 40 bar at 60 LPM Chips conveyor Conveyor type Hinged (Hardox material) Width The conveyors should have a width of 600 mm CNC Control -type -producer Sienumerik One Siemens / Fanuc oiF

Condition: good (used), Year of construction: 1996, functionality: fully functional, Diameter x width: 750 x 1,500 mm max. operating pressure 300 bar Cutting force 60 kN Weight: approx. 2,800 kg 76 chisel Ncjdpfx Adoqnvtzjwel

Condition: used, Year of construction: 2025, boring spindle diameter 130 mm taper ISO 50-7388/1 milling spindle diameter 200 mm direct current motor 22 kW Ncjdpfx Adjyacn Nowel 10-1600 U/l rapid traverse der Achsen 6000 m/min z-axis 800 mm y-axis 2100 mm x-axis 3000 mm w-axis 1500 mm Size of table plate 1250 x 1500 mm table movement max. 10000 KG kW im Eilgang 3,5

Condition: good (used), Uchida GA-4W Four-Head Paper Drill This machine is in very good condition and ready for operation. Made in Japan. The machine has a number of features that make it easy to use, including: – four drilling heads with independently adjustable positions – a sliding programming bar – spacers for easy setup for drilling holes Technical specifications: Drill diameter: 2-10 mm, Stack height: 50 mm, Head spacing: 65 mm – 330 mm Weight: 370 kg 380V power supply Njdpfx Adsx N I Saowocl Automatic drilling cycle, controlled by a foot pedal. Sturdy construction on a pedestal. Waste discharge is directed outwards. Front and side margins. Includes operating tools. New cutting stick, drill bits, and sharpener.

Condition: good (used), Hohner Exact Double-Head Stitcher Machine in very good condition, ready for production. Two Hohner 52/8 stitching heads Ncodox N I Nlepfx Adwsl Head spacing adjustment. Cycle output: 206 cycles/min Worktable size: 550x280mm 380V power supply Safety guards. Machine complies with CE standards

Condition: good (used), Sicom B163-5 Double-Head Binder Riveter Nodpox N I Etefx Adwecl Manufacturer: Sicom, Italy Very good condition, ready for production. Double head riveting machine to fit two rivets simultaneously on ring-binders, sample books and similar products. Cardboard thickness: 0.5-4 mm Maximum board size: 1000 x 900 mm Weight: 170 kg Pneumatic supply: 6-8 bar Automatic rivet feeding, material piercing, and mechanism crimping.

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, year of last overhaul: 2024, Four Corner Head Welding and CNC Corner Cleaning Line STURTZ SE - HSM 30/26 Compact. The whole line works properly and well. The equipment was operational up to its uninstallation. Nsdpfxjv Uzr Es Adwscl
