NAKAMURA-TOME WY150

NAKAMURA-TOME WY150

Condition: excellent (used), Year of construction: 2018, Sub-spindle, Y-axis, C-axis FANUC 31i B-NT-SmartX control Turning diameter max 225 mm Turning length -656 mm Bsdpfxjvwkirs Amnowp Chuck Diameter -210 mm Main-spindle speeds 4'500 rpm Sub-spindle speeds 6'000 rpm Turret head 1+2: 24 positions with 12 driven positions each Robot for workpiece loading Tool presetting device Misc. accessories MARCELS MASCHINEN CH

Condition: good (used), TECHNICAL DATA AXLE Rapid feed X,Y: 15000 mm/min Rapid feed A,B: 15000 mm/min Rapid feed Z1,Z2,E: 18000 mm/min Rapid feed C: 90000°/min Smallest input unit: 0.001 mm Smallest input unit, C-axis: 0.001° MACHINING PERFORMANCE Max. turning diameter: 20 mm Max. Headstock stroke: 205 mm Max. Drilling capacity: Stationary: 14 mm; Driven: 8 mm Max. Tapping capacity: Stationary: M10 x P1.5; Driven: M6 X P1.0 MAIN SPINDLE Spindle speed: 500 - 10000 rpm Drive: Spindle drive Bjdpfx Amou Uic Tonswp Main spindle motor: 3.7 / 5.5 kW Main spindle bore: 26 mm WHEELING SPINDLE Max. Clamping diameter: 20 mm Max. Part length for ejection to the front: 150 mm Max. Clamping length: 75 mm Spindle speed: 500 - 10000 rpm Pick-up spindle motor: 2.2 / 3.7 kW Indexing angle: 1°, 15° CONFIGURATION Operation mode: Right-handed Dimensions: 2700 x 1400 x 2400 mm Weight: 3400 kg SCOPE OF OFFER U.A: (list not exhaustive) Control system: Fanuc Fire extinguishing system: Siemens Oil mist separator: Donaldson Transformer Hydraulic unit Parts conveyor Chip conveyor Bar feeder: LNS Tool holder Exact scope of supply according to photo gallery We assume no liability for the correctness, completeness and up-to-dateness of the information.

Condition: new, Year of construction: 2023, operating hours: 10 h, MAIN SPINDLE Maximum turning diameter: 20 mm Max. spindle bore diameter: 24 mm Maximum speed [rpm]: 10,000 Maximum power [kW]: 3.7 C-axis with 0.001° Stroke Z1 [mm]: 50mm /160mm Synchronous guide bush unit Guide bush type: 22.001 / T223 Type of collet chuck: 145E / F25 COUNTER SPINDLE Maximum speed [rpm]: 8,000 Maximum power [kW]: 2.2 Maximum pick-up diameter [mm]: 20 max. part length ejection to the front [mm]: 70 C-axis with 0.001° Stroke Z2 [mm]: 215 Type of collet chuck: 145E / F25 TOOLING OPTIONS Tool slide X1,Y1: - Tool holder plate for 6 external turning tools 12 x 12 mm Cross drilling/milling device: - Quantity: 4 driven ER16 modular drilling/milling spindles - Power: [kW]: 1.1 (S6000) - Front drilling unit for 5 drilling quills diameter 25 mm Cross slide counter spindle - Quantity: 2 driven drilling/milling spindles ER16 modular - Power: [kW]: 1.0 (S6000) Back machining 6 driven tools axial ER16 2 driven tools radial ER16 3 turning tool holders 12x12 XD20III 1.0 kW (Fanuc) 1.02 kW (Siemens) TRAVERSING AXES AND CONNECTED LOAD Number of servo axes: 5 Number of spindle axes: 2 Rapid traverse speeds m/min: 32m/min (Z1,Z2,Y,X2) ; 24 m/min (X1) Connected load [KVA]: 15 CONTROL Control type: Fanuc 0i-TF Number of axes: 5 (X1, Z1, Y1, X2, Z2) Simultaneous 4-axis control External control panel with handwheel 10.4" color monitor LCD/MDI Automatic switch-off function PowerOff Program check function (test run possible via handwheel) Continuous thread cutting cycle Runtime display / parts counter CF card interface Tool radius compensation Bwodpfx Amstw Uzvonep Absolute reference point Self-diagnosis function Interface to bar feeder Interface for JBS ACCESSORIES / INCLUDED Alignment shoes with leveling elements Tool box and service tool set Work area light Signal lamp (3-color) Safety door switch with interlock Maintenance and central lubrication unit (1.8 liter lubricating oil volume) Coolant flow monitoring Pneumatic blow-out device for the pick-up spindle gripper Manual and documentation in German and English (maintenance and operating instructions incl. parameter list and test log)

Condition: used, Year of construction: 2016, turning diameter 366 mm turning length 700 mm control Celos Mitsubishi M730U turning diameter over bed 920 mm turning diameter over cross slideways 742 mm max. turning speeds 4.000 min/-1 drive capacity - main spindle 18,5/18,5/15 kW max. rod diameter 80 mm number of tool places 12 Pos. tool taper BMT 80 x-axis 260 mm z-axis 795 mm y-axis +/- 50 mm mm tailstock taper MT5 Number of working hours ca. 20.564 h auto power on hours ca. 28.664 h weight of the machine ca. 4,7 t The machine has been overhauled with the following components: - Ball screws in the X, Y, and Z axes - New main spindle - Complete maintenance package - Recalibrated and recalibrated This puts the machine in like-new technical condition. There are 2 machines available. Price per unit. Technical Features: - 12-position BMT 80 tool turret, max. speed 10,000 rpm, 5.5/5.5/3.7 kW - Y-axis - Overhang for driven tools 100 mm - Scraper-belt chip conveyor - Coolant system with increased pressure of 5 bar Accessories: - Coolant shower on the main spindle chuck - Compressed air blow-off system for tool cutting edges Bedpfx Amoyvvt Ssnswp - Line filter for coolant system - Compressed air blow-off system for tailstock center - Mechanical I/F for 150 mm oil mist separator - 4-color signal light - EtherNET I/P interface for automation Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: ready for operation (used), Year of construction: 2020, spindle speed (max.): 3,400 rpm, number of axes: 4, This 4-axis HAAS ST-30Y horizontal turning machine was manufactured in 2020. It features C+Y-axis capability, a 3,400 rpm A2-6 spindle, and a 12-station BMT65 turret. The machine is equipped with an automatic tool presetter, bent-type chip conveyor, and programmable tailstock. Bwsdpfxjyh Hw Ie Amnep The machine can be inspected under power and test cuts are possible upon request. Contact us for further details. • Running hours: 556 h • C+Y-axis • 3,400 rpm A2-6 spindle • 12-station BMT65 turret • Programmable Tailstock Additional equipment • Bent-Type Chip Conveyor • Oil skimmer • Exhaust system • Automatic Tool Presetter (ATP) • WIFI camera • Remote Jog Handle

Condition: used, TECHNICAL DETAILS - Number of axes : 9 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 16 [mm] - Travel : 205 [mm] - Spindle speeds : 10.000 [rpm] - C axis indexing precision : 0,001 [°] COUNTER-SPINDLE - Max. bar diameter : 16 [mm] - Spindle speeds : 10.000 [rpm] - C axis indexing precision : 1 [°] GUIDE BUSH HOLDER 1 - Number of positions : 10 - Number of motorized positions : 4 - Live tools speed : 8.000 [rpm] Bedpfxjuwd Ryo Amnewp SECONDARY OPERATION - Number of positions : 5 - Number of motorized positions : 3 POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 2.269 x 1.160 [mm] - Machine height : 1.693 [mm] - Machine weight : 1.800 [kg] EQUIPMENT - CNC : Mitsubishi MELDAS - Rotating guide bush - Parts catcher - Ejection of workpiece - Coolant tank - Bar loader : LNS Hydrobar Express 332 - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 20194, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,500 mm, power: 49 kW (66.62 HP), Features Bodpfx Aex S Hgzemnjwp High rigidity for heavy-duty machining Large table for oversized workpieces CNC control with HEIDENHAIN TNC 530 for precision operations Automatic tool changer with 50 positions Centralized lubrication and hydraulic system

Condition: good (used), Year of construction: 2014, Technical data shown on photos. Bwsdpfx Amoufp Svsnep Parts shown by hand not come.

Condition: used, Year of construction: 1992, spindle speed (min.): 7,500 rpm, spindle speed (max.): 24,000 rpm, 4 motorized grinding spindles (liquid-cooled, purge air / oil mist lubrication) including REFU HF frequency converter, e.g. for powering the spindles of a Voumard 400 CNC T4. Grinding spindle GMN TSSV 170-7500 7,500 rpm, 350V, 19.3A, 7.5kW, 250 Hz Grinding spindle Voumard BM15-170 15,000 rpm, 350V, 35A, 18kW, 250 Hz Grinding spindle Voumard BM18-15032 18,000 rpm, 350V, 28.5A, 12kW, 600 Hz Grinding spindle Voumard BM24-150 24,000 rpm, 350V, 27A, 12kW, 800 Hz Bwjdjl Tn Afopfx Amnjp REFU HF Converter 316/25 High-frequency converter (inverter, frequency inverter) Frequency converter / inverter for powering motor spindles GMN tool spindle, motorized grinding spindle The spindles are fully functional, sold as is – manufacturing year approx. 1992 A collection of various grinding spindle shafts / arbors for grinding wheels is available for these spindles and can be purchased separately. Price / details on request All technical data subject to error or omission. We sell exclusively to countries within the European Community.

Condition: used, machine/vehicle number: 008438, Max. panel width: 4500 mm Max. panel length: 4500 mm Main saw blade projection: 50 mm No of Grippers: 8 Bwsdoyngy Sepfx Amnop
