Vertical Turret Lathe - Double Column

WMW- NILES DKZ6300-2500 B

Condition: good (used), functionality: fully functional, Year of construction: 1990, machine/vehicle number: 4ROLL, roller (bottom) diameter: 470 mm, roller (top) diameter: 470 mm, side roll diameter: 420 mm, roller diameter: 470 mm, roller length: 3,050 mm, working width: 3,050 mm, working height: 1,800 mm, sheet thickness (max.): 50 mm, sheet thickness steel (max.): 45 mm, sheet thickness aluminum (max.): 45 mm, sheet thickness copper (max.): 45 mm, overall weight: 43,000 kg, total length: 7,700 mm, total width: 2,410 mm, total height: 2,470 mm, power: 37 kW (50.31 HP), input voltage: 380 V, type of input current: three-phase, working length: 3,050 mm, Equipment: documentation/manual, emergency stop, PLATE BENDING MACHINE FACCIN - 4 ROLL HYDRAULIC 3000 X 40 MM MODEL 4HCI3-35/30 YEAR 1990 PLATE BENDING ROLL LINEAR GUIDEWAYS DOUBLE PINCH PRE-BENDING Machine in good working condition Bending capacity -Plate width : 3000 mm -Rolling plate thickness 40 mm - Prebend thickness 35 mm Rolls dimensions: -Useful length 3050 mm Kdjdpfjwb Scmex Aayok -central rolls upper/lower 470 mm -side rolls left/right 420 mm • Hardening of the 4 rolls high strength surface • 3 rolls driven powered with gear unit with hydraulic motor • Conical bending attachment side rolls tiltable to form cones, contrast pad roller type. • Opening front hydraulic drop-end to unload the closed shell. • Variable speed working roll bending rotation hydraulic speed fast/slow. • Console electric on wheels with centralized commands joysticks and 3 digital readout. • Digital readouts of the rolls position bending and pre-bending repeatability. • Hydraulic tank capacity oil 350 liters – power electric 37 Kw voltage 380 /50 • Dimension 7700 x2410 x H 2470 mm - weight 43000kgs

Condition: good (used), Year of construction: 1988, grinding length: 1,000 mm, grinding width: 550 mm, grinding height: 400 mm, grinding wheel diameter: 400 mm, grinding wheel width: 100 mm, Manufacturer: ELB-SCHLIFF Model: SWBE 010 ND Ksdpfxsu Rqyno Aayodk Year of manufacture: 12-1988 Delivery time: immediately Electro-permanent magnetic clamping plate SAV 1000 X 400 mm Fine pole pitch 45-5 mm Electric straightening device with compensation Digital display vertical Holder with grinding wheel max. 400 X 100 X 127 mm Spindle motor 7.5 KW 1435 min/1 Setting wedges Coolant system with universal paper belt filter Complete documentation

Condition: excellent (used), Technical Details: Working width: 3100 mm Maximum bending capacity: 16.0 mm Maximum pre-bending: 12.0 mm Top roll diameter: 300 mm Side roll diameter: 270 mm Ksdpfx Aoxyvx Tsayjdk All three rolls powered Hardened rolls Conical bending device by tilting of both side rolls Swiveling control panel with digital display Hydraulic drop end bearing Motor power: 7.5 kW Dimensions (L x W x H): approx. 5800 x 1700 x 1500 mm Net weight: approx. 8.5 tons The seller is not liable for typing or data transmission errors. The machine's appearance, technical condition, and wear correspond to its age; used machines are sold without any warranty.

Condition: excellent (used), Year of construction: 2018, operating hours: 2,000 h, functionality: fully functional, turning height: 3,000 mm, workpiece weight (max.): 30,000 kg, turning diameter: 3,500 mm, power: 100 kW (135.96 HP), TECHNICAL CHARACTERISTICS 1. Max. machining diameter mm 3.500 2. Min. machining diameter mm 0 3. Max. height of the part mm 3.000 4. Max. load on the table to 30 5. Table diameter mm 3.000 Ksdpfxstpnlwe Aayodk 6. Table speed range rpm 2 ÷ 130 7. Main AC motor - turning kW 100 8. The maximum torque of the faceplate in turning mode Nm 105.000 9. Ram vertical stroke (Z axe) mm 1.750 10. Turning ram cross section mm x mm 300x300 11. Horizontal stroke –X axe mm 2.000 12. Feed range (X and Z axe) mm/min 1 ÷ 6000 13. Rapid traverse (X and Z axe) mm/min 8.000 14. Feed motor torque (X and Z axe) Nm 22 18. Vertical stroke of the cross rail mm 2.700 CNC Equipment 1. Equipment type Fanuc Overall Dimensions 1. Floor space m 8.5 x 6 2. Max. height of the machine m 8.2 3. Max. height over floor level m 7.4 3. Machine weight to 89 Tool Magazine 1. Number of tool magazines - 1 2. Number of tools/magazine - 16 3. Feed motor torque with encoder Nm 12 4. Tool change time sec. 25 5. Maximum weight of the tool holder - for turning daN 100 6. Maximum length of the tool holder - for turning mm 600

Condition: good (used), functionality: fully functional, Characteristics: Distance between centers: 4500 mm Turning diameter: max. 750 mm Spindl bore diameter: 105 mm Control: Heidenhain Including 2 x chuck diameter 500 mm and 315 mm Kjdsvy Adgjpfx Aayodk Including 2 x steady rest

Condition: used, Technical details: spindle diameter: 130 mm drill depth: 1380 mm x-travel: 2500 mm y-travel: 1600 mm z-travel: 380 mm w-axis: 900 Bohrspindelvorschub mm U-axis: 320 Planschiebervorschub mm control: auf Wunsch tool taper: ISO SK50 revolution per minute: Planschieber:4,5-180 U/min rpm - drive spindle: 4,5-900 U/min feed:: x/y: 5-2000 total power requirement: ca. 40 kW weight of the machine ca.: ca.< 35 + AZusatzeinrichtungen t The machine can be offered in 4 different sales options. Please choose! 1. the machine is in mint mechanical condition. As is/is. 2. the machine as is/is incl. plate field 4000x2000x300mm = stock no. 1101081 3. the machine is newly wired, with new electrical cabinet, digital display, with 4-axis, AC drives from Siemens, axis motors from Siemens (50A/31Nm) with 12 months warranty on all new parts. Ksdpfxevr S Ule Aayedk 4. further additional equipment can be offered as an option. Such as coolant system, chip conveyor, enclosure etc. We should discuss this on the table with your technical staff. i.D. *

Condition: excellent (used), Herringbone Gear Generator MDV 2000 MDV 2000 Characteristics: Max wheel diameter: 2000 mm Min wheel diameter: 50 mm Max module: 12 Min module: 3 Kedpfxjfx Ibno Aayjdk

Condition: used, Year of construction: 1988, functionality: fully functional, Gear Grinding Machine VEB ZSTZ 630 C 3 P – 1988, Ready to Operate Description: For sale: gear grinding machine from the German manufacturer VEB Werkzeugmaschinenkombinat, model ZSTZ 630 C 3 P, year of manufacture 1988. The machine is in good technical condition, available immediately, and ready for inspection. Currently connected to power, allowing immediate testing of its operation. Ideal for workshops specializing in precise gear machining and industrial machine repair. Specifications: Manufacturer: VEB Werkzeugmaschinenkombinat Kodeyfq E Hspfx Aayodk Model: ZSTZ 630 C 3 P Year of manufacture: 1988 Condition: good technical condition Availability: immediate Ready for inspection, connected to power Contact: Please contact us for inspection arrangements or further information.

Condition: used, Aufspannplatte - Tisch einer Langhobelmaschine - Kjdjbn Amfspfx Aaysdk Tischbreite/Aufspannbreite: 1845 Tischlaenge/Aufspannlaenge: 5505 mm 7 T-Nuten laengs fuer T-Nutensteine: M 30 T-Nutenabstaende zueinander: 263 mm Gesamtlaenge: 6230 mm Plattenhoehe insgesamt: 350 mm Gewicht: 11 t

Condition: used, Year of construction: 2008, turning diameter 1000 mm swing diameter 1250 mm turning height 500 mm control Siemens Sinumerik 840 D Workpiece spindle flange diameter 520 mm work piece spindle speed range 0-440 U/min total power requirement 75 kW weight of the machine ca. 25 t dimensions of the machine ca. 5100 x 3034 x 4500 mm With grinding spindle Kdedpfsw Rgcfjx Aayok Table travel: - Z1/Z2 axis 1000 mm, - X1/X2 axis approx. 1300 mm Table speed continuously adjustable: - Z axis 0–30 m/min, - X axis 0–50 m/min - Feed speed continuously adjustable 0.01–15 mm/min - Feed dependent on stroke 0.0005–0.1 mm - Workpiece spindle positioning C axis Equipment/accessories: - Grinding spindle - Kaiser dresser - Tool measuring probe - Filter system - With flushing nozzle connections - 2 Capto holders - 1 set of jaws for chuck - technical documentation
