MHL Maschinenhandel Andreas Ludewig

Condition: good (used), Year of construction: 2007, Functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, controller manufacturer: Heidenhain, controller model: 530, spindle speed (min.): 10,000 rpm, coolant supply: 80 bar, 5-axis machining center with automation Manufacturer: Hermle Type: C20U Drawrb Year of manufacture: 11-2007 Control: Heidenhain iTNC-530 On-time hours: 100,650 h Spindle hours: 57,000 h S/N: XXXX Technical parameters: ----- • Travel paths X-Y-Z: 600 x 450 x 450 mm • C-axis: 360° • A-axis: +/-115° • Swivel rotary table Ø280 mm • Spindle: 10,000 rpm • Magazine: 30x SK-40 • Coolant system 40-80 bar including IKZ and bed flushing • Automatic door • Tool breakage monitoring Blum • 3D probe Heidenhain • Electrical heat compensation • Sealing air for glass scales • Paper belt filter • Chip conveyor Automation: ----- • Sherpaloader M20 Vision • Sherpa robot with optics for edged material • Control via M commands / macros • Control via portable control unit • Clamping control via torque monitoring, ..Clamp is clamped mechanically by robot, ..Tightening torque 5-60 Nm • Incl. HWR Solidstamp embossing station • Incl. protective fence and light curtain • SMS alarm module Accessories: ----- • Documentation • Flushing gun • Maintenance history Machine fully operational, functional video available on request. Inspection of the machine possible after approval by the previous user. Machine in very good condition, many replacement parts, no maintenance backlog! Use without automation is possible without any problems.

Condition: good (used), Year of construction: 2007, operating hours: 30,000 h, Functionality: fully functional, travel distance X-axis: 1,270 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 610 mm, controller model: Winmax, rotational speed (max.): 12,000 rpm, Equipment: chip conveyor, documentation/manual, 3-axis machining center Manufacturer: Hurco Type: VMX-50 Year of manufacture: 2007 Control: WinMax V8.01 Switch-on hours: approx. 30,000 h S/N: H-HXXXXX Origin: Taiwan technical data: ----- Is29Rwr2O - Table size: 1,500 x 660 mm - Travel X-Y-Z: 1,270 x 660 x 610 mm - Spindle: 12,000 rpm + spindle oil cooler - Tool holder: SK40 - Tool magazine: 24x - Coolant through spindle: 20 bar - Chip conveyor - 3D probe: Renishaw OMP-60 - Tool probe: Renishaw TS-27R - 4th axis: Ø200 mm Kitagawa - Software options: DXF + 3D - Footprint LxWxH: 3.50 X 2.30 X 2.60 m - Weight: approx. 9.2 tons Accessories: ----- - Documentation - handwheel - 2x new side windows

Condition: excellent (used), Functionality: fully functional, center height: 125 mm, grinding length: 440 mm, grinding wheel diameter: 400 mm, Cylindrical grinding machine Manufacturer: Studer Type: RHU-400 Year of construction: n.a. General overhaul: 2013 Dqm9Kt S/N: XXX.XX Control: conventional + digital display Switch-on hours: n/a Technical data: ----- - electro-hydraulic control - Center height: 125 mm - Center width: 400 mm - Grinding length: 440 mm - Table orientation: 12 ° - Table speed: 0.05 - 5.5 m/min - Workpiece spindle: 30-675 rpm - Spindle bore: 28 mm - Piece holder spindle type: Morse 5 - Grinding wheels: Ø400 x 50 x 127 mm - Grinding spindle speed: 1,500 - 2,420 mm - Grinding spindle rotatable +/-45° - Dresser (without diamond) on counter holder - Motor power: 3 kW - Weight: 2,100 kg Accessories: ----- - 20x grinding wheels with flange - 2x grinding wheel without flange - Coolant device - 3x machine feet - Various small parts and tools

Condition: good (used), Year of construction: 2004, operating hours: 54,000 h, Functionality: fully functional, travel distance X-axis: 1,060 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 610 mm, controller manufacturer: Hurco, spindle speed (max.): 10,000 rpm, 3-axis machining center Manufacturer: Hurco Type: VMX-24 Year of manufacture: 11-2004 Control: Ultimax S/N: H-HXXXXX Switch-on hours: approx. 54,000 h Technical data: ----- - Table size: 1,270 x 610 mm - Travel X-Y-Z: 1,060 x 610 x 610 mm - Spindle: 10 - 10,000 rpm max. - Tool holder: SK-40 - Number of magazine positions: 24 - Chip conveyor - Weight: approx. 6,700 kg - Total power requirement: 30 kVA Ciahwkiv - Dimensions LxWxH in mm: 2,200 x 2,400 x 2,800 Accessories: ----- - manuals - Electronic handwheel - Cross groove table

Condition: excellent (used), Year of construction: 2007, Functionality: fully functional, saw blade diameter: 200 mm, Fully automatic metal circular saw for burr-free cuts and high sawing performance in thin-walled material Manufacturer: Rohbi Series: RKA-86 Control system: Siemens Year of manufacture: 2007 Origin: Switzerland technical data: ----- - High-speed spindle for saw blade 500 - 3,900 rpm (2.0 kW) - Clamping cylinder pneum. 2.000 N Gxcb2Tq - Cutting range round solid material with HSS saw blade: 2-60 mm - Cutting range profiles solid material with HSS saw blade: 60x40 mm - Cutting range round pipe material with HSS saw blade: 2-70 mm - Cutting range profile material with HSS saw blade: 80x40 mm - Material feed carriage max. stroke: 1,250 mm Drive via gear wheel / gear rack - Clamping vice clamping: hydraulic - Minimum quantity lubrication - Saw blade dimensions: 100 - 200 mm (HSS or solid carbide) - Saw blade monitoring via load pick-up - Chip removal via external extraction possible - Material removal via retracting chute - Weight: 900 kg Accessories: ----- - Operating instructions - 3x sets of clamping jaws with drawings

Condition: excellent (used), Year of construction: 1999, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, overall weight: 9,500 kg, spindle speed (max.): 12,000 rpm, tool mount: 40 mm, 3-axis machining center Manufacturer: DMG Series: DMU-80P Year of manufacture: 1999 Control type: Heidenhain TNC-430 Switch-on hours: approx. 95,900 h Program run: approx. 28,100 h technical data: ----- - Travel X-Y-Z: 800 x 700 x 600 mm - Work table: 900 x 630 mm - Spindle max.: 12,000 rpm - Swivel head H/V - Tool holder: SK40 - Tool magazine: 30x / chain - Coolant system - Central lubrication - SpäFö - Weight: approx. 9.2 t Accessories: ----- - Manuals - 3D workpiece probe TS-641 Remarks: ----- - FEB 2023: new spindle + kinematics - FEB 2023: new E-module 36kW - APR 2023: new AC servo inverter - DEZ 2015: General overhaul Bdsrziojb - Machine absolutely true to size!

Condition: excellent (used), Year of construction: 2014, Surface grinding machine Efsbo890 Manufacturer: Ziersch Type: ZT 24 Year of construction: 2014 Control system: Mitsubishi GOT-1000 Technical data of the vehicle: ----- - Travel X/Z: 400 / 250 mm - Magnet: 400 x 200 mm P9 - Table load max.: 250 kg - Distance from center of grinding wheel to table: 540 mm - Y-axis with direct path measuring system - Grinding wheel: 250 x 38 mm (50.8 mm bore) - Gradual grinding spindle control 1,000 to 4,500 rpm - Grinding spindle new in 04-2024! - V-constant - automatic vertical infeed with compensation of the dressing amount - Coolant device / paper belt filter - Magnetic separator - Weight: approx. 2,900 kg - Dimensions: 2,600 x 1,800 x 2,350 mm Accessories: ----- - Documentation - Handwheel

Year of construction: 1999, Condition: excellent (used), Tool milling machine Manufacturer: Fehlmann Type: Picomax 80 CNC 2/3 Control: Heidenhain TNC 407 year of construction: 1999 switch-on hours: approx. 35.750 h spindle hours: approx. 10.250 Technical parameters: ----- - spindle: 50 - 9.200 rpm max. - Spindle mounting SF32 - traverse X-Y-Z in mm: 700 x 315 x 495 - clamping area table: 1.230 x 410 mm - traverse path quill: 180 mm - Coolant system - Total connected load: 20 kW - Weight: approx. 3.4t Accessories: ----- Csnebtqplj - Documentation - Renishaw 3D wireless probe MP-15 - Dividing head with collet chuck - Tool holder package - Handwheel Special features: ----- - Spindle new bearing in 2019 - Brinkmann F4 Drive frequency converter new in 2019 - Dividing head new in 2019

Year of construction: 2019, Condition: excellent (used), image guided 3D coordinate measuring machine Dapsv2T Manufacturer: Keyence Type: XM-1200 Series Year of manufacture: 2019 Control: Keyence Technical Data: ----- - Camera chip: 4 MP CMOS - Measuring range: 600 x 300 x 200 mm - Smallest display unit: 1 µm - Smallest angle: 0.0001 - Repeatability (locked): ±3 µm - Max. table load: 25 kg - Display: 15" TFT - Weight: 40 Kg Accessories: ----- - manuals - analog delivery condition (data sheet attached)
