Condition: excellent (used), 21 spindles spindles right/left table dimensions 840x440mm 2 pneumatic clamps spindles span 32mm pedal control Ncsdpfx Adoyxc Hwjvop pneumatic setting vertical/horizontal

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Device description Table width - 850mm Drill stroke - max 70mm Number of spindles - 21 Distance between spindles - 32mm 4 pneumatic clamps Drilling depth adjustment Vertical, horizontal and angle drilling 1.5kW main engine Pneumatically adjustable drilling speed Pneumatically adjustable drilling angle Ncsdeyxc Hqspfx Advep Quick-release drill attachment

Condition: good (used), Year of construction: 2019, operating hours: 2,189 h, load capacity: 1,400 kg, lifting height: 5,016 mm, fuel type: electric, mast type: triplex, construction height: 2,165 mm, empty load weight: 1,600 kg, mileage: 2,189 km,

Condition: good (used), 23 spindles spindles right/left spindles span 32mm 2 pneumatic clamps pneumatic setting vertical/horizontal Ncodpfjyxc Hdox Advop pedal control

Condition: excellent (used), 23 spindles left/right spindles 3 pneumatic clamps spindles span 32mm Ncsdpjyxc E Tofx Advop pedal control CE

Condition: good (used), Year of construction: 2022, operating hours: 534 h, load capacity: 1,000 kg, lifting height: 1,517 mm, fuel type: electric, mast type: duplex, construction height: 1,940 mm, mileage: 534 km, Electric stackerBrand: STILL (Germany)Year of manufacture: 2022ONLY 534 operating hoursCapacity: 1,000 kgLifting height: 1,517 mmOverall height: 1,940 mmEquipped with FREELIFTBattery: with BUILT-IN charger Nodpfx Aeyxc E Hodvjcp

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, TECHNICAL DETAILS Travel X: 1,250 mm Travel Y: 880 mm Travel Z: 800 mm MACHINE DETAILS Manufacturer: DECKEL MAHO Model: DMU 125 P Year of manufacture: 1999 Machine hours: 93,440 hours Ncedsyxc Etspfx Advsp Spindle hours: 51,147 hours Control: HEIDENHAIN EQUIPMENT Tool changer Chip conveyor

Condition: excellent (used), functionality: fully functional, Year of construction: 2019, TruLaser 3040 – CO2 4000W Ncsdpfx Adsyxc Egsvjp Laser on: approx. 25,600 hours Beam on: approx. 13,100 hours

Condition: excellent (used), 29 spindles left/right spindles spindles span 32mm horizontal or vertical drilling setting of depth of drilling Ncsdpfx Adjyxc Eaevep pneumtatic movement of drilling head

Condition: good (used), table dimensions 450x300mm working height regulation Ncjdpfx Adjyxc D Novop iron cast body

Condition: excellent (used), functionality: fully functional, Year of construction: 2019, TruLaser 3030 L81 – FIBER 4000W Njdpfxjyxc D Ao Advjcp Laser on: approx. 13,300 h Machine on: approx. 26,300 h

Condition: good (used), heads set: right/left/top/top spindles span 32mm motors 1,1kW heads with 5 spindles max heads span 2,5m Ncjdpfjyxc Dvex Advep pneumatic clamps regulation of drilling speed

Condition: excellent (used), pneumatic clamps automatic material feeding unit angle regulation pneumatic movement of spindles regulation of oscillation range Nedpfx Ajyxc Dpedvecp

Condition: excellent (used), pneumatic clamps Ncjdpfx Adjyxc Dievop automatic strip feed aggregate angle adjustment pneumatic spindle movement strip supports oscillating drill movement adjustment feed stroke adjustment 380V power supply

Condition: good (used), Spot welding machine, spot welding system, spot welding gun, spot and projection welding machines, AC welding current control, welding current control, welding control -Manufacturer: HiE, welding current control for spot and projection welding machines Nedpfx Aeyxc A Ssdvecp -Type: Accent T-500 / L050 -Imax: 500 A -Technical data: see photo datasheet -Dimensions: 250/160/H100 mm -Weight: 1.5 kg

Condition: ready for operation (used), Year of construction: 2002, operating hours: 41,245 h, functionality: fully functional, machine/vehicle number: 1113000335, travel distance X-axis: 880 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, controller manufacturer: HEIDENHAIN, Equipment: chip conveyor, TECHNICAL DETAILS Travel X-axis: 880 mm Travel Y-axis: 630 mm Travel Z-axis: 630 mm MACHINE DETAILS Control: HEIDENHAIN Operating Hours Machine hours: 74,780 hours Spindle hours: 41,245 hours Ncsdpfx Aeyxc Dcodvop EQUIPMENT Chip conveyor Filtration system

Condition: excellent (used), two speed with switch belt gear motor power 0,3kW CE year 2003 Nodpfx Adsyxc A Eevscp Connection 380V

Year of construction: 1990, condition: used, functionality: fully functional, Stainless steel mixer with a capacity of 600 liters or 1,500 kg filling weight. Lid opening with grid and option for dust extraction. Mixing screw drive 5.5 kW. Swing arm drive 1.5 kW. The mixer has not been refurbished but can be viewed in operation. Refurbishment can be offered upon request. Stainless steel pneumatic side discharge, swing arm, mixing screw, vessel, and lid. Nodpfx Adsyxc Axsvecp

Condition: used, Year of construction: 2020, functionality: fully functional, turning length: 1,200 mm, turning diameter over cross slide: 500 mm, spindle motor power: 40,000 W, spindle speed (max.): 5,000 rpm, spindle bore: 87 mm, travel distance X-axis: 490 mm, travel distance Y-axis: 125 mm, travel distance Z-axis: 1,200 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 50 m/min, rotational speed (max.): 12,000 rpm, swing diameter over cross slide: 500 mm, spindle nose: CAPTO C6, CELOS CNC WITH SIEMENS 840D AND MULTI-TOUCH SCREEN Ncedpfx Adeyxc Arjvop WORKING AREA: Turning diameter: mm 500 Max turning diameter: mm 500 Max turning length: mm 1,200 Distance between spindles (machine with sub-spindle): mm 1,470 MAIN SPINDLE: Spindle nose flange: mm 170 h5 Spindle bore: mm 87 Inner diameter of draw tube: mm 67 Front bearing diameter: mm 130 Power, S1-100% ED / S3-40% ED: kW 33/40 Speed range: rpm 4,000 Torque S1-100% ED / S3-40% ED: Nm 580/700 SUB-SPINDLE: Power, S1-100% ED / S3-40% ED: kW 25/32 Speed range: rpm 5,000 Torque S1-100% ED / S3-40% ED: Nm 280/360 SLIDE: X-axis travel: mm 490 (-10/+480) Y-axis travel: mm ±125 Z-axis travel: mm 1,200 Rapid traverse X, Y, Z: m/min 40/40/50 Feed force S6-40% X/Y/Z: kN 9/6/9 MILLING-TURNING SPINDLE: Tool interface: Capto C6 Max spindle speed: rpm 12,000 Power, S1-100% ED / S3-40% ED – 2 min: kW 19/22.5 Torque, S1-100% ED / S3-40% ED – 2 min: Nm 85/120 Spindle indexing resolution: degrees 0.001 Holding torque: Nm 850 B-AXIS CNC: Swivel range B1: ±120° Swivel speed: °/min 25,200 B-axis torque, S6-40% ED: Nm 614 Hydraulic clamping: Nm 2,800 MACHINE CONFIGURATION Control CELOS with Siemens 840D sl Operate ERGOline 21.5’’ with multi-touch screen Main Spindle Integrated motor spindle ISM 102 Drive: 33/40 kW (100/40% ED) Torque: 580/700 Nm (100/40% DC) Speed range: 0–4,000 rpm Semi-hollow hydraulic clamping device Inner draw tube Ø 104 x 800 mm depth C-axis and spindle brake (hydraulic) Sub-Spindle Integrated synchronous motor spindle ISM 76 Drive: 25/32 kW (100/40% ED) Torque: 280/360 Nm (100/40% DC) Speed range: 0–5,000 rpm Semi-hollow hydraulic clamping device, inner Ø 67 C-axis and spindle brake (hydraulic) Lower slide (Z3), servo-driven with ball screw drive, direct measuring system Coolant through spindle Spindle cleaning device Spindle Options Hydraulic hollow clamping device Ø 104 mm, pull force 105.5 kN at max pressure 45 bar, max speed 3,600 rpm Differential pressure for main spindle Differential pressure for sub-spindle Main Spindle Chuck 3-jaw hollow power chuck with through hole, BBD 315/122, manufacturer SMW-Autoblok Sub-Spindle Chuck 3-jaw chuck BBD 210–66, manufacturer SMW Autoblok Milling Spindle Milling spindle and tool magazine with Capto C6 interface Tailstock Tailstock function for sub-spindle including pedal Mechatronic programmable thrust control Thrust force: kN 2.5 – 6 Tool Magazine Chain-type tool magazine, 48 positions, Capto C6 interface Coolant / Chip Removal Hinged belt chip conveyor, including coolant tank High-pressure coolant system through milling spindle, consisting of: 980 L coolant tank with belt filter system 8 bar / 20 L/min Spindle cleaning device on main spindle and sub-spindle Mechanical fume extractor 1100 m³/h, filter class H13 Control Options (CELOS with Siemens) Technology cycle for alternating spindle speed to reduce vibrations Machine complete with: • Approx. 50 Capto C6 tool holders with related tools • No. 2 cabinets with inserts and various equipment • Instruction manuals and CE declaration of conformity

Condition: excellent (used), functionality: fully functional, pneumatic clamps automatic strip feed aggregate angle adjustment pneumatic spindle movement strip supports oscillating drill movement adjustment Nodpfsyxc Alox Advecp feed stroke adjustment 380V power supply

Condition: excellent (used), Year of construction: 2014, 3 kW resonator power Ncsdpoyxc Afsfx Advsp

Condition: excellent (used), pneumatic clamps automatic material feeding Nedsyxcz Ujpfx Advjcp unit angle regulation pneumatic movement of heads material support slot length regulation slot distance regulation

Condition: ready for operation (used), Year of construction: 2000, Immediately available from Swiss toolmaking: 5-axis milling machine Deckel Maho Type DMU 35 M Year of manufacture: 2000 CNC control: Heidenhain TNC 310 M Electronic handwheel Table 400 x 280 mm Table load up to 100 kg Travel X/Y/Z: 350/240/340 mm Infinitely variable spindle speeds: 0 – 5,000 rpm Taper SK 40 Rapid traverse 5 m/min Nodsyxcz Iepfx Advocp Servo motors for X/Y/Z axes Swivel range 360 degrees Table clamping plus 105/minus 150 degrees Weight 2 t Accessories, hydraulic vise Price: EUR 5,000.—plus VAT, ex works

Condition: used, mileage: 4,42,169 km, power: 194 kW (263.77 HP), first registration: 04/2019, fuel type: diesel, empty load weight: 6,860 kg, maximum load weight: 9,065 kg, overall weight: 16,000 kg, tire size: 285/70 R19,5, axle configuration: 2 axles, wheelbase: 5,350 mm, brakes: engine braking, driver cabin: day cab, gearing type: automatic, emission class: euro6, suspension: air, number of seats: 2, total length: 2,550 mm, total width: 3,800 mm, total height: 9,400 mm, loading space length: 7,100 mm, loading space width: 2,480 mm, loading space height: 2,400 mm, Equipment: ABS, air conditioning, central locking, compressed air brake, cruise control, differential lock, onboard computer, parking heater, spoiler, truck registration, DAF LF 260 box truck | Tail lift 1500kg | Automatic EURO 6, air conditioning | Multifunction steering wheel, cruise control | Radio/CD, differential lock | Gross weight: 16,000kg, curb weight: 6,840kg | Payload: 9,085kg | Tyres: 285/70 R19.5 | Subject to errors, input mistakes, and prior sale. Ncsdpfsyxczzex Advop

Condition: good (used), pneumatic clamps automatic material feeding angle regulation pneumatic movement of heads material support slot length regulation slot distance regulation Ncsdpfx Aoyxczujdvjp
