Band Saw

BERG & SCHMID VOLLAUTOMAT AH 360H

Condition: good (used), Year of construction: 1961, Heavy-duty lathe, turning machine, lathe, center lathe, center lathe -Condition of machine bed: very good condition -Machine bed: hardened -Manufacturer: Martin, lead screw lathe type DLZ 502 Kdsdswfpilopfx Aadsw -Turning length: 2200 mm -Turning Ø over bed: 580 mm -Turning Ø over support: 300 mm -Spindle bore: Ø 65 mm -Spindle speeds: 22.4 - 1000 rpm -Wedge bar chuck: Forkardt Ø 320 mm -Tailstock mount: MK5 -Drive: 7.5 kW -Accessories: 4x bezels, tool holder, tools see photos -Dimensions: 1260/3720/H1260 mm -Weight: 2510 kg

Year of construction: 2009, condition: ready for operation (used), Turning diameter: 200mm, passage diameter: 330mm, passage diameter over cross slide: 260mm, travel X/Z: 160mm/460mm, feed X/Z: 24m/min, speed: 5000rpm, spindle clearance: 51mm, spindle power: 16.5kW/11kW, torque: 1665.5Nm/112Nm, tailstock: 400mm, tool positions: 12. Machine dimensions X/Y/Z: approx. 4200mm/1700mm/2300mm, weight: approx. 3500kg, control: Siemens Sinumerik 810D. Including chip conveyor. Documentation available. On-site inspection is possible. Kdedpfov Dkb Iex Aadew

Condition: good (used), Year of construction: 1997, machine/vehicle number: 887043, Offer 24557 Technical data: - max. working length 4060 mm - column clearance 3680 mm - max. pressing force 1700 kN - max. distance table / ram 385 mm - column projection 410 mm - ram stroke 215 mm - stroke speeds - downward speed idle max. 200 mm/sec - upward speed 135 mm/sec - downward pressing speed 1 to. 11 mm/sec - Total drive power 30 kW - Space requirement approx. W 5600 x H 3000 x D 2400 mm - Weight approx. 18000 kg Ksdpfx Aaeu T Nknsdodw - with: - with 6-axis CNC control DELEM - Two-hand control panel with foot switch - Crowning device - Controlled back stop with height adjustment 5 - 860 mm - Hydraulic upper + lower tool clamping - Die table displacement pneumatically supported

Condition: new, Year of construction: 2023, shaft diameter: 80 mm, Profile bending machine AHB 80 - electro-hydraulic ring/profile bending machine - hydraulic bottom roller adjustment - Hydraulic side roller adjustment - Lower shafts individually adjustable - Three driven rollers - divided roller segments - digital display - touch screen - Hardened shafts and standard rollers - Hydraulically adjustable side straighteners - Can be used horizontally and vertically - Mobile control panel - CE mark / declaration of conformity Shaft diameter 80 mm hardened Fully hydraulic Motor 400 Volt 50 Hz 3 ph. Kodpfjqxcy Hex Aadedw Weight approx. 1,700 kg Dimensions 1340 x 1390 x 1640 mm

Condition: new, Working area round 360 mm Working area quadrant 360 x 360 mm Working area bundle W x H 180 - 280 x 50 - 160 mm Cutting speed 20 - 100 m/min (infinitely variable) Saw blade dimensions 4,420 mm x 34 mm x 1.1 mm Hydraulic saw blade tensioning Multiple feed 500 mm Drive power 3.7 kW Machine size LxW 2,500 x 2,200 mm Kodpfxjqrqvhe Aadodw Machine weight 2,300 kg Standard equipment - Hydraulically controlled full-stroke double clamping system. - Driven by IE3 motor with inverter (PMSM, Euate IE4) - User-friendly NC touchscreen control with high-end system (NCIII CONTROL) - Feed rate display on the HMI (10" HMI screen) - Automatic chip conveyor - Automatic shuttle feed - IC board control for all electrical and hydraulic functions - Floating pendulum vice - Two-piece front vice - Stepless speed control by inverter - Hydraulic blade clamping - Roller bearings with hydraulically controlled carbide blade guide system - Automatic working height control through quick start sensor - Preset cutting counter with cut-off function - Nesting device for bundle cutting (hold-down device) - Power-operated blade cleaning brush - Saw blade monitoring with regard to standstill and blade breakage - Flushing hose for machine cleaning - Work light - Roller table with 2 m length - One M42 bi-metal saw blade - One set of tools and one toolbox

Condition: used, Year of construction: 1995, cutting diameter 280 mm saw band length 4200 mm cutting width 280 x 280 mm dimensions of saw-band 4200 x 34 x 1,1 mm cutting speed 18 - 115 m/min multiple feeding 0 - 6000 mm power capacity 3,0 kW Kedpfxep Rai Ee Aadodw voltage 400 V total power requirement 5,0 kW weight of the machine ca. 2,3 t dimensions of the machine ca. 2,35 x 2,40 x 2,00 m - serial-no.: 6082 - control: SIEMENS COROS - OP 15 - chip conveyor - multiple feeding - coolant equipment

Condition: new, Year of construction: 2024, SEMI-AUTOMATIC DRILLING RIG “UNIBORFIX 50” With the UniBohrFix 50 drilling system, all profiles can be machined against a stop or with grippers. The Drilling is done manually using the lever, with the materials on the X-axis automatically pointing to the drive to the next drilling position. Easily drill entire programs or work with the stop plate quickly carry out individual drillings. The system is suitable for weights up to 100 kg. The facility also contains a minimum quantity spray unit with holder and spray can. The technical data of the standard version can be found in the table. If necessary, all components of the system can be adapted to your requirements. You can choose between different drilling machines, roller conveyors, select positioning systems and vices. Plantec configures the system so that it suits you perfectly! ADVANTAGES A sequence of holes is automatically executed at precise intervals. Potential operator errors are drastically reduced. Programming takes just a few minutes. Very good value for money. Significant reduction in manpower. Standard measuring lengths: 3,000mm 6,000mm Kjdpfjgwt Slex Aadedw Drill: Unimax 2 T Spindle MK2 Continuous drilling capacity 18 mm Speed ​​ranges: 100-2000rpm, 200-4000rpm Projection 225 mm Spindle/table distance 60-400 mm Adjustable vice with measuring linear display Positioning length stop: PD-100e control for automatic positioning Positioning: absolute or chain dimensions Easy to read LED display Trolley with DC servo motor Positioning accuracy +/- 0.1 mm/m Attachment arm with spring damping Stop plate with groove Memory control with 3,000 memory options Roller conveyors: RD-200/3 load capacity 200 kg/m Roll width 290 mm Roll diameter 40 / 50 mm insert sheets Struts for stabilization switch cabinet Available options: Minimum quantity spray system with spray head and holder Gripper tongs for clamping the material on the stop plate

Condition: new, capacity 90 degrees: round 510 mm capacity 90 degrees: square 480 mm 610 x 450 saw band length 5320 x 34 x 1,1 mm band speed 15 - 100 m/min table height 820 mm total power requirement 3,0 kW weight of the machine ca. 2,3 t dimensions of the machine ca. 2,65 x 2,8 x 2,2 m Ksdpfx Aajfu Nbbedsdw For miter cuts up to 45° left in fully automatic Operation and up to 60° left in semi-automatic operation Material height sensor (automatic cut start detection) Automatic feed unit via ball screw with incremental feed automatic length compensation Button on the saw band for automatic adjustment of the saw stroke Fully automatic control of the saw frame and clamping device Hydraulic unit with automatic pressure shut-off when idling Mechanical chip clearing brush feed vice opening on both sides Remaining piece length 100 mm Modern CNC control freely programmable for multiple sawing jobs with various Cutting lengths and quantities. Automatic feed unit 500 mm via ball screw incremental feed with automatic length compensation. Adjustable for section lengths of 25 – 9,999mm. Fully hydraulic control of saw frames and clamping devices Preselection of 3 different material feed speeds Visualization of the entire workflow with simple data entry

Condition: excellent (used), functionality: fully functional, Year of construction: 2003, machine/vehicle number: 070A-633, shaft diameter: 70 mm, roller diameter: 245 mm, rotational speed (min.): 8 rpm, overall weight: 1,300 kg, total length: 1,640 mm, total width: 1,220 mm, total height: 1,580 mm, input voltage: 380 V, type of input current: three-phase, operating speed: 8 mm/s, Equipment: documentation/manual, emergency stop, Profile bending roll Tauring Alfa 70H2 year 2003 -Hydraulic section bending machine with digital readout -3 rolls powered driven - -dual pre-pinch pyramid roll configuration Shafts output 70 mm – Size of universal rollers 245 mm Lateral correctors left/right side hydraulic motorized operated reversible, can work with shafts vertical /horizontal Tooling: -Set of universal rolls and spacers Pipe bending rolls set for tube 22,5 – 61 – 76 - ( see photos of the rolls in enclosed ) Power total installed 5,5Kw Vac 380/50 Kdsdjwkrpfspfx Aadsw Dimension 1640 x 1220 x H1580 mm Weight 1300 kgs

Condition: used, Year of construction: 1972, Dreh-Øüber Bett 400 mm Dreh-Øüber Support 220 mm turning length 1000 mm spindle turning speed range 12,5 - 2000 U/min spindle taper Bajonett 55022 spindle bore 47 mm Kdjdpfevzhhyex Aadjw feeds - longitudinal 0,07 - 4,16 mm/U feeds - cross 0.035 - 2,08 mm/U thread - mm pitch mm thread - inch 2 - 24 Gang/ inch. rapid travel - longitudinal/face 3,4 / 1,7 m/min spindle drive 11 kW power capacity 13 kW weight of the machine ca. 2,8 t dimensions of the machine ca. 2,8 x 1,2 x 1,5 m • 3-jaw chuck Ø 250 mm, • 4-jaw chuck Ø 200 mm, • 2-axis- digital display, ANILAM WIZARD LATHE - retrofitted in 1992
