Erowa Powerchuck and pallets Ø148

Erowa

Year of construction: 2007, condition: ready for operation (used), overall weight: 1,300 kg, number of axes: 3, This 3-axis EROWA Robot Easy Automation was manufactured in 2007. It features a maximum load capacity of 1500 kg and a magazine plate with 6 positions per level. The machine has a Z-axis travel of 75 mm and an M-axis capable of 360° movement. If you are looking to get high-quality automation capabilities, consider the EROWA Robot Easy Automation system we have for sale. Contact us for further details. • Maximum Load Capacity (Magazine): 1500 kg • Magazine Plate Type: MTS 400 • Magazine Capacity: 6 Positions per Level • Maximum Load per Level: 1500 kg • Maximum Load per Position: 250 kg • Maximum Transfer Weight (RCS 5): 250 kg • Maximum Transfer Weight (RCS I): 130 kg • Required Coupling for Loads >130 kg: RCS 5 Coupling with RCS 5 Gripperlink ER-038622 • Supply Voltage: 3 × 400 VAC ±10% / 3 × 208 VAC ±10% / 3 × 480 VAC ±10% • Frequency: 50/60 Hz • Power Rating: 710 VA • Nominal Current: 1.8 A • Fuse Protection: 10 ATT • Service Socket Voltage: 230 VAC • Minimum Pneumatic Pressure: 5 bar • Minimum Air Consumption: 200 l/min (Nameplate) • Pneumatic Air Quality: Dry, Oil-Free • X-Axis Travel: Type Dependent • Z-Axis Travel: 75 mm • M-Axis Rotation: 360° • Z-Axis Drive: Pneumatic • M-Axis Drive: Electric • Net Weight: 1300 kg • Interface Type: EROWA Standard Interface • Communication Interface: RS232 • Optional Communication Interface: RS422 • Interface Connector: 72-Pin Harting Connector • Communication Protocol: EROWA EWIS Protocol • Alternative Communication Protocol: EROWA Standard Protocol • Robot Door: Pneumatic Door Valve Kit Todpfezcdwdjx Aired • Pneumatic Connection: Standard • Electrical Connector: Harting 6-Pin (230 V) • Electrical Connection: 230 V (Phase 1 + 2) • Machine Condition: No Longer Connected to Power • Viewing: Available

Year of construction: 2014, condition: excellent (used), DMG PH 150-8 . year of construction 2014 . with pallets . Tsdpfx Aijin Dklorsd Touch screen . plant in very good condition .

Condition: excellent (used), functionality: fully functional, Year of construction: 2020, For sale is an automation cell from the brand EROWA, type Robot Dynamic 150 Linear (ERD 150L), including the process control system JMS 4.0 MoldLine. With the exception of the gantry eroding machine, all production and measuring machines have already been sold. Only the EROWA automation is offered; the Gantry Eagle 500 can be offered separately. The system was put into operation in mid-2020 and is in very good and well-maintained condition. Technical data: Year of construction: 2020 Control / control system: JMS 4.0 MoldLine from Certa Systems Magazine capacity (total): - 20 pallet spaces for PARTOOL clamping system - 360 spaces for EROWA ITS 50 Turret rotation radius: -30° to +300° Transfer weight max.: 150 kg Identification system: EWIS 10 (ID chips) Loading station: Yes, with rotary table Tedpsz Szh Njfx Airsd Safety enclosure: Yes, according to layout Acceptance: Complete CE acceptance Included in the offer: 3 gripper arms and grippers with RCS coupling, as well as RCS gripper S, support gripper for ITS 50, collection tray on the rotary turret, gripper station (Gripper Dock), software license for Robot Dynamic 150 L, machine interface box including interfaces, loading station, enclosure including all elements and doors, CMM - light curtain system. Note regarding tooling & coaching: The chucks, adapter pallets, vices, Partool tooling, and EROWA ITS holders are NOT included. Coaching by EROWA Automation is not included in the scope of delivery. Upon request, transport and loading can be organized throughout Europe for an additional charge. Prices do not include VAT. Inspection is possible by appointment. Contact us, our team will be happy to assist you. Trade-in or exchange possible! Machine buying and selling PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Do you need a high-quality but affordable metalworking machine for your production? Or do you want to sell yours? For more information or contact options, visit our website.

Condition: ready for operation (used), Year of construction: 2020, total height: 2,700 mm, travel distance X-axis: 600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 500 mm, overall weight: 2,350 kg, product length (max.): 2,100 mm, number of axes: 3, This 3-axis EROWA CMM Qi was manufactured in 2020. It features a travel range of 600mm on the X-axis, 700mm on the Y-axis, and 500mm on the Z-axis. The machine can handle a maximum workpiece weight of 650kg and includes advanced components like the PH10MQ touch probe system and FCR25-L6 touch probe changer. Ideal for precise measurements in quality control processes. Contact us for more information about this machine. • Max. distance between table and probe holder (without probe): 668 mm • Max. distance between columns at table height: 650 mm • Usable granite slab area: 650 x 1700 mm Todsx D Hvqjpfx Airod • Max. loadable workpiece weight: 650 kg Additional equipment • PH10MQ touch probe system with SP25M-2 • FCR25-L6 touch probe changer • ARCO Presoft software

Year of construction: 1999, condition: like new (used), functionality: fully functional, Manufacturer: Arthur Klink Year of construction: 1999 Type: horizontal broaching machine Model: RIW 10x1600x400 Weight: 2.700 KG General / technical data: horizontal hydraulic internal broaching machine in mint condition with tool holding system ideal for the use of flat broaching tools. Broaching stroke: 1.600mm Tractive force: 10,000 kg (100kN) Mounting in the drawbridge: Ø 85mm Cylindrical Through-hole in the clamping table: Ø 100mm Workpiece diameter: max. 400mm (due to the machine body of the tool trough) Cutting speed: hydraulically infinitely variable from 1.0 m/min to 9 m/min Return speed: hydraulically infinitely variable from 1 m/min to 24 m/min Space requirement of the machine: (w x d x h) approx. 6,400 mm x 1,450 mm x 1,600 mm (without working area) Power supply: 400Volt 50 HZ Connected load: 9kw Equipment: - the machine has an electric control for the clearing stroke movement with manual operation and automatic sequence - the machine has an integrated coolant system - the machine has a tool holding system for flat broaching tools (no feed) - The broaching carriage with the pulling head holder is equipped with a flat guide on both sides Tjdpfsr A Hcbex Airjd Accessories - 1 universal pulling head for flat shanks from 3mm to max. 25mm wide and a maximum pulling force of 10kN (10,000kg) - Complete machine documentation and CE declaration of conformity Remarks: The machine is ideal for the production of keyways. Due to the connection with the stable machine bed of the machine and the broaching tool holding system, the machine is particularly suitable for quick and easy use of flat broaching tools. The machine has been used very little and is in mint condition. The machine is available for inspection in our warehouse and is ready for demonstration under power. Our direct contact details and further information about the machine can be found in the attached PDF document

Condition: used, Year of construction: 2003, operating hours: 81,060 h, functionality: fully functional, machine/vehicle number: 921083, workpiece weight (max.): 750 kg, travel distance X-axis: 350 mm, travel distance Y-axis: 220 mm, travel distance Z-axis: 220 mm, total height: 2,000 mm, total length: 2,020 mm, total width: 2,050 mm, wire diameter (max.): 0.3 mm, workpiece height (max.): 220 mm, workpiece width (max.): 550 mm, workpiece length (max.): 1,000 mm, type of input current: three-phase, table width: 450 mm, table length: 680 mm, table height: 1,000 mm, empty load weight: 2,450 kg, table load: 750 kg, input voltage: 400 V, tank capacity: 760 l, distance table to quill: 220 mm, input frequency: 50 Hz, input current: 18 A, Equipment: documentation/manual, The table has a hard chrome finish. In addition, we also sell the matching EasyChange XT 4-position workpiece changer from Erowa; see the nameplate for the model. Tsdpfx Aijz Spd Isrod Pick-up only.

Condition: used, Good day, We are offering used clamping devices from Erowa. These are part of the Erowa UPC system and are suitable for die-sinking EDM and milling. The following parts are available: Tedpfstk Haksx Airod ER-048377 UPC Alignment pallet Erowa T-slot pallet 320x320 Base body made of aluminum, bars hardened and ground. ER-016917 UPC Aluminum pallet 320 x 320 x 40 with clamping bar They have been cleaned and checked by us. A functional test was also carried out. The clamping devices have signs of use and are technically in very good condition. Individual acceptance also possible. Spare parts are available. Do you have any questions? Then please do not hesitate to contact us.

Condition: ready for operation (used), Year of construction: 2010, controller manufacturer: MAZATROL, controller model: MATRIX, This 3-axis Mazak QTN 250 M X 1000 horizontal turning machine was manufactured in 2010. If you are looking to get high quality turning capabilities consider the Mazak QTN 250 M X 1000 machine we have for sale. Contact us for more information. Tjdpfxsyalpcj Airsd Machine Benefits Technical Machine Benefits • Max. Capacity: 640 • X-axis rapid traverse speed: 36000 / z-axis rapid feed speed: 36000 / c-axis rapid feed speed: 555 • Machinable diameter: 380 • Maximum machinable length: 600 • Bar capacity: 76 • Self-centring dimensions (main spindle): 250 • Stroke: 1000/cone: cm 4 • Coolant tank: 300 l

Condition: used, Good day, We are offering used clamping beams from Erowa, System 3R and Becker Erodiertechnik. These clamping beams are suitable for wire erosion. The following parts are available: ER-017646 ER-017647 ER-017648 ER-021128 Todstk N E Aspfx Aired ER-021127 System 3R 3R-239-545-9911-V01 Becker erosion technology SB430-SB680 The clamping devices have signs of wear and are in very good technical condition. Individual acceptance also possible. Spare parts and accessories are available. Do you have any questions? Then we are at your disposal.

Condition: excellent (used), Hello, we offer used Erowa PalletSetW vices. They have been cleaned and checked by us. ER-025895 Vice PalletSet W 40mm ER-054922 flat vise 8mm PalletSet W Tjdpeitcq Tsfx Airod ER-055774 Vice 0-170mm In addition, a functional test was carried out. The vices have slight signs of wear and are technically in very good condition. Individual purchase also possible. Spare parts are also available Do you have any questions? Then we are at your disposal.

Year of construction: 2007, condition: ready for operation (used), Cutting range round: 560mm, cutting range flat (W x H): 620/560mm, material feed length, single: 900mm, multiple feed: 9999mm, shortest cut length: 6mm, minimum diameter to be cut: 15mm, minimum remnant in single cut: 15mm, shortest remnant length in automatic mode: 80mm, saw motor power, frequency-controlled: 5.5kW, cutting speed, stepless: 13-127m/min, saw blade dimensions: 7400/54/1.6mm, material support height: 700mm, total drive capacity in basic configuration: 12kW, length: 2370mm, width: 3610mm, overall dimensions with chip conveyor (L/W): 2370/3610mm, machine table height lowered: 2230mm, weight: approx. 5.2t with chip conveyor. An inspection on site is possible. Tedpfx Aijxg Rhvjrod

Condition: refurbished (used), Hello, We are offering rebuilt ER-093996 square 15 holders C from Erowa. The holders were converted from the old version ER-007986 without gripper grooves and sealing plate. We completely disassembled, blasted, cleaned, and readjusted them. Tedjwa I Hrepfx Airod You are also welcome to send us your holders for rebuilding or overhaul. We are happy to answer any questions or provide technical assistance.

Condition: good (used), Good day, we offer here used clamping devices from Erowa. These belong to the PalletSet W and are for Wire EDM machining. The following parts are available: Fixed holder ER-030678 Floating holder 3D ER-030923 They have been cleaned and tested by us. In addition, a functional test was carried out. The clamping devices have slight traces of use, and are technically in a very good condition. Individual acceptance also possible. Spare parts are available. Do you have any questions? Then we are at your disposal. Tjdpsp Eb Dvefx Aired

Condition: good (used), drilling depth: 1,500 mm, feed length X-axis: 2,000 mm, feed length Y-axis: 1,300 mm, feed length Z-axis: 1,500 mm, Manufacturer: TBT deep drilling technology Type: BW 250-S Control: SIEMENS 840D Year of manufacture: 2007 Drilling, Milling, Tapping for heat exchanger bases and plates Swivable A Axis + 25 to - 15 Degrees Filtration and Coolant system 1000 L Cip conveyor 2000 x 1200 height out put Milling tool changer Tower Station 20 positions Capacity ELB Drilling 3 - 35 mm Capacity Milling 250 ccm/Min Feed rates all axis 15,000 mm/Min X-Y-W-Z Cutting hours approx. 15,000 Large tooling package Specifications Metric US Standard Max. Drill Ø steel 40 mm Drilling depth 1500 mm X - axis 2000 mm Y - Axis 1300 mm Z-axis 1500 mm W-axis 750 mm Table load 15000 Table dimensions / L x W or ø 1600 x 1200 mm Spindle mount HSK 63 Mk Spindle power 11 kW Speed 8000 Rpm Dimensions (estimate) Length 7200 mm Width 7800 mm Height Tedev A Uw Dopfx Airjd 4250 mm Weight 23000 kg Please note: The information on this page is believed to be accurate and is provided by us and, where possible, from the manufacturer. The information is provided in good faith but accuracy cannot be guaranteed. Accordingly, it will not constitute a representation or contractual terms. We recommend that you check all important details.

Condition: refurbished (used), functionality: fully functional, Hello, Tjdpewa Sffsfx Airsd We are offering rebuilt ER-093996 Square 25 Holder C from Erowa. The holders were converted from the old version ER-010607 without gripper grooves and sealing plate. We completely disassembled, blasted, cleaned, and readjusted them. Including clamping spigots. You are also welcome to send us your holders for rebuilding or overhaul. We are happy to answer any questions or provide technical assistance.
