Swiss type lath MANURHIN K'MX 920 CLEVER

Condition: ready for operation (used), Year of construction: 2008, operating hours: 9,965 h, - USED - 3-AXIS VERTICAL MACHINING CENTRE WITH ROTO-PALLET X-AXIS TRAVEL: 560 mm Y-AXIS TRAVEL: 400 mm Z-AXIS TRAVEL: 570 mm DISTANCE SPINDLE NOSE-TABLE: 210 - 780 mm RAPID FEEDS X-Y-Z: 40 - 40 - 32 m/min SPINDLE: 80-10000 rpm; 15-18,5 kW; ISO 40 - BT Casdeq Nqkxjpfx Addoa PALLET: N.2 ; 712X475 mm MAX ADMITTED LOAD: 300X2 Kg HIGH PRESSURE COOLANT: 15 Bar TOOL MAGAZINE: CHAIN-TYPE ; 32 POS MAX TOOL DIAMETER: 90(150) mm MAX TOOL LENGHT: 300 mm MAX TOOL WEIGHT: 8 Kg CONTROL UNIT: FANUC 21i - MB WEIGHT: 7600 Kg OVERALL DIMENSIONS: 3010 x 3450 x 3145 mm

Condition: good (used), Year of construction: 2004, spindle passage 60 mm turning length 280 mm control 840 D Siemens turning speed range - drive spindle 6300 U/min drive capacity - spindle motor 3,3 kW turret 1 Scheibenrevolver no. of tools in turret 1 8 worktool system DIN 69 880 / 25mm x-travel 90 mm z-travel 280 mm feed power 5500 N rapid traverse 24 m/min power capacity - milling spindle 5000 kW turret Schwalbenschwanz no. of tools in turret 2 6 x-travel 81 mm z-travel 80 mm feed power 5500 N rapid traverse X-axis 16 m/min rapid traverse Z-axis 24 m/min weight of the machine ca. 2,5 t dimensions of the machine ca. 6,0 x 2,0 x 2,0 m TThe INDEX ABC machine is a compact lathe for short turned parts made from bar stock. It has an inclined bed design with two independent turrets. The top turret is primarily intended for internal machining and machining, while the lower turret is used for external machining. The turret arrangement enables collision-safe working and simple programming programming with high tool availability. The large free space in the working area enables a favourable chip fall The work area consists of two turrets: ‘Turret 1’ - Disc turret with 7 radially arranged tool holders Ø 25 mm DIN 69880 and a holder for the reinforced synchronised spindle on the turret station 8. tools with 1’ holders can also be used with an equalising holder can also be used. The turret is prepared for the V-ledge system. - Synchronised spindle for rear end machining, simultaneous parallel machining with main spindle. Ø42 collet chuck or 3-jaw gripper chuck for internal and external clamping and external clamping. Jaw stroke 0.6 mm. Clamping diameter (external) 75 mm. - Back-boring device. Starting from the centre of the working spindle in clockwise direction, 3 stationary back-boring tools are back boring tools are arranged. These are located in the pitch circle of the synchronised spindle. The back machining is carried out simultaneously with the machining on the the working spindle. Two additional tools can also be used, can be equipped with a tool feed drive. ‘Revolver 2’ - Turret with 6 symmetrical dovetail holders and each station with 2 locating holes for cylindrical shank per station. The following tool systems can be used. - stationary tools that can be moved in the Z direction - Driven tools with cylindrical shank Ø25 (can be used in two positions per station) can be used) - including bar loader LM 3200 - + various accessories (various Ø guide half-shells/tool holders) Technical data: - Material bar diameter: (Ø 25 / Ø 36 / Ø 52)- --> round Ø 8 - 25.4 / 8 - 36 / 8 - 52 mm --> square SW Ø 6 - 14 / 6 - 20 / 6 - 20 mm --> hexagon SW Ø 7 - 22 / 7 - 30 / 7 - 41 mm --> octagonal SW Ø 7 - 22 / 7 - 32 / 7 - 40 mm Codpfx Aswbvhajddoaa --> bar length max. 3200 mm --> from bars Ø 25 mm, min. 2,500 mm --> up to rods Ø 25 mm, min. 1,500 mm --> bar support = approx. 300 = 6 bars Ø 52 mm Mass (bar loader) = 700 kg

Condition: used, Year of construction: 2006, functionality: fully functional, turning length: 780 mm, turning diameter: 270 mm, spindle motor power: 15 W, travel distance X-axis: 195 mm, travel distance Y-axis: 120 mm, travel distance Z-axis: 780 mm, Nakamura-Tome WT-300 CNC Lathe Year of manufacture: 2006 CNC Control: FANUC Series 18i-TB Machine weight: 12,000 kg Machine dimensions: Length: 5,230 mm Width: 2,500 mm Height: 2,300 mm Machining capacities: Max swing diameter over upper/lower carriage: Ø 310 mm (upper and lower) Distance between spindles (min - max): 120 mm – 1,200 mm Max turning diameter, main spindle/sub-spindle: Ø 270 mm Max turning length: 780 mm Spindle/bar capacity, main spindle/sub-spindle: Ø 65 mm Axis travels: X1 / X2 Axis: 195 mm Y Axis: 120 mm (±60 mm) Z1 / Z2 Axis: 780 mm B Axis: 850 mm C Axis: 360° (continuous) Main spindle and sub-spindle: Spindle speed: 50 – 4,500 rpm Spindle nose: ASA A2-6 Chuck diameter: Ø 225 mm Minimum programmable C-axis increment: 0.001° Motor power (cont. / 30 min.): 11/15 kW (both spindles) Turret No. 1 & No. 2 (identical): Static/tooling stations: 24 stations (12 live tooling) Live tooling speed: 3,600 rpm Live tooling motor power: 3.7 / 5.5 kW Turning/boring tool size: 25×25 mm / Ø 32 mm Rapid traverse rates: Csdowx Hicjpfx Addsaa X1 / X2 / Y Axis: 16,000 mm/min Z1 / Z2 Axis: 24,000 mm/min B Axis: 36,000 mm/min C Axis: 100 rpm B Axis: 27,000 mm/min Included accessories: LNS bar feeder model MOVE (length capacity 2,300 mm) Chip conveyor Coolant collection tank with wash-down pump High-pressure pump with external coolant tank Various fixed and driven tool holders Tool presetting arm with dual-head RENISHAW interface Part unloading arm Manuals, electrical diagrams, and EC Declaration

Condition: used, Year of construction: 2015, TAKISAWA TS4000YS year 2015 CNC control FANUC 32i-MODEL B Max. turning diameter 315 [mm] Max. swing over bed 600 [mm] Max. Turning length 735 [mm] Stroke X axis 267 [mm] Stroke Z axis 840 [mm] Stroke Y axis -50 [mm] / +70 [mm] Stroke A axis 780 [mm] Rapid traverse rate X axis 30000 [mm/min] Cedpfx Adjwq Sf Todeaa Rapid traverse rate Z axis 30000 [mm/min] Rapid traverse rate Y axis 10000 [mm/min] Rapid traverse rate A axis 30000 [mm/min] Spindle nose A2-8" Max. bar diameter 82 [mm] Spindle throughbore 94 [mm] Max. spindle speed 4200 [rpm] Spindle power 22 [kW] Counter spindle nose F140 Counter spindle throughbore 53 [mm] Max. counter spindle speed 6000 [rpm] Counter spindle power 11 [kW] Max. tool holder cross-section 25 [mm] Number of tool stations 15 Number of tool stations driven 15 Max. speed driven tools 6000 [rpm] Lubrication tank capacity 370 [l] Total power required 37 [kVA] Supply voltage 400 [V] Chip conveyor with machine 5 live tool holders Weight 6700 [Kg]

Condition: used, TECHNICAL DETAILS - Number of axes : 9 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 32 [mm] - Travel : 310 [mm] - Spindle speeds : 280 - 7.000 [rpm] - Spindle power : 7,5 [kW] - C axis indexing precision : 0,01 [°] COUNTER-SPINDLE - Max. bar diameter : 32 [mm] - Z stroke : 150 [mm] - Spindle speeds : 280 - 7.000 [rpm] - Spindle power : 3,7 [kW] - C axis indexing precision : 0,01 [°] - Number of turrets : 1 UPPER TURRET - Number of positions : 10 - Number of motorized positions : 10 - Live tools speed : 5.700 [rpm] - Live tools power : 2,8 [kW] Cedpsuha Elofx Addoaa GUIDE BUSH HOLDER 1 - Number of positions : 4 - Number of motorized positions : 3 - Live tools speed : 6.000 [rpm] POWER SUPPLY - Supply voltage : 200 [V] - Total installed power : 8 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.645 x 1.403 [mm] - Machine height : 1.680 [mm] - Machine weight : 3.880 [kg] EQUIPMENT - CNC : Fanuc 16 iTB - 3 colors status lamp - Parts catcher - Parts conveying strip - Chips conveyor - Coolant tank - Bar loader : IEMCA BOSS 432/32LL - Electric transformer

Condition: new, sheet thickness steel (max.): 4 mm, - Capacity 4 mm Codsgg Nq Hepfx Addeaa - Adjustment of the hydraulic roller - foot switch - Brake motor - With 4 roller sets - Emergency stop - 400V

Condition: used, Year of construction: 2010, Technical details: x-travel: 800 mm y-travel: 685 mm z-travel: 630 mm c-axis: 360° (Planscheibe-Tisch) control: Siemens 840D Power Line spindle speed:: 20 - 10.500 U/min max. torque on the spindle: 180 Nm tool taper: HSK -A63 DIN 69893 tool changer with: 40 places Csdpfxeu Idgpe Addjaa no. of tables: 2 table swivelabel +/-: je 120 (a-Achse) ° table surface area: 280 x 275 mm table load capacity: 320 kg interface: RS232 spindle hours: 38.700 h Total power requirement: 37 kW dimension machine xH: 4,0 x 4,4 x 3,0 m dimensions LxWxH: Späneförderer: 2,1 x 1,05 x 1,5 m dimensions L x W x H: Kühlschmieranlage: 1,3 x 1.6 x 1,95 m 5 - axis machining center CNC machining center Clamping table for 4th and 5th axis (swivel 120° right/left/speed 50 rpm and turn with faceplate Ø 280mm/200 rpm) max. workpiece size 940 x 650mm for/on table with chip conveyor make Knoll, 750 K-1/150; year of manufacture 2009 Bürener coolant system with paper belt filter belt width 700mm; year of manufacture 2009 for both control cabinets with cooler Rittal Accessories exclusive i.D. *

Condition: good (used), Manufacturer ESTARTA Model 301 MV Condition Used Stock number 4576 Location Badajoz, Spain Dimensions 1520x1020x1260mm Weight 1550 kg Opening between grinding wheels 1,5/50mm Max. grinding wheel width in plunge grinding plunge 125mm Dimensions of the Caodpor Ezfpjfx Addja working wheel (od x id x width) 300x125x175mm Øext.min. working wheel working wheel 220mm Max. depth of profile of working profile depth 8mm Dimensions of the driving wheel (od x id x width) 220x125x125mm Øext.min. of driving wheel drive wheel 165mm Max. depth of profile of the driving wheel profile depth 8mm Grinding wheel motor power motor power 7,5Kw Motor power of grinding wheel driving motor power 0.75Kw Tilting angle angle of working working +/- 5º

Condition: excellent (used), Complete steel structure of the production hall. Codpfx Aexu E Igsddoaa Dimensions - 31.5 x 30 x 9.85 m with the corresponding ROOF sandwich panels made of insulating panels. NOTE - hall is WITHOUT WALL PANELS The hall was built in 2010. In excellent condition! The total weight of the structure is approx. 60 tons. The structure is protected with primer and varnish. The outer columns are made of IPE 500 profile, and the middle one is made of IPE 600. The hall has preparation for a crane track. A project and static calculation have been made for the hall. The hall has been disassembled and transportation and loading can be arranged.

Condition: excellent (used), CNC-swiss type automatic lathe brand: STAR type: SR-38B new in: 2017 equipped with: FANUC 31i - B control subspindle back working driven tools 2x c-axis programmable b-axis Cjdpfsxl Etqjx Addjaa y2-axis x3-axis switchable between guide bush and non-guide bush modes high pressure pump ol mist parts conveyor chip conveyor fire extinguishing system automatic barloader FMB LSK 38
