Used Stepless Toolmaker's Lathe for sale (6,914)

Condition: like new (used), Year of construction: 2021, functionality: fully functional, Weiler Praktikant VCD Precision Lathe (2021) Manufacturer: Weiler Model: Praktikant VCD Precision Lathe Year of manufacture: 2021 Condition: Used, excellent, like new, incl. new maintenance and measurement protocol prior to sale Centre distance: 650 mm Centre height: 160 mm Swing over bed: 320 mm Swing over cross slide: 190 mm Cross slide travel: 150 mm Top slide travel: 110 mm Top slide swivel range: +/-65° Bed saddle guideway length: 350 mm Bed width: 205 mm Tool shank cross-section (H x W): 20 x 20 mm Height from top slide to turning centre: 30 mm Spindle head according to ISO DIN 702-3 (DIN55027) size 5 Spindle diameter in front bearing: 70 mm Spindle bore: 43 mm Main spindle taper metric 50 Drive power: 6 kW Speed range: 30 – 4,000 rpm Number of gear stages: 1 Number of speeds: stepless Todpsztyrqefx Abtjb Number of feeds: 24 Longitudinal feed: 0.02 – 0.63 mm/rev Facing feed: 0.006 – 0.2 mm/rev Quill diameter: 40 mm Quill stroke: 85 mm Quill taper: 3 Morse taper Weight, without packaging and accessories: approx. 1,150 kg Dimensions (L x W x H), net: 1,720 x 890 x 1,700 mm Headstock / Rear cover / Sliding guard: Light grey RAL 7035 Machine base / Machine bed: Basalt grey RAL 7012 Display housing: Blue NCSS 4550-R80B

Condition: used, Year of construction: 1989, functionality: not functional, turning length: 600 mm, turning diameter: 350 mm, spindle bore: 105 mm, spindle motor power: 22 W, total length: 3,063 mm, total width: 1,660 mm, overall weight: 4,300 kg, Equipment: documentation/manual, The machine is not functioning due to a fault in the regulator. All the machine's mechanical properties are perfect. The machine is very rigid and can achieve tolerances as tight as 0.01 mm. It can also be used as spare parts. Tsdpfxozwdame Abtob

Condition: used, Swiss-type cnc lathe TRAUB TNL 12K Tedpfjzxignjx Abtob

Condition: used, Swiss-type cnc lathe TRAUB TNL 12K Tsdpozxiiiofx Abteb

Condition: used, Swiss-type cnc lathe TRAUB TNL 12K Tedpfx Ajzxiivobtob

Condition: used, Swiss-type cnc lathe TORNOS DELTA 20/5 III Tedpfx Aszxikmsbtob

Condition: used, Swiss-type cnc lathe TRAUB TNL 12K Tjdpfxszxuc Uo Abteb

Condition: like new (used), Year of construction: 2018, operating hours: 3,621 h, functionality: fully functional, machine/vehicle number: ML272-000046, turning length: 1,074 mm, turning diameter: 550 mm, spindle bore: 102 mm, spindle speed (max.): 3,000 rpm, spindle speed (min.): 30 rpm, travel distance X-axis: 300 mm, travel distance Z-axis: 1,080 mm, spindle motor power: 35,000 W, type of input current: three-phase, overall weight: 9,450 kg, mount diameter: 32 mm, The machine is in very good condition, maintains new parameters and accuracy. Can be tested. No warranty of any kind. Data subject to error. Sale reserved until deposit is received. Tedpfsvri I Aex Abtob

Year of construction: 2001, condition: excellent (used), Multispindle lathe Schütte AG20 Tedpfx Abjhrihysteb

Year of construction: 1996, condition: good (used), Mehrspindel Schütte SG18 Todpsg S Tx Iofx Abteb

Condition: ready for operation (used), Year of construction: 1985, Mazak Slant Turn 40 MC CNC lathe with chip conveyor. Year of manufacture 1985, weight 8 tons. Control system Mazatrol T3, with three-jaw chuck, tool turret, tailstock. Ready for use, can be viewed while still powered. Tjdovzgyhepfx Abteb

Condition: good (used), Year of construction: 2006, control FANUC 21i-TB Control x-axis 390 mm z-axis 780 mm spindle taper A2-11 number of spindle speeds 2000rpm engine output 37 kW Tsdpfovzln Rsx Abteb weight of the machine ca. 9000 kg dimensions of the machine ca. 1905,0 × 2720,0 × 3260,0 m The machine has chucks that can produce gears from 100 to 500 mm. Special chuck is available

Condition: good (used), Year of construction: 1998, Circulation/rotation Ø over bed 475 mm Rotation/rotation Ø via cross slide 260 mm Sledge path plan 260 mm centre distance 1500 mm power capacity 22 kW Gear stages. m= manual / e= electric. 2 e Spindle head DIN 55026 / DIN 55027 A6 / 6 Spindle Ø in front bearing 115 mm spindle bore 78 / 70 mm turning speed range (V-constant) 1 - 3.000 U/min feed range flat 1µ - 1.000 mm/U feed range lengthwise and thread 1µ - 2.000 mm/U Rapid traverse plan/longitudinal 5 / 10 m/min diameter of quill 70 mm quill travel 120 mm quill inner cone 5 MK This machine is used for the production of individual parts and small batches from simple to the most complex contours. It is characterised by: Tsdpfxowgn Ago Abteb --> Ease of operation Precision Working range

Condition: new, Year of construction: 2023, functionality: fully functional, DN Solutions PUMA 5100MB – NEW, UNUSED MACHINE! Year: 2023 Fanuc Oi-TF 15” control Tjdpfozpw Dpex Abtjb C-axis powered tool 21-inch chuck (535mm) Spindle bore: 166mm 12-position BMT75 turret Max. turning diameter: ø 650 mm Max. turning length: 952 mm Prepared for steady rest support Tailstock Tool probe CROMAR chip conveyor 12 tool holders, including 4 powered tool holders (2/2)

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, turning length: 145 mm, turning diameter: 168 mm, travel distance X-axis: 130 mm, travel distance Y-axis: 110 mm, controller model: FANUC 31i-TA, TECHNICAL DETAILS Turning diameter: 168 mm Turning length: 145 mm X-axis travel: 130 mm Z-axis travel: 110 mm Spindle speed: 45–6,000 rpm MACHINE DETAILS Control system: FANUC 31i-TA EQUIPMENT 2 × Portal clamping system 2 × Part chute for inspected parts 2 × 3-jaw chuck, SMW Autoblok, Type BHM 165, 152.4 mm (6 inches) SMW Autoblok hydraulic cylinder, Type SIN-S 100, left SMW Autoblok hydraulic cylinder, Type VNK 70/37, right Chip conveyor, discharging to the rear of the machine Air-controlled part clamping monitoring, right Part clamping monitoring, on both sides 4-position spindle orientation, on both sides Coolant injection in the chuck via Deublin rotary distributor, on both sides Automatic coolant pump with 200 l tank capacity Tjdpfx Aszul Ruebtjb 2 × 8-station turret Signal light with traffic light design Preparation for oil mist extraction Automatic machine shutdown Automatic central lubrication RS-232-C interface External transformer 10 × Boring bar holders 3 × Turning tool holders, right 3 × Turning tool holders, left Customer macro B Turning cycles

Condition: used, Year of construction: 1996, functionality: limited functionality, turning length: 330 mm, turning diameter: 248 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 370 mm, travel distance Z-axis: 190 mm, TECHNICAL DETAILS Turning diameter: 248 mm Turning length: 330 mm Travel range, X-axis: 370 mm Tsdpfxszul Ums Abteb Travel range, Z-axis: 190 mm Spindle bore: 45 mm Spindle speed: 6,000 rpm Tailstock quill travel: 120 mm Note: A switch on the X-axis needs to be reset.

Condition: excellent (used), Year of construction: 2007, operating hours: 11,000 h, functionality: fully functional, turning length: 500 mm, turning diameter: 240 mm, spindle bore: 65 mm, spindle speed (max.): 4,000 rpm, travel distance Y-axis: 40 mm, spindle motor power: 15 W, Working length 500 mm Max. working diameter 240 mm Spindle speeds 4.000 rpm Spindle bore 65 mm Number of tools 12 pcs Y-travel +/- 40 mm Control FANUC 18 i TB Running hours 5.000 Todpeycubtsfx Abtsb Main motor power 15 Kw

Condition: used, Year of construction: 1991, total length: 10,730 mm, total width: 1,600 mm, total height: 2,400 mm, Colour: Green Empty weight: 12.000 kg Price: On request - Year: 1991 - Documentation available: No - CE certificate present: No - Serial number: 0443848 - Drive system: Conventional - Power [kW]: 30.0 - Centre height [mm]: 625 - Swing over bed [mm]: 1250 - Carriage turning diameter [mm]: 1100 - Distance between centres [mm]: 8000 - Bed width [mm]: 800 - Spindle bore [mm]: 110 - Min. spindle speed [rpm]: 1.8 - Max. spindle speed [rpm]: 355 - Options: Fixed steady, Four-jaw chuck, Three-jaw chuck - Transport dimensions: 10730mm x 1600mm x 2400mm (l x w x h) - Transport weight [kg]: 12000kg - Transport packages [pcs.]: 3 Tsdpfxoy E Imvo Abtjb Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 2018, LNS QUICK LOAD SERVO III, year 2018 Tsdpfxszpyq Eo Abteb in very good condition.

Condition: used, Year of construction: 2015, Swiss-type CNC lathe TSUGAMI B0206E-III Tsdpfx Abezp D Uueteb TECHNICAL SPECIFICATIONS: Year of manufacture: 2015 CNC control: FANUC series 32i-B Number of axes: 6 Rapid traverse rate, X1 axis: 24,000 mm/min Rapid traverse rate, X2 axis: 24,000 mm/min Rapid traverse rate, Z1 axis: 32,000 mm/min Rapid traverse rate, Z2 axis: 32,000 mm/min Rapid traverse rate, Y1 axis: 15,000 mm/min Rapid traverse rate, Y2 axis: 15,000 mm/min Max. bar diameter: 20 mm Minimum spindle speed: 200 rpm Maximum spindle speed: 10,000 rpm C-axis resolution: 0.001° Spindle power: 3.7 kW Minimum counter-spindle speed: 200 rpm Maximum counter-spindle speed: 12,000 rpm C-axis resolution of the counter-spindle: 0.001° Counter-spindle power: 2.2 kW Number of positions in the front tool holder: 8 Number of positions in turret 1: 5 Number of driven positions in turret 1: 3 Speed of driven tools in turret 1: 8,000 rpm Number of positions for secondary machining: 8 Number of driven positions for secondary machining: 4 Speed of driven tools for secondary machining: 8,000 rpm Maximum cross-section of the tool holder: 12 x 12 mm Weight: 1,750 kg

Condition: used, Year of construction: 2001, TSUGAMI BS26-III with Iemca bar feeder Tjdszp Eddspfx Abtjb Fanuc control Year 2001

Condition: used, Year of construction: 1999, turning diameter / mm turning length / mm Tedpfozu A Ttsx Abtob control /

Condition: used, Year of construction: 2001, turning diameter: 210 mm, spindle bore: 53 mm, travel distance X-axis: 195 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 700 mm, rotational speed (max.): 6,000 rpm, overall weight: 6,500 kg, distance table center to spindle nose: 960 mm, OKUMA OSP-U100L control unit, with TOP AUTOMAZIONI XF370 bar feed system. Todpfx Abjzw Nu Nstjb Workholding and tooling are not included. MUST BE PICKED UP BY SEPTEMBER 2026.

Condition: as good as new (ex-display), EXHIBITION MACHINE For sale is a like-new Drechselmeister Stratos FU 230 lathe with a center distance of 680 mm and a 2 HP motor. The exhibition machine is in its original condition, so you will receive the full warranty. Technical specifications: - Center height 230 mm - Swing diameter 455 mm (with optional external turning attachment 800 mm!) - Center distance approx. 680 mm (extendable!) - Spindle connection M33 x 3.5 (hardened) with ASR (Euro) drain safety groove* - Spindle and tailstock taper MK2 - Speeds (2 belt stages): 60 – 1,350 rpm and 180 – 3,750 rpm - Quill travel 100 mm (with scale and trapezoidal thread) - Motor 2 HP (connection 230 V) - Weight 178 kg The machine is located in A-5431 Kuchl and can be inspected at any time during our opening hours. Subject to prior sale! Freight shipping: Todpfxezwt H No Abteb Austria: €95.00 incl. VAT Germany: €120.00 incl. VAT South Tyrol: €140.00 incl. VAT Freight shipping: Austria: €95.00 incl. VAT Germany: €120.00 incl. VAT South Tyrol: €140.00 incl. VAT Related terms: Lathe, turning machine, lathe, wood turning lathe, turning, turning tool, wood turning, turning, machine Reference: R-A0117

Condition: excellent (used), Year of construction: 2016, operating hours: 5,000 h, functionality: fully functional, machine/vehicle number: 60022, turning length: 250 mm, turning diameter: 42 mm, spindle speed (min.): 6,000 rpm, travel distance X-axis: 150 mm, travel distance Y-axis: 385 mm, travel distance Z-axis: 250 mm, spindle motor power: 7,500 W, total height: 1,900 mm, total length: 3,500 mm, total width: 1,900 mm, overall weight: 4,200 kg, i-42 Ultimate lathe • Number of controlled axes: 10 • Number of driven tools: 12 • Max. diameter: 42 mm • Max. length: 250 mm Tsdezwmknspfx Abtob Includes a feeder – max. length 1 m.
