Vertical machining center

Mazak MTV-655/60

Condition: used, Year of construction: 1996, x-travel 1500 mm y-travel 650 mm z-travel 650 mm size of pallet 1740 x 650 mm spindle taper SK 50 spindle turning speed range 25 - 6000 U/min feeds longditudinal/cross/vertical max. 8 mm/min rapid traverse longitudinal and cross 26 m/min rapid traverse vertical 20 m/min Dodpfx Agstqqtko Roul spindle throat 665 mm distance spindle nose and table 200 / 850 mm drilling in full material 50 mmø threading M 45 ATC 60 Pos tool diameter 125 mm wotkpiece diameter with 2 vacant positions 260 mm workpiece length 400 mm weight of tools max. 20 kg spindle drive 18,5 kW max. torque on the spindle max. 758 Nm Accessories: chip conveyor, coolant

Condition: good (used), Year of construction: 2005, Tool holder BT 40, 12.000 rpm, 60 tool places in tool changer, Dusdpfxowbaqle Ag Rol 70 bar IKZ, laser Renishaw OMI-2. Parts shown by hand not come.

Condition: like new (used), Year of construction: 2024, CNC SMOOTH AI, Travel X axis 650 mm, Y axis 550 mm, Z axis 530 mm, B axis +120° to -30°, indexation 0.0001°, C axis 360° indexation 0.0001° and continuous, Max. part diameter 730 mm, Max. height 450 mm, Spindle 18,000 rpm BT 40, 90-tool magazine, RENISHAW RMP 600 probe, 70 bar through-spindle coolant, CROMAR chip conveyor. Options: electronic handwheel, robot interface preparation, and automatic side door, simultaneous 5-axis machining and engraving function. Duedpfxexw S Raj Ag Rjl

Condition: ready for operation (used), travel distance X-axis: 750 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 725 mm, Equipment: chip conveyor, documentation/manual, 4-axis machining center, year 2016, control: Siemens 840D Solution Line, NC rotary table 360 x 0.001 degrees, 2-fold pallet changer, pallet size: 500 x 630 mm, 60-fold tool changer, HSK63 tool holder, IKZ, Knoll PF 210/1750 gravity belt filter, Hyfra TKR 30 coolant temperature control, Knoll 450 K-1 scraper belt conveyor, infrared measuring probe Dodporx Sh Ajfx Ag Rjul

Condition: used, Year of construction: 2011, Mazak HC Nexus 5000-II Mazatrol Matrix Nexus Year: July 2011 Pallet Size: 500 x 500 mm Duedpfx Aev Tvh Seg Rsl Movement: - X: 730 mm - Y: 730 mm - Z: 740 mm Spindle Speed: 12,000 rpm Tool Changer: 40 positions Chip Conveyor: Chrome

Condition: good (used), Year of construction: 2005, Parts shown by hand not come. Duodpfxevf D Ane Ag Rol

Condition: used, Year of construction: 1983, nominal force 2500 t stroke 600 mm cycle time 13 - 18 s distance between columns 1720 mm Distance table/ram, max. stroke up, adjustment up 2600 mm table surface area 1720 x 1800 mm allowed max. force 4000 t blow die to die 5000 t ram surface 2100 x 1320 mm capacity of ejector in table 40 t ejector stroke in table 250 mm ejector surface area in table 900 x 820 mm capacity of ejector in ram 6 t ejector stroke in ram 40 mm spindle diameter 425 mm power requirement 900,0 kW weight 335,0 t Dimensions (WxDxH) 3,4 x 4,6 x 9,7 m height over floor 8,3 m fully automated forging line / spindle press with automation for the production of flanged shafts for hot forming only with reversible AC motor, pneumatic brake, plate ejector in table (40 t / 250 mm), ejector in ram (6 t / 40 mm), lifting device for repositioning, marking, tool change, insertion device, tilting device, loading and unloading arm, rotary table, circular oil lubrication, centralised grease lubrication cycle time approx. 13 - 18 s Dusdpfxjwmf Tvj Ag Rel as is where is, WITHOUT putting into operation

Condition: good (used), Year of construction: 2005, Horizontal machining center Machine type: Mori Seiki NH 8000 DCG Control: Fanuc 18 imb + Mapps 2 Dodpfxsv Nhylo Ag Reul Year of construction: 2005 TECHNICAL DATA: Travels: X-axis: 1,400 mm Y-axis: 1,200 mm Z-axis: 1,200 mm B-axis: 0.001° Rapid traverse: (X/Y/Z): 50 m/min. Speed range: 10,000 1/min. Drive power: 30 / 25 kW Tool holder: BT 50 Tool changer Tool places: 140 Pallet system Number of pallets: 2 Pallet size: 800 x 800 mm Machine weight: 32,000 kg Space requirement (LxWxH): 9.200 x 4.900 x 3.920 m Equipment features: Internal cooling (IKZ): bar Chip conveyor High pressure pumps

Condition: used, Year of construction: 2000, max. workpiece diameter 40 mm min. workpiece diameter 10 mm workpiece length 200 - 640 mm Control SPS Siemens S5 95 U total power requirement 25 kW weight of the machine ca. 5 t dimensions of the machine ca. 8,5 x 2,8 x 2,35 m Hydraulic cutting and double-end machining machine suitable for pre-machining trapezoidal thread spindles and other round workpieces in the form of sawing off the bar and double-sided end machining such as chamfering, countersinking and drilling with fixed parts and rotating tools. Machine consisting of: Duedpevp Sd Iofx Ag Rel - Basic machine model TR 60/4-650, passage 640 mm - Bar magazine for bar lengths 2 - 3.5 m - Normal version for solid material up to ? 40 mm - Central position of the bar feed rollers - Bar feed unit - Feed gripper in standard version - Cross switch with 4 clamping stations model TR 300.00 - 4 base jaws, width 80/140 mm, contact ? 75 mm - Swiveling cross switch in both directions - Saw unit with worm drive TR 200.00, stroke 100 mm - Saw blade 350 mm, speed 25/39 rpm - Motor power 2.6/3.2 kW - Motorized positioning of saw head - Automatic positioning of saw stand with hydraulic. Clamping - Saw blade guide - Processing unit no. 1 - USP.00/M - Speeds 842/1684 rpm, kW 3.3/4.0 - Working stroke 80 mm - Rapid feed 40 mm - Spindle mount ISA 40/M 16 - Toothed belt drive - Machining unit no. 3 - USP.00/M - Speeds 842/1684 rpm, kW 3.3/4.0 - Working stroke 80 mm - Rapid feed 40 mm - Spindle mount ISA 40/M 16 - Toothed belt drive - Machining unit no. 4 - USP.00/M - Speeds 943/1882 rpm, kW 3.3/4.0 - Working stroke 80 mm - Rapid feed 40 mm - Spindle mount ISA 40/M 16 - Unloading chute - Millimeter bars for all adjustment movements - Hydraulic system with feed pump SAUER SUNDSTRAND - Pressure accumulator - Rexroth flow regulator for machining units and saw - Coolant system with filter and container - Coolant pump CALPERA - Electrical equipment in separate electrical control cabinet, Control voltage 24V/50 Hz - PLC SIEMENS S5 95 U - Machine light - Flashing light to signal machine downtime - Central lubrication - Chip conveyor. In 2011, an extensive mechanical overhaul was carried out to optimize positioning and centering accuracy for € 25.000. In addition, switches, some cables, ball bearings, seals, hydraulic hoses, etc. were replaced. The machine has hardly been used in recent years; the seller estimates the whole operating hours at around 24,000. Machine under power in sellers factory. Machine dealer with own stock of 1600 m².

Condition: used, Year of construction: 2008, Technical details: max. workpiece diameter: 29 mm min. workpiece diameter: 26 mm workpiece length: 66 mm the system was originally delivered for the following workpiece sizes: diameter 26mm - 29mm length 65mm - 66mm Changing parts in the clamping device, handling, etc. would probably result in diameters of up to approx. Ø50mm Total length will probably be almost 400 mm possible with a few conversions. Also dependent on tool lengths, machining lengths on the component, etc. Dusdslqac Sopfx Ag Rsl *
