Vertical strapping machine

Messersi VR88

Automatic Vertical Strapping Machine VR 88
Year of manufacture: 2008
Machine type: VR88
Machine number: 3177

The automatic vertical strapping machine VR 88 is ideally suited for strapping pallets.
It is suitable for integration into both powered and non-powered conveyor systems.

The lower lance enables the strap to be fed through the pallet.
During tensioning, the strapping head moves horizontally to compensate for tolerances, ensuring consistent strap tension and high stability.

The system control program allows for single or multiple strapping cycles, depending on the specific packaging requirements of the customer.

The machine has been fully overhauled by us and is in fully functional condition.

Technical Data
Power supply: 230 V / 400 V / 3 Ph / 50 Hz
Power consumption: 3 kW
Strap types: PP or PET
Strap width: 12 mm
Strap thickness: 0.6 – 1.0 mm
Strap tension: up to 200 kg (optionally up to 500 kg)
Fpsdpfx Aex Ta Sasg Rjb
Seal type: Hot-wedge welding
Sealing time: approx. 1 – 3 s, depending on strap type
Strap feed speed: 2.5 – 5.5 m/s
Strap retraction speed: 2.5 – 5.5 m/s
Strap tensioning speed: approx. 0.25 m/s
Strap dispenser: 405 mm core
Strap frame: 1,200 × 1,600 mm (can be rebuilt for a clearance height of 2500 mm)

When installed at the customer site, a 6-month warranty is available.

The listing was translated automatically. Translation errors are possible.
