Used Horizontal Slot Mortising Machine for sale (66,368)

Condition: new, Year of construction: 2025, GANNOMAT "MASTER 325" FRAME DOWEL AND MORTISE BORING MACHINE Specifically designed for staircase construction Complete in standard configuration according to price list 01/19/D, featuring: - Precision collet chuck for ER40 collets Ø 3-26 mm, incl. collets Ø 10 / 13 / 16 / 20 - Pole-switchable motor 1400/2800 rpm, 1.5 kW - Line laser with bracket - Boring unit, continuously rotatable from the front (65°-0°-65°) - Position setting via digital counter - Position adjustment for 2 levels, pneumatic (0-100 mm) - Maximum boring depth 200 mm - Precision indexing rail with 12 mm pitch with central detent and lateral adjustment 320 mm - Complete stop system consisting of: 1 center stop and 1 stop for oversized frames 1 stop rod, approx. 850 mm long (can be reversed from left to right) 2 flip stops - Mortising unit lowerable, with 2 program cams (400V, 3Ph, 50Hz, 1.5 kW) Extraction funnel, dust-tested, Ø 80 mm Double miter stop adjustable from 0°-60° Pneumatic clamping of the X-axis with on/off switch at the indexing handle Pair of auxiliary workpiece supports, swiveling (left and right) Clamp column re-positionable to the front Bwedjxdttpspfx Antow Chassis with 4 wheels for easy machine movement 1 piece Collet extension Ø 20 mm, incl. collet for drill shank Ø 9 mm 1 piece Baluster drill bit Ø 25 mm, chrome steel, with centering tip Available: at short notice

Condition: like new (used), Year of construction: 2008, travel distance X-axis: 1,050 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 880 mm, controller model: Fanuc Oi-MC, KAFO HMC 630 HMC Category: HORIZONTAL MACHINING CENTERS (HMC) Reference No.: 400234 Capacity: 630 X 630 MM Year of Construction: 2008 Technical Specification: Bwodpfjy D E Syox Antew SPINDLE Spindle Taper : CAT 50 WORKING CAPACITY Pallet Size : 630 x 630 mm Travels (XYZ) : X1050 x Y800 x Z880 mm B-Axis : 0.001° Distance from spindle nose to table center : 150 - 1030 mm Distance from spindle center to pallet surface : 100 - 900 mm Table Load Capacity : 1200 kg Max. Work Size : Ø1050 mm ATC Tool Change Capacity : 40 Maximum Tool Weight : 20 Kg CNC Control : Fanuc Oi-MC

Condition: good (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 255179729, travel distance X-axis: 1,050 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 880 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 40 m/min, nominal power (apparent): 74 kVA, torque: 525 Nm, controller manufacturer: Mazak, controller model: 640M, workpiece height (max.): 1,000 mm, workpiece diameter (max.): 1,050 mm, workpiece weight (max.): 1,500 kg, total height: 3,200 mm, total length: 6,400 mm, total width: 2,600 mm, table width: 630 mm, table length: 630 mm, table load: 1,500 kg, overall weight: 19,700 kg, spindle speed (min.): 50 rpm, spindle speed (max.): 10,000 rpm, spindle nose: BT 50, number of spindles: 1, number of slots in tool magazine: 80, mount diameter: 50 mm, tool length: 500 mm, tool diameter: 420 mm, tool weight: 30,000 g, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, TECHNICAL DETAILS Operating condition Condition: fully functional Inspection: possible under power after prior arrangement Table and swivel axis Table design: swivel axis Bjdpoz R A Ibjfx Antoww Division of swivel axis: 1/360° Machine dimensions Length: approx. 6,400 mm Width: approx. 2,600 mm Height: approx. 3,200 mm Coolant system Tank volume: approx. 800–900 l Tank length: 1,800 mm Tank width: 800 mm Tank height: 650 mm Pallets Number of pallets: 2 pcs. Pallet dimensions: 630 × 630 mm EQUIPMENT Tool holders External coolant drum filter tank Renishaw MP10 measuring probe system Grid frame in front of the machine, partially mobile 2 pallets, 630 × 630 mm

Condition: good (used), Year of construction: 2005, operating hours: 33,000 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, controller manufacturer: Okuma, controller model: OSP E100, table width: 500 mm, table length: 500 mm, rotational speed (min.): 10 rpm, rotational speed (max.): 15,000 rpm, spindle speed (max.): 15,000 rpm, coolant supply: 40 bar, spindle nose: BT40, number of spindles: 1, number of slots in tool magazine: 60, Equipment: chip conveyor, documentation/manual, Horizontal machining center Okuma MB 500H with a 2-position pallet changer Year of manufacture: 2005 Control system: Okuma OSP E100M Technical data: Bwjdpfx Ansz Tc Uystew Spindle speed: 10 - 15,000 rpm Drive power: 26 kW Tool holder: BT 40 Number of magazine positions: 60 Internal coolant pressure: 70 bar Travel distances: X-axis: 800 mm Y-axis: 800 mm Z-axis: 800 mm 4th axis: Index 1° Number of pallets: 2 Pallet size: 500x500 mm Accessories: - Coolant system, type ConSep 2000, by Mayfran - Chip conveyor, type ConSep, by Mayfran - Tool breakage monitoring in the magazine - Workpiece coolant shower

Condition: like new (used), Year of construction: 1994, functionality: fully functional, HOFFMANN HT 200 Dowel and Slot Drilling Machine In very good condition, this machine comes from an educational institution, has been used very little, and is in absolutely like-new condition; it has only very few signs of wear. It can be used to mill slots and drill dowel holes; the drilling height can be read very precisely on a digital counter. Comes with 3 drill chucks: for drills with an M10 external thread and for drills with 12mm and 16mm shanks. With workpiece support rests on the left and right sides, which are pivotable and have a support roller. The machine has a chassis. With 2 angle stops on the machine table for left and right. The clamping arms are reversible and adjustable. 380V, 1400 and 1800W through the 2 speed ranges. 1400 and 2850 rpm. Year of manufacture: 1994 Weight: approx. 280 kg With this machine, you can mill slots for, e.g., lock cases and similar items, or produce all types of frame dowel joints at right angles, butt joints, and miter joints. Ideal for producing dowel joints in timber frame construction, furniture, door, window, and staircase construction, and for similar applications. The drilling unit can be pivoted on both sides up to 65° and has a detent at 0°; this allows the machine to also be used to drill handrail posts into staircase stringers. The 2 speed ranges allow drills with large diameters to be used without overheating during drilling. Due to the detents and stops and the machine's design, dowel joints can be produced in a very short time, making the machine very economical. The machine requires a compressed air connection of 6 bar (the air consumption is very low). Right-hand rotation. Mills and drills very well and cleanly. Workpiece clamping is done with 2 pneumatic clamping cylinders via a foot pedal. The linear laser at the top of the machine allows marked dowel holes and angles to be drilled quickly and accurately. Comes with a precision 12mm guide rail with a center detent and 13 detents on the left and right. Working travel in width: max. 330mm The max. borehole height is 90mm. The max. borehole depth is 200mm with stop. The max. workpiece height is 150mm. Everything functions perfectly. Comes with manual. We will personally deliver and demonstrate the machine anywhere in Germany for €220.00, so you have no risk when purchasing; delivery to Austria and other countries is also possible upon request. The machine table is 1100mm wide and 250mm deep. Professional equipment, not cheap hardware store junk. You can start working with the machine immediately. Bjdpfx Aoyy Rtzsntoww Very stable and durable construction. The precision guides with the play-free ball bearing bushings are in good condition and move smoothly; the pivoting mechanism is also very smooth due to a ball bearing; locking is possible with a locking screw.

Condition: excellent (used), For sale: a robust horizontal milling machine from the renowned manufacturer VEB Heckert Auerbach (GDR), model FW 250x1000. The machine is in very good condition, complete, and fully functional – ready for operation. ✔ Technical specifications: • Model: FW 250x1000 • Year of manufacture: 1979 • Manufacturer: VEB Werkzeugmaschinenfabrik Auerbach, Kombinat “Fritz Heckert” • Weight: approx. 1,700 kg • Work table: 250 × 1000 mm, T-slots • Spindle speed range: 630 – 1800 rpm • Power supply: 3x380 V / 50 Hz • Power: 5.8 kW • Control voltage: 220 V • Rated current: 16 A, fuse 25 A • Mechanical and automatic feeds in all axes ✔ Equipment: • Robust machine vice on the table • Work light • Cooling system • Complete control panel with adjustment wheels and feeds ✔ Advantages: • Very stable, heavy-duty construction (1.7 tons) – ideal for precise and repeatable machining • Renowned manufacturer – Heckert (GDR), known for its durable machines • Fully functional and complete – ready for immediate use • 1000 mm table – allows for machining of larger parts This machine is reliable; it is not a lightweight, cheaply made Chinese product – it is a classic from a time when equipment was built to last. Bjdpfx Asz Slfmsntoww

Condition: good (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 630 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 650 mm, controller manufacturer: Siemens, controller model: Sinumerik 840 D, rotational speed (max.): 18,000 rpm, overall weight: 14,000 kg, spindle speed (max.): 18,000 rpm, operating hours of spindle: 100 h, coolant supply: 70 bar, spindle nose: HSK 63, number of spindles: 1, number of slots in tool magazine: 180, Equipment: chip conveyor, documentation/manual, Horizontal BAZ DECKEL MAHO DMC 60 H Linear with 4-position pallet changer and 180 magazine slots Year of manufacture: 2007 Control system: Sinumerik 840D Technical data: Spindle speed: 0-18,000 rpm Drive power: 35 kW Torque: Spindle connection: HSK 63 Bwodpfjx Dlgnex Antew Number of magazine slots: 180 Number of pallets: 2 Pallet size: 500x500 mm Travel distances: X-axis: 630 mm Y-axis: 800 mm Z-axis: 650 mm C-axis: 0.001° All axes have linear drives Accessories: -Coolant system -Chip conveyor The machine has been regularly maintained. It is still very accurate! More pictures will follow. Video available upon request.

Condition: used, Year of construction: 1996, travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,250 mm, controller model: Siemens 840 C, spindle speed (max.): 4,000 rpm, TECHNICAL DETAILS X-axis travel: 1,500 mm Y-axis travel: 1,200 mm Z-axis travel: 1,250 mm Spindle speed: 10–4,000 rpm Spindle power: 40 kW Spindle interface: HSK-A100 Bwjdpfxj Agftmo Antew Pallet size: 1,000 × 1,000 mm Rotary table speed: 1–500 rpm Pallet load: max. 2,000 kg Magazine type: Chain magazine Number of tool positions: 161 MACHINE DETAILS CNC control: Siemens 840 C Overall dimensions: 8,500 × 4,800 × 4,800 mm EQUIPMENT Chip conveyor Paper filter Rotary table Automatic horizontal and vertical spindle

Condition: good (used), Year of construction: 2013, operating hours: 37,297 h, functionality: fully functional, travel distance X-axis: 3,400 mm, travel distance Y-axis: 2,300 mm, travel distance Z-axis: 1,000 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 40 m/min, controller manufacturer: Siemens, controller model: 840D sl, table width: 1,500 mm, table height: 30 mm, table length: 2,000 mm, table load: 2,000 kg, spindle speed (max.): 18,000 rpm, operating hours of spindle: 12,486 h, spindle motor power: 24 W, number of slots in tool magazine: 21, Equipment: documentation/manual, rotational speed infinitely variable, For sale is an EiMa CNC-controlled 5-axis machining center, type Sigma M, with a fixed portal and moving table, designed for the precise machining of aluminum and finishing of steel. The machine is engineered for high accuracy, rigidity, and large travel paths, making it ideal for demanding milling, drilling, and sawing operations in metal and aluminum profile applications. Year of manufacture: 2013 Power-on hours: approx. 37,297 h (as of November 2025) Spindle running time: approx. 12,486 h total (as of November 2025) AXIS TRAVEL & DYNAMICS: - X 3,400 mm · Y 2,300 mm · Z 1,000 mm - Feed rate: X/Y 60 m/min, Z 40 m/min STRUCTURE & TABLE: - Sturdy steel construction, precision linear guides, servo drives, automatic central lubrication - Moving table 2,000 × 1,500 mm, 30 mm thick, threaded grid 100 × 100 mm - Max. load capacity 2,000 kg SPINDLE & TOOL CHANGER: - 24 kW HSK 63 A spindle up to 18,000 rpm, water-cooled - Disc-type tool changer with 20 positions + 1 pick-up position (for tools up to Ø 500 mm) 5-AXIS HEAD: - C3 fork head, swiveling ranges approx. C ±200°, A ±120°, high positioning accuracy MEASURING SYSTEMS: - m&h wireless probe (workpiece measurement) Bwedpfx Anex H Ib Netow - BLUM laser (tool measurement) EQUIPMENT: - MMS system (internal & external lubrication) - Fully enclosed cabin, separate tool change chamber - Mist extraction system with electrostatic separator (approx. 1,900 m³/h) already integrated CONTROL: - Siemens 840D sl, 5-axis package, Advanced Surface, TCP - 15" control panel, remote maintenance prepared ACCURACY: - Repeatability approx. ±0.012 mm SPECIAL FEATURES: - Connected to power – demonstration possible at any time - Direct from production – no dealer sale - Complete technical documentation available - Support with dismantling, loading, and transport possible (at extra cost) HIGHLIGHT: - New spare spindle from Omlat included (approx. €25,000 value) NOTE: - Collection possible from January/February onwards All information has been provided to the best of our knowledge and belief. Subject to change, errors, and prior sale.

Condition: good (used), Code: 0028 Bedpoz N A T Ijfx Antsww Brand: OMG Model: EPM/70 Automatic slotting machine for blinds Technical data Spindle connection mm 10 Drill speed 12000 rpm Simultaneous machining of 2 sections 18 possible pitches with a single toothed rod Slots depth up to 25 mm Drill motor Hp 1,5 Slide motor Hp 1 Up to 20 slots / minute Inclination from from 90 degrees (vertical) to 0 degrees (horizontal) Max section dimensions mm 100 x 120 Automatic stop Overall dimensions: machine mm 1500 x 1000 x 1200 h - kg 490 - Rack mm 3200 x 100 x 200 h - kg 30

Condition: ready for operation (used), functionality: fully functional, Year of construction: 1972, operating hours: 24 h, machine/vehicle number: 2025, overall weight: 5,200 kg, power: 10 kW (13.60 HP), input voltage: 380 V, input frequency: 50 Hz, broaching length: 320 mm, workpiece diameter (max.): 630 mm, total length: 2,650 mm, total width: 1,810 mm, total height: 2,890 mm, Slotting Machine STANKO 7M430 The STANKO model 7M430 is a heavy-duty vertical slotting machine, designed for machining internal keyways, slots, internal splines, and profiled surfaces in large and heavy workpieces. Manufactured in 1972, this machine is intended for industrial applications requiring robust construction, high rigidity, and reliable operation. The machine is equipped with a rotary worktable with a diameter of 630 mm, allowing flexible positioning of workpieces. The maximum stroke length of the ram is 320 mm (minimum stroke 120 mm), providing a wide working range for various slotting operations. The slotting head can be swivelled ±10°, enabling angular machining and increased versatility. Feeds along the X- and Y-axes are adjustable in the range of 0.2 to 2.4 mm per double stroke, while the rotary feed of the table can be set from 0.1 to 1.4°, ensuring precise control of cutting parameters. The maximum permissible table load is 3000 kg, making the machine suitable for large and heavy components. The distance from the table surface to the chisel guides is 500 mm, and the machine offers generous table travels: 650 mm longitudinal, 500 mm transverse, with 360° table rotation. The drive motor has a power rating of 10 kW, providing sufficient cutting force for demanding machining tasks. Bwsdpfx Anox U Tr Ajtsw With overall dimensions of approximately 2650 × 1810 × 2890 mm and a total weight of about 5200 kg, the STANKO 7M430 features a rigid cast-iron construction that ensures excellent vibration damping and long-term stability. Condition: *Used machine *Ready for operation *Fully functional *Operating hours: approx. 24 h Scope of delivery: *Complete set of change gears *Technical passport (Russian) *Operating manual (Russian) Typical applications: *Slotting of internal keyways *Machining of internal splines *Profile machining of internal surfaces *Machining of large and heavy components *General mechanical engineering and repair work

Condition: good (used), Code: 0423 Brand: ME.SA - ITALY Model: GT 60 S - CE Standard Chain and locks mortising machine with bits and cutters for joinery, wooden joinery, doors, furniture and various – CE Standard Bwodpfx Aszgt Edontew Technical data: Max mortise length 250 mm Head transverse stroke mm 100 Head rotation +/- 45° Vertical stroke of upright bracket 250 mm Vertical rotation of upright bracket +/- 45° Max window/door frame height 1000 mm Chain motor 3 Hp Vertical spindle motor 2 Hp Min/max horizontal spindle centre distance 50/130 mm Overall dimensions mm 850 x 900 x 1900 h Weight kg 390

Condition: used, Year of construction: 2011, Horizontal machining center Burkhardt + Weber Type/Model: MCX 900 Condition: Used Year of manufacture: 2011 Operating hours: 27,289 h Control system: Siemens 840D Technical data Working area and workpiece capacity Travel ranges X / Y / Z: 1,650 mm / 1,600 mm / 1,500 mm Interference circle: 1,850 mm across the entire X travel range Pallet size: 1,000 x 800 mm Max. pallet load: 3,000 kg Tilting moment for pallet machining up to 40,000 Nm Pallet design: T-slots Main spindle Tool holder: SK 50 Gear unit: 2-stage Spindle speed up to 8,000 rpm Spindle power: 37 kW (S1) Spindle torque: 1,220 Nm (S1) Tool management Magazine with over 200 tool positions Max. tool weight: 40 kg Tool tilting moment up to 120 Nm Tool taper cleaning Tool loading via the spindle Tool planning system on the spindle Mechanical drill break detection up to 750 mm Coolant system Coolant tank volume: 2,500 liters Paper band filter High-pressure coolant system: 70 bar Adjustable coolant pressure Cooling unit Flushing of pallet support Workpiece flushing Coolant spray gun Automation and hydraulics Linked to a robot cell Year of manufacture of the robot cell: 2013 Fixture hydraulics Hydraulic connection on the pallet changer Hydraulic connection in the working area Hydraulic connection to the pallets Hydraulic extension for clamping pressures over 60 bar Equipment: Process monitor iCut Collision monitoring system Brankamp CMS UPS Bwedpfo Afpnijx Antsw 4-way light stack Quoted item: Shipping costs will be provided in a separate offer.

Condition: used, TOS W100A - Horizontal Boring and Milling Machine The W100A is one of the most successful models from TOS Varnsdorf and represents the latest version of the classic series (H100, H100A, W100, W100A). It is robustly built, technologically versatile, and easy to operate and maintain. Ideal for single and small batch production with high reliability and comparatively low costs. - Classic design with a fixed column - Extendable spindle - Cross-traveling, rotatable work table - Integrated faceplate support in the spindle head - Option to use long drill rods with support from the drill support - Hardened and ground guide rails - Central lubrication - Position indicator The machine is suitable for drilling, milling, facing, and threading, as well as general machining operations on large workpieces. Technical data Spindle head: - Spindle diameter: 100 mm - Spindle connection: ISO 50 Bwsdpj Ahg Dtefx Antsw - Spindle travel (Z): 900 mm - Spindle center height above the table (Y): 0 - 1120 mm - Distance between faceplate and support bearing: 2800 mm - Faceplate diameter: 600 mm - Centering hole diameter in the table plate: 280 H6 mm - Centering hole depth: 8 mm - Max. facing diameter: 900 mm T-slots: - Faceplate, number/size/pitch: 2 / 20 H12 / 335 mm - Slide, number/size/pitch: 2 / 16 H12 / 150 mm Table: - Table cross travel (X): 1600 mm - Table longitudinal travel (W): 1250 mm - Clamping area: 1250 × 1250 mm - T-slots, number/size/pitch: 9 / 22 mm / 160/80 mm - Centering hole diameter in the table: 180 H6 mm - Centering hole depth in the table: 6 mm - Max. workpiece weight: 3000 kg - Tailstock slide travel: 1000 mm Speed: - Number of spindle speed steps: 23 - Spindle speed range: 7.1 – 1120 rpm - Number of faceplate speed steps: 16 - Faceplate speed range: 7.1 - 224 rpm - Max. torque of the spindle at speed: 3350 / 7.1 - 78.5 / 1120 Nm/rpm Feeds: - Drilling feeds, number/range: 32 / 0.02 - 12 mm/rev - Drilling feeds, number/range: 18 / 18 - 900 mm/min - Drilling feeds, number/range: 32 / 0.02 - 12 mm/rev - Drilling feeds, number/range: 18 / 25 - 1400 mm/min Rapid traverses: - Spindle, spindle head, table & tool slide: 2800 mm/min - Table rotation: 1 rpm - Tailstock bearing: 696 mm/min Threads: - Metric threads, number/range: 18 / 0.25 – 12 mm - Inch threads, number/range: 18 / 120 - 2.5 threads/1" Electrical data: - Main motor power: 11 kW - Total power consumption: 15 kW - Operating voltage: 3x 400 V / 50 Hz Dimensions & weights: - Machine dimensions WxHxD: approx. 6020 × 3000 x 3500 mm - Machine weight: approx. 14000 kg

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 1,250 mm, workpiece length (max.): 1,450 mm, workpiece height (max.): 1,450 mm, workpiece diameter (max.): 1,450 mm, workpiece weight (max.): 2,000 kg, overall weight: 25,000 kg, spindle speed (max.): 12,000 rpm, coolant supply: 70 bar, number of slots in tool magazine: 244, Equipment: chip conveyor, documentation/manual, Horizontal Machining Center Model A99ε with Microcomputercontrol Professional 3 and integrated CNC - Control FANUC System FMS System MMC2 - L2 16 PALLETS Cross movement (X- axis) of the column 1.250mm Heigth movement (Y- axis) of the spindle unit 1.100mm Distance table surface to spindle center 100 – 1.200mm Longitudinal movement (Z- axis) of the table 1.250mm Distance table center to the spindle nose 70 – 1.320mm Max. tilting height above pallets 1.450mm Admissable swing diameter in the cabin 1.450mm Pallets – Index table with 360 x 1°- degrees. position tolerance ± 3 arc sec. 2 rotation directions Max. pallet load 2.000 kg (Option: 3.000 kg) Bedpfx Ao Ah Ecxsntjww Pallet size 800 x 800 mm. Pallet surface with 5 T-slots, 22 mm H8, distance 160 mm, 2-edge locater for fixtures 400  0,01 mm. Compact design as 1 transport unit with 3-point levelling, without foundation. T-bed and machine column in Meehanite-cast iron, inherently rigid bed, bicolumn with symmetric guideways. Guideways as preloaded patched linear ball-guideways. Spindle unit 20 – 12.000 rpm, highly dynamic asynchronus three-phase motor spindle. Intensify torque in the lower speed range with winding switch and digital control. Direct input 5-characters for each speed between 20–12.000 rpm. speed override from 50 - 120 % in steps of 10 % within the selected range by M-Function eligible on and off. power 30 kW (30min) torque max. 420 Nm (25%ED) acceleration 0–6.000 min-1 1,9 s acceleration 0–12.000 min-1 7,1 s deceleration 6.000–0 min-1 1,8 s deceleration 12.000–0 min-1 4,6 s bearing diameter in the main bearing  115/175 mm. Spindle unit with Tool holder for hollow shaft according DIN 69871 AD, ISO - 50 (similar). tool clamping power 19,6 kN Temperatur control of the main motor by controlled circulating oel cooling with electrical throughput control. cooling and lubrication of the spindle bearings with an air-oel-mixture. electronic spindle alignment and positioning. direct tapping with synchronisation of the feed drive in Z-axis via pulscoder in the spindle motor. Max. speed n = 3000 rpm. Feed drive with AC-Servomotors Fabr. FANUC model alpha for X-, Y- and Z-axes, with digital control, in connecting with pre-loaded hollow shaft ball screws for the X-axes and each two ball screws for Y- and Z-axes. Rapid traverses : X-, Y-, Z-axis 50.000 mm min-1 feed rating : X-, Y-, Z-axis 1..50.000mm min-1 Standard measuring system: Tp  0,015mm (VDI DGQ 3441). Tool magazine with 244 storageplaces design chainmagazine, T-order 4-characters, free selectable. Security cover with security switch. average positioning time 9 s tool changing 1,7 s chip to chip 5 s max. tool diameter 125 mm max. tool length 600 mm max. tool weight 20 kg max. unbalance tool weight into the gripper 20 Nm with empty pockets right and left max. tool diameter 300 mm Tool holder for deep taper shafts according DIN 69871 AD, ISO-50

Condition: used, Offered is a horizontal boring machine. Equipped with a rotary clamping table with T-slots, horizontal boring and milling spindle head, large vertical faceplate with clamping slots, mechanical control levers and handwheels, as well as an additional clamping surface with T-slots. Inspection possible by arrangement. Bwsdpfxo Afpk Do Antew

Condition: like new (used), Year of construction: 2017, operating hours: 10,000 h, functionality: fully functional, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 830 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, Base Machine - SH-5000P - Demonstration Machine Like New • Basic machine, 4-axis • Control: Siemens 840D sl • Table size: 500x500mm • Max. table load: 500kg • X/Y/Z travels: 730/730/830mm • X/Y/Z rapid traverse: 60/60/60 m/min • Milling spindle: • HSK63 • 30/50kW • 18,000 rpm • Tool magazine with 40 stations • Automatic pallet changer • Automatic loading door • Hydraulic unit • Oil separator • Oil mist extraction • Air conditioning unit for electrical cabinet • External measuring systems, linear axes • Media feed under pallets • Central lubrication • Door interlock • Coolant unit • Internal cooling with 70 bar high pressure • Coolant and compressed air gun • Chip conveyor Bedpfs Af Ui Rex Antoww • Documentation in German, digital

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, 4 units 6 pressure clamps regulation of oscillation regulation of slot position up/down regulation units right/left possible drilling without oscillation CE total power 13kW Bedpjz D Adbofx Antoww

Condition: like new (used), Year of construction: 2022, operating hours: 10,000 h, functionality: fully functional, number of slots in tool magazine: 80, MAZAK HCN-5000 Horizontal Machining Center Year 2024 Control Unit: Smooth G X-axis travel: 730 Bwodpfx Ansz Aauketow Y-axis travel: 730 Z-axis travel: 800 Table length: 500 Table width: 500 Maximum workpiece dimensions (length x width x height): D.800x1000 Table surface: Tapped holes Maximum workpiece weight: 700 kg Spindle speed: 18000 rpm (high torque) Spindle taper: ISO 40 Rapid traverse rate (X-axis): 60,000 Rapid traverse rate (Y-axis): 60,000 Rapid traverse rate (Z-axis): 60,000 Number of tools (ATC): 40-60-80 Maximum tool diameter (ATC): D. 95 D.170 Maximum tool length (from reference line) (ATC): 170 Tool selection method (ATC): FIXED Maximum tool weight (ATC): 12 Tool change time (ATC): 2.8 Coolant pressure: 15 Bar Coolant tank capacity: 500L Height (machine dimensions): 2813 Width (machine dimensions): 2623 Depth (machine dimensions): 5769 Weight (machine dimensions): 11430 Pallet size: 500x500

Condition: like new (used), Year of construction: 2012, functionality: fully functional, I sell the horizontal foil wrapping packing machine Producer: SCM GROUP, Italy Model: PACK 8080 Year: 2012 / like NEW, almost not used before Working circle diameter 1300mm. Working tables width 900mm. Feeding manual with tables total length 2,60m Assembled, ready for work. Avialable immediately. On stock. Bedpfxjr Alx Uj Antsww

Condition: good (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 10160, travel distance X-axis: 800 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 805 mm, rapid traverse X-axis: 38 m/min, rapid traverse Y-axis: 38 m/min, rapid traverse Z-axis: 38 m/min, total height: 3,500 mm, total length: 7,000 mm, total width: 6,000 mm, overall weight: 17,000 kg, number of slots in tool magazine: 180, tool length: 600 mm, tool diameter: 250 mm, tool weight: 35,000 g, STARRAG HECKERT CWK 500 Horizontal Machining Center - Tool holder: HSK A 100 - Min. distance from the front edge of the working spindle to the center of the pallet: 150 mm - Min. distance from the center of the working spindle to the top edge of the pallet: 100 mm - Max. permissible height of workpiece and clamping devices for changing the work area: 900 mm - Workpiece side (pallet) with hole grid according to DIN 55201, clamping surface: 500 x 500 mm - Max. load per pallet (centered): 800 kg - Guide bore diameter: 20 H6 - Centering bore diameter: 50 H6 Bjde Afnc Eopfx Antsww - Number of mounting threads: 23 x M12 - Distance of the guide bore to the center of the table: diameter 200 +- 0.013 mm - Interference circle diameter: 800 mm - Max. table rotation: 18 rpm - Automatic pallet changer - Pallet changer with rotating setup station - max. pallet change time: 10 sec - Pallet change time with clamping hydraulics: min. 12 sec - Feeds: X/Y/Z axis: continuously adjustable working feed range: 1 - 38,000 mm/min - Working spindle diameter in the front bearing: 100 mm - Max. tool diameter with free neighboring positions: 250 mm - Max. tool diameter for bridge tools: 500 mm - Max. tool diameter with occupied neighboring positions: 125 mm - Tool overhang length: 600 mm - Max. tool weight: 35 kg - Average tool weight with full occupancy: 10 kg - Max. imbalance in the tool magazine: 100 kg - Number of pallets: 2 With Balluff system, technical documentation, with RENISHAW 3D measuring probe, including 30 HSK 100 tool holders, mostly equipped with tools. Transport: The machine can most likely be transported on a truck with a width of up to 3000 mm. FCA D-01445 Radebeul - loaded onto a truck

Condition: ready for operation (used), Year of construction: 1995, Available immediately ex works: Hydraulic horizontal band saw automation machine, Jaespa Type W 320 AZ – 6 Year of manufacture 1995 Cutting capacity: 320 mm round / 90 degrees Cutting capacity: 320 x 320 mm rectangular / 90 degrees Band speed, infinitely variable: 15 – 110 m/min Drive power: 4.9 kW Cutting lengths: 5 – 9999 mm Complete as shown in the picture, including all powered roller conveyors Weight: 2.2 tons Bwodpfxo Aa Iibs Antsw Price: EUR 2,750.00 plus VAT, ex works

Condition: like new (used), Year of construction: 2018, machine/vehicle number: DC-2075, Work table 700 x 300 mm, Drilling width 240 mm, Drilling depth 150 mm, Max. travel 230 mm, Drill head height adjustment 160 mm, Drill head swivel 45°-0°-45°, Bwodpovl Eynsfx Antew Wescott drill chuck 0 - 20 mm, Speed 3,000 rpm, Motor 2.2 kW, 400 volts, 50 Hz, Weight approx. 345 kg, Ex works, from the Seevetal location, excluding transport, as inspected, subject to prior sale.

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, Horizontal Machine Center DMG MORI NH 5000DCG/40 Year 2010 Tavel X 730 Y 730 Z850mm Fully C axis 0.001 degree MAPPS FAUNC Spindle 14,000rpm Bwodpfxe Ad Ucij Antjw 37/22KW 303Nm HSK-A63 Taper 60 ATC Pallet 500 x 500mm

Condition: good (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller manufacturer: Matsuura G-tech (Fanuc), controller model: 16i, workpiece height (max.): 750 mm, workpiece diameter (max.): 650 mm, workpiece weight (max.): 400 kg, total height: 2,635 mm, total length: 5,870 mm, total width: 3,440 mm, table width: 500 mm, table length: 500 mm, table load: 400 kg, overall weight: 13,700 kg, spindle speed (min.): 50 rpm, spindle speed (max.): 15,000 rpm, coolant supply: 25 bar, number of slots in tool magazine: 240, Equipment: chip conveyor, documentation/manual, We are pleased to offer this well-maintained Matsuura H-Plus 405 with pallet pool. This is a highly compact machine with extensive machining capabilities and 240 tool positions in the magazine. The machine was manufactured in 2004 and is equipped with the Matsuura G-Tech 16i (Fanuc 16i) control system. Technical specifications: Table dimensions: 500 x 500 mm Number of pallets: 6 Table load capacity: 400 kg X-axis travel: 600 mm Y-axis travel: 600 mm Z-axis travel: 600 mm Table indexing: 0.001° Spindle mount: Mas BT40 Big Plus Spindle speed: 50 – 15,0001 rpm Spindle motor: 22/18.5 kW Magazine capacity: 240 We realise that you may wish to receive further information or view the machine. In that case, please contact us, providing your company details so that we can get in touch with you. About Mamach Machinehandel: With over 40 years experience in the CNC machinery sector, we are now one of Europe’s leading suppliers of metalworking machinery. Our success is based on high quality, customer-focused service and a strong international network. Discover our wide range of used CNC lathes and machining centres – we’d be happy to advise you personally! Bjdpfjz Rmk Tox Anteww
