Used Index Gs 65 for sale (163)

Condition: excellent (used), Year of construction: 2004, - Synchron - C axis - Transmit function Kdodpfx Aeyvkbdobcei - Polygon device/thread milling cutter - 1 rear driven unit - Iemca Master 880 bar feeder, year 2004

Condition: used, Year of construction: 2013, INDEX ABC 65 Distance between main and counter spindle: approx. 250 mm Main spindle: - Spindle bore: 65 mm - Max. speed: 6,000 rpm - Power: 25 / 35 kW at 80 / 120 Nm - Chuck diameter: 160 mm - Spindle bearing (ISO 702/1): 140 mm - C-axis Upper tool turret: - 10 stations - Max. speed: 12,000 rpm - Power: 7.5 kW at 11.25 Nm - Travel X / Y / Z: 140 / ± 50 / 300 mm - Rapid traverse X / Y: 30 / 50 m/min Lower tool turret: - 9 stations - Max. speed: 12,000 rpm - Power: 9 kW at 10 Nm - Travel X / Y / Z: 140 / ± 50 / 300 mm - Rapid traverse X / Y: 30 / 50 m/min Kdsdjymbp Sjpfx Abcoi Counter spindle: - Spindle bore: 52 mm - Max. speed: 6,000 rpm - Power: 5 / 9 kW at 10.5 / 20 Nm - Chuck diameter: 110 mm - Travel X / Y: 140 / 300 mm Back machining units: - 8 units incl. 5 driven stations - Max. speed: 12,000 rpm - Power: 6.4 kW at 7 Nm Workpiece and offcut handling unit with gripper: - Travel X: approx. 1,580 mm - Speed: approx. 68 m/min - Swivel angle: approx. 33° - Max. diameter: 65 mm - Max. workpiece weight: 2 kg CNC control: INDEX C 200-4D (based on Siemens Sinumerik 840 D-sl) Dimensions: approx. 4.1 x 2.1 m Required floor space incl. bar loader and coolant/filter unit: approx. 11 x 1.5 x 2 m (L x W x H) Weight: approx. 7 t Power supply: 400 V / 50 Hz Operating hours: 30,431 h Hydraulic hours: 28,806 h Scope of delivery: - Bar loader INDEX MBL - Coolant filtration unit KNOLL KF 150 - Chip conveyor KNOLL 320 S-1/160

Condition: used, Year of construction: 2014, INDEX ABC 65 Distance between main and counter spindle: approx. 250 mm Main spindle: Bore: 65 mm Maximum speed: 6,000 rpm Power: 25 / 35 kW at 80 / 120 Nm Chuck diameter: 160 mm Bearing ISO 702/1, diameter 140 mm C-axis Upper tool turret: 10 stations Maximum speed: 12,000 rpm Power: 7.5 kW at 11.25 Nm Travel X / Y / Z: 140 / ±50 / 300 mm Rapid traverse X / Y: 30 / 50 m/min Lower tool turret: 9 stations Maximum speed: 12,000 rpm Power: 9 kW at 10 Nm Travel X / Y / Z: 140 / ±50 / 300 mm Rapid traverse X / Y: 30 / 50 m/min Counter spindle: Bore: 52 mm Maximum speed: 6,000 rpm Power: 5 / 9 kW at 10.5 / 20 Nm Chuck diameter: 110 mm Travel X / Y: 140 / 300 mm Back machining units: 8 units incl. 5 driven stations Maximum speed: 12,000 rpm Power: 6.4 kW at 7 Nm Kdedpfx Abjymblaocsi Workpiece and offcut handling unit with gripper: Travel X approx. 1,580 mm Speed approx. 68 m/min Swivel angle approx. 33° Maximum diameter: 65 mm Maximum weight: 2 kg CNC control: INDEX C 200-4D (based on Siemens Sinumerik 840 D-sl) Dimensions: approx. 4.1 x 2.1 m Required space incl. bar loader and coolant/filter unit: approx. L x W x H 11 x 1.5 x 2 m Weight: approx. 7 t Voltage: 400 V / 50 Hz Operating hours: 18,384 h Hydraulic hours: 16,694 h Scope of delivery: - Bar loader INDEX MBL - Coolant filter unit KNOLL KF 150 - Chip conveyor KNOLL 320 S-1/160 - Additional cooling unit KLH SC 8.K2L.MT-00-IND

Condition: like new (used), Year of construction: 2013, operating hours: 64 h, functionality: fully functional, As-new Production Package: INDEX ABC 65 & FMB Turbo 5-65 Bar Loader (Year 2025) Description: For sale is a turnkey manufacturing package in absolutely top condition. The system was planned for a major project that was halted shortly before final commissioning due to a client cancellation. 1. CNC Production Turning Machine INDEX ABC 65 Condition: As new, used exclusively for internal training purposes. Advantage: Extremely low operating hours, no signs of wear from series production. Highlights: High-dynamic bar machining (Ø 65 mm), synchronous spindle for rear-side machining, two turrets for simultaneous machining, finished parts gripper, compact footprint. 2. FMB Turbo 5-65 Bar Loading Magazine Condition: Brand new (year of manufacture 2025), unused and in original packaging. Highlights: Massive cast iron bed for maximum vibration damping, modern 8.4" touch control panel (mobile), material range Ø 5 – 65 mm. Documentation: Complete documentation and standard accessories included. Reason for Sale & Availability: The combination has already been matched and is available for immediate delivery from stock. This allows you to avoid the currently long lead times of the manufacturers and obtain a system in new condition. Kdsdpfoynb N Iox Abcei Price: On request (negotiable)

Condition: used, Year of construction: 2005, turning diameter 140 mm turning length 600 mm control Siemens 840 D PowerLine distance between spindles 615 mm Max. rpm 5.000 min/-1 power capacity - main spindel 20 / 27 kW max. Torque 105 / 145 Nm C-Axis 0,001 ° chucking diameter 140 - 160 mm spindle head ISO 702/1 A5 max. bar capacity 65 mm spindle bearing diameter 110 mm Max. rpm 5.000 min/-1 power capacity - Sub spindle 20 / 27 kW max. Torque 105 / 145 Nm C-Axis 0,001 ° chucking diameter 140 - 160 mm spindle head ISO 702/1 A5 max. bar capacity 65 mm x-travel 150 mm z-travel 600 mm spindle bearing diameter 110 mm Number of Turret 3 pos. tool taper VDI 25 x 48 DIN 69880 number of toolpositions 3x 12 pos. Number of driven toolspositions 3x 12 pos. Spindle speed - driven tools max. 6.000 min -1 power capacity - driven tools 8 kW max. Torque 16 Nm x-travel 1/2/3: 110 mm z-travel 1/2/3: 360 mm y-axis 1/2/3: 70 mm b-axis 2x +/-1 ° rapid traverse ( X / Y / Z ) 25 / 12 / 50 m/min total power requirement 53 kVA Kdjdpex R En Iofx Abcoi weight of the machine ca. 6,5 t dimensions of the machine ca. 8,0 x 3,5 x 2,5 m High-Performance - CNC - Turning- and MillingCenter INDEX - C65 SpeedLine - Main- and Subspindle - 3 turrets - 2(3) y-Axis +/-35mm - 2 b-corrective-Axis (+/-1°) - 3x 12 driven tool positions - IRCO - Profimat 65.6

Condition: excellent (used), INDEX ABC 65 is an INDEX CNC Turning‑Milling‑Drilling Center designed for high precision, accuracy and reliability. Capacity: 2 turning spindles, 2 turrets; spindle bore 65 mm; spindle diameters 140/110 mm; travels Z300 X140 Y100 mm; turret positions 10/9 (back 8). Specs: main spindle stepless 0–6000 rpm, 25/35 kW, torque 80/120 Nm; back spindle 6000 rpm, 5/9 kW; driven tools 7.5/9 kW; tool shank 45 mm; indexing 0.4 s; rapids X30/Z50 m/min; power supply 3x400 V 50 Hz; installed power 41 kW; weight ~6500 kg; dims 3600×1280×1950 mm. Accessories: 300 l coolant, 80 bar high‑pressure, paper filter, lamp, collet device, USB, parts conveyor, chip conveyor, toolholder set. Achieves tight tolerances; ideal for automotive, watchmaking, aerospace, medical and toolmaking. Kdsdjxx U Svjpfx Abcji

Condition: used, Year of construction: 1990, turning diameter 60 mm turning length 200 mm number of slides total power requirement 20 kW weight of the machine ca. t dimensions of the machine ca. m Kodpfx Aot Hw Atjbcodi

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 720052, turning length: 600 mm, turning diameter: 140 mm, bar passage: 65 mm, controller model: Siemens 840 D PowerLine, distance between spindles: 615 mm, TECHNICAL DETAILS Turning diameter: 140 mm Turning length: 600 mm Maximum bar diameter: 65 mm Distance between spindles: 615 mm Max. spindle speed: 5,000 rpm Main spindle drive power: 20/27 kW Spindle nose: ISO 702/1 140 mm Spindle bearing diameter: 110 mm Max. torque: 105/145 Nm C-axis: 0.001 Chuck diameter: 140 - 160 mm Tool turret: 3 Y-axes: 2 to 3 axes +/- 35 mm B-correction axes: 2 axes +/-1 Kdodpfxoxg Im Ae Abcoi Driven tool positions: 3 x 12 Tool holder: VDI 25 x 48 DIN 69880 Drive power for driven tools: 8 kW MACHINE DETAILS Control: Siemens 840 D PowerLine Dimensions & Weight Space requirements: approx. 8.0 x 3.5 x 2.5 m Machine weight: approx. 6,500 kg Electrical Data Rated voltage: 400 V AC Rated current: 101 A Rated power: 59 kW Number of phases: 3 Frequency: 50 Hz Control voltage: 24 V DC Total power requirement: 53 kVA EQUIPMENT Index MBL bar loader

Condition: used, TECHNICAL DETAILS - Number of spindles : 2 - Number of axes : 6 - Number of turrets : 3 MAIN SPINDLE - Spindle power : 29 [kW] - Spindle speeds : 6000 [rpm] - Max. bar diameter : 65 [mm] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Spindle power : 4.2 [kW] - Spindle speeds : 4500 [rpm] - C axis indexing precision : 0.001 [°] - Travel : 280 [mm] UPPER LEFT TURRET - Number of positions : 5 - Tool type : VDI25 UPPER RIGHT TURRET - Number of positions : 8 - Number of motorized positions : 8 - X/Z stroke : 90/280 [mm] - Tool type : VDI25 - Live tools speed : 4500 [rpm] - Live tools power : 4.2 [kW] LOWER LEFT TURRET Kdjdpfxsuhac Ds Abcei - Number of positions : 6 - X/Z stroke : 81/80 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 35 [kW] EQUIPMENT - CNC : INDEX C200-4 - Coolant tank * with high-pressure pump - Chips conveyor - Parts catcher - Parts conveying strip - Collet chuck

Condition: used, Year of construction: 1998, functionality: fully functional, We offer various lathes such as INDEX GS30, INDEX GSC42, cam-type automatics B and C, Mahr roundness measuring device, Mitutoyo profile projector ... Price on request. Kdodpeym Avmjfx Abcoi

Condition: excellent (used), Year of construction: 1994, CNC Lathe Automatic Index GS42 Kjdpfsx E Sqlox Abcodi Control: Index C200-8 (Sinumerik 880) Spindle bore: 42 mm, two machining turrets Turret 1 – X=120 mm, Z=220 mm, 12 tool stations (6 driven), part handover Turret 2 – X=120 mm, Z=80 mm, 8 tool stations (4 driven) Dynamic C axis Bar feeder with magazine INDEX MBL 3500 mm, including complete set of reduction sleeves Set of clamping collets – 10 pcs Driven tool holders – 5 pcs Standard VDI20 tool holders – 5 pcs The machine is 100% operational and in excellent condition (maintains tolerances up to 0.001 mm)

Condition: used, Year of construction: 2007, turning diameter 140 mm turning length 615 mm control C200-4D spindle passage 65 mm turning speeds 5.000 U/min max. torque at 40% / 100% load 145 / 105 kW turret-slide 1,2 und 3 x-travel 110 mm z-travel 360 mm y-travel 70 mm rapid traverse X/Y/Z 25/12/45 m/min slide travel X-axis 150 mm Kedpjwzynqofx Abcjdi Z- Travel 600 mm turning speeds 5.000 U/min B - axis B-Korrekturachse +/- 1 ° tool turret - number of stations 3 x 12 tool taper DIN 69880 VDI 25 x 48 C-axis 0,001 ° total power requirement 61 kW weight of the machine ca. 6,5 t dimensions of the machine ca. 9,75 x 3,10 x 2,85 m Loading: Breuning Profimat 65.8x270/8 multi-channel loading magazine, built in 2005 for bars with lengths of 500–3,000 mm, 8 guide channels with spindle insert tubes (Ø 16, 25, 30, 40, 45, 55, 60, 65 mm) Unloading: BREUNING ILS-REX-7208 automatic workpiece unloader, built in 2007

Condition: used, Year of construction: 2013, turning diameter 110 mm turning length 450 mm control Siemens Kjdpfx Aboyuzfvecedi weight of the machine ca. 9000 kg

Condition: excellent (used), Year of construction: 2023, X/Y/Z: 360/120/750 mm Bar capacity: 82 mm 12-station driven tool turret C-axis Y-axis Kdodpfxsw Nxyaj Abcei VDI 40 NC tailstock MK 5 with foot switch Foot switch for clamping on main spindle Air curtain Signal light Coolant device Chip conveyor Hydraulic holding brake ShopTurn Transmit function (cylindrical machining on outer and face surfaces) iXpanel (control system operation and organization extension) Gripper tray Small tool package

Condition: ready for operation (used), Year of construction: 2018, spindle speed (max.): 7,000 rpm, bar diameter (max.): 42 mm, travel distance X-axis: 70 mm, travel distance Y-axis: 70 mm, controller manufacturer: FANUC, controller model: 31i-B, number of axes: 10, This 10-axis Index C100 horizontal turning machine was manufactured in 2018. It features impressive axis travels of 70 mm in both X and Y directions, and 400 mm in Z. The machine includes three turrets with driven tools capable of 8000 rpm, and a counter spindle diameter of 42 mm. If you are looking to get high-quality turning capabilities, consider the Index C100 machine we have for sale. Contact us for further details. Kdedpeyuwyvofx Abcei • Production hours: approx. 15,000 h • Spindles: Main and counter spindles with D42; counter spindle Ø42 mm, 7000 rpm • Turrets: 3x VDI25 with Index W-serration; driven tools on all three turrets, up to 30 driven tool positions, 8000 rpm • Coolant system: Emulsion; flushing beside main and counter spindle; through counter spindle; 8 bar pump; 18 bar pressure-increasing pump (no Eco Fluid 80 bar); mechanical coolant filter (no paper filter); coolant tower for cooling main/counter spindles and electrical cabinet • Software/Functions: Milling cycles Transmit / Tracyl • Monitoring: Index Motorforce tool monitoring for Fanuc • Interfaces/Preparation: Ünimag4 interface for bar feeder; preparation for oil mist unit (mechanical flange D200 mm; electrical Harting plug 3x240 V) • Clamping: SK45 in main spindle (without collets); E173 in sub spindle (without collets) • Storage/condition: Machine stored under power in a heated warehouse Additional equipment • Bürener chip conveyor, 840 mm height, hinge-chain type • Handling unit with 2‑finger gripper for finished part and remnant • Conveyor belt for finished parts with flap for remnants • Bar feeder: LNS, 1500 mm Technical Specification Counter Spindle Yes

Condition: ready for operation (used), Year of construction: 2000, travel distance X-axis: 81 mm, travel distance Z-axis: 80 mm, number of axes: 2, Horizontal turning machine manufactured in 2000. This Index ABC features a maximum spindle speed of 5000 1/min and a bar capacity of 60 mm. It includes an 8-station revolver with driven tools capable of 6000 1/min. If you are looking to get high-quality turning capabilities, consider the Index ABC machine we have for sale. Contact us for further details. • Main Spindle Torque (100/40% ED): 95/140 Nm • Bar Capacity: Max. 60 mm Kodpsyuu N Isfx Abcjdi • Revolver 1: 8 stations (7 for VDI 25 tools, 1 for synchronous spindle) • Revolver 1 Driven Tools: Max. speed 6000 1/min, power 3.3 kW • Revolver 2: 6 stations, X-travel 81 mm, Z-travel 80 mm • Synchronous Spindle: Max. speed 4500 1/min, torque 10 Nm • Coolant Tank Capacity: 220 liters • Power Supply: 400 V, 50 Hz • Cabinet Dimensions: 1300 mm width x 2000 mm height • Display: 24 cm color flat screen interface • Control Version: C200-4 Additional equipment • Loading Magazine: INDEX MBL 65/3700 • MBL Bar Length Capacity: 3000 mm (D 5–10) / 3600 mm (D 10–65) • Chip Conveyor: Knoll chip conveyor with 840 mm discharge height Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: used, Year of construction: 1996, Type: Multispindle lathe Make: Index Model: G200 Year of manufacture: 1996 Condition: Used Kdedpfx Asyn Hmxebcei Quantity: 1

Condition: excellent (used), Year of construction: 2009, operating hours: 28,742 h, functionality: fully functional, bar passage: 65 mm, FANUC Series 31i-Model A Kdjdpjydmbuofx Abcei 3 turrets Parts conveyor Magazine Further details on request

Condition: used, Year of construction: 2019, controller manufacturer: Siemens, controller model: 840 Dsl, _____ Description: Year of manuf. : 2019 Control : Siemens 840 Dsl Mainspindle: Technology:Motorspindle Speed:6.000 rpm Power:20 kW Barcapacity:65 mm Workpiececlamping:Collet chuck, Hainbuch Spanntop Modular Gr. 65 Toolcarrier I (X/Z): Technology:Turret with 8 Stations Taper:VDI 25 Tooldrive:6.000 rpm, 4,2 kW, 10 Nm Complete processing:Synchronspindle with 3-Jaw chuck, ø95 mm Movement in X/Z:90/280 mm Rapid travers in X/Z:27/36 m/min Toolcarrier II (X/Z): Technology:Turret with 8 Stations Taper:Dovetail Guide Tooldrive:6.000 rpm Movement in X/Z:81/80 mm Rapid travers in X/Z:27/36 m/min Kdsdoyq Um Ejpfx Abcei Backworking attachment: Technology:Backworking attachment with 5 stations Driven Tools:2 stations Tooldrive:6.000 rpm Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Coolant pump with High-pressure, 20 bar Rawmaterialfeed:Barloader, Breuning Irco ILS-MUK 7012 III Finished part removal:Parts catcher with conveyor belt Oilmistseparation:Interface prepared Toolholder:Misc. static toolholder (VDI25 & Dovetail)

Condition: ready for operation (used), Year of construction: 2008, spindle speed (max.): 3,000 rpm, travel distance X-axis: 640 mm, travel distance Y-axis: 210 mm, travel distance Z-axis: 2,000 mm, spindle motor power: 67,000 W, total height: 2,591 mm, total width: 2,199 mm, overall weight: 21,000 kg, product length (max.): 6,300 mm, tool weight: 5,000 g, swivel angle B-axis (max.): 360 °, swivel angle C-axis (max.): 360 °, number of axes: 4, This 4-axis Index G 400 horizontal turning machine was manufactured in 2008. It features a maximum turning diameter of 630 mm, a length capacity of 2000 mm, and supports a workpiece weight up to 300 kg. Equipped with a high-speed milling spindle at 6000 rpm and a main spindle speed of 3000 rpm, it offers robust machining capabilities. Consider the opportunity to buy this Index G 400 horizontal turning machine. Contact us for more information. Kodpox D D Ecefx Abcedi Main spindle 0102 direct driveMaximum material throughput: 102 mmMaximum speed: 3000 rpmFront bearing diameter: 170 mmVariable hollow shaft motorPower at main spindle D102:Power at 100/40% duty cycle: 53 kW/68 kWTorque: 675 Nm/900 NmWork spindle alignment and switching device D1022.5° increments via indexing discHydraulicly actuated hollow clamping cylinder D102 with analog clamping stroke monitoringMaterial clearance: 102 mmStroke: 48 mmMaximum clamping force (tension/compression): 10,900 dNMulti-clamping pressure deviceClamping pressure adjustable from 8 to 80 bar via a multi-stage parts catalog for the main spindle clamping cylinder. Chuck release movement required for transitioning to a lower clamping l carrier 1 (standard equipment)Cross slide X, Z, turning length 2000 h internal coolant supply and shut-off valve, ball screws D=40 mmin the X-axis, D=50 mm in the Z-axis. Axis drives protected by overload clutches, counterweight in the s X ZWorking travel mm: 320 2000Rapid traverse speed m/min: 20 40Feed force N: 14000 14000X-axis measuring system: Glass scale (absolute)Z-axis: ROQ encoder (absolute)X-Y-Z-B housing (WT1)Turret with AC motor, positioned by spur gears, hydraulically lockedY-axis quill, hydrostatically mounted, lockable via spur gearsBall screw, D=40 mmOverload clutchTravel: 220 mmRapid traverse speed: 12 m/minFeed force: 24,000 NROQ encoder (abs)B-axis drive with AC motorSwivel angle: 360°Tool drive unitwith two clutches:Maximum speed: 6,000 rpmPower (25%) at n= 6,000: 17 kWMaximum torque (25%): 37 NmDisc turret with 12 stations on cross slide 1Tool holder system DIN 69880-40x63Increased repeatability during tool changes due to additional W-slotsMultifunction unit on cross slide 1Maximum speed: 6,000/1,500 rpmGearbox: i=4Torque: 36/144 NmTools: SK50Front bearing diameter: 75 mmInternal coolant feedthrough, disc spring clampingTool carrier 2, right - X, ZTurning length 2000 mm, preferably oncounter spindle machine with internal coolant supply and shut-off valve, turret control via AG motor, ball screws D= 50 mm for Z-axis, D= 40 mm for X-axis. Axis drives protected by overload clutches, counterweight system in ret head oriented to the right towards the counter s X ZTravel mm 210 2000Rapid traverse speed m/min 20 40Feed force N 8600 14000X-axis measuring system: glass scale (abs)Z-axis: ROD encoder (abs)Disc turret with 10 on cross slide 2Tool holder system DIN 69880-40x63Increased repeatability during tool changes thanks to additional W-slotsPositioned by face gearing, hydraulically lockedCounter spindle D102, size 11-DIN 55026/55021 and ISO 702/1Turning length 2000 mmZ-axis slide driven by AC motor and 50 mm diameter ball screwAxis drive protected by overload clutchIn the working position, the slide is held against the stop by the AC motor.

Condition: ready for operation (used), Year of construction: 1998, operating hours: 39,445 h, controller manufacturer: SIEMENS, controller model: SINUMERIK 840C, number of axes: 12, This 12s Index MS42C was manufactured in 1998. It features a maximum bar diameter of 42 mm and operates with a fully automatic system, making it suitable for high-volume precision turned parts. The machine is equipped with a Siemens SINUMERIK 840C control system and AC servo drives, ensuring efficient performance. Consider the opportunity to buy this Index MS42C automation equipment. Contact us for further details. • Maximum bar diameter: 42 mm • Number of spindles: 6 • Spindle pitch circle diameter: approx. 320 mm • Maximum spindle speed: approx. 5,000 rpm • Number of CNC axes: 12 linear axes (6 × X, 6 × Z) • Axis configuration: X/Z per spindle station • Control: Siemens SINUMERIK 840C (INDEX OEM integration) • Drive system: AC servo drives with SERCOS interface • Automation level: Fully automatic • Operating mode: Continuous production (24/7 capable) • Cooling: Central coolant system Kedpfx Abjyhf N Eocsdi • Lubrication: Central automatic lubrication • Electrical supply: 3-phase industrial power • Installed power: approx. 70–75 kW (configuration dependent) • Machine construction: Rigid cast iron base • Typical materials: Steel, stainless steel, aluminum, brass • Typical applications: High-volume precision turned parts

Condition: ready for operation (used), Year of construction: 2003, operating hours: 92,000 h, controller manufacturer: SIEMENS, controller model: 840D, number of axes: 5, This 5-axis Index G 200 RATIO LINE was manufactured in 2003. It features a Y-axis travel of 120 mm, a main spindle diameter of D65, and a counter spindle diameter of D60. The machine is equipped with a turret that has 12 stations and driven tools on turret 1 and 2. If you are looking to get high-quality turning and milling capabilities, consider the Index G 200 RATIO LINE turn-mill centre we have for sale. Contact us for further details. • C-axis on main and counter spindle • Thread cutting without compensating chuck • Electronic shaft • Additional V24 RS232 interface in control cabinet • Transmit-/Tracyl function • MDE interface (machine on, machine running, parts counter) • Marposs (Brankamp) collision monitoring CMS100 • 3D machine model for kinematic simulation in CAM programming system • Control cabinet cooling unit • Main spindle D65 • Counter spindle D60 • Coolant flushing of counter spindle (electrically controlled shut-off valve) • Foot switch Ksdpfx Abeylw Dcocsdi • Turret (12 stations) bottom and top • Driven tools on turret 1 and 2 • Control function “synchronous tailstock” for turret 2 • Y-axis 120 mm • Automatic sliding door (hydraulic) • Coolant pump 80 l / 8 bar • High-pressure coolant connection slide 1 and 2 with solenoid valve • Coolant flushing gun • Preparation for extraction and filter system connection • Operating hours approx. 92,000 h Additional equipment • Portal unloading device with actuated gripper, NC-controlled • Gripper fingers D4–45 mm and D40–65 mm • Indexed conveyor belt • UNIMAG interface • Chip conveyor (hinged belt), discharge height 1250 mm • Vacuum rotary filter KNOLL (emulsion use) • High-pressure pump 80 bar • Workholding: • Collet chucks for draw tube, HAINBUCH (main and counter spindle) • Power chucks D210 with quick jaw change, Schunk (main and counter spindle) • Stop device • Optional: large number of powered tool holders and spare parts warehouse

Condition: ready for operation (used), Year of construction: 2002, operating hours: 24,971 h, spindle speed (max.): 6,000 rpm, controller manufacturer: SIEMENS, controller model: SINUMERIK 840C, number of axes: 12, This 12s Index MS42C multi-spindle turning machine was manufactured in 2002. It features a maximum bar diameter of 42 mm and a spindle speed of approximately 5,000 rpm, making it suitable for high-quality turning capabilities. Consider the opportunity to buy this Index MS42C multi-spindle turning machine. Contact us for further details. • Maximum bar diameter: 42 mm • Number of spindles: 6 • Spindle pitch circle diameter: approx. 320 mm • Number of CNC axes: 12 linear axes (6 × X, 6 × Z) Kedpjyhpgujfx Abcsdi • Axis configuration: X/Z per spindle station • Control system: Siemens SINUMERIK 840C (INDEX OEM) • Drive system: AC servo drives with SERCOS interface • Automation level: Fully automatic • Cooling system: Central coolant system • Lubrication system: Central automatic lubrication • Installed power: approx. 70–75 kW • Typical materials: Steel, stainless steel, aluminum, brass

Condition: ready for operation (used), Year of construction: 2008, controller manufacturer: SIEMENS, number of axes: 3, This 3-axis Index MC 400 horizontal turning machine was manufactured in 2008. Ideal for precision turning operations, it offers robust construction and reliable performance. If you are looking to get high-quality turning capabilities consider the Index MC 400 machine we have for sale. Contact us for more information about this machine. Machine Benefits Technical Machine Benefits • Max turning diameter: 350 mm • Max turning length: approximately 300 mm • Hole through spindle: 66 mm • 14-tool revolver • Driven tools Extra Information Machine still under power Kjdpfx Aoyar Ifebcjdi

Condition: ready for operation (used), Year of construction: 2000, spindle motor power: 22,000 W, total height: 2,050 mm, overall weight: 4,000 kg, controller manufacturer: INDEX, controller model: C200-4 / C200-8, This 5-axis Index G200 C turn-mill centre was manufactured in 2000. Consider the opportunity to buy this Index G200 C turn-mill centre. Contact us for more information. Additional equipment • Synchronous device for counter spindle machining • Tool carrier 3 for synchronous spindle (rear end machining) • Additional milling spindle • Thread milling and polygon turning device • Gripperless tool changer (6 tools, HKS-50 B, KM40) • Workpiece handling WHU100 • with c-axis • no driven tools Machine Benefits Technical Machine Benefits • Space requirement (without material guide): 3580 x 3108 mm • Control unit: resolution: 0. 001 mm (input/output/correction) • Comprehensive movement range with multiple axes configuration Kdedpfxeyailzo Abcoi • High precision with 0. 001 mm resolution in numerical control • Versatile expansion stages and additional equipment for enhanced functionality Extra Information Movement Cross slide 1 (top) - XYZB axes: X-axis: Slide path 155 mm, feed force 5000 N, rapid traverse 20 m/min, resolution 0.0005 mm Y-axis: Slide travel 120 mm, feed force 10000 N, rapid traverse 7.5 m/min, resolution 0.0005 mm Z-axis: Slide path 590 mm, feed force 5000 N, rapid traverse 30 m/min, resolution 0.001 mm B-axis (rotating): 360° swivel range, angular steps 5° (with locking), resolution 0.001° (with clamping), switching time for 180°: 1 s Cross slide 2 (bottom) - XZ axes: X-axis: Slide travel 105 mm, feed force 5000 N, rapid traverse 20 m/min, resolution 0.0005 mm Z-axis: Slide path 307 mm, feed force 5000 N, rapid traverse 30 m/min, resolution 0.001 mm Turret Turret right: X-axis: Slide path 120 mm Z-axis: Slide travel 400 mm Tail Stock Center distance: 400 mm Pressure force (max): 5500 N Drive: Hydraulic or electric Media Power supply: 400 V, 50/60 Hz Connected load: 20-45 kVA Current consumption: 35-80 A Hydraulic system: Delivery rate: 18 l/min System pressure: 90 bar Filling capacity: 70 liters Cooling lubricant system: Pump capacity (switchable): 20 l/min at 18 bar / 50 l/min at 3 bar / 60 l/min at 5-7 bar Filling quantity: Approx. 230 liters Chip conveyor: Hinged belt or scraper Workpiece holder: Main spindle: DB5 internal mount / D140 external mount, optional short taper Counter spindle: D140 external mount (only tensile clamping permitted for collet and chuck clamping) 1st spindle data (main/counter spindle): Spindle clearance (collet clamping): Variants: 30 mm / 42 mm / 60 mm / 65 mm Spindle Ø in front bearing: 75 mm (with 30 mm clearance) / 85 mm (42 mm) / 100 mm (60+65 mm) Speed (max): 7500 rpm (30 mm) / 6300 rpm (42 mm) / 5000 rpm (60 mm) Spindle nose: ISO 702/1 (size 4 or 5) Chip diameter (workpiece Ø): 110-130 mm (30 mm) / 140-160 mm (42 mm) / 165 mm (60 mm) Torque (Md max 100%): 33-62 Nm (30 mm) / 35-95 Nm (42 mm) Power (P max 100%): 7-13 kW (30 mm) / 7.5-20 kW (42 mm) Dimensions Machine Depth 3580 mm
