Used Maho 700 for sale (444)

Condition: used, Universal milling machine table, angle table, setup angle, clamping table, presumed MAHO make T-slot table, add-on table for universal tool milling machine Table no.: 76-400-1 / 2210 05 00 Table size: 700 x 330 mm Overall height: 210 mm T-slot width: 12 mm T-slot pitch: 45 mm - Table plate with 7x T-slots, 12 mm each - Mounting surface 90°, 13 mm diameter holes, 14 mm elongated holes for fastening and 12 mm guide slot - Hole spacing, top mounting plate Ø 13 mm = 500 mm, 50 mm from the table surface (measured at center) - Hole spacing, middle mounting plate Ø 13 mm = 472 mm, 95 mm from the table surface (measured at center) Laodpfx Ajxy Stysn Ijd - Elongated hole spacing, middle mounting plate = 475 mm, 140 mm from the table surface (measured at center) - Elongated hole spacing, bottom mounting plate = 475 mm, 185 mm from the table surface (measured at center) Dimensions (L x W x H): 820 x 330 x 210 mm Weight: 61 kg In good condition

Condition: used, NC universal tool milling machine MAHO type MH 700 P with HEIDENHAIN TNC 121 linear control . 71247 Circuit diagram no. ET 226 Built in 1979 Travel paths X: 600 mm, Y: 400 mm, Z: 400 mm Table size 900 x 500 mm Spindle mount ISO 40 Lajdpjwd Szbefx An Ijd Spindle speed 40-2000 rpm, 18 steps Feed rate X, Z-axis 1 - 600 mm/min, continuously variable Feed rate Y 1 - 300 mm/min, continuously variable Rapid traverse X, Z-axis 1.5 m/min Rapid traverse Y-axis 0.75 m/min Vertical spindle travel 80 mm Horizontal spindle travel 80 mm Spindle drive 4 kW Power supply 380 V, 50 Hz, 10 kW - HEIDENHAIN TNC 121 NC linear control - Vertical milling head with automatic Quill feed - Hydro-mechanical tool clamping - Coolant system in the machine base - Universal built-in rotary table, swiveling and tilting via threaded spindles +/- 30° - Universal built-in rotary table with manual transverse adjustment of 200 mm - Universal built-in rotary table with 360° rotation function and hydraulic clamping - Rotary table with direct indexing 72 x 5° and indirect indexing via hole plate 1:120 = 1 rev = 3° - Pivoting control panel - Central lubrication system - Electrical diagram Space requirement L x W x H 2000 x 1650 x 2250 mm Weight approx. 2800 kg Good condition

Condition: repair required (used), functionality: limited functionality, Offered for sale is a Maho 700 milling machine. Visually and technically in good condition. Includes digital readouts for the X, Y, and Z axes. Comes with a machine vise (as shown in the photos). It was used by us for apprentice training. The machine is being sold as in need of repair. Feed in the X and Y axes functions perfectly. The feed in the Z-minus direction also works. Only in Z-plus (raising) does it stick a little. However, this should be fixable with maintenance. The machine can be inspected under power in 45659 Recklinghausen. Lodpey Rxvlofx An Iead

Condition: ready for operation (used), Maho milling table for Maho milling machine MH 700 S, milling table for interchangeable pallets 500x630 mm, used, normal signs of wear, 100% functional, scope of delivery as shown in photos. ATTENTION: Please enquire separately for costs of packing and shipping! Ljdpfox Dw Iwex An Iead

Condition: ready for operation (used), Maho milling head (Maho milling machine MH 700 S), used, normal signs of wear, 100% fully functional, scope of delivery as per photos. NOTE: Please enquire separately for costs of packing and shipping! Ledpfjx Dw Iqox An Ioad

Condition: used, Year of construction: 1987, Technical details: x-travel: 700 mm y-travel: 500 mm Lasdpeu Idbyofx An Isd z-travel: 600 mm table swivelling +/-: A-Achse: 20° / 60° Grad table rotating: B-Achse: 360° Grad control: Maho 432 (3-D Bahnsteuerung) Max. Milling-capacity: ST: 60 und GG: 22 mm tool changer with: 24 Plätze number of spindle speeds: 20 - 6300 U/min. max. table load: 200 kg spindle taper MT: ISO 40 (hydr. Spannung) spindle head swivable left - right: 90° (manuell) ° quill stroke: 80 mm feed range: X/Z: 1 - 3000 und Y: 1 - 4000 und B: 0,1 - 3000°/min. mm/min rapid traverse:: X/Z: 10 und Y: 8 und B: 20 U/min. m/min control voltage: 110/220 V total power requirement: ca. 20 kVA Weight approx.: 5,5 t dimension machine xH: 3,0 x 2,4 x 2,25 m space requirements of the machine approx.: 5,2 x 5,0 x H: 2,3 m NC rotary table Ø 520 mm with A and B axes Adjustable three-phase motor with 4-stage reduction gear Working spindle can be swiveled out for horizontal spindle Equipment: -manual control unit -coolant device -machine ilumination *

Condition: like new (used), Like-new tilting and swiveling rotary table Length: 800 mm Width: 300 mm Lasdpjy Ul D Rofx An Ijd

Year of construction: 1982, condition: good (used), machine/vehicle number: 75 810, table mounting size: 630 Ø mm movement x: 600 mm movement y: 450 mm movement z: 500 mm tailstock stroke: von Hand 80 mm Ledpfx Ajby Hhton Iead spindle taper: ISO 40 spindle turning speed range: 20 - 3150 rpm carriages continuously adjustable: 1 - 3000 mm/min rapid move: 4 m/min electrical connection: 380 V kW space needed: 2000 + 850 x 2000 x 2000 mm weight: 3300 kg

Year of construction: 1972, condition: ready for operation (used), Spindle-to-table distance min./max.: 81mm/481mm, counter support spindle center distance: 195mm, spindle head swivel: 360°, milling spindle diameter: 70mm, spindle adjustment: 100mm, headstock adjustment: 300mm, table dimensions X/Y: 480mm/820mm, travel X/Y/Z: 500mm/200mm/400mm, max. workpiece length: 400mm, spindle speed: 1600rpm, feed X/Y: 500mm/min, feed Z: 250mm/min, spindle head swivel: +/-30°, machine dimensions X/Y/Z: approx. 1600mm/2550mm/1700mm, weight: approx. 2300kg. The machine was electrically tested at the end of 2025 and a defect of the emergency stop switch was discovered. Documentation available. On-site inspection is possible. Lsdpex S Rcmefx An Ijad

Condition: ready for operation (used), Year of construction: 1989, Travel X/Y/Z: 700mm/500mm/600mm, speed: 6300rpm, power: approx. 10kW, feed X/Y/Z: 4m/min, rapid traverse X/Y/Z: 10m/8m/10m/min, machine dimensions X/Y/Z: approx. 4500mm/2300mm/2500mm, weight: approx. 6000kg, operating hours: 65425h. On-site inspection is possible. Ljdjwmqxkspfx An Ijad

Condition: ready for operation (used), Deckel Maho 5100027000 touch panel for Deckel Maho CNC 432 control unit, serial number as shown in the photo, used, with normal signs of wear, 100% functional, scope of delivery as shown in the photos. Ledpfxoi D Upge An Ioad

Condition: used, functionality: fully functional, We offer this used Hahn+Kolb MH700 milling machine, year of manufacture unknown. Lajdpfoy Nkamex An Iod Operating voltage: 380 V Frequency: 50 Hz Control voltage: 220 V Rated current: A Main fuse: 15 A Wiring diagram no.: 7102 If you have any questions or require more information, please feel free to send us a message or call us.

Year of construction: 1986, condition: ready for operation (used), Travel X/Y/Z: 700mm/500mm/450mm, table dimensions X/Y: 900mm/500mm, max. table load: 500kg, spindle mount: SK40, speed: 3150rpm, quill stroke: 100mm, feed: 3m/min, rapid traverse: 6m/min, machine dimensions X/Y/Z: approx. 3550mm/3150mm/2100mm, weight: approx. 3600kg. On-site inspection is possible. Ljdpowkihxjfx An Ijad

Condition: ready for operation (used), Year of construction: 2005, operating hours: 20,729 h, functionality: fully functional, travel distance X-axis: 980 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, controller model: Heidenhain iTNC 530, rotational speed (max.): 18,000 rpm, TECHNICAL DETAILS Travel range X-axis: 980 mm Travel range Y-axis: 630 mm Travel range Z-axis: 630 mm Spindle speed range: 0–18,000 rpm Tool holder: HSK 63 MACHINE DETAILS Control system: Heidenhain iTNC 530 Clamping area: 1,250 × 700 mm Operating hours Ledpfszmry Tsx An Isad Machine operating hours: 46,922 h Program runtime: 20,279 h Spindle operating hours: 20,746 h EQUIPMENT Fixed angular table 3D measuring probe Heidenhain Tool measurement in the working area with BLUM laser Vertical tool changer with 32 magazine slots Full protective enclosure with sliding doors and interior lighting Electronic handwheel Operating modes 3 and 4 Chip conveyor Coolant system 3 height-adjustable machine feet Spindle cooler Control cabinet cooler from Rittal Operating manuals

Condition: excellent (used), Year of construction: 1999, X-axis travel: 1,250 mm Ledpfx Ansgypabe Isad Y-axis travel: 880 mm Z-axis travel: 800 mm Main spindle: Speed range – main spindle, max. 12,000 rpm Drive power – main spindle: 15 / 10 kW Table surface area: 1,500 x 1,050 mm Number of tool positions: 30

Condition: used, CNC 3+2 axis vertical machining center DECKEL MAHO type DMU 35 M CNC control SIEMENS 810D with ShopMill Manufacturer no. 11065353554 Year of manufacture 2001 Travel paths: X: 350 mm, Y: 240 mm, Z: 340 mm Table movements: C-axis: 360° Swivel range: +105° / -15° Universal swivel - rotary table: 400 x 290 mm, center hole 30H6 Table load: max. 100 kg Distance spindle nose - table: min. 145 mm to max. 485 mm Feed rate: 5,000 mm/min Rapid traverse (X / Y / Z): 5 m/min Lsdpfovt D D Ujx An Ioad Input resolution: 0.01 mm Total power requirement: 15 kVA Speed range - main spindle: 20 - 6,300 min/-1 Drive power - main spindle: 6.3 / 10 kW (100% / 40% ED) Torque: max. 55 / 80 Nm Tool holder: SK 40 DIN 69871 Pull bolt: DIN 69872 or ISO 7388/2 Type B Interface: Serial RS232C, LAN (RJ45) Power connection: 400 volts, 50 Hz, 15 kVA Compressed air connection: 6 bar - CNC control Siemens Sinumerik 810D with ShopMill V05.03.22, NCU 03.03.34-CCU1E, MMC103 - 3-axis controlled (X, Y and Z axis) - Manual swivel rotary table, C axis = table rotation 360°, B-axis = swivel range +105°/ -15° - direct path measuring system for all 5 axes - electronic handwheel - spindle drive via servo motor with toothed belt and 2 gear stages - fully protected cabin with sliding door - swiveling control panel - coolant nozzles on the vertical head - chip tray with coolant container and cooling lubricant pump - work area lighting - documentation available space requirement L x W x H 2000 x 2000 x 2100 mm weight 1750 kg good condition

Condition: used, Vertical milling head, milling head, angle milling head MAHO suitable for MH300 or MH400. Year of manufacture approx. 1990. Tool holder: SK 40. Quill stroke: 60 mm. Centering diameter on the flange plate: 102 mm. Outer diameter of flange: 180 mm. Bolt circle on flange plate: Ø 150 mm. Mounting holes on flange plate: 4x Ø 11 mm. - Quill feed: 0.015 / 0.03 / 0.06 / 0.12 mm/rev. - Head drive via shaft Ø 32 with 10 mm keyway. - Knurled wheel with scale for quill stroke. - Angle scale on angle milling head 2x 90°. Dimensions L x W x H: 300 x 280 x 300 mm. Total weight: 31.4 kg. In good condition. Lodpfx Anexf Ur No Iead

Condition: used, Universal Tool Milling Machine MAHO Type MH 800 P with digital readout and HEIDENHAIN TNC 121 contouring control . 80983 Year of manufacture: 1982 Machine overhauled by MMD in 2008, subsequently used only occasionally in the workshop of an electronics company. Travel X: 700 mm, Y: 450 mm, Z: 500 mm Table size: 1050 x 627 mm Spindle taper: ISO 40 Spindle speed: 40–2000 rpm, 18 steps Feed X, Z-axis: 10–500 mm/min, stepless Feed Y-axis: 5–250 mm/min, stepless Rapid traverse X, Z-axis: 1.4 m/min Rapid traverse Y-axis: 0.7 m/min Quill vertical travel: 100 mm Quill feed, vertical: 0.02 / 0.03 / 0.05 / 0.08 / 0.12 / 0.2 mm/rev Quill horizontal travel: 100 mm Spindle drive: 5.5 kW Power supply: 380 Volt, 50 Hz, 10 kW - NC contouring control HEIDENHAIN TNC 121 - Vertical milling head with automatic quill feed 0.02–0.2 mm/rev (6 steps) - Hydro-mechanical tool clamping - Coolant system integrated in the machine base - Universal rotary table, 360° rotatable, tilts and swivels 30°, 225 mm cross adjustment - Rotary table with direct indexing 72 x 5° and indirect indexing via index plate 1:120 = 1 rev = 3° - Swiveling control panel - Central lubrication - Operating manual - Machine mounted on steel plate L x W x H 1400 x 1000 x 50 mm = 550 kg Space requirements L x W x H 2650 x 2000 x 2450 mm Lajdpfxjv Amrye An Ied Weight: 3700 kg + 550 kg steel plate Total weight: 4250 kg (actual) Very good condition

Condition: used, CNC tool milling machine MAHO, type MH 400 E Ljdpfjh Ic Ufex An Ijad Machine no. 43072, year of manufacture 1989 Travel distances X: 400 mm, Y: 250 mm, Z: 375 mm Table size 700 x 270 mm Distance spindle nose / table max. 410 mm Tool holder ISO 40 with draw bolt type B Spindle speed 80 - 4000 rpm, 18 steps Feed rate 1-1500 mm/min, stepless Rapid traverse (X, Z and Y) 2.5 m/min. Quill travel, vertical 50 mm Spindle drive 2.2 kW Power connection 400 Volt, 50 Hz, 19 kVA - swiveling control panel with CNC path control PHILIPS 432 - LCD monitor VISCOTECH - hydro-mechanical tool clamping system - pivoting device for the vertical milling head - splash guard cabinet as a table enclosure with 3 fold-up doors - electrical control cabinet fixed to the machine - V24 (RS 232) interface for data transfer - 52470 operating hours, main switch on - fixed angular table - coolant system with coolant pump located next to the machine - central oil lubrication system Vogel - operator's manual, electrical wiring diagram Space requirement L x W x H 2250 x 1800 x 1850 mm Weight approx. 1.5 tons good condition

Condition: used, DECKEL MAHO DMC 60 U 5-axis universal machining centre, built 2002. Travels 600 x 700 x 600 mm with rapid traverse up to 40 m/min. The 12.000 rpm motor spindle in SK 40 DIN 69871 delivers 28 kW (40% ED) / 19 kW (100% ED) and is carried by an automatic universal swivel milling head with controlled B axis, working together with an NC rotary table to give full 5-axis capability. Siemens SINUMERIK 840D 3D path control. Rotary pallet changer with 2 pallets of 630 x 500 mm, 600 kg each, plus clamping hydraulics for hydraulically actuated fixtures on the rotary table and pallets. 60-pocket SK 40 magazine with horizontal double-gripper changer. Fitted with internal coolant supply and a 900 l coolant tank, chip conveyor, RotoClear rotating viewing window and Blum laser tool measurement in the work area. Lajdpoznffrjfx An Ijd

Condition: good (used), Year of construction: 2006, machine/vehicle number: 2329200, functionality: fully functional, operating hours: 33,674 h, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, overall weight: 11,000 kg, table length: 700 mm, table width: 900 mm, spindle speed (max.): 16,000 rpm, table load: 800 kg, 5-axis machining center, manufacturer: DECKEL MAHO, type: DMU 80 P duoBLOCK, year of manufacture: 2006, operating hours (h): 33,674, serial no.: 2329200, travel (X/Y/Z): 800/800/800 mm, max. spindle speed 16,000 rpm, HSK 63 tool holder, HEIDENHAIN Mill Plus IT control, G7 function, internal coolant supply, 60-position tool changer, chip conveyor, DMG filter system, serial no.: 13812-01560, DMG WK331 cooling unit. Ljdpfxorkz Rgs An Isad

Condition: good (used), Year of construction: 1997, machine/vehicle number: 570035, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, travel distance X-axis: 710 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 520 mm, total height: 3,300 mm, total length: 4,600 mm, total width: 5,500 mm, overall weight: 6,000 kg, table length: 700 mm, table width: 500 mm, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 10 m/min, spindle motor power: 25,000 W, rapid traverse Z-axis: 30 m/min, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, spindle speed (max.): 12,000 rpm, spindle speed (min.): 20 rpm, Equipment: documentation/manual, 5-axis machining center, manufacturer: DECKEL MAHO, type: DMU 70 V, year of manufacture: 1996, serial no.: 570035, travel X/Y/Z): 710/520/520 mm, HEIDENHAIN control, max. spindle speed 12,000 rpm, 60-fold tool changer, compact filter system INTERLIT SUK200/900, year of manufacture: 1997, filling volume 900 l, filter surface 0.2 m³, chip conveyor, internal coolant supply Lasdpfx Aorkz A Isn Ied Comment: 1 tool changer defective

Condition: good (used), Year of construction: 1996, machine/vehicle number: 54634, functionality: fully functional, operating hours: 51,997 h, power: 10 kW (13.60 HP), input voltage: 400 V, type of input current: three-phase, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, workpiece weight (max.): 500 kg, total height: 2,400 mm, total length: 2,600 mm, total width: 1,800 mm, overall weight: 3,500 kg, feed rate X-axis: 6 m/min, feed rate Y-axis: 6 m/min, feed rate Z-axis: 6 m/min, mount diameter: 40 mm, rapid traverse Z-axis: 60 m/min, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, spindle speed (max.): 15,000 rpm, spindle speed (min.): 10 rpm, Equipment: documentation/manual, 5-axis machining center, manufacturer: DECKEL MAHO, type: DMU 50 V, year of manufacture: 1996, operating hours (h): 51,977, serial no.: 054 634, travels (X/Y/Z): 500/380/380 mm, machine on 21,341, max. spindle speed 15,000 rpm, tool holder SK40, Heidenhain control, chip conveyor, 24-fold tool changer, compact filter system INTERLIT SK200-760, year of manufacture: 21,341, max. spindle speed 15,000 rpm, tool holder SK40, Heidenhain control, chip conveyor, 24-fold tool changer, compact filter system INTERLIT SK200-760, year of manufacture: 1996, tank capacity 600 l, filter area 0.2 m² Ledpfxerkzyas An Iead

Condition: excellent (used), Year of construction: 2006, machine/vehicle number: 11460000643, functionality: fully functional, operating hours: 35,319 h, input voltage: 400 V, type of input current: three-phase, travel distance X-axis: 1,250 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 10,000 mm, spindle speed (max.): 10,000 rpm, spindle speed (min.): 10 rpm, 5-axis machining center, manufacturer: DECKEL MAHO, type: DMU 125 P duoBLOCK, year of manufacture: 2006, operating hours (h): 35,319, serial no.: 11460000643, travels (X/Y/Z): 1,250/1,000/1,000 mm, spindle speed max. 10,000 rpm, 60-fold tool changer, B-axis, 190° swivel, HEIDENHAIN Mill Plus control, internal coolant supply, tool measuring system, chip conveyor, DMG filter system, serial no.: 13812-01560, DMG WK331 cooling unit. Laodpfx Anerkz Tfe Iod

Condition: excellent (used), Year of construction: 2004, operating hours: 8,909 h, travel distance X-axis: 630 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, controller manufacturer: Heidenhain, controller model: iTNC 530, workpiece weight (max.): 500 kg, total height: 2,700 mm, total length: 2,800 mm, total width: 2,700 mm, table width: 500 mm, table length: 800 mm, overall weight: 4,500 kg, spindle speed (min.): 10,000 rpm, Year of manufacture: 2004 CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 630 Y-axis travel mm: 500 Z-axis travel mm: 500 Worktable Table dimensions mm: 800x500 Max. workpiece weight kg: 500 Spindle Spindle speed rpm: 10000 Spindle drive power kW: 9/13 (40/100% ED) Cooling Cooling through the spindle center: 15 Tank capacity: 750 Tool system Tool holder: SK 40 Lodpszn Awrjfx An Isad Tool magazine slots: 24 Equipment Electronic handwheel Chip conveyor Internal coolant supply Operating mode 4 Air blowing through the spindle center, selectable via M-function Measuring probe Machine running times Under power: 34476 Spindle working: 8909 Rated power kVA: 32 Basic machine dimensions / weight Length mm: 2800 Width mm: 2700 Height mm: 2700 Weight kg: 4500
