Used Precision Surface Grinding Machine for sale (67,870)

Condition: excellent (used), FANUC Power Mate control Grinding range 800 x 400 mm Wheel diameter / width / bore 250/ 50 / 127 mm Magnetic plate 800 x 350 mm Misc. accessories Tsdpfx Aeyla Nuoirsd MARCELS MASCHINEN CH

Condition: ready for operation (used), functionality: fully functional, grinding length, max. 600 mm Table clamping surface 600 x 200 mm Magnet dimensions 500 x 200 mm Maximum distance between table surface and center of the grinding spindle 495 mm Grinding wheel dimensions (D x b x d) 250 x 25 x 51 mm Grinding spindle drive 5.5 kW Tsdpfx Aioz Ayqxjrjd

Condition: used, Year of construction: 1967, grinding length 450 mm grinding width 250 mm workpiece height 275 mm table surface area 550 x 200 mm distance spindle center to table max. 400 mm table speeds 0 - 30 m/min cross feed 0 - 60 mm/Hub Tedpfozwxxdsx Airod rapid traverse cross 1,2 m/min grinding wheel size ø 250 x 30 x ø 51 mm grinding spindle speed 1400 / 2800 U/min total power requirement 4 kW weight of the machine ca. 1 t dimensions of machine L x W x H 1,55 x 1,23 x 1,80 m Accessories: magnetic plate 450 x 200 mm, grinding wheel with flange, wheel trueing attachment

Year of construction: 1981, condition: ready for operation (used), Table dimensions X/Y: 900mm/300mm, max. grinding length: 900mm, max. grinding width: 350mm, max. table to spindle center distance: 575mm, max. table load: 670kg, max. table longitudinal movement/cross movement: 859mm/300mm, grinding spindle speed: 2800rpm, grinding wheel outer diameter min./max.: 400mm/165mm, bore diameter for 400mm: 127mm. Machine dimensions X/Y: approx. 1100mm/1100mm, weight: approx. 3100kg. Documentation available. On-site inspection is possible. Tsdpfxox Tul Uj Aired

Condition: good (used), Surface grinding machine Manufacturer: Harig Stock number: 2965-4 Year of manufacture: Machine number: Type: Super 612 Grinding length: 300 mm Grinding width: 175 mm Table clamping surface: 300 x 150 mm Magnet: 250 x 120 mm Vertical adjustment: 250 mm Table movement, longitudinal: 330 mm, manual Table movement, transverse: 175 mm, manual Spindle speed: 3,600 rpm Grinding wheels: 200 x 20 x 51 mm Connection: kW Accessories/Equipment: Tjdpfx Aiez Hzyyerjd Condition: good Weight: t Dimensions: 870 x 900 x 1,900 mm

Condition: ready for operation (used), functionality: fully functional, grinding length: 800 mm, grinding width: 350 mm, Magnet, 800 x 350 mm. Todozimmmspfx Airod

Condition: used, machine/vehicle number: 62220966, Max. grinding wheel diameter: approx. 250 mm, grinding area: 350x150 mm, with magnetic clamping plate, machine light, and coolant system. Todoz Nhr Njpfx Airjd

Condition: excellent (used), Year of construction: 1988, functionality: fully functional, grinding length: 600 mm, grinding width: 375 mm, grinding height: 375 mm, grinding wheel diameter: 300 mm, grinding wheel width: 50 mm, Equipment: documentation/manual, Very well-maintained ELB surface grinding machine with automatic feed Type: Optimal 6375 ND Year of manufacture: 1988 Grinding area: 600 x 375 x 375 Grinding wheel: 300 x 50 x 76.2 mm Accessories: Magnetic chuck with adjustable holding force (600 x 350 mm), paper band filter system, operating manual. Todjzxn H Hepfx Airjd

Condition: used, Year of construction: 1988, functionality: fully functional, grinding length: 1,200 mm, grinding width: 400 mm, total height: 2,900 mm, total length: 4,500 mm, total width: 2,400 mm, grinding wheel width: 70 mm, overall weight: 5,500 kg, travel distance X-axis: 1,200 mm, travel distance Y-axis: 400 mm, We provide spare grinding wheels for the machine (2-3 pieces). A centering stand is included. This machine was used in our own production and is currently not in operation, but it was moved and stored in perfect working order. Tedpfsz Hw T Njx Aired During transport, we will assist with loading using our own crane, provided that a truck with top-loading and side-opening capabilities is used.

Condition: defective spare-parts repository (used), Year of construction: 1997, grinding length: 880 mm, grinding width: 510 mm, grinding wheel width: 100 mm, spindle speed (max.): 4,300 rpm, overall weight: 7,500 kg, power: 26 kW (35.35 HP), Surface Grinding Machine Manufacturer: JUNG Model: C 740-E Year of manufacture: 1997 Control system: Siemens Technical specifications: - Grinding length: 880 mm - Grinding width: 510 mm - Max. speed: 4,300 rpm - Grinding wheel diameter: 210 – 400 mm - Grinding wheel width: 100 mm - Total power requirement: 26 kW - Machine weight: approx. 7.5 t The machine is untested and is offered as a source of spare parts! Tedjwwl N Sspfx Aired Accessories, tools, and workholding devices shown are included in the scope of delivery only if noted in the additional information. Subject to technical changes, errors, and prior sale.

Year of construction: 1989, condition: used, Max. grinding length: 600mm, max. grinding width: 400mm, max. working height with new/worn grinding wheel: 550/650mm, max. workpiece weight: 300kg, clamping surface: 1020x300mm, number of T-slots: 1, T-slot width: 10mm, max. height above floor level: 1005mm, dimensions: 3140x2900x2140mm, weight: 2.9t, with electromagnetic chuck: 600x300mm and coolant system. An on-site inspection is possible. Tedpfxo Adt Hyo Airsd

Year of construction: 1959, condition: used, Operating voltage: 380V, connected load: 3.05kW, weight: 1.1t, an on-site inspection is possible. Tedpj Aalnzjfx Airjd

Condition: used, max. grinding length: 300 mm max. grinding width: 150 mm Todpfx Aier Nyatorsd table movement - longitudinal: 2 - 20 m/min grinding plate rotations: 3000 Upm electrical connection: 380 V, 1,1 kW space needed: 1500 x 1100 x 1750 mm weight: 920 kg

Condition: used, Year of construction: 1961, Technical details: grinding length: 600 mm grinding width: 200 mm workpiece height: 270 mm grinding length: mit Magnet: 500 mm Distance Spindlecenter - clamping surface area, min:: 350 mm grinding spindle speed: 1000...4700 U/min table surface area: 720 x 200 mm Tsdju Ngg Ujpfx Airod table load capacity: 60 kp magnetic plate size: 455 x 180 (Gleichstrom) mm magnetic-table: vertical kippen 90° längs Stück total power requirement: 2,0 (2,7 PS) kW weight of the machine ca.: 1600 + 176 kg Gleichrichter kg dimension machine xH: 1,4 x 1,8 x 1,7 m transport measurements machine: 1,4 x 1,8 x 1,6 m dimensions electric cabinet: L: 850 x B: 450 x H: 1.100 mm dimensions of grinding wheel: Ø 225 x 20 x Bohrung Ø 51 mm mm The magnetic plate (24V) is cooled. Grinding spindle: The grinding wheel infeed is electric, vertical 270mm, infeed z-axis 0,002 mm to unlimited inching infeed 0,001 - 0,010mm Peripheral speed max 35 m/sec. allowed equipped with coolant tank, pump and magnetic separator, as well as grinding wheel - size Ø 152 x 14mm plus various accessories (in the cabinet) like some grinding wheels and balancing flange The machine is pre-equipped for an exhaust system. *

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 196520 € Tsdpfx Aoxpizmjired 3714.23 € 2000 mm 730 mm 2000 x 600 mm 2x 1000 x 600 mm 2100 mm 5 - 30 m/min 0 - 2250 mm/min mm 685 mm 0 - 675 mm/min 0.001 - 0.04 mm 560 mm 500 - 2200 1/min 11 kW 5.5 kW 6225 mm 07 mm 2305 mm 6530 × 00 ×3350 (brutto mm 10200 kg 1600 kg 1150 kg 1600 kg Dm. 405 x 75 x 127 mm je 3,1 kW 10.4" graphic NC control on a swivel arm with touchscreen for: Operating mode selection Cycle selection and program creation Surface grinding Cross grinding Plunge grinding Dressing with automatic compensation Semi-automatic balancing in the machine Automatic spindle speed for constant surface speed Spindle load visualization Unbalance control Graphical status monitoring Alarm list Max. table speed 30 m/min Integrated machine body temperature control Turbide-coated double V-guides Hydraulic table drive with cooling Linear guides with recirculating ball screws and AC motors for precise positioning in the X and Z axes Automatic lubrication with a pressure switch for automatic stop in case of pressure drop Electro-magnetic chuck 2x 1000 x 600 mm Coolant system with automatic paper filter and magnetic separator (500 l) Automatic dressing device mounted on the table, without diamond, with automatic compensation Grinding wheel flange with 1 grinding wheel Grinding wheel balancing stand LED machine light Machine and equipment according to CE regulations Operating manual in GERMAN or ENGLISH OPTIONS (PRICES ON REQUEST): Complete enclosure of the work area Oil mist extraction

Condition: good (used), Year of construction: 2001, functionality: fully functional, Technical details grinding length 4200 mm grinding width 1300 mm workpiece height 550 mm Control SIEMENS 840 D magnetic clamping plate 4200 x 1300 mm segment head diameter 1400 mm grinding motor turning speeds up to 320 U/min. grinding motor 306 kW weight of the machine ca. 50,0 t Additional information Segment dimensions: 120/106 x 41 x 250 mm Number of segments: 1 set = 26 pieces Grinding motor feed: 0.5 - 35 m/min, infinitely variable Grinding motor feed: - in steps: 0.002 - 1 mm continuous: up to 5 mm/min. infinitely variable Equipment: * CNC-control SIEMENS Sinumerik 840 D * Automatic hydr. swivelling of the grinding motor from hollow to cross grinding * NC-controlled adjustment of the Marposs measuring head by means of precision support. - new grinding dimensions can be entered into the control, whereby the the grinding head automatically adjusts to the corresponding height. * Dresser with adjustment axis in the machine bed * Coolant system * Electro-magnetic table * Switch cabinet * Oil mist extraction Tsdpfx Aiez Rnrlorjd * Documentation Dimensions (length x width x height) Bed: 11800x2200x1400 mm, weight 27500 kg Grinding head: 3000 x 2500 x 3100 mm, approx. weight 16 t 2 x Oil mist extraction: 1200 x 800 x 2000 mm each Control panel: 1200 x 800 x 400 mm Small control cabinet: 1400 x 1400 x 800 mm 2 x gears each 1200 x 800 x 500 mm Control cabinet: 1600 x 800 x 2000 mm Control cabinet: 3400 x 600 x 2400 mm

Year of construction: 1988, condition: used, Operating voltage: 3x 380V, frequency: 50Hz, rated current: 40A, fuse protection: 50A, control voltage: 220V, DC voltage: 215/323V, an on-site inspection is possible. Todpfxoz S Iw Do Aired

Condition: used, Year of construction: 2007, grinding wheel diameter: 400 mm, table load: 800 kg, grinding wheel width: 100 mm, overall weight: 5,700 kg, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, Horizontal Surface Grinding Machine Manufacturer: ABA Z&B Model: ECOLINE 806 E Year of manufacture: 2007 Control system: SIEMENS 840D powerline Technical details: Spindle motor: 11 kW Grinding wheel diameter: 400 mm Grinding wheel width: 100 mm Max. table load: approx. 800 kg X-axis: 800 mm Y-axis: 700 mm Z-axis: 600 mm Machine weight approx.: 5,700 kg In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and workholding devices shown are included in the scope of delivery only if specified in the additional information. Tjdpfxszy Sine Airsd Subject to changes and errors in technical data and specifications, as well as prior sale!

Condition: used, Year of construction: 2000, grinding length 1600 mm grinding width 600 mm workpiece height 500 mm Tedpfx Aijt Hxcbored total power requirement 50 kW

Condition: used, Diskus Werke DSH 600/1000 Surface Grinding Machine This machine type is a machine with a motor-driven grinding spindle. The workpieces are clamped and ground using clamping devices adapted to the specific task. The devices are attached to the machine bed. The column carriage, on which the motor spindle is mounted, serves as a feed, dressing, and oscillating slide. Manufacturer: Diskus Type: DSH 600/1000 Operating voltage: 380 V DC voltage: 24 V Control voltage: 220 V Rated power: 27 kW Rated current: 56 A Year of manufacture: 1964 Condition: used You can find more items – new and used – in our shop! International shipping costs available upon request! Tjdpohtyudofx Airjd

Condition: used, Year of construction: 2004, grinding length 800 mm grinding width 400 mm Tedo Afarropfx Airod workpiece height 550 mm table dimensions 1.200 x 400 mm speed spindle max. 1.000 U/min. feed x-axis 40.000 mm/min weight of the machine ca. 4,10 t

Condition: used, Year of construction: 2001, grinding length 600 mm grinding width 400 mm workpiece height 350 mm table-size 820 x 350 mm Tjdpfxszi Ey Ss Aired dist. center of grinding spindle - table 140-525 mm table movement 660 mm workpiece weight max. 400 kg diameter / bore of grinding wheel 350 x 50 x 76,2 mm table speeds 2-28 m/min power capacity - grinding motor 3,7 kW total power requirement 8 kW weight of the machine ca. 2100 kg dimensions of the machine ca. 4,5 x 3 x 2,4 m Geipel & Hotz FS 60 AC surface grinder, built in 2001, in good condition

Condition: new, neu 050250 März 2027, Zwischenverkau Taiwan 83670 € 1581.36 € 810 mm 610 mm 800 x 400 mm 800 x 400 mm Tjdpfozwqa Hox Airsd 5 - 25 m/min 0 - 2.250 mm/min 450 mm 0 - 675 mm/min 480 mm 500 - 2200 1/min 3,75 (optional 5,5 / 7,5) kW 1.5 kW 3250 mm 3075 mm 2250 mm 2900 kg 175 kg 350 kg 355 x 50 x 127 mm 1,1 kW Fully enclosed splash guard 10.4" graphic NC control on a swivel arm with touchscreen for: Operating mode selection Cycle selection and program creation Surface grinding Cross grinding Plunge grinding Dressing with automatic compensation Semi-automatic balancing in the machine Automatic spindle speed for constant surface speed Spindle load visualization Unbalance control Graphical status monitoring Alarm list automatic vertical feed servo drive for grinding wheel feed and table cross feed heavy duty spindle with 2 sets (4) of class P4 super precision angular contact ball bearings hardened and ground C2 grade ballscrew on crossfeed and elevation hardened slide ways electro-magnetic chuck coolant equiptment with aut. paper filter and magnetic separator (120 lt) oil mist collector autom. dressing attachment table mounted with compensation grinding wheel grinding wheel flange grinding wheel balancing stand LED machine lamp machine and equipment according to the CE-regulations user manual in GERMAN and ENGLISH OPTIONS (PRICES ON REQUEST): autom. dressing attachment mounted over the wheel version without fully enclosed splash guard

Condition: used, Year of construction: 2001, grinding length 4200 mm grinding width 1300 mm workpiece height 550 mm Control Siemens 840D Tjdpfx Aothumuoirod passage width 1300 mm electro-magnetic table 4200 x 1300 mm grinding height 550 mm grinding motor 306 kW grinding motor turning speeds up to 370 U/min grinding motor feed, infinitely variable 0,5-35 m/min coolant flow rate 2000 l/min weight of the machine ca. 50 t dimensions of the machine ca. 11,21 x 5,25 x 3,85 m Equipment / Accessories: - segment head - diameter 1400 mm - for segment dimensions 120/106 x 41 x 250 mm - number of segments: 1 set = 26 pieces - grinding motor adjustment - in steps: 0,002 - 1 mm - continuous: up to 5 mm/min stepless

Condition: good (used), > JONES & SHIPMAN 540 AP GRINDER - 1983 - Dual view > HEIDENHAIN > J&S 540 AP automatic surface grinder, 450x150 magnetic table. > 1983, in good condition, with dual Heidenhain visualization (Z and transverse). > Automatic feeds, coolant system, grinding wheel. Magnetic table. > 400V - 1100kg - Operational, removed from a precision mechanical workshop. > *Specifications:* > - Capacity: 450 x 150 mm magnetic > - Grinding wheel: 200 x 20 x 51 mm Tedpozxiwgofx Airod > - Longitudinal travel: 500 mm > - Spindle motor: 1.5 kW > - Weight: ~1100 kg > - 400V
