Used Machine Tools for sale (66,306)

Condition: used, Year of construction: 2014, Technical details: max. turning diameter: 350 mm turning length: 540 mm control: 0i-TD swing dia.: 510 mm bar material dia.: 66 mm spindle bore diameter: 76 mm travel -x axis: 200 mm travel -z axis: 560 mm Spindle 1 RPM: 4000 1/min Spindle 1 Power: 18,5 kW turret stations / rotary tool stations: 12/0 BMT 55 Rapid traverse feeds x/z: 24/ 24 m/min tailstock quill taper MT: MK4 (Live) Tailstock Travel: 490 mm tailstock quill stroke: 80 mm Kedpfoyv Erdox Abcjlp tailstock quill diameter: 75 mm dimensions of the machine ca.: 3500 x 1400 x 1850 mm total power requirement: 32 kW weight of the machine ca.: 4 t Accerories Chip conveyor Parts catcher Spindle 1 Chuck 200 mm manual tool eye Samsung turning center in excellent condition with rotary tools, y-axis and subspindle for complete manufacturing of components. *

Condition: used, Year of construction: 2015, Technical details: max. turning diameter: 350 mm turning length: 540 mm control: 0i-TD swing dia.: 510 mm bar material dia.: 52 (66) mm spindle bore diameter: 61 (76) mm travel -x axis: 200 mm Klsdpfxsyv En Ss Abcjp travel -z axis: 560 mm Spindle 1 RPM: 4000 1/min Spindle 1 Power: 18,5 kW turret stations / rotary tool stations: 12/12 BMT 55 Power rotary tools: 3,7 /2,2 kW RPM of rotary tools: 6000 1/min torque rotary tools: 26,2 Rapid traverse feeds x/z: 24/ 24 m/min tailstock quill taper MT: MK4 (Live) Tailstock Travel: 400 mm tailstock quill stroke: 80 mm tailstock quill diameter: 75 mm dimensions of the machine ca.: 3500 x 1400 x 1850 mm total power requirement: 32 kW weight of the machine ca.: 4 t Accerories Chip conveyor Parts catcher Spindle 1 Chuck 200 mm manual tool eye Samsung turning center in excellent condition with rotary tools, y-axis and subspindle for complete manufacturing of components. *

Condition: not inspected (used), Year of construction: 2014, machine/vehicle number: 12097, CNC Milling Machine XYZ SMX3500 The machine is in very well-maintained condition. ● Condition: Not inspected ● Delivery terms: Free on truck (FOT) Kjdpfeyvi Enjx Abcslp ● Location: 42477 Radevormwald, Germany ● Availability: By arrangement – Collection date for the item is set for 06.05.2026. Unfortunately, collection outside of this timeframe cannot be accommodated. ● Payment terms: Advance payment by bank transfer ● Internal ID: DÄ10 ● Power-on demonstration possible: Yes Technical specifications: ● Control: PROTO TRAK SMX ● Table dimensions: 1200 x 300 mm ● Spindle speed: 5,000 rpm ● Main drive power: 3.75 kW ● 400 V ● 50 Hz Scope of delivery: ● Available manuals (completeness not guaranteed) ● Hoffmann vice, jaw width: 125 mm ● Machine lamp Dimensions & weights: ● Installation dimensions (L x W x H approx.): 2000 x 2000 x 2500 mm ● Weight approx.: 2,500 kg If you have any questions or would like to arrange an inspection, please feel free to contact us! Additional notes: ► On request, we can offer transport to the destination ► The quoted price is net, plus VAT ► The goods are sold under exclusion of any warranty ► Technical data provided without guarantee ► Subject to prior sale ❗Sale of the item is exclusively to businesses❗

Condition: not inspected (used), Year of construction: 2014, machine/vehicle number: SL375, CNC Lathe XYZ SLX355 ● Condition: Unchecked ● Delivery terms: Free loaded on truck ● Location: 42477 Radevormwald, Germany ● Availability: By arrangement – The pickup period for the equipment is set for 06/05/2026 and 07/05/2026. Unfortunately, collection outside this timeframe cannot be accommodated. ● Payment terms: Advance payment – by bank transfer ● Internal reference number: DÄ5 ● Inspection under power: Yes Technical specifications: ● Control system: PROTO TRAK SLX ● Drive power: 5.5 kW ● Spindle speed: max. 4000 rpm Klodpfxjyvi A Te Abcop ● Turning length approx.: 750 mm ● Swing over bed approx.: 400 mm ● Swing over cross slide approx.: 180-200 mm Equipment: ● Three-jaw chuck (diameter: 200 mm) ● Tailstock ● Quick-change tool post Scope of delivery: ● Available manuals ● Set of quick-change tool holders with turning tools ● Four-jaw chuck (Röhm, diameter: 160 mm) ● Toolbox with accessories as shown in the images Dimensions & weight: ● Footprint (L x W x H) approx.: 2300 x 1400 x 1900 mm ● Weight approx.: 2000 kg If you have any questions or wish to arrange an inspection, please do not hesitate to contact us! Additional notes: ►Transport to the destination can be offered upon request ►The offer price is net plus VAT ►The equipment is sold with exclusion of any warranty ►Technical data provided without guarantee ►Subject to prior sale ❗Sale exclusively to business customers❗

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, travel distance X-axis: 785 mm, travel distance Y-axis: 470 mm, travel distance Z-axis: 530 mm, table width: 500 mm, table length: 900 mm, spindle speed (max.): 8,000 rpm, XYZ LPM Vertical Machining Centre Model: LPM Year: 2016 ‘X’ axis Travel: 785mm ‘Y’ axis Travel: 470mm ‘Z’ axis Travel: 530mm Kjdpfjyg N Aaox Abcjlp Table Size: 900 x 500mm Spindle Taper: BT 40 Spindle Speeds: 8000 RPM Automatic Toolchanger: 16 station

Condition: new, functionality: fully functional, machine/vehicle number: RM310119, feed length X-axis: 787 mm, feed length Y-axis: 508 mm, feed length Z-axis: 584 mm, quill diameter: 105 mm, table width: 355 mm, table length: 1,372 mm, type of input current: three-phase, rotational speed (max.): 5,000 rpm, rotational speed (min.): 40 rpm, table load: 600 kg, overall weight: 2,390 kg, input voltage: 400 V, workpiece weight (max.): 600 kg, warranty duration: 12 months, input current: 22 A, input frequency: 50 Hz, Built-in programming cycles: Position: Spindle positioning Drilling: Simple holes, holes on a circle Milled holes: Holes made by milling cutter – straight and circular Kjdowtnxnspfx Abcolp Arcs: Arcs in XY, XZ, and YZ plane Pockets: Rectangular, circular, irregular Island: Milling rectangular, circular, and irregular islands Profile: Rectangular, circular, irregular Helix: Spiral ramping Milling: Straight lines along X, Y, or Z axis or any combination Engraving: Text engraving Thread cutting: Thread cutting with tap Thread milling: Thread milling with form cutters Copying: Copying a series of cycles Mirror: Mirror image Rotation: Rotation around an axis Repetition: Repetition of a series of cycles G-code editor Clipboard

Condition: excellent (used), Year of construction: 2016, These machines are marketed as 2 opp machines and very good they are too but we consider them to be great little 1st opp machine in its own right. can be demonstrated Remarkable capacity for such a small machine. Machine has 6 tool holders Year: 2016 Control: ProtoTrak TMX Table Size: 457 x 381mm ‘X’ axis Travel: 355mm ‘Y’ axis Travel: 305mm ‘Z’ axis Travel: 455mm Spindle Speeds: 50 – 6000 RPM Spindle Taper: BT 30 Tool magazine capacity: 8 station Kljdpfeydvzdjx Abcjp Dimensions w x d x h: 760 x 1220 x 2585mm Weight: 1,100 kg can be demonstrated if required

Condition: used, Year of construction: 2015, XYZ 2-OP Vertical Machining Centre ProtoTRAK TMX Control (2015) Year of Manufacture: 2015 Spindle Speeds to 6,000rpm Spindle Taper BT30 Table Size 457 x 381mm Table Travels 355 x 305 x 455mm (XYZ) 6 Station ATC Rapid Traveres 15m/min Footprint 760 x 1,220 x 2500mm Weight 1100kgs 415V Electrics Air Require for ATC Klodpfx Ajya H Nkobcop For sale with *Jet Machinery Ltd* Jet Machinery Stock No: #79155 Machine Serial Number: SOP02060 Cost: £17,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: ready for operation (used), Year of construction: 2012, XYZ SLX555 x 3m ProtoTRAK Control Gap Bed Centre Lathe ProtoTRAK SLX Control (2012) Max. Distance Between Centres 3000mm Max. Swing over Bed 560mm Max. Swing over Gap 935mm Max. Swing over Cross slides 350mm Max. Cross slide Travel 290mm Spindle Nose D1-11 Spindle Bore 104mm Spindle Speeds 30 – 1800rpm Spindle Motor 15Hp Quick Change Tool Post Tailstock MT7 Tailstock Dia’ 75mm Tailstock Travel 160m Manufactured | 2012 Dimensions: L x D x H 5220 x 2150 x 1950 mm Weight 7400 kg Supplied with: 3 Jaw Chuck Machine Handbooks TRAKing®. Constant Surface Speed. Rapid Traverse with Joy Stick. QCTP & Holders 2 x Fixed Steadys 15” Interlocking Guards Auto Lubrication. Kjdpfoyaywhjx Abcolp Coolant. Worklight We can offer delivery & installation, operator training and warranties. *For sale with Jet Machinery Ltd* Jet Machinery Stock No: #79024 Machine Serial Number: SLM00035 £47,500.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: ready for operation (used), Year of construction: 2007, XYZ SMX SLV 3 Axis Turret Milling Machine ProtoTRAK | SMX Control (2007) 3 Axis CNC Capacity (X Axis, Y Axis & Quill) Kedpsx Tiq Ssfx Abcolp Spindle Taper ISO 40 Spindle speeds to 70 - 3600 RPM Table Size 1473 x 305mm Table Travel: X - 1000mm Y - 410mm Knee Travel: Z - 413mm Quill Travel Z - 127mm Air Power Draw Bar Supplied with a range of spindle tooling Coolant Year of Manufacture: 2007 Weight: 1850 Kgs Power Requirements: 18A *For sale with Jet Machinery Ltd* Jet Machinery Stock No: #79109 Machine Serial Number: 12308 Cost: £14,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: good (used), Year of construction: 2018, Table 1473 x 305mm, Traverses XYZ: 1000 x 410mm x 400mm (knee), quill travel 127mm, Kljdpfx Abjxftqdjcjp Spindle Taper ISO40, Power Drawbar, Spindle Motor 5HP, Spindle Speeds 70 - 3600rpm, Prototrak SMX CNC Control,

Condition: excellent (used), Year of construction: 2011, XYZ Proturn SLX 355 ProtoTRAK CNC Gap Bed Centre Lathe ProtoTRAK SLX Control (2011) Max’ Distance Between Centres 1000mm Max’ Swing over Cross-slide 225mm Max Swing over Bed 360mm Spindle Bore 52mm Spindle Speeds 50 – 4000 rev/min Spindle Motor 5.75Kw Quick Change Tool Post Tailstock MT4 Tailstock Dia’ 75mm Tailstock Travel 160m Manufactured | 2011 Supplied with: 3 Jaw Chuck Interlocking Chuck & Main Guards Machine Manuals 3 Toolholders (More available if required). TRAKing Constant Surface Speed Coolant Worklight Auto Lubrication For Sale with Jet Machinery Ltd Jet Machinery Stock No: #79003 Machine Serial Number: SL281 Cost: £22,500.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Kledpfx Asx D U Arjbcsp Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: excellent (used), Year of construction: 2021, XYZ RMX 3500 3 Axis CNC Bed Milling Machine ProtoTRAK RMX Control YOM 2021 Spindle: 5HP – Programmable 40 – 5000rpm 2 Ranges 40 – 600 & 300 – 5000rpm ISO40 Quill Dia 105mm Ksdpfex D Tbmox Abcjlp Table: 1370 x 355mm 4 0ff T Slots T Slot size 15.9mm Max load 600kgs Travel: X – 787mm Y – 508mm Head Vertical (Z) – 500mm Quill (Z) 127mm Dims without travel – 1905 x 2069 x 2225mm Dim with travel – 2758 x 2869 x 2490mm Weight 2430Kgs Power Requirements 22A Air Requirements 6bar YOM 2021 For Sale with Jet Machinery Ltd Jet Machinery Stock Number: #78900 Machine Serial Number: RM310097 £35,000.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: excellent (used), Year of construction: 2017, XYZ 2000 Turret Milling Machine (2017) (Ex College) Kjdpfx Abjxxb Rrocslp 3 Axis Newhall DRO (X, Y & Knee) Spindle Taper R8 Spindle speeds to 500 – 4200 rev/min Table Size 1270 x 254mm Table Travel: X - 812mm Y - 406mm Knee Travel: Z - 406mm Quill Travel Z - 127mm For sale with Jet Machinery Ltd Jet Machinery Stock No: #79047 Machine Serial Number: 12907 Cost: £9,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: used, Year of construction: 2005, XYZ Proturn VL425 ProtoTRAK Control Gap Bed Centre Lathe ProtoTRAK VL Control (Reconditioned 2025) Max’ Distance Between Centres 1250mm Max Swing over Bed 400mm Max’ Swing over Gap 700mm Spindle Bore 80mm Spindle Speeds 25 – 2500 rev/min Spindle Motor 10hp / 7.5Kw Quick Change Tool Post Tailstock MT5 Tailstock Dia’ 75mm Tailstock Travel 160m Manufactured | 2005 We can offer delivery & installation, operater training and warranties. Supplied with: 3 Jaw Chuck Tooling as photographed Machine Handbooks 3 Toolholders (More available if required). Tracking Coolant Worklight Kljdpext Ibysfx Abcop Auto Lubrication *For sale with Jet Machinery Ltd* Jet Machinery Stock No: #78938 Machine Serial Number: L247 Cost: £14,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: excellent (used), Year of construction: 2007, XYZ Proturn SLX 355 ProtoTRAK CNC Gap Bed Centre Lathe ProtoTRAK SLX Control (2007) Max’ Distance Between Centres 1000mm Max’ Swing over Cross-slide 225mm Max Swing over Bed 360mm Spindle Bore 52mm Spindle Speeds 50 – 4000 rev/min Spindle Motor 5.75Kw Quick Change Tool Post Tailstock MT4 Tailstock Dia’ 75mm Tailstock Travel 160m Manufactured | 2007 Supplied with: 3 Jaw Chuck Interlocking Chuck & Main Guards Machine Manuals 3 Toolholders (More available if required). TRAKing Constant Surface Speed Coolant Worklight Auto Lubrication Jet Machinery Stock No: #78986 Ksdpfjxawdkjx Abcjlp Machine Serial Number: SL286 Cost: £19,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: good (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 370648, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, feed rate X-axis: 2 m/min, feed rate Y-axis: 2 m/min, feed rate Z-axis: 2 m/min, quill stroke: 60 mm, rapid traverse X-axis: 5 m/min, rapid traverse Y-axis: 5 m/min, rapid traverse Z-axis: 4 m/min, mount diameter: 40 mm, table length: 800 mm, table width: 425 mm, total height: 2,000 mm, total length: 2,000 mm, total width: 2,000 mm, overall weight: 1,800 kg, table load: 250 kg, controller manufacturer: HEIDENHAIN, KUNZMANN WF 7/3 Tool Milling Machine - Operating voltage: 400 V - Frequency: 50 Hz - Rated current: 25 A - Connection: 13 kVA - T-slots: 6 - T-slot width: 14 H7 - Slot spacing: 63 mm - Max. distance table top to horizontal spindle center: 130 to 550 mm - Table top to bottom edge of vertical head: max. 480 mm - Tool holder: SK 40 - Speed range 1: up to 1125 rpm - Speed range 2: 1126 - 4500 rpm - Vertical quill stroke: 60 mm Klodpfx Absyvqv Iecjp - Vertical head swivels both sides: 90° - Feed longitudinal and cross: 0 - 2000 mm/min - Rapid traverse longitudinal and cross: 5000 mm/min - Vertical feed: 0 - 2000 mm/min - Rapid vertical traverse: 4000 mm/min Note: The item must be collected on a binding date yet to be agreed between 12.05. and 22.05.2026. FCA D-74821 Mosbach – loaded on truck.

Condition: good (used), Year of construction: 1989, functionality: fully functional, Technical details x-travel 400 mm y-travel 390 mm Kedsyv Abvopfx Abcolp z-travel 350 mm Control DIALOG4/CONTOUR 3 tool taper SK 40 spindle turning speed range 31 - 3150 U/min feed range 10 - 2000 mm/min weight of the machine ca. 1,7 t dimensions of the machine ca. 1.600 x 2.500 x 2.000 mm Additional information CNC control DIALOG4/CONTOUR 3 Table: 700 x 480 mm rigid angle table Swivel-type vertical milling head Coolant tank

Condition: good (used), Clamping surface of the fixed angle table: 195 x 605 mm Table travel longitudinal/vertical automatic and manual: 290/300 / 330/340 mm Spindle head transverse travel manual: 150 mm Spindle taper: ISA 40 16 spindle speeds: 40 - 2000 rpm 16 feeds: 10 - 500 mm/min Spindle drive motor: 380 V, 1/1.4 kW Kedpfx Ajyvgf Rjbcslp Weight approx.: 660 kg Space requirement: 1200 x 900 x 1570 mm

Condition: used, Year of construction: 1985, x-travel 710 mm y-travel 600 mm z-travel 500 mm NC-rotary table 630 mm spindle taper SK 40 spindle turning speed range 18 - 6300 U/min control DIALOG 4 feed 2 - 3600 mm/min rapid traverse 6 m/min table load max. 485 kg quill stroke 80 mm spindle drive 9,5 kW total power requirement 20 kVA weight of the machine ca. 4,6 t dimensions 3,8 x 2,24 x 2,35 m Accessories: vertical head with hydr. tool clamping and quill retraction, Kljdetqqtbepfx Abcop electron. handwheel, coolant

Condition: used, Year of construction: 1985, x-travel 485 mm y-travel 385 mm z-travel 380 mm table surface area 800 x 460 mm spindle taper SK 40 Kljdjtqqllepfx Abcop control CONTOUR 1 spindle turning speed range 50 - 2500 U/min feeds 10 - 1000 mm/min rapid traverse 2 m/min table load capacity 600 kg quill stroke 80 mm total power requirement 7,5 kW weight of the machine ca. 2,0 t dimensions 2,4 x 1,7 x 1,98 m Acc.: vertical head with hydr. tool clamping and quill retraction, solid table, coolant - movement of X/Y/Z also possible via handwheels -

Condition: new, neu ca. 4 Monate ab Auftragse Taiwan 48000 € 916.8 € 40 -3200 U/min ISO 40 600 x 500 x 400 mm 1000 x 500 mm 3.75 kW 1814 kg 1000 mm/min 8 14 x 63 mm 300 kg 600 mm 500 mm 400 mm 0 - 600 mm/min. 0 - 600 mm/min. 40 - 3200 40 - 3200 +/- 90° ° 100 mm manuell 3,75 kW 1200 x 250 mm 160 - 660 mm 95 - 495 (2. T-Nut), 180 mm swiveling operating panel 3 axes digital read out Fagor 400ib Innova motor for horizontal- and vertical spindle: 3,75 kW feed motors with inverter for X/Y/Z: 0,75 / 0,75 / 0,75 kW ball screw spindles for X/Y/Z axes manual gear box for spindle speeds 1 pc. long milling arbor 27 mm Kodpfx Aeyrhrqebcjlp 3 pcs. recustion sleeves (MK1, MK2, MK3) 1 pc. drawing bar ISO40 for horizontal or vertical spindle spindle protection with switch table safety guard with doors with switches outer arbor support for horizontal spindle LED work lamp automatic lubrication for X/X/Z guidways safety hand wheels for X/Y/Z axes coolant equipment with chip tray covers for X/Z axes level pads and bolts tool box with tools operating manual in English or German according to CE rules

Condition: used, Year of construction: 2004, gebraucht 2004 4540 ca. 2 Wochen ab Auftragse Österreich 19900 € 1 63 - 3150 (18) U/min 700 x 500 x 500 mm 900 x 500 mm 6.6 kW 2150 mm 2220 mm 2120 mm 2550 kg 500 kg 100 mm CNCHeidenhain TNC 410 18. mech. feeds with rapid travel in X,Y,Z axes ball screw spindles toolmaker accuracyDIN 8615 hyd. tool clamping with holdersSK40 vertical und horizontal vertical spindle+/- 30° swiveling Ksdpfx Ajwirmnobcslp swing out device digital 3D edge finder work area protection coolant equiptment aut. central lubrication fixed angle table with 10 t-slots chip collecting tray machine lamp users manual in GERMAN + CE COMPLIES WITH THE CURRENT INDUSTRIAL SAFETY REGULATIONS (AMVO & UVV)

Year of construction: 2012, condition: ready for operation (used), General Data Machine weight 15000 kg Main Drive Spindle motor power 45 kW This INGRAMATIC RP72 L was manufactured in 2012. It features a double starter unit with TR7 dies, capable of threading diameters from M14 to M20. The machine operates at speeds up to 120 rpm, powered by a robust 45 kW motor. Weighing 15,000 kg, it is in very good condition and ready for immediate shipment. CE compliant and includes Brankamp control process. Contact us for more information about this machine. Klodox D Dtgepfx Abcjp Application Types Other Machine Tools

Condition: excellent (used), Year of construction: 1992, 1 pre-owned, very well-maintained universal tool milling machine with 3-axis digital readout, brand HEIDENHAIN, and stepless speed adjustment Manufacturer: MAHO, Origin Germany Model: MH 1000 Year of manufacture: 1967 / geometrically overhauled in 1992! Working area Table size: 1250 x 740 mm Travel ranges X-axis: 1000 mm Y-axis (vertical): 600 mm Z-axis (transverse): 750 mm Manual cross traverse of the table: 275 mm Working spindle Tool holder (DIN 2079): ISO 40 Quill stroke of the vertical spindle: 125 mm Kodpoygctrofx Abcjlp Speeds and feeds Spindle speed range: 32 – 1600 rpm, steplessly adjustable Feed range X + Z axis: 10 – 500 mm/min Rapid traverse X + Z axis: 1.4 m/min Feed range Y axis: 5 – 250 mm/min Rapid traverse Y axis: 0.7 m/min Drive power: 5.5 kW Resolution of linear measuring systems: 0.01 mm Weight and space requirement Dimensions (L x W x H): approx. 2400 x 2400 x 1800 mm Weight: 5500 kg Accessories / Special features: • 3-axis digital display, brand HEIDENHAIN • Tool holder ISO 40, DIN 2079 • Universal clamping table (rotatable, tiltable, and swivelable) • Stepless speed adjustment via MITSUBISHI A 700 inverter (converted in 2006 with new control cabinet) • Spindle head with horizontal spindle • Central lubrication • Coolant system • Lighting Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany
