Used Stylus Grinding Machine for sale (84,075)

Condition: ready for operation (used), Year of construction: 2008, total height: 2,100 mm, overall weight: 3,000 kg, travel distance X-axis: 220 mm, travel distance Z-axis: 300 mm, controller manufacturer: FANUC, controller model: 31i-Model A, General Data Measurements width 1560 mm Measurements depth 2000 mm Measurements height 2100 mm Machine weight 3000 kg Control Unit Brand FANUC Model 31i-Model A Movement X-Axis Movement 220 mm Nedpsx D Ed Hofx Aanjdf X-Axis Rapid Traverse 20000 mm/min Z-Axis Movement 300 mm Z-Axis Rapid Traverse 20000 mm/min Additional Equipment Workpiece spindle motor: 2 kW This VOUMARD VM 110 CNC T was manufactured in 2008. A robust internal grinding machine, it features a GE FANUC Series 31i-Model A control, a maximum grinding diameter of 150 mm, and a depth of 80 mm. It supports a longitudinal travel (Z-axis) of 300 mm and a cross travel (X-axis) of 220 mm. Consider the opportunity to buy this VOUMARD VM 110 CNC T internal grinding machine. Contact us for more information. Application Types Grinding

Condition: ready for operation (used), Year of construction: 1986, operating hours: 1,200 h, functionality: fully functional, wheel width: 250 mm, helix angle: 45 °, type of input current: AC, travel distance Y-axis: 250 mm, feed rate X-axis: 12 m/min, stroke length: 400 mm, rotational speed (min.): 1,500 rpm, rotational speed (max.): 2,600 rpm, grinding wheel speed: 2,100 rpm, grinding spindle motor power: 1,500 W, gear diameter: 250 mm, overall weight: 3,730 kg, rotary table diameter: 200 mm, stroke adjustment: 400 mm, tool length: 280 mm, wheel diameter: 250 mm, distance table center to spindle nose: 607 mm, Equipment: sliding door, Grinding Machine STANKO 3A662 The STANKO 3A662 is a semi-automatic tool grinding machine designed for precision sharpening of worm milling cutters and gear cutting tools. Manufactured in the former USSR, this machine is known for its robust mechanical design, reliability, and long service life in industrial environments. The machine is capable of sharpening cutters with a maximum diameter of up to 200 mm and a maximum cutter length of approximately 280 mm. Grinding is performed using abrasive or diamond grinding wheels with diameters from 200 to 250 mm, allowing flexibility for different sharpening operations. The grinding slide provides a maximum stroke of 400 mm, with adjustable feed speeds depending on the spiral pitch of the cutter. The grinding head can be swiveled up to ±45°, enabling the sharpening of cutters with different helix angles. The grinding spindle operates at discrete speeds of 1500, 1900, 2100, and 2600 rpm and is powered by a 1.5 kW motor. The machine operates on three-phase AC power (220/380 V, 50 Hz). With an overall machine weight of approximately 2600 kg (up to 3730 kg including accessories), the rigid cast-iron construction ensures excellent stability and vibration damping during operation. Key Features -Semi-automatic grinder for worm milling cutters -Maximum cutter diameter: 200 mm -Grinding wheel diameter: 200–250 mm -Adjustable grinding slide stroke up to 400 mm -Swivel grinding head up to ±45° -Multiple spindle speeds: 1500 / 1900 / 2100 / 2600 rpm -Supports abrasive and diamond grinding wheels -Heavy-duty industrial construction Ndjdjx Nprbspfx Aanjf Typical Applications -Sharpening of worm milling cutters -Maintenance and reconditioning of gear cutting tools -Tool rooms and gear manufacturing plants

Condition: used, Year of construction: 2010, Centre distance: 400 mm Wheel speed: 2085 rpm Grinding wheel size: Ø355×38×Ø127 mm Hydraulic tank: 65 l Ndsdpfxex Hzz Ns Aansf Machine net weight: 2000 kg

Condition: used, Year of construction: 2014, Technical details: weight of the machine ca.: 6,5 t 3 identical machines available from OEM production The Junker Jucam 1S 51 is designed for grinding bearings and camshaft bushings (exhaust and intake). Parts are automatically fed and removed via an external loading cell. Njdpfsx Auufsx Aanodf *

Condition: ready for operation (used), Year of construction: 1982, operating hours: 120 h, functionality: fully functional, machine/vehicle number: 572, wheel width: 32 mm, helix angle: 45 °, type of input current: three-phase, workpiece weight (max.): 200 kg, stroke length: 160 mm, rotational speed (min.): 50 rpm, rotational speed (max.): 280 rpm, grinding wheel speed: 1,920 rpm, grinding spindle motor power: 1,500 W, grinding wheel bore: 127 mm, grinding wheel diameter: 350 mm, overall weight: 8,000 kg, grinding wheel width: 32 mm, rotary table diameter: 280 mm, stroke adjustment: 160 mm, table diameter: 280 mm, table load: 200 kg, wheel diameter: 350 mm, Gear Grinding Machine Stanko 5M841 / 5A841 The Stanko 5M841 (5A841) is a heavy-duty gear grinding machine designed for precision finishing of cylindrical gears with straight and helical teeth. This machine is widely used in industrial gear production and is known for its robust construction, reliability, and long service life. The machine is capable of grinding gears with helix angles up to ±45° and supports workpieces weighing up to 200 kg. Grinding is performed using disc-type grinding wheels with a diameter of 260–350 mm and a width of 16–32 mm, ensuring high accuracy and consistent surface quality. Ndodpfx Aajx I Ncdsnef The grinding wheel spindle operates at 1920 rpm and is driven by a 1.5 kW motor. The reciprocating stroke of the grinding slide is infinitely adjustable from 20 to 160 mm, with a variable stroke rate of 50 to 280 double strokes per minute, allowing precise adaptation to different gear sizes and grinding conditions. The machine is equipped with a rotary work table (Ø 280 mm) and is designed for continuous industrial operation. Power supply is 3-phase, 380 V, 50 Hz. With an overall machine weight of approximately 8000 kg, the 5M841 offers excellent stability during grinding operations. Key Advantages: -Suitable for straight and helical gears -Helix angle up to ±45° -Heavy, rigid cast-iron construction -Infinitely adjustable grinding stroke -Reliable mechanical design, easy maintenance -Ideal for medium and heavy industrial applications Typical Applications: -Precision gear finishing -Gear manufacturing and refurbishment -Mechanical engineering and heavy industry

Condition: used, Year of construction: 1998, Technical details: grinding diameter: 250 mm grinding length: 2710 mm max. module: min. module: total power requirement: 45 kW weight of the machine ca.: 15 t space required L x W X H: 7,1 x 4,7 x2,7 m max. wheel dia.: 450 mm Spindle drives Arena Siemens For Worm grinding we have not module, but pitch. Pitch is freely programmable from 0.001 to big value i.e. 500mm * Nsdpfxsudf E Aj Aanedf

Condition: used, Technical details: Nsdpfjrkr U Eex Aanodf grinding length: 600 mm centre height: 180 mm swing dia.: 360 mm workpiece weight: 80 kg max. dia. of grinding wheel: 500 mm grinding wheel width: 80 mm grinding wheel hole diameter: 203,2 mm peripheral speed: 45 m/sec There is also a 3200 liter coolant tank including cooling unit + fire extinguishing system. *

Condition: used, Year of construction: 1983, Technical details: internal diameter: 140 mm total power requirement: 5,5 kW weight of the machine ca.: 1,8 t dimensions of the machine ca.: 2,8 x 2,5 m max. workpiece weight: 15 kg clamping dia. max.: 140 mm clamping length: 250 mm max. bore diameter to be ground: 0,8-90 mm min./max. hole to grind: 160 mm Ndodsr R Elhjpfx Aanjf centre height: 90 mm workpiece spindle stepless: 112-1000 U/min

Condition: used, Year of construction: 2007, Technical details: weight of the machine ca.: 24 t dimensions of the machine ca.: 3900 x 3500 x 2500 m -the machine has no B axis -two grinding spindles with one grinding wheel each - The transport instructions can be found in the documentation (attachment). including Hoffmann KSM filter system Loading list available Operating data v. : Operating time: 21727 h / production time: 11960 h Machine documentation: 1 set of circuit diagrams, electrical plans, operating instructions Accessories: 2 replacement measuring heads Marposs S/500; prism supports Other: Hoffmann KSM filter system Machine condition: according to age, due to processing with emulsion * Njdpfx Aasx Aq Etsnodf

Condition: used, Year of construction: 2003, Technical details: grinding length: 1500 mm Ndjdpfx Aaox Hgilonjf weight of the machine ca.: 12 t Karstens EMAG H310 Universal Grinding Machine Year of manufacture: 2004 Center distance: 1500 mm Center height: 325 mm Reinforced workpiece spindle, load capacity up to 250 kg Driven C-axis for polygon, thread, and eccentric grinding. 3 individually mounted grinding spindles. Siemens 840D control system *

Condition: used, Year of construction: 1989, Technical details: Nsdpfsr R Elpjx Aanodf grinding diameter: 300 mm grinding length: 540 mm centre height: 175 mm total power requirement: 20 kVA centre distance: 1000 mm

Condition: used, Year of construction: 1990, Technical details: adjustment drive of the grinding de: 0,0025 - 0,05 mm total power requirement: 100 kW adjustment of grinding head slide: 150 mm weight of the machine ca.: 17 t grinding spindle drive: 2 x 37 kW grinding width: 30-150 mm Nsdpfxjvnmnro Aanjdf peripheral speed: 34 m/sec workpiece speeds: 60 - 300 mm/Sek. grinding height: 70 mm grinding wheel diameter: 750 mm grinding tools: 750 x 75 x 350 mm grinding wheel turning speeds: 870 U/Min. max. workpiece diameter: 250 mm

Condition: used, Year of construction: 2001, Technical details: max. wheel diameter: 280 mm max. module: 5 min. module: 1 min. number of teeth: 7 Ndodswh Dlmepfx Aanef toolpiece turning speed range: 4.000...10.000 U/min tool length: 210 mm CBN *

Condition: used, Year of construction: 1990, Technical details: Ndjdswwlu Iepfx Aanef dimensions of the machine ca.: 3,5 x 2,0 x 2,5 m

Condition: used, Year of construction: 2005, Technical details: grinding length: 400 mm workpiece weight: 250 kg weight of the machine ca.: 4,1 t Ndedjvap Ryopfx Aanef swing diameter: 250 mm grinding spindle speed: 2387, 2938 U/min

Condition: used, Year of construction: 2005, Technical details: Nsdpfxjvap S De Aanjdf grinding diameter: 20 mm grinding length: 20 mm max. workpiece diameter: 20 mm min. workpiece diameter: 1 mm grinding wheel diam. min/max.: 300-400 grinding wheel turining speeds: 2.000-7.000 U/min Weight: 950 kg dimensions: 1200 x 2100 mm

Condition: used, Year of construction: 2014, Technical details: grinding diameter max.: 3-220 mm regulating wheel width: 500 mm max. width of grinding wheel: 500 mm weight of the machine ca.: 16 t. dimensions of the machine ca.: 12 x 10 x 8 m. Ndodet Uw Avspfx Aansf grinding wheel diam. min/max.: 420-610 grinding wheel diameter - width-internal grin: 304,8 x 500 mm Regulatin wheel diameter min/max.: 300-350 mm The machine is currently designed for plunge grinding JUPITER's Centerless grinding, also available with CBN. Junker this circular grinding method with CBN grinding wheels, which opens up significant productivity benefits from the long service life of the grinding wheel, especially at high volumes. In addition, the simultaneous removal takes on the entire Schleswig-Holstein, which provides both in mass production and in small batches for significantly reduced processing times. The grinding process with JUPITER When centerless grinding, there are two grinding processes: the through grinding and plunge. Both methods are possible with the JUPITER. Applications through grinding: Pin and Bushings Body, rings, smaller rings, piston parts (eg compressors), waves with constant diameter piston rods (eg shock), Small piston for hydraulic and fuel injection, precision wires and rods, piston pins. Applications Plunge: Rotor shafts, transmission parts, bearing surfaces of camshafts, tube and pipe fittings for composite camshafts, universal joints, parts for needle injection, valve stems, barrel rolls. *

Condition: used, Year of construction: 2006, Technical details: grinding diameter: 5-55 mm Nedevg Thijpfx Aanedf grinding length: 500 mm total power requirement: 44 kW -- Intended use and general information -- Fully automated external and surface grinding of synchronous rings Centre height: 200 mm Grinding length: 500 mm Grinding wheel arrangement: right, 30° angled Grinding wheel dimensions: 600 x 30 x 203.2 mm Drive power: 7 kW X/Z axis drive: ball screw Travel speed: 0.01 - 10,000 mm/min. Resolution: 1 µm Concentricity of workpiece spindle: < 1 µm Workpiece changing system: Fanuc robot Control: Siemens Sinumerik 840-D Machine weight: 7,000 kg Centre height: 200 mm Grinding length: 500 mm *

Condition: used, Year of construction: 1992, Technical details: grinding diameter: 50 mm grinding length: 100 mm Nsdpsr R Ek Ssfx Aanodf centre height: 100 mm centre distance: 200 mm

Condition: used, Year of construction: 1988, Technical details: max. wheel diameter: 210 mm total power requirement: 60 kW weight of the machine ca.: 8 t dimensions of the machine ca.: 2,85 x 2,60 x 1,80 m Ndedpfxowrzute Aansf grinding slide feed: 700 mm grinding slide feeds: 1-15.000 m/min max. workpiece weight: 150 kg centre height: 260 mm grinding wheel diameter: 240 mm

Condition: used, Year of construction: 1996, Technical details: grinding length: 1370 mm Njdew S Hy Hopfx Aanedf grinding width: 560 mm workpiece height: 800 mm total power requirement: 50 kW dimensions of the machine ca.: 9 m ABA Z&B 2000, profile grinding machine with swivel dresser Mounting fixtures: magnet, dividing head E-axis dresser B-axis dividing head *

Condition: used, Year of construction: 1997, Technical details: max. module: 7 weight of the machine ca.: 5 t worm grinding diameter: 280-350 mm width of grinding worm: 84-104 mm min. number of teeth: 6 max. number of teeth: 600 max. top circle diameter: 360 mm Ndsdex Aq Egopfx Aanef max. workpiece weight: 60 kg without filter *

Condition: used, Year of construction: 1996, Technical details: weight of the machine ca.: 15 t Nedpfjizldxsx Aanodf

Condition: used, Year of construction: 2000, Technical details: max. wheel diameter: 180 mm max. module: 5 min. module: 1 weight of the machine ca.: 14 t dimensions of the machine ca.: 4,5 x 2,84 x 2,8 m min. number of teeth: 7 toolpiece turning speed range: 4000-10000 U/min tool length: 210 mm With tail stock No dressing device Only CBN * Nodpfx Ajwv Ug Reanedf

Condition: used, Year of construction: 2001, Technical details: grinding diameter max.: 3-220 mm regulating wheel width: 400 mm max. width of grinding wheel: 400 mm grinding motor: 55 kW peripheral speed: max. 45 m/sec regulating wheel dimensions: 350 x 400 x 203 mm dimensions of grinding wheel: CBN 500 x 400 x 304 mm grinding wheel size: KORUND 600 x 400 x 304 mm total power requirement: 75 kVA weight of the machine ca.: 13 t. dimensions of the machine ca.: 4,47 x 2,77 x 2,49 m. Centerless Grindign Machine JUNKER JUPITER 500 CNC SIEMENS in good condition. Including: · 2 robots Kuka KR 16 Year 2007 · CNC loading and unloading device Promot EPL60NC Year 2007 The machine was lately used for grinding of guide bushes (through grinding). Plunge is possible. JUPITER's Centerless grinding, also available with CBN. Junker this circular grinding method with CBN grinding wheels, which opens up significant productivity benefits from the long service life of the grinding wheel, especially at high volumes. In addition, the simultaneous removal takes on the entire Schleswig-Holstein, which provides both in mass production and in small batches for significantly reduced processing times. The grinding process with JUPITER Nodpjttxg Iofx Aanedf When centerless grinding, there are two grinding processes: the through grinding and plunge. Both methods are possible with the JUPITER. Applications through grinding: Pin and Bushings Body, rings, smaller rings, piston parts (eg compressors), waves with constant diameter piston rods (eg shock), Small piston for hydraulic and fuel injection, precision wires and rods, piston pins. Applications Plunge: Rotor shafts, transmission parts, bearing surfaces of camshafts, tube and pipe fittings for composite camshafts, universal joints, parts for needle injection, valve stems, barrel rolls. *
