Plate transport trolley

Variofit PL-150.010

Condition: as good as new (ex-display), functionality: fully functional, Edgebander with most accessories in its technological range, with an excellent quality/price ratio. Work table dimensions 3465 x 710 mm Min. ÷ max. thickness of rolled edges 0,4 ÷ 3 mm Max. thickness of edges in strips 5 mm Min. ÷ max. panel height 8 ÷ 50 mm Min. panel length/width 190/110 mm Feed speed 9 m/min This edgebander increases productivity with the feed track of the panel brought to a speed of 9 m/min and it guarantees high quality standards in processing thanks to the possibility of working with polyurethane glue, perform grooves, all being extremely easy to use. MACHINE COMPOSITION: ME 40TR AUTOMATIC EDGE BANDER 109999 Security execution R00341 me 40tr versione CE 930731 Volt 400 EU 931201 Frequency 50 Hz 580653 EDGE SCRAPING UNIT 580444 BRUSHING UNIT 580654 GLUE SCRAPING UNIT 580656 Spare glue pot for poliurethane glue with fast unloading system 580509 Device for the panel edge heating 580510 Anti-adhesive unit 580548 Spray-mist device for edge finishing Ksdpfx Acsqw Ux Tswodw 580658 "Nesting" copying device kit for Trimming unit 580659 "Nesting" copying device kit for Edge scraping unit 580666 Internal machine lightening

Condition: used, Year of construction: 2016, TECHNICAL DATA AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting working area mm 0 x 800/0 x 800 X axis stroke mm 750 Max. travel speed of X-Y axes m/min 25 DRILLING UNIT Vertical spindles Number 7 (4X-4Y one common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed grooving saw (direction) X Grooving saw diameter mm 100 Max. grooving saw thickness mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Grooving saw speed rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air requirement bar 6 Compressed air consumption Nl/cycle 90 Extraction requirement m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 80+80 F10L Drilling unit Includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with one drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. Diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit. Positioning of the workpiece and drive of the work unit: A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the work unit during machining. Movement in the X and Y axes takes place on THK guides with transmission to reinforced toothed rails. Movement in the Z axis is pneumatically controlled on ball-bushing guides with adjustable stop positioning. The positioning of the work units is carried out using technology and drives with DC motors. CNC CONTROL The control system was specially developed for use in drilling and milling machines. CN - 7" color screen with touchscreen function - Alphanumeric keyboard - Self-diagnosis and any error messages or malfunctions that may occur, in the operator's language Programming - Programming via the CN - Automatic optimization of drilling operations - Option of plate zero point shift - Option of saving and importing drilling programs via USB dongle - Option of importing drilling programs from CAD-CAM external software Configuration - User interface in the same language as the instruction manual Graphic representation of the unit configuration Vacuum suction cups "B-Power Vacuum suction cups with double vacuum connection, recommended for particularly porous panels (e.g. MDF light). Machine user interface software Xilog Maestro USB Hardware and software requirements: - Operating system: Windows XP Professional (SP2), Windows Vista or Windows 7 - Processor: Intel compatible, 2GHz min; Multicore processor recommended - Memory capacity: 1GB min., recommended 2GB - Free disk space: 5GB - Graphic card: Compatible OpenGL (The code includes a DVD for installation and a USB key) Xilog Maestro Features Programming - Parametric, graphic programming - Assisted programming with graphic and syntax help for drilling operations - Possibility to create and save machining macros Integrated additional functions - Self-diagnosis and possible error messages or malfunctions, in the operator's language - User interface in Kodpfx Aevvi I Rjcwjdw

Condition: excellent (used), Year of construction: 1995, Max. panel width 4400 mm Max. panel length 4300 mm Kdedpfx Asmt Hhwjcwew Main saw blade projection 110 mm No of Grippers 8 Front Loading Beam Panel Saws Max. saw blade projection 110 mm Front support tables no. tables 4 Control system NC 410 Safety standard CE mark Total installed power 20 KW

Condition: new, Work and assembly table Worktop made of solid sheet metal equipped with high-quality workbench (can be removed using screws) Easy back-friendly work thanks to height adjustment using a foot pedal Perfectly aligned using the 4 adjustable feet, very easily using an Allen key Continuous height adjustment and 3 fixed working heights Optimal handling thanks to 4 swivel castors with parking brake Regional quality From conviction - 5 year guarantee Load capacity 300 kg Height 400 - 1010 mm Worktop length 1485 mm Worktop 1700 x 790 mm Useful stroke 610 mm Weight 140 kg Front pliers 520 x 70/190 mm Kdedpfx Aovymfhocwjw (size/span) Side pliers 460x140/145 mm (size/span) Availability: short term Storage location: Flörsheim

Condition: new, Type GB/T10850 Motor power 0.18 kW Ksdpfx Acjd Tymnjwodw Air pressure 3-6 bar The power supply voltage 220 V 50 Hz Total power 1.4 kW Heating power 1.2 kW Edge width 8-50 mm Edge thickness 0,3-3 mm Sealing side speed 0-26 cm/s Vacuum suction of workpiece Transport dimensions Net weight 300 kg

Condition: used, machine/vehicle number: 007289, X axis working area: 3200 mm Y axis working area: 900 mm Main Electrospindle power: 4.5 KW Kdodpfx Acowukyqjwew Number of controlled axes: 3 axes Total number of drilling spindles: 16

Condition: new, Year of construction: 2022, Belt width: 150mm Belt length: 2600mm Oscillation: yes Sanding rollers for curves: 1 Sanding unit can be swivelled: yes Table size: 750mm x 290mm Suction connection: 120mm Kedjiuld Dspfx Acwedw Motor power: 3kW Machine length: 1700mm Machine width: 700mm weight: 180kg

Condition: used, Year of construction: 2016, CNC boring machine – BIESSE EKO 2.1, year of manufacture 2016 An excellent multifunctional machine for vertical and horizontal drilling and milling. Equipment: -14 vertical drills -8 horizontal drills -1 saw in the X direction -1 milling spindle, 5.5 kW -8 positions in the revolver for tools and aggregates Additional: Extra license for bSolid software Workpiece length measurement and shifting of drilling from the edge according to tolerance The machine is in good condition, everything works, regularly lubricated and maintained. Price without VAT. Kdjdpfxjxfz Azj Acwsw
