Planers Offers
CATALOG NUMBER 6133
TECHNICAL DATA
- max width of the workpiece 220mm
- max height of the workpiece 130mm
5 spindles:
1) horizontal bottom 220mm 5.5kW
2) vertical right 130mm
3) vertical left 130mm; 2 and 3 11kW
4) horizontal top 220mm 5.5kW
5) horizontal bottom 220mm 11kW
- all adjustable spindles up / down, right / left
- diameter of the spindles 40mm
- from above, 4 introducing rollers, toothed, including 2 double ones
- from above, 1 pulling roller, rubber, double
- pressure on the insertion...
FREUD TM06M AM3 Helical planer cutter heads
with disposable knives
the year 2010
Vucbne
Diameter 125mm
Lenght = 236mm
Boring diameter 40mm
knives= 39 pcs
knives 24 x 12mmx 1,5mm
Planer cutter heads with a good finish
when cutting a maximum depth of 20 mm.
Technische Daten: - Hobelbreite 630 mm
- Hobelhöhe min./max. 3-300 mm
- max. Spanabnahme 8 mm
Bpuskbatlw
- min. Werkstücklänge 280 mm
- Abmessung Dickentisch 1050 x 630 mm
- Motor 7,5 kW / 400 V
- Drehzahl 4800 U/min
- Spiralmesserwelle 4-spiralig mit HM-Wendeplatten
- Vorschubgeschwindigkeit stufenlos 0 - 16 m/min.
- segmentierte Stahleinzugswalze
- 2 glatte Stahl Auszugswalzen
- Dickentisch auf 4 Tragspindeln
- elektrische Höhenverstellung
- Dickentisch vorprogrammierbar
mit Digitalanzeige de...
used
type pressure bar planer head
Tragkörper aus aluminium
mech. feeder
Ok7c2
flight circle diameter 127 mm
internal diameter 35 mm
Schneidenbreite 240 mm
Schneidenanzahl 4 pc.
original price 624,- ?
located in 97447 Gerolzhofen
Surface planer KÖLLE AH 40
is optically and technically in a very good condition, the machine comes from a small assembly company and was only little used
all guides and bearings are OK, the machine works perfectly
with suction socket 160mm
max. planing width 400mm
the chips can be removed very well
with 4 cutterblock for Centrofix- planing knives, they are similar to Tersa- planing knives, no adjustment work necessary
with complete knife cover for highest safety
the machine will be delivered an...
working width 410mm
4-knives shaft
Cxvyjgyg
manual regulation of infeed table
shaft speed 5000 RPM
fence with angle regulation
delta/star start
CATALOG NUMBER 6134
TECHNICAL DATA
- max width of the workpiece 230mm
Btxvqwfh3p
- max height of the workpiece 160mm
number of spindles 6
1) horizontal bottom 230mm 7.5kW
2) vertical right 160mm 7.5kW
3) vertical left 160mm - electrically adjustable front / rear from the 7.5kW control panel
4) horizontal upper 230mm with ATS 11kW
5) horizontal upper 230mm with ATS 11kW
6) horizontal bottom 230mm 11kW
- all spindles adjustable up / down, right left
- 1,2,3,5,6 spindles equipped with electric brak...
für Schlüsselweite 51 mm
Lagerort : Holztreppe Büro
Hr9xjvkxu
Lagerort: Nattheim
Technische Daten: - Arbeitbreite 630 mm
- min. / max. Hobelhöhe 3 / 300 mm
- Spiral Messerwelle, FI 125 mm
- Drehzahl 5000 U/min.
- Motor 7,5 kW / 400 V
- Absaugstutzen Durchmesser 160 mm
- max. Spanabnahme 8 mm
- Vorschub stufenlos regelbar 5 - 21 m/min
Fq2y72r
- elektrische Tischhöhenverstellung mit 2 Geschwindigkeiten
- 2 getrennt einstellbare Walzen im Dickentisch
- 4-fach präzisionsgeführter Dickentisch
- Gliederdruckwalze ermöglicht Werkstücktransport von unterschiedlichen Dicken
- Handrad...
used, cleaned, function checked,
test run, greased,
Vorschubketten renewed and new adjusted,
spindle rotation:
2/100-0/100-1/100-0/100-2/100-1/100 mm
manufactured by Weinig
type U - 16 - K
built in 1975
Masch.-No. 570/799
number of spindles 6
spindle alignment:
u - right hand - left hand - o - u - right hand
motors:
4 - 3 - 5,5 - 5,5 - 3,0 - 5,5
planing width ca. 160 mm
planing height ca. 120 mm
table length ca. 2000 mm
pressure bar planer heads
table lubrication
feeder vor der surface planer
f...
Opportunity in excellent condition
Btxrunk72o
Guilliet four-head KXY 180/120 mm
Leitz centrofix heads
working width 530mm
4-knives shaft
fence with angle regulation
manual regulation of infeed table
Btmf8anehc
delta/star start
CATALOG NUMBER 6135
TECHNICAL DATA
- max planing width 260mm
- max planing height 160mm
6 spindles:
1) horizontal bottom 260mm 5.5kW
2) vertical right 160mm 5.5kW
3) vertical left 160mm 7.4kW
4) horizontal upper 260mm 11kW
5) horizontal bottom 260mm 11kW
6) universal 360 °, electrically adjustable up / down 11kW
Jwthqa
- spindle diameter 5 - 50mm
- diameter of the remaining spindles 40mm
- all adjustable spindles up / down and right / left
- 8 drawing rollers in advance, including 4 double, 2 tr...
Working width 15 – 230 mm
Working height 10 – 150 mm
Planing table 2.5 m long (including joint rule)
Insertion (min. working width 25 mm, chip removal on the dressing spindle max. 7 mm)
Spiral feed roller in the machine table in front of the first lower spindle (for wet wood).
Two driven rollers in the machine table, 210 mm
Spindle arrangement:
1. First lower 7.5 kW, 6000 rpm,
2. First rights 5.5 kW, 6000 rpm,
Btw3ptmvip
3. First left mobile spindle positioned electronically 5.5 kW, 6000 rpm,...
Technische Daten: - Max. Hobelbreite 180 mm
- Min. Hobelbreite 18 mm
- Max. Hobelhöhe 120 mm
- Min. Hobelhöhe 7 mm
- min. Werkstücklänge bei Einzelelementen 450 mm
- min. Werkstücklänge bei Serie 350 mm
- Anzahl Arbeitsspindeln 5
- Spindeldrehzahl 6000 U / min / min.
- Spindeldurchmesser FI 40 mm
- Durchmesser der Köpfe:
- Nenndurchmesser 1, 2, 3, 4, 5 FI 125 mm
- Fügefalzfräser FI 140 x 10 mm
Bhhiyhcol9
- Hobelwellen 2, 3, 4 und 5 FI 100 - FI 180 mm
- Hobekopflänge 1, 4 und 5 beträgt 190 mm
- H...
pressure bar planer head Z4
with strip planer knifes
used
dimension 180 x 125 x 35
located in 97447 Gerolzhofen
sale in current condition
Bn0dohiakd
Surface planer, dresser, dresser
-Working width: 640 mm
-Table length: 2500 mm
-Knife shaft: 4
-Dimensions: 2600/950/H1000 mm
-Weight: 880 kg
Hh8zktj3y
working width 430mm
4-knives shaft
infeed table length 1350mm
manual regulation of infeed table
F39wkeyww
fence with angle regulation
motor power 4kW
year of manufacture 1996
delta/star start
Order No. 6127
TECHNICAL DATA
- max width of the workpiece 630mm
- max thickness of the workpiece 200mm
in advance:
- pawls
- pulling shaft, toothed
- clamps
- pulling shaft, toothed
- pressure
- toothed pulling shaft
- pressure
- 630mm planing shaft for 6 5.5kW knives
- pressure
- smooth pulling shaft
from down:
- smooth skid roller
- 630mm planing shaft for 6 4kW knives
- 2 smooth skid rollers 2 pcs
- adjustable rollers in the lower table top
- smooth regulation of the feed speed
- 3kW feed...
WEINIG Hydromat 22BL, 8 Spindeln
Year of construction 12 / 1988
Machines No. 220-1120
Working width 220mm
Working height 120mm
feed 8-40M / min ( rigid ), drive 7,5 kw
Spindle arrangement:
Bitivjjoee
1. bottom/ 7.5kw
2. bottom / 5.5kw / Jointer
3. right / 5.5kw
4. left / 7.5kw
5. top / 22kw
6. bottom / 22kw
7. bottom / 5.5kw
8. top 5.5kw / Jointer
Speed 6000m / min
spindle diameter: 50mm
380 V / 50 Hz
Technische Daten: - max. Hobelbreite 405 mm
- Durchlasshöhe 220 mm
C3ezajxg
- Tischgröße 750 x 408 mm
- max. Spanabnahme 5 mm
- min. Werkstücklänge 156 mm
- Motorleistung 4 kW
- Spannung 400V / 50Hz
- Vorschubgeschwindigkeit 6,5 m/min
- Absauganschluss 120 mm
- Hobelwellendurchmesser 95 mm
- Hobelwellendrehzahl 4200 Upm
- Hobelmesseranzahl 3 Stück
- Aufstellmaß 985 x 968 x 955 mm
- Transport Abmessungen L=815 mm, B=740 mm,H=1140 mm
- Gewicht 232 kg Lieferumfang:
- Streifenhobelmesser montiert (...
pressure bar planer head Z4
Bn0feypf20
with strip planer knifes
used
dimension 180 x 125 x 35
located in 97447 Gerolzhofen
sale in current condition
Number of spindles 7 St.
Working width 230 mm
Working height 120 mm
Length of the planing table 2000 mm
Feed motor 3 kW
Feed speed 5-24 m/min.
Dimensions (L/W/H) 5200 x 2000 x 1900 mm
weight of the machine ca. 4500 kg
Bklzrop0vx
# 2545 Weinig Unimat 23 E with ATS control for width and height,
divide out of glazing bead possible
.....
Technical data summary
(please inquire about additional accessories)
.....
Generally
.....
> Working width: 230 mm
> Working height: 120 mm
> Number of spindle...
working width 520mm
4-knives shaft
4-step feeding speed control
Cwr93duo
delta/star start
max thickness of material 300mm
electric table regulation
roll in the table
CATALOG NUMBER 6128
TECHNICAL DATA
- shaft width 630mm
- 4-knife shaft
- max thickness of the processed element 230mm
Btxpjkcuds
in advance:
- pawls
- input shaft, toothed, pulling, sequential
- pressure
- planing shaft
- pressure
- smooth, pulling shaft
from down:
- adjustable rollers in the lower table top, 2 pcs
- 4.8kW engine
- dimensions length / width / height 1100x1250x1000mm
- weight 970 kg
- German production
- very good condition
- used thicknesser
Net price: PLN 9900
Net price: EU...
Exhibition machine
Year of manufacture: 2020
Equipment and technical data:
> Solid German machine construction
> for dressing and jointing including hollow and
Bqcjg9fcyn
and point joint adjustment for HOBEL WIDTHs
up to 510 mm and max. chip removal up to 8 mm
> Ergonomic working position directly
the cutter head
> Panhans four-knife shaft with strip planing knives
and setting devices
> finely planed cast iron tables, total table length
2850 mm
> Control panel on top at eye level with digital
di...
Technische Daten:
- Hobelbreite 20 - 200 mm
- Hobelhöhe 8 - 125 mm
- minimal Werkstücklänge 590 mm (einzeln) / 250 mm (bei Serie)
- 6 Spindeln
- Spindel FI 40 mm
- Drehzahl 6800 U/min
- Vorschubgeschwindigkeit stufenlos 8 - 33 m/min
- Abrichtwelle, unten max. Werkzeug FI 125 mm
Ihjb0vt
- Rechte Vertikalwelle max. Werkzeug FI 108 - 180 mm
- Linke Vertikalwelle max. Werkzeug FI 108 - 180 mm
- obere Horizontalwelle max. Werkzeug FI 108 - 180 mm
- zweite obere Horizontalwelle max. Werkzeug FI 108 ...
pressure bar planer head Z4
Bn0fd22u9x
with strip planer knifes
used
dimension 180 x 125 x 35
located in 97447 Gerolzhofen
sale in current condition
Technical data:
Max planing width: 530 mm
Max planing height: 240 mm
Knife shaft diameter: 120 mm
Number of knives: 4
Power supply: 400V
Main engine power: 4 kW
4 feed speeds: 5 / 7.5 / 10/15 m / min
Electric lifting
Extraction port: 140 mm
Producer: SAC
Overall dimensions:
Length: 960 mm
Width: 1120 mm
Height: 1100 mm
Btxoc208lr
Complete planing line for up to 6m long boards with infeed, outfeed, bundle collator, bundler and Paternoster stacker.
Pack infeed with 7 infeed chains
Vacuum destacker with 6 vacuum pads
Infeed conveyor with single board feeder
Mouder infeed with 6 hyraulically driven feed rollers
Hydraulic unit
Moulder outfeed with rollers, kickers and return.
Bundle collector / collator
Roller conveyor to bundling unit / strapping unit
Outfeed conveyor from bundling unit with return
Paternoster stacker
Pa...
CATALOG NUMBER 6129
TECHNICAL DATA
- shaft width 500mm
- 4-knife shaft
- length of the tops 2740mm
- cast iron tops
- both adjustable tops
- cast iron guide adjustable at an angle
- 4kW engine
- dimensions length / width / height 2740x1000x980mm
- weight 680 kg
ADVANTAGES
- 4-knife shaft
- planer used, very good condition
Net price: PLN 9900
Net price: EUR 2276 depending on the price, EUR 4.35
(Prices may change with higher fluctuations)
Btxpdbz787
Description:
Used Weining Unimat PFA22N, ready for inspection and immediate sale :).
Technical specifications
Year of manufacture 1972
Working width mm 220
Planing height mm 120
Number of spindles 5
Spindle configuration b-r-l-t-b
Spindle rotation speed max 1/min 6000
Infeed table length mm 2500
Feedrate max m/min 36
Type of feed roller drive Chain
Further technical details
Bottom spindles 2
Right spindles 1
Left spindles 1
Top spindles top 1
Spindle diameter mm 40
Jcvuuhede
Btuklbkae2
Seperate ...
Technische Daten:
- Hobelbreite 50 - 330 mm
- Hobelhöhe 8 - 250 mm
- min. Werkstücklänge 700 mm (einzeln) / 300 (bei Serie)
- stufenloser Vorschub 8-36 m/min.
- Spindel FI 50 mm
Bhhgz73wro
- Drehzahl 6000 U/min
- untere horizontale Welle min. /max. Werkzeug FI 140 mm
- rechte vertikale Welle min. /max. Werkzeug FI 140 / 230 mm
- linke vertikale Welle min. /max. Werkzeug FI 140 / 230 mm
- obere horizontale Welle min. /max. Werkzeug FI 140 / 230 mm
- 2. obere horizontale Welle min./max. Werkzeug...
feeder rolls
Pos - No. 157
manufactured by Weinig
feeder rolls 1 piece
gummed
roll diameter ca. 180 mm
roll width ca.15 mm
Gwttp8
internal diameter 35 mm
keyway 10 mm
located in 97447 Gerolzhofen
sale in current condition. as seen. Without examination.
- free on truck -
Double side planer (Double Surface Planer )
Maximum working width 610 mm
Bqfgafxwly
Maximum working height 200 mm
Heavy cardan feed system
Special spike feedsystem
Unlike the conventional chain drive systems, this machine employs a patented synchronized transmission system along the four fitting columns.
Electronic height adjustment
Spiral cutterheads top and bottom
Latest generation IE-3 motors
Spindle and feed brakes
CE
Top 22 KW
Bottom 18.5 KW
planing width 630 mm
Btgoprt9xq
7,5 kW
planing height 245 mm
CATALOG NUMBER 6130
TECHNICAL DATA
- shaft width 510mm
- 4-knife shaft
- length of the tops 2850mm
- longer introductory table top
- cast iron tops
- both adjustable tops
- cast iron guide adjustable at an angle
- diameter of the extractor stub pipe 130mm
- 4kW engine
- dimensions length / width / height 2850x1160x1050mm
- weight 690 kg
Zu7nu0or
- planer used, very good condition
Net price: PLN 11900
Net price: 2736 EUR depending on the price 4.35 EUR
(Prices may change with higher fluctuation...
Technical specifications:
Country of origin: Japan
Working surface width, mm: 250
Passage height, mm: 180
Weight, kg: 350
Bno2jvllzv
O8n3j
Additional equipment, knives (pieces): 2
Dimensions, mm (L x W x H): 970x850x1230
There are additional knives (new), pc: 2
Technische Daten: - Hobelbreite 20 - 230 mm
- Hobelhöhe 8 - 160 mm
- minimal Werkstücklänge 840 mm (einzeln) / 400 mm (bei Serie)
- 6 Spindeln (5+Uni)
Bhhh2apha7
- Spindel FI 40 mm
- Drehzahl 6000 U/min
- Vorschubgeschwindigkeit stufenlos 6 - 36 m/min
- Abrichtwelle, unten max. Werkzeug FI 125 mm
- Rechte Vertikalwelle max. Werkzeug FI 200 mm
- Linke Vertikalwelle max. Werkzeug FI 200 mm
- Dickenwelle, oben max. Werkzeug FI 180 mm
- Zweite untere Welle max. Werkzeug FI 200 mm
- Univer...
pressure bar planer head Z4
with strip planer knifes
used
dimension 180 x 125 x 35
located in 97447 Gerolzhofen
sale in current condition
K83ftjpl
1 x Elektronic Motor Braking Unit
Power range 3 - 15KW
Voltage range 200-575V
Power frequency 50Hz/60Hz
Siemens EMG 15
Btwveo38l0
working width 530mm
4-knives shaft
motor power 4kW
4 feeding speed 5/7,5/10/15 m/min
delta/star start
Btfbgioatr
electric table regulation
max element thickness 230mm
CATALOG NUMBER 6131
TECHNICAL DATA
- shaft width 410mm
- 3-knife shaft
- cover for the planer shaft
- length of the tops 2500mm
- cast iron tops
- both adjustable tops
- cast iron guide adjustable at an angle
Bhzz88f
- 3kW engine
- dimensions length / width / height 2500x800x950mm
- weight 610 kg
ADVANTAGES
- 3-knife shaft
- planer used, very good condition
Net price: PLN 6500
Net price: EUR 1494 depending on the price: EUR 4.35
(Prices may change with higher fluctuations)
New machine
Partnership Edition
Technical data:
working width: 630 mm
4-knife planing shaft system TERSA, d=120mm: 4.800 rpm
Bojbeemsi8
max. chip removal Dressing according to CE: 8 mm
min./max. thickness passage: 3/310 mm
min. workpiece length: 250 mm
Feed speed: stepless. 6 - 20 m/min.
Motor 380 Volt / 50 Hz.: 7,5 kW
Sound level according to EN 27960: 86 - 90 dB(A)
Basic equipment:
Thickness table adjustment via 4 trapezoidal threaded spindles
electromotive thicknessing table stroke with elect...
