Tool and Cutter Grinder

WALTER Helitronic Power Production

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, spindle speed (max.): 7,000 rpm, type of input current: three-phase, grinding wheel diameter: 200 mm, overall weight: 4,650 kg, grinding length: 350 mm, center height: 190 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, travel distance X-axis: 490 mm, travel distance Y-axis: 320 mm, travel distance Z-axis: 660 mm, grinding spindle motor power: 24,000 W, workpiece diameter (max.): 320 mm, input voltage: 400 V, nominal power (apparent): 35 kVA, spindle nose: ISO 50, swivel angle A-axis (min.): 360 °, CNC tool grinding machine WALTER Helitronic Power Production TECHNICAL CHARACTERISTICS: CNC control: HMC 500 Software installed: Tool Studio 2.1 R4 Number of axes: 5 Height of centers: 190 [mm] Stroke X: axis 490 [mm] Resolution X axis: 0.00001 [mm] Stroke Y axis: 320 [mm] Resolution Y axis : 0.00001 [mm] Stroke Z axis: 660 [mm] Resolution Z axis: 0.00001 [mm] Traversing feeds X, Y and Z axes: 15000 [mm/min] A axis: 360 [°] C axis: +/- 200 [°] Resolution C axis: 0.0001 [°] Max. workpiece lenght: end face grinding: 320 [mm] Max. grinding length: 350 [mm] Max. grinding diameter: 320 [mm] Grinding spindle attachment: NCT Grinding spindle diameter: 80 [mm] Grinding wheel max. speed: 7000 [rpm] Grinding spindle motor power: 24 [kW] Max. diameter grinding wheel: 200 [mm] Internal workpiece spindle nose: ISO 50 Workpiece spindle max. speed: 60 [rpm] Total power required: 35 [kVA] Weight: 4650 [Kg] EQUIPMENT INCLUDED: Csdpjyh Nf Ijfx Agkjpw x1 TRANSOR 12290-800A filtration unit x1 MTA oil chiller model TAE 015 x1 DSL oil mist extractor model AES-GAMMA 30 x1 RENISHAW part probe x1 disc-type tool loader 40 positions x1 SCHUNK gripper x2 grinding wheel arbor adapters x1 fire protection system - to be inspected by the buyer through a certified organization x1 electrical schematic manual x1 Service Instructions manual LICENSED WALTER WINDOW MODE (WWM) PACKAGES: - Package 001 (cylindrical mills) - Package 002 (tapered mills) - Package 003 (drills) - Package 004 (step drills) - Package 006 (woodwork tools) - Package 013 (reamers) - Package 015 (insert seats) - Package 016 (warmup program) - Package 027 (flexible program) - Package 090 (loader package) - Package 091 (acm) - Package 098 (loader package) - Package 099 (loader package) - Package 100 (reference data m.) - HELICONE (flute calc. conical.) - HELIDRILL (flute calc. drills) - HELIFLUTE (flute calc. cyl. mill.) - MCS (machine control .) - SCHEIBE (wheels menu) - TS_ADVANCED (toolstudio (v1.0-v.) - TS_STANDARD (toolstudio (v1.0-v.) - TS_STEPTOOLS (toolstudio (v1.0-v.) LICENSED TOOLSTUDIO OPTIONS: - Tool Studio 2.0 server/machinecontrol - Tool Studio 2.0 standard license - Tool Studio 2.0 advanced license - Tool Studio 1.9 upgrade options - Tool Studio 2.0 upgrade options - Option steptools - Option profile light (contour roughing ...) - Option calibration w/ touch probe - Option drills Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed.

Condition: excellent (used), Year of construction: 2009, CNC control : FANUC 160i - Accessories available. Cpsdpfxsr Ha Dvo Agkjw - Fanuc loading robot - Coolant system (Edge 2 tower from ARO-Technologies) - Oil mist separator (ELBARON SA) Travels: X-axis 650 mm Y-axis 300 mm Z-axis 300 mm C-axis swivel angle +150°/ -60° C' axis swivel angle +/- 180° Grinding spindle: Wheel dimensions up to 250 mm Speed 0 - 10,000 rpm. Max. spindle power 26 kW HSK 80 holder Max. Number of disks 6 Workpiece headstock Vmax 180°/s Drive power 1.6 kW ISO 50 mounting Precision (resolution) Resolution linear axes 0.001 mm C-axis 0.001° Dimensions: Length 3100 mm Width 1915 mm height 2190 mm Weight 8'500 kg

Year of construction: 2003, condition: good (used), Strokes 560x 410 x 510 mm, table 900 x 410, magazine 30 tools, spindle 12.000 rpm, chip conveyor Cpjdoiwkhkjpfx Agkew

Condition: good (used), Year of construction: 2007, max. wheel diameter 400 mm gear width 250 mm max. module 8 min. module 0,5 root circle diameter 10 mm number of teeth 5 - 999 ical angle +/- 45 ° weight 12.5 t With Hoffmann filter system: Year of manufacture: 2006 Filter no. 05919 - Type HSF 100 SEK • Grinding wheel flange • 1 grinding wheel • 1 original dressing device • 1 set of dressing wheels • 1 sensor Cpedpoyclrpsfx Agksw -> Very good condition, only 22,500 operating hours

Condition: reconditioned (used), Year of construction: 2006, CNC Universal Milling & Drilling Machine DECKEL MAHO DMU 80 P duoBlock With MILL PLUS iT path control system Year of manufacture: 2006 Travel paths: X 800 Y 800 Z 800 mm Spindle speed range: 0 – 8,000 rpm, stepless (SK 50) Including the following accessories: - NC rotary table, 900 mm x 700 mm clamping surface (maximum table load 1.4 t) Cjdpfx Agsxn Aczskepw - Universal milling head with controlled B-axis - Universal tool changer with 40 magazine stations, double gripper (SK 50) - Fully enclosed guard cabin with sliding doors and interior lighting - ICS – 40 bar (internal coolant supply) - Chip conveyor - Rotoclear - 3D tactile probe Heidenhain TS 641 - Operating modes 3 + 4 - Electronic handwheel - 50 pcs. tool holders SK 50 - 3 height-adjustable machine feet - Transport device - Operating manuals

Condition: used, Technical details: grinding diameter: 600 mm grinding length: 2600 mm Cjdpfx Agow Rktbskspw centre height: 180 mm workpiece diameter - max.: 360 mm swing diameter: 600 mm grinding wheel diameter: 600 x 305 x 160 mm total power requirement: 17,6 kW coolant device: 90 l/min work piece spindle speed: 12,5-250 U/min feed continuous: 0,05 - 6,0 mm weight of the machine ca.: 8,2 t dimension machine xH: 6,4 x 2,2 x 1,9 mm Final balance balancing device Tailstock with cylinder error correction Digital display X=0.001 - Z=0.01 Radius device 2-10 mm *

Condition: used, CNC cylindrical grinding machine STUDER S31 CNC LeanPro with "Pictogramming" Distance between centers: 1000mm Center heigh 175mm Grinding Wheel head rotation (B) 360° (1°) 2 ext Grinding Wheels 1 int Grinding Wheel Ext Grinding wheel 400 mm x 40 mm x 127 mm overhauled spindle > see photos Workhead CM 4 0-1000 RPM CNC Fanuc Programming: Pictogramming Heidenhain linear encoders Cpjdpfx Ajwim U Hjgkjw This machine can be inspected under power in our warehouse in Gussago BS Italy

Condition: good (used), Year of construction: 2007, 1 used CNC tool grinding machine Make: Schneeberger Model: Corvus GDS 650 Year of manufacture: 2007 CNC Control: FANUC 160i Software: Quinto 4.3 Activated software options (option numbers): 1, 2, 19, 21, 22, 30, 31, 32, 35 - Fanuc loading robot Cpjdpfx Ageu A Dn Nskjw - Coolant system Travel: X-axis: 650 mm Y-axis: 300 mm Z-axis: 300 mm C-axis swivel range: +150°/ -60° C’-axis swivel range: +/- 180° Grinding spindle: Wheel diameter up to 250 mm Speed: 0 – 10,000 rpm Max spindle power: 26 kW HSK 80 interface Max. number of wheels: 6 Workpiece spindle head: Vmax: 180°/s Drive power: 1.6 kW ISO 50 interface Precision (resolution): Linear axis resolution: 0.001 mm C-axis: 0.001° Dimensions: Length: 3,100 mm Width: 1,915 mm Height: 2,190 mm Weight: 8,500 kg U-axis is integrated with steady rest, clamping cylinder, and tailstock 6-pallet loader (diameter 3 to 32 mm) 64 plastic collets Technical data subject to change without notice

Condition: refurbished (used), Year of construction: 1974, functionality: fully functional, machine/vehicle number: 1276, CNC Hot Radial Forging GFM SX-13 New in 1974 / 2022 New control system PLC SIEMENS S7 Machine number: 1276 No. of Hammers: 4 Forging force each hummer: 160 Ton Hammer stroke / min: 700/min Hammer lenght: 240 mm Diameter setting range: 80 mm Codpjq U R T Njfx Agkspw Maximum forging diameter: Structural steel, round-cross section: Ø 130 mm square cross section: Ø 115 mm Smallest dimensions forged: Ø 25 mm Manipulator A max. displacement: 6820 mm Manipulator B max. displacement: 7150 mm Maximum workpiece length: 6000 mm Rapid speed manipulator: 400mm/sec Total connected power: 300 kW 380 V, 50 Hz Machine dimensions: Forging height over floor: 615 mm Total height pf the machinr over floor: 1665 mm Total machine lenght: 32670 mm Total foundation lenght: 33400 mm Tot. machine width (without auxliary equipments): approx 3885 mm Total foundation width: 16000 mm Total weight of the machine: 84.000 Kg

Condition: ready for operation (used), Year of construction: 2019, total height: 2,797 mm, overall weight: 1,570 kg, This 3-axis ZEISS Contura 7/10/6 RDS was manufactured in 2019 and features a robust motorized CNC drive system with a maximum vector speed of 465 mm/s. It includes the ZEISS RDS-C articulating head and VAST XXT TL3 sensor, capable of scanning speeds up to 150 points/second. Ideal for precise measurements with a maximum workpiece weight of 730 kg. Consider the opportunity to buy this ZEISS Contura 7/10/6 RDS CMM machine. Contact us for more information about this machine. Additional information • Maximum workpiece size: approx. 1344 x 910 x 716 mm • Maximum workpiece weight: 730 kg • Table height: 850 mm • Equipped with vibration damping system • Sensor System: • Articulating head: tilt ±180°, rotation increments 2.5° • Scanning speed: up to 150 points/second • Max. stylus length: 150 mm Codex D Ngfepfx Agkopw • Max. stylus weight: 15 g • Min. stylus tip diameter: 0.3 mm • Accuracy (per ISO 10360 standards): • Length measurement error (E₀): 1.7 + L/350 µm (at 18–22°C) • Scanning error (THP): 2.7 µm • Form measurement error (RONt): 1.7 µm • Repeatability (R₀): 1.2 µm • Controller: ZEISS C99L • Software: ZEISS CALYPSO, ZEISS GEAR PRO, ZEISS HOLOS • Control mode: Motorized / CNC • Interface: Ethernet, USB • Performance: • Drive system: Motorized CNC • Travel speed (axes): 0–70 mm/s • Max. vector speed: 465 mm/s • Max. acceleration: 1.85 m/s² • Scanning speed: up to 125 mm/s • Utilities: • Power supply: 100–240V AC (±10%), 50–60 Hz • Max. power consumption: 800 VA • Typical power usage: 200 W • Compressed air: 6–8 bar, pre-cleaned, dry (ISO 8573-1 Class 4) • Air consumption: max. 120 Nl/min • Environmental Conditions: • Operating temperature: 18°C–22°C • Relative humidity: 30–60% (non-condensing) • Compliance & Certifications: • Conforms to EC Machine Directive 2006/42/EC • EMC Directive 2014/30/EU • Quality management: ISO 9001:2008 • Environmental management: ISO 14001:2004 • Accredited ISO / IEC 17025:2005 Dimensions Machine Depth 1975 mm
