Suction Unit

Wieland VS-3 T

Condition: good (used), Year of construction: 2012, arm reach: 2,696 mm, controller model: KR C4, KUKA Robots Model: KR 90 R2700 pro Iodpfxetpwxlo Ab Ioa Technical data Maximum reach: 2696 mm Rated payload: 90 kg Rated supplementary load, rotating column / link arm / arm: 0 kg / 0 kg / 50 kg Rated total load: 140 kg Pose repeatability (ISO 9283): -/+ 0,06mm Number of axes: 6 Mounting position: Floor Footprint: 830 mm x 830 mm Weight: approx. 1058 kg Axis data Motion range A1: -/+ 185 ° A2: -140 / -5 ° A3: -120 / 155 ° A4: -/+ 350 ° A5: -/+ 125 ° A6: -/+ 350 ° Speed with rated payload A1: 136 ° / s A2: 130 °/ s A3: 120 ° / s A4: 292 ° / s A5: 258 ° / s A6: 284 ° / s Operating conditions Ambient temperature during operation: 10 °C bis 55 °C (283 K bis 328 K) Controller: KR C4

Condition: ready for operation (used), Number of axis: 6, nominal load: 90kg, controls: Engel, weight: 1.13t. Iodpfjk N Dnhsx Ab Iea

Condition: used, System: Used chamber filter press Iedewqyfujpfx Ab Ioa Type: Aquachem EC 470 AK25 Application: Sludge dewatering, sludge treatment Year of manufacture: 2005 Filter plate size: 470x470 mm Number of plates: approx. 20 Filter plates: PP Cake thickness: 25 mm Filter cloths: optionally available, to be matched to the medium Filter area: approx. 12 m² Press volume: approx. 66 dm³ Filter pressure: approx. 15 bar Discharge: closed Pump technology: optional Filter cloths: optional Drip tray: yes Purchase or rent: Inspection of the systems by arrangement at our facility.

Year of construction: 2018, condition: excellent (used), EFD Type: MINAC 6/10 SM Heat treatment The compact design of the Minac induction heating system allows for easy installation and offers fast, concentrated and controlled heating with full repeatability. repeatability. Medium frequency product line Technical data: Maximum output power 10 kW Continuous output power 6 kW Mains voltage 400-480 V Frequency range 10-25 kHz Control range of output power 2-100% Recommended back-up fuse 16 A Cooling water approx. 4 l/min Cooling water flow temperature min./max. 18 - 35°C Iedpjt Din Ajfx Ab Iea Cooling water pressure min./max. 4 - 6 bar Weight approx. 50 kg Dimensions (WxDxH): 345 x 708 x 453 mm Year of construction: 2018 optris CTlaser infrared thermometer Abbreviation: 3ML Measuring range: 50 to 400 °C Spectral sensitivity: 2.3µm Typical application: Metals at low object temperatures (from 50°C) Temperature control ECU 1214C Hyfra eChilly water cooler 4-S Cooling capacity 4395W The device comes from the laboratory sector. Only a few operating hours. Condition: used Scope of delivery: (see picture) (Changes and errors in the technical data, specifications are reserved!) We will be happy to answer any further questions you may have on the phone.

Condition: used, Technical details: Heating: 15 kW rated current: 28 A Heating capacity: 15 kW current: max.71 A cooling water consumption: 11 l/min frequency range: 10-25 kHz frequency range: 50/60 voltage: 400-480 +-10% V current- max.: 3020 A Iodpfexfvldox Ab Ioa weight: 406 kg dimensions L x W x H: 1,25 x 0,8 x 1,6 m The device is a mobile induction heater with medium power (15 kW), suitable for: Local heating of metals (e.g., bearings, bolts, screws, pipes, sheet metal edges). Preheating for welding processes Soldering and shrinking applications Heat treatments (e.g., tempering or hardening of smaller components). Due to its frequency range of 10–25 kHz, the device is more suitable for medium to large workpieces, as the penetration depth at these frequencies is higher than with high-frequency systems. *
