ProdEq Trading GmbH

Condition: used, Year of construction: 2007, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 510 mm, controller manufacturer: HURCO, controller model: ULTIMAX, overall weight: 13,200 kg, spindle speed (max.): 15,000 rpm, space requirement length: 4,700 mm, space requirement width: 5,500 mm, CONTROLS .. CNC controls HURCO ULTIMAX WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 5 .. X-axis travel: 800 mm .. Y-axis travel: 700 mm .. Z-axis travel: 510 mm .. rotating range A-axis from: -30 ° .. rotating range A-axis up to: 110 ° .. rotating range B-axis up to: 360 ° SPINDLE / HEAD .. spindle revolutions (max): 15000 /min .. tool fixture: HSK E40 TOOL MAGAZINE .. number of positions: 32 ELECTRICAL SPECIFICATIONS .. mains power supply: 30 kVA .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 4700 mm .. space requirements -front/back-: 5500 mm .. total weight approx.: 13200 kg Kelhewl Umvjcdw Holt Accessories: -chip conveyor -2 pallets various spare parts

Condition: used, Year of construction: 2012, travel distance X-axis: 550 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 360 mm, controller manufacturer: FANUC, controller model: 31I A5, overall weight: 7,700 kg, spindle speed (max.): 15,000 rpm, CONTROLS .. CNC controls FANUC 31I A5 WORKING RANGE -CUBIC- .. X-axis travel: 550 mm .. Y-axis travel: 400 mm .. Z-axis travel: 360 mm SPINDLE / HEAD .. spindle revolutions (max): 15000 /min .. tool fixture: HSK A63 .. spindle torque: 45 Nm TOOL MAGAZINE .. number of positions: 32 Kjlhcowl A E Hsdw Hslt ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. total weight approx.: 7700 kg ATTACHMENTS .. chip conveyor: yes .. coolant unit: yes .. band filtration unit: yes .. through spindle coolant attachment: yes .. closed cabin: yes .. European CE standards: yes

Condition: used, Year of construction: 2002, travel distance X-axis: 270 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 250 mm, controller manufacturer: HEIDENHAIN, controller model: ITNC 530, total height: 2,200 mm, overall weight: 2,800 kg, spindle speed (max.): 40,000 rpm, spindle motor power: 10 W, space requirement length: 2,300 mm, space requirement width: 2,200 mm, CONTROLS .. CNC controls HEIDENHAIN ITNC 530 Klelhjwlnk Iocdw Hot WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 5 .. X-axis travel: 270 mm .. Y-axis travel: 250 mm .. Z-axis travel: 250 mm SPINDLE / HEAD .. spindle revolutions (min): 10 /min .. spindle revolutions (max): 40000 /min .. tool fixture: HSK A25 .. drive power: 10 kW TOOL MAGAZINE .. number of positions: 60 AUTOMATIC WORKLOAD EQUIPMENT .. number of store positions: 24 DIMENSIONS / WEIGHTS .. space requirements -left/right-: 2300 mm .. space requirements -front/back-: 2200 mm .. total height: 2200 mm .. total weight approx.: 2800 kg Operating hours: Spindle 12,324h Programme run 27,356 Accessories: -2-axis NC rotary table with EROWA -tool measurement Blum -measuring probe -tool magazine HSK25 -workpiece magazine for EORWA ITS50 tool holder 30 pieces -oil mist extraction -spindle alignment mandrel

Year of construction: 2009, Condition: used, controller manufacturer: SIEMENS, controller model: S7 300, CONTROLS .. PLC SIEMENS S7 300 Pipe pointing machine HAGINGER AHM 63 with slide insertion device S - Pipe diameter 20 - 70 mm - Wall thickness 1 - 6.5 mm - Pipe length 3,000 - 10,000 mm - Material: Steel tubes with a strength of 800 N/sqmm - Max. forming force: 4 x 630 kN Kljlhcdwewlgm Io Hjt - Stroke rate: 630/min - Drive motor power: 30 kW

Condition: good (used), Year of construction: 2022, travel distance X-axis: 210 mm, travel distance Y-axis: 270 mm, travel distance Z-axis: 360 mm, controller manufacturer: SIEMENS, controller model: 840 D SL, overall weight: 9,000 kg, spindle speed (max.): 40,000 rpm, CONTROLS .. CNC controls SIEMENS 840 D SL WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 4 .. X-axis travel: 210 mm .. Y-axis travel: 270 mm Kjlhcdowlgmuow Helt .. Z-axis travel: 360 mm SPINDLE / HEAD .. spindle revolutions (max): 40000 /min .. tool fixture: HSK A40 TOOL MAGAZINE .. number of positions: 64 AUTOMATIC WORKLOAD EQUIPMENT .. workpiece manipulator: articulated robot .. number of store positions: 32 ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. total weight approx.: 9000 kg ATTACHMENTS .. chip conveyor: yes .. coolant unit: yes .. band filtration unit: yes .. closed cabin: yes Operating hours: Spindle 1: 4050 h, Spindle 2: 11,114 h Internal cooling 70 bar Fanuc Automation Robot M-10IA Integrated workpiece changing device Knoll coolant tank Knol KF 400/900

Year of construction: 2010, Condition: used, controller manufacturer: SIEMENS, controller model: S7, power: 140 kW (190.35 HP), tractive force with load: 3,00,000 N, material length: 16,000 mm, outer diameter: 45 mm, pipe diameter: 55 mm, pipe length: 10,000 mm, wall thickness: 3 mm, CONTROLS .. PLC SIEMENS S7 FEEDSTOCK TUBE .. external diameter min.: 22 mm .. external diameter max.: 55 mm .. wall thickness min.: 1 mm .. wall thickness max.: 3 mm .. length min.: 5000 mm .. lenght max.: 10000 mm PRODUCT (PROFILE, TUBE) .. external diameter min.: 15 mm .. external diameter max.: 45 mm .. wall thickness min.: 0.8 mm .. wall thickness max.: 2.8 mm .. length min.: 7000 mm .. lenght max.: 16000 mm CHARACTERISTICS DRAWING MACHINE .. force: 300 kN .. number of parallel trains / strands max.: 3 .. speed max.: 30 m/min .. drive system -drawing machine-: chain .. main drive power: 110 kW ELECTRICAL SPECIFICATIONS .. total power consumption: 140 kW Kljlhowlgmnscdw Hst .. mains voltage: 460 V .. mains frequency: 60 Hz Drawing machine BRESCIANI S.A. - 3 strands - drum magazine, manually loaded - chain new in 2018 Pipe pointing machine HAGINGER AHM 63 with slide insertion device S - Pipe diameter 20 - 70 mm - Wall thickness 1 - 6.5 mm - Pipe length 3,000 - 10,000 mm - Material: Steel tubes with a strength of 800 N/sqmm - Max. forming force: 4 x 630 kN - Stroke rate: 630/min - Drive motor power: 30 kW Slide insertion device ‘S’ - Infinitely variable feed speed: 0 - 100 mm/s - Carriage stroke max.: 600 mm - Speed of the clamping head (infinitely variable): 0 - 50 /min - Insertion force: 2.0 KN - Power of the hydraulic unit: 7.5 KW SEMA cross chain conveyor.

Condition: used, Year of construction: 2005, travel distance X-axis: 2,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 550 mm, controller manufacturer: FANUC, controller model: 18I MB, total height: 2,500 mm, spindle speed (max.): 9,000 rpm, space requirement length: 5,357 mm, space requirement width: 3,202 mm, CONTROLS .. CNC controls FANUC 18I MB WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 3 .. X-axis travel: 2000 mm .. Y-axis travel: 500 mm .. Z-axis travel: 550 mm SPINDLE / HEAD .. spindle revolutions (max): 9000 /min TOOL MAGAZINE .. number of positions: 24 .. tool diameter max.: 75 mm .. - with free neighbour positions: 160 mm .. tool length max.: 320 mm Ksljwldyfohcdw Hjlt .. tool weight max.: 4 kg .. tool changing time: 15 s AUTOMATIC WORKLOAD EQUIPMENT .. number of store positions: 24 DIMENSIONS / WEIGHTS .. space requirements -left/right-: 5357 mm .. space requirements -front/back-: 3202 mm .. total height: 2500 mm including chip conveyor Duty cycle 53'700h Spindle hours 26'400h Tool holder 5 pieces The following auxilliaries can be bought seperately at additional cost: Röhm double clamps Torsion springs for tool holders 50 pieces Tribos-S Polygon chuck with diameter 6,8,10,12,16 Lathe chuck diameter 12,20,32 SK40 Tightening bolt with hole

Condition: used, Year of construction: 2000, travel distance X-axis: 180 mm, travel distance Y-axis: 215 mm, travel distance Z-axis: 1,250 mm, overall weight: 6,600 kg, controller manufacturer: SIEMENS, controller model: 840 C, number of spindles: 2, CONTROLS .. CNC controls SIEMENS 840 C BASIC FUNCTIONS .. number of spindles: 2 .. number of turrets: 2 .. live positions: yes .. number of c-axes: 2 X/Z SLIDE .. Z-axis travel: 1250 mm .. X-axis travel: 180 mm .. Y-axis travel: 215 mm .. number of tool positions (total): 12 X/Z SLIDE .. Z-axis travel: 1250 mm .. X-axis travel: 140 mm Klolhcdswldx Iow Hst ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. total weight approx.: 6600 kg

Condition: used, Year of construction: 2000, turning length: 1,250 mm, turning diameter: 250 mm, travel distance X-axis: 215 mm, travel distance Y-axis: 180 mm, travel distance Z-axis: 1,250 mm, total height: 2,150 mm, controller manufacturer: INDEX, controller model: C200-4, number of spindles: 2, space requirement length: 5,300 mm, CONTROLS .. CNC controls INDEX C200-4 BASIC FUNCTIONS .. design principle: inclined bed .. number of spindles: 2 .. number of x/z slides: 2 .. number of turrets: 2 .. live positions: yes .. number of c-axes: 2 WORKING RANGE TURNING .. turning diameter (max): 250 mm .. worpiece length max.: 1250 mm MAIN SPINDLE .. drive power S6 40%: 43 kW .. drive power S1 100%: 57 kW COUNTER SPINDLE .. drive power S6 40%: 28 kW .. drive power S1 100%: 40 kW .. spindle torque S6 40%: 178 Nm .. spindle torque S1 100%: 255 Nm .. c-axis: yes X/Z SLIDE .. Z-axis travel: 1250 mm .. X-axis travel: 215 mm .. Y-axis travel: 180 mm .. number of tool positions (total): 12 X/Z SLIDE Kljlhcdswldxzow Hst .. Z-axis travel: 1250 mm .. X-axis travel: 140 mm .. tool fixture: Turret .. number of tool positions (total): 12 DIMENSIONS / WEIGHTS .. space requirements -left/right-: 5300 mm .. total height: 2150 mm ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz

Condition: excellent (used), Year of construction: 2016, travel distance X-axis: 1,100 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 600 mm, controller manufacturer: FANUC, controller model: 0I MD, total height: 2,940 mm, table length: 1,300 mm, overall weight: 7,200 kg, spindle speed (max.): 8,000 rpm, space requirement length: 4,400 mm, space requirement width: 4,100 mm, CONTROLS .. CNC controls FANUC 0I MD Kelswldxuehcdw Helt WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 3 .. .. among of them simultaneous CNC axes: 3 .. X-axis travel: 1100 mm .. Y-axis travel: 650 mm .. Z-axis travel: 600 mm TABLE .. table surface (left-right): 1300 mm SPINDLE / HEAD .. spindle revolutions (max): 8000 /min TOOL MAGAZINE .. number of positions: 40 ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 4400 mm .. space requirements -front/back-: 4100 mm .. total height: 2940 mm .. total weight approx.: 7200 kg Operating hours 1500 h Furnishing: - 3D buttons - Breakage control - div Werkzeughalter - 2 Goody Schraubstock

Condition: excellent (used), Year of construction: 2014, overall weight: 1,100 kg, total height: 1,400 mm, space requirement length: 4,200 mm, space requirement width: 800 mm, CONTROLS .. electronic controls DIMENSIONS / WEIGHTS .. space requirements -left/right-: 4200 mm .. space requirements -front/back-: 800 mm .. total height: 1400 mm .. total weight approx.: 1100 kg Kljlhcdwjwldxnj Hjt ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz Facility in good to very good condition tech. Data Diameter Ø 5 - 52mm max. bar length 3200 mm Dimensions: 4200 x 800 x 1400mm

Year of construction: 2019, Condition: like new (used), overall weight: 100 kg, total height: 860 mm, space requirement length: 560 mm, space requirement width: 660 mm, CONTROLS .. CNC controls Klolhcdowk Nh Sow Het ELECTRICAL SPECIFICATIONS .. mains voltage: 240 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 560 mm .. space requirements -front/back-: 660 mm .. total height: 860 mm .. total weight approx.: 100 kg Optical measuring machine for testing diameter, shape, roundness, angle, cylindricity, bending radius, and length. Measuring range: Ø 8 x 100 mm Max. workpiece dimensions: Ø 90 x 260 mm Max. workpiece weight: 3 kg Repeatability (diameter) at 20°C: 0.4 µm Repeatability (length) at 20°C: 3 µm Max. travel speed (vertical): 20 mm/s Max. rotation speed: 180 °/s

Year of construction: 2016, Condition: used, CONTROLS Klelswk Nh Eohcdw Hot .. electronic controls

Condition: used, Year of construction: 1994, turning diameter: 210 mm, spindle speed (max.): 5,500 rpm, bar passage: 42 mm, bar diameter: 42 mm, overall weight: 4,800 kg, controller manufacturer: FANUC, number of spindles: 2, CONTROLS .. CNC controls FANUC BASIC FUNCTIONS .. design principle: inclined bed .. number of spindles: 2 .. number of x/z slides: 2 .. number of turrets: 2 .. live positions: yes .. number of c-axes: 2 .. number of y-axes: 1 WORKING RANGE TURNING Kjlewk Nhxohcdw Helt .. turning diameter (max): 210 mm .. bar diameter (max): 42 mm MAIN SPINDLE .. spindle revolutions (max): 5500 /min .. c-axis: yes COUNTER SPINDLE .. spindle revolutions (max): 5500 /min .. c-axis: yes DIMENSIONS / WEIGHTS .. total weight approx.: 4800 kg ATTACHMENTS (TURNING) .. chip conveyor: yes .. hydraulic system: yes

Year of construction: 2015, Condition: excellent (used), CONTROLS .. electronic controls Kslhcewk Nhrodw Hslt

Condition: reconditioned (used), Year of construction: 1960, travel distance X-axis: 1,000 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 1,120 mm, spindle diameter: 80 mm, spindle speed (max.): 710 rpm, total height: 2,500 mm, table length: 1,060 mm, table width: 980 mm, travel distance W-axis: 710 mm, overall weight: 9,000 kg, year of last overhaul: 2008, controller manufacturer: HEIDENHAIN, power: 15 kW (20.39 HP), space requirement length: 4,500 mm, space requirement width: 2,400 mm, CONTROLS .. digital read out HEIDENHAIN BASIC DESIGN .. basic design: cross table WORKING RANGE -CUBIC- .. X-axis travel: 1000 mm .. Y-axis travel: 900 mm .. Z-axis travel: 1120 mm .. W-axis travel: 710 mm TABLE .. table surface (left-right): 1060 mm .. table surface (front-back): 980 mm .. workpiece load (max): 3000 kg .. rotation axis: B .. - mode of operation: manual SPINDLE / HEAD .. spindle type: horizontal .. spindle revolutions (min): 6 /min .. spindle revolutions (max): 710 /min .. spindle diameter: 80 mm .. tool fixture: MK 5 ELECTRICAL SPECIFICATIONS .. total power consumption: 15 kW DIMENSIONS / WEIGHTS .. space requirements -left/right-: 4500 mm .. space requirements -front/back-: 2400 mm Klolhswk E A Secdw Hot .. total height: 2500 mm .. total weight approx.: 9000 kg Table type boring machine in excellent condition, still under power. Video available. Lots of clamping devices and tools.

Condition: used, Year of construction: 2007, grinding length: 800 mm, grinding width: 600 mm, overall weight: 5,000 kg, grinding spindle motor power: 15 W, controller manufacturer: SIEMENS, controller model: S7, spindle motor power: 15 W, CONTROLS .. CNC controls SIEMENS S7 WORKING RANGE SURFACE GRINDING .. grinding length: 800 mm .. grinding width: 600 mm .. vertical travel: 55 mm TABLE (SURFACE GRINDING) .. table surface (left-right): 1200 mm .. table surface (front-back): 600 mm .. workpiece load (max): 800 kg .. magnetic table: yes SPINDLESTOCK GRINDING SPINDLE .. X-axis travel: 900 mm .. Y-axis travel: 550 mm .. Z-axis travel: 560 mm .. drive power: 15 kW GRINDING TOOL .. type of grinding tool: wheel .. diameter (max): 400 mm Klslhcdwowk Dxls Hst .. borehole: diameter: 127 mm .. width: 80 mm ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. total weight approx.: 5000 kg

Condition: used, Year of construction: 1967, installation height: 407 mm, pressing force: 100 t, tool height: 407 mm, CONTROLS .. conventional PRESS DESIGN .. drive system: eccentric / crank .. frame design: C-frame, single sided PRESS FORCES .. total force (nominal): 100 to SLIDE .. slide force: 100 to .. stroke rate (max.): 72 /min SLIDE (MECHAN. PRESS) .. slide adjustment: 80 mm .. stroke adjustment: yes .. stroke min.: 8 mm Kelowkr Eyshcdw Holt .. stroke max.: 112 mm TOOL ASSEMBLY DIMENSIONS .. shut height (stroke down, adjustment up), BDC: 407 mm ATTACHMENTS (PRESSES) .. 2-hand engagement: yes for safe tools only

Condition: used, Year of construction: 1996, overall weight: 73,000 kg, sheet thickness steel (max.): 5 mm, number of straightening rollers: 9, sheet thickness (max.): 5 mm, pressing force: 400 t, installation height: 705 mm, ram stroke: 210 mm, controller manufacturer: SIEMENS, controller model: S7-400, lifting height: 210 mm, load capacity: 4,000 kg, worktable length: 2,600 mm, coil outer diameter: 1,500 mm, coil weight: 4,000 kg, coil width: 400 mm, material thickness: 5 mm, material width: 400 mm, table length: 2,600 mm, table width: 990 mm, tool height: 705 mm, year of last overhaul: 2009, CONTROLS .. PLC SIEMENS S7-400 PRESS DESIGN .. drive system: eccentric / crank .. openings in uprights: yes .. number of suspensions: 2 .. slide ejectors / cushion: yes .. table cushion: yes .. opening in table: yes .. quick die change system: yes PRESS FORCES .. total force (nominal): 400 to .. nominal work capacity: 32 kNm PRESS TABLE .. table surface (left-right): 2600 mm .. table surface (front-back): 990 mm .. thickness of bolster plate: 200 mm .. height above floor level: 800 mm .. opening in bed (left-right): 2325 mm .. opening in bed (front-back): 280 mm SLIDE .. slide force: 400 to Klelswkr Etehcdw Hot .. table surface (left-right): 2600 mm .. table surface (front-back): 950 mm .. stroke: 210 mm .. stroke rate (max.): 90 /min SLIDE (MECHAN. PRESS) .. slide adjustment: 150 mm .. stroke rate (min.): 25 /min .. stroke rate (max.): 90 /min .. main drive power: 75 kW SLIDE EJECTOR / CUSHION .. number of ejectors: 13 .. nominal force: 3.7 to .. stroke: 89 mm TOOL ASSEMBLY DIMENSIONS .. shut height (stroke down, adjustment up), BDC: 705 mm OVERALL SPECIFICATIONS (COIL LINES) .. sheet width max.: 400 mm .. sheet thickness max.: 5 mm .. coil weight max.: 4 to .. feed velocity max.: 50 m/min DECOILER .. design: single reel, traversable .. coil weight max.: 4 to .. max. diameter of coil: 1500 mm .. mandrel expansion range from: 460 mm .. mandrel expansion range up to: 530 mm LEVELLER UNIT .. number of leveller rolls: 9 .. diameter of leveller rolls: 50 mm .. loop controls: yes STRIP-FEEDER .. feeder type: roll feeder .. roll diameter: 160 mm TRANSFER SYSTEM .. distance between tools, stroke X max.: 360 mm .. distance between tools, stroke X min.: 90 mm .. stroke Y max.: 80 mm .. stroke Z max.: 0 mm .. Inner width clamping rails closed max.: 470 mm .. Inner width clamping rails closed min.: 275 mm .. distance press table - transfer rail min.: 320 mm DIMENSIONS / WEIGHTS .. height above floor level: 6300 mm .. total weight approx.: 73000 kg ATTACHMENTS (PRESSES) .. European CE standards: yes + KOHLER coil line with SIEMENS S7-317 control system + Zig-zag feed 1-3 fold + HIESSL band lubrication unit + SANDER 2-axis transfer unit with variable feed + UNIDOR press force monitoring + die cushion bar in the table with exchangeable die cushions + System regularly maintained and in good condition

Condition: used, Year of construction: 2003, installation height: 555 mm, table length: 2,000 mm, table width: 1,200 mm, pressing force: 315 t, ram stroke: 160 mm, overall weight: 45,000 kg, material thickness: 5 mm, sheet thickness steel (max.): 5 mm, controller manufacturer: SIEMENS, controller model: S7, lifting height: 160 mm, load capacity: 4,000 kg, worktable length: 2,000 mm, coil outer diameter: 1,500 mm, coil weight: 4,000 kg, coil width: 400 mm, material width: 400 mm, number of straightening rollers: 9, sheet thickness (max.): 5 mm, tool height: 555 mm, CONTROLS .. PLC SIEMENS S7 PRESS DESIGN .. drive system: knuckle-joint .. frame design: H-frame, monoblock .. openings in uprights: yes .. number of suspensions: 2 .. feedstock transport direction: left to right PRESS FORCES .. total force (nominal): 315 to .. nominal work capacity: 38 kNm PRESS TABLE .. table surface (left-right): 2000 mm .. table surface (front-back): 1200 mm .. thickness of bolster plate: 200 mm SLIDE .. slide force: 315 to .. table surface (left-right): 1995 mm .. table surface (front-back): 1100 mm .. stroke: 160 mm .. stroke rate (max.): 80 /min SLIDE (MECHAN. PRESS) .. slide adjustment: 140 mm .. stroke rate (min.): 20 /min .. stroke rate (max.): 80 /min .. main drive power: 90 kW TOOL ASSEMBLY DIMENSIONS .. shut height (stroke down, adjustment up), BDC: 555 mm .. distance between columns (H-frame): 2060 mm .. passline opening (free passage in side columns): 1060 mm OVERALL SPECIFICATIONS (COIL LINES) .. sheet width max.: 400 mm .. sheet thickness max.: 5 mm COIL CHAIR .. coil weight max.: 4 to DECOILER .. design: single reel, traversable .. sheet width max.: 400 mm .. sheet width (min): 30 mm .. coil weight max.: 4 to .. max. diameter of coil: 1500 mm .. mandrel expansion range from: 460 mm .. mandrel expansion range up to: 530 mm .. movement: 1500 mm LEVELLER UNIT .. sheet width max.: 400 mm .. sheet width (min): 50 mm .. material cross section max. (450 N/mm2): 1000 mm² .. number of leveller rolls: 9 .. diameter of leveller rolls: 50 mm .. number of infeed-/outfeed rolls: 150 .. feed velocity min.: 5 m/min Kslhcdwjwkr Ems Holt .. feed velocity max.: 50 m/min STRIP-FEEDER .. feeder type: roll feeder .. sheet width max.: 400 mm .. sheet thickness max.: 5 mm ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. total weight approx.: 45000 kg ATTACHMENTS (PRESSES) .. decoiler: yes .. leveller unit: yes .. strip feeder: yes Coil Reel KOHLER 4000.1 Straightener KOHLER KRM 50.400/9 KOHLER Loop control BÜ5 Roll feed KOHLER WVE 120/400 HIESSL belt lubrication (wide spray) UNIDOR control system Tool loading consoles

Condition: used, Year of construction: 1994, sheet thickness steel (max.): 2 mm, number of straightening rollers: 19, sheet thickness (max.): 2 mm, pressing force: 200 t, installation height: 542 mm, ram stroke: 178 mm, lifting height: 178 mm, load capacity: 2,000 kg, worktable length: 1,780 mm, coil outer diameter: 1,500 mm, coil weight: 2,000 kg, coil width: 260 mm, material width: 260 mm, table length: 1,780 mm, table width: 1,300 mm, tool height: 542 mm, PRESS DESIGN .. drive system: eccentric / crank .. frame design: H-frame, tie rod .. openings in uprights: yes .. table cushion: yes .. feedstock transport direction: left to right PRESS FORCES .. total force (nominal): 200 to PRESS TABLE .. table surface (left-right): 1780 mm .. table surface (front-back): 1300 mm .. opening in bed (left-right): 1445 mm .. opening in bed (front-back): 260 mm SLIDE .. slide force: 200 to .. table surface (left-right): 1500 mm .. table surface (front-back): 1100 mm .. stroke: 178 mm .. stroke rate (max.): 120 /min SLIDE (MECHAN. PRESS) .. slide adjustment: 150 mm .. stroke rate (min.): 20 /min .. stroke rate (max.): 120 /min DIE CUSHION (TABLE CUSHION) .. number of cushions: 11 .. cushion force: 3 to TOOL ASSEMBLY DIMENSIONS .. shut height (stroke down, adjustment up), BDC: 542 mm .. passline opening (free passage in side columns): 900 mm DECOILER .. design: twin reel .. sheet width max.: 260 mm .. coil weight max.: 2 to .. max. diameter of coil: 1500 mm .. mandrel expansion range from: 460 mm Klelhowkr Egscdw Het .. mandrel expansion range up to: 530 mm LEVELLER UNIT .. sheet width max.: 250 mm .. sheet thickness max.: 2 mm .. sheet thickness min.: 0.3 mm .. number of leveller rolls: 19 .. diameter of leveller rolls: 18 mm .. feed velocity min.: 5 m/min .. feed velocity max.: 60 m/min .. loop controls: yes STRIP-FEEDER .. feeder type: roll feeder .. sheet width max.: 250 mm TRANSFER SYSTEM .. distance between tools, stroke X max.: 260 mm .. distance between tools, stroke X min.: 60 mm .. stroke Y fix: 55 mm .. Inner width clamping rails closed max.: 455 mm .. Inner width clamping rails closed min.: 205 mm ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz ATTACHMENTS (PRESSES) .. decoiler: yes .. leveller unit: yes .. strip feeder: yes .. gripper transfer system: yes + Coil feed line KOHLER with straightener KRE2 18.260/19 + Feeder KAISER KWV 250 + 2-axis gripper bars transfer SANDER with adjustable pitch + table cushion rail with various cushions and fillers (separate data sheet available)

Condition: used, Year of construction: 1971, total height: 2,420 mm, installation height: 220 mm, sheet thickness (max.): 5 mm, sheet thickness steel (max.): 5 mm, overall weight: 6,000 kg, pressing force: 80 t, space requirement length: 2,420 mm, space requirement width: 1,700 mm, year of last overhaul: 2008, power: 9 kW (12.24 HP), controller manufacturer: SIEMENS, controller model: S7, lifting height: 50 mm, coil width: 180 mm, material thickness: 5 mm, material width: 180 mm, ram stroke: 50 mm, table length: 420 mm, tool height: 220 mm, CONTROLS .. PLC SIEMENS S7 Klolhcdwowkhtys Hst PRESS DESIGN .. drive system: link drive .. feedstock transport direction: left to right SLIDE .. total force (nominal): 80 to .. stroke: 50 mm .. stroke rate (max.): 80 /min COUNTER RAM .. nominal force: 22 to .. stroke: 8 mm V-RING .. nominal force: 25 to .. stroke: 15 mm TOOL DIMENSIONS .. lower table (left-right): 420 mm .. lower table (front-back): 420 mm .. upper table (left-right): 420 mm .. upper table (front-back): 420 mm .. shut height max.: 220 mm .. ram adjustment: 80 mm .. distance between columns (H-frame): 450 mm .. passline opening (free passage in side columns): 200 mm OVERALL SPECIFICATIONS (COIL LINES) .. sheet width max.: 180 mm .. sheet thickness max.: 5 mm .. feed velocity max.: 999 m/min STRIP-FEEDER .. feeder type: roll feeder .. sheet width max.: 180 mm .. sheet thickness max.: 5 mm .. feeding step max.: 999 mm .. sheet length min: 1350 mm CROP SHEAR .. cutting force: 6.6 kN ELECTRICAL SPECIFICATIONS .. total power consumption: 9 kW .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 2420 mm .. space requirements -front/back-: 1700 mm .. total height: 2420 mm .. total weight approx.: 6000 kg ATTACHMENTS -FINEBLANKING PRESS- .. closed cabin: yes .. waste cutter: yes Info to the Press - good mechanical condition - incl. servo feeders - frequency converter for the main drive motor, i.e. infinitely variable speed - CE

Condition: used, Year of construction: 2000, travel distance X-axis: 1,050 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 825 mm, controller manufacturer: MAZATROL, total height: 3,225 mm, table width: 630 mm, overall weight: 17,000 kg, spindle speed (max.): 10,000 rpm, spindle motor power: 30 W, space requirement length: 6,770 mm, space requirement width: 3,380 mm, CONTROLS .. CNC controls MAZATROL WORKING RANGE -CUBIC- .. X-axis travel: 1050 mm .. Y-axis travel: 800 mm .. Z-axis travel: 825 mm TABLE .. table surface (front-back): 630 mm .. clamping surface diameter: 630 mm .. workpiece load (max): 1500 kg Klslhjwitypjcdw Hst SPINDLE / HEAD .. spindle revolutions (max): 10000 /min .. drive power: 30 kW TOOL MAGAZINE .. magazin type: chain magazine .. number of positions: 160 AUTOMATIC WORKLOAD EQUIPMENT .. store type: table changer .. number of store positions: 6 ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 6770 mm .. space requirements -front/back-: 3380 mm .. total height: 3225 mm .. total weight approx.: 17000 kg ATTACHMENTS .. chip conveyor: yes .. coolant unit: no .. through spindle coolant attachment: yes .. closed cabin: yes The machine comes without a cooling system but with a high-pressure pump.

Condition: used, Year of construction: 1990, total height: 3,200 mm, installation height: 455 mm, pressing force: 100 t, table width: 560 mm, table length: 710 mm, overall weight: 8,500 kg, ram stroke: 320 mm, controller manufacturer: SIEMENS, controller model: S5, lifting height: 320 mm, worktable length: 710 mm, material thickness: 20 mm, material width: 300 mm, sheet thickness (max.): 20 mm, sheet thickness steel (max.): 20 mm, space requirement width: 2,100 mm, tool height: 455 mm, CONTROLS .. electronic controls SIEMENS S5 PRESS DESIGN .. drive system: hydraulic .. frame design: C-frame, single sided .. openings in uprights: yes .. table cushion: yes .. opening in table: yes PRESS FORCES .. total force (nominal): 100 to PRESS TABLE .. table surface (left-right): 710 mm .. table surface (front-back): 560 mm SLIDE .. slide force: 100 to .. table surface (left-right): 560 mm .. table surface (front-back): 450 mm .. spigot hole diameter: 50 mm .. stroke: 320 mm .. thickness of bolster plate: 150 mm SLIDE (HYDR. PRESS) .. approximation velocity max.: 340 mm/s .. working velocity max.: 32 mm/s .. return velocity max.: 330 mm/s SLIDE EJECTOR / CUSHION .. stroke: 40 mm DIE CUSHION (TABLE CUSHION) .. stroke: 80 mm TOOL ASSEMBLY DIMENSIONS .. shut height (stroke down, adjustment up), BDC: 455 mm STRIP-FEEDER .. feeder type: roll feeder .. sheet width max.: 300 mm .. sheet thickness max.: 20 mm .. speed max.: 120 m/min Klolhcswityijdw Hjt ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -front/back-: 2100 mm .. total height: 3200 mm .. total weight approx.: 8500 kg ATTACHMENTS (PRESSES) .. decoiler: optional .. leveller unit: optional .. strip feeder: yes .. 2-hand engagement: yes Equipment: - Cutting impact dampening - Hydraulic die cushion and ejector - CNC - gripper feed (200x900x1700) - Soprem belt system (optional) see article no. 3-49541

Condition: used, total height: 3,360 mm, installation height: 350 mm, table length: 650 mm, pressing force: 70 t, space requirement length: 2,400 mm, space requirement width: 1,750 mm, worktable length: 650 mm, tool height: 350 mm, PRESS DESIGN .. drive system: eccentric / crank .. openings in uprights: yes .. opening in table: yes PRESS FORCES .. total force (nominal): 70 to PRESS TABLE .. table surface (left-right): 650 mm .. thickness of bolster plate: 90 mm .. height above floor level: 860 mm .. opening in bed (left-right): 350 mm SLIDE .. table surface (left-right): 650 mm .. table surface (front-back): 650 mm SLIDE (MECHAN. PRESS) .. slide adjustment: 90 mm .. stroke adjustment: yes .. stroke min.: 10 mm .. stroke max.: 90 mm .. stroke rate (min.): 40 /min .. stroke rate (max.): 160 /min TOOL ASSEMBLY DIMENSIONS .. shut height (stroke down, adjustment up), BDC: 350 mm .. passline opening (free passage in side columns): 330 mm DIMENSIONS / WEIGHTS .. space requirements -left/right-: 2400 mm .. space requirements -front/back-: 1750 mm .. total height: 3360 mm ATTACHMENTS (PRESSES) .. decoiler: yes .. strip feeder: yes Scope of delivery: - press (still under power) - Decoiler Kljlhcdwewif D Ts Hst - Servo feeder make Zehnder and Sommer
