Condition: used, Year of construction: 2013, controller manufacturer: Siemens, controller model: 840 D, _____ Description: Year of manuf. : 2013 Lsdpfx Apezvt Ikodeag Control : Siemens 840 D Rotary-Indexing-table/Spindle: Clamping stations:12 motorised spindles Drive:Torque drive, water-cooled Position measuring system:Direct Switching time:1.5 seconds Spindles:Water-cooled motor spindles C-axes:0.001°, hydraulic clamping Speed:5,500 rpm Power:11 kW Clamping device:Chuck Basic modules: Technology:Positioning module, 3-axis X-axis:50 mm Y-axis:100 mm Z-axis:100 mm Position measuring systems:Direct in all axes Coolant supply:Integrated : : Workpiece size (max.):100 x 100 x 100 mm Station 1: Horizontal:feeding of raw parts (indexing conveyor + Stäubli robot) Vertical:Measuring raw part Station 2: Horizontal:4-fold turret without drive Vertical:Measuring reclamping error (C-axis zeroing) Station 3: Horizontal:4-fold turret without drive Vertical:Not used Station 4: Horizontal:4-fold turret without drive Vertical:Not used Station 5: Horizontal:6-position turret with WAN, 10,000 rpm Vertical:6-position turret with WAN 10,000 rpm Station 6: Horizontal:4-fold turret without drive Vertical:Not used Station 7: Horizontal:6-position turret with WAN, 10,000 rpm Vertical:Not used Station 8: Horizontal:6-position turret with WAN, 10,000 rpm Vertical:Not used Station 9: Horizontal:4-fold turret without drive Vertical:Not used Station 10: Horizontal:6-position turret with WAN, 10,000 rpm Vertical:Not used Station 11: Horizontal:6-position turret with WAN, 10,000 rpm Vertical:6-position turret with WAN 10,000 rpm Station 12: Horizontal:Charging/discharging unit with double swivelling gripper + discharging belt Equipment: Chipmanagement:Chip conveyor High preassure unit:Cooling unit 50 bar Toolmonitoring:Toolbreaktagecontrol ARTIS Rawmaterialfeed:Conveyorbelt with robot Finishpartremoval:Conveyor with 3-way switch Oilmistseparation:Electrostatic filter Fire extraction system:Kraft + Bauer Part labelling:Laser Parts cleaning:HESO cleaning system

Condition: used, Year of construction: 2002, Riello Model VFX300–6/4–0/1-V Vertiflex Transfer Machine with Rotary Table, 6-Stations, 5- Multi Heads with 6 Tools Per Head, 1 Work Station, 2 Setting Stations, Chiller, Swarf Conveyor, Coolant Management System and Tooling. S/No. 27.151.000 (2002). Country of Origin: Italy Lodozvcgijpfx Apdoag Please Note: This lot is located in Budapest, Hungary. Unfortunately there are no loading facilities onsite, dismantling and Loading will be at the cost of the purchaser.

Condition: excellent (used), Year of construction: 1995, High-performance rotary transfer machine, specifically designed for the mass production of medium and large-sized parts. Thanks to reduced production times, high precision, and reliability, it contributes to greater efficiency in the mechanical machining sector: it can perform up to 15 machining operations, transverse machining operations, or front-side machining operations on both sides. Lasdpfxjznnpmj Apdjg

Condition: used, Year of construction: 2011, controller manufacturer: Fanuc, controller model: 30i, _____ Description: Year of manuf. : 2011 Lodpfxjzfu Rfs Apdsag Control : Fanuc 30i In General: Year of manufacture:2011 Control system:Fanuc 30i Maximum table load:100 kg Travel range X/Y/Z:300/300/370 mm Installation weight:approx. 33,000 kg Machining station I (X/Y/Z/B): Technology:1 x vertical spindle Speed:8,000 rpm Tool holder:HSK-A 63 Power:31 kW Torque:197 Nm Tool changer:12 stations B-axis:0.001°, pneumatic indexing, clamping force Tool diameter/length:125/250 mm Machining station II (X/Y/Z/B): Technology:1 x vertical spindle + 1 x horizontal spindle Speed:8,000 rpm Tool holder:HSK-A 63 Power:31 kW Torque:197 Nm Tool changer:12 stations B-axis:0.001°, pneumatic indexing, clamping force Tool diameter/length:125/250 mm Machining station III (X/Y/Z/B): Technology:1 x vertical spindle Speed:8,000 rpm Tool holder:HSK-A 63 Power:31 kW Torque:197 Nm Tool changer:12 stations B-axis:0.001°, pneumatic indexing, clamping force Tool diameter/length:125/250 mm Machining station IV (X/Y/Z/B): Technology:1 x vertical spindle + 1 x horizontal spindle Speed:8,000 rpm Tool holder:HSK-A 63 Power:31 kW Torque:197 Nm Tool changer:12 stations B-axis:0.001°, pneumatic indexing, clamping force Tool diameter/length:125/250 mm Loading station: Numbers:2 pieces (front and rear) Equipment: Position measurement systems:Direct on all axes Chip removal:Chip conveyor Coolant supply:IKZ system, 30 bar Tool breakage monitoring:Artis, type CTM V5 Zero-point clamping system:Erowa Emulsion mist separator:Reven

Condition: ready for operation (used), A complete Winema CNC rotary transfer production line including interlinking, peripherals and a washing system is available. 1) Winema RV20 Flexmaster rotary transfer machining center, stations: 6, machining positions: 12, max. material passage: 42mm, internal thread 1: M16x1.5, internal thread 2: M20x1.5, holes: 8.7mm/15mm/17mm/18mm, reaming: 9mm/15mm/18mm, cycle time: approx. 7s, throughput capacity: approx. 500parts/h, control system: Siemens Sinumerik 840D. 2) Winema bar loading magazine, tube support: 800mm, max. tube thickness: 2mm, max. bar length: 3200mm. 3) Knoll Turbofilter coolant cleaning system, dirty tank volume: 500l, clean tank volume: 150l, filter fineness: 50mm. 4) Knoll cooling unit, cooling capacity: 15kW, max. oil temperature: 30°C. 5) UAS oil mist extraction system, separation efficiency: 96%-98%. 6) Interlinked continuous washing system with automatic parts transfer. 7) Hydraulic system. 8) Conveyor units. 9) Fire extinguishing system. This is a complete and interlinked system for NC control valve production. The production of additional components can presumably be set up. Documentation available. An on-site inspection is possible. Lodpfx Apezbl N Sodoag

Condition: used, Year of construction: 2002, Article: Rotary transfer machine Manufacturer: Pfiffner Lsdpfx Apoy N Agrjdoag Type: Hydromat HB-32/45 Yob: 2002 Please, contact us for getting more information and pictures on mail(at) or *

Condition: ready for operation (used), Year of construction: 2011, A horizontal CNC rotary transfer machine Sinico for tube and bar processing is available. Throughput capacity: approx. 2500pieces/h, max. cutting capacity: 110mm, max. workpiece length: 350mm, max. tube diameter: 81mm, max. bar diameter: 40mm, tool holder: HSK-63, machine weight: approx. 16000kg. The machine has an unknown defect. Documentation available. An on-site inspection is possible. Ledjy Nm U Hjpfx Apdsag

Condition: ready for operation (used), Year of construction: 2005, A horizontal CNC rotary transfer machine Sinico for tube and bar processing is available. Throughput capacity: approx. 2500pieces/h, max. cutting capacity: 81mm, max. workpiece length: 340mm, max. tube diameter: 81mm, max. bar diameter: 40mm, tool holder: HSK-63, machine weight: approx. 16000kg. Documentation available. An on-site inspection is possible. Ljdpfx Apoy Nm U Tsdoag

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, coolant tank capacity: 1,800 l, Equipment: documentation/manual, - 16 TOOL STATIONS - YEAR OF PRODUCTION 2000 (ONLY 3 YEARS PRODUCTIVE USE) - INCL. BAR FEEDER “IEMCA” (2 t CAPACITY) - INCL. OIL TANK SYSTEM (1.400 l COOLENT CONTENT) - INCL. CHIP CONVEYOR (WITH MUD CLEARING) Lasdsy Nmb Hopfx Apdeg - INCL. TOOL SETTING EQUIPMENT - MAX RATED POWER 40KW / 3 x 400 V - “BOSCH” HYDRAULIC UNITS - “SYNUMERIC 840” OPERATING SYSTEM - DOCUMENTATION - UNDER POWER AVAILABLE FOR INSPECTION - VERY GOOD CONDITION

Condition: ready for operation (used), Year of construction: 2020, functionality: fully functional, machine/vehicle number: HB32-305, Hydromat HB32/16, double cycle, year of manufacture 2020, location: LOGA Präzisionsteile GmbH, Himmelreich 4-6, 78554 Aldingen. Control: Bosch MTX, HME operating interface Coolant system: Knoll (oil), vacuum rotary filter, low-pressure and high-pressure pumps for internal tool cooling Machine table with 8 collet chucks and 8 two-jaw chucks 1x Stäubli robot for transferring workpieces from the first to the second clamping position 1x loading magazine, 4.2m 1x VE 40/80 sawing unit 8x feed units: VE 36/100 or VE 35/60 5x CNC 50/100 turning units 2x 3-axis CNC milling units Nordmann tool monitoring Pickup conditions: The machine base measures approximately 4 meters in length, 3 meters in height, and 2.5 meters in width. The weight is approx. 6 tons. The other components are demountable. Lodpfx Apsy Nkhdodoag The hall is very spacious. There is no crane runway; a forklift is required for disassembly. No forklift is available on site! The aisles are 3 meters wide. There is a large roller gate, and trucks can drive directly up to, or even through, the gate for loading.

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 61062, bar passage: 24 mm, TECHNICAL DETAILS Spindle bore: 24 mm Bar loader Model: IEMCA PRA52 F33 Year of manufacture: 2004 Maximum bar length: 3300 mm Maximum bar diameter: 9.1 mm Control system: Siemens S7-200 Drive for parting unit Stroke per slide: 7.15 mm Lasdeyx Ia Nspfx Apdjg Actuation angle: 26.565° Facing chuck PKD 80 MACHINE DETAILS Operating voltage: 230 / 400V Frequency: 50 Hz EQUIPMENT Nordmann tool monitoring with touchscreen Tool Monitor Chip conveyor (Knoll 500 K-1/450, year 2004) Oil filtering system (Knoll FKA 150) Scraper conveyor with coolant system High-pressure unit FKA / 250 Tubes with coolant connections Hydraulic unit Central lubrication Hydraulic schematic and accessories Pressure intensifier HC3 - 4.0 - B Deflection plate T-T Pneumatic accessories (for 4 cylinders) Compressed air service unit DA 300 Clamping plate for chuck TK420 Oil distributor 2-jaw chuck (Röhm, ID no. 431074, stroke 4.25 mm) Cut-off saw with gear transmission Clamping flange (diameter: 100 mm) Spindle unit complete with toothed belt drive Coolant supply Cover plates for empty stations Material stop (stroke: 60 mm) Parting unit extended by 35 mm Measuring system Z-axis Spindle unit with hydraulic NC-axis Device for rinsing the clamping jaws Change parts for material clamping Stops for hydraulic unit carrier Change parts for bar loading magazine Tools Tool holders Additional clamping with collet Further details about the machine can be found in the attached documents.

Condition: ready for operation (used), Year of construction: 1993, A multi-station transfer machine Riello with drilling and tapping units is available. Horizontal working units: 2x drilling units, 2x tapping units, 1x combined unit. Radial working units: 1x drilling unit, 1x tapping unit, 1x combined unit. Quill stroke: 100mm, spindle holder: SK40, rotary table type: TG 320, turret stations: 5, chuck diameter: 200mm, jaw opening travel: 12mm+12mm, spindle holder-chuck center distance: 225mm, total connected load: 23kW. Machine dimensions X/Y/Z: approx. 3700mm/3400mm/3050mm, weight: approx. 5800kg. Documentation available. An on-site inspection is possible. Ledpfxeytgpwe Apdeag

Condition: new, Year of construction: 2024, working width: 1,500 mm, sheet thickness steel (max.): 20 mm, Hydraulic guillotine shear – built-to-order machine (delivery time approx. 10–14 weeks) – including foot switch, touchscreen, rear installation area with light barrier monitoring, automatic/electric cutting gap adjustment, automatic/electric cutting angle adjustment, hydraulic hold-down, motorized backgauge up to 1000 mm depth Lasdpfoynatlex Apdsg - Images similar -

Condition: new, Year of construction: 2025, working width: 3,000 mm, sheet thickness (max.): 10 mm, Hydraulic guillotine shear – made to order (delivery time approx. 10–14 weeks) – includes foot pedal, touchscreen, rear operating area with light curtain monitoring, automatic/electric blade gap adjustment, automatic/electric cutting angle adjustment, hydraulic hold-down, motorized backgauge up to 1000 mm depth Lodpfxjym Uv Ee Apdsag -Images similar-

Condition: new, Year of construction: 2026, functionality: fully functional, Flexbility: Our Rotaflex machines stand out due to their exceptional flexibility, surpassing that of competitors. These machines are versatile, capable of performing a variety of operations including turning, milling, threading, and recessing. Each station operates independently with up to 5-Axes, ensuring efficient and precise machining. Advanced Turning Capabilities: Rotaflex machines are designed for real turning operations, featuring chucks that can simultaneously position on the B axis and perform turning at speeds up to 6,500 RPM. Please find the demonstration videos below: Lodpoyg Nwdofx Apdsag Innovative Plug-and-Run Chucks: Our Plug-and-Run Chucks enable swift chuck changes within seconds, allowing for seamless transitions between jobs. This technology sets Technica apart in the rotary transfer machine industry. Why Choose Technica Rotaflex Machines: Technica machines offer unparalleled versatility and precision, making them ideal for mass production environments that demand high-quality and adaptable machinery. Combining Swiss engineering precision with the multifunctionality, our machines provide reliable and efficient performance.

Condition: used, Technica brand, Stemoflex model rotary transfer machine Lodpoydcm Hofx Apdeag

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: HB32-287, TECHNICAL DETAILS Station 1: Sawing Station 2: Drilling Station 3V: Drill Station 3H: Drilling Station 4: CNC Station 5: CNC Station 6V: Thread cutting Station 6H: Drilling Station 7: Turning Station 8: CNC Facing Station 9: CNC Thread Cutting Station 10: Drill Station 11: Drilling Station 12: No Unit Station 13: CNC Station 14: 45° Milling Station 15: 45° Drilling Station 16: 45° Drilling MACHINE DETAILS Condition: Dismantled In storage since: August 2024 Connection rating: 400 V, 40 kW EQUIPMENT - Loading magazine - Knoll chip conveyor Laedpfx Ajx U Tgaepdjg - Knoll vacuum rotary filter VRF 500 - Machine is sold without the black platform

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 8450-02-001, rotary table diameter: 4,000 mm, Equipment: chip conveyor, TECHNICAL DETAILS Rotary indexing table diameter: 4,000 mm Machining stations: 12 Axis configuration: 4 × 3 axes, 8 × 2 axes Clamping chucks: 12 units for tool holders Drilling units: NC-controlled Laedpfxjxur Ruj Apdeg Accessory systems Chip conveyor: Knoll, type 500K-1/500, year of manufacture 2001 Coolant system: available Filtration system: available Measuring device: integrated MACHINE DETAILS Identification number: 8450-02-001 Customs tariff number: 84573010 Weight Machine: 6,000 kg Control cabinet: 800 kg Coolant system: 600 kg Dimensions Working height: 1,170 mm Machine height: 2,220 mm Footprint: 5,231 x 4,540 mm EQUIPMENT - Rotary indexing table with large 4,000 mm diameter for extensive machining operations - 12 NC drilling units with 12-piece clamping chuck setup - Integrated chip conveyor of type Knoll 500K-1/500 - Complete system with filtration and coolant system - Measuring system and automatic loading and unloading for seamless automation

Condition: good (used), Year of construction: 2010, Rotary table Fabr.WEISS Type: TC 220T Year: 2010. Lsdsxr Dh Hepfx Apdsag

Condition: not inspected (used), Year of construction: 1967, Manufacturer: Steinel Model: 5 Station Rotary Transfer Drilling Machine BE 10 VK Year of Manufacture: 1967 Weight: approx. 3,000 kg General / Technical Data: 5-station rotary transfer special drilling machine for horizontal drilling with multi-spindle heads Drilling units: 4 units Station 1 – loading and unloading Laodpfx Apow H Rh Ssdjg Station 2 – horizontal drilling unit type: BE 10 VK Station 3 – horizontal drilling unit type: BE 10 VK Station 4 – horizontal drilling unit type: BE 10 VK Station 5 – horizontal drilling unit type: BE 10 VK Feed of drilling units: mechanical feed via quill Drill heads: multi-spindle drilling units Rotary table: mechanical indexing in 5 positions, Ø 400 mm Workpiece clamping: hydraulic, via centric mandrel, workpiece Ø approx. 80 mm Machine dimensions (W x D x H): approx. Ø 1,800 mm x H = 2,200 mm Power supply / connected load: 380 Volt, 50 Hz Accessories / Special features: • Machine is designed for large-scale production • Features a robust cast iron machine table with lateral chip removal and separate coolant tank • Automatic safety guard door • Equipped with a 5-station rotary indexing table • Heavy cast iron machine table, ideal for the retrofit or rebuilding of a special purpose machine • Suitable for refurbishment or conversion

Condition: not inspected (used), Year of construction: 1969, Manufacturer: Steinel Model: 6-Station BE 10 VK, BE 6 VK Year of manufacture: 1969 Weight: approx. 3,000 kg General / Technical specifications: 6-station rotary transfer special-purpose drilling machine for vertical and horizontal drilling in small workpieces Drilling units: 7 pcs Station 1 – Loading and unloading Station 2 – Vertical drilling unit, type: BE 10 VK Station 3 – Horizontal drilling unit Station 4 – Horizontal and vertical drilling unit, type: BE 6 VK Station 5 – Horizontal spindle unit, type: BE VK, with additional guide. Mounting: slip bush Ø 28 mm Station 6 – Horizontal drilling unit and vertical tapping unit, type: BE 6 VK Feed advance for drilling units: mechanical feed via quill Drill heads: single-spindle drilling units Rotary index table: mechanically indexed in 8 positions, Ø 400 mm Workpiece clamping: manual, via collet Ø 30 mm Machine dimensions (W x D x H): approx. Ø 1,800 mm x H = 2,200 mm Power supply / connected load: 380V, 50 Hz Lodsw H I R Rjpfx Apdsag Accessories / Special equipment: • The machine is designed for mass production use • The machine is equipped with a robust cast iron machine table with chip disposal at the rear and a separate large coolant tank (rear outlet) • Safety light curtain (Sick) • Extensive accessories: spare parts, spindle units, and rotary indexing table • The machine features a 6-station rotary indexing table • Heavy cast iron machine table, ideal for rebuilding as a special-purpose machine

Condition: ready for operation (used), Two identical rotary transfer machines Eubama including filtration systems are available. Workpiece diameter: 60mm, workpiece length: 320mm, clamping stations: 10, cycle rate: 20/min, spindle stroke: 100mm, drilling capacity steel/brass: 20mm/30mm, threading capacity steel/brass: M30/M40. Documentation available. An on-site inspection is possible. Lajdpsw Hglmjfx Apdsg

Condition: used, Year of construction: 1971, Manufacturer: Steinel Model: 8 Stations Drilling Units: Type Steinel BE 10 VK Year of Manufacture: 1971 Weight: approx. 4,500 kg Lodow E Hpvspfx Apdjag General Information / Technical Data: 8-station rotary indexing special drilling machine for vertical and horizontal drilling operations in workpieces, with manual collet clamping. Drilling units: 7 units Station 1 – Loading and unloading Station 2 – Horizontal drilling unit, type: BE VK, power 2.2/3 kW, spindle mount: sleeve Ø 36 mm Station 3 – Vertical drilling unit, type: BE VK, collet chuck mounting Station 4 – Horizontal drilling unit, type: BE VK, spindle mount: sleeve Ø 36 mm Station 5 – Vertical spindle unit, type: BE VK, spindle mount: sleeve Ø 28 mm Station 6 – Horizontal drilling unit, type BE VK with additional guide, spindle mount: sleeve Ø 28 mm Station 7 – Horizontal drilling unit, type: BE VK, power 2.2/3 kW, spindle mount: sleeve Ø 36 mm Station 8 – Vertical spindle unit, type: BE VK, power 2.2/3 kW, spindle mount: sleeve Ø 28 mm Drilling feed: mechanical feed via quill Rotary indexing table: mechanically indexing, 8 positions, Ø 500 mm Workpiece clamping: manual via collet Ø 45 mm Machine dimensions (W x D x H): approx. 2,600 mm x 2,400 mm x 2,500 mm Power supply / connected load: 380 Volt, 50 Hz Accessories / Special Equipment: • Machine is designed for high-volume production • Features a robust cast machine table with chip conveyor to the rear and a separate large coolant tank • Extensive range of clamping devices and auxiliary tools included • The machine is equipped with a mechanically switched 8-station rotary indexing table • Coolant system with chip tray • Extremely stable machine bed, also ideally suited for rebuilding as a special-purpose machine

Condition: ready for operation (used), Year of construction: 1994, Stations: 24, substations: 20, side stations: 20, axes: 2/station, collets: 24, production output single/double cycle: 120/240 pieces/min, stroke: 35mm, max. workpiece diameter: 25mm, spindle speed: 20000rpm, machine weight: approx. 2650kg, control: Mikron MAC 50, operating hours: approx. 17335h. Documentation available. An on-site inspection is possible. Lasdpfx Apew Emx Rsdsg

Condition: used, Year of construction: 1963, functionality: unexamined, Manufacturer: Steinel Model: 6 Stations Year of manufacture: 1963 Lsdpfxjwyn S Uo Apdeag Weight: approx. 2,500 kg General / Technical Data: 6-station rotary indexing special drilling machine for vertical and horizontal drilling in small workpieces Drilling units: 7 units Station 1 – Loading and unloading Station 2 – Vertical drilling unit Station 3 – Horizontal drilling unit Station 4 – Horizontal and vertical drilling unit Station 5 – Horizontal spindle unit Station 6 – Horizontal drilling unit and vertical thread-cutting unit Feed of the drilling units: mechanical feed via quill Drilling heads: single-spindle Tool diameter: approx. Ø3 mm to Ø8 mm Workpiece clamping: manually operated via collet chuck Machine dimensions (W x D x H): approx. Ø 2,000 mm x H = 2,200 mm Power supply / Connected load: 380 Volt, 50 Hz Accessories / Special features: • The machine is designed for large-scale production • The machine features a sturdy machine table with chip discharge to the underside of the table center with a separate large coolant tank • Extensive set of clamping and auxiliary devices included • The machine is equipped with a 6-station rotary indexing table
