Condition: used, Type 693 Euro5 Year: 1996 General data Cutting length: 3200 mm Cutting width: 2650 mm Max. cutting height: 60 mm Main saw Speed: 2870 rpm Power: 5.5 kW Max. Ø280 mm Scoring saw Speed: 2850 rpm Power: 1.1 kW Max. Ø125 mm Total connected load: 8 kW Machine weight: 3150 kg Ihodoyac Ebspfx Adwjt

Condition: used, Cart 320cm Tiltable blade Iedoyac Agopfx Adwoht Cutter 400V

Condition: used, Year of construction: 2009, functionality: fully functional, cutting length (max.): 3,800 mm, cutting height with scoring (max.): 80 mm, saw blade diameter: 380 mm, cutting height (max.): 100 mm, main saw diameter: 380 mm, input voltage: 380 V, GIBEN SMART panel saw with front loading, cutting capacity 3800 mm, in working condition. Ihsdpfsx U Emrox Adwet

Condition: used, Year of construction: 2023, Exhibition machine Garbsen HORIZONTAL PANEL SAW GABBIANI P Manufacturer: SCM Type: GABBIANI P80 Year of manufacture: 2023 1 unit MAIN FEATURES INDIVIDUALLY SELECTABLE AIR CUSHION TABLES: AN INDISPENSABLE TOOL SIDE SAFETY DEVICES: MORE SPACE FOR WORKING FLOATING GRIPPERS: GUARANTEED PERFECT CUT TECHNICAL DATA GENERAL INFORMATION gabbiani p80 Saw blade projection mm 80 Working table height mm 950 Standard number of grippers 5 Number of grippers for versions 33/38/43 9 / 10 / 10 Number of grippers for versions 33/38/43 with FlexCut 1 unit (single gripper with double fingers included) 10 / 11 / 11 CUTTING DIMENSIONS Version 33 mm 3300x2100 Version 33 (Opt.) mm 3300x3200 Version 38 mm 3800x3200 Version 38 (Opt.) mm 3800x3800 Version 43 mm 4300x3200 Version 43 (Opt.) mm 4300x4300 AXIS SPEED Variable saw carriage speed m/min 6 – 60 Variable pusher speed () m/min 60 MAIN SAW BLADE Motor power (S6 -40%) - 50hz (star-delta start) kW (HP) 7 (9) (11) Speed – 50 hz rpm 4650 Saw blade diameter mm 340 Shaft diameter main saw blade mm 80 SCORING BLADE Motor power (S6 -40%) - 50hz kW (HP) 1.5 (2) Speed – 50 hz rpm 5850 Scoring blade diameter mm 200 Shaft diameter scoring blade mm 80 INSTALLATION Installed power kW 12÷15 Base machine voltage Euro voltage (400 V / 50 hz) Compressed air demand NL/min 300 Required compressed air pressure bar 7 Extraction air requirement m3/h 2440 Extraction air speed m/sec 20 Extraction port diameter mm 4x120 () Note: in countries where EU standards apply, the forward pusher feed speed is limited to 25 m/min. GENERAL CHARACTERISTICS Fully automatic, PC/PLC-controlled horizontal panel saw suitable for cutting solid wood, MDF, chipboard, plywood, and similar materials. Frame and working table – Machine frame is a steel tube construction – Working table of rib-reinforced steel with Bakelite coating – Longitudinal fence on the left side Saw carriage made of steel, consisting of: – a motor for the main saw blade and a motor for the scoring blade – vertical lifting of the saw blade on linear ball bearing guides and shoes – running rollers of hardened and ground steel – balanced mass distribution for optimal cut quality – running direction towards the longitudinal fence – saw carriage drive via rack and pinion – carriage travel on cylinder guides – cylinder guides of hardened and ground steel (5-year warranty), protected by special dust wipers – pneumatic switch for fast and safe main and scoring blade change Pressure beam – pressure beam with uniform pressure across the entire cut length, recesses to prevent collision with grippers; pneumatic height adjustment via high-precision rack and pinion, pressure adjustable from 1.5 to 6 bar – dual extraction system with one unit above the pressure beam for cleaning the work table and one unit below on the saw carriage – side automatic aligner with pneumatic cylinder over the entire length. Sliding on linear ball bearing guides and shoes. * Travel distance: 1200 mm * minimum working width: 60 mm * maximum working width: 1200 mm Positioning pusher and rear part of the machine – Positioning pusher full length, powered by a robust drive shaft. Positioning pusher control... Ihjdpfx Adsx Twcvswjt

Condition: good (used), Year of construction: 1998, still well-preserved panel saw max. cutting length 3200 mm Price ex location, not dismantled, Austria, Linz area Iedpfx Adjx Sdrhowsht

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 0-341-07-8874, cutting length (max.): 3,200 mm, cutting height with scoring (max.): 72 mm, saw blade diameter: 350 mm, cutting height (max.): 70 mm, cutting width (max.): 3,200 mm, feed rate X-axis: 80 m/min, feed rate Y-axis: 60 m/min, main saw diameter: 350 mm, total length: 5,800 mm, total height: 2,000 mm, total width: 6,410 mm, Equipment: scorer, Panel beam saw HOLZMA type HPP 32/32/L Left side execution machine Main motor 7,5 kW Pre-cutting unit, motor 1,1 kW Central side pressure device with infinitely adjustable side pressure 3 "air" tables: size 1800x600 mm 6 pcs of grippers: 3 pcs double finger stop; 3 pcs single finger stops Label printer Software for cut plan optimalization Software for CSV import Iedpex Sap Njfx Adweht

Condition: used, Year of construction: 2001, functionality: fully functional, machine/vehicle number: AE/22614, cutting length (max.): 3,200 mm, cutting width (max.): 4,500 mm, total length: 5,000 mm, total height: 2,350 mm, total width: 7,000 mm, SECOND-HAND PANEL SAW SCM MOD. SIGMA 65 - CE RULES - Cutting dimensions: 4500X3200 mm - Main blade projection: 65mm - N. 6 clamps - Saw carriage speed: 12m/min - Main blade diameter: 300mm - shaft diameter 80mm - Scorer blade diameter: 160mm - shaft diameter 55mm Ihedpfx Asx Rvazodwst - Main blade motor: 5,5kW - Overall dimensions: 7000x5000x4350 - S/N AE/22614 - Year 2001

Condition: ready for operation (used), Year of construction: 2020, functionality: fully functional, machine/vehicle number: 1000031582, cutting length (max.): 3,800 mm, saw blade diameter: 350 mm, cutting width (max.): 3,800 mm, saw blade bore: 65 mm, throughput speed: 417 mm/s, TECHNICAL DETAILS Saw blade diameter min.: 200 mm Saw blade diameter max.: 350 mm Saw blade bore diameter: 65 mm Max. cutting length: 3,800 mm Max. cutting width: 3,800 mm Ihsdpfxex Rbkre Adwot Number of feed clamps: 6 Max. feed rate: 25 m/min MACHINE DETAILS Electrical data Main motor power: 18.0 kW Voltage: 400 V Current consumption: 36 A Power: 18.0 kW Dimensions & weight Dimensions (L x W x H): 6,050 x 1,750 x 2,400 mm Weight: 5,000 kg Transport packages: 3 pcs. EQUIPMENT Documentation CE marking Optiplanning software – Easy version, SOPHIA services

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: 561, cutting length (max.): 3,100 mm, cutting height (max.): 95 mm, cutting width (max.): 3,100 mm, feed rate X-axis: 100 m/min, saw drive: 11 W, warranty duration: 12 months, Equipment: scorer, HOLZ-HER Pressure Beam Saw Tectra 6120 power, year of manufacture 2025, delivery ex works - 1 angular air-cushion table 1800 x 600 mm with 1800 mm stop rail - 2 air-cushion support tables 1800 x 600 mm - 3 feed rollers at the front - 3 double-finger floating workpiece clamps - 4 floating workpiece clamps - Sliding door on the left - Automatic cut length limitation - Pro-Lock quick-change clamping system - Optibase Plus optimization software for office use - Uninterruptible Power Supply (UPS) - Automatic central lubrication - Label printer and software - Hand-held remote control unit - Width stop positioning speed 25 m/min, return speed 100 m/min Ihedox Nqrvopfx Adwjt - Saw carriage feed speed 0–100 m/min, return speed 130 m/min - Scoring motor 2.2 kW - Maximum saw blade projection: 95 mm - Motorized groove height adjustment 0–30 mm - Delivery time: immediately available

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, cutting length (max.): 3,800 mm, saw blade diameter: 380 mm, cutting height (max.): 90 mm, cutting width (max.): 3,800 mm, main saw diameter: 380 mm, overall weight: 4,400 kg, Beamsaw SIGMA IMPACT 90 (SCM Group) suitable for furniture panels precize cutting by one or more panels overlapped. Manufacturer: SCM Group Model: Sigma Impact 90 Production year: 2017 Cutting width: 3.800 mm Cutting depth: 3.200 mm Max. cutting height: 90 mm Front tables (air cushion): 1x 2.500x600mm, 3x 2.500x600mm Machine basement with air-cushion. Max. main blade diameter: 380 mm Scorer diameter: max. 300 mm PUSHER: brushless motor, max. speed 120 m/min ! SAW CARRIAGE: brushless motor, max. speed 150 m/min ! THK linear guides for the saw carriage movement. THK linear guides for the PUSHER movement. Ihsdpfx Adjx Nc Ayswot Automatic centralized lubrication of THK linear guides. Hi-Tronic kit: - main motor 15 kW (mode S6) - vertical movement of main and scoring blade by price ball-screws - optimized stroke of the main blade - electronic scorer adjustment in 2 axis (vertical, horizontal) - grooving with the main blade (electronic depth adjustment) - postforming cuts - window cut outs (blind cuts) - AKE flange for main and scoring blade Quantity of clamps (grippers): 10 pcs (maximum) Automatic exclusion of the clamp acting on the panels edge (up to 800 mm width). Start/stop pedal. Label printer. Control SW: WINCUT Optimalisation program: OTTIMO PERFECT CUT TOP (1x HW key) Control PC Eye-S: Windows + LCD touch screen 21" Air conditioning device for the electric box. Panel´s dimension automatic measuring. Laser line for the visualisation of the cutting line. Automatic double side aligner - motorized (60-2.200 mm). Machine stat: fully working Possibility to see in actuall production. Availability: cca April 2026

Condition: ready for operation (used), Year of construction: 2002, Giben rip saw Year of manufacture: 2002 New computer installed in 2024 Rits Gripper 7 pcs Transport dimensions: 4 packages 7.5 cubic meters approx. 5000 kg total Technical data Total saw length 665 cm Ihsdpfx Asx Huhiedwet Saw length 3700 mm Pusher 3300 mm Saw height 90 mm

Condition: excellent (used), works and looks impeccable, very well maintained without signs of wear on the table, electric lifting and tilting to 0-45, 5.5 kw motor + pre-cutter, year of manufacture 2009 Iedpjx Dx I Sjfx Adwjht

Condition: as good as new (ex-display), Year of construction: 2023, operating hours: 10 h, functionality: fully functional, input frequency: 50 Hz, input voltage: 400 V, power: 8.83 kW (12.01 HP), Equipment: scorer, Mayer panel saws impress with their consistently well-thought-out machine design and numerous detailed solutions that precisely meet every requirement. Each machine type is a testament to top-level performance. However, the more varied the requirements for the materials to be cut, the more important the small details become in determining the success of the entire process. With their heavy and robust saws, Mayer stands for long-lasting quality and high-grade engineering. The overall concept is also convincing: the heavy-duty design featuring a steel pressure beam and material pusher, user-friendly one-person operation, and maximum process reliability thanks to a modular cutting optimization program and new software packages all ensure peak performance and precision in efficient panel cutting. The modular cutting optimization program with barcode labeling guarantees the highest process reliability. The saw carriage, with main and scoring saw units, runs on a hardened and ground round-shaft guide system. Extremely smooth carriage travel at cutting speeds from 5 to 100 meters per minute is ensured by the high-precision gear and rack drive system. High-end cut edges are achieved by automatic cutting height adjustment for the optimal saw blade entry angle and exceptionally smooth carriage movement. The dual measurement system guarantees maximum repeat accuracy. The pressure beam opens in accordance with material height, minimizing material feed times. The "Greenline Package" includes controlled extraction shutters and direct motor control, reducing energy consumption by up to 30%. Optional equipment: 22 Electronic cutting height adjustment 25 Motorized scoring saw adjustment from the control panel 30 Air cushion table 2300 x 600 mm 42 Single-finger package clamp 41 Additional package clamp, position 493 mm 61 Thermal label printer 90 Network connection preparation Isdsx Anuropfx Adweht Further technical details: Scoring saw: 150 mm Extraction ports: 120 / 100 mm Feed speed: 5-100 m/min Saw blade protrusion: 77 mm Saw carriage and material pusher can execute cuts up to 3200 mm in length Return speed: 130 m/min Angle table: 2300 x 600 mm 2x material table: 1800 x 600 mm Includes delivery and installation within postal code areas 70, 71, 72, 73, 77, 78, 79, 86, 87, 88, 89.

Condition: excellent (used), Year of construction: 2007, Panel saw HOLZMA HPP250 320x320 cutting length 3200 mm cutting width 3200 mm Ihedpfxjxugdve Adwst 3 air tables power control year of manufacture 2007

Condition: used, Year of construction: 2023, Cutting area: 5600x5600 mm 1x Gabbiani G 3 130 (56) - High-performance panel saw 1x Compact label printer 1x "eye-M EVO" operating console 1x Human-machine interface software (HMI) MAESTRO ACTIVE 1x Maestro Pattern 1x High-performance fixed air cushion table with guide, 2500x600 mm, with infeed rollers 3x High-performance movable air cushion table - 2500x600 mm, with infeed rollers 1x Double lateral automatic aligner with motor drive 1x Foot switch for START/STOP of operating cycle 1x Grooving device with height-adjustable saw blade via control system 1x "Autosetting" device on the saw carriage for cut length/width 1x Main saw blade motor 25 HP (18 kW) 50 Hz with star-delta starter 1x Quick-clamping of saw blades with mechanical "AKE" flanges 1x Selective collet closure (area 0 - 1600 mm) 3x Additional double collets 4x Additional single-finger collets 1x Compact office label printer 1x Cut editor 1x Maestro Optiwise - Advanced - No. 1 license 1x Maestro Connect: service contract for 1 year (including "plug & play" gateway kit) 1x Base 1x MACHINE LANGUAGE: German Iodpoxlvktofx Adwoht 1x PC LANGUAGE: GERMAN 1x SPEC01 special version 01 1x European safety regulations (CE marking) Including 123 hours of on-site commissioning (within Germany) (daily working time is 8 hours including travel time). Includes 1 day online training for MAESTRO OPTIWISE PRO (as required) Includes 1 year MAESTRO CONNECT Includes MAESTRO PATTERN IMPORT (normally €255 - free of charge) Location:

Condition: refurbished (used), functionality: fully functional, Panel Dividing System PA 4115 – 3100 x 3100 DNC-AT Condition: Completely overhauled Warranty: 1-year warranty Technical Specifications: Left-angle stop according to AGA 4383 Longitudinal Saw FM 16-3100: - Hardened guides - Automatic forward and return travel of the saw unit - Return travel with automatic lowering - Feed speed: 2–50 m/min (stepless adjustment via potentiometer) - Return speed: 70 m/min (rapid traverse) - Integrated extraction channels in the machine base and pressure beam - Scoring saw adjustable from outside (without opening the safety hood) - Saw unit with controlled DC drive: - Precise positioning (e.g. for cutouts) - Slowed extraction from the cut - Includes safety hood locking, SZ 5008 lamella curtain - Offcut device SP 5004 – Offcuts down to at least 5 mm - Main saw motor: 7.0 kW - Scoring saw motor: 1.1 kW (can be switched off separately) - Cutting length: 3100 mm - Cutting height: 70 mm - Dust tested: Threshold of 2 mg/m³ is significantly undercut - CE compliant Angle Pressure Device WP 5003: - With pressure claw for cross cuts - Adjustment range up to 2400 mm - Semi-automatic function Iedpfxjxhg Ibs Adwsht Material Feed Table HP 5021 (mounted at rear of FM 16): - Parallel fence with 6 spring-loaded clamping fingers - Direct drive of material pusher via servo motor - Table surface with closed Pertinax panels (suitable for narrow strips) - Feed speed: 25 m/min (safety limited) - Return speed: 40 m/min - Table length: 3100 mm - Stop depth: 3100 mm Multi-microprocessor control Integrated PC with hard disk Operating system: LINUX Interfaces: serial + parallel, USB Network connectivity (also wireless LAN) Optimize cutting plans in the office and send directly to the machine Multitasking capable Printing function via USB Remote maintenance via Internet (Remote Desktop, TeamViewer) Multilingual dialog programming 15” flat screen + multifunctional keyboard Swiveling control panel Graphical representation of cutting plans and work processes Additional Equipment: Angle Stop Table HP 5043 (front mounted): - Machined steel angle, Pertinax table top - Table size: 1800 × 800 mm Workpiece Support Table HP 5025 (front mounted): - Pertinax surface - Table size: 1800 × 800 mm Air Cushion Device LK 5030 - Integrated into HP 5043 and HP 5025 Accessories: - 1 Circular saw blade KSB 4005 – Ø 305 mm, Z=60 (for main saw) - 1 Circular saw blade KSB 4006 – Ø 200 mm, Z=60 conical (for scoring saw)

Condition: used, Year of construction: 2009, functionality: fully functional, machine/vehicle number: 731, feed length X-axis: 3,800 mm, cutting length (max.): 3,800 mm, cutting height with scoring (max.): 100 mm, saw blade diameter: 380 mm, cutting height (max.): 100 mm, cutting width (max.): 3,800 mm, feed rate X-axis: 70 m/min, main saw diameter: 380 mm, total height: 1,650 mm, overall weight: 4,500 kg, travel distance X-axis: 3,800 mm, workpiece weight (max.): 80 kg, extraction nozzle diameter: 120 mm, input frequency: 50 Hz, input current: 35 A, input voltage: 400 V, compressed air connection: 6 bar, rotational speed (max.): 4,800 rpm, rotational speed (min.): 2,800 rpm, air pressure: 6 bar, saw blade bore: 80 mm, Equipment: scorer, The saw is regularly serviced and in perfect working order. It is in daily operation on a single shift. Sale due to transition to a newer production system. Still functional, it can be seen in operation until October 10, 2025. Also supplied with a set of saw blades and a pre-cutter. Option to purchase a vacuum board lifter, which can be seen in the video. Isdpoxf Im Tsfx Adwoht

Condition: excellent (used), Pressure beam panel saw FIMAL CONCEPT 350 - used - Tiltable up to 46°, Ihedexdl N Aspfx Adwjt extendable angle stop up to 2,500 mm, digital display on the angle stop, mitre stop +/- 50°, automatic cutting length detection, stepless feed of the saw carriage, touchscreen, cutting line laser ----- Technical Data ----- Cutting length: 3,200 mm, Cutting width: 1,300 mm, Max. cutting height: 100 mm, Saw unit feed rate max.: 0 - 40 m/min., Main saw motor output: 5 kW, Main saw blade Ø: 350 mm, Dust extraction port (bottom) Ø: 120 mm, Dust extraction port (pressure beam) Ø: 100 mm, Compressed air connection: 7 bar Quality Info: - complete basic inspection - complete basic cleaning - electrics checked - immediately operational

Condition: excellent (used), Year of construction: 2012, Panel saw SCM Sigma Impact with rear loading system. Machine dismantled. Ihjdpfx Asw Rdkasdwot

Condition: as good as new (ex-display), Year of construction: 2023, functionality: fully functional, cutting length (max.): 3,200 mm, saw blade diameter: 350 mm, cutting height (max.): 105 mm, cutting width (max.): 1,300 mm, total length: 4,300 mm, overall weight: 1,300 kg, input frequency: 50 Hz, input voltage: 400 V, power: 7.35 kW (9.99 HP), rotational speed (max.): 4,000 rpm, pivoting range: 45 °, The Concept 350 combines the advantages of various saw systems: As flexible as a panel saw, the cutting quality of a pressure beam saw, and as ergonomic as a trimming saw. This is the sawing concept for modern industrial production. The machine is a leasing return. Further technical data: - Motorized rip fence with 4 aluminum stops, which move synchronously - Screen control with 8" touchscreen - Air requirement: 6 bar - Sliding table: 1,000 x 400 mm (extension table) - Outrigger table size: 3,200 mm with 2 digital stop jaws - Extraction connection: 1 x 100 mm, 1 x 120 mm - Feed speed: 0 - 40 m/min Special features: - Programmable saw blade height adjustment - Mitre fence +/- 50° - Cutting line laser - Additional support table 800 x 200 mm Ihsdpfx Ajwzuipjdwot With the new Concept 350, you no longer need a panel saw! The workpiece rests on the machine and is positioned precisely with a pressure beam. The saw unit can be swiveled from 90° to 45°, is guided with precision, and cuts your workpiece at a constant feed speed of 0–40 m/min, ensuring the best possible cutting results. The standard crosscut fence enables quick cutting to length and efficient operation, with significantly less space required compared to any sliding table saw! Advantages over a sliding table panel saw: - Significantly less space required - The pressure beam secures the workpiece on the machine and guarantees optimal cutting results - The pressure beam prevents the operator from reaching into the saw blade - Ergonomic operation, as the operator no longer has to push the material through the saw blade - Time saving, as the operator does not need to guide the material during the sawing process Including delivery and installation within postal code areas 71, 72, 73, 77, 78, 79, 86, 87, 88, 89.

Condition: used, Year of construction: 2011, WINCUT Numerical Control Working dimensions mm 3800 x 3800 Max blade projection (mm) 107 Front panel loading N. 10 pincers on the pusher carriage Lateral aligner Scoring group (max blade diameter / power) 160 / Kw 1,5 Main blade unit (max blade diameter / power) 380 / Kw 7.5 Adjustable speed of the blade carriage (m/min) 1 - 135 Pusher carriage speed 70 m/min N. 3 air curtain front benches TECHNICAL DETAILS TO CHECK WHEN THE MACHINE WILL BE IN OUR WAREHOUSES Ihodpowwrywefx Adwet

Condition: new, Year of construction: 2025, functionality: fully functional, cutting length (max.): 3,300 mm, saw blade diameter: 315 mm, cutting height (max.): 82 mm, feed rate X-axis: 100 m/min, feed rate Z-axis: 150 m/min, total length: 3,300 mm, total width: 3,350 mm, overall weight: 3,000 kg, saw drive: 9,000 W, power: 9 kW (12.24 HP), rotational speed (max.): 4,400 rpm, saw blade speed: 4,400 rpm, Equipment: rotational speed infinitely variable, SCHEER PA 4500 – 3300 x 3350 S7WIN10 Year of manufacture: 2025 | Condition: NEW | Control: PA-WIN10 + SIMATIC S7 | Powerful panel dividing system for highest precision & efficiency The SCHEER PA 4500 is a robust, industrially proven panel dividing saw for the precise processing of coated and uncoated wood-based panels. It was designed for demanding applications and already meets all the requirements of modern cutting operations in its basic configuration. Main technical data: Cutting length (max.): 3300 mm Cutting height (stepless): up to 82 mm Main saw blade: Ø 315 mm | 60 teeth | cutting width 3.2 mm Scoring saw blade: Ø 200 mm | conical | cutting width 3.2–4.0 mm Saw motor: 9.0 kW Scoring motor: 1.1 kW Saw carriage drive: 2.32 kW Main saw blade speed: approx. 4400 rpm Saw carriage feed: 0–100 m/min (stepless adjustable) Saw carriage return: 150 m/min (lowered) Electrical connection: 400V / 50Hz / 3Ph Pneumatics: 6 bar, 15 NL/stroke Extraction: 3 x 140 mm | Capacity: 3300 m³/h at 20 m/s Working height: approx. 930 mm Angle stop: left Machine concept & highlights: Heavy cast honeycomb construction for vibration damping Absolute value encoder for highest positioning accuracy (no referencing) Distance- and time-optimized saw carriage operation Ihjdswrpcxepfx Adwjt Automatic oil mist lubrication & blowing of the guides Program-controlled saw blade adjustment (height & scoring side) ProLock quick-release system for the saw blade “wood dust tested” – emission only 0.65 mg/m³ System equipment: 1x angle pressing device WP 8500-1400 Adjustment range: 0–2200 mm Pressing force: approx. 480 N Cycle-controlled retraction function for panel transport 1x material feed table HP 5130 – 33 x 33 Mounted at the back with hardened guides & racks Roller conveyor system for easy panel transport 6 clamping fingers (spacing: 70 / 262 / 454 / 838 / 1173 / 2630 mm) Servo drive with ±0.1 mm accuracy 1x angle stop table HP 5137-1-1465 1x workpiece support table HP 5135-1-1465 Pertinax coating, each 1465 x 800 mm 1x air cushion unit LK 5169 central radial fan, pressure max. 2800 N/m² 1x control cabinet dustproof, separately mounted, vibration protected 19" TFT flat screen, keyboard, trackball Control & software: SIMATIC WinLC RTX soft PLC with S7 functionality PA-WIN10 operating interface on Windows 10 Professional (64 bit) (update to the latest Windows version possible at any time) True-to-scale real-time simulation and graphical cutting plan editor Integrated interfaces (label printing, panel warehouse management, etc.) Network-capable, future-proof, modularly expandable Operating modes & operation: Manual operation: single, chain dimension, trimming, residual cutting Automatic operation: cutting plan processing, online order processing Editor: parts list-based planning & optimization Maintenance & diagnosis: saw blade measurement, individual control, and more 📞 Contact us for an individual offer or a viewing. Delivery, installation, commissioning, and training possible as options.

Condition: like new (used), functionality: fully functional, cutting length (max.): 3,100 mm, cutting height with scoring (max.): 70 mm, saw blade diameter: 305 mm, feed rate X-axis: 40 m/min, feed rate Z-axis: 50 m/min, total length: 3,100 mm, total width: 3,100 mm, overall weight: 3,000 kg, power: 7 kW (9.52 HP), space requirement length: 3,100 mm, space requirement width: 3,100 mm, Equipment: rotational speed infinitely variable, scorer, Panel Sizing System SCHEER PA 4136 – 3100 x 3100 The PA 4136 is a high-performance, electronically controlled panel saw designed for precise, efficient, and automated cutting of wood-based materials. Ideally suited for industrial applications in joineries, furniture production, and panel processing. Condition & Service: Condition: Very good Functionality: Fully operational Warranty: 12 months CE-compliant and dust-tested (limit value < 2 mg/m³) Key Technical Data & Equipment: - Rip saw FM 20-3100 with hardened guides - Automatic forward & return travel of the saw unit (automatic lowering during return) - Feed drive via three-phase gear motor, frequency inverter controlled - Feed speed: 2 – 40 m/min (stepless) - Return speed (rapid traverse): 50 m/min - Extraction channels in machine base & pressure beam - Score saw blade adjustable externally (without opening the hood) - Safety hood locking with lamella curtain SZ 5008 - 3-step cutting height adjustment LA 4143 - 6 cut-out sections in the pressure beam for residual cuts down to 5 mm - Saw motor: 7.0 kW | Scoring motor: 1.1 kW (switchable) - Cutting length: 3100 mm | Cutting height: 70 mm Material Handling & Feed: - Angle pressure device WP 5003 with clamping claw for cross cuts - Adjustment range: 2400 mm - Fully automatic control via DNC-AT - Material feed table HP 5091 - 2 upper guides, rack-and-pinion guidance - Servo drive for material pusher - Feed speed: 25 m/min (safety limited) - Return: 40 m/min - 6 clamping fingers, 4 double roller tracks - Table length: 3100 mm | Fence depth: 3150 mm - Closed Pertinax surface in the area of the angle fence Ijdowrn Efjpfx Adwjht Control & Operation: - Operating system: Ubuntu Linux - Integrated PC with hard disk, parallel & serial interfaces - Network capable (LAN/WLAN), remote maintenance via internet (TeamViewer, Remote Desktop) - USB printing function - Multilingual dialog programming - 15" flat screen, multifunction keyboard on a swiveling control console - Graphic display of cutting plans and processes Software / Programs: - OPTIMAX: Office optimization, waste calculation, material requirements - OPTIMIN: Direct optimization at the machine PC with parts list entry - Processing via USB, diskette or online (optional) - Manual, automatic & special operation modes (e.g. grooving, veneered parts) Additional Equipment: - Angle fence table HP 5085: 1,720 x 800 mm | Pertinax overlay - Workpiece support table HP 5025: 1,720 x 800 mm | Pertinax overlay - Air cushion system LK 5030 integrated in both tables - Circular saw blade KSB 4005: Ø 305 mm, Z = 60 - Circular saw blade KSB 4006: Ø 200 mm, Z = 60, tapered Reliability in Continuous Operation: This machine is in use worldwide – under extreme conditions. Whether in the dry climate of Africa or in high humidity regions of Southeast Asia (e.g. Thailand): The PA 4136 runs reliably in 3-shift operations – 365 days a year – and stands out for its outstanding stability and durability. Warranty: We are so convinced of the quality and stability of our machines that we offer a 7-year warranty on the machine frame and guideways. (Excludes electronic supply parts and wear parts.) 📞 Contact us for an individual offer or to arrange a viewing appointment. Machine available from stock. Delivery, commissioning, and training available upon request.

Condition: excellent (used), Year of construction: 1994, - Cutting length: 3200mm - Diameter: 76mm - Main motor: 7.5kW Ihjdpfx Adewq Sl Tewet - Scoring unit: 1.5kW

Condition: new, Year of construction: 2025, functionality: fully functional, Offer: SCHEER PA 8504 FLAGSHIP Panel Saw We are offering a state-of-the-art PA 8504 panel saw for sale. The machine has a table length of 4200 mm, a stop depth of 4650 mm, and a cutting length of 3100 mm. Machine specifications: - Maximum cutting height: 105 mm, with continuously variable cutting height adjustment - Automatic saw unit, continuously adjustable feed speed (2-100 m/min), return speed 130 m/min - Automated scoring saw adjustable via keyboard - Fully automatic angle clamping device - Two air cushion tables for optimal material processing - Slider with parallel stop and 6 adjustable clamping fingers for precise support - Integrated cross alignment unit and four-spindle lifting table (3100 x 2200 mm), loadable from both sides *The machine can be customized to your requirements, as we specialize in custom machine construction. Technical Features: Ihedpfx Ajwlnqusdwet - Powerful 11.0 kW saw motor, 2.2 kW scoring motor - Residual cut device for efficient work - Siemens PLC for control, with guard lock and integrated extraction ducts - Complies with CE guidelines Operating Ease: - 19" flat screen in the pivoting control panel - Modern Windows 10 operating system with graphical display of cutting plans - Wireless network capability (compatible with Windows, Linux, Mac, and Novell networks), remote maintenance and regular updates possible - Optional: Cutting plan optimization in the office (ARDIS) and label printing during sawing This machine offers you the most precise processing, maximum flexibility, and modern operating comfort. For further information and to arrange a viewing appointment, please contact us directly!
