Milling Machining Centers 5 Axis

AXON LITZ LU 620 / iTNC 640

Condition: used, Year of construction: 2021, operating hours: 3,372 h, travel distance X-axis: 730 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 470 mm, workpiece weight (max.): 200 kg, total height: 2,933 mm, total length: 2,984 mm, total width: 2,300 mm, overall weight: 6,780 kg, spindle speed (max.): 18,000 rpm, operating hours of spindle: 1,114 h, Equipment: documentation/manual, CNC 5-Axis Vertical Machining Centre CNC Control Mazatrol Smooth X Table size Ø 500 mm Table load 200 kg Number of pallets 1x Max. Workpiece 500x320 mm Movement X-axis 730 mm Kljdozf Hyrepfx Aafsw Movement Y-axis 450 mm Movement Z-axis 470 mm C-Axis (table rotation) 360° B-Axis travel ±110 (220) ° Spindle speed 18.000 R/min Spindle Taper HSK A-63 Spindle motor 15/11 kW Magazin capacity 48 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Year of construction: 1998, condition: good (used), Make: UNION Type: Ti 1800 Year: 1998 Specifications Metric US Standard Table Length 2000 mm Table Width 1800 mm Table load 16000 Movement V-axis 1250 mm Rotation B-Axis 360.000 ° Rotation speed B-Axis 1,35 Omw/min. Movement speed V-axis 4000 mm/min. Dimensions (Estimate) Length 3400 mm Ksdpfjkwcdbox Aafolw Width 2000 mm Height 920 mm Weight 6500 kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 2022, controller manufacturer: Sonstige, controller model: Brother C00, _____ Description: Year of manuf. : 2022 Control : Sonstige Brother C00 Speed : 10000 rpm Movement X/Y/Z : 700/400/300 mm Tool holder : BBT 30 Mainspindle: Technology:Directdrive Speed:10.000 rpm Power (max.):26,2 kW Torque (max.):92 Nm Taper:BBT 30 Workingtable: Clampingsurface:800 x 400 mm Tableloading (max.):250 kg In general: Toolmagazine:21 Stations Rapid travers in X/Y/Z:50/50/56 m/min Equipment/Accessory: Chipmanagement:Chip coveyor Coolingmanagement:Minimumlubrication (IKZ), Company Lubrix V5 4.-Axis:Lehmann EA-510 with Counterbearing Workpiececlamping:Hydrulic, 80-210 bar Contactcontrol:Pneumatic Klsdeylrn Ajpfx Aafew Automationinterface I:Automatic Door (electrical) Automationinterface I:Robotinterface Oilmistseparation:Mechanical extraction, company Sara UC1 SD Columnextention:150 mm Setup operations:Electronic Handwheel Further Equipment:Trafo

Condition: new, travel distance X-axis: 850 mm, travel distance Y-axis: 820 mm, travel distance Z-axis: 610 mm, workpiece height (max.): 450 mm, workpiece weight (max.): 500 kg, number of slots in tool magazine: 60, controller manufacturer: HEIDENHAIN, overall weight: 14,000 kg, controller model: TNC 7, coolant supply: 40 bar, spindle motor power: 32 W, rapid traverse Z-axis: 48,000 m/min, rapid traverse X-axis: 48,000 m/min, rapid traverse Y-axis: 48,000 m/min, rotary table diameter: 630 mm, rotational speed (max.): 12,000 rpm, spindle nose: SK 40 BIG PLUS (BVD 40), tool diameter: 150 mm, tool length: 300 mm, tool weight: 8 g, workpiece diameter (max.): 750 mm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, LAGUN EVZ 630 – 5-Axis Simultaneous Machining Center The new LAGUN EVZ 630 is a 5-axis simultaneous machining center designed for maximum precision and dynamic performance in modern machining. This machine impresses with its robust design, high thermal stability, and state-of-the-art HEIDENHAIN control and drive technology. It is ideal for tool and mold making, mechanical engineering, and demanding contract manufacturing. Your advantages at a glance: ✔ Installation & commissioning in Germany included ✔ Service & spare parts directly from JMT ✔ Financing / lease purchase possible ✔ Compact design with high stability ✔ 24 months warranty Why LAGUN: LAGUN is one of the leading machine tool manufacturers in Spain (MAHER HOLDING) and stands for robust construction, high dynamic performance, and durable machine concepts. The machining centers are characterized by reliability, easy maintenance, and low operating costs. Technical equipment: Control: HEIDENHAIN TNC 7 CNC control HEIDENHAIN TFT screen 21" HEIDENHAIN motors, scales, and electronic handwheel HR 510 Chip disposal: Chip conveyor Enclosure: Full enclosure with automatic door opening for convenient and ergonomic access to the work area Accuracy: Positioning accuracy: ± 0.005 mm Repeatability: ± 0.003 mm Your advantages as a JMT customer: Kodpfx Aaop Nnutefelw ✔ Official LAGUN sales partner in Germany ✔ On-site technical support and service ✔ Fast spare parts supply ✔ Training and instruction included Contact us – we will be happy to advise you and create a customized offer.

Condition: good (used), Year of construction: 2006, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, Travel paths Longitudinal (X): 2500 mm Vertical (Y): 1250 mm Transverse (Z): 1000 mm Table size (rotary): Length: 1000 mm Width: 1000 mm Max. table load: 5000 kg T-slots: 6 x 22 mm H10 Drive power: 100% duty cycle, 24 kW Tool holder: ISO 50, DIN 69871 - AD Spindle speeds: 20 – 4000 rpm Torque: 479 Nm Feed rates (X, Y, Z): 10 – 10,000 mm/min Rapid traverse (X, Y, Z): 25,000 mm/min Weight: approx. 15,000 kg Equipment: - Internal coolant supply according to DIN 69871 Form AD, including minimum quantity oil lubrication with 15 different dosing levels via programmable M-functions; 20 bar - NC rotary table, size 1000 x 1000 mm, integrated as 4th axis into the CNC control. Max. load capacity 5000 kg, positioning accuracy ±5", table surface with 22 mm T-slots. - Chip conveyor for TA-D 25 - Tool changer Accessories - Front-mounted movable control pendant including Heidenhain iTNC 530 control (1 processor) - Portable electronic handwheel HR 420 with 3 m spiral cable (option) - 3D thermal expansion compensation - Automatically indexing milling head / 2 planes with 2.5° indexing (H200) (option) - Distance spindle nose to table edge: 250 mm - NC rotary table, size 1000 x 1000 mm, integrated as 4th axis into the machine control. Max. load capacity 5000 kg, positioning accuracy ±5", table surface with 22 mm T-slots - Coolant system with 150 l tank capacity, delivery pressure 5 bar, delivery rate 50 l/min, discharge via shower ring around spindle - Splash guard enclosure, fully enclosed on 4 sides with front sliding doors and an additional sliding door on the left side column and viewing windows on all 4 sides - Heidenhain drive motors on all axes with digital drive technology - INA linear roller guide system on all axes - Direct linear measuring system Heidenhain on all axes Kodpfx Asykbxzeafjlw - Telescopic covers for X-axis guideways - Ball screws on X, Y, and Z axes - Automatic cycle lubrication for all axes and moving components - Electrical equipment by Siemens - Hydraulic system by Vickers

Condition: used, Year of construction: 2000, Year of manufacture: 2000 Control: Mazatrol 640 Documents included Chip conveyor TECHNICAL DATA – MAZAK INTEGREX 200SY Performance / Capacity Max. swing: Ø 540 mm Chuck size: 8" Max. machining diameter: Ø 540 mm Max. machining length: 1018 mm Max. outside diameter for bar material: Ø 51 mm Main spindle Spindle nose: JIS A2-6" Spindle bore diameter: Ø 61 mm Spindle speed: 35 – 5000 rpm (Standard) / 35 – 4500 rpm (Option: 5000)* Motor power (30 min. rating): 22 kW (18.5 kW*) Max. torque: 350 Nm (35.7 kgf·m) Sub spindle (counter spindle) Spindle nose: JIS A2-6" Kedpfxsyh E Irj Aafolw Spindle bore diameter: Ø 44 mm Spindle speed: 35 – 5000 rpm Motor power (10 min. rating): 7.5 kW Max. torque: 57 Nm (5.8 kgf·m) Turret / Tool data Turret type: With ATC, spindle turret External turning tool size: □ 25 mm Internal turning tool size: Ø 40 mm Milling tool: Max. Ø120 × 250 mm length Indexing time (90°): 0.5 s Milling spindle speed: 15 – 6000 rpm (Option: 10000) Milling spindle motor power: 7.5 kW Max. milling spindle torque: 62.29 Nm (6.35 kgf·m) Feed axes X-axis: Travel 530 mm / Rapid traverse 30,000 mm/min Z-axis: Travel 1065 mm / Rapid traverse 33,000 mm/min Y-axis: Travel 140 mm / Rapid traverse 15,000 mm/min Z2-axis: Travel 1005 mm / Rapid traverse 20,000 mm/min Media / Control Coolant tank volume: 250 L Power consumption (continuous): 32.7 kVA Machine dimensions / Weight Overall length: 3485 mm Overall width: 2105 mm Overall height: 2416 mm Weight: 73,575 N (7,500 kgf)

Condition: excellent (used), Year of construction: 2013, Travel: X-800 mm, Y-600 mm, Z-500 mm Kedpfsyxh Hpox Aafjlw Control: Heidenhain iTNC530 Spindle speed: 15.000 U/min tool magazine: 30 seats probe: Heidenhain electric handwheel: Heidenhain table size: 1000 mm x 560 mm Spänewanne: .

Condition: like new (used), functionality: fully functional, workpiece weight (max.): 3 kg, feed length X-axis: 100 mm, feed length Y-axis: 100 mm, feed length Z-axis: 200 mm, workpiece diameter (max.): 180 mm, milling length: 200 mm, overall weight: 5,000 kg, rotational speed (max.): 3,000 rpm, rotational speed (min.): 400 rpm, tool diameter: 80 mm, Equipment: documentation/manual, rotational speed infinitely variable, This machine is completely dismantled and rebuilt from the ground up. During the overhaul, it undergoes comprehensive modernization with state-of-the-art technology and the latest premium-quality components. Following refurbishment, the machine is presented in a technical and visual condition equivalent to new – reliable, high-performance, and future-proof. The equipment and configuration can be tailored individually to your requirements, ensuring maximum productivity in your production environment. Kjdpfx Asx Af A Heafolw

Condition: good (used), CHIRON FZ 08 KS Magnum is a 5‑axis machining center engineered for precision, high accuracy and reliable production. Travels X450×Y270×Z310 mm; drilling 12 mm; tapping M8. Tool magazine 24 pos., tool Ø max 47 mm (100 mm free), length 160 mm, tool wt 1.2 kg. Spindle HSK‑A40 0–36000 rpm; spindle motor 7 kW; rapid 75 m/min; 3×400V 50Hz; air 6 bar; installed power 14 kW (19 kVA); machine ≈3400 kg; dims 2308×1405×2447 mm. Features: tool‑break control, RS232, switch‑cabinet air‑con, status light. Delivers tight tolerances for automotive, aerospace, medical, watchmaking. Ksdpfx Aaeyxn Hcjfelw

Condition: excellent (used), workpiece diameter 10 - 250 mm threading length 900 mm thread pitch 0,3 - 100 mm Klodpfjyb S Riox Aafsw spindle turning speed range 72 / 1700 - 2540 U/min relief of the tap 0,03 - 8 mm clamping length max. 1190 mm max. module 10 workpiece turning speeds 0,4 - 160 U/min total power requirement 13 kW weight of the machine ca. 7,4 t dimensions of the machine ca. 4,5 x 2,0 x 2,1 m Many accessories.
