Bystronic Xpress 80/2100 Hydraulic Press Brake

Bystronic Xpress 80/2100

Condition: new, - Capacity: 700 x 2 mm - Conical rollers - Removable top roller - Foot control Rcodpeihv Hpsfx Afhjd - Emergency stop - Documentation - 400V

Condition: used, Year of construction: 2013, Punching capacity 220 kN laser capacity in Watt 4000 travel -x axis 2500 mm travel -y axis 1250 mm Cutting capacity structural steel 8 mm Cutting capacity stainless steel 8 mm Cutting capacity aluminum 6 mm workpiece weight 280 kg weight of the machine ca. 24.000 kg dimensions 10130 x 8898 x 2328 mm Includes DORNER 2200 Series conveyor belt Operating hours: - Approx. 7,880 h Standard equipment: - Travelling ball-bearing tables - Linear magazine for tool stations and clamping jaws - 22 tool stations, 3 clamping jaws - Foot switch for closing the jaws - Flap for stamped parts 500 x 500 mm incl. sensor - Chip container - 2 good parts containers (stamping and laser side) - Initial fill of hydraulic oil - FocusLine - NitroLine - FastLine - Additional Xp and Yp axes - Ejection cylinder for laser parts - High-speed flap for laser parts 500 x 500 mm incl. sensor - Liftable laser cutting table - Liftable laser cutting table - Slag cone detection TRUMPF Laser: - CO2 laser TruFlow 2700 incl. LensLine and optimized StandBy - Maintenance-free turbo radial blower - High-frequency excitation - TASC laser control Cutting head: - Lens cutting head with 170 mm lens - Universal quick-change device (UTI) with bus connection - ControlLine Punching head: - Electro-hydraulic punching head - Hydraulic single-tool holder with 360° rotation - Programmable hold-down device (active/passive/re-adjustment) - Tool length compensation - Spray lubrication for punch - Punching scrap extraction - Level monitoring for thread forming and tool lubrication Control system: - Open control system based on Rexroth IndraMotion MTX - 15" TFT color screen - Teleservice via the Internet - Automatic shutdown - Production plan Data transfer - USB interface - RJ45 network connection Safety: - CE marking - Dual-beam safety light curtains - Emergency stop Tools: Redpfsy D T S Usx Afhscd 2x 10-function multitool 1x 5-function multitool 1x 5-function EeasyType multitool 5x thread forming tools 1x Multishear 1x calibration tool 1x ball deburrer 2x gills M3–M8 threading dies Centering studs (top and bottom) Countersinking tools for 1.5 and 2 mm Various countersink and form countersink tools

Condition: excellent (used), functionality: fully functional, Year of construction: 2012, operating hours: 55,771 h, laser hours: 35,157 h, laser power: 3,200 W, sheet thickness (max.): 20 mm, sheet thickness steel (max.): 20 mm, sheet thickness aluminum (max.): 8 mm, table length: 3,000 mm, table width: 1,500 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 150 mm, positioning speed: 140 m/min, positioning accuracy: 0.02 mm, year of last overhaul: 2024, feed length X-axis: 3,000 mm, feed length Y-axis: 1,500 mm, feed length Z-axis: 150 mm, Equipment: cooling unit, documentation/manual, safety light barrier, The laser is in operation, can be inspected and tested. Regularly serviced in good technical condition. Mirrors completely replaced in 2024. Rcjdpfsv Hxbbex Afhed

Condition: excellent (used), Year of construction: 2021, machine/vehicle number: 7771, functionality: fully functional, pressing force: 100 t, stroke length: 300 mm, operating speed: 75 mm/s, reverse speed: 75 mm/s, table height: 900 mm, throat depth: 1,000 mm, total width: 3,100 mm, overall weight: 8,900 kg, travel distance X-axis: 1,000 mm, controller model: EC20 - graficzne 2D, working width: 3,000 mm, bending force (max.): 100 t, back gauge: 1,000 mm, back gauge speed R-axis: 250 mm/s, back gauge travel distance R-axis: 200 mm, back gauge travel distance Z-axis: 1,000 mm, distance between stands: 3,000 mm, control type: CNC control, degree of automation: semi-automatic, back gauge adjustment: CNC-controlled, number of axes: 4, actuation type: electric, Equipment: CE marking, emergency stop, european tool clamping system, safety light barrier, Servo-electric press brake SAFANDARLEY type E-Brake 100-3100 NS (100T - 3060 mm) AMADA tooling system Manufacturer: Netherlands - Lochem Rcedpfx Afoylt Ukjhod We are the official representative of SafanDarley in Poland. - Servo-electric drive - Press force: 100 T - Bending length: 3060 mm - Stroke: 300 mm - CNC control in axes Y1 / Y2 / X / R / Z1 / Z2 - CNC-controlled backgauge with 4 axes - X / R / Z1 / Z2 - 2D graphical control - EC20 model - Programmable light curtain - AMADA tooling system - WILA tooling system - lower clamp compatible with 4V / 2V / 1V / T-type dies, 60 mm base - Lower table crowning compensation

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, Pannellatrice Trumpf modello 7030 anno costruzione 2016 installazione maggio 2017, macchina completa di tutti gli optional compreso angolo di piega laser ACB sistema di programmazione Tec Zone, disponibilità immediata Rsdpfx Aeyw Uggefhocd

Condition: new, Comparable to Durma, Baykal, Ermaksan, etc. Bending length: 3,020 mm Pressing force: 135 t Approach speed: 140 mm/s Bending speed max.: 10 mm/s Rsdoq Rdtqjpfx Afhocd Return speed: 130 mm/s Stroke: 320 mm Installation height: 550 mm Throat depth: 450 mm X-axis travel: 750 mm X-axis speed: 300 mm/sec R-axis travel: 250 mm R-axis speed: 100 mm/sec Clear distance between frames: 2,555 mm Machine length: 3,730 mm Machine width: 2,300 mm Total height: 2,850 mm Table height: 900 mm Motor power: 15 kW Oil tank: 190 l Machine weight: 9,500 kg (Technical data may vary depending on equipment) Standard features: - 3 CNC axes (Y1, Y2, X) - Double-guided, stable, and precise ram - Robust, double-guided backgauge - Manually adjustable, double-guided stop fingers on linear guides - Adjustable front support arms with height adjustment - Lateral and rear safety covers - Lower die adapter rail, 60 mm - Manual upper tool clamping system (Promecam system) - Manual crowning - Foot switch with emergency stop - 380 V, 50-60 Hz, 3-phase - LED lighting Recommended options: - Dener DA 66T control - Fiessler AKAS 2M laser finger protection - FPSC Safety PLC (manual) - X and R axes with servomotors - CNC crowning for high bending accuracy - 2 additional stop fingers - Other working lengths and thicknesses available with suitable accessories! -

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, operating hours: 417 h, Amada HFE M2 5012 press brake (2021) Manufacturer: Amada Type: HFE M2 5012 press brake Rjdpfx Afoy Twk Hshscd Condition: used, in production and operational Year of manufacture: 10/2020 Operating hours: 6830 hours Working hours: 417 hours (still in use) Pressing force (kN): 500 Press beam length (mm): 1270 Distance between machine uprights (mm): 1035 Stroke (mm): 150 Opening width without punch holder (mm): 480 Overhang (mm): 100 Working height (mm): 920 Working speed (mm/sec): 15 Approach speed (mm/sec): 185 Opening speed (mm/sec): 185 Dimensions: Length (mm): 2585 Width (mm): 2190 Height (mm): 2420 Weight (kg): 3600 Video available.

Condition: like new (used), functionality: fully functional, Year of construction: 2024, For sale: CNC bending machine CIDAN FX32 PLUS with a pivoting beam, featuring both fixed and segmented tooling. The Plus model, with its adjustable bending center, maintains a consistent distance to the radius rail throughout the entire bending process. The result is a perfect radius, without causing material stress, regardless of thickness, ensuring a flawless finish and virtually unmatched accuracy in angles and measurements. Technical specifications: Year of manufacture: 2024 Rcodpfx Afozc Hviehed Control: CNC with nuLink Mechanical bending compensation adjustment (Crowning system) Working length: 3200 mm Max. bending thickness: 2 mm Bending beam tooling: 7/10 and 20 mm Automatic back gauge – flexible 1550 mm CNC control with nuLink graphical user interface (intuitive, easy programming) Quick-change segmented tooling High accuracy and repeatability Application: These machines are designed for bending, forming, and profiling sheet metal. They are ideally suited for the production of ventilation systems, facades, sheet metal structures, metal doors, chimneys, and roofing systems. The robust frame and precise CNC control enable extremely high production accuracy. If you have any further questions, we will be happy to answer them.

Condition: new, functionality: fully functional, Year of construction: 2026, laser power: 12,000 W, Description BAISON V52U(12+12 meters): (12 or 20 kW) FOUR-CHUCKS HEAVY-DUTY TUBE FIBER LASER CUTTING MACHINE WITH AUTOMATIC LOADING AND UNLOADING SYSTEM 12 meters automatic loading system + 12 meters automatic unloading system (can be equipped in different configurations ex:12+6 meters) This machine is also for profile, tub and different shape. Tube size range: Round tube: φ50-φ500mm Square tube: □50*50-□500*500mm Channel Steel: 5#-50# Angle Iron: 200*200mm I-beam:10#-50# H-beam:100*100mm-500*500mm Laser Power 12.000 W (Raycus) Max. Single Tube Weight 2.000 kg Claw Stroke Full stroke Min. Tail Length 0 mm Max. chuck speed 40 r/min Max Speed 50 m/min Max Acceleration 0.4 G Max. Tube Cutting Length 12.000 mm Ultra-short Tail Material 0 mm X-axis 500 mm Y-axis 12.000 mm Z-axis 500 mm Positioning Accuracy (X/Y) ±0.05 mm/m Repeated Positioning Accuracy (X/Y) ±0.05 mm Power Data 130kw / 225A Power supply 380V/50Hz/3Phases Power Protection Level IP54 Machine Size 29.080*5.000*3.250 mm Machine Weight 28.165 kg(Including Semi-automatic loading system and automatic unloading system) Configuration: ACCESSORIES INCLUDED IN THE OFFER Laser source RAYCUS 12 kW Laser head with automatic focus – RAYTOOLS BS12K-3D Controller system – FSCUT 5000A Automatic self-centering pneumatic chucks Semi-automatic loading system with chain Servo motors – VEICHI Reducer – TECHMECH High precision X/Y transmission mode with rack and rails – K.H Guide rail – SHAC Industrial cooling/heating system of the laser head and laser source - Dual cooling system – HANLI Proportional valve – AVENTICS Welded and heat-treated machine bed – BAISON Wireless remote controller Computer with Windows 11 interface, Internet & WIFI Centralized automatic lubrication system Exhaust smoke system with centrifugal fan Operation, maintenance and programming manuals Voltage stabilizer & regulator unit Complete CE standard Rodpfevcbw Djx Afhjcd - Machines for cutting tubes and profiles - Fiber laser is the green laser technology for the future - (Saving of at least 50% energy costs) - Components / therefore very low-maintenance - Save up to 50% per part through more efficient production - In addition, precise cuts and smooth surface quality - Heavy-duty constructed frame - equipped with world-famous, durable, high-quality components - Optional: Light barrier safety protection - Complete CE standard Price is EXW (Stock Europe), Include loaded on truck. Transport, installation, commissioning, training, and yearly service contracts are available upon request for an additional fee. Installation and training is always done by our high qualified Service team in 3 locations in Europe. Netherlands, Germany, Romania. Official Seller CNC Top Ten bv Coevorden, Netherlands

Condition: new, Year of construction: 2026, functionality: fully functional, working height: 2,200 mm, BUMEX Sp. z o.o. offers a professional industrial washing system designed for the preparation of components prior to the powder coating process. The equipment has been engineered for demanding industrial environments where washing efficiency, process stability, and long-term durability are essential. The washing system enables effective preparation of steel and aluminum components through a multi-stage cleaning, degreasing and rinsing process. Technical parameters Working chamber dimensions: 1500 × 3200 × 2200 mm Process technology: 3-stage washing process Process tanks The unit is equipped with three process tanks: tank for cleaning / degreasing chemicals tank for rinsing water tank for demineralized water (DEMI water) Tank capacity: 1500 – 2000 liters DEMI water generator The system is equipped with a demineralized water generator, ensuring high-quality final rinsing and optimal surface preparation before powder coating. Heating system The chemical tank is equipped with a heating system for the process liquid. Available heating options: oil heating gas heating electric heating Maximum operating temperature: up to 60°C Machine construction The machine is manufactured entirely from high-quality stainless steel AISI 1.4301, which provides: excellent chemical resistance long service life easy maintenance and cleaning Rcedpfx Aohfv D Ssfhod The washer features: very robust industrial construction full thermal insulation of the entire machine to reduce energy losses spray system designed for minimal mixing of process liquids pre-filter for collecting contaminants high washing efficiency Control system The machine is equipped with a fully automatic control system, enabling precise control of: process temperature pump operation washing time sequence of process stages Why choose BUMEX? Our equipment stands out on the market due to: very high manufacturing quality robust industrial construction operational safety complete technical documentation possibility of adapting the equipment to the existing production facility All machines manufactured by BUMEX Sp. z o.o. are CE certified. Additional technological support BUMEX also provides: powder coating booths dust extraction and filtration systems industrial ventilation systems professional technological consulting Cooperation conditions company transport available (price determined individually) VAT invoices issued short production lead times possibility of manufacturing machines in custom configurations and dimensions
