Heuft InLine IR Empty Bottle Inspector (2013)

Heuft EBI (Leerflascheninspektion)

Condition: used, Year of construction: 2012, Overview  This empty bottle inspection machine was manufactured in 2012 by German company HEUFT. The Glas InLine reflexx IR is designed for quality control of empty glass bottles in high-speed filling lines. The machine is still installed with energy disconnected, stopped since September 2025, and can be visited on request. It is described as in very good condition and available immediately. Technical data  Capacity: Up to 72,000 bph Formats: 330 ml Application: Empty glass bottle inspection Flow direction: Left to right Operating hours: 48,121 h Dujdpfx Aeyi Almjfwjp

Condition: used, Brewing plant with a wort output of 20 hl, consisting of the following components: 1. grist plant (Joh. Albrecht, 2000, 500 kg/h) with mill, malt hull, floor scales, grist conveyor and control cabinet 2. 3-device compact brewhouse with insulated stainless steel vessels with copper bonnets, spindle station and control cabinet 3. fermentation and storage cellar with 4 x fermentation vats (Joh. Albrecht, 1999, 25 hl), 1 x fermentation tank (Nerb, 2002, 50 hl, 0.99 bar), 5 x storage tank (Joh. Albrecht, 1999, 44 hl, 0.99 bar) and 6 x storage tank (Joh. Albrecht, 1999, 22 hl, 0.99 bar). All tanks with jacket cooling. 4th pressurised tank cellar with 2 x pressurised tank (Speidel, 2021, 86 hl, 3 bar), 1 x pressurised tank (INOX, 2018, 67 hl, 3 bar) and 4 x pressurised tank (Joh. Albrecht, 1999, 12 hl, 2.5 bar). All tanks with jacket cooling. 5. keg cleaning and filling system (BTB. Multimat MT/2, 1997, 17-20 kegs/h) 6. refrigeration system as ice water generator (Joh. Albrecht, 1999, cooling capacity 14.5 kW) 7. steam generator with soft water system (Jumag, 2000, 224 kg/h steam, oil-heated) 8. 40 hl hot water tank (Joh. Albrecht, 1999), heatable, with switch cabinet Interested in only part of the system? The system is offered as a consignment sale. A partial sale might be possible – feel free to contact us and submit your offer. Additional title: cast wort volume 20 hl, years of manufacture 1997-2001 Dodpfxswgc Udo Afwsup Cast wort capacity: 20 hl Features: Grist system; 3-device compact brewhouse; fermentation vats; fermentation, storage and pressurised tanks; keg system; refrigeration system; steam generator, warm water tank, CO2 liquid gas tank

Condition: used, Year of construction: 2009, Overview  This empty bottle inspector was built in 2009 by the German manufacturer Heuft and is still in operation until the end of October. The machine is available as it is being converted to a new inspection solution as part of a line modernization. The system includes the Heuft InLine reflexx Release 9 empty bottle inspector, the Heuft Spectrum SX TB 72 pre-sorter and the associated Heuft Gateway II for network connection. Interested parties have the opportunity to view the inspection line in operation by prior arrangement. Technical details Output: up to 72,000 bottles per hour Year of construction: 2009 Bottle types that can currently be processed: 0.33 l ale / green / crown caps 0.33 l ale / brown / crown cap 0.50 l NRW / brown / crown cap 0.50 l NRW / clear / screw cap 0.50 l Euro / brown / crown cap 0.33 l Krombacher-Bügel / brown / with embossing 0.50 l swing top / brown Control functions: Pre-sorting (Heuft Spectrum SX TB 72): Bottle shape Bottle height Inspection (Heuft InLine reflexx Release 9): Side wall inspection (inlet & outlet) Mouth & thread inspection Bottom inspection Residual liquid detection (IR/HF) Label residues in the neck area Test bottle detection Scope of delivery Heuft InLine reflexx Release 9 Heuft Spectrum SX TB 72 (pre-sorting) Heuft Gateway II (network connection) Rejection table and piece of infeed and outfeed conveyor Rejection of defective bottles Dusdpswr Aadsfx Afwop

Condition: used, Year of construction: 2006, Overview  The Heuft InLine TI 60 BFS2-r is an inspection system for empty PET bottles that was manufactured in 2006. With a maximum output of 36,000 bottles per hour, the machine is ideal for the efficient inspection and quality control of empty bottles in filling lines. The empty bottle inspector is equipped with several rejections and a wide range of accessories. Technical details  Output: Up to 36,000 bottles/hour Location: Germany Installation location: In front of the filler Immediately available Inspection functions  Bottom inspection: 1st bottom-IN-r Mouth inspection: Mouth-IN-r Side wall inspection: 1. sidewall-IN-r 2nd side wall IN-r Side wall with double resolution-r Support ring inspection: PET-r Abrasion inspection: RefPet Abrasion-r Ventslot inspection: RefPet Ventslot-r Stress crack detection: Stress Crack Detection-r Residual liquid detection: IR Rejection and adjustment options  Rejection: mono-X, DELTA-K-X Inlet control: mono-X Height adjustment: For rejections Cross adjustment: For rejections Accessories  Height-adjustable transport belts Cooling units for base housing and side wall Mouth outlet Dedpfx Afsu Scr Eswsup

Condition: good (used), Year of construction: 1994, Fillerblock, make Nagema, type: Varifill 40/10K/10PP, for 12.000 bph, with 40 filling valves, with 10-head crown capper and 10-head screw sealer (for MCA 28 caps), with double pre-evac, runs on 0,33 lt Longneck- and 0,5 lt NRW-bottles, direction: left->right, Siemens S5 control, built 1994 Duedpfen D Hm Sex Afwop L: 4.000 mm, W: 2.700 mm, H: 2.800 mm

Condition: used, Year of construction: 2012, Overview The Heuft InLine IXs reflexx is an empty bottle inspector for quality control in filling lines. The machine was commissioned in May 2012, is in very good condition and is ready for use at short notice. Technical details  Output: Up to 46,000 bottles/hour Control system: Heuft Synchron TX Network: Heuft Hlan, incl. gateway Licensing: 5 type licenses Equipment: Software wizard for troubleshooting and container changeover Availability: Ready for use at short notice Missing components Thread blow-off (must be added if required) Controls  Monitoring of the incoming bottle flow (optional) Output of a stop signal in the event of incorrect bottle dimensions Inspection of the bottle base, mouth sealing surface and thread Inspection of the inner and outer side wall Detection of conductive liquids (e.g. lye) and residual liquids (oils, paints) using IR technology Rejection of faulty containers or output of a rejection signal Scope of delivery  Spectrum TX conveyor control unit Measuring bridges for inlet control and rejection with height adjustment 2 x Delta K rejection units Air conditioning unit Various spare parts (pulleys, belts) Documentation and training documents (German) Transponder for test bottles Dsdpfsu Scr Sjx Afwjup

Condition: used, Year of construction: 2011, Overview  This Heuft Glas InLine reflexx IR is an inspection machine for empty bottles, designed for quality control in filling lines. The machine has a maximum output of 46,000 bottles per hour and was originally delivered in December 2011. It is in very good condition and ready for use at short notice. The flow direction is from left to right and it is equipped with a Secomak blower instead of a compressed air blow-off system. Technical details  Output: Maximum 46,000 bottles/hour Flow direction: Left to right Equipment: Two triggers Secomak blower Transponder recognition for RFID test bottles Rejection monitoring Heuft HLAN network (can be retrofitted as an option) Two-way rejection Delta K to the right Four type licenses Delta K tripods for belt height of 1130 mm Two fluids for lye detection Missing components Infeed control (must be added if required) Thread blow-off (must be added if required) Documentation (not available, can be replaced) Controls  Monitoring of the incoming bottle flow (optional) Output of a stop signal if bottles are too high, too wide or lying down Inspection of the bottle base Inspection of the mouth sealing surface Inspection of the thread Inspection of the inner and outer side wall Detection of conductive liquids (e.g. lye) Detection of residual liquids (e.g. oils, paints) using IR technology Rejection of faulty containers or output of a rejection signal Monitoring of the rejection process Dujdpfxou N Snke Afwep

Condition: used, Year of construction: 2019, Overview  This semi-automatic bag filler was manufactured in 2019 by Spain-based Cartobol. The machine is available for sale because the owner purchased a more advanced model to improve production. It is available promptly. Technical data  Capacity: Up to 600 bags/h (3L) 510 bags/h (5L) 390 bags/h (10L) 360 bags/h (15L) 300 bags/h (20L) Formats: 3L – 20L Bag-in-Box (individual and web bags) Dimensions: 0.73m x 0.93m x 1.85m Weight: 156 kg Pressure: Min. 6 Bars Voltage: 220V Intensity: 6 A Construction: Stainless steel frame and rollers, mobile on wheels Filling system: High-precision electromagnetic flowmeter Pump: Stainless steel centrifugal pump (8,000 L/h) Control: PLC with 7" touch screen Features: Automatic CIP cleaning system Optimized filling with load cells Fast format change Low air content inside bags Dedjwi Txljpfx Afweup

Condition: ready for operation (used), A Seitz filter machine including a Schenk dosing device for beer production is available. 1) Kieselguhr frame filter Seitz Orion 60, max. throughput capacity: 70hl-80hl/h, effective throughput capacity: approx. 45hl/h, max. total filtration capacity: approx. 600hl, pressing device: 2-stage planetary gear, number of plates: 36, number of end plates: 2, plate dimensions X/Y: 600mm/600mm, pipe diameter: 50mm, nominal width: NW50, machine dimensions X/Y/Z: approx. 3800mm/1100mm/1400mm. 2) Dosing device Schenk DO-S120, year of construction: 1971, capacity: approx. 160l/h, high-speed capacity: approx. 320l/h, nominal width: NW50, pipe diameter: 50mm. Documentation available. On-site inspection is possible. Duedewd Talspfx Afwjp

Condition: ready for operation (used), Bottle formats: 0.125/ 0.2/ 0.5/ 0.75l, bottle shape: various, operational hours: ca. 35,000h. Duodpjd H Sg Tofx Afwop
