Vertical CNC Machining Center

HOLZ-HER EVOLUTION 7405 4mat

Condition: new, Year of construction: 2024, functionality: fully functional, overall weight: 1,060 kg, total height: 1,800 mm, total width: 1,830 mm, total length: 2,000 mm, feed length X-axis: 3,000 mm, feed length Y-axis: 800 mm, feed length Z-axis: 50 mm, spindle speed (max.): 3,200 rpm, workpiece weight (max.): 25 kg, power: 2.2 kW (2.99 HP), air demand: 750 m³/h, operating pressure: 6 bar, number of spindles: 12, empty load weight: 975 kg, warranty duration: 12 months, Easy programmamble through-feed boring machine with touch-easy-smart software, 3 controlled axis X,Y,Z, also performing grooving operations (optional) and working from above Vacuum panel feeding Machine manufactured according to EC standards STANDARD EQUIPMENT HEAD UNIT Kdsdpfxju U Hgie Aayek Independent spindles N.7 vertical N.1 double horizontal -spindle TH1 (X axis) for back/ forth drilling Manual SIDE-ALIGNER PANEL EDGE-READER for perfect panel joints Teleservice Software Dust-collection nozzle Wokring table with GENTLE BRUSHES to avoid storage of dust and shavings. Working process can be in a cycle or back to the operator HARDWARE & SOFTWARE 12" touch-screen - NO TEXT System, patented by Maggi USB and Ethernet ports for file uploading, on-line assistance and system upgrades System based on Linux Kernel Up to 1.000 working programs storable Package: on a wooden pallet (2200x2050x160 mm - Kg 123)

Condition: used, Year of construction: 2018, total height: 2,200 mm, total length: 4,550 mm, total width: 2,200 mm, Empty weight: 3.000 kg - Year: 2018 - Documentation available: No - CE marking present: Yes - CE certificate present: Yes - Serial number: AH00000267 - Number of milling spindles [pcs.]: 1 - Type milling table: Beam table - Drilling unit present: Yes - Saw unit present: Yes - Safety feature: Enclosed fence - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Main motor power [kW]: 2.2 - └ Connection diameter [mm]: 33 - Working range X [mm]: 3050 - Working range Y [mm]: 1250 - Z-axis working range [mm]: 130 - Transport dimensions: 4550mm x 2200mm x 2200mm (l x w x h) - Transport weight [kg]: 3000kg - Transport packages [pcs.]: 3 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Kjdpexn S H Njfx Aayjdk Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: ready for operation (used), Year of construction: 2019, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,670 mm, travel distance Z-axis: 500 mm, number of axes: 4, spindle motor power: 12,000 W, spindle speed (max.): 24,000 rpm, This 4s FORMAT4 Profit H200 13.33 was manufactured in 2019. It features a CNC portal machining center with a working area of 4000 mm in the X-axis and 1670 mm in the Y-axis. The machine is equipped with an electrospindle power of 12 kW and a tool magazine with 12 positions. If you are looking to get high-quality wood machining capabilities, consider the FORMAT4 Profit H200 13.33 machine we have for sale. Contact us for further details. • Working field (max panel size) • X: 3300 mm • Y: 1280 mm • Z clearance: 250 mm • Spindle • Tool interface: HSK F63 • Rated power at: approx. 12,000 rpm • Cooling: Air-cooled • Rotation: CW / CCW • Tool magazine • Linear tool magazine (side-mounted): 12 positions • Additional linear magazine on gantry: 4 positions • Max. tool diameter: 250 mm • Max. tool length: 300 mm • Drilling unit • Model: DH 24 6H 2S • Vertical spindles: 18 (12 in X, 6 in Y) • Horizontal spindles: 6 (4 in X, 2 in Y) • Max. drill length: 70 mm • Max. tool diameter: 10 mm • Grooving saws: 2 (X and Y) • Max. saw diameter: 120 mm Kdedpfxsyi U Els Aayek • Max. speed: 6,000 rpm • Vacuum table • 6 consoles (instead of 4) • Dual-circuit vacuum system • Vacuum cups height: 100 mm • Pneumatic console locking • Adjustable side stops (Y-axis) • Axis system • X-axis: Rack and pinion drive • Y/Z-axis: Ball screw drive • Linear guideways on all axes • Central automatic lubrication • Control and software • CNC control with CAD/CAM software • 3D simulation preview • DXF import capability • Parametric programming • Remote service package (internet-ready)

Condition: used, Year of construction: 2014, No. 01 Homag Weeke machining center Mod. BMG 111/45/12/K Usable working area with electrospindle 4500 x 1550 mm Usable working area with all units 4500 x 1250 mm Boring head with 12 vertical spindles and 4 + 2 horizontal spindles, saw unit 0/90 Electrospindle 9 kW 12 Hp HSK, rotation speed from 1250 to 24000 rpm 4th axis for aggregate rotation 8-position circular tool changer 8-position lateral tool changer Lateral pick-up tool changer Special FLEX 5 HIGH PERFORMANCE unit for drilling, milling, cutting Automatic tilt adjustment 0 – 100 degrees Chip conveyor discharge to the right 8 Schmalz work tables, 16 suction cups Suction cup positioning laser 2 vacuum pumps Kdedpfxeyarwto Aayok POWERTOUCH control system Woodwop dxf import Teleservicenet assistance CE compliant Year 2014

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, power: 10 kW (13.60 HP), input voltage: 400 V, type of input current: AC, cutting height (max.): 133 mm, saw blade diameter: 400 mm, tilt adjustment saw blade: 45 °, rotational speed (min.): 3,500 rpm, total length: 4,500 mm, Equipment: documentation/manual, saw blade guard, scorer, We are offering this very well-maintained Felder Format-4 Kappa 450 x-motion panel saw, year of manufacture 2023. Manufacturer: Felder Model: Format-4 Kappa 450 x-motion Year of manufacture: 2023 Ksdpfxoytpzpo Aayjdk If you have any questions or require further information, please feel free to send us a message or call us.

Condition: excellent (used), Felder kappa 550 panel saw, format 4 Sliding table 320 cm, Blade tilt and height adjustment motorized, Right-hand fence motorized adjustable up to 1600 mm, Main motor 7.35 kW, Kjdpfxex Swzve Aayedk Max blade diameter 500 mm Used machine, in very good condition.

Condition: excellent (used), Machining Centre HOLZ-HER EVOLUTION 7405 -used- Continuous feed machining, 4-sided edge routing possible, integrated vacuum pump, automatic positioning of suction cups, hardened, dust-protected prism guides, ball screw drives on all axes, network card for remote maintenance, integrated control cabinet, control cabinet cooling with heat exchanger, manual control device, XL drilling head, saw unit for grooving in the X direction, pick-up tool changer, automatic central lubrication. ----- Technical Specifications ----- Min. workpiece length X: 200 mm, Min. workpiece width Y: 70 mm, Min. workpiece thickness: 8 mm, Max. workpiece length X: 3,200 mm, Max. workpiece width Y: 920 mm, Max. workpiece thickness: 70 mm, Machine control software: CAMOUS HOPS, Main spindle motor power: 6.5 kW, Main spindle speed: 1,000 - 18,000 rpm, Main spindle interface: HSK-F63, Drilling unit motor power: 1.7 kW, Drill spindle interface: M10, H7 fit 11 mm, Number of vertical drilling spindles: 13 pcs, Kdodpfxjyrp Sro Aaysk Number of horizontal double drill spindles in X direction: 2 pcs, Number of horizontal double drill spindles in Y direction: 1 pc, Saw blade diameter (saw unit): 120 mm, Number of tools in changer: 6 pcs, Extraction port diameter: 2 x 120mm + 1 x 140 mm, Required air flow rate: 4,100 m³/h, Required static vacuum: 2,500 - 3,000 Pa, Required air velocity: 30 m/s, Compressed air connection: 6 bar, Compressed air consumption: 300 l/min. Quality information: - complete basic cleaning - electrics checked - pneumatics checked - set according to manufacturer’s specifications - ready for immediate use

Condition: new, Year of construction: 2025, functionality: fully functional, feed length X-axis: 2,800 mm, feed length Y-axis: 1,000 mm, feed length Z-axis: 50 mm, feed rate X-axis: 140 m/min, feed rate Y-axis: 90 m/min, feed rate Z-axis: 50 m/min, workpiece length (max.): 2,800 mm, workpiece width (max.): 1,000 mm, control type: CNC control, High-performance CNC drilling center KDT KD-610NHZ for six-sided machining of workpieces. Immediately available from stock. Upper and lower drilling units. Precise machining and high speed. Ideal for carcass furniture production. The machine can be inspected by appointment. Ksdpfoymz Alsx Aayjdk

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, Carriage length: 3800 mm Scoring unit Electric adjustment of blade and scorer height and angle Electric positioning of right fence Touchscreen digital control panel Kedpfxsymwy Te Aayjdk Table equipped with additional blade switches Maximum blade diameter: 550 mm Total power: 7.35 kW Year of manufacture: 2014 Power supply: 380 V

Condition: as good as new (ex-display), Year of construction: 2025, Spindle tilting: Yes, 0 to 45° Height adjustment: Electric / Position control Swivel adjustment: Electric / Position control Milling stop adjustment: Electric / Position control Milling jaw adjustment: Manual / Handwheel Ksdpewhuvcofx Aayodk Height display: Digital display Swivel angle display: Digital display Milling stop display: Mechanical counter Aigner integral stop: Yes Milling spindle diameter: 30 mm Speeds: 3000, 4500, 6000, 7000, 10000 Motor power: 7 kW Motor brake: Yes, automatic Extraction connection: 2 x 120 mm Machine length: 2599 mm Machine depth: 900 mm Weight: 655 kg
