Used Wmw Universal Tool Milling Machine for sale (68,378)

Condition: used, Year of construction: 1992, functionality: unexamined, Used CNC tool milling machine, Fehlmann Picomax 51-CNC 3, year of manufacture 1992. Last documented inspection: 03/31/2023. Technical data: - Travels X/Y/Z: 420 / 240 / 120 mm - W-axis: 450 mm - Table: 730 x 280 mm - Distance from table to spindle: 0–560 mm - Maximum table load: 75 kg - Spindle power: 4 kW - Torque: 45 Nm - Speed: 50–9,000 rpm - Tool changer: SF32 - Feed rate X/Y: 1–7,200 mm/min - Feed rate Z: 1–3,600 mm/min - Drilling capacity in steel: up to 20 mm - Thread cutting: up to M20 - Milling: up to 20 mm - Weight: approx. 1,300 kg - Connection: 3 x 380 V / 50 Hz, 10 kW - Positioning accuracy: 0.01 mm on 400 mm Crodpfx Apjzrnymstjg - Repeatability: 0.002 mm Extensive accessories and documentation as shown in the photos. Location: 65618 Selters, Germany.

Condition: used, Universal Milling Machine DECKEL FP1 Travel X: 300 mm Travel Y: 150 mm Travel Z: 300 mm Horizontal + vertical spindle Cone CM4 DECKEL Spindle speed: from 40 to 2000 RPM Horizontally tiltable head Spindle motor: 2 speeds Motor: 1,5 kW Feeds: X - Z auto / Y manual Crjdpfezqulaox Aptog Supplied without table only with one 4 concentric jaws Ø 140 mm Voltage: 380 V Width: 1200 mm Depth: 1200 mm Total height: 1600 mm Weight: approx 900 KG

Condition: used, Year of construction: 2018, total height: 4,000 mm, total length: 5,100 mm, total width: 3,800 mm, overall weight: 20,000 kg, POS POSmill H 800 U – 5-axis machining center The machine is designed as a 5-axis machining center and features a swivel axis with a range of -120° to +120°, as well as a rotary table with a continuously rotating 360° C-axis. A separate A-axis is not available. The working area is realized by a high-quality Kessler rotary table with a diameter of 800 mm. The machine is not equipped with a pallet changer. A key highlight is the 96-position tool changer, making the machine ideal for series production as well as complex machining tasks. In combination with the integrated through-spindle coolant system (IKZ) with 50 bar, the machine is well suited for demanding applications in toolmaking and the automotive industry. Operating data: Control ON: approx. 25,280 h Machine ON: approx. 24,730 h Program run: approx. 9,150 h Spindle hours: approx. 8,555 h 5-axis machining: Yes Spindle speed: 18000 - rpm Travel Y-axis: 820 - mm Dimensions (LxWxH) approx.: 5100 x 3800 x 4000 mm Weight approx.: 20,000 kg Control: Heidenhain ITNC 530 Travel Z-axis: 600 - mm Crsdpfxoy An A Es Apteg Travel X-axis: 670 - mm Year of construction: 2,018 Condition: in working order Terms of payment: 100% prepayment before pick-up Terms of delivery: From foundation under power: Yes

Condition: used, x-travel 560 mm y-travel 500 mm z-travel 450 mm table surface area 900x520 mm Codpfoyutuvox Apterg turning speeds 4000 U/min tool taper SK 40 Control Heidenhain type TNC 355 elec. weight of the machine ca. 2,7 t The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, CNC universal tool milling machine DECKEL, Type FP 4 MA Machine No. 2204-1734 Serial No. 25842 Year of manufacture 1989 CNC path control: GRUNDIG Contur 2 Travel distances X: 485 mm, Y: 385 mm, Z: 380 mm Distance table to milling spindle max. 480 mm Table size 800 x 460 mm Spindle mounting ISO 40 Spindle speed 63 - 3150 rpm, 18 steps Feed rate max. 2000 mm/min Distance table to milling spindle max. 480 mm Vertical quill travel 80 mm Horizontal quill travel 150 mm Credpfszwmc Rox Aptjg Main spindle drive 3.7 / 4.4 kW Power connection 400 volts, 50 Hz, 13 kW - CNC path control: GRUNDIG Contur 2 with TFT screen - Hydro-mechanical tool clamping - Swiveling control panel - Handwheels for each axis - Rigid angular table - Coolant system in the machine base - Central lubrication - Control cabinet located next to the machine, L x W x H 800 x 750 x 1150 mm Space requirement L x W x H 2400 x 2300 x 2000 mm Weight approx. 2400 kg Good condition

Condition: new, Year of construction: 2024, functionality: fully functional, - Swiveling control panel - CNC control SIEMENS 828D - Motor for horizontal and vertical spindle - Feed motors with inverter - Ball screws for X/Y/Z axes - Automatic 2-stage gear box for spindle speeds - 1 long milling mandrel 27 mm - 3 reducing sleeves (MK1, MK2, MK3) - Pneumatic hydraulic clamping system for the vertical spindle - Spindle protection with safety switch - Protective cover in the work area with electrically secured doors - Counterholder for horizontal milling - LED work light - Automatic central lubrication system - Safety handwheels for X/Y/Z axes - Coolant system with chip tray - Guideway covers - Base plates and adjusting screws - Operating tools - Technical documentation - CE version - Colors: * RAL 7024 - Graphite gray * RAL 7035 - Light gray Technical data: Fixed angle table: - Dimensions of the work surface: 1,000 x 500 mm - T-slots: Number / width x distance: 8 pieces / 14 x 63 mm - Max. table load: 250 kg Vertical table: - Dimensions of the work surface: 1,200 x 250 mm - T-slots: Number / width x distance: 3 pieces / 14 x 63 mm Travel paths: - Axis travel paths: automatic/manual - Longitudinal (X): 600 mm - Transverse (Y): 500 mm Crodpfsvupa Rjx Aptsg - Vertical (Z): 400 mm Feed rates: - Control: stepless - Range (X,Y,Z): 0 – 2,000 mm/min. - Rapid traverse - X,Y,Z axes: 5,000 mm/min. - Rapid traverse - Z axis: 4,000 mm/min. Horizontal spindle: - Tool holder: DIN 2080 / ISO 40 - Speed range (2 levels): 0 – 3,200 rpm. Vertical milling head: - Tool holder: DIN 69871 / / ISO 40 - Speed range (2 levels automatic): 0 – 3,200 rpm - Head swivel: +- 90° - Distance spindle nose/angle table: min/max.: 70 – 470 mm - Distance spindle center to column: min./max.: 160 / 660 mm Motors: Main drive power: 7.00 kW Feed motor power X-Y-Z: 2.85 KW Dimensions and weight Dimensions (W x D x H): 2,850 x 1,950 x 1,900 mm Weight: 1,950 kg

Condition: used, Year of construction: 1985, x-travel 710 mm Credpfx Apotqqtbjteg y-travel 600 mm z-travel 500 mm NC-rotary table 630 mm spindle taper SK 40 spindle turning speed range 18 - 6300 U/min control DIALOG 4 feed 2 - 3600 mm/min rapid traverse 6 m/min table load max. 485 kg quill stroke 80 mm spindle drive 9,5 kW total power requirement 20 kVA weight of the machine ca. 4,6 t dimensions 3,8 x 2,24 x 2,35 m Accessories: vertical head with hydr. tool clamping and quill retraction, electron. handwheel, coolant

Condition: excellent (used), machine/vehicle number: 28652, table mounting size: 250 x 800 mm x-axis: 400 mm Credpfx Apoh D Rzustog y-axis: 175 mm z-axis: 450 mm spindle retainer: ISO 30 spindle rotations: 50-2000/50-3400 rpm operating voltage: 380 V total energy requirement: ca. 2,5 kVA kW space needed: 1200 x 1000 x 1600 mm weight: ca. 1100 kg

Condition: used, Year of construction: 1985, x-travel 485 mm y-travel 385 mm z-travel 380 mm table surface area 800 x 460 mm Credetqqllspfx Aptog spindle taper SK 40 control CONTOUR 1 spindle turning speed range 50 - 2500 U/min feeds 10 - 1000 mm/min rapid traverse 2 m/min table load capacity 600 kg quill stroke 80 mm total power requirement 7,5 kW weight of the machine ca. 2,0 t dimensions 2,4 x 1,7 x 1,98 m Acc.: vertical head with hydr. tool clamping and quill retraction, solid table, coolant - movement of X/Y/Z also possible via handwheels -

Condition: used, Year of construction: 1989, x-travel 600 mm y-travel 450 mm z-travel 400 mm table-size 850 x 440 mm spindle taper SK 40 Crodpfx Aey Nnw Noptsg control HEIDENHAIN TNC 355 ATC 32 Pos spindle turning speed range 20 - 4000 U/min spindle drive 5,9 kW quill stroke 80 mm feeds longditudinal/cross/vertical 1 - 2000 mm/min power feed x/y/z 7200 N rapid traverse longitudinal and cross 10 m/min rapid traverse vertical 10 m/min total power requirement 12 kW weight of the machine ca. 3 t Acc.: NC-dividing unit (=4th axis) make WALTER with 3-jaw chuck 160 mmø, vertical head with hydr. tool clamping and quill retraction, solid table, various tool fixtures, electron. hand wheel, coolant

Condition: used, MAHO MH 600 P Tool Milling Machine Tool Milling Machine MAHO Type/Model MH 600 P Control Heidenhain TC 135 Condition Used Technical Data Travel (X / Y / Z): 500 mm / 400 mm / 400 mm Quill stroke: 80 mm Table dimensions: 720 mm x 140 mm Max. table load: approx. 500 kg T-slots: 8 pieces (spacing 54 mm) Tool holder: SK 40 / ISO 40 Spindle speed range: 40 to 2,000 rpm Crjdpfjzxhfvjx Aptjg Spindle drive power: 4.0 kW Working feed rate continuously adjustable: 5 to 500 mm/min Rapid traverse speed (X / Z): approx. 1.2 m/min Rapid traverse speed (Y): approx. 0.8 m/min Connection voltage: 380 V / 50 Hz Machine weight: approx. 1,450 - 1,900 kg Space requirement (L x W x H): approx. 1.8 m x 1.5 m x 1.9 m

Condition: used, x-travel 400 mm Cedpjxv D Uzsfx Aptjrg y-travel 400 mm z-travel 300 mm rapid traverse 1,2 m/min feed range 5 - 500 mm/min creep feed 1:100 tool taper ISO 40 stroke v60 h70 mm table - universal ca. 620 x 320 mm table vertical adjustable 350 mm weight of the machine ca. 1200 kg Machine was used in a public facility and is in good condition. Machine can be viewed under power by prior appointment

Condition: repair required (used), Machine number: 1464 Type / Model: FUW 250/IV Travel ranges x-y-z: 400 - 220 - 400 mm Table: 630 x 350 mm Table clamping area: 700 x 300 mm Speed range: 45 to 2,240 rpm Spindle connection: SK 40 Feed rate range, longitudinal: 6.3 to 1,250 mm/min Feed rate range, transverse: 6.3 to 1,250 mm/min Power consumption: 7.4 kW Credpfed Hl Stex Aptjg Accessories / Equipment: Vertical head Condition: 2 controllers defective Note: Machine repair EUR 2,000 Weight: 1.45 t Dimensions: 1,500 x 1,600 x 1,800 mm

Condition: used, CNC Milling Machine DECKEL Type FP 3 A Tool-tool milling machine with handwheels, also for conventional operation Serial No. 2206 - Built in 1982 GRUNDIG CNC 2101 CNC control system Travel paths X: 490 mm, Y: 300 mm, Z: 340 mm Cedpfov R E Rdex Aptorg Table size 705 x 425 mm Spindle mount SK 40 Quill stroke 100 mm Spindle speed 25 - 2500 rpm, 21 steps Feed rate 5 - 500 mm/min, continuously variable Rapid traverse speed 1200 mm/min Spindle motor power: 2/4 kW, pole-changing Power supply: 380 V, 50 Hz - GRUNDIG CNC 2101 CNC control system - Mechanical handwheels for all three axes - Universal tilt-and-turn table - Vertical milling head tilts and is manually adjustable by 200 mm - Hydro-mechanical tool clamping - Coolant system in the machine base - Protective enclosure at the front and sides with three hinged doors - Control cabinet adjacent (L x W = 600 x 430 mm) Space requirement: L x W x H: 1900 x 1700 x 1950 mm Weight: 1700 kg (machine 1540 kg + electrical cabinet 160 kg) Very good condition

Condition: used, Year of construction: 1971, x-travel:450 mm y-travel:320 mm z-travel:450 mm Crjdpfx Apjiv Tf Hotsg table-size:950 x 300 mm spindle turning speed range:39-2320 U/min spindle taper:SK 40 power capacity - milling spindle:2,5 kW total power requirement:2,8 kW weight of the machine ca.:1,3 t dimensions of the machine ca.:1,4 x 1,3 x 1,8 m with vertical head, spindle quill, swivelling horizontal spindle, variable adjustable feed for all 3 axes, coolant device, machine light, chip pan, emergency cut-off

Condition: used, machine/vehicle number: 1621, x-travel:800 mm y-travel:300 mm z-travel:400 mm table-size:1000 x 440 mm Tool taper:SK40 spindle speeds:40 - 2000 U/min Crodpfx Apoh Ra Nqotog speed steps work spindle:18 spindle speed max.:( 6000 Possible by interchanging the Belt U/min feed range:10 - 500 mm/min feed steps:18 total power requirement:3 kW weight of the machine ca.:2,1 t dimensions of the machine ca.:1600x1550x1930 m The models FP3L has a tilting Spilndle Head can be swiveled 90° left or right direction for vertical and horizontal machining application. - With Rigid Angular Table: 1000 x 440 mm (6 nos of "T-Slots" with of 12mm width) - With 2 Step Dial Configaration for Quick changing on Speed and Auto Feed - Quick Lever for rapid traverse movement on all axis - Universal Table , Separate power cabinet, and Chip tray

Year of construction: 1989, condition: ready for operation (used), Weight: 1.5t, operating hours unknown, with documentation, machine vices and fixtures are available as accessories, the machine ran in one shift operation and was serviced regularly. An inspection on site is possible. Crodpfx Ajzbb Spspteg

Condition: ready for operation (used), A CNC universal tool milling machine Hermle is available. Travel X/Y/Z: 700mm/550mm/500mm, table dimensions X/Y: 1000mm/500mm, quill stroke: 100mm, tool holder: SK40, spindle speed: 3150rpm, feed rate: 2m/min, rapid traverse: 5m/min, max. workpiece weight: 400kg. Machine dimensions X/Y/Z: approx. 3900mm/3300mm/2100mm, weight: approx. 3300kg, control: Heidenhain TNC 150. An on-site inspection is possible. Crjdpfxjxwcu Ae Aptjg

Condition: good (used), Year of construction: 2001, Power: 4.5 kW Crjdpozvnldsfx Apteg Drilling capacity: 30 mm End milling: 25 mm Motor power: 0.85/1.5; 2.2 kW

Year of construction: 1990, condition: excellent (used), Mikron WF2S tool milling machine with a 3-axis Elesta-Visulesta digital display. Fixed angular table, SK 40 spindle mount. In very good, operational condition, from an institute. The machine can be demonstrated under power by arrangement. Crjdpsg Nw Rzsfx Apteg

Condition: excellent (used), Year of construction: 1982, functionality: fully functional, Universal milling machine Deckel FP1 with 3-axis digital display, Heidenhain active control, and continuously variable feed. Technical data: >> Year of manufacture: 1982, Machine no. 2101-1995 >> Fixed angular table >> Speed: 40 - 2000 rpm >> Continuously variable feed in 2 axes >> Rapid traverse in 2 axes >> Drive power: 1.5 / 1.9 kW >> Spindle brake >> Travels X/Y/Z: 300/160/340 mm >> Vertical milling head, adjustable by 100mm on the spindle head Crodezrn Tyjpfx Aptsg >> Vertical quill and horizontal quill - SK40 >> Clamping system S20x2 >> Weight approx. 800 kg Accessories and equipment: >> 3-axis digital display Heidenhain >> Coolant system >> Operating manual, parts list About the machine: Offered is a Deckel FP1 universal milling machine in very good original condition. The machine has very little backlash and all spindles move easily. Even at maximum speeds, the milling machine runs smoothly. The FP1 was in a training workshop at a university and was used very little. This newer FP1 model has continuously variable feed in two axes, and the machine also has rapid traverse in these axes. A major advantage is the active 2-axis digital display. With this Heidenhain positioning control, you can enter dimensions that the machine will automatically approach. An oil change has been carried out. Mechanically and electrically inspected. The Heidenhain digital display makes working easier and even more precise. Take advantage of the opportunity to inspect and test this machine on-site while it is powered up.

Condition: used, NC universal tool milling machine MAHO type MH 700 P with HEIDENHAIN TNC 121 linear control . 71247 Circuit diagram no. ET 226 Built in 1979 Travel paths X: 600 mm, Y: 400 mm, Z: 400 mm Table size 900 x 500 mm Spindle mount ISO 40 Spindle speed 40-2000 rpm, 18 steps Feed rate X, Z-axis 1 - 600 mm/min, continuously variable Feed rate Y 1 - 300 mm/min, continuously variable Rapid traverse X, Z-axis 1.5 m/min Rapid traverse Y-axis 0.75 m/min Vertical spindle travel 80 mm Horizontal spindle travel 80 mm Spindle drive 4 kW Power supply 380 V, 50 Hz, 10 kW - HEIDENHAIN TNC 121 NC linear control - Vertical milling head with automatic Quill feed - Hydro-mechanical tool clamping - Coolant system in the machine base - Universal built-in rotary table, swiveling and tilting via threaded spindles +/- 30° - Universal built-in rotary table with manual transverse adjustment of 200 mm - Universal built-in rotary table with 360° rotation function and hydraulic clamping - Rotary table with direct indexing 72 x 5° and indirect indexing via hole plate 1:120 = 1 rev = 3° Credpfx Ajwd Szbjptsg - Pivoting control panel - Central lubrication system - Electrical diagram Space requirement L x W x H 2000 x 1650 x 2250 mm Weight approx. 2800 kg Good condition

Condition: used, Year of construction: 1987, Universal CNC Milling Machine CNC MAHO MH 400 E Travel X: 400 mm Travel Y: 375 mm Travel Z: 250 mm Numerical Command CNC PHILIPS 432 Table: 700 x 270 mm Cone: SA40 Spindle speed: from 80 to 4000 RPM Year of construction: 1987 Central lubrication Cedpfx Apjzm Spzoterg Manually swivel head Supplied with doc + machine parameters Voltage: 380 V Width: 2200 mm Depth: 2000 mm Total height: 2000 mm Weight: approx 1,5 T

Condition: good (used), Year of construction: 2004, Universalfräsmaschine mit Streckensteuerung HEIDENHAIN TNC 124 mech. Handräder drehbarer Kipptisch +- 45°, hydr. Werkzeugspannung, Crjdpfeigm Tcjx Aptjg Halbkabine Kühlmittelbehälter Handbuch Technische Details: x-Weg 600 mm y-Weg 400 mm z-Weg 400 mm Spindeldrehanzahl 63 - 3.150 1/min Vorschub stufenlos 12-3000 / 6-1500 (Z) mm/min Pinolenhub 100 mm Kopf schwenkbar +/- 90° Spindelaufnahme ISO SK 40 Aufspannfläche 630 x 400 mm Gesamtleistungsbedarf 8 kW Maschinengewicht ca. 2,2 t Raumbedarf ca. 2 x 1,9 x 1,95

Condition: not inspected (used), Please see technical details on photo. Codpjhvzxzjfx Aptjrg
