Truck mounted crane

MAN 26.470 6x4-4 Hydrodrive Fassi Kran F545 Jib

Condition: new, mileage: 400 km, power: 345 kW (469.07 HP), overall weight: 26,000 kg, fuel type: diesel, color: white, axle configuration: 3 axles, gearing type: automatic, emission class: euro6, Year of construction: 2025, Equipment: ABS, air conditioning, crane, electronic stability program (ESP), parking heater, soot filter, Vehicle: MAN TGS 26.470 6x4H-4 BL CH HydroDrive • Vehicle type: Flatbed truck and chassis, suitable for crane mounting • Chassis color: Pure White RAL 9010 • Cab color: Graphite Black RAL 9011 Engine • Type: MAN D2676 LF85 • Power: 346 kW (470 hp) • Torque: 2,400 Nm • Emission standard: Euro 6d Transmission • MAN TipMatic 12-speed automatic • Reinforced single-plate clutch (430 mm) • Driving modes: Efficiency, Manoeuvre, Idle Speed Driving, Rock-Free Chassis • Wheelbase: 3,900 mm • Rear overhang: 1,950 mm • Main axle distance (between rear and trailing axle): 1,350 mm • Frame height above cab: up to 4,000 mm • Frame longitudinal member thickness: 8 mm • Frame end: straight Axles • Front axle: 9,200 kg, steered, HydroDrive without through drive • Rear axle: 13,000 kg, HY axle, non-steered, non-driven • Trailing axle: 9,000 kg, steered, liftable, non-driven • Axle ratio: i = 3.70 Air Suspension • Electronically controlled air suspension (ECAS) on trailing axle • Automatic level control • Spring capacities: FA 9,500 kg / RA 13,000 kg / TA 8,000 kg Brakes • Electronic Braking System (EBS) • ABS, ASR • High-performance engine brake MAN EVBec (adjustable) • Disc brakes on all axles • Electronic parking brake Tyres and Rims • Front axle: 385/55 R22.5, steel rims 11.75x22.5 • Rear axle: Goodyear 315/70 R22.5, steel rims 9.00x22.5 • Trailing axle: Michelin 315/70 R22.5, Alcoa matte Cab • Type: FN, flexible, narrow, standard roof • Comfort seats: air-suspended, seat heating, armrest • Multifunction steering wheel • Central locking • Climatronic air conditioning • Lower comfort bed • Storage in seat console and compartments • Interior styling: Moon Grey • Sun blinds, tilting roof • Various storage compartments • USB ports • LED lighting technology Permissible Loads • Technical gross weight: 26,000 kg • Axle loads: FA 9,000 kg / RA 11,500 kg / TA 7,500 kg • Technical towing capacity: max. 30,000 kg Tanks • Fuel tank: 400 l • AdBlue tank: 60 l Dksdpfx Asxhadcehxsu Assistance Systems • ESP, ASR, cruise control • Emergency brake assist • Lane departure warning • Digital tachograph • Advanced navigation system (7 inch) • MAN SmartSelect Interfaces for Body Applications • Prepared for crane installation • Towing hitch: RINGFEDER type 4040G150A • Various electrical and pneumatic connections Special Features • HydroDrive: hydraulic front wheel drive for enhanced traction • Comfort features for driver • Factory interfaces and preparations for municipal, construction, and public authority applications as well as flexible superstructures ----FASSI Loader Crane F545RA.2 xe-dynamic Basic Unit • Type: F545RA.2 xe-dynamic • CE Directive EN 12999 HD5S2 compliant • Color: RAL 3020 Traffic Red, cylinders black Slewing Range • Continuous rotation Hydraulics • Double-acting hydraulic cylinders • Piston rods hard chrome-plated Articulating System • Double knuckle boom with PROLINK • Articulating arm can be over-stretched up to 15° Overload Protection • Electronic overload shutdown FX500 • FSC stability control • LMB II • Emergency stop and optical alarm Valves & Filters • Pressure relief and load holding valves • High-pressure filter • Separate hydraulic tank 180 l, with filter and oil cooler on the base Control • FASSI radio remote control RCH/RCS • Pressure value display • Danfoss D850 control block with 4 control valves • Emergency manual control Stabilizers • Hydraulically extendable on both sides • Stabilizer spread: 7.79 m Speed Control • Dynamic Control

Condition: new, mileage: 400 km, power: 345 kW (469.07 HP), overall weight: 26,000 kg, fuel type: diesel, color: white, axle configuration: 3 axles, gearing type: automatic, emission class: euro6, Equipment: ABS, air conditioning, electronic stability program (ESP), navigation system, parking heater, soot filter, Vehicle: MAN TGS 26.470 6x4H-4 BL CH HydroDrive Vehicle Type: Platform truck and chassis, suitable for crane installation Chassis Color: Pure White RAL 9010 Cab Color: Graphite Black RAL 9011 Engine Type: MAN D2676 LF85 Power: 346 kW (470 hp) Torque: 2,400 Nm Emission Standard: Euro 6d Transmission MAN TipMatic 12-speed automatic Reinforced single-disc clutch (430 mm) Driving Modes: Efficiency, Manoeuvre, Idle Speed Driving, Rock-Free Chassis Wheelbase: 3,900 mm Rear overhang: 1,950 mm Main axle spacing (between rear and trailing axle): 1,350 mm Frame height above cab: up to 4,000 mm Frame rail thickness: 8 mm Frame end: straight Axles Front axle: 9,200 kg, steered, HydroDrive without through drive Rear axle: 13,000 kg, HY axle, non-steered, non-driven Trailing axle: 9,000 kg, steered, liftable, non-driven Axle ratio: i = 3.70 Air Suspension Electronically controlled air suspension (ECAS) on trailing axle Automatic leveling control Spring load capacity: FA 9,500 kg / RA 13,000 kg / TA 8,000 kg Brakes Electronic Braking System (EBS) ABS, ASR High-performance engine brake MAN EVBec (adjustable) Disc brakes on all axles Electronic parking brake Tyres & Rims Dedpfx Aexhac Sehxjku Front axle: 385/55 R22.5, steel rims 11.75x22.5 Rear axle: Goodyear 315/70 R22.5, steel rims 9.00x22.5 Trailing axle: Michelin 315/70 R22.5, Alcoa matte finish Cab Type: FN, flexible, narrow, standard height Comfort seats: air-suspended, seat heating, armrest Multifunction steering wheel Central locking Climatronic air conditioning Lower comfort bed Storage in seat console and storage compartments Interior styling: Moon Grey Sun blinds, tilting roof Various storage solutions USB sockets LED lighting technology Permissible Loads Gross vehicle weight: 26,000 kg Axle loads: FA 9,000 kg / RA 11,500 kg / TA 7,500 kg Technical trailer load: max. 30,000 kg Tanks Fuel tank: 400 l AdBlue tank: 60 l Assistance Systems ESP, ASR, cruise control Emergency brake assist Lane departure warning Digital tachograph Advanced navigation system (7-inch) MAN SmartSelect Body Interfaces Prepared for crane installation Trailer coupling: RINGFEDER type 4040G150A Various electrical and pneumatic connections Special Features HydroDrive: hydraulic front-axle drive for increased traction Driver comfort features Factory interfaces and preparations for municipal, construction, and government applications as well as flexible body solutions ---- FASSI Loader Crane F545RA.2 xe-dynamic Base Unit Type: F545RA.2 xe-dynamic CE Directive EN 12999 HD5S2 compliant Colour: RAL 3020 traffic red, cylinders black Slewing Range Infinitely rotatable Hydraulics Double-acting hydraulic cylinders Piston rods hard-chromed Linkage System Double linkage system with PROLINK Articulated arm can be overextended up to 15° Overload Protection Electronic overload shutdown FX500 FSC stability control LMB II Emergency stop and visual alarm Valves & Filters Pressure relief and load-holding valves High-pressure filter Separate hydraulic tank 180 l with filter and oil cooler at base Control FASSI radio remote control RCH/RCS Pressure value display Danfoss D850 control block with 4 control valves Emergency operation Stabilizers Hydraulically extendable on both sides Support width: 7.79 m Speed Control Dynamic Control – load-dependent Additional Articulated Boom / Jib Type: L214 4x hydraulically extendable up to 10.30 m
